XUMA CKL-112B User manual
CKL-112B
Bluetooth
Keyboard Case
for iPadand new iPad
User Manual
Welcome
Congratulations on the purchase of your new Xuma Bluetooth
Keyboard Case for the iPad 2 and new iPad. This case features a
removable Bluetooth keyboard housed in a stylish, textured folio
iPad case. You can store your iPad in the case, and when you’re ready
to type, just open the folio, prop up your iPad, and pair it with the
keyboard. The keyboard charges via USB, features an ultraslim design,
and boasts seventeen shortcut keys for maximum functionality.
Here are some basic instructions
to get you through the setup
& synchronization process.
Thank you for
choosing Xuma.
Overview & Charging
A. Box Contents
. Folio case
. Removable Bluetooth Keyboard
. USB Charging Cable
. User Instruction Manual
(this booklet)
Charging
To charge the keyboard, use the included
USB charging cable to connect it to your
computer’s USB port (Figure
or to a USB AC adapter (not included).
The charging light will glow when the
unit is charging, and will turn o when it
reaches a full charge. (Figure
The charging light will blink
when battery power is low.
Figure : Micro USB charging port Figure : Charging light
Getting Started
. Pull out the tab from behind the iPad
sleeve. Line up your iPad with the
sleeve, making sure that the front
and rear cameras line up with the
corresponding holes in the iPad case.
. Insert the iPad into the sleeve
(Figure , and secure it by fitting
the tab between the iPad and
the case. (Figure
. To convert the case to a stand for
viewing and working, open the folio
so the iPad is at a right angle to the
keyboard.
. Pull the bottom of the iPad away
from the case, so it rests securely on
the area above the keyboard.
. Remove the keyboard from the
case if you want to control the iPad
remotely, or if you want to pair the
keyboard with a dierent Bluetooth
device. You can use the keyboard
from up to 33 feet (10 m) away.
When replacing the keyboard in the
case, make sure to line it up with the
integrated magnets on the inside of
the folio. (Figure 5
Getting Started
Figure
Figure
Figure
When replacing the keyboard
in the case, make sure to fit
the tab behind the keyboard
to hold it in place.
Pairing Up the Keyboard
. Turn on the keyboard by moving the
power switch to the ON position.
The pairing light will briefly glow.
. To enter pairing mode and make
your keyboard discoverable, press
the pairing button. The pairing light
will blink in pairing mode.
. On your iPad, select
Settings > General > Bluetooth.
(Figure
. Select ON to activate the iPad’s
Bluetooth feature. The iPad will
automatically search for available
Bluetooth devices.
. Select Bluetooth Keyboard from the
list of discovered Bluetooth devices.
. Type in the four-digit code that
appears onscreen and press ENTER.
Device Pairing
Figure
Once the initial setup is
complete, your iPad will
automatically recognize your
Xuma keyboard for future use.
Keyboard Functions
Shortcut Keys
The shortcut keys are shortcuts to
various functions on your iPad. They are
located in the top row, directly above
the number keys.
Volume up
Volume down
Mute
Press once for next track
Press and hold for fast forward
Press once for previous track
Press and hold for fast rewind
Play/Pause
Onscreen keyboard
Brightness up
Brightness down
Home
Paste
Copy
Select all
Spotlight search
Cut
Picture frame mode
All
Activates and deactivates
sleep mode on iPad
Press the fn key + the space
bar to switch the keyboard
language.
Sleep Mode / Troubleshooting
Sleep Mode
When the keyboard is inactive for fifteen
minutes, it will enter sleep mode in order
to conserve power. Press any key and wait
for the keyboard to turn back on; it may
take a few seconds.
Troubleshooting
Following are a few common problems
that may arise during the operation of
your Bluetooth wireless iPad Case, and
basic troubleshooting solutions to avoid
them.
The keyboard does not
respond.
The wireless keyboard
is not pairing up with
the iPad.
The keyboard will not
charge.
Make sure that the wireless keyboard is turned on,
and that the battery is charged.
Make sure the USB cable is properly connected to
the wireless keyboard and the power source.
If you are using a USB AC adapter (not included),
make sure that it has an output of at least one
ampere-hour (Ah), and that it is properly plugged
into the power outlet.
Make sure that the wireless keyboard and the iPad
are turned on, and that their batteries are charged.
Make sure the wireless keyboard is within operating
distance of the iPad ( feet, or m).
Make sure the iPad’s Bluetooth setting is turned on.
Make sure to select Bluetooth Keyboard on the iPad’s
list of discovered Bluetooth devices.
If there are multiple Bluetooth Keyboards in the
iPad’s list of discovered Bluetooth devices, make sure
to select the right one.
Problem Solution
LIMITED ONEYEAR WARRANTY
Xuma provides a limited warranty that this product is free from defects in materials
and workmanship to the original purchaser under normal use for a period of one
() year from the original purchase date or thirty () days after replacement,
whichever occurs later (the “Warranty Period”). Our responsibility with respect to
this limited warranty shall be limited solely to repair or replacement, at its option,
of any product which fails during normal consumer use.
To obtain warranty coverage during the Warranty Period, contact your place of
purchase (“Seller”) to obtain a return merchandise authorization (“RMA”) number,
and return to Seller the defective product along with proof of purchase and the
RMA number.
This warranty does not extend to damage or failure which results from misuse,
neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT
AS PROVIDED HEREIN, XUMA MAKES NEITHER ANY EXPRESS WARRANTIES
NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. This warranty provides you with specific legal rights, and you may also
have additional rights which vary from state to state.
www.XumaUSA.com © Copyright 2012 Xuma
