Yamaha YZF R1 User manual

DIC183
1KB-28199-11
YZFR1B(C)
OWNER’S MANUAL
Read this manual carefully before operating this vehicle.
LIT-11626-25-45

EAU10042
Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
U1KB11E0.book Page 1 Monday, August 8, 2011 11:14 AM

INTRODUCTION
EAU10083
Congratulations on your purchase of the Yamaha YZFR1B(C). This model is the result of Yamaha’s vast experience in the
production of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and
reliability that have made Yamaha a leader in these fields.
This manual will give you an understanding of the operation, inspection, and basic maintenance of this motorcycle. If you
have any questions concerning the operation or maintenance of your motorcycle, please consult a Yamaha dealer.
The design and manufacture of this Yamaha motorcycle fully comply with the emissions standards for clean air applicable at
the date of manufacture. Yamaha has met these standards without reducing the performance or economy of operation of the
motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the
recommended maintenance schedules and operating instructions contained within this manual.
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and this
manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10011
Please read this manual and the “YOU AND YOUR MOTORCYCLE: RIDING TIPS” booklet carefully before operating
this motorcycle. Do not attempt to operate this motorcycle until you have attained adequate knowledge of its con-
trols and operating features. Regular inspections and careful maintenance, along with good operating techniques,
will help ensure that you safely enjoy the capabilities and reliability of this motorcycle.
U1KB11E0.book Page 1 Monday, August 8, 2011 11:14 AM

IMPORTANT MANUAL INFORMATION
EAU10133
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
U1KB11E0.book Page 1 Monday, August 8, 2011 11:14 AM

IMPORTANT MANUAL INFORMATION
EAU10193
YZFR1B(C)
OWNER’S MANUAL
©2011 by Yamaha Motor Corporation, U.S.A.
1st edition, July 2011
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Corporation, U.S.A.
is expressly prohibited.
Printed in Japan.
P/N LIT-11626-25-45
U1KB11E0.book Page 2 Monday, August 8, 2011 11:14 AM

TABLE OF CONTENTS
LOCATION OF IMPORTANT
LABELS .............................................1-1
SAFETY INFORMATION ..................2-1
DESCRIPTION ..................................3-1
Left view ..........................................3-1
Right view ........................................3-2
Controls and instruments.................3-3
INSTRUMENT AND CONTROL
FUNCTIONS .......................................4-1
D-mode (drive mode) ......................4-1
Main switch/steering lock ................4-1
Indicator lights and
warning lights ..............................4-3
Multi-function meter unit .................4-7
Handlebar switches ......................4-15
Clutch lever ...................................4-17
Shift pedal .....................................4-17
Brake lever ...................................4-17
Brake pedal ..................................4-18
Traction control system ................4-18
Fuel tank cap ................................4-21
Fuel ...............................................4-21
Fuel tank breather hose and
overflow hose ............................4-23
Catalytic converter ........................4-23
Seats ............................................4-24
Helmet holder ...............................4-25
Storage compartment ...................4-26
Rider footrest position .................. 4-26
Rear view mirrors ......................... 4-27
Adjusting the front fork ................. 4-27
Adjusting the shock absorber
assembly ................................... 4-29
Luggage strap holders ................. 4-31
Sidestand ..................................... 4-32
Ignition circuit cut-off system ........ 4-32
FOR YOUR SAFETY –
PRE-OPERATION CHECKS ............. 5-1
OPERATION AND IMPORTANT
RIDING POINTS................................. 6-1
Starting the engine ......................... 6-1
Shifting ........................................... 6-2
Engine break-in .............................. 6-3
Parking ........................................... 6-4
PERIODIC MAINTENANCE AND
ADJUSTMENT ................................... 7-1
Owner’s tool kit ............................... 7-2
Periodic maintenance chart for
the emission control system ....... 7-3
General maintenance and
lubrication chart .......................... 7-5
Removing and installing
cowlings ...................................... 7-9
Checking the spark plugs ............. 7-11
Canister (for California only) ........ 7-12
Engine oil and oil filter cartridge ...7-13
Coolant ........................................ 7-15
Air filter element ........................... 7-18
Checking the engine idling
speed ........................................ 7-19
Checking the throttle grip free
play ........................................... 7-19
Valve clearance ........................... 7-19
Tires ............................................. 7-20
Cast wheels ................................. 7-22
Adjusting the clutch lever free
play ........................................... 7-22
Checking the brake lever free
play ........................................... 7-23
Brake light switches ..................... 7-24
Checking the front and
rear brake pads ........................ 7-24
Checking the brake fluid level ...... 7-25
Changing the brake fluid .............. 7-26
Drive chain slack .......................... 7-26
Cleaning and lubricating
the drive chain .......................... 7-28
Checking and lubricating
the cables ................................. 7-28
Checking and lubricating
the throttle grip and cable ......... 7-29
Checking and lubricating
the brake and shift pedals ........ 7-29
Checking and lubricating
the brake and clutch levers ...... 7-30
Checking and lubricating
the sidestand ............................ 7-30
U1KB11E0.book Page 1 Monday, August 8, 2011 11:14 AM

TABLE OF CONTENTS
Lubricating the swingarm
pivots .........................................7-31
Checking the front fork .................7-31
Checking the steering ...................7-32
Checking the wheel bearings .......7-32
Battery ..........................................7-32
Replacing the fuses ......................7-34
Replacing a headlight bulb ...........7-35
Tail/brake light ..............................7-37
Replacing a turn signal light
bulb ...........................................7-37
Replacing the license plate light
bulb ...........................................7-38
Auxiliary light ................................7-38
Supporting the motorcycle ............7-39
Troubleshooting ............................7-39
Troubleshooting charts .................7-41
MOTORCYCLE CARE AND
STORAGE ..........................................8-1
Matte color caution .........................8-1
Care ................................................8-1
Storage ...........................................8-4
SPECIFICATIONS .............................9-1
CONSUMER INFORMATION...........10-1
Identification numbers ..................10-1
Reporting safety defects ...............10-3
Motorcycle noise regulation ..........10-4
Maintenance record ......................10-5
YAMAHA MOTOR
CORPORATION, U.S.A.
STREET AND ENDURO
MOTORCYCLE LIMITED
WARRANTY ............................. 10-7
YAMAHA EXTENDED SERVICE
(Y.E.S.) ..................................... 10-9
U1KB11E0.book Page 2 Monday, August 8, 2011 11:14 AM

LOCATION OF IMPORTANT LABELS
1-1
1
EAU10384
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of
your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label
is available from your Yamaha dealer.
2,3
1 4 5,6
87
U1KB11E0.book Page 1 Monday, August 8, 2011 11:14 AM

LOCATION OF IMPORTANT LABELS
1-2
1
EMISSION HOSE ROUTING
#4#3#2#1
FUEL TANK
THROTTLE BODY
CHARCOAL
CANISTER
ATMOSPHERE
14B-21686-00
VACUUM HOSE ROUTING
#1 #4#3#2
14B-21684-00
INTAKE MANIFOLD
PRESS. SENSOR
NOTICE
Cleaning with alkaline or
acid cleaner, gasoline or
solvent will damage
windshield.
Use neutral detergent.
4B5-2815K-00
2 California only
1 3 California only
U1KB11E0.book Page 2 Monday, August 8, 2011 11:14 AM

LOCATION OF IMPORTANT LABELS
1-3
1
WARNING
4C8-2118K-00
BEFORE YOU OPERATE THIS VEHICLE, READ
THE OWNER’S MANUAL AND ALL LABELS.
ALWAYS WEAR AN APPROVED MOTORCYCLE
HELMET, eye protection, and protective clothing.
PREMIUM UNLEADED GASOLINE ONLY
91 Min. Pump Octane (R+M)/2
3JJ-28446-A1
1 kg {2 lbs}
4BR-24877-A0
LOAD LIMIT
Cold tire normal pressure should be set
as follows.
Up to 90 kg (198 lbs) load
: 250 },kPa, {2.50 kgf/cm2 36 psi
:290 kPa, {2.90
kgf/cm2
}, 42 psi
90 kg ( 198 lbs )
: 250 },kPa, {2.50 kgf/cm2 36 psi
:290 kPa, {2.90
kgf/cm2
}, 42 psi
~
maximum load
14B-21668-00
8
74
5
6
