Yard force YF2200LC User manual

SAVE THIS MANUAL FOR REFERENCE
Our Customer Service staff is ready to provide assistance.
In the case of a damaged or missing part, most replacement parts ship from our
facility.
For immediate help with assembly, or for additional product information, visit
www.YardForceUSA.com or email [email protected]
You will need this manual for safety
instructions, operating procedures, and Warranty.
The original sales receipt is required for warranty service.
YF2200LC
Y0EWN22WR01
ELECTRIC PRESSURE WASHER
OPERATOR’S MANUAL

2
YF2200LC Original Instructions
TABLE OF CONTENTS
Important safety instructions ........................................................................................................................... 3
Safety features ................................................................................................................................................. 5
Parts and diagram list ...................................................................................................................................... 6
Technical data .................................................................................................................................................. 8
Assembly and operation instructions ............................................................................................................... 9
Machine assembly ..................................................................................................................................... 9
Operation instruction ................................................................................................................................ 13
Cleaning detergents dispenser ................................................................................................................. 14
Shutting down and storage ............................................................................................................................ 16
Cleaning and maintenance ............................................................................................................................. 17
Troubleshooting ..............................................................................................................................................18
Warranty ......................................................................................................................................................... 20

3
IMPORTANT SAFETY INSTRUCTIONS
Please read all of the safety precautions before operating this machine every time. Please pay particular
attention to all sections with following symbols.
WARNING
Could cause injury or death if not followed.
CAUTION
Could damage machine if not followed.
WARNING
When using this product, basic precautions should always be followed, including:
1. Read all instructions before using the product.
2. To reduce the risk of injury, do not operate the machine near children.
3. Learn how to stop this product and release pressure quickly. Be thoroughly familiar with the controls.
4. Stay alert - watch what you are doing.
5. Do not operate this product when fatigued or under the inuence of alcohol or drugs.
6. Keep operating area clear of all people and pets.
7. Do not stand on unstable surfaces. Do not overreach or stand on unstable support. Keep good footing
and balance at all times.
8. Follow the maintenance instructions specied in the manual.
9. If replacement of the plug or cord is needed, use only identical replacement parts.
10. This product or its power cord contains lead, a chemical known to cause cancer, birth defects or other
reproductive harm. Wash hands after handling.
WARNING
Risk of injury Injection Hazard.
• Equipment can cause serious injury if the spray penetrates the skin.
• Do not point the gun at anyone or any part of the body. In case of penetration, seek medical
aid immediately.
WARNING
Risk of injury
DO NOT direct discharge stream at self or other persons.
• High-pressure jet can be dangerous if misused.
• The jet must not be directed at persons, animals, electrical devices, or the unit itself.
WARNING
Risk of Explosion - Do not spray ammable liquids
• Do not use acids, alkaline, solvents or any ammable material in this product. These products
can cause physical injuries to the operator and irreversible damage to the machine.
WARNING
Risk of Electric Shock
• Inspect cord before using - do not use if cord is damaged.
• Keep all connections dry and off the ground.
• Do not touch plug with wet hands.

4
CAUTION
Gun Kick Back
• Hold with both hands.
• The trigger gun safety lock prevents the trigger from being engaged accidentally.
• The safety feature DOES NOT lock trigger in the ON position.
GENERAL SAFETY RULES
1. Never operate the machine without all components properly connected to the machine (handle, gun/
wand assembly, nozzle, etc.).
2. Never operate pressure washer with broken or missing parts. Check equipment regularly and repair or
replace worn or damaged parts immediately.
3. Never put hand or ngers over the nozzle or spray tip while operating the unit.
4. Never spray ammable liquids or use pressure washer in areas containing combustible dust, liquids or
vapors. An electric spark could cause an explosion.
5. Never leave the wand unattended while the machine is running or switched on.
6. Never disconnect the high pressure discharge hose from the machine while the system is pressurized.
To depressurize machine, turn power and water supply off, then depress gun trigger 2-3 times.
7. Never cover the pressure washer during operation to allow free air cooling.
8. Always wear safety glasses or goggles when operating or performing maintenance.
9. Always move switch on unit to “OFF” (O) position before connecting or disconnecting cord to electrical
outlets.
10. Always turn water supply “on” before turning pressure washer “on” unless draining for storage. Running
pump dry causes serious damage.
11. Always hold gun and wand rmly when starting and operating the machine.
12. Always follow detergent manufacturer’s label recommendations for proper use of detergents. Always
protect eyes, skin and respiratory system from detergent if used.
13. Always lock the trigger of spray gun in the safety position when not in use.
14. Do not use pressure that exceeds the operating pressure of any of the parts (hoses, ttings, etc.) in the
pressurized system. Never use with any other manufacturer’s accessories or components.
15. Do not spray electrical apparatus and wiring or the machine itself.
16. Do not operate the pressure washer with the inlet water lter screen removed. Keep lter clear of debris
and sediment.
17. Discharge residual pressure by depressing the trigger until no more water comes out of the nozzle.
18. Keep clear of nozzle. Never direct high pressure spray at any person, animal or self.
19. To minimize the amount of water getting into the pressure washer, the unit should be placed as far as
possible from the cleaning site during operation.
GROUND FAULT CIRCUIT INTERRUPTER PROTECTION
This device provides additional protection from the risk of electrical shock. Plug the Ground Fault Circuit
Interrupter (GFCI) into a power outlet. Indicator should turn red. TEST BEFORE EACH USE. Press the
“TEST” button. Red indicator should disappear. Press “RESET” button again for use. Do not use if above
test fails.
GROUNDING INSTRUCTIONS
This product must be grounded. If it should malfunction or breakdown, grounding provides a path of at
least resistance for electric current to reduce the risk of electric shock. This product is equipped with a
cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
IMPORTANT SAFETY INSTRUCTIONS

5
IMPORTANT SAFETY INSTRUCTIONS
TOTAL STOP SYSTEM (TSS)
The pressure washer is equipped with a total stop system (TSS) that will sense when the trigger on the gun
is depressed or released. It will open the power circuit to the motor, and cause the pressure washer motor
to stop. The motor will start again when the trigger is depressed.
WARNING
The pressure washer is also equipped with a main power “ON/OFF” (I/O) switch located on
the unit. It should always be moved to the “OFF” (O) position when the pressure washer is
not being used to prevent possible injury or damage.
EXTENSION CORDS
If possible, do not use extension cords with this product. However, if you must use one, observe all of the
warnings and instructions listed below:
Use a sufcient gauge:
Maximum extension cord length: 50’ (15.2 m). Only use 12 or 14 AWG rated extension cords.
• Use only extension cords that are intended for outdoor use. These extension cords are identied by a
marking that reads “Acceptable for use with outdoor appliances; store indoors while not in use.”
• Use only extension cords having an electrical rating not less than the rating of the product.
• Do not use damaged extension cords. Examine extension cord before using and replace if damaged.
Do not abuse extension cord and do not yank on any cord to disconnect.
• Keep cord away from heat and sharp edges.
• Always disconnect the extension cord from the receptacle before disconnecting the product from the
extension cord.
• To reduce the risk of electric shock, keep all connections dry and off the ground. Do not touch plug with
wet hands.
CAUTION
This machine has been designed for use with detergents that are specically approved for
pressure washer use. The use of other cleaning detergents may affect the operation of the
machine and void the warranty.
DANGER – Improper connection of the equipment –grounding conductor can result in a risk of
electrocution. Check with qualied electrician or service personal if you are in doubt as to whether
the outlet is properly grounded. Do not modify the plug provided with the product – if it will t the
outlet, have a proper outlet installed by a qualied electrician. Do not use any type of adaptor with
this product.
SAFETY FEATURES

6
PARTS AND DIAGRAM LIST
PARTS AND DIAGRAM LIST
Fig. 1

7
Check contents of the box
As shown in Fig. 1
Carefully remove the pressure washer and parts from its packaging. Identify all the parts packaged in the
carton against the parts list. Please contact Yard Force customer service center (Monday - Friday 8:30AM
- 5:00PM ET) at 1-[phone] if anything is missing.
1. Power cord with GFCI x1
2. Detergent tank x1
3. Wheel x2
4. Axle Bolt x2
5. Cotter pin x2
6. Pressure washer main unit x1
7. Storage bucket x1
8. Center Handle x1
9. High pressure hose x1
10. Gun holder x1
11. Upper Handle x1
12. Spray gun x1
13. Spray wand x1
14. Turbo nozzle x1
15. 15 º nozzle x1
16. 25 º nozzle x1
17. 40 º nozzle x1
18. Soap nozzle x1
19. Nozzle Cleaning Needle (Packed together with the manual) x1
20. Operating manual x1
WARNING: If any parts are damaged or missing, do not operate this tool until the missing
parts are replaced. Failure to heed this warning could result in serious personal injury.
NOTE! Always recycle the packaging in accordance with local recycling codes.
PARTS AND DIAGRAM LIST

8
PARTS AND DIAGRAM LIST
Model Y0EWN22WR01
Input voltage rating 120V AC
Rated Power 13 A
Working pressure 2200 PSI
Max pressure 2500 PSI
Rated Flow rate 1.20 GPM (272.5LPH)
Max. Flow rate 1.35 GPM (306 LPH)
Inlet pressure ≥20 PSI
Supply water temperature (max.) Cold tap water 104 °F (40 °C)
Electrical cord 35 ft. (10.7 m)
High-pressure hose 25 ft. (7.6 m)
Detergent injection rate 3%~12%
TECHNICAL DATA

9
Surface Preparation
Before starting any cleaning project, it is important to inspect the area for objects that could create a haz-
ard. Remove any objects from the work area that could be tripped over, such as toys or outdoor furniture.
Ensure that all doors and windows are closed tightly.
Water Supply (Cold Water Only)
Only draw water through the unit. For use with cold water supply only. Garden hose must be at least a 1/2”
(13 mm) in diameter. Flow rate of water supply must not fall below 2 GPM (gallons per minute). Flow rate
can be determined by running the water for one minute into an empty 5-gallon container. The water supply
temperature must not exceed 104°F (40°C).
CAUTION
• Never use the pressure washer to draw in water contaminated with solvents (e.g. paint thin-
ners, gasoline, oil, etc.).
• Dirt in the water inlet will damage the unit. To avoid this risk, we recommend checking the wa-
ter lter (located inside the water inlet. To clean it out, see Maintenance section).
• Always prevent debris from being drawn into the unit by using a clean water source and an
additional accessory water lter if required.
• To prolong the life of the unit, rest the unit for 5 minutes after every 30 minutes of use.
MACHINE ASSEMBLY
Your Yard Force pressure washer will need to be assembled before operation (tools not required):
1. Install the wheels. (Fig. 2)
The short axle (A) is rst passed through the wheel (W) and then attach to the shaft under the frame of the
machine. Then insert a cotter pin (P) through the hole in the shaft to secure. Repeat that for the second
wheel.
ASSEMBLY AND OPERATION INSTRUCTIONS
Fig. 2

10
2. Attach storage bucket. (Fig. 3)
Attach the storage bucket onto pressure washer main unit by sliding open slot over tab.
ASSEMBLY AND OPERATION INSTRUCTIONS
Fig. 3
3. Assemble middle handle. (Fig. 4)
Push and hold the push-pin buttons on the sides of the middle handle as sliding the middle handle onto the
frame.
4. Assemble upper handle. (Fig. 5)
Push and hold the push-pin buttons on the upper sides of the middle handle as sliding the upper handle
onto the middle handle.
Fig. 4 Fig. 5
5. Assemble gun holder. (Fig. 6)
Assemble the gun holder onto pressure washer.
6. Assemble the nozzle cleaning needle. (Fig. 7)
Take out the nozzle cleaning needle and put into the slot on the base of the bucket.
Fig. 6 Fig. 7

11
7. Insert the turbo nozzle. (Fig. 8)
Put the turbo nozzle into the nozzle holder together with the gun holder.
8. Connect high-pressure hose to pressure washer main unit. (Fig. 9)
Tighten the high-pressure hose to the water outlet of the pressure washer main unit.
ASSEMBLY AND OPERATION INSTRUCTIONS
Fig. 8 Fig. 9
9. Connect the high-pressure hose to spray gun. (Fig. 10)
Roll down the high pressure hose and then tighten to the spray gun.
10. Connect spray wand to spray gun and attach the nozzles. (Fig. 11)
Connect the spray wand to the spray gun, and then attach the nozzles you wanted.
Fig. 10 Fig. 11
CAUTION
Placing any spray tip too close to a surface can result in permanent damage to the
surface being sprayed. Maintain at least a 24” distance between the tip and the surface being
sprayed until you have determined it is safe to move the tip closer to the surface.
11. Connect garden hose (Fig. 12)
Attach the garden hose to water inlet of the pressure washer, tighten by hand.
12. Connect to water supply (Fig. 13)
Attach garden hose to water supply and turn water valve on to the fall on position.
CAUTION! The water temperature must not exceed 104oF and the supply pressure must be
between 40 to 80 PSI.

12
ASSEMBLY AND OPERATION INSTRUCTIONS
CAUTION
The pressure washer must only be used with clean water. Use of unltered water or corrosive
chemicals will damage the pressure washer.
This pressure washer is not intended to pump hot water. Never connect it to a hot water
supply as it will signicantly reduce the life of the pump.
Fig. 14 Fig. 15
13. OFF position (Fig. 14)
Make sure the ON/OFF switch is on the OFF position before plugging in the unit, press the switch button
with mark “O” to ensure it is off.
14. Connect to power socket (Fig. 15)
Insert the plug into the power socket.
WARNING
The pressure washer is equipped with a main power “ON/OFF” (I/O) switch located on the
unit. It should always be moved to the “OFF” (O) position when the pressure washer is not
being used to prevent possible injury or damage.
Ground Fault Circuit Interrupter Protection
This device provides additional protection from the risk of electrical shock. Plug the Ground Fault Circuit
Interrupter (GFCI) into a power outlet. Indicator should turn red. TEST BEFORE EACH USE. Press the
“TEST” button. Red indicator should disappear. Press “RESET” button again for use. Do not use if above
test fails.
Fig. 12 Fig. 13

13
OPERATION INSTRUCTIONS
WARNING
Risk of injury, Do Not Direct discharge stream at self or other persons.
WARNING
Before cleaning any surface, an inconspicuous area should be cleaned to test spray pattern
and distance for maximum cleaning results.
ASSEMBLY AND OPERATION INSTRUCTIONS
Fig. 16
1.Turn ON the pressure washer by pressing the button with mark “ I ”. The unit will run for a few seconds to
build up pressure, then will stop on the function of total stop system (TSS). (Fig. 16)
2.Release the trigger lock and squeeze the gun trigger until there is a steady stream of water. Change the
spray tip as per the recommendation above if necessary. Before changing spray tip, switch the machine
OFF, depress trigger to release pressure and engage the trigger lock. (Fig. 17)
CAUTION
Make sure spray tip and wand is well locked. Do not remove the spray tip while trigger is
depressed.
CAUTION
If painted surfaces are peeling or chipping, use extreme caution as pressure washer may
remove the loose paint from the surface.
For most cleaning applications, a twenty-ve degree (25) spray angle is recommended to
avoid damage to the surface being sprayed.
The pressure of spray on the surface will increase when you move the wand closer to the
surface.
Fig. 17
Fig. 18

14
ASSEMBLY AND OPERATION INSTRUCTIONS
3. Turn off the pressure washer by pressing the switch button with mark “ O ”, activate the safety latch for
a break. For storage, drain machine after use by removing water connection, turning ON the machine for 3
seconds and depressing gun trigger to release remaining water in the pump. Turn OFF immediately. (Fig. 18)
CLEANING DETERGENTS DISPENSER
Only use cleaning detergents recommended for pressure washers.
Always follow detergent manufacturer’s label recommendations for proper use of detergents or soap. Al-
ways protect eyes, skin and respiratory system from detergent if used.
CAUTION
Working with detergent ensures a quick soaking of the dirt, and allows the high-pressure water to
penetrate and remove the dirt more effectively.
To apply detergents, you must be operating at low pressure. This provides a gentle application of
detergent, with the pressure equivalent to the lowest garden hose. The high-pressure setting is
used for cleaning, you cannot apply detergents when working at high pressure.
Always test detergent in an inconspicuous area before use.
NO BLEACH!
1. Engage gun safety lock.
Fig. 19 Fig. 20
2. Attach the low-pressure spray tip (black) for soap or detergent application. Detergent application will
only work with low pressure spray tip.
3. As shown Fig.20 remove the cap of detergent tank, ll tank with detergent or soap and replace the cap.
Apply detergent as instructed by the detergent manufacturer.
4. Turn on the pressure washer. Squeeze trigger to operate unit. The liquid detergent will automatically mix
with water, and be discharged through the nozzle. Apply detergent to work surface, from bottom to top.
5. Allow detergent to remain on the surface for a short time before rinsing. Do not allow detergent to dry
on surface.
6. Rinse with clean water under high pressure. On a vertical surface, rinse from the bottom up, then rinse
from the top down to avoid streaking. Hold nozzle 8-10” from the cleaning surface, at a 45° angle.

15
CAUTION
Failure to follow detergent cleaning procedure will cause the dispensing system to become
clogged.
Damage may occur to painted surfaces if a chemical is allowed to dry on surface. Wash and
rinse a small section at a time. Avoid working on hot surfaces or in direct sunlight.
Never use:
• Bleach, chlorine products and other corrosive chemicals
• Liquids containing solvents (i.e., paint thinners, gasoline, oils)
• Tri-sodium phosphate products
• Ammonia products
• Acid-based products
These chemicals will harm the unit and will damage the surface being cleaned.
ASSEMBLY AND OPERATION INSTRUCTIONS

16
SHUTTING DOWN AND STORAGE
1. (If you are not using detergent, go directly to Step 2.) When you have nished using the detergent dis-
pensing system, ll detergent tank with clean water to rinse the system clean. Squeeze the gun trigger
for one minute at low pressure so that all detergents remaining in system are thoroughly ushed out.
Remove detergent tank to empty the remaining water, and rinse it until it is thoroughly cleaned.
2. Turn off water supply and disconnect the garden hose from the faucet and the water inlet on the unit.
3. Squeeze the gun trigger for a few seconds to release any remaining water until water spray stops, turn
off unit immediately.
4. Unplug power cord from the power outlet and wrap it.
5. Disconnect the high-pressure hose from the gun wand and wrap it.
6. Engage gun trigger lock and disconnect the quick-connect wand from trigger handle, disassemble and
replace the spray tip to tip holder on the unit, insert the wand into the wand holder.
7. Store the machine and accessories in a room that does not reach freezing temperatures. Do not store
near furnace or other sources of heat as it may dry out the pump seals.
WARNING
Turn off water supply and squeeze trigger to depressurize the unit. Failure to do so could
result in personal injury due to discharge of high-pressure water.
Optimum Winterizing Procedure
Winterizing your pressure washer will help protect and prolong its life. We strongly recommend you follow
the below steps using *Pressure Washer Pump Saver.
This will keep the internal parts lubricated, protected from rust, and prevents the pump from freezing.
8. Connect Pressure Washer Pump Saver hose onto the water inlet.
9. Depress button on top of pump saver container.
10. Continue until uid exits the high-pressure hose for 15 seconds.
11. Remove the hose from pump inlet (water inlet).
*Pressure Washer Pump Saver not included.
Fig. 21

17
Water Filter Screen
The pressure washer is equipped with a water inlet lter screen to protect the pump. If the screen is not
kept clean, the ow of water to the pressure washer will be restricted and the pump may be damaged.
1. To clean inner water screen, remove the inlet adaptor and remove the lter screen from the pump inlet.
2. Rinse screen until it is free of debris and blockage.
3. Replace screen immediately to prevent any foreign matter from entering the pump.
CLEANING AND MAINTENANCE
Fig. 22
A clogged water lter screen can cause excessive pressure to build-up in the pressure washer’s pump. The
wand’s water lter screen should be cleaned regularly to avoid damaging the wand or pump. For new pur-
chase please call at 1-[phone].
4. Using needle-nose pliers, carefully take the water lter screen out of the wand.
5. Clean the water lter screen by carefully inserting the water lter cleaning tool provided or a thin and
sharp instrument (e.g. paperclip) into the lter to remove any dirt deposited. Rinse with clean water.
6. Using needle-nose pliers, carefully reinsert the water lter screen into the wand. Ensure the screen ts
tightly into the wand’s water inlet opening.
Main body cleaning
Use only mild soap and damp cloth to clean the main body.
WARNING
Never use the unit to clean itself.
Connections
Connections on pressure washer hoses, gun and spray wand should be cleaned regularly and lubricated
with non-water soluble grease.
Spray Tips Only
Clogging of the spray tips causes the pump pressure to be too high and cleaning is immediately required.
Clean the spray tips by carefully inserting the needle provided into the tip to remove any dirt deposited.
WARNING
To assure product safety and reliability, repairs should be performed by authorized service
centers or other qualied service personnel, always use identical replacement parts.
Fig. 23

18
Disconnect the machine from the power source before making any repairs.
Symptom Cause Solution
Motor does not run
when “ON” ( I ), fully
connected and trigger
depressed.
On/Off switch is in the “OFF” (O)
position.
Turn switch to the “ON” ( I ) position.
Power cord is not plugged in. Plug in power cord.
Extension cord is too long. Extension
cord is not proper gauge.
Extension cord is damaged.
Replace extension cord with either a 25’
(7.6 m) 14/3 gauge cord or a 50’ (15 m)
14/3 gauge cord.
Electrical outlet does not
supply adequate power.
Try a different outlet.
Tripped pressure washer thermal
protector.
Allow to cool, and restart unit.
Unit does not reach
high pressure.
Diameter of garden hose is too small. Replace with a 1” (25 mm) or 5/8” (16 mm)
garden hose.
Water supply is restricted. Check garden hose for kinks, leaks and
blockage.
Not enough water supply. Open water source fully.
Water inlet lter is clogged. Remove lter and rinse in warm water.
Power nozzle is in low pressure
position.
Replace with desired high pressure tip.
Pump is sucking air. Check that hoses and ttings are airtight.
Turn OFF machine, and purge pump by
squeezing trigger gun until a steady ow of
water emerges through the nozzle.
Output pressure varies
high and low.
Not enough inlet water supply. Turn water on fully. Check garden hose for
kinks, leaks or blockage.
Pump is sucking air. Check that hoses and t- tings are airtight.
Turn OFF machine, and purge pump by
squeezing trigger gun until a steady ow of
water emerges through the nozzle.
Water inlet lter is clogged. Remove lter and rinse with warm water.
Discharge nozzle is obstructed. Blow out or remove debris with a ne
needle.
Calcied gun, hose or power nozzle. Run distilled vinegar through detergent
tank.
Detergent is not
working.
Detergent container is empty. Add more detergent.
Detergent bottle or suction tube not
properly connected.
Check connections.
Detergent is too thick. Dilute detergent.
Filter on detergent suction tube is
clogged.
Run warm water through lter to remove
build-up.
Damaged or clogged detergent suction
tube.
Remove obstruction or replace detergent
suction tube.
Nozzle is in high-pressure position. Use low pressure (black) tip.
Discharge nozzle is obstructed. Blow out or remove debris with a ne
needle.
Garden hose
connection leaks.
Loose ttings. Tighten ttings.
Missing / worn rubber washer. Insert new washer.
Spray wand, extension,
or nozzle leaks.
Spray nozzle not properly attached. Ensure quick-connect wand is attached
securely. Ensure spray tip is clicked in
securely.
Broken o-ring or plastic insert. Call the Toll-Free Hotline.
TROUBLE SHOOTING

19
Pump is noisy. Pump is sucking air. Check that hoses and ttings are airtight.
Turn off machine and purge pump by
squeezing trigger gun until a steady ow of
water emerges through the nozzle.
Water lter is clogged. Remove water lter and rinse in warm
water.
Water leaks from pump
(up to 10 drops per
minute is permissible).
Loose ttings. Check that all ttings are tight.
Water seals are damaged or worn. Call the Toll-Free Hot line.
Oil is dripping. Oil seals are damaged or worn. Call the Toll-Free Hot line.
Motor buzzes but fails
to run.
Supply voltage below minimum. Verify that only the pressure washer is
running on this circuit.
System has residual pressure. Turn unit OFF, squeeze trigger on spray
wand to release pressure, then turn unit
ON.
Voltage loss due to extension cord. Unplug any extension cords attached and
plug the unit directly into the outlet.
Pressure washer not used for long
periods.
Call the Toll-Free Hot line.
Residual friction among components.
Unit might hum.
Disconnect water supply and power ON
for 2 to 3 seconds, repeat couple times or
until the motor starts.
No water. Water supply is OFF. Turn ON water supply.
Kink in the garden hose. Remove kink in garden hose.
If you have any questions, visit our website for key FAQ’s, downloadable troubleshooting steps,
instructional videos, and replacement parts purchase at www. ForceToolsUSA.com, or call our toll free hot
line: 1-[phone].
TROUBLE SHOOTING

20
WARRANTY
YARD FORCE TWO YEAR LIMITED WARRANTY
Product Warranty
Please keep your original purchase receipt in a safe place as proof of purchase. Warranty coverage for
this product must be veri ed by the original purchase receipt. The warranty period begins on the day that
the product was purchased from an authorized retailer of Yard Force products. Warranty coverage only
applies to the original purchaser and is not transferrable. Warranty coverage is only provided on prod-
ucts purchased and used in the USA from authorized Yard Force retailers. Products purchased or used
outside of the USA are not covered by this warranty.
(2) Two-Year Warranty – Pump and Engine
The Y0GWB31EW00 has a 2-Year Limited Warranty from the date of purchase against manufacturer
defects for residential use only. Commercial use voids the warranty. This warranty does not cover acci-
dental damage, unreasonable use, normal wear and tear, neglect or non-compliance with the Operating,
Safety and Maintenance Instructions. All service, outside of normal maintenance as described in this
manual, must be done by an authorized service technician. Any unauthorized service or changes to the
original con guration of this product will void the warranty. All parts and accessories used on and with
this product must be manufacturer/or and authorized by Merotec Inc.
(90) Ninety-Day Warranty – Accessories
The accessories included with the Y0GWB31EW00; including hose, trigger handle and wand, and other
similar parts are warranted against manufacturer defects for residential use only for a period of 90 days
from date of purchase.
Warranty does not cover loss of use or other consequential damages arising from any of the above, nor
does it cover repairs made or attempted by unauthorized persons. This warranty is void if the product
is used for commercial, rental or industrial purposes. Certain parts, attachments and accessories are
subject to normal wear and tear and are excluded from the warranty.
Service and Warranty Claims Process
Contact the Yard Force Support Center toll-free at 1-[phone] Monday-Friday between 8:30 AM
and 5:00 PM Eastern Time for service and warranty support.
Yard Force USA Service Support agents can help you troubleshoot problems over the phone to get
you back up and running as quickly as possible. In the situation where service or warranty inspection is
needed, please follow these steps:
1. Contact Yard Force USA at 1-[phone] Monday-Friday between 8:30 AM and 5:00 PM Eastern
Time.
2. Send in proof-of-purchase and serial number (if applicable) to con rm warranty coverage.
3. If service or a warranty evaluation is requested, Yard Force USA will provide an RGA number that
should be used in all communications with Yard Force USA and is required to be indicated on the prod-
uct itself and on the outside of the box.
4. All shipments to Yard Force USA must have an RGA number. Any shipment received that does not have
an RGA number clearly marked on the outside of the box will be refused.
5. All shipments must be sent pre-paid, Yard Force USA does not pay for any shipping costs for service
or warranty evaluation. Yard Force USA is not responsible for any packages that are lost by carrier. We
recommend that shipments are made by a carrier that provides tracking and delivery con rmation.
For more information or to ask questions, please call toll-free 1-[phone] Monday-Friday between
8:30 AM and 5:00 PM Eastern Time.
SAVE THESE INSTRUCTIONS
