XRPlus IPC-100 User manual

Network Camera
IPC-100 User Manual
XRPLUS INCORPORATED
WWW.XRPLUS.CO.KR
[email protected].kr

IPC-100 User Manual
Safety Precaution
We appreciate your purchasing IPC series. Before installing the product,
please read the following with care.
Make sure to turn off the power before installing IPC-100.
Do not install under the direct sunlight or in dusty areas.
Make sure to use the product within the temperature and humidity specified in the
Do not operate the product in presence of vibrations or strong magnetic fields.
Do not put electrically conducting materials in the ventilation hole.
Do not open the top cover of the product. It may cause a failure or electric shock on
To prevent from overheating, make sure to keep the distance at least 10cm from the
Check for proper voltage before connecting the power.

specification.



the components.

ventilation hole.

-1-

IPC-100 User Manual
Table of Content
Table of Content..................................................................................................2
1. Introduction .....................................................................................................3
1. About User Manual..................................................................................3
2. Feature.....................................................................................................3
3. Product andAccessories.........................................................................4
4. Part Names and Functions......................................................................5
5. System Connections................................................................................6
2. Installation.......................................................................................................8
1. Connecting Network(LAN).......................................................................8
2. Connecting Audio.....................................................................................8
3. Connecting Serial Ports...........................................................................9
4. Connecting Sensor and Alarm.................................................................9
5. Connecting Power ...................................................................................9
6. Check if It Works......................................................................................9
3. System Operation ...........................................................................................9
1. Remote Video Monitoring....................................................................9
2. Initialization of IPAddress..................................................................10
4. Remote Configuration...................................................................................12
1. Using Internet Explorer..........................................................................12
2. IPC-100 Configuration...........................................................................13
2.1 System Configuration...................................................................13
2.2 Video Configuration......................................................................15
2.3 Audio Configuration......................................................................18
2.4 Network Configuration..................................................................19
2.5 Serial Port Configuration ..............................................................21
2.6 Event Configuration......................................................................22
2.7 Preset Configuration.....................................................................25
2.8 User Configuration........................................................................27
2.9 Camera Configuration ..................................................................29
-2-

IPC-100 User Manual
1. Introduction
1. About User Manual
The User Manual is to provide information on operation of the high quality Network
Camera, IPC-100. In this guide, information on installation, operation, configuration of
IPC-100 is written as well as how to trouble shoot in case problems arise.
2. Feature
IPC-100 is a network camera and a video and audio surveillance transmission system
based on IP network through LAN, ADSL/VDSL, and Wireless LAN.
Video
-High-quality compression algorithm, H.264
-Compression in various resolution: CIF, Half-D1, D1
-Wide range of video transmission rate: 32kbps ~ 4Mbps
-Various transmission mode: CBR, VBR
-Motion detection
Audio
-Multi-transmission mode: Uni-direction (IPC-100 -> Client PC or Decoder,
Client PC or Decoder ->IPC-100), Bi-direction
Network
-Static IP and Dynamic IP(DHCP, PPPoE)
-One to one and one to many connection
-Multicasting
-Automatic transmit rate control according to network condition
Serial Data
-One serial ports (RS-485)
-Data pass-through mode: Serial data communication between IPC-100 and
Decoder
-3-

IPC-100 User Manual
Sensor and Alarm
-Connections to external sensor and alarm devices
-Event Alarm
User Interface
-System status display utilizing OSD(On Screen Display)
-System configuration using Internet Explorer
Reliability
-Reliable embedded system
-System recovery utilizing dual watch-dog functions
3. Product and Accessories
IPC-100System UserManual
Power adaptor and cable CMS S/W CD
-4-

IPC-100 User Manual
<Picture 1> Product and Accessories
4. Part Names and Functions
Rear
Connector Function
1. LAN/802.3af LAN port/802.3af PoE (Power over Ethernet)
2. AUDIO OUT Audio output
3. AUDIO IN Audio input
9
8
6, 7
5
4
32
1
-5-

IPC-100 User Manual
4. RESET Button Reset button for network reset
5. POWER IN DC 12V power input
6. SENSOR/ALARM Sensor input/ Relay output
7. RS-485 Serial port. Support RS-485 protocol
8. POWER LED Power LED
9. VIDEO OUT Video output
5. System Connections
IPC-100 systems can be connected in either 1-to-1 fashion where one IPC-100 is
connected one PC client or decoder system or 1-to-many fashion where one IPC-100
connected to many PC and decoder systems. (IPE-3100 video server can work as a
decoder system which takes the data from a video server or IP camera, decodes and
outputs analog video.)
Topology
Generally, the IPC-100 and the PC & decoder are connected in 1-to-1 mode or 1-to-
many connection is also supported.
1:1 Connection (Unidirection)
IPC Decoder
Site Remote Center
IPC PC
Site Remote Center
Mostly used configuration is 1 to 1 connection. An IPC-100 is installed at a site where
-6-

IPC-100 User Manual
video images can be transmitted and a PC or a decoder is installed at a center location
to receive and view the video images on analog monitor. Audio and serial data are
transferred in either direction.
1:N Connection (Unidirection)
IPC PC or Decoder
PC or Decoder
PC or Decoder
Remote Center
Site
In this configuration, a site can be monitored from many remote center locations.
Although up to 64 PCs or decoders can be connected to on IPC-100, in the real network
environment, network bandwidth can limit the maximum connections.
Functionally, the central monitoring system software can replace the decoder.
Multicast Mode
Within the network that supports multicasting, a large number of decoders can be used
to receive video effectively from an IPC-100 using a single streaming of video and audio.
Relaying
IPC Decoder
Site Center 1
Decoder
Center 2
In this arrangement, video and audio can be retransmitted from a center to another
center. The arrangement is useful when the network bandwidth to the site is limited
while there are more than one center wanting to monitor the site.
-7-

IPC-100 User Manual
Central Monitoring System
Site Remote Center
IPC CMS
IPC Decoder
Site Remote Center
CMS
CMS (Central Monitoring System) is a Windows based remote monitoring program to
access multiple IPC-100 for real-time monitoring or control of the encoders and
connected cameras. Please refer to CMS User Manual for more information on CMS.
2. Installation
1. Connecting Network (LAN)
Connect LAN and there is a Video output to check video quality.
2. Connecting Audio
Audio is bi-directional in any configuration. If necessary, it can be configured to be in
transmit-only, receive -only or bi-directional mode.
-8-

IPC-100 User Manual
- Connect audio input and output ports to audio devices accordingly.
- Audio signal is in line level, therefore, microphone or speaker with amplification
function should be used.
3. Connecting Serial Ports
The serial port (RS-485) in IPC-100 can be connected to external equipment such as
PTZ receiver etc. Then, PC client can send PTZ commands to the external equipment
via serial port. When a decoder system instead of PC client is connected to IPC-100,
the serial port of IPC-100 and that of the decoder system works in pass-through mode.
That is, data at one port are delivered to the other port, vice versa.
4. Connecting Sensor and Alarm
Connect sensor and alarm devices to corresponding terminals accordingly.
5. Connecting Power
After confirming the power source, connect power adaptor and connect the 12VDC
connector to the system. Soon the system will boot up to an operating mode.
6. Check if It Works
As soon as the power is supplied to the system, it will boot and, after about 30 seconds,
the system will be ready for operation.
3. System Operation
1. Remote Video Monitoring
There are two ways to view the video once connections are made between the site and
center system. In order for a proper operation, an IP address must be set accordingly
and please refer to IP Manager in Chapter 4 or Remote Setting in Chapter 5 for a
further details.
Default ID : admin Password : 1234
-9-

IPC-100 User Manual
Video Monitoring with Decoder System
Once the IPC-100 IP address is set in the remote IP address section of the decoder, the
decoder system will connect to the IPC-100 and start receiving the video images.
Normally, a monitor connected to the decoder will display video images.
Video Monitoring using Internet Explorer
If an encoder’s IP address in entered on the Internet Explorer, the system will ask for
confirmation to install Active-X control. Once authorized, the Internet Explorer will start
to display video images from the encoder as shown below.
http://192.168.10.100
2. Initialization of IP Address
If a system IP address is lost, the system can be reset to a known IP address using the
reset button in the back side of the system:
cWhile system is in operation, press the reset button more than 5 seconds.
dThe system will reboot automatically
eOnce the system has been rebooted, IP address will be set to the following.
-IP mode: Fixed IP
-10-

IPC-100 User Manual
-IP address: 192.168.10.100
-Subnet mask: 255.255.255.0
-Gateway : 192.168.10.1
-Base port : 2222
-Http port : 80
-11-

IPC-100 User Manual
4. Remote Configuration
1. Using Internet Explorer
The server can be configured using web browser. Type IP address of IPC-100 in the
address input area of Internet Explorer, then a live viewing screen will be displayed.
Press Setup button located in the upper right area of the monitoring screen, then the se
page for server setup will be displayed.
cEnter IP address
dPress Setup button
The configurations are grouped into 8 categories: System, Video, Audio, Network,
Serial, Event, Preset and User. Any configuration changes are not applied until Apply
is pressed. Leaving the page without pressing Apply button, changes in the page will be
discarded.
-12-

IPC-100 User Manual
2. IPC-100 Configuration
2.1 System Configuration
Video Standard
Video signal type: Select NTSC or PAL
System ID
-13-

IPC-100 User Manual
System ID: Alphanumeric System ID to be transferred to remote software
 Language
Language to be used for web-based configuration (English, Japanese and
Korean)
Firmware version
Current firmware version
Start Time
Latest system boot date and time
Current Time
Current date & time: Enter a new date and time and press Set Current Time
button to update date & time.
Time Zone
Time zone: Select time zone of where the system is installed. Depending on the
time zone, Daylight Saving Time will work automatically..
Automatically synchronize with NTP server
Synchronize system time with an NTP server using NTP (network time
protocol). Name of the NTP server should be registered on NTP server Name.
Reboot Server
Pressing Reboot Server button will cause the system to reboot. Do not press
the Reboot button unless the server needs a reboot.
Factory Reset
Set all settings to the factory default values. System log and user registrations
are also cleared.
-14-

IPC-100 User Manual
2.2 Video Configuration
Preference
Preference in video compression and transmission: With ‘Bitrate’ selected,
the video compression will be effected by the ‘Bitrate’ value entered. With
‘Quality’ selected, the video compression will be effected by the quality of
-15-

IPC-100 User Manual
image selected. Therefore, ‘Bitrate’ and ‘Quality’ corresponds to CBR and
VBR respectively.
Resolution
Selectable video compression resolution:
NTSC: 720X480, 720x240, 352X480, 352X240
PAL: 720X576, 720X288, 352X576, 352X288
Frame rate
Selectable video frame rate: Determine the maximum number of frames of
video images to compress. The frame rate of actually transmitted video
can be affected by the network bandwidth limitation.
Quality
Video image compression quality: The selection is possible with
Preference is set to ‘Quality’.
Bitrate
Video bitrate: The value is applicable when Preference is set to ‘Bitrate’.
I-Frame Interval
I-frame interval: Possible values between 0 and 255. There will be no I-
frames if 0 is selected.
Use Motion Detection
Turn on/off motion detection operation.
Motion Detection Area Editing
Configure regions for motion detection. Regions of arbitrary shape can be
configured by the following steps.
cEnable Edit item.
dSelect editing Mode. Set is for including cells to motion detection region
and Erase is for excluding.
-16-

IPC-100 User Manual
eSelect cells using the right button of the mouse. Multiple cells can be
selected conveniently by press and dragging.
fPress Apply Edited Area to save the editing.
Sensitivity
A condition to trigger events with motion detection. The value determines
the sensitivity of the motion detection within a block: the smaller, the more
sensitive.
 Information Display
System ID and/or server time can be display over the video window in
Internet Explorer. Each item can be turn on or off separately, and position
also can be configure. These information are displayed after the video is
decompressed.
Burn-in OSD
Inserts system ID and date/time in the compressed video. Separately
System ID and Time can be turned On or Off in the video. Position
specifies the position of such data.
Brightness
Controls input video brightness by selecting values between 0 and 100.
-17-

IPC-100 User Manual
Contrast
Controls input video contrast by selecting values between 0 and 100.
Hue
Controls input video Hue by selecting values between 0 and 100.
Saturation
Controls input video saturation by selecting values between 0 and 100.
2.3 Audio Configuration
Mode
Select audio operation mode.
Mode Action
Off No operation
Tx-Only Transmit only
Rx-Only Receive only
Tx & Rx Transmit and Receive
-18-

IPC-100 User Manual
 Input Gain
Set audio input gain.
2.4 Network Configuration
IP Mode
Three IP modes are supported. Depending on the selected mode, further
configuration items come as follows.
IP Mode Selection Description
-19-
