Yabang VDP-C37 User manual

¿ÉÊÓ¶Ô½²ÃÅÁå
VDP-C37
Designs Subject to Change Without Prior Notice.
7”Two-wire Hand-Free Color Video Door Phone
INSTRUCTION MANUALINSTRUCTION MANUAL

BRIEF INTRODUCTIONBRIEF INTRODUCTION
INDOOR MONITOR
ÌØÊ⹦ÄÜ:
66
11
22
33
44
55
77
99
1010
1111
1212
1313
88
1414
1515
Welcome to use our video security intercom system, this 2-wire system is
newly released for villas or single houses. This products are based on CCTV
technologies, you can watch over the outside conditions on indoor monitor
through the camera built in outdoor camera unit. The dual-directional speaker
system and indoor lock-control function maximize safety by identify the visitors
before o peni ng d oor. E ven at dark night, you can see the visitors clearly with
infrared & white LEDs built in t he camer a. This product is of 2 wiring non-polarity
technologies, it is much convenient and simple for installation and popularly used
in homes, offices or businesses.
Please read these instructions carefully before installing the system and follow all of
the directions to ensure proper installation. This manual should be retained for future
reference.
.FEATURES.FEATURES
4. It can call and communicate but monitor screen illuminates with
no picture, the brightness and contrast control are not adjusted.
Switch Power Supply(SMPS) 100V 240V(50Hz/60Hz)
Power Consumption Operation 14W Standby 2W
Chime Tones Dingdong/ 8 Chord Melody Rings
Audio Communication System Duplex Hand-Free
Automatically Shutdown Time 60 Seconds
Unlock Signal Output 12V/2A 100ms
Wiring Cable between Monitor & Camera:
2
<50m: 20AWG, 0.5mm
2
>50m: 18AWG, 1.0mm
2
Door Lock Wiring: 18AWG, 1.0mm
00
Working Temperature -10 C to +40 C
. SPECIFICATIONS. SPECIFICATIONS
. STANDARD PARTS. STANDARD PARTS
1 Monitor and 1 Camera 1m Cable for Testing
User Manual
Mounting Bracket for Monitor,
Camera & Screws

OUTDOOR CAMERA
44
1
1
2
2
3
3
5
5
8
8
7
7
6
6
ODS-J ODS-5
Microphone
Wiring Terminal to Monitor L1
Speaker
Screw Holes
568
7
ODS-S ODS-2
4
4
Lock Connector UNL+ Lock Connector UNL-
Camera
568
7
Wiring Terminal to Monitor L2
Call
..
Indoor Monitor
Call Button
1. Visitor Calling: A visitor presses the Call Button on the outdoor camera unit. The
monitor's speaker will sound a chime tone to announce that a visitor is at the door
and the visitor's image will be automatically displayed on the indoor monitor.
Press Talk Button to Answer the Call
Press Call Button
OPERATIONOPERATION
Put the wired Camera Unit in the bracket, then attach a metal cover to the unit and
fix with 4 self-tapping screws.
1. Do not install the monitor and camera units where they will be exposed to direct
sunlight or other strong light and near to intense magnetic field.
Carefully read and perform the following procedures before returning your video
door phone for repairs of replacement.
Bracket Metal Tab Camera Unit Metal Cover
Cable
. IMPORTANT NOTES. IMPORTANT NOTES
2. Do turn off power of unit before cleaning. Do not use liquid or aerosol cleaners.
Use a dry cloth for body of unit.
3. Disconnect the power if you do not use the product for a long time.
4. Do not attempt to service this unit yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified
service personnel.
. TROUBLE SHOOTING GUIDE. TROUBLE SHOOTING GUIDE
1. The unit totally dead(Power Lamp off), check the power plug if it is properly inser ted
into the AC outlet or the AC is not supplied.
2. Power Lamp is dim, the wires between the monitor and camera are shorted.
3. It can call and communicate but there is no audio signal, it is due to
defective camera.

2. Talking: Press Talk Button and talk to the visitor. The visitor's image will remain
o n th e screen for 60 seconds or until you pressing the Talk Button again to finish
talking. If there is no respond, the visitor's image will disappear from the monitor's
LCD screen within 60 seconds and return to standby mode.
Hi John, here you are. Ok,
I open the door for you now.
Hi John, here you are. Ok,
I open the door for you now.
Waiting Outside Press Unlock Buttonto Release Door Lock
Press Warning Button
Siren Outside
Keep away
from my house!!
4. Monitoring: Press Monitor Button under standby mode, you will see the camera's
field of view for 60 seconds. And press Monitor Button again to close monitoring.
Outdoor View
Press Monitor Button
Sirening
3. Warning: After speaking with the visitor, and if you have installed an electronic door
locking system, you can press Unlock Button to ele ctronica lly unlock the door. If
you come into a bag guy or some one playing trick with you, you can keep pressing
Warning Button for >2 seconds, the outdoor came ra's sp eaker will siren loudly to
scare away them.
Driver for Hex Socket
Cap Screws(Provided)
Put-in
4 ODS-24 ODS-2
Drill a hole in the center area of the bracket just big enoughfor the electrical
wiring to pull through. And drill 7 small holes for the plug bolts.
Flush Box
Cable
3 ODS-S3 ODS-S
Dig a square hole which is the same size of the Flush Box in the wall and d rill a
hole in the center for wiring and 2 small holes for plug bolts.
Fix the plug bolts in the 2 small holes and put the Flush Box into the wall and
fix with 2 self-tapping screws.
Pull the wiring which connect to Monitor Unit through the central hole and
connect well with Terminals L1&L2. Also prepare 2 wires to connect with Lock
Connectors UNL+& UNL- and pull through Flush Box and central hole in the
wall and connect with the door lock.
Put the wired Camera Unit in the Flush Box and fix with 2 Hex Socket Cap Screws.
Insert and fix the plug bolts in the 7 small holes, then attach the mounting
bracket and fix with 3 self-tapping screws(please note the 3rd screw is fixed
with a Metal Tab).
Pull the wiring which connect to Monitor Unit through the central hole and
connect well with Terminals L1&L2. Also prepare 2 wires to connect with Lo ck
Connectors UNL+& UNL- and pull through Bracket and central hole in the wall
and connect with the door lock.

5. Others: 1) Effect Adjusting: Use the slide switch for Volume, Brightness & Contrast
controls to get best effect you want. 2) Optional Chime Tones: Press Talk But ton
under standby mode till the tone automatically sounds(about 5 seconds), then press
Warning Button to change tones(change with each pressing) till you find suitable
tones, press Talk Button again to confirm and set it.
3) When come to expandable system, press Intercom Button under standby mode to call
the o ther m onitors and a “ DuDu”tone is heard at the other monitors' speakers, and press Talk
Button to talk.
Press Talk Buttonfor 5s
Tone Sound Automatically.
Press Warning
Button to Change Tone.
Living Room
Bedroom
Intercom & Interphone
1. While a visitor presses Call Button, a call tone is heard which verifies the call was placed .
2. The host press Talk Button, then intercom with the visitor through microphones.
3. The unit is built in infrared & white LEDs, you can see the visitors clearly even at deep ni ght.
Outdoor Camera
2 ODS-52 ODS-5
Dig a square hole which is the same size of the Flush Box in thewall and drill
a hole in the center for wiring and 4 small holes for plug bolts.
“UNL+& UNL-”and pull through Bracket and central hole in the wall and connect
with the door lock.
Put-in
Self-Tapping Screws
Drive Screw
Tab
Cable
Pop-out
Bracket
Put the wired Camera Unit in the bracket and pop out the tab at the bottom of the
unit. Fix it with drive screw and press back the tab.
Fix the plug bolts in the 4 small holes and put the Flush Box into the wall and
fix with 4 self-tapping screws.
Pull the wiring which connect to Monitor Unit through the central hole and connect
well with Terminals L1&L2. Also prepare 2 wires to connect with Lock Connectors
UNL+& UNL- and pull through Flush Box and central hole in the wall and connect
with the door lock.
Put the wired Camera Unit in the Flush Box and fix with 4 drive screws.
Drive Screws
Put-in
Flush Box
Cable

. INSTALLATION. INSTALLATION
L1
L2 UNL+ UNL-
Slave Indoor Monitor
Master Indoor Monitor
Outdoor Camera
Door Lock
1.Wiring Diagram
1) For expandable system, please make sure it is master indoor monitor rather
than slave indoor monitor to connect with outdoor camera. There is always 1
master indoor monitor only in a system, the other slave indoor monitors should
be connected from the master indoor monitor.
L1
L2
S2
S1
L1
L2
S2
S1
L1
L2
S2
S1
Slave Indoor Monitor
1) Select a mounting location to an AC outlet but the monitor cannot be exposed to
2.Monitor Unit
3) The above figure in dotted line illustrates the standard system, that is 1 camera & 1
monitor. Maximum 1 camera can expand to work with 3 monitors.
2) This system is of 2-wire non-polarity technologies. The connection of terminals
can ignore their “+/-”polarity.
dirt, direct sunlight(or other strong light), direct moisture conditions. After determining
the location, attached mounting bracket securely to the wall.
3) Insert and fix the plug bolts in the 4 small holes, then attach the mount ing bra cket
to the wall and fix with 4 self-tapping screws.
2) Drill a hole in the center area of the bracket just big enough for the electrical wiring
to pull through. And drill 4 small holes for plug bolts.
Notes:
3. Camera Unit
The monitor is compatible with several camera units (ODS-J/ODS-5/ODS-S
/ODS-2 are optional.), please verify the model no. before installation and follow
correct directions. The recommended location of camera unit is at the height
150~170cm from central part of Camera to the floor(for reference only).
1) ODS-J1) ODS-J
Drill a hole in the center area of the bracket just big enough for the electrical
wiring to pull through. And drill 2 small holes for the plug bolts.
Plug Bolt Bracket Self-Tapping Screws Hook Holes
1.5-1.7m
Notes: Do not expose the camera unit to direct
sunlight and be sure it is shield from storm rain. The
background of visitors may be affected by street lamp
and other strong light, you can mount some lamps to
highlight for clearer images of visitors.
Cable
4) Connect well the wires from Wiring Terminal and pull through the central hole
which connect to the camera unit.
.
Insert and fix the plug bolts in the 2 small holes, then attach the mounting
bracket to the wall and fix with 2 self-tapping screws.
Pull the wiring which connect to Monitor Unit through the central hole and connect
5) Attach the wired monitor unit to the bracket by setting the monitor over the four
bracket hooks and sliding it down.
well with Terminals L1&L2. Also prepare 2 wires to connect with Lock Connectors
