Xtreme JX-200 Guide
JX-200
User & Installaon Manual
www.xpcc.com | © 2019 Xtreme Power Conversion Corporaon. All rights reserved. (Rev 12/2/19)
Xtreme Power Conversion Corporaon
JX-200 User’s Manual
Page 2
1. Important Safety Warnings
You should be receiving the following items inside the package:
• Power Condioner
• User Manual
1.1 Safety instrucons
Please comply with all warnings and operang instrucons in this manual strictly. Save this manual properly
and read carefully the following instrucons before installing the unit. Do not operate this unit before reading
through all safety informaon and operang instrucons carefully.
• Do not try to repair the unit yourself, contact your local supplier or your warranty will be void.
• To eliminate any overheang of the Power Condioner, keep all venlaon openings free from obstrucon
and do not place any foreign objects on top of the isolaon transformer.
• Do not install the power condioner in direct sunlight.
• This isolaon transformer is not designed for use in dusty, corrosive and salty environment.
• The warranty for this isolaon transformer will be void if water or other liquid is spilt or poured directly
onto the Power Condioner. Similarly we do not warrant any damage to the Power Condioner if foreign
objects are deliberately or accidentally inserted into the Power Condioner enclosure.
• Servicing of isolaon transformer should be performed or supervised by trained personnel with knowledge
of Power Condioner and the required precauons.
• The socket-outlet shall be installed near the equipment and shall be easily accessible
1.1 Consignes de sécurité
Veuillez vous conformer strictement à tous les averssements et instrucons d’ulisaon de ce manuel. Con-
servez ce manuel correctement et lisez aenvement les instrucons suivantes avant d’installer l’unité. N’ulisez
pas cet appareil avant d’avoir lu aenvement toutes les informaons de sécurité et les instrucons d’ulisaon.
• N’essayez pas de réparer l’appareil vous-même, contactez votre fournisseur local ou votre garane sera
annulée.
• Pour éliminer toute surchaue du condionneur d’alimentaon, gardez toutes les ouvertures de venlaon
libres de toute obstrucon et ne placez aucun objet étranger sur le transformateur d’isolement.
• N’installez pas le condionneur d’alimentaon en plein soleil.
• Ce transformateur d’isolement n’est pas conçu pour être ulisé dans un environnement poussiéreux, cor-
rosif et salin.
• La garane de ce transformateur d’isolement sera nulle si de l’eau ou un autre liquide est renversé ou versé
directement sur le condionneur d’alimentaon. De même, nous ne garanssons aucun dommage au Power
Condioner si des objets étrangers sont délibérément ou accidentellement insérés dans le boîer du Power
Condioner.
• L’entreen du transformateur d’isolement doit être eectué ou supervisé par du personnel qualié con-
naissant le condionneur d’alimentaon et les précauons requises.
• La prise de courant doit être installée près de l’équipement et doit être facilement accessible
1.2 Operang Environment
Condion Visual Indicator Alarm
Temperature Storage 32°F ~ 104°F
Maximum altude Operaon 11,500 feet
Storage 50,000 feet
Humidity Relave Humidity 0% - 95% No condensaon
• Make sure the isolaon transformer is installed within the proper environment as specied.
Xtreme Power Conversion Corporaon
JX-200 User’s Manual
Page 3
2. Product Overview
NOTE: Before installaon, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep
the original package in a safe place for future use.
2.1 External Dimension
2.2 Rear and Front Panel View
1. Breaker
2. Output 5-15R
3. Input C14
4. Green LED: lit when proper AC input is present
5. Red LED: lit when Site Wiring Fault is detected
3 Installaon and Setup
3.1 Unpacking & Inspecon
1. Remove the isolaon transformer from the packing.
Note: The isolaon transformer is very heavy, be cauous when unpacking and liing the unit to avoid injury.
2. Check the inside package
• Power Condioner unit
• Quick guide
• Wall mounng x 2
• Handle screws x 4
Xtreme Power Conversion Corporaon
JX-200 User’s Manual
Page 4
3.2 Selecng Installaon Posion
It is necessary to select a proper environment to install the unit, in order to minimize the possibility of damage to
the isolaon transformer and extend the life of the isolaon transformer. Please follow the instrucons below:
1. Do not block the air-ow to the venlaon openings of the unit.
2. Please ensure the installaon site environmental condions are in accordance with the unit’s working
specicaons to avoid overheat and excessive moisture.
3. Do not place the unit in a dusty or corrosive environment or near any ammable objects.
4. This unit is not designed for outdoor use.
3.3 Mounng the Ears
Aach mounng ears to the side mounng holes of isolaon transformer using the screws provided. Refer to le
chart.
4. Specicaons
MODEL NUMBER JX-200
CAPACITY Power rang 200VA (200W)
INPUT
Voltage 120VAC
Frequency 50/60Hz
Breaker 5A,125VAC
OUTPUT
Voltage 120VAC
Frequency 50/60Hz
Surge suppression 300 joules
Let-through Noise <10 volts normal mode and < .5 volts common mode
PHYSICAL
Dimensions (W x D x H) 6.9 x 8.5 x 1.25 in (175 x 216 x 32 mm)
Weight 6.6 lbs(3.0 kg)
Line cord C13 to 5–15P
Receptacles (3) 5–15R
ENVIRONMENT
Temperature 32–104°F (0–40°C)
Humidity 0–95%
Altude 11,500 feet above sea level
APPROVALS UL60950 RoHS
COMMUNICATIONS INTERFACE LED*2(green/red)
INCLUDED IN BOX User manual
AVAILABLE OPTIONS Line cord with oset right angle 5–15P
Xtreme Power Conversion Corporaon
JX-200 User’s Manual
Page 5
Obtaining Service
If the power condioner requires Service:
1. Use the TROUBLESHOOTING secon in this manual to eliminate obvious causes.
2. Verify there are no circuit breakers tripped.
3. Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the problem,
call Xtreme Power Conversion Corp Technical Support at 800.582.4524. Technical support inquiries can
also be made at [email protected]. Please have the following informaon available BEFORE calling the
Technical Support Department:
• Your name and address.
• The serial number of the unit.
• Where and when the unit was purchased.
• All of the model informaon about your Power Condioner.
• Any informaon on the failure, including LED’s that may or may not be illuminated.
• A descripon of the protected equipment, including model numbers if possible.
• A technician will ask you for the above informaon and, if possible, help solve your problem over the
phone. In the event that the unit requires factory service, the technician will issue you a Return Mate-
rial Authorizaon number (RMA).
If you are returning the power condioner to Xtreme Power for service, please follow these procedures:
1. Pack the Power Condioner in its original packaging. If the original packaging is no longer available, ask
the Technical Support Technician about obtaining a replacement set of packaging material. It is important
to pack the Power Condioner properly in order to avoid damage in transit. Never use Styrofoam beads
for a packing material.
2. Include a leer with your name, address, dayme phone number, RMA number, a copy of your original
sales receipt, and a brief descripon of the problem.
3. Mark the RMA number on the outside of all packages. Xtreme Power cannot accept any package without
the RMA number marked on the outside of the boxes.
4. Return the UPS by insured, prepaid carrier to the address provided by the Technician.
5. Refer to the Warranty statements in this manual for addional details on what is covered.
Xtreme Power Conversion Corporaon
JX-200 User’s Manual
Page 6
Xtreme Power Conversion Limited Warranty
Xtreme Power Conversion (XPC) Corporaon warrants Xtreme Power Conversion equipment, when properly ap-
plied and operated within specied condions, against faulty materials or workmanship for a period of three years
(USA & Canada) for JX-Series products from the date of purchase. For equipment sites within the United States
and Canada, this warranty covers repair or replacement, at the sole discreon of XPC Corporaon. The customer is
responsible for the costs of shipping the defecve product to XPC Corporaon. XPC Corporaon will pay for ground
shipment of the repaired or replacement product. For equiptment outside the US & Canada, the warranty does
not include shipping to and from XPC service depot. This warranty applies only to the original purchaser.
If equipment provided by XPC Corporaon is found to be Dead-on-Arrival (DOA), XPC Corporaon will be respon-
sible for the costs of shipping product to and returning equipment from the customer in a mely manner as agreed
to with the customer, once the customer has requested and received a Return Material Authorizaon (RMA)
number. DOA equipment is dened as equipment that does not properly funcon according to user documenta-
on when inially received and connected in conjuncon with proper procedures as shown in the user documen-
taon or via support provided by XPC Corporaon personnel or authorized agents.
This warranty shall be void if (a) the equipment is repaired or modied by anyone other than XPC Corporaon or
a XPC Corporaon approved third party; (b) the equipment is damaged by the customer, is improperly used or
stored, is subjected to an adverse operang environment, or is operated outside the limits of its electrical speci-
caons; or (c) the equipment has been used or stored in a manner contrary to the equipment’s operang manual,
intended use or other wrien instrucons. Any technical advice furnished by XPC Corporaon or a XPC Corpora-
on authorized representave before or aer delivery with regard to the use or applicaon of Xtreme Power Con-
version equipment is furnished on the basis that it represents XPC Corporaons best judgment under the situaon
and circumstances, but it is used at the recipient’s sole risk.
EXCEPT AS STATED ABOVE, XPC Corporaon DISCLAIMS ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCEPT AS STATED ABOVE, IN NO EVENT WILL XPC Corporaon BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCI-
DENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF Xtreme Power Conversion EQUIPMENT,
including but not limited to, any costs, lost prots or revenue, loss of equipment, loss of use of equipment, loss
of soware, loss of data, cost of substutes, or claims by third pares. Purchaser’s sole and exclusive remedy for
breach of any warranty, expressed or implied, concerning Xtreme Power Conversion equipment, and the only
obligaon of XPC Corporaon under this warranty, shall be the repair or replacement of defecve equipment,
components, or parts; or, at XPC Corporaons sole discreon, refund of the purchase price or substuon of an
equivalent replacement product.
