YASKAWA G2 User manual

Quick Guide for Ethernet Network Card G2
06/01/2019
Revision 8

Introduction
Page 1
The Ethernet Network Card is used for monitoring and controlling purposes. The Ethernet Net-
work Card supports industry standard Modbus RS485 communication and TCP/IP protocol.
When used with an Internet connection, it can send data to an online portal from where up to 32
inverters can be monitored. It can also be used to remotely update the inverter firmware.
Capabilities
● Remote inverter firmware upgrade support by Yaskawa Solectria Solar (YSS).
● Remote diagnostics by YSS Technical Support & Service.
● Direct customer data from the Ethernet Network Card via a programmable Ethernet XML
Sunspec Data Exchange connection for customers who want to manage their own data directly.
● Pass-thru Modbus communications to a third-party gateway.
General data
Voltage supply
Connections
Communicate to
Modbus daisy chain
Third-party data logger
Cloud service
Third-party server
Raw data client
RS485 port A
RS485 port B
Pass-thru
Ethernet
WiFi module
Isolated RS485, Max. 32 devices
Pass-thru port, Isolated 3 Pin RS485
Ethernet port, MQTT
Ethernet port, HTTPS
Ethernet port, Modbus/TCP
Internal installation, RS485+DC Input, 6 Pin
External installation, RS485+DC Input, 5 Pole 3.5 mm pitch EDG
Only one effective at the same time between port A and B
RS485, 3 Pole, A+ / B- / G
RJ45, 10Base-T / 100Base-T
4Pin connector
Input voltage
Power consumption
9 ~ 24 Vdc
< 1 W, Max. 5 W
Ambient conditions
Degree of protection
Ambient temperature
Relative humidity
Installed in inverter wire-box or 3rd party enclosure
-40√ to +85√, Natural convection
< 85%, Non-condensing
Dimensions ( W/H/D)
Weight
Status display
140 mm / 70 mm / 15 mm
50 g
LEDs for Activity, Cloud, RS485 and Power

Page 2
Ethernet Port
WiFi Module Port
Switch
Pass-through Port
Reboot Button
RS485 Port B
Switch
RS485 Port A
Internal installation option
Activity
Cloud
RS485
Power
External installation option
A
A+ B- G
Vin GND A+ B- G
Ethernet Network Card (ENC) G2
Interface & Indicators
B

Page 3
Activity
Cloud
RS485
Power
Caution:
The termination switch should always be ON if it is the last device in a daisy chain.
If the length of the cable connecting to RS485 port or Pass-through port of
the ENC is over 1000 meters, the termination switch button must be set to ON.
Activity
Fast Blink: Executing Command
Blink: Gateway Heartbeat
Cloud
ON: Connected
Fast Blink: Communication with Cloud
Blink: LAN Activity
OFF: Disconnected
RS485
Blink: Device R/W
OFF: No Activity
Power
ON
OFF
Contents Note
ENC G2 DC 9~24V, Max. 5 W
WiFi Module
Accessories D2XH Cable, 3 Standoffs with Screws,
3-Pin Connector, 5-Pin Connector
ENC Enclosure 80mm * 92.5mm * 35mm
Scope of Delivery
Terminating Resistance
Switch
Terminating Resistance
Switch

Page 4
A
Installation Option
Internal in Wire-Box of the Inverter
Inverter Inverter
Inverter
Wire Box
RS485
3rd Party Server
HTTPS
YSS Server
MQTT
WiFi Module + APP
Router
When the inverters are monitored via the ENC, a unique RS-485 address for each
inverter can be set up through the LCD interface.
Up to 32 inverters can be connected together in the communication network.

Page 5
The Communication Board of Inverter
RS485 Port
1
Inverter Wire-Box
Remove the (3) screws that attach
the inverter communication board
in the Wire-Box using a #2 Phillips
bit.
2Replace the screws with the (3)
standoffs included in the ENC Kit.
6-PIN Header
6-PIN Connector
3
Install the ENC by carefully aligning
the 6-PIN connector in the upper
left-hand corner of the communication
board.
Install the (3) screws into the stand-
offs to secure the ENC in place.
Install the 3 screws and torque to 7
in-lbs using a #2 Phillips bit.

Page 6
Ethernet Port
Connect the 3rd party Datalogger to the Pass-Through in the bottom left-hand corner
of the ENC using the 3-Pin Connector provided in the ENC Kit.
Connect the RS485 inverter daisy chain to the inverter communication board using
the 5-Pin Connector provided in the ENC Kit.
NOTE: The 5-Pin Connector is installed on the port on the bottom of the inverter
communication board (behind the ENC) .
The RJ45 LAN cable is inserted into
the Ethernet port of the ENC.
The LAN cable must be able to access
the Internet without port filtering behind
the firewall.
5
A+ B- G
Vin GND A+ B- G
RS485 of 3rd Party Data Logger
RS485 Inverter Daisy Chain
4
Optional wire
Optional wire
A + / B - / G
A + / B - / G

Page 7
RS485 Daisy Chain
Pass-through
D2XH Cable (Provided)
WiFi Module
Ethernet Port
Internet
WiFi
Inverter
3rd Party
Data
Logger
6
The WiFi module is connected to the WiFi port of ENC via the D2XH cable provided.
Download and install the “Yaskawa Connect ” app from the Apple Store and
Google Play.
RS485 & A+ / B- '
RS485 & A+ / B- '

Page 8
1
The ENC may be installed in an enclosure as shown.
The ENC Enclosure includes a DIN rail mounting clip for installation in
a NEMA4 communication box.
Screw M3*8
Screw M3*6
Installation Option
ENC in external enclosure
B
92.5 mm 80 mm
35 mm

Page 9
Ethernet
RS485
Data logger
Ethernet
Cellular
Fiber
Meter
RS485
Weather Station
Ethernet
RS485
Modbus/TCP Converter
AC/DC
Power
- +
Inverter
ID:101
Inverter
ID:102
Inverter
ID:117
Switch
Third-party DAS
Example
RS485
Surge
S
S
- +
- +
Pass-through
Ethernet
RS485
2Typical
Don’t use the Modbus ID 160.
It is reserved for broadcast
commands.
Ground wire diameter is 1 mm2

Page 10
Open the firewall ports before commissioning !
If a firewall is used to protect the network, the following ports must be opened
both ways (incoming and outgoing communications):
TCP 1883 with destination IP 47.254.52.209
The following outgoing ports must be opened :
TCP 443 with destination solrenview.com
(IP 209.160.64.80)
if the firmware of ENC installed is lower than 1.6000, the following port must be
opened both ways:
TCP 80 and 88 with destination IP 47.254.31.163
If the user cannot have these ports open, remote diagnostics and firmware
updates will not be available.
It is recommended to use a separate modem/router so that the inverters’
network is not part of the high security network used on the site.

Page 11
Setup and Activation
1 2
WiFi Gateway
Ethernet Card No-LCD Inverter
Firmware
Installer Site Owner
Open the APP and click “Ethernet Card”
under the “Installer” tab.
Ensure the D2XH Cable and WiFi Module
are connected to the ENC.
Select WiFi settings and connect to the
network name beginning with “CPLK-“.
The password is “Password”.
The ‘P’ is capital and it is case sensitive.
WiFi Setting
Next
Connect to ModuleBack
Connected to the WiFi SSID
start with “CPLK-”
And the password is
“Password”
WiFi
Module

Page 12
3 4
Quit New Gateway Activate
Once connected to the network navigate
back to the APP. Note do not close the
app as you will need to repeat the previ-
ous steps.
“DHCP” enabled means that the card will
try to obtain IP and DNS by itself from
your server.
This is the recommended settings. If you
network administrator requires a static IP,
disable this feature and enter it manually.
“Inverter Baud Rate” :
Speed 2400 / 4800 / 9600 / 14400 / 19200
Parity E / N / O
Data 8 / 9
Stop 1 / 2
“Modbus Range” can be selected in the
range of 1 - 246. Modbus ID 160 should
not be used.
Upload Interval (minutes): You can select
the upload interval for the data going to
the cloud.
DHCP
Inverter Baud Rate
Modbus Range 1 ~ 16
9600 N81
Test Save the Config
Basic Ethernet RS485
ENC Name: unknown
Model: FG4E-US
SN: 1088000000106
Hardware Ver: V1.4.1751
Firmware Ver: V01.6142
Quit New Gateway Activate
DHCP
Upload Interval
Advanced Settings
1 Minutes
Test Save the Config
Basic Ethernet RS485
Runtime: 22 Minutes
MQTT Connection: DISCONNECT
MQTT Server Host: None
Routing: LINK_OFF
MAC: 00005E113C08
IP Address: 0.0.0.0
Mask: 0.0.0.0
Gateway: 0.0.0.0
DNS: 0.0.0.0

Page 13
5
Quit New Gateway Activate
If the boxed items above are showing
0.0.0.0 , please contact your network
administrator for further help.
If the card has successfully obtains an IP
address, it will be displayed as shown.
Quit New Gateway Activate
DHCP
Upload Interval
Advanced Settings
1 Minutes
Test Save the Config
Basic Ethernet RS485
Runtime: 25 Minutes
MQTT Connection: CONNECT
MQTT Server Host: yss.solectria.com 1883
Routing: LINK_ON
MAC: 00005E113C08
IP Address: 192.168.1.100
Mask: 255.255.255.0
Gateway: 192.168.1.1
DNS: 6.6.6.6
DHCP
Upload Interval
Advanced Settings
1 Minutes
Test Save the Config
Basic Ethernet RS485
Runtime: 22 Minutes
MQTT Connection: DISCONNECT
MQTT Server Host: None
Routing: LINK_OFF
MAC: 00005E113C08
IP Address: 0.0.0.0
Mask: 0.0.0.0
Gateway: 0.0.0.0
DNS: 0.0.0.0

Page 14
6 7
Back Advanced Settings
”Reboot” will only restart the ENC. It will
not erase any settings.
“Reset” will restore the ENC to factory
settings. All previous data will be perma-
nently deleted.
In the “Ethernet” area, the user can con-
nect the ENC to the two different servers.
This setting should not be changed.
Inverter Port
Pass-through Port
Ethernet
Reboot
Reset
Upgrade Firmware
Back Ethernet Execute
DHCP
Protocol of Server
MQTT
HTTPS

Page 15
8 9
Quit New Gateway Activate
Click “Test” to check the default configura-
tion and the ENC will query each inverter
in the daisy chain and display the connec-
tion with all units.
Make sure all inverters have unique
Modbus ID addresses. Select the appro-
prate Modbus Range for your system.
If the card has internet access and it is not
being blocked, it will display [OK]. Please
contact your network administrator, if
another message is received.
Once the “Test” is complete, the user
should be able to see all the inverters that
were found in the given range.
If the user is missing an inverter, make
sure it has a unique ID and it is within the
range. Once you find all the expected
inverters, please press “Save the Config”.
At this point the “Activate” button at the
top right corner should be highlighted.
DHCP
Inverter Baud Rate
Modbus Range 1 ~ 32
9600 N81
Test Save the Config
Basic Ethernet RS485
---------------------------------------
Test:
1. Server Connection [ OK ]
2. Query Inverter 1...
Quit New Gateway Activate
DHCP
Upload Interval
Advanced Settings
1 Minutes
Test Save the Config
Basic Ethernet RS485
Runtime: 25 Minutes
MQTT Connection: CONNECT
MQTT Server Host: yss.solectria.com 1883
Routing: LINK_ON
MAC: 00005E113C08
IP Address: 192.168.1.100
Mask: 255.255.255.0
Gateway: 192.168.1.1
DNS: 6.6.6.6

Page 16
10 11
Press “Activate”. The APP will prompt you
for an internet connection.
This will require the user to disable the
WiFi between his/hers smart device and
the WiFi module and enable the 3G/4G
network of the smart device to take over.
Once you disable the WiFi, navigate back
to the APP. Do not close the APP.
Ensure the mobile phone is connected to
the Internet during this step.
For email type [email protected] and
then press “ Next”. This is the only email
you can use in this step.
Quit
Next
Email of Site Owner

Page 17
12 13
Back
Name a new site or choose an existing
site. Please ensure that the Yaskawa
Solectria Solar Technical Support & Ser-
vice team has the same site name on file.
Name a new ENC.
Choose the time zone of the site.
Click “Apply” to proceed with activation.
Site Name
ENC Name None
None
Apply
ENC
Time Zone

Page 18
14
Quit New Gateway Activate
For verification purposes, please log out
and close the app
Connect via WiFi to the ENC.
If the Connection is successful the user
will see an “Activated” status at the top
right corner.
The ENC name is also visible in this
screen.
DHCP
Inverter Baud Rate
Modbus Range 1 ~ 16
9600 N81
Test Save the Config
Basic Ethernet RS485
ENC Name: Genesis
Model: FG4E-US
SN: 1088000000106
Hardware Ver: V1.4.1751
Firmware Ver: V01.6142
Upon successful creation of the site, it will
appear on the Service portal.
The service portal is only available for
service personnel. Please call Yaskawa
Solectria Service to ensure that your site
was successfully created.

Monitoring Support
Phone: ( 978 ) 683 9700, Option 5
Hours: 8:30 AM to 5:30 PM (EST) Mon-Fri
Email: monito[email protected]m
