Yard force YF1800LR User manual

Model/Modelo: YF1800LR
OPERATOR’S MANUAL
Electric Pressure Wahser
English page 1
Version 1
MANUAL DE
INSTRUCTIONES
Lavadora a Presión
Eléctrica
Español página 23
Versión 1
QUESTIONS
SAVE THIS MANUAL
FOR REFERENCE
¿PREGUNTAS?
GUARDE ESTE MANUAL
DE REFERENCIA
Our Customer Service staff is ready to provide
assistance. In the case of a damaged or
missing part, most replacement parts ship
from our facility.
For immediate help with assembly, or for
additional product information,
visit www.ForceToolsUSA.com or
email [e-mail]
Nuestro personal de servicio al cliente está
listo para proveer asistencia. En el caso de
una parte dañada o faltante, la mayoría de las
piezas de repuesto se envían desde nuestro
centro.
Si necesita ayuda inmediata con el montaje,
o para obtener información adicional sobre el
producto, visite
www.YardForceUSA.com support@
ForceToolsUSA.com o correo electrónico
You will need this manual for safety
instructions, operating procedures, and
Warranty. The original sales invoice is
required for warranty service.
Usted necesitará este manual para
las instrucciones de seguridad, los
procedimientos operativos y de Garantía.
La factura de compra original se requiere
para el servicio de garantía.

1
YF1800LR Operating Manual
TABLE OF CONTENTS
Important safety instructions
Safety features
Parts and diagram list
Assembly and operation instructions
Machine assembly
Operation instruction
Shutting down and storage
Cleaning and maintenance
Troubleshooting
Technical data
Warranty
2
5
6
8
8
11
16
17
18
21
21

2
IMPORTANT SAFETY INSTRUCTIONS
Please read all of the safety precautions before operating this machine every time.
Please pay particular attention to all sections with following symbols.
WARNING
Could cause injury or death if not followed
CAUTION
Could damage machine if not followed
WARNING
When using this product, basic precautions should always be followed,
including:
1. Read all instructions before using the product.
2. To reduce the risk of injury, do not operate the machine near children.
3. Learn how to stop this product and release pressure quickly. Be thoroughly
familiar with the controls.
4. Stay alert - watch what you are doing.
5. Do not operate this product when fatigued or under the inuence of alcohol
or drugs.
6. Keep operating area clear of all people and pets.
7. Do not stand on unstable surfaces. Do not overreach or stand on unstable
support Keep good footing and balance at all times.
8. Follow the maintenance instructions specied in the manual.
9. If replacement of the plug or cord is needed, use only identical replacement
parts.
10. This product or its power cord contains lead, a chemical known to cause
cancer, birth defects or other reproductive harm. Wash hands after handling.
WARNING
Risk of injury Injection Hazard
• Equipment can cause serious injury if the spray penetrates the skin.
• Do not point the gun at anyone or any part of the body. In case of
penetration, seek medical aid immediately.
WARNING
Risk of injury
Do Not direct discharge stream at self or other persons.
• High-pressure jet can be dangerous if misused.
• The jet must not be directed at persons, animals, electrical devices, or
the unit itself.
WARNING
Risk of Explosion - Do not spray ammable liquids

3
• Do not use acids, alkaline, solvents or any ammable material in this
product. These products can cause physical injuries to the operator
and irreversible damage to the machine.
WARNING
Risk of Electric Shock
• Inspect cord before using - do not use if cord is damaged.
• Keep all connections dry and off the ground.
• Do not touch plug with wet hands.
CAUTION
Gun Kick Back
• Hold with both hands.
• The trigger gun safety lock prevents the trigger from being engaged
accidentally.
• The safety feature DOES NOT lock trigger in the ON position.
GENERAL SAFETY RULES
1. Never operate the machine without all components properly connected to the
machine (handle, gun/wand assembly, nozzle, etc.).
2. Never operate pressure washer with broken or missing parts. Check equipment
regularly and repair or replace worn or damaged parts immediately.
3. Never put hand or ngers over the nozzle or spray tip while operating the unit.
4. Never spray ammable liquids or use pressure washer in areas containing
combustible dust, liquids or vapors. An electric spark could cause an explosion.
5. Never leave the wand unattended while the machine is running or switched on.
6. Never disconnect the high pressure discharge hose from the machine while the
system is pressurized. To depressurize machine, turn power and water supply off,
then depress gun trigger 2-3 times.
7. Never cover the pressure washer during operation to allow free air cooling.
8. Always wear safety glasses or goggles when operating or performing
maintenance.
9. Always move switch on unit to “OFF” (O) position before connecting or
disconnecting cord to electrical outlets.
10. Always turn water supply “on” before turning pressure washer “on” unless draining
for storage. Running pump dry causes serious damage.
11. Always hold gun and wand rmly when starting and operating the machine.
12. Always follow detergent manufacturer’s label recommendations for proper use
of detergents. Always protect eyes, skin and respiratory system from detergent if
used.
13. Always lock the trigger of spray gun in the safety position when not in use.
14. Do not use pressure that exceeds the operating pressure of any of the parts
(hoses, ttings, etc.) in the pressurized system. Never use with any other
manufacturer’s accessories or components.

4
15. Do not spray electrical apparatus and wiring or the machine itself.
16. Do not operate the pressure washer with the inlet water lter screen removed.
Keep lter clear of debris and sediment.
17. Discharge residual pressure by depressing the trigger until no more water comes
out of the nozzle.
18. Keep clear of nozzle. Never direct high pressure spray at any person, animal or
self.
19. To minimize the amount of water getting into the pressure washer, the unit should
be placed as far as possible from the cleaning site during operation.
GROUND FAULT CIRCUIT INTERRUPTER PROTECTION
This pressure washer is provided with a Ground Fault Circuit Interrupter (GFCI) built
into the power supply cord. This device provides additional protection from the risk of
electrical shock. Should replacement of the plug or cord become necessary, use only
identical replacement parts that include GFCI protection. See Page 5 for testing
procedure.
WARNING
Connect directly to outlet. Do not use machine with extension cord. The
use of an extension cord will override the GFCI built into the plug of the
power supply cord resulting in the risk of electrical shock.
DOUBLE-INSULATION INSTRUCTION
In a double-insulation product, two systems of insulation are provided instead of
grounding. No grounding is provided on a double-insulated product, nor should a
means for grounding be added to the product. Servicing a double-insulated
product requires extreme care and knowledge ofthe system, and should be done
only by qualied service personnel. Replace- ment parts of a double-insulated
product must be identical to the parts they replace. A double-insulated product is
marked with the words “DOUBLE-INSULATION” or “DOUBLE-INSULATED”.
The symbol “ ” may also be marked on the product.

5
SAFETY FEATURES
TOTAL STOP SYSTEM (TSS)
The pressure washer is equipped with a total stop system (TSS) that will sense when
the trigger on the gun is depressed or released. It will open the power circuit to the
motor, and cause the pressure washer motor to stop. The motor will start again when
the trigger is depressed.
WARNING
The pressure washer is also equipped with a main power “ON/OFF” (I/O)
switch located on the unit. It should always be moved to the “OFF” (O)
position when the pressure washer is not being used to prevent possible
injury or damage.
Ground Fault Circuit Interrupter Protection
This device provides additional protection
from the risk of electrical shock. Plug the
Ground Fault Circuit Interrupter (GFCI) into a
power outlet. Indicator should turn red. TEST
BEFORE EACH USE. Press the “TEST” button.
Red indicator should disappear. Press “RESET”
button again for use. Do not use if above test
fails.
EXTENSION CORDS
If possible, do not use extension cords with this product. However, if you must use one,
observe all of the warnings and instructions listed below:
Use a sufcient gauge:
Maximum extension cord length: 50’ (15.2 m). Only use 12 or 14 AWG rated extension
cords.
• Use only extension cords that are intended for outdoor use. These extension cords
are identied by a marking that reads “Acceptable for use with outdoor appliances;
store indoors while not in use.”
• Use only extension cords having an electrical rating not less than the rating of the
product.
• Do not use damaged extension cords. Examine extension cord before using and
replace if damaged. Do not abuse extension cord and do not yank on any cord to
disconnect.
• Keep cord away from heat and sharp edges.
• Always disconnect the extension cord from the receptacle before disconnecting
the product from the extension cord.
• To reduce the risk of electric shock, keep all connections dry and off the ground.

6
Do not touch plug with wet hands.
CAUTION
This machine has been designed for use with detergents that are
specically approved for pressure washer use. The use of other cleaning
detergents may affect the operation of the machine and void the warranty.

7
PARTS AND DIAGRAM LIST
PARTS AND DIAGRAM LIST
Fig. 1 Fig. 2
Fig. 3

8
Parts # Quantity Description
1 1 Handle
2 1 Handle locking pin
3 1 Detergent tank cap
4 2 Wheel
5 2 Crank handle
6 1 High pressure hose
7 1 Water inlet
8 1 Carrying handle
9 1 ON/OFF switch
10 3 Nozzle storage holders
11 1 Power cord
12 1 Spray gun trigger handle
13 1 Quick-connect wand
14 1 Turbo tip
15 1 15° tip (yellow)
16 1 40° tip (white)
17 1 Soap tip (black)
18 1 Tip cleaning needle
Check contents of the box
As shown in Fig. 3
Carefully remove the pressure washer and parts from its packaging. Identify all the
parts packaged in the carton against the parts list. Please contact our customer service
center (Monday - Friday 8:30AM - 5:00PM ET) at [phone] if anything is missing.
A. High-pressure washer
B. Spray gun trigger handle
C. Quick-connect wand
D. Turbo tip
E. 15° tip (yellow)
WARNING: If any parts are damaged or missing, do not operate this tool
until the missing parts are replaced. Failure to heed this warning could
result in serious personal injury.
NOTE! Always recycle the packaging in accordance with local recycling
codes.
F. 40° tip (white)
G. Soap tip (black)
H. Tip cleaning needle
I. Operating manual
J. Crank handle

9
ASSEMBLY AND OPERATION INSTRUCTIONS
Surface Preparation
Before starting any cleaning task, it is important to inspect the area for objects that
could create a hazard. Remove any objects from the work area that could be tripped
over, such as toys or outdoor furniture. Ensure that all doors and windows are closed
tightly.
Water Supply (Cold Water Only)
Only draw water through the unit. For use with cold water supply only. Garden hose
must be at least a 1/2” (13 mm) in diameter. Flow rate of water supply must not fall
below 2 GPM (gallons per minute) [9.1 LPM (liters per minute)]. Flow rate can be
determined by running the water for one minute into an empty 5-gallon (19 L) container.
The water supply temperature must not exceed 104°F (40°C).
CAUTION
• Never use the pressure washer to draw in water contaminated with
solvents (e.g. paint thinners, gasoline, oil, etc.).
• Dirt in the water inlet will damage the unit. To avoid this risk, we
recommend checking the water lter (located inside the water inlet. To
clean it out, see Maintenance section).
• Always prevent debris from being drawn into the unit by using a clean
water source and an additional accessory water lter if required.
• To prolong the life of the unit, rest the unit for 5 minutes after every 30
minutes of use.
MACHINE ASSEMBLY
Fig. 4
Attach hand cranks onto the hose reel and cord reel on both sides.

10
Fig. 5
Locking/releasing pin
1. Pull the Locking/releasing pin outward on the left side of the machine, so that the
locking/releasing pin stays clear of the original hole where it was seated and hold it
in place with one hand.
2. While turning the handle upward with the other hand, it can rotate around its pivot.
At this moment it allows release the locking/releasing pin, so that it can depress
against the surface of the handle.
3. Keep rotating the handle until the locking/releasing pin slips into another hole on the
same side of the handle, before using this device, ensure that it is fully engaged into
this hole.
To fold the handle
1. This operating procedure is the same as above mentioned.
2. The difference is turning the handle downward.
Fig. 6
Attach high pressure hose from hose reel to the gun wand, hand tighten until two parts
are locked.

11
Recommendation for spray tip usage:
White
40°
Can be used to
clean wide areas
faster than the 15
degree nozzle
Black Turbo
Low pressure
To apply
detergent
Yellow
15°
Can be used to
clean concrete.
Fig. 7
Attach desired color coded spray tip to quick - connect wand by pushing to ensure it is
clicked in securely. Insert quick–connect wand into the gun wand, hand tighten until two
parts are locked.
CAUTION
Placing any spray tip too close to a surface can result in permanent
damage to the surface being sprayed. Maintain at least a 24” distance
between the tip and the surface being sprayed until you have determined
it is safe to move the tip closer to the surface.
Fig. 8
Attach the garden hose to the water inlet (hand tighten only).
Fig. 9
Attach garden hose to water supply and turn water valve on to the fall on position. The
water temperature must not exceed 40oC(104oF) and the supply pressure must be
between 40 to 80 PSI.

12
CAUTION
The pressure washer must only be used with clean water. Use of
unltered water or corrosive chemicals will damage the pressure washer.
This pressure washer is not intended to pump hot water. Never connect
it to a hot water supply as it will signicantly reduce the life of the pump.
OPERATION INSTRUCTIONS
WARNING
Risk of injury, Do Not Direct discharge stream at self or other persons.
WARNING
Before cleaning any surface, an inconspicuous area should be cleaned
to test spray pattern and distance for maximum cleaning results.
Fig. 10
Make sure the ON/OFF switch is on the OFF position before plugging in the unit, press
the switch button with mark “ O ” to ensure it is off.
Fig. 11
Completely unwind power cord and plug the unit into an outlet.

13
Fig. 12
Ensure the gun safety latch is released by pushing it down and engage the trigger for a
few seconds to discharge the residual pressure in the high pressure hose.
Fig. 13
Turn ON the pressure washer by press- ing the button with mark “ I ”. The unit will
run for a few seconds to build up pressure, then will stop on the function of total stop
system (TSS).
Fig. 14
Depress the gun trigger until there is a steady stream of water. Change the spray tip
as per the recommendation above if necessary. Before changing spray tip, switch the
machine off, depress trigger to release pressure and activate gun safety latch.

14
Fig. 15
CAUTION
Make sure spray tip and wand is well locked. Do not move the spray tip
while trigger is depressed.
CAUTION
If painted surfaces are peeling or chipping, use extreme caution as
pressure washer may remove the loose paint from the surface.
For most cleaning applications, a twenty degree (20o) spray angle be
recommended to avoid damage to the surface being sprayed.
The pressure of spray on the surface will increase when you move the
wand closer to the surface.
Fig. 16
OF
Turn off the pressure washer by pressing the switch button with mark “ O ”, activate
the safety latch for a break. For storage, drain machine after use by removing water
con- nection, turning ON the machine for a few seconds and depressing gun trigger to
release remaining water in the pump. Turn OFF immediately.
CLEANING DETERGENTS DISPENSER
Only use cleaning detergents recommended for pressure washers.
Always follow detergent manufacturer’s label recommendations for proper use of
detergents or soap. Always protect eyes, skin and respiratory system from detergent if
used.

15
CAUTION
Working with detergent ensures a quick soaking of the dirt, and allows the
high- pressure water to penetrate and remove the dirt more effectively. Always
spray detergent on a dry surface, do not pre-soak area. Wetting the surface
rst dilutes the detergent and reduces its cleaning ability.
To apply detergents you must be operating at low pressure. This provides
a gentle application of detergent, with the pressure equivalent to the lowest
garden hose. The high-pressure setting is used for cleaning, you cannot
apply detergents when working at high pressure.
Always test detergent in an inconspicuous area before use.
NO BLEACH
1. Engage gun safety lock.
Fig. 17
Fig. 18
2. Attach the low-pressure spray tip (black) for soap or detergent application.
Detergent application will only work with low pressure spray tip.
Fig. 19
Fig. 20
3. As shown Fig.19 Lift up to remove the cap of detergent tank, ll tank with
detergent or soap and replace the cap. Apply detergent as instructed by the
detergent manufacturer.
4. Turn on the pressure washer. Depress trigger to operate unit. The liquid detergent
will automatically mix with water, and be discharged through the nozzle. Apply
detergent to a DRY work surface, from bottom to top.
5. Allow detergent to remain on the surface for a short time before rinsing. Do not
allow detergent to dry on surface.

16
6. Rinse with clean water under high pressure. On a vertical surface, rinse from the
bottom up, then rinse from the top down to avoid streaking. Hold nozzle 6-8” (15-
20 cm) from the cleaning surface, at a 45° angle.
7. As shown Fig.20 When you have nished using the detergent injection system, if
certain amount of remaining detergent still exist in detergent tank.
• Drain it by unscrewing the threaded plug, which is located at the bottom of
device.
• Secondly, put the threaded plug back into place.
• Fill detergent tank with clean water. Siphon water by using soap tip for one
minute, so that all detergent is ushed through system.
CAUTION
Fail to follow detergent clean procedure will cause the dispensing
system to become clogged.
Damage may occur to painted surface if chemical is allowed to dry on
surface. Wash and rinse a small section at a time. Avoid working on hot
surfaces or in direct sunlight.
Never use:
• Bleach, chlorine products and other corrosive chemicals
• Liquids containing solvents (i.e., paint thinners, gasoline, oils)
• Tri-sodium phosphate products
• Ammonia products
• Acid-based products
These chemicals will harm the unit and will damage the surface being
cleaned.

17
SHUTTING DOWN AND STORAGE
1. (If you are not using detergent, go directly to Step 2.) When you have nished
using the detergent dispensing system, ll detergent tank with clean water to rinse
the system clean. Depress the gun trigger for one minute at low pressure so that
all detergents remaining in system are thoroughly ushed out. Remove detergent
tank to empty the remaining water, and rinse it until it is thoroughly cleaned.
2. Turn off water supply and disconnect the garden hose from the faucet and the
water inlet on the unit.
3. Depress the gun trigger for a few seconds to release any remaining water until
water spray stops, turn off unit immediately.
4. Unplug power cord from the power outlet and wrap it into the cable reel by rotating
the reel with hand crank.
5. For storage, disconnect the high pressure hose from the gun wand and wrap hose
into the hose reel by rotating the reel with hand crank.
6. Engage gun safety latch and disconnect the quick – connect wand from gun wand,
disassembly and replace the spray tip to tip holder on the unit, insert the wand into
the wand holder, turn back the hand to the down position.
7. Store the machine and accessories in a room that does not reach freezing
temperatures. Do not store near furnace or other sources of heat as it may dry out
the pump seals.
WARNING
Turn off water supply and squeeze trigger to depressurize the unit.
Failure to do so could result in personal injury due to discharge of high-
pressure water.
Optimum Winterizing Procedure
Winterizing your pressure washer will help protect and prolong its life. We strongly
recommend you follow the below steps using *Pressure Washer Pump Saver.
This will keep the internal parts lubricated, protected from rust, and prevents the pump
from freezing.
1. Connect Pressure Washer Pump Saver hose
onto the water inlet.
2. Depress button on top of pump saver
container.
3. Continue until uid exits the pressure hose for
15 seconds.
4. Remove the hose from pump inlet (water inlet).
*Pressure Washer Pump Saver not included
Fig. 21

18
CLEANING AND MAINTENANCE
Water Filter Screen
The pressure washer is equipped with a water inlet lter screen to protect the pump. If
the screen is not kept clean, the ow of water to the pressure washer will be restricted
and the pump may be damaged.
1. To clean inner water screen, remove
the inlet adaptor and remove the lter
screen from the pump inlet.
2. Rinse screen until it is free of debris and
blockage.
3. Replace screen immediately to prevent
any foreign matter from entering the
pump.
A clogged water lter screen can cause excessive pressure to build-up in the pressure
washer’s pump. The wand’s water lter screen should be cleaned regularly to avoid
damaging the wand or pump.
1. Using needle-nose pliers, carefully take the water lter screen out of the wand.
2. Clean the water lter screen by carefully inserting the water lter cleaning tool
provided or a thin and sharp instrument (e.g. paperclip) into the lter to remove
any dirt deposited. Rinse with clean water.
3. Using needle-nose pliers, carefully reinsert the water lter screen into the wand.
Ensure the screen ts tightly into the wand’s water inlet opening.
Main body cleaning
Use only mild soap and damp cloth to clean the main body.
WARNING
Never use the unit to clean itself.
Connections
Connections on pressure washer hoses, gun and spray wand should be cleaned
regularly and lubricated with non-water soluble grease.
Spray Tips Only
Clogging of the spray tips causes the pump pressure to be too high and cleaning is
immediately required. Clean the spray tips by carefully inserting a needle provided or a
thin and sharp instrument (e.g. paperclip) into the tip to remove any dirt deposited.
WARNING
To assure product safety and reliability,
repairs should be performed by authorized
service centers or other qualied service
personnel, always use identical replacement
parts.
Fig. 22

19
TROUBLE SHOOTING
Disconnect the machine from the power source before making any repairs.
Symptom Cause Solution
Motor does not run when
“ON” ( I ), fully connected
and trigger depressed.
On/Off switch is in the
“OFF” (O) position.
Turn switch to the “ON” ( I
) position.
Power cord is not plugged
in.
Plug in power cord.
Extension cord is too long.
Extension cord is not
proper gauge.
Extension cord is dam-
aged.
Replace extension cord
with either a 25’ (7.6 m)
14/3 gauge cord or a 50’
(15 m) 14/3 gauge cord.
Electrical outlet does not
supply adequate power.
Try a different outlet.
Tripped pressure washer
thermal protector.
Allow to cool, and restart
unit.
Unit does not reach high
pressure.
Diameter of garden hose
is too small.
Replace with a 1” (25 mm)
or 5/8” (16 mm) garden
hose.
Water supply is restricted.
Check garden hose for
kinks, leaks and blockage.
Not enough water supply. Open water source fully.
Water inlet lter is clogged. Remove lter and rinse in
warm water.
Power nozzle is in
lowpressure position.
Replace with desired
highpressure tip.
Pump is sucking air. Check that hoses and t-
tings are airtight. Turn OFF
machine, and purge
pump by squeezing trigger
gun until a steady ow of
water emerges through the
nozzle.
