Yadea TROOPER 01 User manual

USER MANUAL
TROOPER 01

Foreword
Dear users：
Thank you for your trust in Yadea Electric Bikes, choosing unique and beautiful shape,advanced and reliable technology,
TROOPER 01 two-wheeled electric bike. We will bring convenience to your life and work with high-quality products and
enthusiastic service. We hope you can enjoy the pleasure of Yadea electric bike.
Before using the TROOPER 01 two-wheeled electric bike, please read the instructions carefully and follow the warnings,
requirements and tips inside strictly, which will help you achieve higher driving safety.
As an integral part of the bike, please hand this manual over with the bike when transferring the use rights, such as sell or lend
the bike to others. Please be sure to purchase Yadea electric bike via official channels, and use the designed spare parts from
Yadea. Please keep the invoice as a proof of warranty.
Please follow this Manual to maintain the bike on schedule. For any problems found, please contact authorized service stations
in your region or our company, we will provide you with quality maintenance, repair and other services.
This manual contains the latest product information at that time.Yadea is committed to improving product design and quality. As a
result, the product design may be changed at any time, which may lead to some inconsistency between the manual and the real
product. If you have any questions, please contact us: [email protected]
Your choice - the beginning of our service! Yadea electric bike with you all the way, a safe life!
The copyright of this manual belongs to Yadea Technology Group Co., Ltd., Without the written consent of the company is not
allowed to reproduce, the offender will be prosecuted.
The right of interpretation of this manual belongs to Yadea Technology Group Co.,Ltd.
Yadea Technology Group Co. Ltd
Special Tips
▪As a more convenient and popular means of transportation, the bike performance is affected by different road conditions and
consumers' usage habits, but consumers usually lack the common sense of regular maintenance. In order to make the bike is
in the best condition, prolong the service life of the bike at the same time, consumers have to do regular inspection and
maintenance for the bike and the related parts of obligation.
• The bike, controller, charger, battery and other original parts of the bike parts shall not be disassembled and replaced without
authorization. If users disassemble and install by themselves or disassemble and repair by non-Yadea authorized maintenance
units, users do not comply with this "notice" standard or non-Yadea designated maintenance units disassemble and repair
resulting in performance failure or quality problems of relevant parts, Yadea Company will not normal warranty. The user shall
be liable for any bike damage or economic loss caused by disassembling, refitting or improper use without permission.
• The design of the bike is limited to one driver , and the rated load mass specified on the load label shall not exceed 75 Kg in
total.
• When the bike is transferred to another person, this instruction manual should be handed over to the new owner together with
the bike
Safety Warning
The safety warning symbols used in this manual.
DANGEROUS：If this warning is ignored, serious injury or death may result.
WARNING：If this warning is ignored, it may result in injury or damage to the bike.
ATTENTION：If this warning is ignored, it may result in an accident due to improper operation.
Ⅱ
Ⅰ

1. Safety Precautions
Dear users, for the safety of you and your family and to prevent accidents, please be sure to read the
"instructions for the use of this product" carefully and master driving skills through practice.
Important Safety Instructions
WARNING：
When using this product, basic precautions should always be followed, including the following:
• Read all the instructions before using the product.
• To reduce the risk of injury, close supervision is necessary when the product is used near children.
• Do not put fingers or hands into the product.
• Do not use this product if the flexible power cord or output cable is frayed, has broken insulation, or any other signs of
damage.
• This ebike is not intended to be used at ambient temperatures less than -20°C (-4°F) or above ambient temperatures of 45°C
(113°F).
• The battery is intended to be charged when the ambient temperature is between 0°C (32°F) and 30°C (86°F). Never charge
the battery when ambient temperatures are outside this range.
• Prolonged Exposure to UV Rays, Rain and the Elements May Damage the Enclosure Materials, Store Indoors When Not in Use
Safety instruction
• You must understand the local laws and regulations,strictly abide by the traffic rules , do not overspeed, run red lights or go
retrograde.
• Drivers of electric two-wheeled bike must pass the examination of the traffic management department and obtain a driving
license before they can drive an electric two-wheeled bike;
• When riding, keep the distance and slow down when passing an intersection. Before turning, a turn signal shall be given, and
a sharp turn shall not be allowed, and the bike shall not be towed or towed by other bike; Do not climb up the bike; Not to
leave the handle or hold the object with both hands; Do not learn to drive a bike on the road;
• Please carry people or articles in accordance with laws and regulations. Overloading is strictly prohibited;
• Do not lend a two-wheeled electric bike to people who can not operate to avoid injury;
• It is strictly prohibited to use high-pressure water gun to wash electronic components and circuits. Wet cloth should be used
to wipe;
• It is strictly prohibited to park in building foyers, evacuation staircases, walkways and safety exits;
• It is strictly prohibited to charge and park in residential buildings. When charging, it should be away from combustible materials
and the charging time should not be too long;
• When the battery is charged, the charger should be placed in a safe place out of reach of children;
• The correct use and maintenance of the battery; Waste batteries shall not be dismantled without authorization and shall be
recycled by the relevant professional departments;
• Safe use of the charger and warning terms; When replacing the charger, it should be matched with the battery model;
• Please do not dismantle the two-wheeled electric bike or tamper with the performance and configuration of the bike without
authorization. You will be responsible for the loss caused, and you will lose our warranty commitment. If you need to replace
the parts, please contact the after-sales service;
• In case of quality problems, please go to Yadea star service station, line repair and maintenance. If the performance failure or
quality problem of the relevant parts is caused by the disassembly and maintenance of your own or non-Yadea authorized
maintenance unit, Yadea Company will not guarantee the normal warranty. In case of bike damage or economic loss caused
by disassembly, refitting or improper use by the user, the user shall be liable for such damage or economic loss.
Notice for use
• Please ride smoothly on the flat road surface. Do not accelerate, brake or turn sharply when driving;
• Do not use the front brake first, so as to avoid the danger caused by the center of gravity moving forward;
• Please drive carefully, pay attention, do not answer the phone, use headphones, etc;
• When driving at night, turn on headlights and wear reflective clothing;
• When driving or moving a bike, keep body parts away from moving parts;
• Do not travel on the handlebars, so as not to lose control of the accident;
• If you encounter problems while driving, stop driving immediately. And timely contact after-sales service;
• Do not use chargers of other brands or specifications; It is also not allowed to use the charger provided by our company to
charge the other two wheeled electric bike;
• When charging, please turn off the power key first, then connect the charger to the battery, and then connect it to the mains;
Driving Environment Requirements
• It shall drive in the two-wheeled electric bike lane, and on the road without a two-wheeled electric bike lane, it shall drive on
the right side of the roadway;
• When riding in rain or snow, the braking distance will be extended. Please slow down and drive slowly.
• Do not drive in inclement weather, such as storm, fog, snow and ice.
• Do not drive on uneven, muddy, gravel road or stairs, or damage the explosion-proof tire or rim, which may cause danger to
your electric bike;
• Do not wade and drive. The water level should not exceed the lower edge of the rear wheel motor bearing block to prevent the
motor from being damaged by water inflow.
