SERVICE MANUAL
■ CONTENTS
TO SERVICE PERSONNEL . . . . . . . . . . . . . . . . . . . .1
SW-P201 REAR PANELS . . . . . . . . . . . . . . . . . . . 1—2
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
SW-P201 DISASSEMBLY PROCEDURES . . . . . . . . .4
100771
SERVICE MANUAL
NS-P220
HOME THEATER SPEAKER SYSTEM
SW-P201 BLOCK DIAGRAM . . . . . . . . . . . . . . . . . . .5
SW-P201 PRINTED CIRCUIT BOARD . . . . . . . . . 6—7
SW-P201 SCHEMATIC DIAGRAM . . . . . . . . . . . . . . .8
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9—14
NS-P220 is composed of NX-220P, NX-C220 and SW-P201.
The NX-220P and NX-C220 loudspeakers are not field serviceable and must be replaced as complete units.
IMPORTANT NOTICE
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already known and understood by the users,
and have therefore not been restated.
WARNING: Failure to follow appropriate service and safety procedures when servicing this product may result in personal injury, destruction of expensive
components, and failure of the product to perform as specified. For these reasons, we advise all YAMAHA product owners that any service
required should be performed by an authorized YAMAHA Retailer or the appointed service representative.
IMPORTANT: The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or recognition of any applicable
technical capabilities, or establish a principle-agent relationship of any form.
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service departments of YAMAHA are
continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and specifications are subject to change without notice or obligation to
retrofit. Should any discrepancy appear to exist, please contact the distributor's Service Division.
WARNING: Static discharges can destroy expensive components. Discharge any static electricity your body may have accumulated by grounding yourself to the
ground buss in the unit (heavy gauge black wires connect to this buss).
IMPORTANT: Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
● SW-P201
● NX-C220
● NX-220P x 4
NS-P220

NS-P220
NS-P220
■TO SERVICE PERSONNEL
1. Critical Components Information.
Components having special characteristics are marked Z
and must be replaced with parts having specifications equal
to those originally installed.
2. Leakage Current Measurement (For 120V Models Only).
When service has been completed, it is imperative to verify
that all exposed conductive surfaces are properly insulated
from supply circuits.
●Meter impedance should be equivalent to 1500 ohm shunted
by 0.15µF.
AC LEAKAGE
TESTER OR
EQUIVALENT
EQUIPMENT
UNDER TEST
INSULATING
TABLE
WALL
OUTLET
WARNING: CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition, other electrical/electronic and/or
plastic (where applicable) components may also contain traces of chemicals found by the California Health and
Welfare Agency (and possibly other entities) to cause cancer and/or birth defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR
ANY REASON WHATSOEVER!
Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes
or expose eyes to solder/flux vapor!
If you come in contact with solder or components located inside the enclosure of this product, wash your hands
before handling food.
1
■SW-P201 REAR PANELS
●Leakage current must not exceed 0.5mA.
●Be sure to test for leakage with the AC plug in both
polarities.
▼ SW-P201 U, C models ▼ SW-P201 B,G models

NS-P220
NS-P220
▼ SW-P201 A model ▼ SW-P201 R model
2

NS-P220
NS-P220
■SPECIFICATIONS
200.6 (7–7/8") 40
(1–3/4") 335 (13–3/16") 9
(3/8")
389 (15–5/16")
390.1 (15–3/8")
5.5
(3/16")
395.6 (15–9/16")
Units : mm (inch)
140.4 (5–1/2")
111.6 (4–3/8")
20.1 (13/16")
100.2 (3–15/16")
100 (3–15/16") 20 (13/16")
111.5 (4–3/8")
140 (5–1/2")
■NX-220P & NX-C220
Type ..................... 2-way acoustic suspension speaker system
Magnetic shielding type
Driver....................................................8 cm (3-1/8") cone type
1.9 cm (3/4") balanced dome type
Nominal Input Power....................................................... 30 W
Maximum Input Power .................................................. 100 W
Impedance ..................................................................... 6 ohms
Frequency Response .................................. 140 Hz to 27 kHz
Sensitivity .........................................................86 dB/2.83 V,m
Dimensions (W X H X D)
NX-220P................................................ 100 x 140 x 113 mm
(3-15/16" x 5-1/2" x 4-7/16")
NX-C220 ............................................... 140 x 100 x 112 mm
(5-1/2" x 3-15/16" x 4-7/16")
Weight
NX-220P............................................. 0.7 kg (1 lbs. 9 oz) x 4
NX-C220 ............................................ 0.7 kg (1 lbs. 9 oz) x 4
Finish ...................................................Black color (R, A, B, G)
Black Gray color (U, C)
Silver color
■SW-P201
Type................... Advanced Yamaha Active Servo Technology
Output Power ..........50 W(100 Hz, 5 ohms at T.H.D. = 10 %)
Input Sensitivity
INPUT1 (SP) ......................................................... 1.2 V
INPUT2 (PJ)........................................................ 55 mV
Input Impedance
INPUT1 (SP) ................................................ 4.7 k-ohms
INPUT2 (PJ).................................................. 12 k-ohms
Frequency Response .................................... 30 Hz to 200 Hz
Speaker Unit ............................................16 cm (6-5/16") cone
Magnetic shielding type
Input Section
INPUT1................................................Speaker terminal
INPUT2......................................................RCA pin jack
Output Section ...............................................Speaker terminal
(parallel connect)
Operating Section .................................... Bass volume control
Power switch
Auto standby switch (H-L-OFF)
Power Supply
U, C models ....................................................AC120V, 60 Hz
A model ...........................................................AC240V, 50 Hz
B, G models ....................................................AC230V, 50 Hz
R model ................................ AC110-120/220-240V, 50/60 Hz
Power Consumption ........................................................ 42 W
Dimensions (W x H x D) ......................... 200 x 395 x 384 mm
(7-7/8" x 15-9/16" x 15-1/8")
Weight ........................................................ 9.3 kg (20 lbs. 8oz)
Finish ...................................................Black color (R, A, B, G)
Black Gray color (U, C)
Silver color
■ACCESSORIES Pin Cord (3 m) x 1
Speaker Cable (15 m) x 2
Speaker Cable (4 m) x 3
Bracket (typeAx 3, typeB x 2, typeC x 5)
Screw with flange x 8
Wing Bolt x 2
* Specifications subject to change without notice.
● NX-220P
● NX-C220
● SW-P201
U . . . . . . . . . . . . . USA model
C . . . . . . . . . Canadian model
A . . . . . . . . Australian model
B . . . . . . . . . . . British model
G . . . . . . . . .European model
R . . . . . . . . . . General model
3

NS-P220
NS-P220
■SW-P201 DISASSEMBLY PROCEDURES
(Remove parts in the order as numbered.)
1. Removal of Front Grille
The front grille is fixed to the cabinet with dowels
at 6 locations.
* As a screwdriver (for slotted head screw) is used
for removal, use special care not to cause damage
to the cabinet.
a. Using the screwdriver inserted in the gap between
the front grille and the cabinet (bottom side first),
push up the front grille.
b. Remove the front grille by lifting it up.
When installing the Front Grille, apply quick-drying
bond to the dowels and then fit them into dowel holes
for secure installation. (The Front Grille will come off
easily if its dowels are fitted into dowel holes only.)
2. Removal of Rear Panel
Remove 14 screws ( q) in Fig. 2.
* Arrow marks ( ) are printed to identify the screws to be
removed. q
Fig. 2
Fig. 1
* When assembling the Rear Panel, check to ensure that
the packing is not damaged so as to prevent air leakage
from occurring.
4

NS-P220
NS-P220
■SW-P201 BLOCK DIAGRAM
IC1A IC1B IC2A
AUTO POWER
SW1
AUTO POWER
ON/OFF CIRCUIT
VR1
VOLUME
L.P.F.
6dB/oct H.P.F.
12dB/oct
L.P.F.
12dB/oct
361 576
8
7
IC2B
IC4
IC5
A.N.I.C
LIMITER
RY1
RY2
422
IC7, 8
Q12
D15, 16, 18
Q4~Q7
D10, 11, 19, 20
1
10
D13
D4
D14
D2
D1
Q10
D5
—B
+B
9
8
3
2
0.1
PROTECTION
H/L
OFF
VCC
PWR
R65
C51
TIMER
IC6
MUSIC
SENSOR
IC3
8
4
6
3
7
Q11
+15
+B
—B
—15
VCC
REGULATOR
REGULATOR
Q1, Q2
Q3
POWER SUPPLY
D3
Q8, D8
Q9, D9
F1
POWER
SW
L
R
+
–
–
+
INPUT 1 SPEAKER
L
R
INPUT 2
L
R
+
–
–
+
OUTPUT
+
—
POWER
AMP
5

ABCDE
1
2
3
4
5
6
7
NS-P220
■SW-P201 PRINTED CIRCUIT BOARD (Component side)
WH BL RE
TO : AMP (B)
WH RE
TO : SPEAKER
AMP P. C. B. ( A ) FROM : AMP (B)
FROM : AMP (C)
FROM : AMP (D)
FROM : AMP (C)
OUTPUT
+ –
INTPUT 1
– +
INTPUT 2
AUTO STANDBY
STANDBY-RED
ON-GREEN
AMP P. C. B. ( C )
TO : AMP (A) TO : AMP (A)
R+ L+ R- L- R- L- R+ L+
L R
6

ABCDE
1
2
3
4
5
6
7
NS-P220
AMP P. C. B. ( D )
VOLUME
TO : AMP (A)
AMP P. C. B. ( E )
WH BE
TO : AMP (B)
POWER
■SW-P201 PRINTED CIRCUIT BOARD (Component side)
AMP P. C. B. ( B )
RE BL WH
TO : AMP (A)
TO : AMP (A)
FROM : POWER CORD
BE
WH
TO : AMP (E)
123
456
VOLTAGE
SELECTOR
BRRE
WH
GR
RE
R only
GR
BR
WH
BE
RE
7

ABCDEFGH
1
2
3
4
5
6
IJK
7
8
NS-P220
■SW-P201 SCHEMATIC DIAGRAM
* All voltage are measured with a 10MΩ/V DC electric volt meter.
* Components having special characteristics are marked Zand
must be replaced with parts having specifications equal to those
originally installed.
* Schematic diagram is subject to change without notice.
BA4558N µPC1237HA
M51848L µPC4570HA
1
9
1SS133
1SR139-400
MTZJ12C
MTZJ15C
MTZJ24B
Anode
Cathode
B
C
E
2SA1015 (Y)
2SC1815 (Y)
2SC2240 (GR, BL)
RBV-402
D
GS
2SK304 (E, T) STK404-050
PIN CONNECTION DIAGRAM OFTRANSISTORS, DIODES AND ICS.
E-8/J-6
POWER AMP
LIMITER
AUTO POWER ON/OFF CIRCUIT
PROTECTION
0
0
-14.3
0
14.3
0
00
0
00.6 1.9
0
0
9.1
9.8
10.4
11.1
0
0
00.1
-0.1 0.1
-0.1
14.3
-14.3
0
000
0
0
0
000
0
0
14.1
-14.1
0.5
0.5 0.1 0
00.1
14.1 14.3
0
0
00
14.3
-14.3
0
0
-1.5
0
5.5 9.8
11.0
9.7
5.5
0
11.0
1.4 0
0
10.9
9.7
9.1
0.8
26.9
0
00
14.3
0
00
14.3
-14.3
0
30.9
0
-31.2
30.9 14.2
14.8
-31.1 -14.2
-14.8
0
29.5
29.9
29.9
4.0
0
0.1
0.7
AC49.0
0
12.1
29.9 11.6
11.7
12.2
3.5 2.2 0.8
0
2.9
0 0 0
0
1.4 9.7
11.0
7.4
10.9 10.9
11.0
0.1 0.1
0
-30.9
14.3
1.2
-1.2
-31.4
30.9
0
1.9
WH
RE
GR
WH
RE
BR
BE
BE
WH
R MODEL
BE
BE
BE
WH WH
WH
BE
+
–
BCE
2SB1565 (EF)
2SD2394 (DEF)
1
8
1
8
1
10
V O1
2–Vm
1
3+Vm
1
4V
EE
5+Vm
2
6–Vm
2
7V
O2
8V
CC
9
V CC
1
1
–+
–+
2
IC2, 3, 7, 8 : µPC4570HA
Dual OP-Amp
IC6 : M51848L
CR Timer
IC1 : BA4558N
Dual OP-Amp
–IN
1
2
+IN
1
3
–V
CC
4
+IN
2
5
–IN
2
6
OUT
2
7
+V
CC
8
OUT
1
1
–
+
–
+
IC4 : STK404-050
AF Power Amp
IC5 : µPC1237HA
Protector IC for Power Amplifier
1
2
534
78
6
Overload
detect
Mid-point
potential
detect
Flip flop
circuit
Vcc on
mute
AC OFF
detect
Latch / automatic
return select
Relay
drive
circuit
GND
Vcc
GND
6
4
12 3
TRIGGER
OUT
RESET
REFERENCE
VOLTAGE
THRESHOLD
DISCHARGE
VCC
78
+
–
FLIP-
FLOP
+
–
5
RR R
12345678910
R1 R4
R5
C1 C2
D1
TR3
TR5
R3 R6
TR4
SUB
R2
TR1 TR2
TR6
TR7
TR8

NS-P220
NS-P220
9
ABBREVIATIONS IN THIS LIST ARE AS FOLLOWS :
C.A.EL.CHP : CHIP ALUMI. ELECTROLYTIC CAP
C.CE : CERAMIC CAP
C.CE.ARRAY : CERAMIC CAP ARRAY
C.CE.CHP : CHIP CERAMIC CAP
C.CE.ML : MULTILAYER CERAMIC CAP
C.CE.M.CHP : CHIP MULTILAYER CERAMIC CAP
C.CE.SAFTY : RECOGNIZED CERAMIC CAP
C.CE.TUBLR : CERAMIC TUBULAR CAP
C.CE.SMI : SEMI CONDUCTIVE CERAMIC CAP
C.EL : ELECTROLYTIC CAP
C.MICA : MICA CAP
C.ML.FLM : MULTILAYER FILM CAP
C.MP : METALLIZED PAPER CAP
C.MYLAR : MYLAR FILM CAP
C.MYLAR.ML : MULTILAYER MYLAR FILM CAP
C.PAPER : PAPER CAPACITOR
C.PLS : POLYSTYRENE FILM CAP
C.POL : POLYESTER FILM CAP
C.POLY : POLYETHYLENE FILM CAP
C.PP : POLYPROPYLENE FILM CAP
C.TNTL : TANTALUM CAP
C.TNTL.CHP : CHIP TANTALUM CAP
C.TRIM : TRIMMER CAP
CN : CONNECTOR
CN.BS.PIN : CONNECTOR, BASE PIN
CN.CANNON : CONNECTOR, CANNON
CN.DIN : CONNECTOR, DIN
CN.FLAT : CONNECTOR, FLAT CABLE
CN.POST : CONNECTOR, BASE POST
COIL.MX.AM : COIL, AM MIX
COIL.AT.FM : COIL, FM ANTENNA
COIL.DT.FM : COIL, FM DETECT
COIL.MX.FM : COIL, FM MIX
COIL.OUTPT : OUTPUT COIL
DIOD.ARRAY : DIODE ARRAY
DIODE.BRG : DIODE BRIDGE
DIODE.CHP : CHIP DIODE
DIODE.VAR : VARACTOR DIODE
DIOD.Z.CHP : CHIP ZENER DIODE
DIODE.ZENR : ZENER DIODE
DSCR.CE : CERAMIC DISCRIMINATOR
FER.BEAD : FERRITE BEADS
FER.CORE : FERRITE CORE
FET.CHP : CHIP FET
FL.DSPLY : FLUORESCENT DISPLAY
FLTR.CE : CERAMIC FILTER
FLTR.COMB : COMB FILTER MODULE
FLTR.LC.RF : LC FILTER ,EMI
GND.MTL : GROUND PLATE
GND.TERM : GROUND TERMINAL
HOLDER.FUS : FUSE HOLDER
IC.PRTCT : IC PROTECTOR
JUMPER.CN : JUMPER CONNECTOR
JUMPER.TST : JUMPER, TEST POINT
L.DTCT : LIGHT DETECTING MODULE
Note) Those parts marked with “#” are not included in the P.C.B. ass'y.
L.EMIT : LIGHT EMITTING MODULE
LED.DSPLY : LED DISPLAY
LED.INFRD : LED, INFRARED
MODUL.RF : MODULATOR, RF
PHOT.CPL : PHOTO COUPLER
PHOT.INTR : PHOTO INTERRUPTER
PHOT.RFLCT : PHOTO REFLECTOR
PIN.TEST : PIN, TEST POINT
PLST.RIVET : PLASTIC RIVET
R.ARRAY : RESISTOR ARRAY
R.CAR : CARBON RESISTOR
R.CAR.CHP : CHIP RESISTOR
R.CAR.FP : FLAME PROOF CARBON RESISTOR
R.FUS : FUSABLE RESISTOR
R.MTL.CHP : CHIP METAL FILM RESISTOR
R.MTL.FLM : METAL FILM RESISTOR
R.MTL.OXD : METAL OXIDE FILM RESISTOR
R.MTL.PLAT : METAL PLATE RESISTOR
RSNR.CE : CERAMIC RESONATOR
RSNR.CRYS : CRYSTAL RESONATOR
R.TW.CEM : TWIN CEMENT FIXED RESISTOR
R.WW : WIRE WOUND RESISTOR
SCR.BND.HD : BIND HEAD B-TITE SCREW
SCR.BW.HD : BW HEAD TAPPING SCREW
SCR.CUP : CUP TITE SCREW
SCR.TERM : SCREW TERMINAL
SCR.TR : SCREW, TRANSISTOR
SUPRT.PCB : SUPPORT, P.C.B.
SURG.PRTCT : SURGE PROTECTOR
SW.TACT : TACT SWITCH
SW.LEAF : LEAF SWITCH
SW.LEVER : LEVER SWITCH
SW.MICRO : MICRO SWITCH
SW.PUSH : PUSH SWITCH
SW.RT.ENC : ROTARY ENCODER
SW.RT.MTR : ROTARY SWITCH WITH MOTOR
SW.RT : ROTARY SWITCH
SW.SLIDE : SLIDE SWITCH
TERM.SP : SPEAKER TERMINAL
TERM.WRAP : WRAPPING TERMINAL
THRMST.CHP : CHIP THERMISTOR
TR.CHP : CHIP TRANSISTOR
TR.DGT : DIGITAL TRANSISTOR
TR.DGT.CHP : CHIP DIGITAL TRANSISTOR
TRANS : TRANSFORMER
TRANS.PULS : PULSE TRANSFORMER
TRANS.PWR : POWER TRANSFORMER ASS’y
TUNER.AM : TUNER PACK, AM
TUNER.FM : TUNER PACK, FM
TUNER.PK : FRONT-END TUNER PACK
VR : ROTARY POTENTIOMETER
VR.MTR : POTENTIOMETER WITH MOTOR
VR.SW : POTENTIOMETER WITH ROTARY SW
VR.SLIDE : SLIDE POTENTIOMETER
VR.TRIM : TRIMMER POTENTIOMETER
■ELECTRICAL PARTS
PARTS LIST ■ WARNING
Components having special characteristics are marked Zand must be replaced
with parts having specifications equal to those originally installed.
●Carbon resistors (1/6W or 1/4W) are not included in the ELECTRICAL PARTS
List. For the parts No. of the carbon resistors, refer to last page.

NS-P220
NS-P220
10
SW-P201 P.C.B. AMP
Schm
Ref. PART NO. Description Remarks
New Parts
*
Schm
Ref. PART NO. Description Remarks
New Parts
*
AAX14790 P.C.B. AMP(UC) 330571
AAX14800 P.C.B. AMP(R) 330572
AAX14810 P.C.B. AMP(A)BG 330573
C1 UR837100 C.EL 10uF 16V 066833
C2 UA655330 C.MYLAR 0.33uF 50V 044570
C3 UA655150 C.MYLAR 0.15uF 50V 065292
C4 UA655180 C.MYLAR 0.18uF 50V 065297
C5 XX707860 C.POL 0.022uF 50V 064984
C6 UR837100 C.EL 10uF 16V 066833
C7 UR837470 C.EL 47uF 16V 066963
C8 UA654470 C.MYLAR 0.047uF 50V 064987
C9 UA655180 C.MYLAR 0.18uF 50V 065297
C10 UR837100 C.EL 10uF 16V 066833
C11 FG644100 C.CE 0.01uF 50V 065452
C12 UA654470 C.MYLAR 0.047uF 50V 064987
C13 UA654470 C.MYLAR 0.047uF 50V 064987
C14 FG644100 C.CE 0.01uF 50V 065452
C15 UJ668100 C.EL 100uF 50V 058262
C16 UA655820 C.MYLAR 0.82uF 50V 051719
C17 VG892500 C.EL 4700uF 50V 066742
C18 Ui367220 C.EL 22uF 50V 058261
C19 Ui367220 C.EL 22uF 50V 058261
C20 VG892500 C.EL 4700uF 50V 066742
C21 Ui367220 C.EL 22uF 50V 058261
C22 Ui367220 C.EL 22uF 50V 058261
C23 UR838100 C.EL 100uF 16V 066840
C24 Ui367220 C.EL 22uF 50V 058261
C25 Ui367220 C.EL 22uF 50V 058261
C26 UR837100 C.EL 10uF 16V 066833
C27 UA354100 C.MYLAR 0.01uF 50V 064981
C28 UR837470 C.EL 47uF 16V 066963
C29 UR837470 C.EL 47uF 16V 066963
C30 FX606590 C.EL 100uF 10V 058260
C31 FG613100 C.CE 1000pF 50V 065385
C32 FG644100 C.CE 0.01uF 50V 065452
C33 XX707850 C.POL 0.0022uF 50V 065055
C34 UJ668100 C.EL 100uF 50V 058262
C35 UJ667470 C.EL 47uF 50V 058259
C36 FX607210 C.EL 10uF 50V 058258
C37 UA655100 C.MYLAR 0.1uF 50V 065269
C38 FX607210 C.EL 10uF 50V 058258
C39 UA654680 C.MYLAR 0.068uF 50V 064989
C40 UR837100 C.EL 10uF 16V 066833
C41 UJ668100 C.EL 100uF 50V 058262
C42 UA655100 C.MYLAR 0.1uF 50V 065269
C43 VE117600 C.EL 220uF 10V 066900
C44 FG644100 C.CE 0.01uF 50V 065452
C45 VG290500 C.EL 1uF 50V 066870
C46 UA654680 C.MYLAR 0.068uF 50V 064989
C47 FG644100 C.CE 0.01uF 50V 065452
C48 UA654470 C.MYLAR 0.047uF 50V 064987
C50 UR838220 C.EL 220uF 16V 045291
C51 VG287800 C.EL 330uF 16V 045312
C52 UG412220 C.CE 220pF 50V 065404
C53 UG412220 C.CE 220pF 50V 065404
C54 FX607210 C.EL 10uF 50V 058258
C55 FX607210 C.EL 10uF 50V 058258
C56 FX607210 C.EL 10uF 50V 058258
C57 FX607210 C.EL 10uF 50V 058258
ZC58 VS741700 C.POL 0.01uF 275V 065262
C59 UA655470 C.MYLAR 0.47uF 50V 044631
C60 UG413220 C.CE 0.0022uF 50V 065407
CB5 VP206500 HOLDER.FUS EYF-52BCT 074277
CB6 VP206500 HOLDER.FUS EYF-52BCT 074277
CB7 VP206500 HOLDER.FUS EYF-52BCT(R) 074277
CB8 VP206500 HOLDER.FUS EYF-52BCT(R) 074277
D1 AAX13500 LED
LED SPR-54MVWF 070008
D2 iF004600 DIODE 1SS133 069460
ZD3 VC971500 DIODE.BRG RBV-402 4.0A 200V 069612
D4 VU264100 DIODE 1SR139-400 069536
D5 VU264100 DIODE 1SR139-400 069536
D6 VG440300 DIODE.ZENR MTZJ12C 12V 069172
D7 VG442500 DIODE.ZENR MTZJ5.6B 069220
D8 VG440800 DIODE.ZENR MTZJ15B 15V 069190
D9 VG440800 DIODE.ZENR MTZJ15B 15V 069190
D10 iF004600 DIODE 1SS133 069460
D11 iF004600 DIODE 1SS133 069460
D12 VG442500 DIODE.ZENR MTZJ5.6B 069220
D13 iF004600 DIODE 1SS133 069460
D14 iF004600 DIODE 1SS133 069460
D15 iF004600 DIODE 1SS133 069460
D16 iF004600 DIODE 1SS133 069460
D17 iF004600 DIODE 1SS133 069460
D18 iF004600 DIODE 1SS133 069460
D19 iF004600 DIODE 1SS133 069460
D20 iF004600 DIODE 1SS133 069460
ZF1 AAX13570 FUSE 2A 250V(UCR) 058991
ZF1 KB000660 FUSE 400mA 250V(ABG) 075126
ZF2 KB000660 FUSE 400mA 250V(R) 075126
IC1 AAX13480 IC BA4558N 044472
IC2 XB247A00 IC uPC4570HA 070111
IC3 XB247A00 IC uPC4570HA 070111
ZIC4 AAX13490 IC STK404-050 AF 058246
IC5 XF663A00 IC uPC1237HA 070293
IC6 XP741A00 IC M51848L 070916
IC7 XB247A00 IC uPC4570HA 070111
IC8 XB247A00 IC uPC4570HA 070111
PJ1 AAX13580 JACK.PIN
2P YKC21-3085 058243
Q1 VS883400 TR 2SD2394 D,E,F 068968
Q2 AAX12590 TR
2SC2240 GR BL 073532
Q3 AAX12590 TR
2SC2240 GR BL 073532
Q4 iC1815M0 TR 2SC1815 Y,GR 068741
Q5 iC1815M0 TR 2SC1815 Y,GR 068741
Q6 iA101590 TR 2SA1015 O,Y 068587
Q7 iA101590 TR 2SA1015 O,Y 068587
Q8 VS883400 TR 2SD2394 D,E,F 068968

NS-P220
NS-P220
11
SW-P201 P.C.B. AMP
Schm
Ref. PART NO. Description Remarks
New Parts
*
Schm
Ref. PART NO. Description Remarks
New Parts
*
Q9 VS883300 TR 2SB1565 E,F 044140
Q10 AAX12590 TR
2SC2240 GR BL 073532
Q11 AAX12590 TR
2SC2240 GR BL 073532
Q12 AAX09180 FET 2SK304 E 051061
R23 AAX11950 R.CAR.FP 1Ω1/4W 084665
R26 AAX11950 R.CAR.FP 1Ω1/4W 084665
R27 VH005800 R.MTL.FLM 2.7KΩ1/4W 068203
R35 AAX11880 R.CAR.FP 1KΩ1/4W 044454
R36 AAX11860 R.CAR.FP 100Ω1/4W 044153
R39 HV454820 R.CAR.FP 82Ω1/4W 044149
R46 VH009600 R.MTL.FLM 100KΩ1/4W 068149
R47 AAX11860 R.CAR.FP 100Ω1/4W 044153
R48 AAX11870 R.CAR.FP 10Ω1/4W 044452
R57 AAX13640 R.METAL 0.1Ω2W 045244
R58 AAX11950 R.CAR.FP 1Ω1/4W 084665
R69 HV456470 R.CAR.FP 4.7KΩ1/4W 044152
R72 HV456470 R.CAR.FP 4.7KΩ1/4W 044152
R74 HV456220 R.CAR.FP 2.2KΩ1/4W 044209
R75 HV456220 R.CAR.FP 2.2KΩ1/4W 044209
R78 AAX11860 R.CAR.FP 100Ω1/4W 044153
R81 VP441400 R.MTL.FLM 10KΩ1/4W 068279
R82 AAX09780 R.MTL.FLM 20KΩ1/4W 068187
R83 VP441400 R.MTL.FLM 10KΩ1/4W 068279
R84 VP441400 R.MTL.FLM 10KΩ1/4W 068279
R88 AAX13650 R.METAL 0.15Ω2W 058287
ZRY1 VU161600 RELAY OSA-SS-224-DM3 079766
ZRY2 VV272600 RELAY OSA-SS-224-DM5 079770
SW1 VD179500 SW.SLIDE
SSSU123-S09N1 044160
TE1 XX707320 PIN IPS-5007 064821
TE2 XX707320 PIN IPS-5007 064821
TE3 AAX13530 TERM.SP 8P 044223
VR1 V2515500 VR A5KΩ058244
BB070700 GND.MTL 075884

ABCDE
1
2
3
4
5
6
7
NS-P220
■SW-P201 EXPLODED VIEW
12
R model
24
3
23
22
4
5
2
21
2
21
12
6
10
6
6
7
15
9
19
19
17
18
22
14
6
6
16
1
15
11
22
19
8
20
14
B
A
C
D
E
13
202
203
208
209
102
101
207
206
205
204
6-3
6-2
6-5
6-4
6-1
20
x 3
x 5
x 2
x 8
x 2
x 3
x 2
x 1
NX-220P & NX-C220 requires replacement as a unit.
Components cannot be supplied as individually.

Ref.
No. PARTNO. Description Remarks Markets
NewParts
*
NS-P220
NS-P220
■SW-P201 MECHANICAL PARTS
13
1 AAX13510 ENCLOSURE BLACK 058581
* 1 AAX23520 ENCLOSURE SILVER 337936
2 AAX12290 FOOT 055357
3 XY559A00 SPEAKER 16cmJA1678 058529
4 AAX13590 GRILLEASS'Y BLACK 058579 (RABG)
* 4 AAX23590 GRILLEASS'Y BLACKGRAY 337280 (UC)
* 4 AAX19530 GRILLEASS'Y SILVER 332028
5 AAX12930 SEAL 056813
6 AAX14790 P.C.B.ASSY AMP 330571 (UC)
6 AAX14800 P.C.B.ASSY AMP 330572 (R)
6 AAX14810 P.C.B.ASSY AMP 330573 (ABG)
6‑1 AAX13560 HEATSINK 058265
6‑2 EP600250 BINDHEADB‑TITESCREW 3x8ZMC2‑Y 075636
6‑3 AAX13540 BINDHEADB‑TITESCREW 3x15ZC 075644
Z6‑4 VE962600 SLIDESWITCH SDKGA4(R) 084733 (R)
6‑5 AAX13660 CUSHION,SWITCH 084851 (R)
Z7 AAX13630 POWERTRANSFORMER 058254 (UC)
Z7 AAX13770 POWERTRANSFORMER 058255 (R)
Z7 AAX13780 POWERTRANSFORMER 058256 (A)
Z7 AAX13790 POWERTRANSFORMER 058257 (BG)
Z8 AAX13760 POWERCORD 050166 (UC)
Z8 AAX13750 POWERCORD 044483 (R)
Z8 VZ163800 POWERCORD 076131 (A)
Z8 VZ163900 POWERCORD 076130 (B)
Z8 VZ164000 POWERCORD 076128 (G)
9 AAX12230 CUSHIONSTOPPER SR‑4 078519
10 CB069250 BINDINGTIE BK‑1 080558
11 AAX13710 REARPANEL 058276 (UC)
11 AAX13720 REARPANEL 058278 (R)
11 AAX13730 REARPANEL 058279 (A)
11 AAX13740 REARPANEL 058280 (BG)
12 AAX13610 MOLDCOVER 044183
13 AAX13520 CUSHIONC 044416
14 AAX12910 SEAL 055433
15 AAX12920 SEAL 058018
16 AAX09370 CUSHIONBUSH 084849
17 EK396010 BINDHEADS‑TITESCREW 4x8FCRM3‑BL 075180
18 VB744600 BINDHEADP‑TITESCREW 4x12FCRM3‑BL 075196
19 AAX09630 BINDHEADB‑TITESCREW 3x8 BLB 075243
20 AAX09640 BINDHEADP‑TITESCREW 3x10BL 075321
21 AAX12130 BINDHEADTAPPINGSCREW M3.5x16 021404
22 AAX12120 BINDHEADTAPPINGSCREW M4x20 021385
23 AAX13600 VOLUMEKNOB 044179
Z24 AAX13550 POWERSWITCH ROCKERJW‑M11RK 058288
* 101 AAX23560 CENTERSPEAKERSYSTEM NX‑C220BLACK 336612 (RABG)
* 101 AAX23570 CENTERSPEAKERSYSTEM NX‑C220BLACKGRAY 337298 (UC)
* 101 AAX23580 CENTERSPEAKERSYSTEM NX‑C220SILVER 337829
* 102 AAX23530 SATELLITESPEAKERSYSTEM NX‑220PBLACK 336613 (RABG)
* 102 AAX23540 SATELLITESPEAKERSYSTEM NX‑220PBLACKGRAY 337299 (UC)
* 102 AAX23550 SATELLITESPEAKERSYSTEM NX‑220PSILVER 337830
ACCESSORIES
202 AAX12600 WALLBRACKET 1pc 012941
203 AAX12140 BRACKET 1pc 012933
204 AAX13700 BRACKETA 1pc 005591
205 AAX13690 PINCORD 1P3m1pc 019075
206 AAX12220 CORD 15m1pc 055751
207 AAX13670 CORD 4m1pc 058602
208 AAX12390 PANHEADSCREW‑SEMS M4x8 017957
209 AAX11360 WINGBOLTS M4x0.7 057360

Parts List for Carbon Resistors
1/6W Type Part No.
HF45 7100
HF45 7110
HF85 7120
HF45 7130
HF45 7150
HF45 7180
HF45 7220
HF45 7240
HF85 7270
HF45 7300
HF45 7330
HF45 7360
HF45 7390
HF45 7470
HF45 7510
HF45 7560
HF45 7620
HF45 7680
HF45 7820
HF45 7910
HF45 8100
HF45 8110
HF45 8120
HF45 8150
HF45 8180
HF85 8220
HF45 8270
HF45 8300
HF45 8330
HF85 8390
HF45 8470
HF85 8560
HF85 8680
HF85 8820
HF45 9100
❊
HF85 9150
HF85 9180
HF85 9220
HF85 9330
❊
HF85 9470
1/4W Type Part No.
HF45 7100
HF45 7110
HJ35 7120
HF45 7130
HF45 7150
HF45 7180
HF45 7220
HF45 7240
HJ35 7270
HF45 7300
HF45 7330
HF45 7360
HF45 7390
HF45 7470
HF45 7510
HF45 7560
HF45 7620
HF45 7680
HF45 7820
HF45 7910
HF45 8100
HF45 8110
HF45 8120
HF45 8150
HF45 8180
HJ35 8220
HF45 8270
HF45 8300
HF45 8330
HJ35 8390
HF45 8470
HJ35 8560
HJ35 8680
HJ35 8820
HF45 9100
HJ35 9120
HJ35 9150
HJ35 9180
HJ35 9220
HJ35 9330
HJ35 9390
HJ35 9470
Value
10 kΩ
11 kΩ
12 kΩ
13 kΩ
15 kΩ
18 kΩ
22 kΩ
24 kΩ
27 kΩ
30 kΩ
33 kΩ
36 kΩ
39 kΩ
47 kΩ
51 kΩ
56 kΩ
62 kΩ
68 kΩ
82 kΩ
91 kΩ
100 kΩ
110 kΩ
120 kΩ
150 kΩ
180 kΩ
220 kΩ
270 kΩ
300 kΩ
330 kΩ
390 kΩ
470 kΩ
560 kΩ
680 kΩ
820 kΩ
1.0 MΩ
1.2 MΩ
1.5 MΩ
1.8 MΩ
2.2 MΩ
3.3 MΩ
3.9 MΩ
4.7 MΩ
1/6W Type Part No.
HF85 3100
❊
HF85 3220
HF85 3330
HF85 3470
HF85 3560
HF45 4100
HF85 4150
HF45 4220
HF85 4270
HF45 4330
HF85 4390
HF45 4470
HF45 4560
HF45 4680
HF45 4750
HF45 4820
HF45 4910
HF45 5100
HF85 5110
HF45 5120
HF45 5150
❊
HF45 5180
HF45 5200
HF45 5220
HF45 5270
HF45 5330
HF45 5390
HF45 5430
HF45 5470
HF45 5510
HF45 5560
HF45 5680
HF45 5820
HF45 5910
HF45 6100
HF45 6120
HF45 6150
HF45 6180
HF85 6200
HF45 6220
HF85 6240
HF45 6270
HF45 6300
HF45 6330
HF85 6360
HF45 6390
HF45 6470
HF45 6510
HF45 6560
HF45 6680
HF45 6820
HF45 6910
1/4W Type Part No.
HJ35 3100
HJ35 3180
HJ35 3220
HJ35 3330
HJ35 3470
HJ35 3560
HF45 4100
HJ35 4150
HF45 4220
HJ35 4270
HF45 4330
HJ35 4470
HF45 4470
HF45 4560
HF45 4680
HF45 4750
HF45 4820
HF45 4910
HF45 5100
HJ35 5110
HF45 5120
HF45 5150
HJ35 5160
HF45 5180
HF45 5200
HF45 5220
HF45 5270
HF45 5330
HF45 5390
HF45 5430
HF45 5470
HF45 5510
HF45 5560
HF45 5680
HF45 5820
HF45 5910
HF45 6100
HF45 6120
HF45 6150
HF45 6180
HJ35 6200
HF45 6220
HJ35 6240
HF45 6270
HF45 6300
HF45 6330
HJ35 6360
HF45 6390
HF45 6470
HF45 6510
HF45 6560
HF45 6680
HF45 6820
HF45 6910
Value
1.0 Ω
1.8 Ω
2.2 Ω
3.3 Ω
4.7 Ω
5.6 Ω
10 Ω
15 Ω
22 Ω
27 Ω
33 Ω
39 Ω
47 Ω
56 Ω
68 Ω
75 Ω
82 Ω
91 Ω
100 Ω
110 Ω
120 Ω
150 Ω
160 Ω
180 Ω
200 Ω
220 Ω
270 Ω
330 Ω
390 Ω
430 Ω
470 Ω
510 Ω
560 Ω
680 Ω
820 Ω
910 Ω
1.0 kΩ
1.2 kΩ
1.5 kΩ
1.8 kΩ
2.0 kΩ
2.2 kΩ
2.4 kΩ
2.7 kΩ
3.0 kΩ
3.3 kΩ
3.6 kΩ
3.9 kΩ
4.7 kΩ
5.1 kΩ
5.6 kΩ
6.8 kΩ
8.2 kΩ
9.1 kΩ
1992
1/4W Type
HF45
1/6W Type
HF85
1/4W Type
HJ35
10mm 5mm
NS-P220
NS-P220
14
