SERVICE MANUAL
100941
IMPORTANT NOTICE
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already
known and understood by the users, and have therefore not been restated.
WARNING: Failure to follow appropriate service and safety procedures when servicing this product may result in personal
injury, destruction of expensive components, and failure of the product to perform as specified. For these reasons,
we advise all YAMAHA product owners that any service required should be performed by an authorized
YAMAHA Retailer or the appointed service representative.
IMPORTANT: The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and
service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable
and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please
contact the distributor's Service Division.
WARNING: Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
IMPORTANT: Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
■CONTENTS
TO SERVICE PERSONNEL .......................................... 2
FRONT PANELS ........................................................ 3~6
REAR PANELS ........................................................ 6~15
SPECIFICATIONS / 参考仕様 ................................ 16~18
INTERNAL VIEW ................................................... 18~19
REMOTE CONTROL PANELS .................................... 19
DISASSEMBLY PROCEDURES/分解手順 ......... 20~23
SELF DIAGNOSIS FUNCTION (DIAG)/
自己診断機能（ダイアグ）..................................... 24~44
AMP ADJUSTMENT/アンプ部調整 ........................... 45
IC DATA ................................................................. 46~51
BLOCK DIAGRAM ................................................. 52~55
DISPLAY DATA ........................................................... 56
PRINTED CIRCUIT BOARD .................................. 57~79
PIN CONNECTION DIAGRAM .................................... 80
SCHEMATIC DIAGRAM ........................................ 81~93
PARTS LIST ......................................................... 95~129
REMOTE CONTROL.......................................... 130~131
AV RECEIVER/AV AMPLIFIER
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
P.O.Box 1, Hamamatsu, Japan
'05.03

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
2
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
WALL
OUTLET
EQUIPMENT
UNDER TEST
AC LEAKAGE
TESTER OR
EQUIVALENT
INSULATING
TABLE
WARNING: CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition, other electrical/electronic and/or plastic (where
applicable) components may also contain traces of chemicals found by the California Health and Welfare Agency (and
possibly other entities) to cause cancer and/or birth defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REA-
SON WHATSOEVER!
Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or expose
eyes to solder/flux vapor!
If you come in contact with solder or components located inside the enclosure of this product, wash your hands before
handling food.
■TO SERVICE PERSONNEL
1. Critical Components Information
Components having special characteristics are marked s
and must be replaced with parts having specifications equal
to those originally installed.
2. Leakage Current Measurement (For 120V Models Only)
When service has been completed, it is imperative to verify
that all exposed conductive surfaces are properly insulated
from supply circuits.
●Meter impedance should be equivalent to 1500 ohms
shunted by 0.15µF.
●Leakage current must not exceed 0.5mA.
●Be sure to test for leakage with the AC plug in both polarities.
“CAUTION”
“F1, 2: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE 8A, 125V FUSE.”
CAUTION
F1, 2: REPLACE WITH SAME TYPE 8A, 125V FUSE.
ATTENTION
F1, 2: UTILISER UN FUSIBLE DE RECHANGE DE MEME TYPE DE 8A, 125V.
本機に搭載されている基板のハンダ付けに使用されているハンダ
は下記の通りです。
The P.C.B.s installed in this unit are soldered using the
following solder.
About Lead Free Solder / 無鉛ハンダについて
Component Side / 部品面 Foil Side / ハンダ面
DSP P.C.B. Lead Solder / 鉛入りハンダ Lead Free Solder / 無鉛ハンダ
FUNCTION P.C.B. – Lead Free Solder / 無鉛ハンダ
OPERATION P.C.B. – Lead Free Solder / 無鉛ハンダ
MAIN P.C.B. – Lead Free Solder / 無鉛ハンダ
POWER P.C.B. – Lead Free Solder / 無鉛ハンダ
SUBTRANS P.C.B. – Lead Free Solder / 無鉛ハンダ
CONVERSION P.C.B. Lead Solder / 鉛入りハンダ Lead Free Solder / 無鉛ハンダ
VIDEO P.C.B. – Lead Free Solder / 無鉛ハンダ
XM P.C.B. Lead Solder / 鉛入りハンダ Lead Free Solder / 無鉛ハンダ

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
3
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
無鉛ハンダにはいくつかの種類がありますが、修理時には下記の
ような無鉛ハンダの使用を推奨します。
・Sn+Ag+Cu（錫+銀+銅）
・Sn+Cu（錫+銅）
・Sn+Zn+Bi（錫+亜鉛+ビスマス）
注意：
① 無鉛ハンダの融点温度は通常の鉛入りハンダに比べ30〜40℃
程度高くなっていますので、それぞれのハンダに合ったハンダ
ごてをご使用ください。
② 鉛入りハンダを使わざるを得ない場合は、あらかじめ交換する
部品端子部やその周辺部の無鉛ハンダをすべて取り除くか、あ
るいは無鉛ハンダと鉛入りハンダが十分に溶けた状態となるよ
うにハンダ付けしてください。
Among some types of lead free solder currently available,
it is recommended to use one of the following types for the
repair work.
• Sn + Ag + Cu (tin + silver + copper)
• Sn + Cu (tin + copper)
• Sn + Zn + Bi (tin + zinc + bismuth)
Caution:
1. As the melting point temperature of the lead free solder is
about 30°C to 40°C (50°F to 70°F) higher than that of the lead
solder, be sure to use a soldering iron suitable to each solder.
2. If lead solder must be used, be sure to remove lead free solder
from each terminal section of the parts to be replaced and
from the area around it completely before soldering, or make
sure that the lead free solder and lead solder melt together
fully.
■FRONT PANELS
RX-V557 (U, C models)
RX-V557 (R, T, K, A, B, G, E, L models)
A, B, G, E models

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
4
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
HTR-5850 (T, K, A models)
DSP-AX557 (J model)
HTR-5850 (U, C models)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
5
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
RX-V457 (U, C models)
HTR-5840 (U, C models)
RX-V457 (R, T, K, A, B, G, E, L models) B, G, E models

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
6
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
HTR-5840 (T, K, A, B, G, E models)
DSP-AX457 (J model)
RX-V557 (U, C models)
■REAR PANELS
B, G, E models

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
7
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
RX-V557 (R model)
RX-V557 (T model)
RX-V557 (K model)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
8
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
RX-V557 (A model)
RX-V557 (B model)
RX-V557 (G, E models)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
9
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
RX-V557 (L model)
HTR-5850 (U, C models)
HTR-5850 (T model)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
10
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
HTR-5850 (K model)
HTR-5850 (A model)
DSP-AX557 (J model)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
11
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
RX-V457 (U, C models)
RX-V457 (R model)
RX-V457 (T model)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
12
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
RX-V457 (K model)
RX-V457 (A model)
RX-V457 (B model)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
13
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
RX-V457 (G, E models)
RX-V457 (L model)
HTR-5840 (U, C models)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
14
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
HTR-5840 (T model)
HTR-5840 (K model)
HTR-5840 (A model)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
15
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
HTR-5840 (B model)
HTR-5840 (G, E models)
DSP-AX457 (J model)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
16
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
■SPECIFICATIONS / 参考仕様
■Audio Section/オーディオ部
Minimum RMS Output Power (Power Amp. Section)/定格出力(パ
ワーアンプ部)
[RX-V557]
(20 Hz to 20 kHz, 0.09% THD, 8 ohms)
FRONT L/R ................................................................. 90 W + 90 W
CENTER ................................................................................. 90 W
SURROUND L/R ........................................................ 90 W + 90 W
SURROUND BACK ................................................................ 90 W
[HTR-5850]
(1 kHz, 0.7% THD, 8 ohms)
FRONT L/R ............................................................ 105 W + 105 W
CENTER ............................................................................... 105 W
SURROUND L/R ................................................... 105 W + 105 W
SURROUND BACK .............................................................. 105 W
[DSP-AX557] (J model)
(20 Hz to 20 kHz, 0.09% THD, 6 ohms)
FRONT L/R ................................................................. 90 W + 90 W
CENTER ................................................................................. 90 W
SURROUND L/R ........................................................ 90 W + 90 W
SURROUND BACK ................................................................ 90 W
[RX-V457]
(20 Hz to 20 kHz, 0.09% THD, 8 ohms)
FRONT L/R ................................................................. 85 W + 85 W
CENTER ................................................................................. 85 W
SURROUND L/R ........................................................ 85 W + 85 W
SURROUND BACK ................................................................ 85 W
[HTR-5840]
(1 kHz, 0.7% THD, 8 ohms)
FRONT L/R ............................................................ 100 W + 100 W
CENTER ............................................................................... 100 W
SURROUND L/R ................................................... 100 W + 100 W
SURROUND BACK .............................................................. 100 W
[DSP-AX457] (J model)
(20 Hz to 20 kHz, 0.09% THD, 6 ohms)
FRONT L/R ................................................................. 85 W + 85 W
CENTER, REAR CENTER ..................................................... 85 W
SURROUND L/R ........................................................ 85 W + 85 W
SURROUND BACK ................................................................ 85 W
Maximum Power/実用最大出力 (EIAJ) (1 kHz, 10% THD)
[RX-V557/HTR-5850] (R, T, K, L models)
FRONT L/R (8 ohms) ............................................ 130 W + 130 W
CENTER, REAR CENTER (8 ohms) ................................... 130 W
SURROUND L/R (8 ohms) .....................................130 W + 130 W
SURROUND BACK (8 ohms) .............................................. 130 W
[DSP-AX557] (J model)
FRONT L/R (6 ohms) ............................................ 130 W + 130 W
CENTER, REAR CENTER (6 ohms) ................................... 130 W
SURROUND L/R (6 ohms) .....................................130 W + 130 W
SURROUND BACK (6 ohms) .............................................. 130 W
[RX-V457/HTR-5840] (R, T, K, L models)
FRONT L/R (8 ohms) ............................................ 125 W + 125 W
CENTER, REAR CENTER (8 ohms) ................................... 125 W
SURROUND L/R (8 ohms) .....................................125 W + 125 W
SURROUND BACK (8 ohms) .............................................. 125 W
[DSP-AX457] (J model)
FRONT L/R (6 ohms) ............................................ 125 W + 125 W
CENTER, REAR CENTER (6 ohms) ................................... 125 W
SURROUND L/R (6 ohms) .....................................125 W + 125 W
SURROUND BACK (6 ohms) .............................................. 125 W
DIN Standard Output Power Per Channel/DINパワー (1 kHz, 0.7%
THD, 4 ohms)
[RX-V557/HTR-5850] (B, G, E models)
FRONT L/R ............................................................ 135 W + 135 W
CENTER ............................................................................... 135 W
SURROUND L/R ................................................... 135 W + 135 W
SURROUND BACK .............................................................. 135 W
[RX-V457/HTR-5840] (B, G, E models)
FRONT L/R ............................................................ 130 W + 130 W
CENTER ............................................................................... 130 W
SURROUND L/R ................................................... 130 W + 130 W
SURROUND BACK .............................................................. 130 W
IEC Power / IECパワー (1 kHz, 0.06% THD, 8 ohms)
[RX-V557/HTR-5850] (B, G, E, L models)
FRONT L/R ............................................................ 100 W + 100 W
[RX-V457/HTR-5840] (B, G, E, L models)
FRONT L/R ................................................................. 95 W + 95 W
Dynamic Power Per Channel/ダイナミックパワー (IHF) (8/6/4/2
ohms)
[RX-V557/HTR-5850]
FRONT L/R ...................................................... 120/155/190/235 W
[DSP-AX557] (J model)
FRONT L/R .......................................................... –/130/160/205 W
[RX-V457/HTR-5840]
FRONT L/R ...................................................... 115/150/185/230 W
[DSP-AX457] (J model)
FRONT L/R .......................................................... –/125/155/200 W
Dynamic Headroom/ダイナミックヘッドルーム (8 ohms)
[RX-V557/HTR-5850] (U, C models) .................................... 1.25 dB
[RX-V457/HTR-5840] (U, C models) .................................... 1.31 dB
Damping Factor/ダンピングファクタ
20 Hz to 20 kHz, SPEAKER-A .................................... 120 or more
Input Sensitivity / Input Impedance(入力感度/入力インピーダンス)
CD, etc. ........................................................... 200 mV / 47 k-ohms
MULTI CH IN
FRONT L/R, CENTER, SURROUND L/R, SUB WOOFER
.................................................................. 200 mV / 47 k-ohms
Maximum Input Signal Level /最大許容入力 (1 kHz, 0.5% THD)
CD, etc. (Effect On) .................................................. 2.2 V or more
Output Level / Output Impedance(出力電圧/出力インピーダンス)
REC OUT ....................................................... 200 mV / 1.2 k-ohms
20 Hz SUB WOOFER .......................................... 4 V / 1.2 k-ohms
[RX-V557] (U, C, A, B, G, E models)
ZONE2 OUT .................................................. 200 mV / 1.2 k-ohms
Headphone Jack Rated Output / Impedance (ヘッドフォン出力/出
力インピーダンス)
CD, etc. (1 kHz, 50 mV, 8 ohms) .................... 150 mV / 100 ohms
Frequency Response/周波数特性
CD, etc. to FRONT L/R (10 Hz to 100 kHz) .................. +0/-3.0 dB
Total Harmonic Distortion/全高調波歪率
(20 Hz to 20 kHz, 40 W, 8 ohms)
CD, etc. (Effect Off) to FRONT L/R SP OUT ........... 0.06 % or less
Signal to Noise Ratio / 信号対雑音比 (IHF-A Network)
CD, etc. (Input shorted) SP OUT
250 mV ................................................................. 100 dB or more
Residual Noise/残留ノイズ (IHF-A Network)
FRONT L/R SP OUT ............................................... 150 µV or less
Channel Separation/チャンネルセパレーション
CD, etc. (Input 5.1 k-ohms shorted, 1 kHz/10 kHz)
60 dB or more/45 dB or more
Tone Control Characteristics/トーンコントロール特性
BASS
Boost/Cut ............................................................. ±10 dB (60 Hz)
TREBLE
Boost/Cut ........................................................... ±10 dB (20 kHz)
Filter Characteristics/フィルター特性
FRONT L/R, CENTER, SURROUND L/R, SURROUND BACK SP
Small (H.P.F.)
fc= 40/60/80/90/100/110/120/160/200 Hz / 12 dB/ oct.
SUBWOOFER (L.P.F.)
fc= 40/60/80/90/100/110/120/160/200 Hz / 24 dB/ oct.
■Video Section/ビデオ部
Video Signal Type/ビデオ信号方式
U, C, R, K, J models .............................................................. NTSC
T, A, B, G, E, L models ............................................................ PAL
Video Signal Type (Video Conversion)/ビデオ信号方式（ビデオ
コンバージョン）
[RX-V557/HTR-5850/DSP-AX557]
U, C, R, K, A, B, G, E, L, J models ....................................... NTSC
R, T, A, B, G, E, L models ........................................................ PAL
Composite Video Signal Level/コンポジットビデオ信号
1 Vp-p / 75 ohms
S-Video Signal Level/Sビデオ信号
Y ........................................................................... 1 Vp-p / 75 ohms
C ................................................................... 0.286 Vp-p / 75 ohms
Component Signal Level (U, C, R, T, K, A, B, G, E, L models)
Y ........................................................................... 1 Vp-p / 75 ohms
Cb/Cr ................................................................ 0.7 Vp-p / 75 ohms

17
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
D4-Video Signal Level / D4端子ビデオ信号 (J model)
Y ........................................................................... 1 Vp-p / 75 ohms
Cb/Cr ................................................................ 0.7 Vp-p / 75 ohms
Maximum Input Level/最大許容入力 .................. 1.5 Vp-p or more
Signal to Noise Ratio/信号対雑音比 ........................ 50 dB or more
Monitor Out Frequency Response/モニターアウト周波数帯域
Composite Video Signal Level,
S-Video Signal Level ..................................... 5 Hz to 10 MHz, -3 dB
D4-Video Signal Level (J model) ................ 5 Hz to 60 MHz, -3 dB
[RX-V557/HTR-5850/DSP-AX557]
Component Video Signal Level .................. 5 Hz to 60 MHz, -3 dB
[RX-V457/HTR-5840/DSP-AX457]
Component Video Signal Level (U, C, R, T, K, A, B, G, E, L models)
5 Hz to 60 MHz, -3 dB
■FM Section/FM部
Tuning Range/受信周波数範囲
U, C models ....................................................... 87.5 to 107.9 MHz
R, L models .......................... 87.5 to 108.0 / 87.50 to 108.00 MHz
T, K, A, B, G, E models ................................. 87.50 to 108.00 MHz
J model ................................................................ 76.0 to 90.0 MHz
50 dB Quieting Sensitivity/50dBSN感度 (IHF) (1 kHz, 100% Mod.)
Mono / Stereo ........................ 2.0 µV (17.3 dBf) / 25 µV (39.2 dBf)
Usable Sensitivity/実用感度 (IHF)
Mono .................................................................... 1.0 µV (11.2 dBf)
Selectivity/選択度 (400 kHz) .................................................. 70 dB
Signal to Noise Ratio/信号対雑音比 (IHF)
Mono / Stereo ............................................................ 76 dB / 70 dB
Harmonic Distortion/歪率 (1 kHz)
Mono/Stereo .................................................................. 0.2 / 0.3 %
Stereo Separation/ステレオセパレーション
1 kHz ...................................................................................... 42 dB
Frequency Response/周波数特性
20 Hz to 15 kHz ............................................................ +0.5 / -2 dB
Antenna Input/アンテナ入力 ......................... 75 ohms unbalanced
■AM Section/AM部
Tuning Range/受信周波数範囲
U, C models ......................................................... 530 to 1,710 kHz
R, L models ................................. 530 to 1,710 / 531 to 1,611 kHz
T, K, A, B, G, E, J models ................................... 531 to 1,611 kHz
Usable Sensitivity/実用感度 ............................................ 300 µV/m
Antenna/アンテナ入力 .............................................. Loop Antenna
■General/総合
Power Supply /電源電圧
U, C mode ls .......................................................... AC 120 V, 60 Hz
R model .............................. AC 110/120/220/230-240 V, 50/60 Hz
T model ................................................................. AC 220 V, 50 Hz
K model................................................................. AC 220 V, 60 Hz
A model................................................................. AC 240 V, 50 Hz
B, G, E models ..................................................... AC 230 V, 50 Hz
L model ............................................. AC 220/230-240 V, 50/60 Hz
J model ............................................................ AC 100V, 50/60 Hz
Power Consumption / 消費電力
U, C models ........................................................... 350 W / 440 VA
R, T, K, A, B, G, E, L models ............................................... 360 W
J model ................................................................................. 245 W
Standby Power Consumption (reference data)/待機時消費電力（参考値）
AC240 V / 50 Hz .................................................................... 0.1 W
Maximum Power Consumption (R model)
6ch Drive, 10% THD ............................................................ 700 W
AC Outlets/ACアウトレット
2 Switched Outlets
U, C, T, J models................................................. 100 W max. total
R, G, E, L models .................................................. 50 W max. total
1 Switched Outlet
A, B models ................................................................. 100 W max.
Dimensions/寸法 (W x H x D)
[RX-V557/DSP-AX557]
435 x 171 x 420.3 mm (17-1/8" x 6-3/4" x 16-9/16")
[HTR-5850/RX-V457/HTR-5840/DSP-AX457]
435 x 161 x 419.3 mm (17-1/8" x 6-5/16" x 16-1/2")
Weight/質量 .................................................. 11.0 kg (24 lbs. 4 oz.)
Finish/仕上げ
[RX-V557]
Gold color ................................................................ R, T, K models
Black color ........................................... U, C, R, A, B, G, E models
Titanium color ............................................ C, A, B, G, E, L models
[HTR-5850]
Gold color ........................................................................... T model
Black color ................................................................... U, C models
Silver color .......................................................... U, C, K, A models
[DSP-AX557]
Gold color ........................................................................... J model
[RX-V457]
Gold color ........................................................... R, T, K, L models
Black color ........................................... U, C, R, A, B, G, E models
Silver color ............................................................... R, K, L models
Titanium color ................................................ C, A, B, G, E models
[HTR-5840]
Gold color ........................................................................... T model
Black color ......................................................... U, C, G, E models
Silver color ............................................ U, C, K, A, B, G, E models
[DSP-AX457]
Gold color ........................................................................... J model
Silver color .......................................................................... J model
Accessories/付属品
Remote Control x 1, Batteries (Manganese Dry) x 4 (RAV254/
RAV255), Batteries x 2 (RAV304), Indoor FM Antenna x 1, AM Loop
Antenna x 1, Antenna Adapter x 1 [PAL 75/300 ohms] (B model)
* Specifications are subject to change without notice due to product
improvements.
※ 参考仕様および外観は予告なく変更されることがあります。
U .......... U.S.A. model C ...... Canadian model
R .......... General model T ....... Chinese model
K .......... Korean model A ...... Australian model
B .......... British model G ...... European model
E .......... South European model L ....... Singapore model
J ........... Japanese model
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, “Surround EX”, and the double-D symbol are
trademarks of Dolby Laboratories.
ドルビーラボラトリーズからの実施権により製造されています。「ドル
ビー」、「PROLOGIC」、「SurroundEX」およびダブルD記号 は、ド
ルビーラボラトリーズの商標です。
"SILENT CINEMA" is a trademark of YAMAHA CORPORATION.
「サイレントシネマ／SILENTCINEMA」はヤマハ株式会社の登録商標
です。
“DTS”, “DTS-ES”, “Neo:6” and “DTS 96/24” are trademarks of
Digital Theater Systems, Inc.
DTS、DTS-ESExtendedSurround、Neo:6およびDTS96/24はデジ
タルシアターシステムズの登録商標です。
TheXMnameandrelatedlogosareregisteredtrademarksofXM
SatelliteRadioInc.
AACロゴマーク はドルビーラボラトリーズの商標です。
RX-V557
DSP-AX557
HTR-5850
RX-V457
HTR-5840
DSP-AX457
161 (6-5/16")
140 (5-1/2")
376.3 (14-13/16")
21
(13/16")
171 (6-3/4")
150 (5-15/16")
21
(13/16")
21
(13/16")
22
(7/8")
419.3 (16-1/2")
380.3 (15")
18
(11/16")
22
(7/8")
420.3 (16-9/16")
435 (17-1/8")
Unit : mm (inch)/単位:mm（インチ）
• DIMENSIONS/寸法図
• The variable range of the parameter (Min/Max/Step)/パラメーターの可変範囲（最小/最大/ステップ）
PARAMETER NAME
DSP LEVEL
INIT. DEY
ROOM SIZE
LIVENESS
P. INIT. DLY
P. ROOM SIZE
P. LIVENESS
S. INIT. DLY
S. ROOM SIZE
S. LIVENESS
SB. INIT. DLY
SB. RM SIZE
SB. LIVENESS
REV. TIME
REV. DLY
REV. LEVEL
PLII/PLIIx
PANORAMA
DIMENSIONS
CT WIDTH
C. IMAGE
MUSIC
-6/3/1
1/99/1
0.1/2.0/0.1
0/10/1
Hall in Vienna
-6/3/1
1/99/1
0.1/2.0/0.1
0/10/1
The Bottom Line
-6/3/1
1/99/1
0.1/2.0/0.1
0/10/1
1.0/5.0/0.1
0/250/1
0/100/1
The Roxy Thtr
-6/3/1
1/99/1
0.1/2.0/0.1
1/49/1
0.1/2.0/0.1
1/49/1
0.1/2.0/0.1
Rock/Pop
-6/3/1
1/99/1
0/10/1
1.0/5.0/0.1
0/250/1
0/100/1
DISC
ENTERTAINMENT
-6/3/1
1/99/1
0.1/2.0/0.1
1/49/1
0.1/2.0/0.1
1/49/1
0.1/2.0/0.1
GAME
-6/3/1
1/99/1
0.1/2.0/0.1
0/10/1
1.0/5.0/0.1
0/250/1
0/100/1
MONO MOVIE
TV THEATER
-6/3/1
1/99/1
0.1/2.0/0.1
1/49/1
0.1/2.0/0.1
1/49/1
0.1/2.0/0.1
TV SPORTS
-6/3/1
1/99/1
0.1/2.0/0.1
0/10/1
MOVIE THEATER
-6/3/1
1/99/1
0.1/2.0/0.1
0/10/1
PRO LOGIC
PLII/PLIIx
OFF/ON
-3/3/1
0/7/1
0.1/1.0/0.1
MOVIE/GAME
PRO LOGIC II / IIx
PLII/PLIIx
OFF/ON
-3/3/1
0/7/1
0.1/1.0/0.1
MUSIC
OFF/ON
-3/3/1
0/1.0/0.1
DTS Neo:6
CINEMA/MUSIC
dB
ms
ms
ms
ms
s
ms
%
UNIT
PROGRAM NAME
7ch STEREO PARAMETER
CT LEVEL
SL LEVEL
SR LEVEL
SB1 LEVEL
SB2 LEVEL
0/100/1
0/100/1
0/100/1
0/100/1
0/100/1
%
%
%
%
%

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
18
■INTERNAL VIEW
CATEGORY MAIN MENU SUB MENU SELECT MENU VALUE [INITIAL]
•BASIC SETUP ROOM : S >M L S / [M] / L
SUBWOOFER : YES [YES] / NONE
SPEAKERS : 6spk 2 / 3 / 4 / 5 / [6]
>SET CANCEL [SET] / CANCEL
CHECK OK? : YES [YES] / NO
FR •••••||•••••
C•••••||•••••
SL •••••||••••• ±10.0 dB step
SB •••••||•••••
SR •••••||•••••
SWFR •••••||•••••
•
MANUAL SETUP 1 SOUND MENU A ) SPEAKER SET FRONT : LARGE SMALL / [LARGE]
CENTER : SML
SUR LR : SML NONE / [SML] / LRG
SUR B : SML
BASS OUT : BOTH SWFR / FRONT / [BOTH]
Cross Over : 80 Hz 40 / 60 / [80] / 90 / 100 / 110 / 120 / 160 / 200 Hz
SWFR PHASE : NRM [NRM] / REV
B ) SP LEVEL FL •••••||•••••
FR •••••||•••••
C•••••||•••••
SL •••••||••••• -10.0 dB to +10.0 dB [0.0 dB] / 1.0 dB step
SR •••••||•••••
SB •••••||•••••
SWFR •••••||•••••
C ) SP DISTANCE UNIT : feet feet (U, C models) / meters (R, T, K, A, B, G, E, L, J models)
FRONT L 10.0 ft / 3.00 m
FRONT R 10.0 ft / 3.00 m
CENTER 10.0 ft / 3.00 m feet : 1.0 ft to 80.0 ft [10.0 ft] / 0.5 ft step
SUR. L 10.0 ft / 3.00 m
SUR. R 10.0 ft / 3.00 m
meters : 0.30 m to 24.00 m [3.00 m] / 0.10 m step
SUR. B 10.0 ft / 3.00 m
SWFR 10.0 ft / 3.00 m
D ) CENTER GEQ TEST : >OFF ON [OFF] / ON
100 Hz -||- 0
300 Hz -||- 0
1 kHz -||- 0 -6 dB to +6 dB [0 dB] / 1 dB step
3 kHz -||- 0
10 kHz -||- 0
E ) LFE LEVEL SP LFE : 0 -20 dB to 0 dB [0 dB] / 1 step
HP LFE : 0
F ) D . RANGE SP D . R : MAX MIN / STD / [MAX]
HP D . R : MAX
G ) AUDIO SET MUTE TYP : MUTE -20 dB / [MUTE]
A. DELAY : 0 ms 0 ms to 160 ms / 1 step
TC. BYPASS : AUTO OFF / [AUTO]
DUAL MONO : MAIN [MAIN] / SUB / ALL (J model)
CATEGORY MAIN MENU SUB MENU SELECT MENU VALUE [INITIAL]
•Set Menu Table / セットメニュー
2 INPUT MENU A ) I/O ASSIGN C . V [A] : DVD [DVD] / VCR / V-AUX / DTV/CBL
C . V [B] : DTV/CBL - - - / VCR / V-AUX / [DTV/CBL]
OUT (1) : MD/CD-R [MD/CD-R] / CD / VCR / V-AUX / DTV/CBL / DVD
IN (2) : MD/CD-R (RX-V557, HTR-5850, DSP-AX557)
IN (3) : DVD - - - / CD / VCR / V-AUX / DTV/CBL / [DVD]
IN (4) : DTV/CBL - - - / CD / VCR / V-AUX / [DTV/CBL] / DVD
IN (5) : CD
MD/CD-R / [CD] / VCR / V-AUX / DTV/CBL / DVD
B ) INPUT MODE > AUTO / LAST [AUTO] / LAST
C ) INPUT RENAME CD
Input is possible to 8 characters / 最大8文字まで入力可能
MD/CD-R Input is possible Character type / 入力可能文字
TUNER CAPITAL / 英大文字 A to Z
DVD SMALL / 英小文字 a to z
DTV/CBL FIGURE / 数字 0 to 9
V-AUX Space / 空白
VCR MARK / 記号 # * - + / ; < > ? etc.
3 OPTION MENU A ) DISPLAY SET DIMMER : 0 -5 to 0 / 1 step
V CONV. : ON OFF / [ON]
B )
MEMORY GUARD MEM. GUARD : OFF [OFF] / ON
C ) PARAM. INI
D ) MULTI ZONE SP B : MAIN [MAIN] / ZONE B
E )
XM RADIO (U model) ANTENNA : NONE [NONE] / 0 % to 100 %

19
RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
■REMOTE CONTROL PANELS
RX-V557 (U, C, R, T, K, A, L models)
HTR-5850 (U, C, T, K, A models)
DSP-AX557 (J model)
RX-V457 (U, C, R, T, K, A, L models)
HTR-5840 (U, C, T, K, A models)
DSP-AX457 (J model)
RX-V457 (B, G, E models)
HTR-5840 (B, G, E models)
RX-V557 (B, G, E models)

RX-V557/HTR-5850/DSP-AX557
RX-V457/HTR-5840/DSP-AX457
20
SUBTRANS (9) P.C.B.
SUBTRANS (10) P.C.B.
SUBTRANS (7) P.C.B.
SUBTRANS (2) P.C.B.
SUBTRANS (6) P.C.B.
SUBTRANS (3) P.C.B.
CONVERSION P.C.B.
FUNCTION P.C.B.
Tuner
XM P.C.B.
SUBTRANS (8) P.C.B.
(U, C, A, B, G, E models )
CB21
CB23 CB24
CB307
CB351
CB452
CB453
CB706
(U, C models )
1
1
2
2
2
CB309
CB306
CB456
Top Cover
トップカバー
Front Panel Unit
フロントパネルユニット
Knob
ノブ
Suport Top
サポートトップ
CB863
Sub Chassis Unit
サブシャーシユニット Plate Side L
プレートサイドL
Plate Side R
プレートサイドR
3
4
4
5
5
6
6
■DISASSEMBLY PROCEDURES
Fig. 1
(Remove parts in the order as numbered.)
Disconnect the power cable from the AC outlet.
1. Removal of Top Cover
a. Remove 4 screws (1) and 5 screws (2). (Fig. 1)
b. Slide the Top Cover rearward to remove it. (Fig. 1)
2. Removal of Front Panel Unit
a. Remove 2 Knobs. (Fig. 1)
b. Remove 1 screw (3) and then remove the Support Top. (Fig. 1)
c. Remove 6 screws (4) and then remove the Front Panel Unit.
(Fig. 1)
3. Removal of Plate Side
a. Remove 2 push rivets (5). (Fig. 1)
b. Remove the Plate Side L/R. (Fig. 1)
4. Removal of Sub Chassis Unit
a. Remove 2 screws (6) and then slide the Sub Chassis Unit
forward. (Fig. 1)
b. Loosen the harness fixture fixing the cable.
c. Remove CB306, CB309, CB456 and CB863 and then remove
the Sub Chassis Unit. (Fig. 1)
5. Removal of DSP P.C.B.
a. Remove 1 screw (7). (Fig. 2)
b. Remove 7 screws (8). (Fig. 3)
c. Remove CB2 and CB11. (Fig. 2)
d. Lift up the SUBTRANS (2) P.C.B. and remove the CB1. (Fig. 2)
e. Remove the DSP P.C.B. with the Support/DSP. (Fig. 2)
Fig. 3
6. Removal of FUNCTION, SUBTRANS (2), (3), (6), (7),
(8) (U, C, A, B, G, E models), (9), (10), CONVERSION,
XM (U, C models) P.C.B.s and Tuner
a. Remove CB21, CB23, CB24 (U, C models), CB307, CB351,
CB452, CB453 and CB706. (Fig. 4)
b. Remove 23 (U, C models) / 21 (A, B, G, E models) / 19 (R, T,
K, L models) screws (9). (Fig. 3)
c. Remove FUNCTION, SUBTRANS (2), (3), (6), (7), (8) (U, C, A,
B, G, E models), (9), (10), CONVERSION, XM (U, C models)
P.C.B.s and the Tuner. (Fig. 4)
RX-V557/DSP-AX557
（番号順に部品を取り外してください。）
AC電源コンセントから、電源コードを抜いてください。
1.トップカバーの外し方
a. 1のネジ4本、
2のネジ5本を外します。（Fig.1）
b. トップカバーを後方へスライドさせ、取り外します。（Fig.1）
2. フロントパネルユニットの 外し方
a . ノブ を2 個 取り外しま す。（Fig.1）
b. 3のネジ1本を外し、サポートトッ プ を 取 り外 しま す 。（Fig.1）
c. 4のネジ6 本を外し、フロントパ ネ ル ユ ニットを 取り外します 。
（Fig.1）
3. プレート、サイドの外し方
a. 5のプッシュリベット2 本を外します。（Fig.1）
b. プレートサイド L / Rを 取り外します 。（Fig.1）
4 . サ ブ シャーシ ユ ニットの外し方
a. 6のネジ2本を外し、サブシャーシユニットを前方に引き出します。
（Fig.1）
b. ケーブルを固定している束 線 止めをゆるめます。
c. CB306、CB309、CB456、CB863を外し、サブシャーシユ
ニットを取り外します 。（Fig.1）
5. DSPP.C.B.の外し方
a. 7のネジ1本を外します。（Fig.2）
b. 8のネジ7本を外します。（Fig.3）
c. CB2、CB11を外します。（Fig.2）
d. SUBTRANS（2）P.C.B.を上部に浮かせCB1を外します。（Fig.2）
e. DSPP.C.B.をサポート/DSPと共に取り外します。（Fig.2）
6. FUNCTION、SUBTRANS（2）、（3）、（6）、（7）、（9）、（10）、
CONVERSIONP.C.B.、TUNERの外し方
a. CB307、CB351、CB452、CB453、CB706を外します。
（Fig.4）
b. 9のネジ22本を外します。（Fig.3）
c. FUNCTION、SUBTRANS（2）、（3）、（6）〜（10）、
CONVERSIONP.C.B.、TUNERを取り外します。（Fig.4）
Fig. 2
7
SUBTRANS (2) P.C.B.
DSP P.C.B.
CB1
CB11
CB2
Support/DSP
サポート/DSP
Fig. 4
