Xware 9200 User manual

GB - 0
DivX Player
9200
USER’S MANUAL

GB - 1
Table of Contents
CHAPTER 1 GETTING STARTED........................................ 2
:: WELCOME ...................................................................................................................... 2
Features....................................................................................................................... 2
Special Features........................................................................................................ 2
Compatible Discs ...................................................................................................... 2
Region code................................................................................................................ 2
:: SAFETY PRECAUTIONS ................................................................................................... 3
:: SAFETY INSTRUCTIONS ................................................................................................. 4
:: TERM.............................................................................................................................. 6
:: PLAYER OVERVIEW ........................................................................................................ 7
CHAPTER 2 CONNECTIONS....................................... 9
:: CONNECTING THE PLAYER ............................................................................................. 9
Step 1 - Connect TV................................................................................................. 9
Step 2 - Connect Audio Components................................................................ 10
CHAPTER 3 SETUP....................................... 11
SETUP MENU CATEGORIES............................................................................................... 11
CHAPTER 4 BASIC OPERATIONS.................................... 17
PLAYING DVD, CD OR VCD ........................................................................................... 17
ADDITIONAL DISC PLAYBACK OPTIONS........................................................................... 17
CHAPTER 5 ADVANCED FEATURES..................................... 18
USING THE DVD’S MENU ................................................................................................ 18
PLAYING VIDEO CDS WITH PBC FUNCTIONS ................................................................ 18
MP3 FILE PLAYBACK ........................................................................................................ 18
PHOTO FILE PLAYBACK..................................................................................................... 19
MPEG-4 FILE PLAYBACK ................................................................................................. 20
MPEG-1/2 FILE PLAYBACK............................................................................................. 20
:: SPECIAL PLAYBACK FEATURE....................................................................................... 21
Repeat Play............................................................................................................... 21
A-B Repeat................................................................................................................ 21
Searching for a Particular Point on a Disc....................................................... 21
A-TIME ....................................................................................................................... 21
Zoom .......................................................................................................................... 22
Angle .......................................................................................................................... 22
OSD............................................................................................................................. 22
Subtitle Selection.................................................................................................... 22
AUDIO Selection...................................................................................................... 23
Resume Playback.................................................................................................... 23
Program Playback................................................................................................... 23
CHAPTER 6 HELP.......................................... 25
:: TROUBLESHOOTING..................................................................................................... 25
:: SPECIFICATIONS ......................................................................................................... 26

GB - 2
Chapter 1 Getting Started
:: Welcome
Congratulations on your purchase of this MPEG-4 player!
Features
•Full compatibility with DVD, SVCD, VCD, CD, MP3 and Kodak Picture CD.
•Dolby® Digital Decoding Compatible.
•Component Video, SCART Video outputs.
•Digital audio coaxial output.
Special Features
•Support MPEG-4 video disc, including DiVX and XViD.
•Firmware updatable
Compatible Discs
This MPEG-4 player can play discs with the following logos:
•DVD Video (from DVD Disc, and DVD±R/RW)
•MPEG-4 Video (from CD/DVD Disc, DVD±R/RW and CD-R/RW)
•Audio CD (from CD Disc, and CD-R/RW)
•Video CD (from CD Disc, and CD-R/RW)
•MP3 files (from CD/DVD Disc, DVD±R/RW and CD-R/RW)
•Kodak Picture CD (from CD Disc, and CD-R/RW)
Region code
The region number of this unit is 2, if the region number printed on the DVD disc does not
correspond to the region number of this unit, this unit can not play that disc.
DVD labeled “ALL” will also play on this unit

GB - 3
:: Safety Precautions
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). NO
USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
This symbol indicates “dangerous voltage” inside the product that presents a risk of electric
shock or personal injury.
This symbol indicates important instructions accompanying the product.
CAUTION: THE PLAYERS USE AN INVISIBLE LASER BEAM WHICH CAN CAUSE HAZARDOUS RADIATION
EXPOSURE IF DIRECTED. BE SURE TO OPERATE PLAYER CORRECTLY AS INSTRUCTED.
WARNING
To reduce the risk of fire or shock hazard, do not expose the PLAYER to rain or moisture.
CAUTION
THIS PRODUCT UTILIZES A LASER. ANY USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVER,
AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.
Handling Cautions
•Before connecting other components to the PLAYER, be sure to turn them all off.
•Do not move the PLAYER while a disc is being played, as the disc may be scratched or broken and the unit's internal parts may
be damaged.
•Do not put a flower vase filled with water or any small metal object on the PLAYER.
•Be careful not to put your hand into the disc tray.
•Do not place anything other than the disc in the disc tray.
•Exterior interference such as lightning and static electricity can affect normal operation of this unit. If this occurs, turn the DVD
PLAYER off and on again with the POWER button, or disconnect and then reconnect the AC power cord to the AC power outlet.
Then, the unit will operate normally.
•Be sure to remove the disc and turn off the PLAYER after use.
•Disconnect the AC power cord from the AC outlet when you don’t intend to use the PLAYER for long periods of time.
•Clean the disc by wiping in a straight line from the inside to the outside of the disc.
Disc Storage
Be careful not to harm the disc because the data on these discs is highly vulnerable to the environment.
•Do not keep under direct sunlight.
•Keep in a cool ventilated area.
•Store vertically.
•Keep in a clean protection jacket.

GB - 4
:: Safety Instructions
1. Read Instructions - All the safety and operating instructions should be read before the product is operated.
2. Retain Instructions - The safety and operating instructions should be retained for future reference.
3. Heed Warnings - All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions - All operating and using instructions should be followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the product manufacturer as they may cause
hazards.
7. Water and Moisture - Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a swimming pool; and the alike.
8. Accessories - Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall,
causing serious injury to a child or adult and serious damage to the product. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer or sold with the product. Any mounting of the product should
follow the manufacturer instructions and a mounting accessory recommended by the manufacturer should be used.
9. Cart Usage - A product and cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart combination to overturn.
10. Ventilation - Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of
the product and to protect it from overheating. These openings must not be blocked or covered.
The openings should never be blocked, for example, by placing the product on a bed, sofa, rug, or other similar
surfaces. This product should not be placed in a built-in installation such as a bookcase or rack unless proper
ventilation is provided or the manufacture instructions have been adhered to.
11. Power Sources - This product should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supplied to your home, consult your product dealer or local power
company. For products intended to operate from battery power, or other sources, refer to the operating instructions.
12. Grounding or Polarization - This product may be equipped with a polarized alternating current line plug (a
plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully
into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug.
13. Power - Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the product.

GB - 5
14. Lightning - For added protection for this product during a lightning storm or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line surges.
15. Power Lines - An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with
them might be fatal.
16. Overloading - Do not overload wall outlets, extension cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.
17. Object and Liquid Entry - Never push objects of any kind into this product through openings as they may touch
dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind
on the product.
18. Servicing - Do not attempt to service this product yourself as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
19. Damage Requiring Service - Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a When the power-supply cord or plug is damaged.
b If liquid has been spilled or objects have fallen into the product.
c If the product has been exposed to rain or water.
d If the product does not operate normally by following the operating instructions. Adjust only those controls
that are covered by the operating instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to restore the product to its normal
operation.
e If the product has been dropped or damaged in any way.
f When the product exhibits a distinct change in performance-this indicates a need for service.
20. Replacement Parts - W hen replacement parts are required, be sure the service technician has used
replacement parts specified by the manuf acturer or that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other hazards.
21. Safety check - Upon completion of any service or repairs to this product, ask the service technician to perform
safety checks to determine that the product is in proper operating condition.
22. Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.

GB - 6
:: Term
What are Title/Chapter and Track?
Title/Chapter (DVD)
DVDs are divided up into large sections, titles, and smaller sections, chapters. The numbers allocated to
these sections are called title numbers and chapter numbers.
DVD
Track (VCD/CD)
Video CDs and CDs are divided up into sections called tracks, and the numbers allocated to these sections
are called track numbers.
VCD/CD
What is MPEG-4?
MPEG-4 is a video compression standard developed by an industrial group called 'Moving Picture Experts
Group' or 'MPEG' for short. MPEG-4's official description by the MPEG is 'a standard for Very Low Bitrate
Audio-Visual Coding'. Many of the standards developed by this group are accepted standards by the ISO
(International Standards Organization) and are therefore also called ISO-standards. MPEG-4 is ISO/IEC
standard #14496. The MPEG standards are widely accepted by the media industry and you can find them in
VCD's, DVD's, mp3's and all sorts of other applications.
To compress a high quality 2 hour video clip to something that can fit on a single CD obviously takes some
serious compression tactics. MPEG-4 does this partly by removing information that we don't notice and partly
by transforming the raw pixel data into a mathematical approximation of that data. The approximation is close
enough for us mere humans not to notice the difference between the source and the result (well, at least in
theory).
What are XViD, DiVX?
Both of them are video codec (encoder/decoder) base on MPEG-4. Each of them can encode a video-file into
a (hopefully) MPEG-4 compliant data stream which can be saved into a container-file like an .avi, .ogm, .mp4
or others. The unit has a built-in MPEG-4 decoder, with it you can play XViD and DiVX video disc.
Example:
Title1 Title2
Chapter1 Chapter2 Chapter3 Chapter 1
Example:
Track1 Track2 Track3 Track4

GB - 7
:: Player Overview
Rear Panel
1. Sub-woofer audio output:
2. Centre audio output
3. Right surround audio output
4. Left surround audio output
5. Right front audio output
6. Left front audio output
7/8/9. Component video output
10. Composite video output
11. S-Video output
12. SCART output
13. Digital coaxial audio output
Front Panel Controls
1. Mains Switch: Switches the unit to Power ON and OFF.
2. PLAY: Start to play back in normal speed.
STOP: Stops playback.
3. PREV: Press this to move back to the beginning of the previous chapter/track
NEXT: Press it to move ahead to the beginning of the next chapter/track
4. FAST REWIND: Fast reverse play
FAST FORWARD: Fast forward play
5. OPEN/CLOSE: Open disc tray or close it.
6. Disc Tray: Please put the disc with label facing up carefully.
7. Front Panel Display: Displays feedback information on player operation.
*Although STANDBY is in off position, the appliance is not completely disconnected from power supply.
FRONT PANEL DISPLAY
1. DVD Disc indicator: when a DVD disc is loaded, the word “DVD” will light up.
2. VCD Disc indicator: when a VCD disc is loaded, the word “VCD” will light up.
3. Working status indicator: the symbol Xwill light up during playback, when you press the
“PAUSE” button, the symbol || will light up.
4. CD Disc indicator: when a CD disc is loaded, the word “CD” will light up.
5. Dynamic tray indicator: when a disc is loaded and playing it will light up and rotate.
6. Time display: display the elapsed time or remaining time.
7. Dolby Digital audio indicator: light up when Dolby digital format audio is playing.
8. DTS indicator: light up when DTS format audio is playing.

GB - 8
Remote Control
1. STANDBY: Switch the unit standby condition.
2. REPEAT: Repeat titles, chapters, songs, etc.
3. A-B: Specify the parts you want to play repeatedly
4. MUTE: Switch sound on and off
5. Y. P b . P r : Switch progressive scan mode on and off
6. DISPLAY: Display information about playback status on screen.
7. FAST REWIND: Fast reverse play
8. VOLUME +: Increase the sound output level
9. PREV: Press this to move back to the beginning of the previous
chapter/track
10. VOLUME -: Decrease the sound output level
11. STEP/PAUSE: Once press it will stop playback and freeze current
picture, press it repeatedly will play one frame at a time, use
PLAY to resume normal playback
12. MENU: Recall DVD’s ROOT menu or VCD 2.0 menu during
playback
13. TITLE/PBC: Recall DVD’s TITLE menu during playback ；
Enable/Disable PBC function during VCD playback, it can allow
you play VCD interactively by following the menu on the TV
screen
14. g/h/i/j: Use them to navigate on-screen menus
15. AUDIO: Change the status to make Audio change possible
16. SUBTITLE: Change the status to make Subtitle change possible
17. NUMBERS: Select the chapter or track by pressing number
buttons directly
18. A-TIME: Go to a specific location on a CD/DVD disc directly
19. OPEN/CLOSE: Open/Close disc tray
20. PROGRAM: Create your own play lists
21. DOLBY PRO LOGIC II: Switches Dolby Pro Logic II mode on and
off
22. FAST FORWARD: Fast forward play
23. NEXT: Press it to move ahead to the beginning of the next
chapter/track
24. STOP: Stop playback
25. SETUP: Call the screen for Player's initial setting, such as Menu
language, parental level
26. RETURN: Go back to the specified position defined by Contents
provider
27. PLAY (ENTER): Start to play back in normal speed, or activates
the selected item on interactive menu
28. CLEAR: It is used to clear the play list, or the wrong digit input
29. ANGLE: Switch among available angles if any
30. ZOOM: Zoom in and zoom out when watch video
Inserting batteries into the remote control:
The supplied remote control unit can be used to control the player. Insert two
'AAA' type batteries into the compartment, matching + and - as indicated on the
inside of the battery housing. The remote control must be pointed direct to the
unit.
NOTE:
1. Avoid exposing the remote control to extremes of temperature e.g. direct sunlight.
2. Ensure that no foreign objects enter the battery housing, especially metal objects.
3. If the unit's infrared sensor is bathed in strong direct sunlight, or intense artificial light, then it may not be able to
receive signals sent from the handset.
4. If the remote control is not to be used for an extended period’s time then please remove the batteries to avoid
leakage and corrosion.

GB - 9
Chapter 2 Connections
:: Connecting the Player
Follow these steps to connect the player to your TV set and audio system. It is
recommended that you turn off power on all components while you are connecting the
player.
Step 1 - Connect TV
Choose one appropriate video connection from ○
2to ○ 5methods:
○
1 Stereo Audio: Connect to the left/right audio inputs of your TV set;
○
2 Composite Video: This connection is popular; you can find the composite video input jack
on the back panel of most TV set. With this connection, Video Setup should be set to
OFF in the VIDEO menu.
○
3Component Video: COMPONENT connector is one of video standard in America and
China. It can offer the best picture quality, and it can still transmit progress scan
signal. To finish this connection you must connect the unit and TV set by using three
cables, and each of component video jacks had been marked as Y/Pb/Pr(Y/Cb/Cr),
please connect them one to one correctly. With this connection, Video Setup should be set to
YUV in the VIDEO menu.
○
4 S-video: A TV set usually support composite video or s-video input, but s-video connection
can offer better picture quality than composite video connection. With this connection,
Video Setup should be set to OFF in the VIDEO menu.
○
5 SCART: SCART connector is one of video standard in Europe; it can transmit both video and
audio signals.

GB - 10
Step 2 - Connect Audio Components
Choose one appropriate audio connection from three methods:
○
15.1 Channels Audio: Connect 5.1 channels audio output of the unit and corresponding
input of amplifier by 5.1 channels audio cable, please set “OFF” mode in “speaker setup page”
○
2Stereo Audio: Connect to the left/right audio inputs of your TV set, or 2-channel analog
amplifier. With this connection, all Analog Out options should be set to 2 channels mode：LT/RT、
Stereo、V SURR.
○
3Digital Audio (Coaxial): Connect to the coaxial digital audio input of your amplifier. With
this connection, all SPDIF options should be set to SPDIF/RAW or SPDIF/PCM.

GB - 11
Chapter 3 Setup
Setup Menu Categories
You can adjust player preferences and function on player Setup menu:
Setup menu How to setup?
Press SETUP button to enter setup menu
○
1 Main menu:
Move cursor to highlight the submenu heading on main menu
by pressing g/h(left or right) buttons.
○
2 Submenu:
Press PLAY button to enter its submenu, The gbutton can be
used to exit submenu and return to the main menu. Press i/j
（up or down ）to move up or move down selection of
submenus
○
3 Option menu:
Select the item you want to setup and press PLAY or h
button to enter the option setup menu, use i/jbuttons
select your desired setting and press PLAY to activate it.
Press gbutton to return to the submenu.
General Setup Page
TV Display
Depending on the type of television you have, you may want to adjust the screen setting
(aspect ratio)
Normal/PS: You can see the central portion of the Anamorphic widescreen picture on 4:3 TV. The extreme left
and right side of movie picture will be cut off.
Normal/LB : You will see the total Anamorphic widescreen picture on 4:3 TV, but black bars will appear at the top
and bottom of the screen
Wide: Select it if you are connecting the player to a wide screen TV set. However, DVDs recorded with 4:3 ratio
cannot be viewed as the full 16:9 picture even if you made this setup.
For example:
Angle Mark
Set it on:
When playing multi-angle DVD disc, a logo like
will be shown automatically on top right TV screen, it
mean that the DVD you are playing has two angle
and you are watching the first angle, you can change
viewing angle by pressing ANGLE button on remote
control.
Set it off:
The player will not display the angle mark, though
you are playing multi-angle DVD disc.
Captions
Set it on:
Make sure that the DVD disc you are playing has a captions
on it, and change your TV color system to NTSC format, then
a caption maybe show on TV screen, or not, because a few
TV set can support display captions.
Set it off:
Disable the function, caption will not be shown.
Notice:
It is quite different from subtitle, subtitle is used to explain the
vocal, and captions not only explain it but also give you more
information about film. It is very useful for deaf man.
..General Setup Page..
TV Display PS Normal/PS
Normal/LB
Wide
Angle Mark
OSD Language
Captions
Screen Saver
Last Memory
Set TV Display Mode
○
2
○
3
○
1

GB - 12
OSD Lang
Select your desired language for the player’s
on-screen display and setup menu.
Last Memory
Set it on:
The unit can automatically start to play the
disc（DVD/VCD/CD）from the last position
when you enable this function.
Set it off:
Set it off the unit will always play it from
beginning.
Screen saver
Set it on:
When there is no activity with the player for several minutes, a
moving picture will be shown on screen to prevent your monitor
from damage, which is call screen saver.
Set it off:
Disable this function, and screen saver will not appear always.
Notice:
During playback the player will automatically disable screen saver
Audio Setup Page
Speaker Setup
Downmix
The unit can mix a multi-channel sound to
encode a two-channel sound, it’s called
downmix.
LT/RT: for Dolby Pro Logic Surround stereo
sound output. It is a matrix encoding process
enabling stereo soundtracks to carry four
channels of audio information—left, center,
right, and surround.
Stereo: for analog stereo sound output. The
unit will send the subwoofer and vocal signal
to your Front Left and Front Right speakers.
V SURR: for listening to virtual surround
sound effect. The unit provide audio
virtualization for two-channel speaker
configuration and created realistic surround
sound from those two speakers.
Off: enable 5.1 channel discrete
surround-sound output
Front speaker/Center speaker/Rear
speaker/Subwoofer
If the DOWNMIX mode is turned OFF, then select how you want
your Front Speakers or Rear Speakers or Center Speaker to be
set; either to small (standard setting) or to large. Large means
that Bass & Treble audio is sent to the speakers. Small means
only Treble audio is sent to the speakers.
You can also switch off the Center Speaker, the Rear L/R
Surround Speakers and subwoofer.
We suggest you switch the subwoofer on in order to hear more
bass sound.
Test To n e :
For test only, the unit will generate a full surround sound signal to
test multi-channel speakers connection. First the unit will send a
signal to Left speaker (you can check the channel information on
information bar), if you connect you speaker correctly then you will
hear the sound from your left side. And then center, right, right
surround, and left surround will be continue
Dialog
When the DOWNMIX is set to LT/RT or
Stereo mode, you can adjust the volume of
dialogue sound.
Post DRC
This function limits the maximum volume setting to avoid
loudspeaker damage.
The standard setting is Auto
ON: Limits the maximum volume.
Off: Switches this function off, please be aware the volume now
can be set so high that the possibility exists you can damage the
loudspeakers.
..Audio Setup Page..
Speaker Setup
SPDIF Setup
Dolby Digital Setup
Channel Delay
Equalizer
3D Processing
Go To Audio Setu
p
Pa
g
e
..Speaker Setup Page..
Downmix Off LT/RT
Front Speaker Stereo
Center Speaker V SURR
Rear Speaker Off
Subwoofer
Te st To n e
Dialog
Post DRC
Set Downmix Mode

GB - 13
SPDIF Setup Page
SPDIF Setup
Select the right SPDIF (Sony Philips Digital Interface) for
coaxial digital audio transmissions.
SPDIF Off: turn off digital audio transmission.
SPDIF/RAW: an untouched digital audio signal will be
transmitted.
SPDIF/PCM: for two channels audio transmissions, a
multi-channel sound will be mixed to reencode a two-channel
sound.
Manual: choose different option for each audio format. It mean
that you can select different digital audio transmission mode
for each of CD/Dolby Digital/DTS/MPEG audio format
manually.
LPCM Out: both “48k” and “96k” are sampling frequency.
Generally, high sampling frequency can give you a better sound
quality.
Dolby Digital Setup
Dual Mono:
Select Left and Right audio output mode.
Stereo: Left channel signal will be sent to left speaker, and
Right channel signal will be sent to right speaker.
L-Mono: Left channel signal will be sent to both left and right
speaker.
R-Mono: Right channel signal will be sent to both left and
right speaker.
Mix-Mono: both left and right channel audio will be mixed to
encode a mono sound, you will hear the same sound from
each speaker
Dynamic:
This Dynamic Range Compression section only applies to
DVD-titles with Dolby Digital technology.
Set it off: low range audio signals will be amplified so that
the audible volume will be increased.
Set it between full and off: Audible effects that fall in the
extreme ranges of Dolby Digital’s audio spectrum will be
compressed.
Set it full: All audible sound, from low frequency to high
frequency audio effects, will be highly distinctive and fall into
the full dynamic range of Dolby Digital.
Channel Delay
You can enjoy natural, realistic surround sound using this
function.
Move the cursor on “Channel Delay” item and press PLAY
button, and then you can adjust what distance you want
between you and different speaker (turns yellow) according to
your room layout, press left key will decrease delay value, and
press right key will increase delay value, use up and down key
to select different speaker.
..SPDIF Setup Page..
SPDIF Output RAW SPDIF Off
CD SPDIF/RAW
Dolby Digital SPDIF/PCM
DTS Manual
MPEG
LPCM Out
Setu
p
SPDIF
..Dolby Digital Setup..
Dual Mono STR Stereo
L-Mono
R-Mono
Mix-Mono
Dynamic
..Audio Setup Page..
Speaker Setup
SPDIF Setup
Dolby Digital Setup
Channel Delay
Equalizer
3D Processing
Center

GB - 14
Equalizer
The unit has a built-in equalizer; it may be useful when you
are listening to music.
Pro Logic II
Dolby Pro Logic II technology decodes 2-channel sources
such as Audio CDs, MP3s, VCDs or SVCDs into a
multi-channel surround sound environment
Only you choose multi-channel audio output you can enable
this function, please set downmix mode to OFF.
Reverb Mode
The unit can imitate following listening environment:
Concert, Living Room, Hall, Bath Room, Cave, Arena,
Church.
Video Setup Page
Component:
Select appropriate video output option for your
connection.
Off: for Composite video and S-video connection.
YUV: for component video connection.
RGB: for SCART connection.
TV Mode:
Select Interlace or Progressive Scan signal output
option for your monitor.
Interlace: for common (analog) TV types.
P-scan: for TV set supported Progressive Scan signal input,
please choose it carefully, most of TV set can’t support P-scan
signal, and blank screen will happen.
Quality:
Adjust picture quality through sharpness, brightness, contrast,
gamma, hue, saturation, luma delay option.
..Equalizer Page..
EQ Type Rock None
Bass Boost Rock
Super Bass Pop
Treble Boost Live
Dance
Techno
Classic
Soft
..3D Processing Page..
Pro Logic II
Reverb Mode Off Off
Concert
LivingRoom
Hall
BathRoom
Cave
Arena
Church
..Video Setup Page..
Component Off Off
YUV
RGB
TV Mode Interlace
P-scan
Quality

GB - 15
Preference Setup Page
TV Type: To set various color system signal for the
video output.
PAL: The TV broadcast system used in UK, Germany and
other countries. It will be output to your TV when you select
“PAL”.
Multi: Select it if you have a multi-system TV set compatible
with NTSC and PAL.
NTSC:The TV broadcast system used in Korea, Japan,
USA, Canada and other countries. Most DVD discs are
recorded in NTSC color system. This will be output to your TV
when you select “NTSC”.
PBC: play back control (for VCD
only)
Set it on: the unit will always automatically
enable this function at beginning.
Set it off: the unit will always automatically
disable this function at beginning.
Subtitle:
Select your preferred language of subtitles recorded
on DVD.
1) The subtitle you selected will be given a high priority so it
can be automatically played at beginning.
2) Subtitle varies from disc to disc. depending on the DVD
You can also select different subtitle by using SUBTITLE button
on the remote control.
Audio:
Select your preferred language of
audio recorded on DVD.
1) The language you selected will be
given a high priority so it can be
automatically played at beginning.
2) Language varies from disc to disc.
depending on the DVD
You can also select different audio by using
AUDIO button on the remote control.
Disc Menu:
Select your preferred language of disc menu recorded
on DVD. It depending on the DVD.
Parental:
Playback of some DVDs can be limited according to a
predetermined level such as the age of the users. Scenes may be
blocked or replaced with different scenes. The “PARENTAL”
function allows you to set a playback limitation level. The
password is used for Parental Control.
..Preference Page..
TV Type PAL PAL
PBC Multi
Audio NTSC
Subtitle
Disc Menu
Parental
Default
..Preference Page..
TV Type 1 KID SAF
PBC 2 G
Audio 3 PG
Subtitle 4 PG 13
Disc Menu 5 PGR
Parental 6 R
Default 7 NC17
8ADULT

GB - 16
1) Move the cursor on “Parental”, then current limitation level set menu will be displayed on right side.
2) If you want to change it, just press PLAY to enter this option menu, using i/jselect a different limitation level
then press PLAY.
3) And now you may be asked for a password if you set “PASSWORD MODE” on.
4) Enter a 5-digit password using the number buttons, press PLAY to confirm it.
5) Done.
Notes:
When you play discs which don’t have the Parental Control function, playback can’t be limited on this unit.
Default
Reload factory preset.
Password Setup Page
Password Setup:
Password Mode:
Set it on: Every time you change the parental level the unit will
ask you for the password.
Set it off: you can change the parental level without enter the
password.
Password Change:
Move the cursor to
“Change” option menu;
Press PLAY, a password
change menu appears;
You must enter old
password first (default is
49540), if the old
password is correct, then you can change the password.
..Password Setup Page..
Password Mode On
Password Change
Go To Password Setup Page

GB - 17
Chapter 4 Basic Operations
Playing DVD, CD or VCD
Follow these steps to play a DVD, CD or VCD disc:
1. Turn on the TV.
2. Set the TV to the AV input connected to the player.
3. Turn down the volume on your amplifier and then power it on.
4. Set the amplifier to the AV input connected to the player.
5. Press mains switch on front panel.
6. Press OPEN/CLOSE on the remote control or front panel to open the disc tray.
7. Place the disc in the tray with the label side facing up and playback side facing down. If the disc
has two sides, place the disc with the desired label facing up.
8. Press OPEN/CLOSE again to close the disc tray.
9. Press PLAY on the remote control or front panel. Many discs will load and begin playing
automatically when the disc tray is closed. If the DVD has a disc menu, or more than one title, the
disc menu may appear.
10. Adjust the volume of the player by pressing the VOLUME button on the remote control.
Additional Disc Playback Options
1. To freeze playback, press PAUSE/STEP.
2. To resume normal playback, press PLAY.
3. To go to the next or previous chapter/track, press NEXT or PREV 
4. To scan forward or backward at variable speeds during playback, press F.FWDor F.REW
repeatedly.
5. To stop playback, press STOP once. To resume playback from the same place on the disc, press
PLAY.
6. To stop playback completely and restart the disc, press STOP twice. To restart the disc, press
PLAY.

GB - 18
Chapter 5 Advanced Features
Using the DVD’s Menu
A DVD is divided into long sections of a
picture or a music feature called “titles.”
When you play a DVD which contains
several titles, you can select the title you
want using the TITLE button.
When you play DVDs that allow you to
select items such as the language for
the subtitles and the language for the
sound, select these items using the
MENU button.
1) Press TITLE or MENU button
2) The disc’s menu appears on the TV screen.
3) The content of the menu varies from disc to
disc.
4) Pressg/h/i/jor the number buttons to
select the item you want to play or change.
5) Press PLAY button.
Playing VIDEO CDs with
PBC functions
PBC (Playback Control) allows you to play
VIDEO CDs(2.0) interactively by following the
menu on the TV screen.
1) Start playing a VIDEO CD with PBC
functions. The menu for your selection
appears.
2) Select the item number you want by
pressing the number buttons.
3) Press PLAY button.
4) To return to the menu, press RETURN
5) Switch PBC functions On and Off by
pressing PBC button.
MP3 File Playback
You can play back DATA CDs
(CD-ROMs/CD-Rs/CD-RWs) recorded in MP3
format.
When a MP3 disc is loaded, a browse window
will be shown as follows:
1. Elapsed time of current song.
2. The whole time of current song.
3. Bitrate of this MP3 file
4. Visual volume indicator.
5. Playback status information.
6. Dynamic spectrum.
7. A-B repeat indicator.
8. Selected song sequence/total number
of songs of current folder.
9. Current folder name.
10. Go up parent directory.
11. File list.
12. Operation information.
1) Pressi/jor the number buttons to select
the song you want to play or change.
2) Press PLAY button to start to play it
3) To return to the parent directory please
press gbutton
4) Using A-TIME button, you can change
current Elapsed time and selected song
sequence, so you can directly go to your
specific point.

GB - 19
Photo File Playback
Photo CDs, including Kodak Picture CDs, contain
JPEG images that can be viewed on your
television screen easily.
When a photo CD is loaded, a browse window
appears:
1. Selected image sequence/total
number of images of current folder.
2. Current folder name.
3. File list.
4. Preview Area.
5. Resolution of current selected image.
1) Pressi/jor the number buttons to select
the picture you want to play.
2) Press PLAY to view it and go into slide show
mode.
3) During slide show you can freeze current
image by pressing PAUSE button, press
PLAY to resume slide show.
4) Press STOP the unit will stop slide show
and show you a DIGEST screen contain 12
thumbnails:
5) Select MENU item and activate it will show
you the remote key function description:
Program：Transition Effect*
Stop：Thumbnail Mode
：Next Picture
：Previous Picture
i：Invert
j：Mirror
g：Contrarotate
h：Rotate clockwise
Zoom：Switch Zoom Mode
：Zoom in
：Zoom out
g/h/i/j：Pan In Zoom Mode
* Transition Effect:
The unit supports 16 kinds of Transition Effect:
1. Wipe top
2. Wipe bottom
3. Wipe left
4. Wipe right
5. Diagonal wipe left top
6. Diagonal wipe right top
7. Diagonal wipe left bottom
8. Diagonal wipe right bottom
9. Extend from centre H
10. Extend from centre V
11. Compress to centre H
12. Compress to centre V
13. Window H
14. Window V
15. Wipe from edge to centre
16. Move in from top
17. None
Specifications:
Media Type Supported Format
File .JPG
Disc Kodak Picture CD
□
1□ 2 □ 3 □ 4
□
5 □ 6 □ 7 □ 8
□
9 □ 10 □ 11 □ 12
SlideShow Menu _Prev Next`
