YWA-10
Wireless Network Adapter
Owner’s Manual
© 2012 Yamaha Corporation Printed in China
English
YWA-10/EN-1
Allows Yamaha AV products equipped with a
NETWORK port and a DC OUT jack to be connected
with a wireless LAN.
Compatible devices can connect to the YWA-10
through a USB connector instead of a DC OUT jack.
Refer to the website below for a list of compatible
devices.
http://yamaha.com/
The firmware of this unit may be updated at times for
improvement. Please refer to the following website for
information on firmware updates.
http://yamaha.com/
Features
AV Receiver
YWA-10
Internet
connection
Modem
Wireless LAN router
(base unit)
Setup procedure
Checking the base unit
• Check that the Wireless LAN router (base unit)
can connect to the Internet.
Connecting to the base unit
• When the Wireless LAN router (base unit) has a
WPS button
^Carry out the procedures in “Step 2-A
Connecting to the base unit (using WPS)” to
connect to the base unit.
• When the Wireless LAN router (base unit) does
not have a WPS button
^Carry out the procedures in “Step 2-B
Connecting to the base unit (manual
configuration)” to connect to the base unit.
✻If connecting using “(using WPS)” does not
succeed, refer to “(manual configuration)” and
configure the connection.
Connecting to an AV product
The Wi-Fi CERTIFIED Logo is a
certification mark of the Wi-Fi
Alliance.
The Wi-Fi Protected Setup Mark
is a mark of the Wi-Fi Alliance.
aPOWER indicator
bWPS indicator
cWIRELESS indicator
dPower connector
eLAN1 port, LAN2 port
fWPS button
gReset button
• If you do not already have an Internet connection, please apply for one
before setting up this unit.
• Do not connect the USB power cable to a USB hub.
Part names
Things to check before setup
a b
d e f
gc
Upper surface of product Rear
Side
a
Check that the wireless LAN router (base unit) can connect to the
Internet without difficulty.
Notes
• If you do not currently have an Internet subscription, please obtain one.
• A wireless LAN router is required to set up a connection using this
procedure. Please obtain a wireless LAN router if you do not have one
available.
b
Check whether the wireless LAN router (base unit) is WPS compatible.
Check the owner's manual and other documentation supplied with the
wireless LAN router.
Note
WPS (Wi-Fi Protected Setup) is a function that uses a button to configure
connections and security on wireless LAN devices.
*Some Wi-Fi devices have “WPS” written on them.
Step 1 Checking the base unit
W
When the wireless LAN router (base unit) has a WPS button
Carry out “Step 2-A Connecting to the base unit (using WPS)”, and then
“Step 3 Connecting to an AV product”, in that order.
W
When the wireless LAN router (base unit) does not have a WPS
button
Carry out “Step 2-B Connecting to the base unit (manual configuration)”,
and then “Step 3 Connecting to an AV product”, in that order.
Computer
Internet connectivity
Wireless LAN
router
(base unit)
Modem
Internet
connection
Notes
• This explanation details the procedure for connecting using the WPS
function. When using a base unit that is not equipped with a WPS
function, refer to “Step 2-B Connecting to the base unit (manual
configuration)” at right.
• You will need to change the IP address of this unit if you are using more
than one YWA-10 at the same time.
Refer to “Troubleshooting” on the reverse page for more details.
1. Supply power to the YWA-10
a
Turn on the power of the AV product that you wish to connect this unit
to.
b
Use the supplied USB power cable to connect the power connector on
this unit to the DC OUT jack on the AV product.
The indicator on the front panel of this unit lights. Wait for approximately one
minute after the indicator lights and then carry out the following procedure.
Note
If the AV product is not equipped with a DC OUT jack, connect to the USB
connector on the front panel.
2. Connect the base unit
a
Press the WPS button on the wireless LAN router (base unit).
Refer to the owner’s manual of the wireless LAN router (base unit) for
information on how to use the WPS button.
b
Press and hold the WPS button on the rear of this unit for more than 5
seconds and release it.
The WPS indicator on the front panel lights.
c
Wait until the WPS indicator turns off (this will take two minutes at
most).
Note
If the WPS indicator blinks, carry out procedure 2 again, starting at number
a
.
Step 2-A Connecting to the base unit
(using WPS)
This completes connection with the base unit. Proceed to “Step 3
Connecting to an AV product”.
AV Receiver
Rear Panel
Press and hold for more
than 5 seconds.
Notes
• When making a manual connection to the base unit, or when you are
unable to connect using the procedure described in “Step 2-A Connecting
to the base unit (using WPS)” at left, refer to the explanation below.
• If the PC you are using to configure this unit is connected to the wireless
LAN, turn the PC’s wireless LAN function off.
• You will need to change the IP address of this unit if you are using more
than one YWA-10 at the same time.
Refer to “Troubleshooting” on the reverse page for more details.
1. Check the network that you are attempting to
connect to.
You will need the setting information from the wireless LAN router (base unit)
when connecting or setting up this unit. Have the following table ready for use.
* Refer to the owner’s manual of the wireless LAN router (base unit) for
information on how to check its wireless LAN settings.
■When using WEP security settings
*1: 16-digit number (0–9, A–F), *2: ASCII (0–9, A–Z, a–z)
■When using WPA/WPA2 security settings
Note
Use only alpha-numeric characters (0–9, A–Z, a–z) for an SSID or password.
Otherwise, Yamaha cannot guarantee normal operation.
Refer to the owner’s manual of the wireless LAN router (base unit) for
information on how to change the SSID or password.
2. Connect this unit to a PC
a
a
Turn the PC power on.
b
Use the supplied LAN cable to connect the LAN1 port (or the LAN2 port)
on this unit to the LAN port on the PC. Then, use the supplied USB
power cable to connect the power connector on this unit to the USB
connector on the PC.
The indicator on the front panel of this unit lights. Wait for approximately one
minute after the indicator lights and then carry out the following procedure.
3. Setting up this unit
a
Start the web browser on the PC.
b
Enter “ywa.setup” in the
address field in the Web
browser, and press the Enter
key.
Note
If the login screen does not appear even after you enter “ywa.setup”, enter
“192.168.1.249” and press the Enter key. If the login screen still does not
appear, refer to “Troubleshooting”.
Step 2-B Connecting to the base unit
(manual configuration)
Name Wireless LAN setting
(1) SSID
(2) Security mode ❑Open ❑Shared
(3) Security key type ❑Hexadecimal*1 ❑ASCII*2
(4) Default key ❑Key 1 ❑Key 2 ❑Key 3 ❑Key 4
(5) Password
Name Wireless LAN setting
(1) SSID
(2) Security mode ❑WPA-PSK ❑WPA2-PSK
(3) Encryption type ❑TKIP ❑AES
(4) Password
To assure the finest performance, please read this
manual carefully.
Keep it in a safe place for future reference.
Check that the following accessories are supplied with
the product.
Owner’s Manual (this manual)
Package contents
Wireless Network
Adapter (this unit)
LAN cable
USB power cable
Continues to the back side.

c
On the login screen, enter
“admin” in the user name field,
and “password” in the
password field, and then click
the OK button.
Note
If you cannot login to the setup screen, check that you have entered the
correct letters.
d
Where necessary, select the display language from the drop-down list.
The screen display language changes.
Note
The display examples in this manual use English as the display language.
e
Click [Setup Wizard] and then [Next], in that order.
The “Wireless Site Survey” screen appears.
f
On the “Wireless Site Survey” screen, choose the same SSID as in (1)
on the table in “1 Check the network that you are attempting to connect
to.” and then click [Next].
Notes
• When the SSID does not appear, click [Refresh] and then search again.
• If the SSID (the name of the device you are connecting to) does not
display even when the above operation is performed, the wireless LAN
router (base unit) power is turned off, or the SSID name notification is
turned off (SSID Broadcast refusal).
In such cases, enter the same SSID as the wireless LAN router (base
unit) directly.
• It is recommended that you connect to an SSID with an RSSI (Received
Signal Strength Indication) of 50 or above.
g
Follow the procedure in “1 Check the network that you are attempting
to connect to.” to set up this unit.
Refer to “■When using WEP security settings” in the table on the reverse
page to set up this unit.
aEnter the profile name of your choice in “profile name”.
bWhen (2) in the table is “Open”
^Select “Open” under “Encryption”.
When (2) in the table is “Shared”
^Select “SHARED” under “Encryption”.
cWhen (5) in the table is set to use a 10 or 5 letter password
^Select “64Bit” under “Key Length”.
When (5) in the table is set to use a 26 or 13 letter password
^Select “128Bit” under “Key Length”.
dWhen (3) in the table is “Hexadecimal”
^Select “Hex” under “Key Format”.
When (3) in the table is “ASCII”
^Select “ASCII” under “Key Format”.
eEnter the same encryption key
as in (5) on the table in the
same Encryption key field as in
(4) in the table.
For example, when (4) in the
table is “Key 1”, enter the same
password as “Encryption Key
1” from (5) in the table.
fSelect the same default key as
(4) from the table in “Default Tx
Key”.
gClick [APPLY].
Refer to “■When using WPA/WPA2 security settings” in the table on the
reverse page to set up this unit.
aEnter the profile name of your
choice in “profile name”.
bEnter the same password as in
(4) from the table in the “Pre-
shared Key” field.
cClick [APPLY].
Note
To register multiple base units repeat procedures ethrough g.
When (2) in the table is “Open / Shared”
When (2) in the table is “WPA-PSK”/“WPA2-PSK”
h
The “LAN Setup” screen appears. Change the IP address if it is already
being used by another device.
Check the settings and click [APPLY].
i
The seconds before this unit restarts are counted down (30 seconds).
When the count reaches “0”, this unit will restart. Click “OK” and check
that this unit can connect to the access point.
j
Close the browser.
k
Remove the connected LAN cable and USB power cable.
a
Use the supplied LAN cable to connect the LAN1 port (or the LAN2 port)
on this unit to the NETWORK port on the AV product. Then, use the
supplied USB power cable to connect the power connector on this unit
to the DC OUT jack on the AV product.
The indicator on the front panel of this unit lights. Wait for approximately one
minute and then carry out the following procedure.
Note
If the AV product is not equipped with a DC OUT jack, connect to the USB
connector on the front panel.
b
Turn on the power of the AV product that you wish to connect this unit
to.
c
Check that the network functions of the connected AV products
function correctly.
Refer to the owner’s manual of the AV product for information on these
network functions.
■The power does not turn on
• Check that the USB power cable is firmly connected to this unit and the AV
product.
• Check that the AV Receiver Network Standby is set to ON. (If Network
Standby is OFF, power supply to the DC OUT jack will turn OFF when the AV
Receiver is set to Standby.)
■Cannot connect using WPS
• Only some devices are WPS compatible. If you are unable to connect using
WPS, configure the settings manually.
■An error occurs when “ywa.setup” or “192.168.1.249” is input in the
address field of the web browser, or the login screen does not appear.
• Check the IP address settings (automatic or fixed setting) of the PC. If the
PC is set to fixed setting, change it to automatic.
• The IP address of this unit may have changed from its default setting. Refer
to “Resetting this unit” and reset this unit.
• If you are using any security software, turn it off temporarily. Refer to the
owner’s manual of the security software for information on how to turn it off.
• If the wireless channel of the base unit is set to “12” or “13”, change it to a
channel between “1” and “11”. (USA and Canada models only)
■Cannot log in from the login screen
• The ID and password may have been changed. Refer to “Resetting this unit”
and reset this unit.
This completes connection with the base unit. Proceed to “Step 3
Connecting to an AV product”.
Step 3 Connecting to an AV product
This completes the setup procedure.
Troubleshooting
AV Receiver
Rear Panel
■Unable to find the base unit in “Wireless Site Survey” on the setup
screen
• If this unit is too far away from the base unit (wireless LAN router, etc.) or
there is an obstacle between them, try searching again in close proximity to
the base unit, in a location where there are no obstacles between the two
devices.
• The base unit may be set to refuse SSID Broadcast. Set the SSID, security
mode, and key by hand.
■Unable to configure settings in “Wireless Site Survey” on the setup
screen
• Check the SSID. If the base unit SSID or password contain characters that
this unit cannot use, the password is greater than 30 characters long, or the
SSID is greater than 32 characters long, change them to settings that are
compatible with this unit.
• Check the base unit security mode, and set the same security mode on the
YWA-10 setup screen.
• The password you have entered may be incorrect. Check the password and
re-enter it.
• If multiple base units are registered, select the units to which you wish to
connect, and click [Connect].
■Not connected to the Internet, or connected to the Internet, but
experiencing sound skipping.
• There may be a problem with your Internet environment. Without using this
unit, check whether your PC can connect to the Internet, as in Step 1.
• Refer to “Step 3 Connecting to an AV product” and check that the products
and cables are connected correctly.
• If this unit is too far away from the base unit (wireless LAN router, etc.) or
there is an obstacle between them, try searching again in close proximity to
the base unit, in a location where there are no obstacles between the two
devices.
• If there is a microwave oven in the immediate area, electromagnetic waves
from the microwave oven may be interfering with the wireless transmissions.
Move further away from the microwave oven and try connecting again.
• The base unit may be restricting connections by MAC Address. Add the MAC
address written on the underside of this unit to the list of permitted
connections on the base unit.
• Turn on the power to this unit again.
• Turn on the power to the base unit (wireless LAN router, etc) again.
• Check the IP address settings (automatic or fixed setting) of the network
device to which this product is to be connected. If the network device is set to
fixed setting, change it to automatic.
• Check that the DHCP server function on the base unit is set to ON.
• Try removing and reinserting the LAN cable connecting this unit and the AV
Receiver.
• Connection is not possible if multiple YWA-10 units are in use, or if another
device is using the IP address “192.168.xxx.249”. Refer to “Changing the IP
address” and change to a unique IP address.
• If you are unable to connect even after performing the above procedure,
reset this unit. Refer to “Resetting this unit” for information on resetting.
• Audio content that utilizes a significant amount of data may not transmit
correctly over a wireless connection in some cases. Use audio formats that
require a small amount of data.
Note
Resetting this unit will erase all of its settings. Be sure to note down the
necessary information before resetting.
aCheck that this unit’s power is on.
bPress the Reset button for at least 10 seconds.
cRelease the Reset button when all the indicators are blinking.
When this unit restarts after approximately 2 minutes, resetting is complete.
When resetting is complete, set up this unit again, starting from “Step 2-A
Connecting to the base unit (using WPS)” or “Step 2-B Connecting to the base
unit (manual configuration)”.
aReset this unit.
Refer to “Resetting this unit”.
bConnect this unit to a PC.
Refer to “2 Connect this unit to a PC” in “Step 2-B Connecting to the base
unit (manual configuration)”.
cOpen the setting screen of this unit.
Refer to “3 Setting up this unit” in “Step 2-B Connecting to the base unit
(manual configuration)”, and carry out procedures 1-3.
dClick “Network” in the menu in the upper area of the setting screen.
eOn the “LAN Setup” screen, enter “192.168.1.xxx” as an IP address.
Set the “xxx” in “192.168.1.xxx” to a number that is between 2 and 248, and
one that is not used by other devices.
fClick [APPLY].
gSet up this unit again.
Carry out “Step 2-A Connecting to the base unit (using WPS),” or “Step 2-B
Connecting to the base unit (manual configuration)”.
Resetting this unit
Changing the IP address
User name (Login ID): admin
IP address: 192.168.1.249
Password: password
Wireless section
Wireless type .................................. IEEE802.11n, IEEE802.11g, IEEE802.11b
Frequency of operation .......................................... US: 1—11 ch, EU: 1—13 ch
Frequency band ................................................ 2.4 GHz (2,400—2,483.5 MHz)
Type of modulation ...................... IEEE802.11n: OFDM, IEEE802.11g: OFDM,
IEEE802.11b: DSSS
Antenna gain...............................................................................................2 dBi
Antenna...................................................................Internal antenna x 2 (2T2R)
Access mode .......................................................................Infrastracture mode
Bandwidth ..........................................................................20 MHz and 40 MHz
Security ...................WPA2-PSK (TKIP), WPA2-PSK (AES), WPA-PSK (TKIP),
WPA-PSK (AES), SHARED, OPEN (WEP: 64bit/128bit,
Key format: ASCII/Hexadecimal), Disabled (No encryption)
Wired section
Ethernet type......................IEEE802.3u (100Base-Tx), IEEE802.3i (10Base-T)
Interface .......................................................................RJ-45 port x 2 (LAN x 2)
Ethernet cable......................................................................Category 5 or more
Configuration window requirement
OS ............................................... Windows 7(32bit/64bit)/Vista(32bit/64bit)/XP,
Mac OS X 10.4/10.5/10.6, CPU: Intel/PowerPC support)
Browser................................ Internet Explorer 6 or above, Firefox 5.0 or above
General
Dissipation power.......................................... Maximum of approximately 2.3 W
Power supply ................................................................................DC +5V 0.5 A
External dimensions.......................... 78 x 70 x 22 (mm) *Excluding protrusions
Weight..........................................................................................................62 g
Operating temperature range.........................................Temperature: 0—40 °C
Humidity: 10—90 % (No condensation)
Strage temperature range..........................................Temperature: –20—60 °C
Humidity: 10—90 % (No condensation)
* Specifications are subject to change without notice.
Factory default settings
Specifications
(E.U. only)
This symbol mark is according to the EU directive 2002/96/EC.This symbol
mark means that electrical and electronic equipment, at their end-of-life, should
be disposed of separately from your household waste. Please act according to
your local rules and do not dispose of your old products with your normal
household waste.
■Precautions
Read this before using this unit.
To assure the finest performance, please read this manual carefully. Keep it in a safe place
for future reference.
1 Install this unit in a cool, dry, clean place away from direct sunlight, heat sources, and
sources of excessive vibration, dust, moisture, and/or cold. (Do not use/keep this unit in
a car etc.)
2 Locate this unit away from other electrical appliances, motors, or transformers to avoid
humming sounds.
3 Do not expose this unit to sudden temperature changes from cold to hot, and do not
locate this unit in an environment with high humidity (i.e. a room with a humidifier) to
prevent condensation inside this unit, which may cause an electrical shock, fire, damage
to this unit, and/or personal injury.
4 Do not clean this unit with chemical solvents; this might damage the finish. Use a clean,
dry cloth.
5 Do not attempt to modify or fix this unit. Contact qualified Yamaha service personnel
when any service is needed. The cabinet should never be opened for any reason.
6 Be sure to read the “Troubleshooting” section regarding common operating errors before
concluding that the unit is faulty.
7 Before moving this unit, disconnect USB power cable from the AV product.
Do not use this unit within 22 cm (9 inches) of persons with a heart pacemaker implant or
defibrillator implant.
Explanations regarding GPL
This product utilizes GPL/LGPL open-source software in some sections. You have the right
to obtain, duplicate, modify, and redistribute this open-source code only. For information on
GPL/LGPL open source software, how to obtain it, and the GPL/LGPL license, refer to the
Yamaha Corporation website (http://download.yamaha.com/sourcecodes/ywa-10/).
• This product is limited to indoor use only.
• Frequencies used by this product may be prohibited to use in some counties. As a user of
this product, you have responsibilities to use this product only in the intended countries
and confirm that this product is set to use frequencies and channels that are allowed to
use in your country. Violators may be punishable by law of the country. For information
about laws of each country, please refer to “ERC/REC 70-03”.
We, the manufacturer (Yamaha Corporation) hereby declare that this equipment (Wireless
Network Adapter), model YWA-10 is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.
• Microsoft, Windows 7, Windows Vista and Windows XP are registered trademarks or
trademarks of Microsoft Corporation in the U.S. and other countries.
• Other product names, technology names, and company names mentioned in this manual may
be trademarks or registered trademarks of their respective owners and are hereby
acknowledged.

AV Receiver
RX-V773
AV Receiver
RX-V773
YWA-10
Internet
connection
Modem
Wireless router
1. Connecting the YWA-10 to the RX-V773
Press and hold for 10 seconds or
until the WPS light turns solid.
YWA-10 Wireless Network Adapter - Quick Setup Guide
The Wi-Fi CERTIFIED Logo is a
certification mark of the Wi-Fi
Alliance.
The Wi-Fi Protected Setup Mark
is a mark of the Wi-Fi Alliance.
AV Receiver
RX-V773
Rear Panel
a. Connect the supplied USB power cable to the YWA-10 and the RX-V773
back panel DC OUT 5V-0.5A USB power port.
b. Power ON the RX-V773 and wait for one minute after the green power
light on the YWA-10 is lit, then proceed to step 2.
3. Checking Network Connectivity
Once the YWA-10 is connected to the RX-V773, you
can test internet connectivity by going to the Net Radio
input and selecting a station.
a. Press the Net button on the receiver remote
repeatedly until Net Radio is displayed.
b. If the On-Screen Display shows Bookmarks,
Locations, Genres, etc. you are successfully
connected to the internet.
Notes:
If your wireless router does not support WPS or if you
need additional help, please refer to the YWA-10
2ZQHU·V0DQXDORUYLVLWKWWSZUGLW<:$+(/3
YWA10BL QSG 0-27108-10770-7
The YWA-10 Wireless Network Adapter can be used to connect the RX-V773 to a wireless home network.
This Quick Setup Guide walks you through using Wi-Fi Protected Setup (WPS) to automatically configure
the YWA-10 to your home network. If your wireless router does not support WPS or you need additional
KHOSSOHDVHUHIHUWRWKH<:$2ZQHU·V0DQXDORUYLVLWKWWSZUGLW<:$+(/3
2. Connecting the YWA-10 to your wireless network
a. Press the WPS button on your wireless router.
b. Press and hold down the WPS button on the rear of the
YWA-10 for 10 seconds or until the WPS indicator light
turns solid.
Wireless router
Press WPS
button
c. Remove your finger from the WPS button and wait for the WPS light to go
out. This can take up to 2 minutes.
1RWH,IWKH:36LQGLFDWRUEOLQNVGLVFRQQHFWSRZHURIWKH<:$DQG
start over at Step 1.
d. Connect the supplied Network cable from the YWA-10 to the Network port
on the RX-V773. Rear Panel

YWA-10
Français
Utilisation de l’adaptateur réseau sans fil YWA-10 à l’aide de l’un des ampli-tuners audio-vidéo ci-dessous
© 2012 Yamaha Corporation
English
When updating the receiver firmware, please follow these instructions.
- Perform the firmware update using a USB memory device. Firmware and instructions can be downloaded from Yamaha's website.
http://download.yamaha.com/
- If updating the firmware over the network using YWA-10, connect the supplied USB power cable to the USB port on the receiver's
front panel.
The DC OUT terminal on the rear panel is not designed for firmware updates. It may not be possible to update the firmware
depending on wireless network conditions.
AV Receiver model list:
- RX-A3020, RX-A2020, RX-A1020, RX-A820, RX-A720
- RX-V3073, RX-V2073, RX-V1073, RX-V773, RX-V673
- HTR-7065, HTR-6065
Using the YWA-10 wireless network adapter with one of the AV receivers listed below

8YAMAHA
1
:t®®l
[Q]
YWA-10
FCC INFORMATION (for US customers)
1 IMPORTANT NOTICE: DONOT MODIFY
TillS
UNIT!
lbis
product, when installed as indicated in the instructions contained in this
manual, meets FCC requirements. Modifications not expressly approved
by
Yarnaha may void your authority, granted by the FCC, to use the product.
IMPORTANT: When connecting this product to accessories and/or another
product use only high quality shielded cables. Cable/s supplied with this
productMUST be used. Follow all installation instructions. Failure to follow
instructions could void your FCC authorization to use this productin the
USA.
NOTE: This product has been tested and found to comply with the requirements
listed inFCC Regulations, Part
15
for Class "B" digital devices. Compliance
with these requirements provides a reasonable level
of
assurance that your
use
of
this product in a residential environment will not result in harmful
interference with other electronic devices. This equipment generates/uses
radio frequencies and, ifnot installed and used according
to
the instructions
found in the users manual, may cause interference harmful to
th
e operation
of
otherelectronic devices.
Compliance with FCC regulations does not guarantee that interference will
not occur
in
all installations.
If
this product is found to be the source
of
interference, which can be detennined by turning the unit
"OFF'
and "ON",
plea~e
try
to
eliminate the problem by using one
of
the following measures:
Relocate either this product or
the
device that is being affected bythe
interference.
Utilize power outlets thatare on different branch (circuit breaker orfuse)
circuits or install AC line filter/s.
In
the case
of
radio orTV interference, relocate/reorient the antenna.
If
the
antenna lead-in is 300 ohm ribbon lead, change the lead-in to coaxial type
cable.
If
these corrective measures do not produce satisfactory result
s,
please
contact
the
local retailer authorized to distribute this type
of
product.
If
you
can not locate the appropriate retailer, please contact Yamaha Corporation
of
America
A/V
Division 6600Orangethorpe Ave., BuenaPark, CA 90620.
Theabove statements apply ONLY
to
those products distributed byYarnaha
Corporation
of
America
or
its subsidiaries.
COMPLIANCE INFORMATION STATEMENT (DECLARATION OF CONFORMITY PROCEDURE)
Responsible
Party
Yamaha
Corporation
of
America
AIV
Division
Yamaha
Canada
Music
Ltd.
Address
6600
Orangethorpe Avenue,
Buena
Park, 135
Milner
Avenue
, Toronto, Ontario,
CA
90620,
USA
MIS
3R1,
Canada
Telephone
1-714-522-9011 1-416-298-1311
Type
of
Equipment
Wireless
Network
Adapter
Model Name
YWA-10
•
This
device complies
with
Part 15
of
the
FCC
Rules
and
RSSGen
of
IC Rules.
• Operation is subject
to
the
following
two
conditions:
I)
this
device
may
not
cause
harmful interference,
and
2) this
device
must
accept
any
interference received including interference
that
m
ay
cause
unde
sired operation.
See
the "Troubleshooting" section
at
th
e e
nd
of
this
manual
if
interference
to
radio
re
ce
ption is suspected.
FCC WARNING
Change
or
modifications
not
expressly
approved
by the party responsible for
compliance
could void
the
user's
authority to
operate
the
equipment.
NOTICE
This
equipment
has
been
tested
and
found
to
comply
with
the
limits for a
Class
B digital device, pursuant
to
part
15
of
the
FCC
Rul
es
.
These
limits
are
designed
to
provide reasonable protection
against
harmful interference
in
aresidential installation.
This
equipment generates, uses
and
can
radiate radio frequency energy and,
if
not
installed
and
used
in
accordance
with
the
instructions,
may
cause
harmful
interference to radio communications. However, there
is
no
guarantee
that
interference will
not
occur
in
a particular installation.
If
this
equipment
does
cause
harmful interference
to
radio
or
television reception,
which
can
be de
termined
by
turning
the
e
quipment
off
and
on
,
the
user
is
encouraged to try to
correc
t the interferen
ce
by
one
or
more
of
the
following measures:
-Reorient
or
relo
ca
te
the
receiving antenna.
-
Incr
ease
th
e separation betw
ee
n the e
quipment
and receiver.
-Connect
th
e
equipment
into
an
outlet
on
a circuit different from that
to
which
the receiver is connected.
-Consult
th
e
dealer
or
an
experienced
radioffV
t
ec
hni
cian
for help.
This
equipment compiles with FCCIIC radiation
exposure
limits
se
t forth
for
uncontrolled
equipment
and
meets the
FCC
radio frequency (RF)
Expo
sure Guidelines in
Supplement
C to
OET65
and
RSS-1
02
of
the
IC radio frequency (RF)
Exposure
rules.
Thi
s
equipment
ha
s
very
low
l
eve
ls
of
RF
energy that
it
de
emed to
comply
without
ma
ximum
permissive exposure evaluation (MPE).
But
it
is desirable that
it
should
be installed
and
operated with
at
least 20
em
and
more
between
the radiator
and
per
s
on's
body
(excluding extremities: hands, wrists, feet
and
ankles).
This transmitter must
not
be
co-located
or
operated
in
conjunction with any
other
an
tenna
or
transmitter.
Warranty policy for U.S. and
Cana~a
customer
Your
Yamaha
product
is
covered
by
a limited warranty
for
one
year
from
the
date
of
purchase.
In
the
unlikely event
of
failure
due
to defective materials
or
workmanship,
Yamaha
will
rep
air
or
replace them at
no
charge
. Please visit
our
website
for
full details.
U.S.: (http:
//www
.yamaha.com/yec/), Canada: (http://www.yamaha.ca/)
© 2
01
2 Yamaha Corporation YAMAHA
CO
RPORATION
Printed in China

II
INFORMATION DE LA FCC (pour les clients residant aux Etats-Unis)
1 AVIS IMPORT ANT : NE PAS APPORTER DE MODIFICATIONSA
CET APPAREIL !
Cet appareil est conforme aux exigences de Ia FCC s'il est installe selon
les instructions du mode d'emploi. Toute modification non approuvee
expressement par Yamaha peut invalider l'autorisation de Ia FCC
d'utiliser cet appareil.
IMPORTANT: N'utiliser que des cables blindes de haute qualite pour le
raccordement de cet appareil ades accessoires et/ou aun autre appareil.
Seuls le ou les cables foumis avec le produit DOIVENT etre utilises.
Suivre les instructions concernant !'installation.
Lenon respect des
instructions peut invalider l'autorisation, accordee par Ia FCC,
d'u tiliser
ce produit aux Etats-Unis.
REMARQUE : Cet appareil a ete teste et declare conforme a ux normes
relatives aux appareils numeriques
deCla sse<< B >>, telles que fixees dans
I'Article
15 de Ia Reglementation FCC. Ces normes sont destinees a
assurer une protection suffisante contre les interferences nuisibles avec
d' autres appareils electroniques dans une installation residentielle. Cet
equipement genere et utilise des frequences radio qui, en cas
d'installation
et d'utilisation non conformes aux instructions du mode
d
'e mploi, peuvent etre al'origine d'interferences empechant d'autres
appareils de fonctionner.
Cependant, Ia conformite a
Ia Reglementation FCC negarantit pas I'absence
d'interterences dans une installation particuliere. Si cetappareil devait
produire des interterences, cequi peut etre determine en
<< ETEIGNANT >>,puis en<< RALLUMANT » l'appareil,l'utilisateurest
invite aessayer de corriger
le probleme d'une des manieres suivantes :
Reorienter cet appareil ou le dispositifaffecte par les interterences.
Utiliser des prises d'alimentation branchees surdifferents circuits (avec
interrupteur de circuit ou fusible) ou installer un ou des filtres pour ligne
secteur.
Dans le cas d'interterences radio ou TV, changer de place l'antenne et Ia
reorienter. Si
I' antenneest un conducteur plat de 300ohms, remplacer ce
cable parun cable de type coaxial.
Si ces mesures ne donnent pas les resultats escomptes, priere de contacter le
detaillant local autorise acommercialiserce type d'appareil. Si ce n'estpas
possible, priere de contacter YamahaCorporation
of America AIV Division,
6600 Orangethorpe Ave., Buena Park,
CA 90620.
Les declarations precedentes concement EXCLUSIVEMENT les appareils
commercialises par YamahaCorporation
of Americaou ses filiales.
DECLARATION SURLES INFORMATIONS DE CONFORMITE
(PROCEDURE DE DECLARATION DE CONFORMITE)
Partie responsable Yamaha Corporation of America AN Division Yamaha Canada Music Ltd.
Addresse
6600 Orangethorpe Avenue 135 Milner Avenue, Toronto, Ontario,
Buena Park, CA 90620, USA MIS 3R1, Canada
Telephone
1-714-522-9011 1-416-298-1311
Type d'equipement
Adapteur de reseau sans- fi1
Nom de modele
YWA-10
• Cet appareil est conforme aIa Partie 15 du Reglement FCC et au RSS-Gen du Reglement IC.
•
Le fonctionnement est soumis aux deux co nditions suivantes: I) Cet appareil ne peut pas causer d'interference s nuisibles et 2) Cet appareil doit
recevoir toutes les interferences, y
compris celles pouvant entralner des problemes de fonctionnement.
Consultez
le mode d'emploi si vous soupc;o nne z que Ia reception ra dio subit des interferences.
AVERTISSEMENT FCC
Tout changement apporte sans !'approbation exp resse du fabricant pourrait entrainer l'annulation du droit d'utili sation de l' a pp areil.
REMARQUE
Cet appareil a ete teste et il s'est avere etre conforme a ux limites determinees pour un appareil numerique deClasse B, conformement aIa partie 15 du
Reglement FCC. Ces limites sontdestinees aoffrir une protection raisonnable contre les interferences nuisibles pouv a nt survenir en cas d'utilisation de
ce produit dans un environnement domestique.
Cet appareil produit, utilise et peut emettre de l'energie radioelectrique et , s'il n'est pas installe conformement aux instructions, peut provoquer des
interferences radio. II n'est toutef ois pas gara nti qu'aucune interf ere nce ne se produir a dans le cas d'une installation donnee. Si l'appar eil provoque des
interferences nu isibles aIa reception de programmes radio ou de television, ce qui peut etre determine en eteignant, puis en allumant I' appareil,
l'utilisateur est prie
de tenter de corriger le probleme en pr en an t l'une ou plusieurs d es mesures suivantes:
-Reorient
er ou deplacer l' antenne receptrice.
-Eloigner davantage rappareil
du recepteur.
-Raccorder
l'appareil a une prise d'un circuit different de celui du recepteur.
-Consulter le revendeur ou un technicien radio/tele experime nt e.
Cet appareil est conforme aux limites FCC!IC d'exposition aux ra yonnements detinies pour les appareils non commandes et satisfait aux dire ctives
d'exposition
aux frequences radio (RF) FCC de I' Ann exe C des reglements OET65 et RSS-102 d'exposition aux frequences radio (RF) IC. Cet appareil
possede des niveaux d'energie
RF tres bas, consideres conformes aux taux d'exposition maximum autorises (MPE) non controles. Mais il est toutefois
preferable d'installer
et d'utiliser 1'appareil en conservant une distance minimum de 20 em entre 1' emetteur et toute per s onne (sauf les extremites:
mains, poignets, pieds
et chevilles).
Ce eme tt eu r ne peut pas etre place aproximite de ou utilise conjointement avec tout autre emetteur ou antenne.
Garantie Canadienne
Votre produit Yamaha est couvert par une garantie limitee de un an a compter de la date d'achat. Dans le cas improbable d'un echec du aux materiaux
ou a !' executi on defectueux, Yamaha les reparera ou l es rempla c era gratuit.
Veuillez visiter notre site Web pour les details complets (http://www.yamaha.ca/)
5300-00004879- 01W
