Yamaha XV17ATMV(C) Road Star User manual

5VN-28199-12
XV17AV(C)
XV17AWV(C)
XV17AMV(C)
XV17ATV(C)
XV17ATMV(C)
OWNER’S MANUAL
LIT-11626-19-45

EAU10041
U5VN12E0.book Page 1 Wednesday, June 15, 2005 1:26 PM

INTRODUCTION
EAU10080
Congratulations on your purchase of the Yamaha Road Star™. This model is the result of Yamaha’s vast experience in the
production of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and
reliability that have made Yamaha a leader in these fields.
This manual will give you an understanding of the operation, inspection, and basic maintenance of this motorcycle. If you
have any questions concerning the operation or maintenance of your motorcycle, please consult a Yamaha dealer.
The design and manufacture of this Yamaha motorcycle fully comply with the emissions standards for clean air applicable at
the date of manufacture. Yamaha has met these standards without reducing the performance or economy of operation of the
motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the
recommended maintenance schedules and operating instructions contained within this manual.
U5VN12E0.book Page 1 Wednesday, June 15, 2005 1:26 PM

IMPORTANT MANUAL INFORMATION
EAU10131
Particularly important information is distinguished in this manual by the following notations:
NOTE:
●This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle
is subsequently sold.
●Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most
current product information available at the time of printing, there may be minor discrepancies between your motorcycle
and this manual. If you have any questions concerning this manual, please consult your Yamaha dealer.
WARNING
EWA10010
PLEASE READ THIS MANUAL AND THE “YOU AND YOUR MOTORCYCLE: RIDING TIPS”BOOKLET CAREFULLY
AND COMPLETELY BEFORE OPERATING THIS MOTORCYCLE. DO NOT ATTEMPT TO OPERATE THIS MOTOR-
CYCLE UNTIL YOU HAVE ATTAINED ADEQUATE KNOWLEDGE OF ITS CONTROLS AND OPERATING FEATURES
The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS
INVOLVED!
Failure to follow WARNING instructions could result in severe injury or death to the
motorcycle operator, a bystander or a person inspecting or repairing the motor-
cycle.
A CAUTION indicates special precautions that must be taken to avoid damage to
the motorcycle.
A NOTE provides key information to make procedures easier or clearer.
WARNING
CAUTION:
NOTE:
U5VN12E0.book Page 1 Wednesday, June 15, 2005 1:26 PM

IMPORTANT MANUAL INFORMATION
AND UNTIL YOU HAVE BEEN TRAINED IN SAFE AND PROPER RIDING TECHNIQUES. REGULAR INSPECTIONS
AND CAREFUL MAINTENANCE, ALONG WITH GOOD RIDING SKILLS, WILL ENSURE THAT YOU SAFELY ENJOY
THE CAPABILITIES AND THE RELIABILITY OF THIS MOTORCYCLE.
*Product and specifications are subject to change without notice.
U5VN12E0.book Page 2 Wednesday, June 15, 2005 1:26 PM

IMPORTANT MANUAL INFORMATION
EAU10192
XV17AV(C)/XV17AWV(C)/XV17AMV(C)/XV17ATV(C)/
XV17ATMV(C)
OWNER’S MANUAL
©2005 by Yamaha Motor Corporation, U.S.A.
1st edition, May 2005
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Corporation, U.S.A.
is expressly prohibited.
Printed in Japan.
P/N LIT-11626-19-45
AFFIX DEALER
LABEL HERE
U5VN12E0.book Page 3 Wednesday, June 15, 2005 1:26 PM

TABLE OF CONTENTS
SAFETY INFORMATION ..................1-1
Location of important labels ...........1-5
DESCRIPTION ..................................2-1
Left view ..........................................2-1
Right view........................................2-3
Controls and instruments ................2-5
INSTRUMENT AND CONTROL
FUNCTIONS.......................................3-1
Main switch/steering lock ................3-1
Indicator and warning lights ............3-2
Speedometer unit ...........................3-3
Self-diagnosis device .....................3-3
Fuel gauge .....................................3-4
Clock ..............................................3-4
Handlebar switches ........................3-5
Clutch lever ....................................3-6
Shift pedal ......................................3-6
Brake lever .....................................3-6
Brake pedal ....................................3-7
Fuel tank cap ..................................3-7
Fuel ................................................3-8
Fuel cock ........................................3-9
Starter (choke) knob .....................3-10
Locking the steering with a
padlock ......................................3-10
Rider seat .....................................3-10
Helmet holder ...............................3-11
Windshield
[XV17ATV(C)/XV17ATMV(C)]....3-12
Saddlebags [XV17ATV(C)] .......... 3-13
Sidecases [XV17ATMV(C)] .......... 3-13
Adjusting the shock absorber
assembly .................................. 3-14
Sidestand ..................................... 3-16
Ignition circuit cut-off system ....... 3-17
PRE-OPERATION CHECKS ............. 4-1
Pre-operation check list ................. 4-2
OPERATION AND IMPORTANT
RIDING POINTS ................................ 5-1
Starting and warming up a cold
engine ......................................... 5-1
Starting a warm engine .................. 5-2
Shifting ........................................... 5-3
Engine break-in .............................. 5-4
Parking ........................................... 5-5
PERIODIC MAINTENANCE AND
MINOR REPAIR................................. 6-1
PERIODIC MAINTENANCE .......... 6-1
Owner’s tool kit .............................. 6-1
Periodic maintenance chart for the
emission control system ............. 6-3
General maintenance and
lubrication chart .......................... 6-4
Removing and installing the
panel ........................................... 6-8
Checking the spark plugs .............. 6-8
Canister (for California only) ........ 6-10
Engine oil and oil filter cartridge ... 6-10
Transfer case oil ........................... 6-13
Cleaning the air filter element ...... 6-15
Carburetor .................................... 6-16
Checking the throttle cable free
play ........................................... 6-17
Valve clearance ............................ 6-17
Tires (For spoke wheel model) ..... 6-17
Tires (For cast wheel models) ..... 6-19
Spoke wheels ............................... 6-22
Cast wheels .................................. 6-22
Accessories and replacement
parts .......................................... 6-22
Adjusting the clutch lever free
play ........................................... 6-23
Adjusting the brake lever free
play ........................................... 6-24
Adjusting the rear brake light
switch ........................................ 6-25
Checking the front and rear brake
pads .......................................... 6-25
Checking the brake fluid level ......6-26
Changing the brake fluid ..............6-27
Drive belt slack ............................. 6-27
Checking and lubricating the
cables ....................................... 6-29
Checking and lubricating the
throttle grip and cable ............... 6-29
Checking and lubricating the
brake and shift pedals ...............6-29
U5VN12E0.book Page 1 Wednesday, June 15, 2005 1:26 PM

TABLE OF CONTENTS
Checking and lubricating the
brake and clutch levers .............6-30
Checking and lubricating the
sidestand ...................................6-31
Lubricating the swingarm pivots ...6-31
Lubricating the rear suspension ...6-31
Checking the front fork .................6-32
Checking the steering ...................6-32
Checking the wheel bearings .......6-33
Battery ..........................................6-33
Replacing the fuses ......................6-35
Replacing the headlight bulb ........6-36
Tail/brake light ..............................6-37
Replacing a turn signal light
bulb ...........................................6-38
Replacing a license plate light
bulb ...........................................6-38
Supporting the motorcycle ............6-39
Troubleshooting ............................6-39
Troubleshooting chart ...................6-40
MOTORCYCLE CARE AND
STORAGE ..........................................7-1
Care ................................................7-1
Storage ...........................................7-4
SPECIFICATIONS .............................8-1
CONSUMER INFORMATION.............9-1
Identification numbers ....................9-1
Reporting safety defects .................9-3
Motorcycle noise regulation ........... 9-4
Maintenance record ....................... 9-5
YAMAHA MOTOR CORPORATION,
U.S.A. STREET AND ENDURO
MOTORCYCLE LIMITED
WARRANTY ............................... 9-7
YAMAHA EXTENDED SERVICE
(Y.E.S.) ....................................... 9-9
U5VN12E0.book Page 2 Wednesday, June 15, 2005 1:26 PM

1-1
1
SAFETY INFORMATION
EAU10251
MOTORCYCLES ARE SINGLE
TRACK VEHICLES. THEIR SAFE USE
AND OPERATION ARE DEPENDENT
UPON THE USE OF PROPER RIDING
TECHNIQUES AS WELL AS THE EX-
PERTISE OF THE OPERATOR. EV-
ERY OPERATOR SHOULD KNOW
THE FOLLOWING REQUIREMENTS
BEFORE RIDING THIS MOTOR-
CYCLE.
HE OR SHE SHOULD:
●OBTAIN THOROUGH INSTRUC-
TIONS FROM A COMPETENT
SOURCE ON ALL ASPECTS OF
MOTORCYCLE OPERATION.
●OBSERVE THE WARNINGS AND
MAINTENANCE REQUIRE-
MENTS IN THE OWNER’S MAN-
UAL.
●OBTAIN QUALIFIED TRAINING
IN SAFE AND PROPER RIDING
TECHNIQUES.
●OBTAIN PROFESSIONAL TECH-
NICAL SERVICE AS INDICATED
BY THE OWNER’S MANUAL
AND/OR WHEN MADE NECES-
SARY BY MECHANICAL CONDI-
TIONS.
Safe riding
●Always make pre-operation
checks. Careful checks may help
prevent an accident.
●This motorcycle is designed to car-
ry the operator and a passenger.
●The failure of motorists to detect
and recognize motorcycles in traf-
fic is the predominating cause of
automobile/motorcycle accidents.
Many accidents have been caused
by an automobile driver who did
not see the motorcycle. Making
yourself conspicuous appears to
be very effective in reducing the
chance of this type of accident.
Therefore:
•Wear a brightly colored jacket.
•Use extra caution when ap-
proaching and passing through
intersections, since intersec-
tions are the most likely places
for motorcycle accidents to oc-
cur.
•Ride where other motorists can
see you. Avoid riding in another
motorist’s blind spot.
●Many motorcycle accidents in-
volve inexperienced operators. In
fact, many operators who have
been involved in accidents do not
even have a current motorcycle li-
cense.
•Make sure that you are qualified
and that you only lend your
motorcycle to other qualified op-
erators.
•Know your skills and limits.
Staying within your limits may
help you to avoid an accident.
•We recommend that you prac-
tice riding your motorcycle
where there is no traffic until you
have become thoroughly famil-
iar with the motorcycle and all of
its controls.
●Many motorcycle accidents have
been caused by error of the motor-
cycle operator. A typical error
made by the operator is veering
U5VN12E0.book Page 1 Wednesday, June 15, 2005 1:26 PM

SAFETY INFORMATION
1-2
1
wide on a turn due to EXCESSIVE
SPEED or undercornering (insuffi-
cient lean angle for the speed).
•Always obey the speed limit and
never travel faster than warrant-
ed by road and traffic conditions.
•Always signal before turning or
changing lanes. Make sure that
other motorists can see you.
●The posture of the operator and
passenger is important for proper
control.
•The operator should keep both
hands on the handlebar and
both feet on the operator foot-
rests during operation to main-
tain control of the motorcycle.
•The passenger should always
hold onto the operator, seat
strap, or grab bar, if equipped,
with both hands and keep both
feet on the passenger footrests.
•Never carry a passenger unless
he or she can firmly place both
feet on the passenger footrests.
●Never ride under the influence of
alcohol or other drugs.
●This motorcycle is designed for on-
road use only, therefore, it is not
suitable for off-road use.
Protective apparel
The majority of fatalities from motor-
cycle accidents are the result of head
injuries. The use of a safety helmet is
the single most critical factor in the pre-
vention or reduction of head injuries.
●Always wear an approved helmet.
●Wear a face shield or goggles.
Wind in your unprotected eyes
could contribute to an impairment
of vision which could delay seeing
a hazard.
●The use of a jacket, heavy boots,
trousers, gloves, etc., is effective in
preventing or reducing abrasions
or lacerations.
●Never wear loose-fitting clothes,
otherwise they could catch on the
control levers, footrests, or wheels
and cause injury or an accident.
●Never touch the engine or exhaust
system during or after operation.
They become very hot and can
cause burns. Always wear protec-
tive clothing that covers your legs,
ankles, and feet.
●Passengers should also observe
the precautions mentioned above.
Modifications
Modifications made to this motorcycle
not approved by Yamaha, or the re-
moval of original equipment, may ren-
der the motorcycle unsafe for use and
may cause severe personal injury.
Modifications may also make your
motorcycle illegal to use.
Loading and accessories
Adding accessories or cargo to your
motorcycle can adversely affect stabili-
ty and handling if the weight distribution
of the motorcycle is changed. To avoid
the possibility of an accident, use ex-
treme caution when adding cargo or
accessories to your motorcycle. Use
extra care when riding a motorcycle
that has added cargo or accessories.
Here are some general guidelines to
follow if loading cargo or adding acces-
sories to your motorcycle:
U5VN12E0.book Page 2 Wednesday, June 15, 2005 1:26 PM

SAFETY INFORMATION
1-3
1
Loading
The total weight of the operator, pas-
senger, accessories and cargo must
not exceed the maximum load limit.
When loading within this weight limit,
keep the following in mind:
●Cargo and accessory weight
should be kept as low and close to
the motorcycle as possible. Make
sure to distribute the weight as
evenly as possible on both sides of
the motorcycle to minimize imbal-
ance or instability.
●Shifting weights can create a sud-
den imbalance. Make sure that ac-
cessories and cargo are securely
attached to the motorcycle before
riding. Check accessory mounts
and cargo restraints frequently.
●Never attach any large or heavy
items to the handlebar, front fork,
or front fender. These items, in-
cluding such cargo as sleeping
bags, duffel bags, or tents, can
create unstable handling or slow
steering response.
Accessories
Genuine Yamaha accessories have
been specifically designed for use on
this motorcycle. Since Yamaha cannot
test all other accessories that may be
available, you must personally be re-
sponsible for the proper selection, in-
stallation and use of non-Yamaha
accessories. Use extreme caution
when selecting and installing any ac-
cessories.
Keep the following guidelines in mind,
as well as those provided under “Load-
ing”when mounting accessories.
●Never install accessories or carry
cargo that would impair the perfor-
mance of your motorcycle. Care-
fully inspect the accessory before
using it to make sure that it does
not in any way reduce ground
clearance or cornering clearance,
limit suspension travel, steering
travel or control operation, or ob-
scure lights or reflectors.
•Accessories fitted to the handle-
bar or the front fork area can
create instability due to improper
weight distribution or aerody-
namic changes. If accessories
are added to the handlebar or
front fork area, they must be as
lightweight as possible and
should be kept to a minimum.
•Bulky or large accessories may
seriously affect the stability of
the motorcycle due to aerody-
namic effects. Wind may at-
tempt to lift the motorcycle, or
the motorcycle may become un-
stable in cross winds. These ac-
cessories may also cause
instability when passing or being
passed by large vehicles.
•Certain accessories can dis-
place the operator from his or
her normal riding position. This
improper position limits the free-
dom of movement of the opera-
Maximum load:
XV17AMV 194 kg (428 lb)
XV17AMVC 194 kg (428 lb)
XV17ATMV 179 kg (395 lb)
XV17ATMVC 179 kg (395 lb)
XV17ATV 179 kg (395 lb)
XV17ATVC 179 kg (395 lb)
XV17AV 194 kg (428 lb)
XV17AVC 194 kg (428 lb)
XV17AWV 194 kg (428 lb)
XV17AWVC 194 kg (428 lb)
U5VN12E0.book Page 3 Wednesday, June 15, 2005 1:26 PM

SAFETY INFORMATION
1-4
1
tor and may limit control ability,
therefore, such accessories are
not recommended.
●Use caution when adding electri-
cal accessories. If electrical acces-
sories exceed the capacity of the
motorcycle’s electrical system, an
electric failure could result, which
could cause a dangerous loss of
lights or engine power.
Gasoline and exhaust gas
●GASOLINE IS HIGHLY FLAMMA-
BLE:
•Always turn the engine off when
refueling.
•Take care not to spill any gaso-
line on the engine or exhaust
system when refueling.
•Never refuel while smoking or in
the vicinity of an open flame.
●Never start the engine or let it run
for any length of time in a closed
area. The exhaust fumes are poi-
sonous and may cause loss of
consciousness and death within a
short time. Always operate your
motorcycle in an area that has ad-
equate ventilation.
●Always turn the engine off before
leaving the motorcycle unattended
and remove the key from the main
switch. When parking the motor-
cycle, note the following:
•The engine and exhaust system
may be hot, therefore, park the
motorcycle in a place where pe-
destrians or children are not like-
ly to touch these hot areas.
•Do not park the motorcycle on a
slope or soft ground, otherwise it
may fall over.
•Do not park the motorcycle near
a flammable source (e.g. a kero-
sene heater, or near an open
flame), otherwise it could catch
fire.
●When transporting the motorcycle
in another vehicle, make sure that
it is kept upright and that the fuel
cock is turned to “ON”or “RES”(for
vacuum type) / “OFF”(for manual
type). If it should lean over, gaso-
line may leak out of the carburetor
or fuel tank.
●If you should swallow any gaso-
line, inhale a lot of gasoline vapor,
or allow gasoline to get into your
eyes, see your doctor immediately.
If any gasoline spills on your skin
or clothing, immediately wash the
affected area with soap and water
and change your clothes.
U5VN12E0.book Page 4 Wednesday, June 15, 2005 1:26 PM

SAFETY INFORMATION
1-5
1
EAU10381
Location of important labels
Please read the following important labels carefully before operating this vehicle.
U5VN12E0.book Page 5 Wednesday, June 15, 2005 1:26 PM

SAFETY INFORMATION
1-6
1
2
3
XV17ATV / XV17ATMV
1
5
6
4
7
XV17ATV / XV17ATMV
California only
California only
U5VN12E0.book Page 6 Wednesday, June 15, 2005 1:26 PM

DESCRIPTION
2-1
2
EAU32220
Left view
XV17AV(C)/XV17AWV(C)/XV17AMV(C)
1. Shift pedal (page 3-6)
2. Starter (choke) knob (page 3-10)
3. Fuel cock (page 3-9)
4. Engine oil filler cap (page 6-10)
5. Battery (page 6-33)
6. Owner’s tool kit (page 6-1)
7. Fuse (page 6-35)
U5VN12E0.book Page 1 Wednesday, June 15, 2005 1:26 PM

DESCRIPTION
2-2
2
XV17ATV(C)/XV17ATMV(C)
1. Shift pedal (page 3-6)
2. Starter (choke) knob (page 3-10)
3. Fuel cock (page 3-9)
4. Engine oil filler cap (page 6-10)
5. Battery (page 6-33)
6. Owner’s tool kit (page 6-1)
7. Fuse (page 6-35)
U5VN12E0.book Page 2 Wednesday, June 15, 2005 1:26 PM

DESCRIPTION
2-3
2
EAU32230
Right view
XV17AV(C)/XV17AWV(C)/XV17AMV(C)
1. Passenger footrest
2. Fuel tank (page 3-7)
3. Fuel tank cap (page 3-7)
4. Brake pedal (page 3-7)
5. Rider footrest
6. Air filter element (page 6-15)
7. Shock absorber assembly spring preload adjusting nut (page 3-14)
8. Muffler
U5VN12E0.book Page 3 Wednesday, June 15, 2005 1:26 PM

DESCRIPTION
2-4
2
XV17ATV(C)/XV17ATMV(C)
1. Fuel tank (page 3-7)
2. Fuel tank cap (page 3-7)
3. Windshield (page 3-12/3-5)
4. Brake pedal (page 3-7)
5. Rider footrest
6. Air filter element (page 6-15)
7. Shock absorber assembly spring preload adjusting nut (page 3-14)
8. Muffler
U5VN12E0.book Page 4 Wednesday, June 15, 2005 1:26 PM

DESCRIPTION
2-5
2
EAU32240
Controls and instruments
XV17AV(C)/XV17AWV(C)/XV17AMV(C)
1. Clutch lever (page 3-6)
2. Left handlebar switches (page 3-5)
3. Speedometer unit (page 3-3)
4. Main switch/steering lock (page 3-1)
5. Right handlebar switches (page 3-5)
6. Throttle grip (page 6-17)
7. Brake lever (page 3-6)
U5VN12E0.book Page 5 Wednesday, June 15, 2005 1:26 PM

DESCRIPTION
2-6
2
XV17ATV(C)/XV17ATMV(C)
1. Clutch lever (page 3-6)
2. Left handlebar switches (page 3-5)
3. Speedometer unit (page 3-3)
4. Main switch/steering lock (page 3-1)
5. Right handlebar switches (page 3-5)
6. Throttle grip (page 6-17)
7. Brake lever (page 3-6)
U5VN12E0.book Page 6 Wednesday, June 15, 2005 1:26 PM
