Xtrons TD714GT User manual

REV0.0
DJ Series User Manual

No boot up.
Fault
After ignition starting
up and power off, all
settings information
were missing.
Poor receive stations
effect
No way to put into
Optical disc
No remote control
action/function
Disc can't play
No action to switch
between Language
and sub-title
No image
Mode screen
dislocation
Functional disorders
Solution
After pressing the RESET key
with a small nib on the face
panel, power on again.
Re-connect the shunting line
Using the same insurance
with main unit to replace
Pop-up the disc in the unit
(device) , then re-insert it
into again.
Checking if the ANT of radio
automatic antenna control
lines are not connected well,
then, please re-check the
antenna and the ground wire
made correct connection all.
replace(change) the battery
of the remote control.
Change the good disc
Using pick up head cleaning
disk to clear the pick up.
Put the face of optical disk
logo upwards and put it into
the device(unit).
No multilingual sub-title's disk.
Can't make switch between
language and sub-title
Re-connect the connection
line.
Calibrate touch screen ( Refer to
page 16 aboutThe touch-screen
calibration of system information) bit
After pressing the resetting key
of "RESET" with a small nib on
the face panel(plate),to re-boot up.
Power fuse was burnt.
Reason
The BATT of ACC ignition
positive power linemade
wrong connection.
Other factors caused the
microprocessorincorrect
operation
Low battery in the remote
control
Car antenna didn't go out ,
Poor antenna grounding.
Disc was scratched
The laser head has been
dirty
Optical disk's positive
and negative were
placed reversal(opposite).
There has installed disks
already in the DVD loader
/mechanism.
CD only burned a
language/ sub-title
No making touch screen
calibration very well.
No connect the video
cables very well from
main unit to TV.
Other factors caused the
microprocessorincorrect
operation
Common Troubleshooting Guide

Hua Wei E220
Hua Wei E1750(Modem:COM6,ATCMD:COM8,COM7 not use)
Hua Wei E1550
Hua Wei E156G(Modem:COM6,ATCMD:COM7)
Hua Wei Vodafone K3765(Modem:COM6,ATCMD:COM9,COM7&COM8 not use)
Hua Wei Vodafone K3565-Rev2(Modem:COM6,ATCMD:COM7)
ZTE Vodafone K3565-Z(Modem:COM6,ATCMD:COM7,COM8&COM9 not use)
ZTE Vodafone K4505-Z(Modem:COM6,ATCMD:COM7&COM9,COM8 not use)
ZTE MF637U(Modem:COM6,ATCMD:COM7,COM9 not use)
MOBIDATA HSPA-500HU
SAMELINE UM200(Modem:COM6,ATCMD:COM7,COM8&COM9 not use)
Vtion E1916(Modem:COM6,ATCMD:COM7,COM9 not use)
2. CDMA2K/EVDO
Hua Wei EC1260
Hua Wei EC1261(Modem:COM6,ATCMD:COM8,COM7 not use)
ZTE AC560/580(Modem:COM6,ATCMD:COM8,COM7&COM9 not use)
ZTE AC2726
ZTE AC2736(Modem:COM6,ATCMD:COM7,COM8&COM9 not use)
ZTE MC8630
SINCOM SE189U
ETCOM E300
Vtion E1916(Modem:COM6,ATCMD:COM8,COM7 not use)

3G settings
The following are some of the USB devices, parts of them don't make actual tests.
Just for your reference.
1. WCDMA/DSDPA:
Hua Wei E180
Enter into 3G settings:
On the screen,please click "Settings" icon of main interface to enter
into the system setting interface ,Dragging the option bar up and down to
find "APN" setting option .
3G supporting lists
Unicom:
Network access point : 3GNET
Phone Number : * 99 #
Username: ( empty )
Password: ( empty )
Telecommunications/Telecom:
Network Access Point: ( empty )
Phone Number : # 777
Username : card
Password : card

USB-IMUSIC installation
diagram/Instruction ( optional )
This unit supports USB-IMUSIC function,which only supports our company's
USB-IMUSIC products .When using it, please insert USB-IMUSIC into the jack
which is marked with the word of LICENSE on the back of this device,then inserting
Apple audio device into the jack which is marked with the word of MEDIA in the
tail ,then,you can use it now. Note : USB-IMUSIC dongle with password !

Map installation and parameter(specification)
GPS parameter :
1.the operating system : Microsoft Windows 06 NET6.0
2.GPS chip : Buit-in(internal) MTK3360
3.Supported screen resolution : 800 * 480
4.GPS BAUD ( baud rate ): 9600bps
5.GPS COM: 2
Map installation s teps:
1.Users can insert the SD card of pre-installed GPS navigation map software
into the GPS card slot on the face panel of this device(unit).
2.On the screen, please click the "Settings" icon of main interface to enter
into the system settings interface,dragging the options bar up and down
to find the settings option of" Navigation Settings " . See picture, entering
into " navigation path " ,the system will automatically find out all the "exe"
files in the navigation card, just need to click the correct navigation path,
thus, you can set the current navigation path as start's navigation path .
3.Re-press GPS key on the face panel of main unit or click the "navigation
key" of main interface to enter into navigation screen . As the following
pictures shown :

Steering wheel control connections instruction.
Enter i nto the steering w heel control:
Please click the "Settings" icon to enter into the system setup interface on
the screen, then,dragging option bar up and down to find the settings option of "
How to learn steering wheel control " .
The procedure f or s teering w heel control s ettings :
1. Clicking the picture of " " to clean up(empty) everything.
2. On the steering wheel, pressing(holding) this button which you will need
to setting(set).
3. Click these buttons on the touch screen, which functions are corresponding
with these buttons(keys) accordingly.
4. When these buttons turn red , it means that these buttons have been set
successfully.
5. Repeat 2-4 key actions to complete all learning .Please correctly connect
the steering wheel control lines ,
please see the following pictures:Connecting two AD lines with the positive pole
of steering wheel control line, connecting the GND with negative pole.

ARM software upgrade instructions
picture 2
picture 1
Copying ARM softwares(total 7pcs files, see picture 1) into SD card and
please ensure the SD card is full empty. Under the device was powered off,
inserting the SD card into this device's GPS card slot,then,turning on the device
(unit), at this time, the device(unit) will automatically search files to run upgrade
(see picture 2), after it completes the upgrade successfully, it will switch to main
UI interface automatically, then, you can use it now. Notes: when upgrade, please
ensure the continuous power supply and keep the unit opening all the time, don't
permit to cut off the power supply, please see picture 1, picture 2.

MCU Software Upgrade Instructions
Copying MCU softwares (total two files )into the SD card ( please ensure the
SD card is full empty ) , then, inserting into the device's GPS card slot, then,on
the screen, please click "Settings" icon of the main interface, thus, it will enter
into system setup interface, dragging the option bar up and down to find the
settings option of " Navigation Options".then, clicking " navigation path ",the
device(unit) will search files automatically and it will find a file name of "01. \
SDMMC \McuUpdate_v4.0.exe ",after you click the file name, it will automatically
return to GPS navigation setup interface. At this time, usercan return(back) to
main UI interface and click the "GPS/navigation" icon, then, it will show an upgrade
GUI(screen), after user clicks the upgrade, the device will run the upgrade
automatically, after it completes the automatic upgrade, it will shut down
automatically. Please see the following pictures.Notes: In the process of upgrade,
please ensure the continuous power supply(never cut off the power supply) and
keep the device(unit) opening all the time.

◆ The product is used for such cars with 12V battery and negative grounding ,
before installing this product on these cars with 24V batteries,such as truck,bus,
big coach etc.cars), please install the reduction voltage equipment firstly.
◆ To avoid short circuit of the electrical system , please firstly switch off the
negative electrode terminal's wire of the batter before installing it .
◆ Please arrange the wiring in some place where can be fixed, thus, keep it no way
to touch any moving parts , such as the handbrake ,gear lever, etc ; Do not arrange
the wiring in the heat source area , such as near the heater discharge outlet ,
otherwise,the heat source will cause the wiring insulation layer was melted or
worn,thus,it will cause short-circuit between the wiring and the car body .
◆ When replacing the blown fuse ,you must use (10A) fuse as ruled. If use high -
capacity rated fuses to replace ruled fuses, or no use fuses to direct connect,
very easy to cause a fire ordamage the device.
◆ Do not let the yellow power cord go through the engine mounting hole and
introduced with warehouse positions to connect the battery , otherwise, it may
damage the power line,then, it will cause short circuit between power line and
car body .
◆ Do not connect this product's power line with other devices's power lines ,
otherwise, it will cause overloading to change overheating.
◆ Please use insulation paste to wrap the leading wire of unused speaker, so as to
avoid(prevent) short circuit,please ensure that the leading wire of unused
speaker gets insulation, otherwise it will cause a short circuit.
◆ Please ensure that keep any exposed wires to get insulation,meanwhile,bundling
all electric wires very well , avoiding any connection terminals to touch the
metal parts of this device's body,thus, it can prevent short sircuits.
◆ If your car's ignition does not have ACC position , please use ignition switch key
to connect ignition wire/lead onto this on/off power source.
◆ When turning on the power source , external power amplifier control signal
leads AMP. CONT outputIf this device(unit) connected an external amplifier ,
please do not connect AMP. CONT leading wire to the end of power amplifier,
otherwise, it will cause electric leakage and fault.
◆ For this product, forbidden its loudspeaker output terminals to connect ground
wire,otherwise it will burn out the amplifier. Do not use such loudspeaker system
with the common ground wire and three kinds of wires styles,no permitting to
connect the loudspeaker to car body.
◆ The loudspeaker which connects this device(unit) must be high-power type, the
minimum rated value is 50W, impedance values(resistance value) is 4Ω, please
don't directly connected a severalof speaker leads or impedance values
(resistance value) outside of this range, otherwise,it will cause short circuit and
damage the loudspeakers.
The notes about the full unit's connection diagram

◆ 30 storage radio stations (FM × 18pcs, AM12 ×pcs) .
◆ Automatic , semi-automatic and manual search , preset memory radio stations.
◆ Be compatible with DVD-R, DVD-RW, DVD + R, DVD + RW, CD-R,CD-RW CD-DA,
MP3, WMA, SVCD, VCD and MPEG1, MPEG2,MPEG4, JPEG format discs .
◆ Analog TV(ATV) ◆ Digital TV(DTV)
◆ 2 roads'AUX inputs. ◆ 1 way rear view camera input.
◆ four-channes' amplifier output,which can be directly speaker.
◆ 2 +1 channel audio output.
◆ Automatic reversing rear view mirror .
◆ Full function infrared remote control and touch function .
◆ Be compatible with DVD-R, DVD-RW, DVD + R, DVD + RW, CD-R,CD-RW
CD-DA, MP3, WMA, SVCD, VCD and MPEG1, MPEG2,MPEG4, JPEG format discs .
◆ Supports SD port and USB(2.0) port.
Functions and features
Radio functions
DVD disc playing functions.
TV functions(optional)
Aux input,output,amplifier and other functions
USB/SD card playing functions
DVR video input function
IMUSIC function
◆ This product supports I MUSIC, it can play the inner music through Apple's
own USB cable to direct connection.Because it adopted the Apple company's
certified chip , so it can support the latest Apple models.
Note: Because Apple control protocol does not support dragging playback ,
so, under the playback screen , it doesn't support to dragging when playing.
The product can't support the playing functions until you installed Apple
authentication chip.
◆ The product can support external DVR(outside) function. Such function
just supports our company's DVR products( optional ).
Notes: This product hard disc only supports FAT32/EXFAT format's file system.

◆ 1080p Full format decoding , which can decode the vast majority of film sources.
◆ Supports lossless musics .
◆ Full-digital DVD, no analog signal, shows is absolutely clear.
◆ Real 5.1 sound channel.
◆ Audio DSP processing , 10 -band EQ to enhance the listening experience
◆ Shutdown status,a second response to reversing.
◆ Music mode supports digital optical fiber .
◆ Quad-core processing ( dual ARM core + DSP core + servo core) .
◆ Songs support jacket pictures display , frequency spectrums display and lyrics display .
◆ High-speed DDR3 memory , main frequency up to 800M.
◆ Very swift ability to receive the satellite.
◆ Bluetooth supports telephone book , contacts sorting and searching and contacts
address display(show) . It also supports background services , a key GPS navigation
more convenient and safer.
Platform features

1.Do not expose the unit in the damp environment to prevent from fire or electric
shock accident.
2.Any change or modification to this unit without the clear priorconsent of the
authorization party may bring inconvenience to the users.
3.This unit is made up of high-precision accessories,do not dismantle the device
or adjust any accessories inside this device ifwithout authorization.
4.Do not touch the display screen with hard objects, so as to avoid scratching the
screen.
5.Please don't install this device in these placeswhich is in the way of driver's view
or effect driving.
6.To avoid any traffic accidents as driver's distraction,please don't operate this
device when driving, if needing to operate, please park the car in a safety
place first.
7.This device is fit for such cars with 12V power supply battery system of cathode
ground wire,please do not install this device to 24V battery's trucks or buses.
Warning

Thank you very much for purchasing and using our digital car audio-visual
series products! To ensure you can use this product correctly,please read this
user manual carefully before use it and keep it well for your future reference.
Laws of some countries prohibit users from watching TV or otherprograms and
performing related operations when driving.For your personal safety,please do
not watch videos,TV and other related operations while driving.
The system is only for assistant function when reversing(backing) ,we accept no
any responsibility for any accidents caused during reversing(backing).
●
●
Class 1 Laser Products
We have the rights not to inform in advacne if the product descriptions in this
manual have any changing.
Safety Warning
Thank patronage!
