Yamaha Seascooter SeaWing User manual

CAUTION
ELECTRICALLY OPERATED PRODUCT
Not recommended for children under 16 years of age. As with all
electrical products, precautions should be observed during handling
to reduce the risk of electric shock.
English Version
User Manual
SEA WING
Distributors in the United States and Canada provide a Standard Limited
Warranty for 6 months from the date of purchase for new products. If you're
not located in the United States or Canada, please contact your Local
Distributor for warranty arrangements in your territory. Please visit
www.seascooter.net for Distributor / Service Center details. Distributors ONLY
warrant Yamaha Seascooter products purchased from an authorized dealer
and with an original purchase receipt. All warranties are limited to a single
original owner on the purchase of new and current product from an
authorized reseller. Closeouts, Discontinued and Secondary sales of any kind
including “like new” or out of box are not eligible for warranty consideration.
This warranty gives the consumer specific legal rights, and those rights may
vary from place to place. Ask your Local Distributor for the warranty period in
your region by calling their Service Center. Any part of the product supplied
by the Distributor and found in the reasonable judgment of the Distributor to
be defective in material or workmanship will be repaired or replaced then
returned by the Distributor without charging for parts and repair costs. The
product including any defective part must be sent to the Distributor within the
warranty period. The customer will pay for the expense of delivering the
product to the Distributor.
This warranty does not cover any product that has been subject to misuse
negligence or accident, or that has been operated in any way contrary to the
operating instructions as specified in the User Manual. Any flood, loss or
damage, for any reason, that is caused by accidental release and sinking of
the unit, or from flooding an o-ring sealed or water tight area will not be
covered under warranty. This warranty does not apply to theft, loss, abuse or
tampering, lack of maintenance, improper storage, exposure to excessive
temperature, extended sunlight, material interactions, deteriorating chemicals
or fumes, any damage to the product that is the result of improper
maintenance or parts replacement performed by someone other than the
official Distributor Service Center or to any product that has been altered or
modified so as to change its intended use. This warranty does not extend to
repairs made necessary by normal wear or by the use of parts or accessories
which are either incompatible with the product or adversely affects its
operation, performance or durability.
CONSUMER WARRANTY
& SERVICE INFORMATION
SEE NEXT PAGE
Yamaha, the Crossed Tuning Fork Design, and any likeness thereof are trademarks
of Yamaha Motor Corp. U.S.A. and Yamaha Motor Co., Ltd. (“Yamaha”) used
under license by Sport Dimension Inc. www.yamaha-motor.com.
This Product is not manufactured by Yamaha. For consumer purposes,
please contact Sport Dimension Inc. at 1-800-678-7873.
LICENSED PRODUCT
200090
Distributors ONLY warrant products with an active
Warranty Registration
ALWAYS ACTIVATE YOUR WARRANTY IMMEDIATELY ON
https://yamahaseascooters.com/pages/warranty-1

Introduction
The dual thruster Yamaha SEAWING is a full-featured
Seascooter that gets you cruising underwater with a top
speed up to 4mph (6.5km/h). Easily shift between 2
rotational speeds as you conserve your energy for more
bottom time.
Use appropriate equipment such as wetsuit, approved
life jacket, mask & snorkel etc. when using seascooter.
Only operate the Seascooter in water.
• Run time up to 45 minutes
• Rated to 130ft / 40m
• Speed up to 4 MPH / 6.5 KM/H
• 2-level rotational speed control
• Battery & speed level indicator
• Superior flood prevention system
• Powered by high performance replaceable
Lithium-Ion battery
• Weight only 8.15 lb / 3.7 kg including battery
Contents
Introduction 1
Warnings 2
Parts diagram 5
Battery instruction 6
Getting started 7
Battery use 8
Care & maintenance 11
Camera assembly 12
Technical specifications 13
Discarded electrical appliances are
recyclable and should not be discarded
in the domestic waste! Please actively
support us in conserving resources and
protecting the environment by returning
this appliance to the collection centers
(if available).
1
• When passing on this device, include the user manual
and all relevant warning information and parts.
• It is the responsibility of the owner to give proper
instruction and precaution (regarding the risk
associated with this device) when lending the device
to other people.
The Seascooter is designed for use in seawater. It will
have less buoyancy in fresh water, lake or pool and
may sink in such waters.
• The seascooter is designed for 1 person use
• The seascooter is not a life saving device. Do not use it as
a buoyancy aid
Warning

2 3
Warnings
14 +
16 +
•Read the user's manual carefully before use.
•Always follow this age recommendation: a
child under 16 years old should never operate
this SEASCOOTER™.
•The seascooter is designed for 1 person use.
•Crushing / Cutting Hazard
•Be careful when you are transporting the
Seascooter and setting it down to avoid
crushing hazard on hands, foot or toes.
•This is not a life saving device.
DO NOT use it as a buoyancy aid.
• ALWAYS wear a life vest (personal floatation
device - PFD) approved by your local
authorities for Snorkeling: (U.S. Coast Guard
Type III vest in the US or Canadian Coast
Guard approved life vest in Canada or SAI
Approval PFD in Australia or ISO/CE
Approved PFD in Europe).
•Never stick body parts, clothing or other
objects in the vicinity of the Propeller. Do not
wear loose or flowing clothing or equipment
that could be drawn into the propeller.
•Particular care should be exercised when
using the SEASCOOTER™ near anybody
with long hair. Users with long hair should tie
it up or wear a swimming cap when using the
SEASCOOTER™.
•Always inspect the swimming area to ensure
it is free of hazards or obstacles such as
boats and swimmers before using the
SEASCOOTER™.
• Do not use alcohol or drugs prior to and
during use of this product.
• Always ensure sufficient charge remains in
the battery to return to the shore surface
before using the Seascooter.
• Be aware of appropriate water levels, tidal
changes, dangerous currents, weather
change and strong offshore winds. ALWAYS
scout unfamiliar water before venturing out.
• Do not attach your body, clothing, other
equipment to the seascooter in any way.

4 5
Parts Diagram
Fig.1
1 Power switch
2 Handle
3 Thruster & Protective Grilles
4 Battery Housing
cover
5 Master lock
6 LED Battery
Status Indicator
7 LED Speed
Status Indicator
8 Buoyancy Chambers
9 Low & High speed switch
10 Battery
11 Charger
12 Camera Mount
13 Carry Bag
CAUTION:
• NEVER remove the grilles except for maintenance.
• Familiarize yourself with the Seascooter functions and
battery life before embarking on any dives or excursions.
• Always charge battery to its fullest before using the
Seascooter.
• Do not allow sun tan oils or lotions to be in prolonged
contact with the Seascooter plastic as it may cause the
plastic to become brittle and break apart.
• ALWAYS keep the Seascooter out of direct sunlight when
not in use. HEAT KILLS BATTERIES AND IT MAY
EXPLODE OR LEAK.
• Never open the Battery Compartment of the Seascooter in
the water.
• When not in use, always turn the Master Switch to the
OFF position.
• Do not use the Seascooter below the recommended
maximum depth of 40m/130ft.
• This machine is not intended for mixing or working with
sand, concrete and material with similar physical
characteristics. This machine is only intended for
swimming and diving in the water.
• Do not use the unit if it is damaged in any way.
• Replace the battery immediately if it is damaged.
• The Seascooter should only be used for scuba diving by
qualified divers.
• When using the Seascooter for scuba diving, ascents and
descents should be made in accordance with recognized
diving practices.
• Due to safety considerations those who have not obtained
a C-Card (attesting to completion of training) from an
entity providing diving instruction must not under any
circumstances use this product for diving.
• In different waters (seawater, lake, pool) and conditions
such as currents, temperature and pressure can affect the
buoyancy of the unit which may cause the unit to sink if
accidentally released.
• DO NOT release or leave the Seascooter in the water.
Always take the unit out of water when not in use.
Top
Bottom
Front
3
1
12
7
6
8
4
2
5
9
10
11
13

Press The cover button
Slide the cover
backward
6 7
Battery Installation
CHARGE THE BATTERY:
1. Please take battery out Fig.2 - 5 reversed, connect charge
socket and Battery charge plug to charge the battery;
2. The light on adaptor is red when charging, it is green when
battery is fully charged, in about 1.5~2 hours;
3. Please make sure Charge socket and Battery charge plug are
dry and clean when charge the battery;
4. Please charge in a dry and ventilated environment.
LED battery status indicator
(operates when Master Switch is on)
Your Seascooter has a Battery Status Indicator (see Fig. 1 “Parts
Diagram” - part 6), which can be seen through the LED Window
located in the Handle. When the battery is full, 4 LEDs are on. When
3 LEDs are on, 3/4 of power remains. When 2 LEDs are on, 1/2 of
power remains. When 4 LED is blinking in red color, the seascooter
will switch to low speed and could only run for approx. 3 minutes.
WARNING!
Replace the battery immediately if it is damaged.
Aim connector at
battery plug-in and plug
Clockise tightening
Slide the cover
forward till closed
Fig.2 Fig.3
Fig.4 Fig.5
Getting started
Press both buttons to start; Grab tight underwater
Unlock the Safety Master Lock
Change to Hi Speed
Fig.6
Fig.7
Fig.8
Battery charge plug
Adaptor
plug
Charge
socket
Fig.4 Fig.5

98
Battery Use
CAUTION
Battery Use
CAUTION
• Use the specified charger only.
• Must be disposed of properly.
• Always store the battery in well ventilated areas where
it is out of the reach of children and away from heat
and ignition sources.
• Do not incinerate, disassemble, damage, short-circuit
or expose to heat.
• The battery contains safety and protection devices
which, if damaged, may cause the battery to generate
heat, rupture or ignite.
• Do not place the battery in fire, direct sunlight or apply
heat to the battery; it may explode or leak.
• Do not leave the battery in direct sunlight or use or
store the battery inside high temperature containers.
Doing so may cause the battery to generate heat,
rupture, or ignite. Using the battery in this manner may
also result in a loss of performance and a shortened
life expectancy.
• Do not place the battery on or near fires, stoves, or
other high temperature locations.
• DO NOT THROW WATER ON A BURNING LI-ION
BATTERY. If an exposed battery does ignite, it will
burn even more violently if it comes into contact with
water or even the moisture in air. A fire extinguisher
must be used.
• Do not expose the battery to water or salt water, or
allow the battery to get wet.
• Do not subject the battery to strong impacts or shocks.
• Do not pierce the battery with nails, strike the battery
with a hammer, step on the battery, or otherwise
damage the outer casing.
• MUST re-charge the battery after EACH USE.
• MUST re-charge the battery at least EVERY SIX
MONTHS when not in use.
• ALWAYS REMOVE the Battery from the seascooter
FOR STORAGE.
• Never leave Lithium-Ion batteries discharged for long -
the batteries do self-discharge and the charge could
drop low enough to damage the battery.
• Keep Lithium-Ion batteries away from high heat - high
temperatures may cause premature battery failure.
• ALWAYS store Lithium-Ion batteries partially
discharged in a cool, dry place.
WARNING
BATTERY SAFETY
• MUST re-charge the battery after
EACH USE.
• MUST re-charge the battery
at least EVERY SIX MONTHS when
not in use.
• ALWAYS REMOVE the Battery from
the seascooter FOR STORAGE.
• Never leave Lithium-Ion batteries
discharged for long - the batteries do
self-discharge and the charge could drop low
enough to damage the battery.
• Keep Lithium-Ion batteries away from high
heat - high temperatures may cause
premature battery failure.
• ALWAYS store Lithium-Ion batteries partially
discharged in a cool, dry place.
• MUST re-charge the battery after
EACH USE.
• MUST re-charge the battery
at least EVERY SIX MONTHS when
not in use.
• ALWAYS REMOVE the Battery from
the seascooter FOR STORAGE.
• Never leave Lithium-Ion batteries
discharged for long - the batteries do
self-discharge and the charge could drop low
enough to damage the battery.
• Keep Lithium-Ion batteries away from high
heat - high temperatures may cause
premature battery failure.
• ALWAYS store Lithium-Ion batteries partially
discharged in a cool, dry place.
www.seascooter.net
RE-CHARGE THE BATTERY
6
6
AT LEAST
MONTHS
EVERY
MONTHS

Washing and Care
• Soak the seascooter into fresh water for approx.
1 hour after every use to prevent salt- sand and
chlorine crystal accumulation in the seascooter.
Or switch the seascooter on for approx. 1
minute in fresh water to flush the seascooter and
propeller components clear of any debris.
• To clean the Seascooter do not use detergents; only use
a damp cloth to wipe the unit clean.
• Use a cloth to dry the seascooter and the battery
compartment.
• DO NOT leave the Seascooter in the water. Always take
the unit out of water when not in use.
Sand or Grit on Seals
Ensure that sand/grit does not get on the seals as correct
maintenance and care is essential. To remove sand or grit
from the seals, rinse the seals in fresh water and apply
fresh lubricant. If there is sand inside the Battery Housing,
gently brush the sand from the unit taking care not to
scratch the sealing surfaces.
10 11
Care & Maintenance
Battery Use
• Use the specified charger only.
• Must be disposed of properly.
• Always store the battery in well ventilated areas where
it is out of the reach of children and away from heat
and ignition sources.
• Do not incinerate, disassemble, damage, short-circuit
or expose to heat.
• The battery contains safety and protection devices
which, if damaged, may cause the battery to generate
heat, rupture or ignite.
• Do not place the battery in fire, direct sunlight or apply
heat to the battery; it may explode or leak.
• Do not leave the battery in direct sunlight or use or
store the battery inside high temperature containers.
Doing so may cause the battery to generate heat,
rupture, or ignite. Using the battery in this manner may
also result in a loss of performance and a shortened
life expectancy.
• Do not place the battery on or near fires, stoves, or
other high temperature locations.
• DO NOT THROW WATER ON A BURNING LI-ION
BATTERY. If an exposed battery does ignite, it will
burn even more violently if it comes into contact with
water or even the moisture in air. A fire extinguisher
must be used.
• Do not expose the battery to water or salt water, or
allow the battery to get wet.
CAUTION
• Do not subject the battery to strong impacts or shocks.
• Do not pierce the battery with nails, strike the battery
with a hammer, step on the battery, or otherwise
damage the outer casing.
• MUST re-charge the battery after EACH USE.
• MUST re-charge the battery at least EVERY SIX
MONTHS when not in use.
• ALWAYS REMOVE the Battery from the seascooter
FOR STORAGE.
• Never leave Lithium-Ion batteries discharged for long -
the batteries do self-discharge and the charge could
drop low enough to damage the battery.
• Keep Lithium-Ion batteries away from high heat - high
temperatures may cause premature battery failure.
• ALWAYS store Lithium-Ion batteries partially
discharged in a cool, dry place.

CAMERA ASSEMBLY
To attach your camera to Seascooter Seal and Explorer, you will
need a thumb screw or hardware depending on the mount you
are using.
ATTACHING YOUR CAMERA TO SEASCOOTER MOUNTS
(Can be used with GoPro®HERO [3, 3+, 4, or 5] cameras, or
other camera with using the same mount system)
*Camera (and Waterhousing), Attachment Buckle and Thumb Screw are not included
Technical Specifications
12 13
19.68 inches x 8.22 inches x 8.89 inches
500 x 209 x 226 mm
Unit Dimensions
Unit Weight
8.15 lb (3.7 kg)
Battery Type 1 x 22.2V / 6.3 Ah rechargeable battery
Speed Up to 4 mph (6.5 km/h)
Depth rating 40 m / 130 ft
(Maximum advised depth rating for
recreational diving)
Battery Life /
Fully Charge
Run up to 45 minutes
1-2 HOURS
RECHARGE
22.2V / 6.3 AH
BAT TERY
2 SPEED
GEAR
P
4 MPH / 6.5 KM/H
SPEED UP TO
45 MINUTES
RUN TIME
8.15 LB / 3.7 KG
WEIGHT
130 FT / 40 M
DEPTH
IN YOUR FLIGHT
HAND-CARRY
Thumb Screw Waterhousing
Simply attach the Camera to the mount
and align the hole, Insert And Tighten Up
The Thumb Screw

US & CANADA MARKET ONLY
Toll Free (US) : 1-800-678-7873
[email protected]
www.yamahaseascooters.com
(US & CANADA MARKET ONLY)
For more information on
Seascooter™Products
(Warranty, Customer Care / Maintenance,
Parts & Battery Purchase)
PLEASE VISIT
www.yamahaseascooters.com
Please visit our website at www.yamahaseascooters.com to find out your local distributor.
Yamaha, the Crossed Tuning Fork Design, and any likeness thereof are trademarks of
Yamaha Motor Corp. U.S.A. and Yamaha Motor Co., Ltd. (“Yamaha”) used
under license by Sport Dimension Inc. www.yamaha-motor.com.
This Product is not manufactured by Yamaha. For consumer purposes,
please contact Sport Dimension Inc. at 1-800-678-7873.
All corresponding specification appear in this manual are correct at the time of printing.
For the latest updates and further information on the complete range of the Seascooter™,
PLEASE VISIT www.yamahaseascooters.com

For any questions or queries you may have regarding your
SEASCOOTER™, please follow the below steps for easy and
fast resolution:
- STEP 1-
Please read your User Manual. For a copy of the User Manuals, please visit
www.yamahaseascooters.com
- STEP 2-
Go to www.yamahaseascooters.com and see our FAQ section to find instant
answers.
- STEP 3-
Contact one of our Customer Service representatives at the Customer Service
Center in your region.
CUSTOMER ENQUIRIES
If your unit is not operating, please refer to your User Manual before
contacting our Customer Service Center. For any damage or repair work
required, please do not return your product to the store where it was
purchased.
RETURN / REPAIR POLICY
Customers must contact their Local Distributor Service Center to ask for an
official Claim Form. The Claim Form must be returned with the customer’s
contact details and a photo of the Seascooter, defective parts, the serial
number and the Original Purchase Receipt. The Distributor Customer Service
Center will review the case and issue a Return / Repair Authorization Number
before sending the product to the Distributor Service Center. Returned
products must be shipped with original packaging including the polystyrene
packing material and all defective parts. Please contact your Local Distributor
Service Center for assistance in handling your case.
Please visit our website www.yamahaseascooters.com
for a listing of most update distributor contacts and
service center contacts.
RETURN / REPAIR PROCEDURE
1. Call the Customer Service Center for your Return / Repair Authorization
Number.
2. Make a copy of your Proof of Purchase (receipt).
3. Pack the defective unit in its original packaging including the polystyrene
foam and include the unit and all defective parts.
4. Attach the copy of your Proof of Purchase (receipt) to the outside of the box
(clearly visible), together with the Return / Repair Authorization Number.
5. Ship the package to the Service Center on your cost.
PLEASE NOTE: Deliveries that do not have the Proof of Purchase (receipt)
and Return / Repair Authorization Number attached clearly to the outside of
the box, will not be accepted by the Service Center.
In addition, this warranty does not cover items that
experience normal wear and tear.
ALL IMPLIED WARRANTIES ARE LIMITED IN THE DURATION TO THE
WARRANTY PERIOD. AND SUCH IMPLIED WARRANTIES INCLUDING
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR
OTHERWISE, ARE DISCLAIMED IN THEIR ENTIRETY AFTER THE
EXPIRATION OF THE APPROPRIATE WARRANTY PERIOD. THE
DISTRIBUTOR’S OBLIGATION UNDER THE WARRANTY IS STRICTLY
AND EXCLUSIVELY LIMITED TO THE REPAIR OR REPLACEMENT OF
DEFECTIVE PARTS AND RETURN OF THE PRODUCT TO THE
CUSTOMER. THE DISTRIBUTOR DOES NOT ASSUME OR AUTHORIZE
ANYONE TO ASSUME FOR THEM ANY OTHER OBLIGATION.
THE DISTRIBUTOR ASSUMES NO RESPONSIBILITY FOR INCIDENTAL,
CONSEQUENTIAL OR OTHER DAMAGES INCLUDING, BUT NOT LIMITED
TO EXPENSE OF RETURNING THE PRODUCT TO THE DISTRIBUTOR,
LOSS OF USE OF PRODUCT AND LOSS OF TIME OR INCONVENIENCE.
THIS PRODUCT IS DESIGNED AND INTENDED FOR PERSONAL
RECREATIONAL USE ONLY!
THIS PRODUCT IS NOT WARRANTED FOR COMMERCIAL OR
RENTAL USE!
REPAIR WORK OR DELIVERY OF A REPLACEMENT DOES NOT
EXTEND OR RENEW THE WARRANTY PERIOD.
WARRANTY SHALL AUTOMATICALLY BE VOID IF DAMAGE IS
RESULT OF NON-ORIGINAL PARTS.
LIMITED WARRANTY for seascooters with camera mount:
• ALWAYS inspect to ensure the product works properly every time before
use. Warranty of this product does not cover any damages due to misuse.
• Failure to follow the user(s) instructions on packaging and/or user(s)
manual may result in damages or loss of your cameras including but not
limited to any user’s personal items, all of which are not covered under
warranty of this product.
• Use at your own risk. Manufacturer(s) and/or suppliers/agents are not
responsible for any damages/repairs, loss to cameras/electronic items
including but not limited to any user’s personal items directly and/or
indirectly resulted in the use of this product. Damage(s) resulting from any
use, misuse, accident, and normal wear and tear are understandably not
covered under this product warranty nor be responsible by manufacturer(s)
and/or suppliers/agents.
EXCLUSIONS
BATTERY. This warranty does not include the battery.
Never replace the original SEASCOOTER BATTERY with an
AFTERMARKET BATTERY. Seascooter with aftermarket battery will not be
covered by this warranty.
