Yard force LP C04A User manual

READ & UNDERSTAND
INSTRUCTION MANUAL
Save all warnings and instructions for future reference.
LP C04A
24V CORDLESS SPRAYER
Original Instructions
Hotline: [phone]
Monday/Friday: 9.00am to 4.30pm
Saturday: 9.00am to 3.00pm
Email: [email protected]

2
Read this manual carefully prior to assembling and
operating the sprayer. It is dangerous to operate this product
without being familiar with these instructions.
Keep this manual in a safe place and have it ready for
future reference.

3
a
b c
B
A
de

4
C
E
G
I
K
J
D
F
H
Extend
L

5
LP C04AOriginal instructions
CONTENT
Intended use
General safety warning
Symbols
Technical specications
Parts description
Package content
Assembly
Operation
Cleaning, maintenance and storage
Troubleshooting
Warranty
5
6~14
15~16
17
17
18
19
19~20
21
22
23

6
INTENDED USE
This sprayer is designed for spraying home and garden chemicals, such as insecticides,
fertilizers and weed killers etc. It is designed for domestic use only. It is not designed for
commercial or trade use.
GENERAL SAFETY WARNINGS
IMPORTANT! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to following
the warnings and instructions may result in an
electric shock, re and/or serious injury.
Save all warnings and instructions for future
reference!
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
5.1 Work area safety
a). Keep work area clean and well lit. Cluttered or dark
areas can cause accidents.
b). Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c). Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
5.2Electrical safety
a). Power tool plugs must match the outlet. Never

7
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce
risk of electric shock.
b). Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c). Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
d). Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.
e). When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
f). If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
5.3 Personal safety
a). Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under inuence of drugs, alcohol or medication. A
moment of inattentionwhile operating power tools may
GENERAL SAFETY WARNINGS

8
result in serious personal injury.
b). Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c). Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on the
switch or energising power tools that have the switch
on invites accidents.
d). Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
in personal injury.
e). Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
f). Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g). If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
h). Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
GENERAL SAFETY WARNINGS

9
GENERAL SAFETY WARNINGS
severe injury within a fraction of a second.
5.4 Power tool use and care
a). Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b). Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
c). Disconnect the plug from the power source and/
or the battery pack from the power tool before
making any adjustments, changing accessories,
or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool
accidentally.
d). Store idle power tools out of reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power. Power
tools are dangerous in the hands of untrained users.
e). Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tools operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
f). Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.

10
GENERAL SAFETY WARNINGS
g). Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the works
to be performed. Use the power tool for operations
different from those intended could result in hazardous
situations.
h). Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handle and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
i). Hold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wire. Fasteners contacting
a "live" wire may make exposed metal parts of the
power tool "live" and could give an electric shock.
5.5 Battery tool use and care
a). Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used
with another battery pack.
b). Use power tools only with specically designated
battery packs. Use of any other battery packs may
create a risk of injury and re.
c). When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a re.

11
d). Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
e). Do not use a battery pad or tool that is damaged or
modied. Damage or modied batteries may exhibit
unpredictable behaviour resulting in re, explosion or
risk of injury. General power tool safety warnings
f). Do not expose a battery pack or tool to re
or excessive temperature. Exposure to re or
temperature above 130°C may cause explosion.
g). Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specied in the instructions. Charging
improperly or at temperature outside the specied
range may damage the battery and increase the risk of
re.
5.6 Service
a). Have your power tool serviced by a qualied repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
b). Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorised service providers.
5.7 Battery
a). Never attempt to open the battery pack for any
PRODUCT SAFETY WARNINGS

12
reason.
b). Use the charger provided to charge the Xnity
battery packs.
c). Do not short circuit the battery, short circuited
battery pack may lead to re.
d). Do not store in locations where the temperature
exceeds 45°C.
e). Do not expose the battery pack to re.
f). Under extreme conditions, battery leakage may
occur. When you notice liquid on the battery, proceed
as follow:
• Carefully wipe the liquid off using a cloth. Avoid
skin contact.
• In case of skin or eye contact, immediately rinse
with water.
• Neutralise with a mid acid such as lemon juice or
vinegar.
• In case of eye contact, rinse abundantly with
clean water for at lease 10 minutes. Consult a
physician.
5.8 Battery charger
a). This battery charger is not intended for use
by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been
given supervision or instruction concerning the use
of the appliance by a person responsible for their
safety.
b). Children should be supervised to ensure that they
do not play with this battery charger.
PRODUCT SAFETY WARNINGS

13
c). Use the battery charger only to charge the Xnity
battery packs. Other batteries could burst, causing
personal injury and damage.
d). Never attempt to charge non-rechargeable
batteries.
e). The battery charger is for indoor use only.
5.9 Safety rules for cordless sprayer
a). Keep the working area well ventilated.
b). Do not work on windy days. Chemicals can be
accidentally blown onto plants or objects that should
not be sprayed.
c). Keep the tool and its handle clean, dry and free
from oil or grease. Always use the clean cloth when
cleaning. Never use brake uids, gasoline, or any
strong solvents to clean your tool. Following this rule
will reduce the risk of loss of control and deterioration
of the enclosure plastic.
d). Do not smoke while using the tool, or work where
spark or ame is present.
e). Do not use commercial grade chemicals or chemicals
for commercial or industrial purposes.
f). Use only consumer grade water-based lawn and
garden chemicals.
5.10 Residual risks
Additional residual risks may arise when using the
tool which may not be included in the enclosed
safety warnings. These risks can arise from misuse,
prolonged use etc.
PRODUCT SAFETY WARNINGS

14
Even with the application of the relevant safety
regulations and the implementation of safety devices,
certain residual risks cannot be avoided. These
included:
a). Injuries caused by touching any rotating/moving parts.
b). Injuries caused when changing any parts, blades or
accessories.
c). Injuries caused by prolonged use of a tool. When
using any tool for prolonged periods ensure you take
regular breaks.
d). Impairment of hearing.
e). Health hazards caused by breathing dust developed
when using your tool (e.g. working with wood,
especially oak, beech and MDF).
PRODUCT SAFETY WARNINGS

15
SYMBOLS
The following symbols are used in this instruction
manual and/or on the sprayer to attach your attention to
possible risks. These symbols and the explanations that
accompany them must be understood.
WARNING! OR CAUTION!
READ the instruction manual before using
this shredder
WARNING! Never direct adjustable nozzle at
people, animals, the unit or any other electric
components
Wear eye and ear protection
Do not expose to rain
Sound power level
Dispose of electrical appliances according to
the regulation and requirement of your local
council.
Australian regulatory compliance mark
96

16
SYMBOLS
Do not throw into water
Do not incinerate battery
Max. ambient temperature 45°C
Dispose of battery according to the regulation
and requirement of your local council
For indoor use only
Class II double insulated
Fuse link
Centre (tip) of output plug is Positive (+) and
the barrel of the output plug is Negative (-)
Li-Ion
T3.15A

17
TECHNICAL DATA
Sprayer:
Model LP C04A
Rated voltage 24Vd.c.
Max. spray pressure0.5 MPa
Max. ow rate 500 cc/min
Tank capacity 4 L
Battery:
Model
24VBAT-LTE
Rated output voltage 24Vd.c.
Capacity 2.0Ah
Charger:
Model XZ2600-2100KS
Rated input voltage 220-240V~ 50/60Hz
Rated input power 100 W
Rated output voltage 24Vd.c.
Rated output current 2A
PARTS DESCRIPTION
Parts description (Fig. A)
1. Adjustable nozzle
2. Telescopic extension
3. Telescopic extension nut
4. Spray wand
5. Spray trigger
6. Spray wand handle
7. Hose connector
8. Hose
9. Battery compartment
10. Sprayer
11. Tank latch
12. Tank
13. Tank hose connector
14. Measuring cup
15. On/off switch
16. Handle and spray wand holder
17. Battery
18. Charger

18
PACKAGE CONTENTS
Fig. B
A. 1 x Sprayer
B. 1 x Instruction manual
C. 1 x Battery
D. 1 x Charger
E. 1 x Shoulder tray
• Remove all packing material.
• Check the completeness of the package content.
• Check the shredder and its accessories for transport damages.
WARNING! Danger of suffocating! Packing materials are not toys! Children must
not play with plastic bags!
WARNING! If any parts are damaged or missing, do not operate this shredder until
the missing parts are replaced.
IF ANY PARTS ARE MISSING OR DAMAGED, PLEASE CONTACT ACTION SPARES
1300 418 640.
Recycle/dispose of packaging materials in accordance to the regulations and
requirements of your local council.

19
ASSEMBLY
Attaching the hose to the spray wand handle (Fig. C and D)
The hose is preassembled to the spray wand handle and sprayer. If the hose becomes loose,
it should be re-connected securely again.
a). Push one end of the hose into the spray wand handle.
b). Connect the nut by rotating clockwise.
c). Connect the opposite end of the hose to the sprayer.
Attaching the shoulder strap
a). Clip the ends of the shoulder strap to the mounting points on both ends of the sprayer.
b). To use the shoulder strap, simply slide the strap over your shoulder.
Charging the battery (Fig. E)
WARNING! Remove the battery from the charger after it is fully charged.
WARNING! The battery has been shipped in a low charge condition, it should
be fully charged before rst use.
a) Connect the charger to the mains. The green power indicator light on the charger will be
on when connected.
b) Insert the battery into the charger until it is locked in place. The charging indicator light
on the charger will be red.
c) It takes about 90 minutes to fully charge the battery. The charging indicator light on the
charger will be green.
d) The battery has three LED power level indicators to show the state of the battery charge.
Press the button on the right of the LED power level indicators to see the power level.
• One LED light on - low state of charge, requires charging soon.
• Two LED lights on - middle state of charge
• Three LED lights on - fully charged
Inserting and removing the battery
WARNING: Before inserting or removing the battery from the sprayer, make sure
the sprayer is switched off.
a) To insert the battery, align the battery with the sprayer's battery compartment and slide
OPERATION

20
the battery in so that it clicks into place.
a) To remove the battery, press and hold the release tab and slide the battery out.
Switching on and off (Fig. H)
a) To switch the sprayer on, press the ON/OFF switch to position "I" (ON). The red light on
the ON/OFF switch will be on.
b) To switch the sprayer off, press the ON/OFF switch to position "O" (OFF). The red light
on the ON/OFF switch will be off.
c) After the sprayer is switched on, the sprayer is in standby mode. Press the spray trigger
to start spraying. Slide the spray trigger to lock down the spray trigger for continuous
spraying.
d) Slide back the spray trigger to unlock for normal operation.
Filling the tank (Fig. I)
WARNING! Always follow the chemical manufacturer's instruction for use,
cleaning and storage of the chemical. Clean thoroughly after each use. The
chemicals should be stored out or the reach of children. Failure to do so may
result in serious personal injury.
WARNING! Remove the battery prior adding liquid to the tank.
a) Use your measuring cup for your concentration.
b) Fill the tank with proper amount of water.
c) Measure the recommended amount of chemical with the measuring cup.
d) Carefully pour in the chemicals then ret the cup, make sure that it is tightened securely.
Extending the spray wand (Fig. J)
a) Loosen the telescopic extension nut.
b) Pull the telescopic extension out to the desired length and rotate the telescopic
extension to the desired direction.
c) Retighten the telescopic extension nut.
Adjusting spray patten (Fig. K)
a) The spray can be adjusted from a jet stream to a fan spray by rotating the adjustable
nozzle.
Spraying tips
WARNING! Always wear ear protection, protective mask, protective gloves and
footwear when spraying.
b) Never point the nozzle to people or animals.
c) Spray downwind.
d) Never work on windy days.
e) Never smoke, eat or drink while spraying.
OPERATION
