No. STK CODE Parts No. Description QNo. STK CODE Parts No. Description Q
1 6036-230201 PROJECTIVE GUARD 1 14 6068-202606 UPPER HANDGRIP (R) 1
2 6228-202701 GUARD ASS'Y 1 15 6010-202602 WIRE 1
2-1 6SDABB04-10 SCREW 2 16 6010-202601 WIRE 1
2-2 6250-202503 WIRE CUTTING BLADE 1 17 6022-230001 SWITCH 1
2-3 6262-202701 GUARD 1 18 6028-230003 TRIGGER 1
3 6228-202004A SPOOL CARRIER ASS'Y 1 19 6068-202605 UPPER HANDGRIP (L) 1
3-1 6140-B23101 PILOT 2 20 6038-202605 HOUSING (L) 1
3-2 6059-202005A SPOOL COVER 1 21 6021-202602 DETENT 1
3-3 6194-202001 WIRE-CUTTING 9m 1 22 6024-202605 SPRING 1
3-4 6008-202001A SPOOL CARRIER 1 23 6056-202607 BUTTON 1
3-5 6059-202004 SPOOL COVER 1 24 6024-202603 SPRING 1
4 6038-202606 HOUSING (R) 1 25 6099-202702 MOTOR 120V 1
5 6SDABB04-18 SCREW 15 26 6154-840001 TERMINAL BLOCK 2
6 6SDABB04-14 SCREW 4 27 6024-202601 SPRING 1
7 6017-230101 JACKET 1 28 6072-202601 MOTOR PLATE 1
8 6056-202603 SNAP BUTTON 1 29 6WSB-04 WASHER 2
9 6114-202602 ADJUSTABLE ROD 1 30 6SDAB-04-10 SCREEW 2
10 6SHDB-06-52 SCREW 1 31 6WSB-03 WASHER 2
11 6WFB-06 WASHER 1 32 6SDAE-03-08 SCREW 2
12 6NBB-06 NUT 1 33 6270-202003 CUTTER ASS'Y 1
13 6196-202601 CENTRAL HANDGRIP 1 34 6024-202604 SPRING 1
1
:
-
REVISED
DATE
DATE
1/18/2006
MODEL NO.
SPECIFY MODEL NO. WHEN ORDERING PARTS
12" String Trimmer
41AC027P900/MTD27P
SERVICE SPARE PARTS LIST
1
2-1
12
11
13 14
19
16
2022232425 21
28
29
30
31
2-2
2-3
3-1
3-2
3-3
3-4
3-5
5
4
7
8
910
27
17
34
6
15 18
26
32
33
6
3
2
