Xtream Cm4642342-mm User manual

Hardware Configuration

•2x2 OFDM and OFDMA DOCSIS®

3.1 channels, 32x8 SC-QAM

DOCSIS® 3.0 channels

•Switchable upstream filters for

5-42/85MHz operation

•Fixed downstream for 108-

1002MHz operation

•1.2GHz Full Capture Bandwidth

Tuner

•2 port Gigabit Ethernet (RJ45)

•1 port 2.5G Ethernet (RJ45)

•1 FXS port for telephony (RJ11)

•3x3 2.4 GHz 802.11ax and 4x4

5GHz 802.11ax

•PacketCable™ 1.5 compliant

•MoCA 2.0 bonded

•RDK based routing function

CM4642342

DOCSIS® 3.1 Dual-Band AX5660 Wi-Fi 6 Cable Gateway

Arcadyan Technology’s CM4642342 is aDOCSIS®

3.1 capable Wi-Fi 6Cable Gateway offering up to

5Gigabit download speeds and VoIP functions for

both residential and small business markets.

The CM4642342 also integrates next generation

Dual-Band Wi-Fi 802.11ax, which offers premium

Wi-Fi performance.Users can enjoy the best Wi-

Fi experience without any interruption of data

transmission in ahome, apartment or SOHO. The

addition of bonded MoCA also provides extra

customer flexibility for in-home connectivity.

All of this in the most compact, heat efficient

design available for your data, video or voice

services.

http://www.arcadyan.com

The information and specifications are subject to change without prior notice. Arcadyan tries to

ensure that all information in this document is correct but does not accept liability for any error or

omission.

Broadband Access Solutions

Digital Home Solutions

Wireless Networking Solutions

Wi-Fi 6

D3.1

2x2

http://www.arcadyan.com

The information and specifications are subject to change without prior notice. Arcadyan tries to ensure that all

information in this document is correct but does not accept liability for any error or omission.

CM4642342

DOCSIS® 3.1 Dual-Band AX5660 Wi-Fi 6 Cable Gateway

TECHNICAL SPECIFICATIONS

System

DOCSIS® SoC BCM3390S Dual Core 1.5GHz Processor

WiFi BCM6710 + BCM43684 (3x3 11ax + 4x4 11ax)

RAM 1GB DDR3 RAM (512MB*2)

Flash 256MB NAND Flash

Wi-Fi Standard IEEE 802.11ax, backwards compatible to 802.11ac/n/a/b/g

I/O Port

1 x DC power jack

1 x RF interface (75ohm F-type) to bi-directional HFC network

2 x RJ45 10/100/1000 Base-T Ethernet LAN

1 x RJ45 1000/2500 Base-T Ethernet LAN

1x FXS port for VoIP services

1x MoCA LED

Buttons 1 x WPS on front panel, 1 x Reset on rear panel

Front Panel LED Indicator Power, DS, US, Online, Voice, LAN, Wi-Fi

Dimensions (H*D*W) 235mm(H) x 214mm(D) x 65mm(W)

Power (External adapter) Input: 100V-240Vac 50-60Hz

Output: DC 12V/3A

RF Downstream

Bonded Channels Up to 2 OFDM DOCSIS 3.1 channels or 32 SC-QAM DOCSIS 3.0 channels

Tuner Configuration 1.2GHz full band capture tuning range

Frequency Range 108MHz –1002MHz

RF Upstream

Bonded Channels Up to 2 OFDMA DOCSIS 3.1 channels or 8 SC-QAM DOCSIS 3.0 channels

Frequency Range 5MHz –42MHz / 5MHz –85MHz switchable

Environment

Operating Temperature 0 to 40 degree C

Operating Humidity 5% to 95 % (non-condensing)

http://www.arcadyan.com

The information and specifications are subject to change without prior notice. Arcadyan tries to ensure that all

information in this document is correct but does not accept liability for any error or omission.

CM4642342

DOCSIS® 3.1 Dual-Band AX5660 Wi-Fi 6 Cable Gateway

TECHNICAL SPECIFICATIONS

Wireless

Frequency Range 2.4GHz and 5GHz

Data Rate Up to 5661Mbps

(861Mbps 2.4GHz 11ax + 4800Mbps 5GHz 11ax under 160MHz)

Wi-Fi Security Level WPA-PSK/WPA2-PSK/WPA-WPA2-PSK (TKIP/AES)

WPS PBC and PIN

QoS WMM/WMM-PS

Antenna 7 internal single-band antennas

Voice Functions

PacketCable Complied with PacketCable 1.5

Signaling Protocol NCS

Call Feature Call Waiting, Three Way Calling, Caller Number, Display and Restriction,

MWI, Call Forwarding

Speech Codecs ITU-T G.711-ulaw, G.711-alaw

Echo Canceller ITU-T G.168

Other Features Caller ID (DTMF/FSK), Fax relay (T.30/T.38), DQoS Lite

MoCA

MoCA 2.0 Dual-Bonded channel

Expended range of operating frequencies –

1125MHz to 1675MHz

Routing Functions

IPv4/IPv6 Dual IP Stack

Discovery Protocol –UPnP

Static and dynamic IP routing (RIP v1/v2)

IGMPv3 proxy, IGMP snooping

NAT, PAT, Port Forwarding, Port Triggering, DMZ

MAC/IP/Port Filtering, Parental Controls

Compliant with RDK structure

Arcadyan EasyMesh

Management and Security

User-friendly GUI via HTTP and HTTPS

Command Line Interface (CLI) –Telnet, SSH v2

Protocol Support –TR-069, SNMP v1/v2/v3

Support SPI Firewall, BPI+security mechanism

http://www.arcadyan.com

The information and specifications are subject to change without prior notice. Arcadyan tries to ensure that all

information in this document is correct but does not accept liability for any error or omission.

CM4642342

DOCSIS® 3.1 Dual-Band AX5660 Wi-Fi 6 Cable Gateway

Industrial Design

January 2021

R01

Power

Adapter

RJ-45

Quick Start GuideQuick Start Guide

Package Contents:

1 Docsis 3.1 Wi-Fi 6 Voice Gateway

1 RJ-45 Ethernet Cable

1 Power Adapter

Quick Installation Guide

Wi-Fi 6 Cable Gateway

CM4642342-MM

Device Overview

The Wi-Fi 6 Cable Gateway supports both MoCA 2.0 and DOCSIS

3.0/3.1 for broadband data transfer to an existing coaxial cable system.

With the channel bonding connectivity, the Gateway allows for the

aggregation of multiple downstream and upstream channels and brings

up to 5 Gbps for download speed and 1 Gbps for upload speed.

The Gateway is also compliant with the IEEE 802.11ax specication

while maintaining full backwards compatibility with the 802.11ac/a/b/

g/n standards. IEEE 802.11ax is the new addition of the IEEE 802.11

standards, running at dual-band of 2.4 GHz and 5 GHz band types, as

well as co-existing with the 802.11ac/11n network. It delivers wide

bandwidth of up to 160 MHz, and reliable high data rates of up to 4.8 Gbps.

The Wi-Fi 6 Cable Gateway supports one 2.5-gigabit LAN port, two

one-gigabit LAN ports, one F-type coax WAN port, one FXS RJ-11 port

for telephony, and 802.11ax dual-band wireless capabilities. It provides

high speed transmission rate for data/voice/video triple-play services.

The Wi-Fi 6 Cable Gateway delivers sufcient bandwidth to stream

HD video, listen to digital music, play online games, transfer large les,

voice service, and surf the Internet simultaneously.

LED Indication and WPS Button

cPower

On Blue Flashing Blue Off

Receiving

power

System

initializing

Power off

dDownstream

On Blue Flashing Blue

Downstream channel

has been locked.

Scanning for a

downstream channel

connection

eUpstream

On Blue Flashing Blue

Upstream channel has

been locked.

Scanning for a

upstream channel

connection

fOnline

On Blue On Green

WAN connection is in

DOCSIS 3.1 mode.

WAN connection is in

DOCSIS 3.0 mode.

Flashing Off

Synchronizing with

termination system

of your ISP (Internet

service provider),

and waiting for IP

assignment from

DHCP server

No WAN connection

gVoice

On Blue Flashing Blue Off

EMTA

(Embedded

Multimedia

Terminal

Adapter)

link has been

established.

Phone call

ongoing, a

phone has

been picked up

to dial,

or there is an

incoming call.

No voice-over-

cable link

hLAN (Front Panel)

On Blue Flashing Blue Off

Ethernet LAN

connection

has been

established.

Sending or

receiving data

on any LAN

port of the

device.

No LAN

connection

LAN (Rear Panel)

On Green Flashing Green Off

Ethernet LAN

connection

has been

established.

The indicated

LAN port

is sending

or receiving

data..

No LAN

connection on

the indicated

LAN port.

iWireless

On Blue Flashing Blue

Wireless link has been

established.

Data is being

transmitted via wireless

network.

Slow Flashing Off

WPS mode in process No wireless link

jWPS Button - Press this button for at least 4 seconds when

activating the WPS function.

Device Connectors

nOne 2.5 gigabit Ethernet Port (RJ-45). Connect 2.5 gigabit network

device on your network to this port.

oTwo Ethernet LAN Ports - one gigabit Ethernet ports (RJ-45).

Connect network devices on your network to these ports.

pReset Button

• Pressing this button less than 5 seconds brings up a reboot to the

Gateway.

• Pressing the button over 5 seconds restores the Gateway to the

default factory settings.

qMoCA (Multimedia over Coax Alliance) LED

On Green Flashing Green Off

Coaxial

connection

has been

established

and working

properly.

Sending or

receiving

network trafc

via coaxial link

No MoCA link

rCoax Port - Connect the coax line to this port.

sPhone Port - Connect the telephone line to this port (RJ-11).

tPower Inlet - Connect the included power adapter to this inlet. Please

contact the authorized distributor of Mediacom for AC Adapter

purchase and installation.

Hardware Installation

Installation Precaution

Comply with the following guidelines for a safe use of your

product:

• Avoid installing this product during an electrical storm. There may be

a remote risk of electric shock from lightning.

• Do not try to disassemble and/or reassemble this device. Tempering

the device might void the product warranty.

• When mounting or cleaning the device, be sure to unplug the power

cord from the device.

• Keep your hands dry when handling the device to avoid the possible

electrical shock.

Choose a Location

• Appropriate safe and solid location which can sustain the device even

in strong wind.

• Do not place the device in high humidity environments.

• For best RF performance, be sure to position this device at the highest

possible location for getting the strongest signal strength from a base

station.

Network Connectivity

Step 1-

a. Connect one end of the

provided Ethernet cable into

any of the LAN ports on the

Wi-Fi 6 Cable Gateway. Then

insert the other end of the cable

into the Ethernet port of your PC or

other Ethernet network device.

b. Use a coaxial cable to connect the

coaxial port of the Gateway

to a cable wall outlet.

Step 2- Plug the power adapter

into the power socket on the rear

of the Wi-Fi 6 Cable Gateway,

and the other end into a power

outlet.

Step 3- Wireless Link: On the

Windows desktop, click Start/

Settings/Network & Internet.

The Network status window

will open. Click Wi-Fi on the left menu bar of the screen. to browse the

available wireless networks. Choose Wi-Fi 6 Cable Gateway from the

list and click Connect button to start using the wireless network.

NOTE: Be sure all of the clients use the same values on your wireless

network. (Default SSID: Wireless) The SSID is the name of your

wireless network. It is used to distinguish your wireless network from

other wireless network.

The SSID and password was printed at the bottom of the Gateway.

System Requirements

To install and connect to the Wi-Fi 6 Cable Gateway, you must have:

• Broadband Internet service and modem/gateway with coax or

Ethernet connection.

• 2.4/5 GHz 802.11ax/ac/a/b/g/n wireless adapter installed on each

PC. Alternatively an Ethernet adapter can be used.

• Windows 7 or later, or Mac OS 10 or later.

• An up to date web browser: Internet Explorer 5.5 or later, Google

Chrome, or Mozilla 1.7/Firefox 1.0 or later.

Software Installation

Conguring Client PC

After completing the hardware setup by connecting all your network

devices, you need to congure your computer to connect to the

Wi-Fi 6 Cable Gateway.

To access the Internet through the Wi-Fi 6 Cable Gateway, you must

congure the network settings of the computers in your LAN to use

the same IP subnet as the gateway. The default IP settings for the

Wi-Fi 6 Cable Gateway are:

• IP address: 192.168.0.1

• Subnet mask: 255.255.255.0

Windows 8

1. On the Windows desktop, click Start/Desktop.

2. Right-click the Ethernet icon on the task bar, then select Open

Network and Sharing Center.

3. The Network and Sharing Center window will open. Click Ethernet

in the View your active networks eld of the screen.

4. On the Ethernet Status screen, click Properties.

5. Double-click Internet Protocol Version 6/Version 4 (TCP/IPv6,v4).

6. If Obtain an IP(v6) address automatically and Obtain DNS server

address automatically are selected, your computer is already

congured for DHCP. If not, select the options.

Windows 10

1. On the Windows desktop, click Start/Settings/Network & Internet.

2. The Network status window will open. Click Ethernet on the left

menu bar of the screen.

3. Click Open Network and Sharing Center.

4. Double-click the Ethernet connection for this device.

5. On the connection status screen, click Properties.

6. Double-click Internet Protocol Version 6/Version 4 (TCP/IPv6/v4).

7. If Obtain an IP(v6) address automatically and Obtain DNS server

address automatically are already selected, your computer is

already congured for DHCP. If not, select the options.

Obtain IP Settings from Your Wireless

Wi-Fi 6 Cable Gateway

Now that you have congured your computer to connect to your

gateway, it needs to obtain new network settings. By releasing

old DHCP IP settings and renewing them with settings from your

Wi-Fi 6 Cable Gateway, you can verify that you have congured your

computer correctly.

1. On the Windows desktop, click Start/Programs/Accessories/

Command Prompt.

2. In the Command Prompt window, type ipcong /release and press

the Enter key.

3. Type ipcong /renew and press the Enter key. Verify that your IP

Address is now 192.168.0.xxx, your Subnet Mask is 255.255.255.0

and your Default Gateway is 192.168.0.1. These values conrm

that your Wireless Wi-Fi 6 Cable Gateway is functioning correctly.

4. Type exit and press the Enter key to close the Command Prompt

window.

Manual TCP/IP Settings

1. Follow steps 1-5 in “Windows 8”.

2. Select Use the following IP Address.

3. Enter an IP address based on the default network 192.168.0.x

(where x is between 2 and 254), and use 255.255.255.0 for the

subnet mask. Use 192.168.0.1 for the Default gateway eld.

4. Select Use the following DNS server addresses.

5. Enter the IP address for the Wi-Fi 6 Cable Gateway in the

Preferred DNS server eld. This automatically relays DNS

requests to the DNS server(s) provided by your ISP. Otherwise,

add a specic DNS server into the Alternate DNS Server eld and

click OK to close the dialogue boxes.

Record the congured information in the following table.

TCP/IP Configuration Setting

IP Address ____.____.____.____

Subnet Mask ____.____.____.____

Preferred DNS Server ____.____.____.____

Alternate DNS Server ____.____.____.____

Default Gateway ____.____.____.____

Macintosh Computer

You may nd that the instructions here do not exactly match your

operating system. This is because these steps and screen shots were

created using Mac OS 10.2. Mac OS 7.x and above are similar, but may

not be identical to Mac OS 10.2.

Follow these instructions:

1. Pull down the Apple Menu . Click System Preferences.

2. Double-click the Network icon in the Systems Preferences

window.

3. If Using DHCP Server is selected in the Congure eld, your

computer is already congured for DHCP. If not, select this option.

Your new settings are shown in the TCP/IP tab. Verify that your IP

Address is now 192.168.0.xxx, your Subnet Mask is 255.255.255.0

and your Default Gateway is 192.168.0.1. These values conrm

that your Wireless Wi-Fi 6 Cable Gateway is functioning.

4. Close the Network window.

Now your computer is congured to connect to the Wi-Fi 6 Cable

Gateway.

NOTICE:

The cable distribution system should be grounded (earthed) in

accordance with ANSI/NFPA 70, the National Electrical Code (NEC),

in particular Section 820.93, Grounding of Outer Conductive Shield of a

Coaxial Cable. other wireless network.

Federal Communication Commission Interference Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one

of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.
