XUMA KMA-112S User manual

KMA-112S
Bluetooth Aluminum
Keyboard
for new iPad and iPad 
User Manual

Welcome
Congratulations on the purchase of your new Xuma Bluetooth
Aluminum Keyboard Case for the new iPad and iPad .
This case features a Bluetooth keyboard housed in a durable aluminum
iPad case. You can store your iPad in the case, and when you’re
ready to type, just remove your iPad, prop it up with the integrated
stand, and pair it with the keyboard. The keyboard charges via USB,
features a slim design, and boasts seventeen shortcut keys for
maximum functionality.
Here are some basic instructions
to get you through the setup
& synchronization process.
Thank you for
choosing Xuma.

Overview & Charging
A. Box Contents
. Aluminum keyboard case
. USB charging cable
. User instruction manual
(this booklet)
Charging
To charge the keyboard, use the included
USB charging cable to connect it to your
computer’s USB port (Figure 
or to a USB AC adapter (not included).
The charging light will glow when the
unit is charging, and will turn o when it
reaches a full charge. (Figure 
Figure : Micro USB charging port Figure : Charging light
The charging light will blink
when battery power is low.


Getting Started
. Match up the iPad’s headphone
jack and dock connector port with
the corresponding cutouts on the
case (Figure .
. Place the iPad facedown into
the case and press firmly on the
corners until secure.
. Remove the iPad from the case by
gently pulling on the corner of the
case nearest the camera. The iPad
will separate from the case and
you will be able to pull it out easily.
. To convert the case to a stand for
viewing and working, place the
iPad in the well and gently let go.
The case supports both landscape
and portrait positions.
. If you want to adjust the viewing
angle, pull up the integrated
kickstand and set its rear feet in
the appropriate notches.
Getting Started
Figure : Headphone jack Figure : Kickstand
When you are ready to store the
iPad, make sure to return the
kickstand to its flat position.
Note: When setting up the
iPad in portrait position, be
sure to use the kickstand to
provide adequate support
(Figure 4).


Pairing Up the Keyboard
. Turn on the keyboard by moving the
power switch to the ON position.
The STATUS light will briefly glow.
. To enter pairing mode and make
your keyboard discoverable, press
the bluetooth button. The STATUS
light will blink in pairing mode.
. On your iPad, select
Settings > General > Bluetooth.
(Figure 
. Select ON to activate the iPad’s
Bluetooth feature. The iPad will
automatically search for available
Bluetooth devices.
. Select Bluetooth Keyboard from the
list of discovered Bluetooth devices.
. Type in the four-digit code that
appears onscreen and press ENTER.
Once paired, the STATUS light will
continue to blink at a slower pace.
Device Pairing
Figure 
Once the initial setup is
complete, your iPad will
automatically recognize your
Xuma keyboard for future use.

Keyboard FunctionsKeyboard Functions
Shortcut Keys
The shortcut keys are shortcuts to
various functions on your iPad. They are
located in the top row, directly above
the number keys.
Press the fn key + the space
bar to switch the keyboard
language.
Volume up
Volume down
Mute
Press once for next track
Press and hold for fast forward
Press once for previous track
Press and hold for fast rewind
Play/pause
Onscreen keyboard
Brightness up
Brightness down
Home
Paste
Copy
Select all
Spotlight search
Cut
Picture frame mode
All
Activates and deactivates
sleep mode on iPad

Sleep Mode / Troubleshooting
Sleep Mode
When the keyboard is inactive for
fifteen minutes, it will enter sleep mode
in order to conserve power. Press any
key and wait for the keyboard to turn
back on; it may take a few seconds.
Troubleshooting
Following are a few common problems
that may arise during the operation
of your Bluetooth wireless iPad Case,
and basic troubleshooting solutions to
avoid them.
The keyboard does not
respond.
The wireless keyboard
is not pairing up with
the iPad.
The keyboard will not
charge.
Make sure that the wireless keyboard is turned on,
and that the battery is charged.
Make sure the USB cable is properly connected to
the wireless keyboard and the power source.
If you are using a USB AC adapter (not included),
make sure that it has an output of at least one
ampere-hour (Ah), and that it is properly plugged
into the power outlet.
Make sure that the wireless keyboard and the iPad
are turned on, and that their batteries are charged.
Make sure the wireless keyboard is within operating
distance of the iPad ( feet, or  m).
Make sure the iPad’s Bluetooth setting is turned on.
Make sure to select Bluetooth Keyboard on the iPad’s
list of discovered Bluetooth devices.
If there are multiple Bluetooth Keyboards in the
iPad’s list of discovered Bluetooth devices, make sure
to select the right one.
Problem Solution

LIMITED ONEYEAR WARRANTY
Xuma provides a limited warranty that this product is free from defects in materials
and workmanship to the original purchaser under normal use for a period of one
() year from the original purchase date or thirty () days after replacement,
whichever occurs later (the “Warranty Period”). Our responsibility with respect to
this limited warranty shall be limited solely to repair or replacement, at its option,
of any product which fails during normal consumer use.
To obtain warranty coverage during the Warranty Period, contact your place of
purchase (“Seller”) to obtain a return merchandise authorization (“RMA”) number,
and return to Seller the defective product along with proof of purchase and the
RMA number.
This warranty does not extend to damage or failure which results from misuse,
neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT
AS PROVIDED HEREIN, XUMA MAKES NEITHER ANY EXPRESS WARRANTIES
NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. This warranty provides you with specific legal rights, and you may also
have additional rights which vary from state to state.
www.XumaUSA.com © Copyright 2012 Xuma
