Xtreme Power 75033 Original instruction manual

10 GALLON FREESTANDING SOLAR SHOWER
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE
PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM
(OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM: 75033
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: [phone] MON-FRI 9AM TO 3PM PST

1
IMPORTANT SAFETY INFORMATION
SAFETY
The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be supplied by the operator. Read
carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to
follow the safety rules and other basic safety precautions may result in serious personal injury.
Read and understand all instructions. Failure to follow all instructions may result in serious injury or
property damage.
DO NOT allow persons to operate or assemble the product until they have read this manual and have
developed a thorough understanding of how it works.
Check for damaged parts before each use. Carefully check that the product will operate properly and
perform its intended function. Replace damaged or worn parts immediately. NEVER operate the product
with a damaged part.
DO NOT use the solar shower with base in high wind conditions. Wind may cause the shower to
become unstable and fall over hurting you, children or property.
THIS IS NOT a recreational device. DO NOT climb on, hang from solar shower or stand on base. Use
only as intended.
When not in use, store the solar shower in an area away from the play of children.
CAUTION: IMPORTANT SAFETY INFORMATION - KEEP SMALL PARTS, HARDWARE AND
PLASTIC BAGS OUT OF THE REACH OF CHILDREN.
WARNING: IF SHOWER HAS NOT BEEN USED FOR MORE THAN THREE DAYS, WE RECOMMEND
RUNNING THE SHOWER FOR 2 MINUTES TO REMOVE STAGNANT WATER. STAGNANT WATER IN
WARM ENVIRONMENT CAN PROVIDE A GROWTH ENVIRONMENT FOR HAZARDOUS BACTERIA.
SAVE THESE SAFETY WARNINGS!

3
PRODUCT FEATURES
Outdoor Solar Shower Powered Adjustable Hot & Cold Water Base Shower
Head Connects to Garden Hose 7ft
This Solar shower allows you to take a refreshing shower in your garden or by your pool before or after
swimming. The shower easily connects to your garden hose, then through solar energy it heats the cold
water up to 140°F for a perfect outdoor shower. A faucet is included to adjust the pressure and temperature,
and the shower comes with screws to mount the base to any at solid surface. Solar shower will be a great
addition to your garden or your swimming pool.
Easy to Assemble - Solar powered shower is made from high-quality materials and is easy to assemble.
Simply connect it to a standard garden hose and use it as a freestanding shower or mount it to most
surfaces.
High-Quality Material - Designed this outdoor solar shower from superior material, including non-
corrosive brass and strong PVC piping.
Temperature and Water Pressure Adjustable - Solar shower, with a built-in 8 gallon water tank,
absorbs solar energy and heats the water inside. A handy faucet allows you to adjust the temperature
and pressure, our shower can be easily connected to your garden hose, and the solar heater can raise
the temperature of water for the perfect outdoor rinse!
Powered by the Sun - Solar-powered shower is 100% powered by the sun. It uses no electrical cords,
batteries, or other cords. It’s easy to assemble and remove for storage.
SPECIFICATIONS

4
PARTS DIAGRAM
HOSE
CONNECTION
DRAIN SCREW
BASE PLATE
BOLTS & WASHERS
FAUCET
HANDLE
SHOWER TUBE
SHOWER HEAD
SHOWER HEAD PIPE
TOP PLATE

INSTALLATION
5
1. Drill holes in the concrete oor or other solid ground. Fix the shower to the ground using the bolts in the
parts bag. Make sure the solar shower will not collapse due to strong wind and other external forces.
2. Install the solar shower in a location with optimal sunshine.
3. Connect the inlet of the solar shower to your home’s water system using a standard garden hose.
4. Turn on water supply to garden hose to ll shower. Shower will take about 2 minutes to ll. NOTE: Filling
tube with valve in hot position ensures no air pockets are trapped in shower. This procedure is used for
initial set up ONLY. When water ows from shower head, turn shower handle off.
5. Test that all components are installed correctly and not leaking. Transportation and any improper operation
during installation can loosen the xings, causing leakage. Check to make sure all xings are tightened.
CAUTION:
To prevent being scalded by hot water, ALWAYS make sure the shower valve is in the cold water position
(blue) before turning on the shower, then turn the valve on and gradually adjust the water toward the hot
water position (red), until reaching the desired temperature.
DO NOT remove or add any parts or attachment, otherwise leaking can occur.
Clean the shower head periodically to make sure water sprays without resistance.
DO NOT allow children to use the solar shower alone.
Fill up the water tube only after the shower id fully assembled and installed. Turning the adjusting handle
to the HOT position, if the water comes out of the shower head, the tube is fully lled.
In winter months, be sure to empty the water inside the tube to avoid water freezing inside the tube,
possibly damaging the unit.
WHEN EXPOSED TO VERY STRONG SUN RAYS, THE WATER
TEMPERATURE COMING FROM THE SOLAR SHOWER MAY
REACH TEMPERATURES AS HIGH AS 140˚ F (60˚ C).
NOTE: Depending on available
sunlight, and outside temperature, it
may take up to 3 hours or longer to fully
heat the water. Using the shower too
soon will yield less heated water.
A recently used shower (that has not
been emptied) will take less time to
heat as it will have retained some hot
water.

WARRANTY
PRODUCT MADE IN CHINA
INSTALLATION
GARDEN HOSE CONNECTOR
OPTION 1:
Firstly, connect the double female connector with the inlet and outlet connector. Then, connect the male
thread end of the ball valve to the double female connector.
NOTE: Both the thread of the double female connector and the inlet and outlet connector are 3/4 NH thread.
Shower Male read
Garden Hose ConnectorFemale Connector
Shower
OPTION 2:
Connect the female thread end of ball valve to the inlet and outlet connector.
NOTE: The thread of the inlet and outlet connector is 3/4 NH thread.
Shower
Garden Hose Connector
Shower Male read
6

7
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS,AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
PLEASE READ THE FOLLOWING CAREFULLY
DISCLAIMER
PRODUCT MADE IN CHINA
