Hand push type double brush head sweeper is a new generation
of environmental sanitation and cleaning appliances.
This machine is exquisite in design and unique in technology. It
doesn't need any mechanical and electrical power. It can be pushed
and walked.
Garbage can be easily recycled to the dustbin. The front and rear
brushes can be adjusted at any time according to the ground and
garbage conditions.It can achieve the lowest reactive power loss
and the best cleaning effect. The armrest adopts movable adjustable
design, which can adapt to users of different height requirements,
and can be folded upright storage, saving space, convenient storage
and transportation. Container handling .It is convenient and tightly
sealed, and can hold acid, alkali, salt, oil dirt and other corrosive
garbage. The main parts are engineering plastic manufacturing,
anti-corrosion, anti-aging, no deformation, rotating parts of the
closed precision bearings, so that the whole machine transport
Flexible and labor-saving. This machine is novel in shape, easy
to use, green and environmental protection, energy-saving and
efficient, cleaning efficiency.It is 4-6 times as much as the traditional
manual broom, especially suitable for street, community, park,
courtyard, school, workshop, etc.It is not suitable to use power
driven cleaning equipment in warehouses and large-scale activity
venues.
Yangzi yz-s1 hand push sweeper conforms to the national
development policy of "energy saving and environmental
protection" and conforms to the global trend.The historical trend
of low-carbon economy makes the cumbersome cleaning work
simple and time-saving.

3
Operating instructions
Product features
Operation precautions
1. The operator should use the sweeper under the normal operation state, and should
consider the surrounding environment when operating; be careful to touch
To people or things, special attention should be paid to the safety of children.
2. Adjust the best height of the front and rear brushes to the ground according to the
situation of cleaning the ground garbage. The brush is too high off the ground
If the cleaning effect is not enough, the brush wear will be increased and the
propulsion resistance will be increased. The adjustment handle of the armrest should
be loose
It should be tightened properly, and do not twist too much to prevent bolt damage.
3. The maintenance of the sweeper should be done by personnel with professional
knowledge, using the spare parts provided by the manufacturer.In order to ensure
that the sweeper has no fault operation.
1. No energy needed--It is easy to recycle garbage to the dustbin without energy.
2. green environmental protection- to adapt to any silent, pollution-free places.
3. The efficiency of sweeping is 4-6 times of that of manual broom. Durable, the
whole machine is made of engineering plastics Made, anti-corrosion, anti-aging, no
deformation.
4. It is convenient to store and transport. One handle is convenient to carry. It can be
stored upright to save space.
1. Before unpacking, please inform the seller of any shipping damage.
2. Before working, please read the operation instructions carefully and check whether
the sweeper works normally.
3. The machine is not suitable for cleaning substances harmful to health. It is strictly
forbidden to use this machine to clean burning or burning substances.
4.It is strictly forbidden to operate the machine with single wheel touching the ground
to avoid damaging the performance of the whole machine.
5. Wear gloves when moving glass, metal or other parts in dustbin.

4
YZ-S1
Instruction Manual Instruction Manual

5

6
YZ-S1
Instruction Manual Instruction Manual

7

8
YZ-S1
Instruction Manual Instruction Manual

9
Instruction Manual
YZ-S1
SERIAL NUMBER ENTRY NAME COMPANY PARAMETER
1Maximum sweeping
width mm 920
2 Maximum efficiency ㎡ /h 3860
3 Walking motor W None
4 Roller brush motor W None
5 Battery capacity V/AH None
6 Side brush motor W None
7Side brush width mm 2*350mm
8Maximum walking
speed Km/h 0-8
9 Bin volume L 55
10 Net weight kg 27.5
11 size mm 890*810*1035

10
YZ-S1
Instruction Manual Instruction Manual
Common problems and Solutions
Problem reason Treatment
Large leaves or large garbage
particles are leaked during
sweeping
Working too fast Reduce the working speed
Brush height Adjust brush height
The bristles are deformed or
entangled with filaments Remove the entanglement
The sweeper leaves dust on
the floor or dust from the
side shields
Filter clogged Clean the filter
Skin damage Check the baffle and replace
it if damaged
Cleaning is not thorough,
leaving paper scraps, leaves
or other garbage
The lifting height of front
bumper is not correct Adjust the skin guard link
The brush wears too fast The brush is pressed too
low Adjust brush height
Too much noise at work
The bristles are entangled
with filaments Remove the entanglement
The bearing is broken Replace the bearing
Brush overpressure Reduce brush pressure
The brush does not rotate
when it works The drive belt is damaged Replace the belt
Brush and fan motor do not
work Motor damage Replace the motor
The electric dust shaker
does not work
Excessive motor load Check and reduce the load
The switch is broken Replace the fuse
The fuse is burnt out Check and reduce the load
Motor damage Replace the motor
Bearing wear Replace the bearing
The brush can work
normally and cannot run
normally
Problems of controller, fuse,
drive motor, governor and
brake switch
Check the input and output
voltage, alarm signal,
indicator light, fuse, drive
motor and connecting
circuit.

11
The car can't move forward
or backward
Pedal governor damaged Replace the governor
Brake pedal position fault
Reset the brake pedal
and check if it is in good
condition
Brake switch failure Replace the brake switch
Controller damage Replace the controller
The battery doesn't charge
Charger does not work Check the charger input
power
The battery is burnt out Replace the battery
Charger Check whether there is
output of charger
Loose battery terminals Check and tighten the
battery terminals
Battery discharging too fast
Insufficient charging time Increase charging time
The battery is burnt out Replace the battery
Charger damaged Replace charger

Instruction Manual
Warranty Card
Inspection Certificate
Model Motor Accessories
Power cable Switch Shell
Suction Control Fuselage
Function Manual Package
Number：
Number：
Name Tell
Mailing address
Purchase time Bill
number
Product number Fuselage
number
Replacement
parts Date
Fault description:
Warranty conditions:
1. Within the date of purchase, the motor is guaranteed for one year (if it is more than 7 days from the date of
purchase, no replacement, only warranty).
2. Before using the equipment, you must understand the instructions and safety instructions.
3. During the warranty period, the artificial damage of warranty accessories will not be guaranteed.
4. During the warranty period, users who do not follow the operation instructions or dismantle and repair by
themselves will not be guaranteed. (if repair is needed, the cost of production will be charged)
5. The buyer shall take the invoice to the place designated by the seller for repair, or send the machine back to our
company for repair. (return freight, insurance paid by yourself)
