Yazoo/Kees 968999757 User manual

Parts Manual
ZMMKW34170 / 968999757
Please read the operator’s manual carefully and make sure you
understand the instructions before using the machine.

©2007 HTC. All Rights Reserved.
Beatrice, NE. Printed in U.S.A.

CONTENTS
NOTE: ALL FASTENERS ARE GRADE 5 UNLESS OTHERWISE SPECIFIED.
CHASSIS / FRAME....................................................4
ENGINE......................................................................6
STEERING.................................................................8
PARKING BRAKE ....................................................10
HYDRAULIC PUMP-MOTOR...................................12
MOWER LIFT / DECK LIFT......................................14
34" DECK.................................................................16
CONTROLS..............................................................18
FUEL SYSTEM.........................................................20
SEAT ........................................................................22
CASTERS.................................................................24
ELECTRICAL ...........................................................26
DRIVE.......................................................................28
DECALS...................................................................30

4
11
15
12
19
18
16 14
3
13
1
6
7
17
2
9
4
17
16
16
14
20
8
10
13
21
5
14
1
18
CHASSIS / FRAME

5
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
CHASSIS / FRAME
539 1215061.. ...2 ...BRACKET, BLOCKOUT
539 1328052.. ....1 ....CHANNEL SEAT MOUNT
539 1328013.. ....1 ....FRAME
539 1108134.. ...1 ...“U” TYPE RETAINER ¼
539 1148325.. ...1 ...DECAL, OIL TANK
539 9777786.. ...2 ...ABRASIVE PAD
539 1079587.. ...2 ...FOOT PAD
539 1012028.. ....1 ....OIL CAP
539 1328049.. ...1 ...PANEL, FRONT
539 11561710.. ....2 ...NUT
5/16-18 HEX NYLOC
539 12176311.. ....1 ....OIL FILTER
539 11869112.. ...1 ...SCREW ¼-20 x ¾" WING
539 10476313.. ...6 ...“U” TYPE RETAINER 5/16
539 99031614.. ...6 ...RHSNB 5/16-18 x ¾
539 13281115.. ...1 ...CHANNEL, TANK MOUNT
539 99071716.. ...6 ...NUT 5/16-18 HEX NYLOC
539 11739917.. ...4 ...SCREW, BUTTON HEAD
539 99018818.. ...2 ...WASHER 5/16 SAE FLAT
539 13283219.. ...1 ...PLATE, FOOT W/DECALS
539 97693420.. ...2 ...HCS 5/16-18 x ¾
539 12176721.. ...1 ...TANK ASSM

6
ENGINE
2
3
4
6
7
8
1
5
9
10
11
12
13
14
14
12
15
17
18
20
16
19

7
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
ENGINE
539 1100651.. ....1 ....BOLT,
7/16 -20 x 2¾
539 1153872.. ....1 ....KEY, ¼ x .88
539 1155463.. ....1 ....WASHER,
7/16
539 1188934.. ....1 ....OIL DRAIN
539 1194895.. ....1 ....HUB, BEARING-SPACER
539 1196806.. ....1 ....ADAPTOR, OIL DRAIN
539 1207867.. ....1 ....CLUTCH
539 1213088.. ....1 ....DRIVE PULLEY, ENGINE
539 9769359.. ....3 ....HCS 5/16-18 x 1½
539 97693710.. ....1 ....HCS 5/16-18 x 2
539 97697911.. ....2 ....NUT 3/8-16 HEX NYLOC
539 99064512.. ....2 ....RHSNB 3/8-16 x 1
539 99071713.. ..18 ....NUT 5/16-18 HEX NYLOC
539 99031614.. ..14 ....RHSNB 5/16-18 x ¾
539 13282015.. ....1 ....SUPPORT, TANK RT
539 13281916.. ....1 ....SUPPORT, TANK, LT
539 13282117.. ....1 ....ANCHOR, CLUTCH
539 13282218.. ....1 ....HITCH, BLACK
539 13282419.. ....1 ....GUARD, REAR
539 13282520.. ....1 ....GUARD, MUFFLER

8
STEERING
3
23
11
9
24
2
30
16
17
14
1
7
33
28
10
35
39
36 41
5
31
37
12
38
39
12
20 14
25
18
4
26
32
15
35
40
17
13
35
6
11
838
39
35
2
36
34
13
24
28 19
29
22
27
21
37
37

9
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
STEERING
539 1013321.. ....2 ....HHB ½-13 x 2¾
539 1083962.. ....2 ....HHB 5/16-18 x 2½
539 1103403.. ....2 ....NUT
5/8-11 HEX NYLOC
539 1155024.. ....4 ....NUT
5/16-24 HEX JAM
539 1155335.. ....2 ....WASHER
5/16 FLAT TYPE A
539 9910736.. ....2 ....NUT 5/16-24 HEX JAM LH
539 1155707.. ....2 ....WASHER, .626 ID x.056
539 1080108.. ....2 ....NUT ½-13 HEX NYLOC
539 1156179.. ....2 ....NUT
5/16-18 HEX NYLOC
539 11563810.. ....2 ....GREASE ZERK
539 11081311.. ....4 ....“U” TYPE RETAINER ¼
539 11567412.. ....8 ....NUT
5/16-18 HEX FLANGE
539 10476313.. ....2 ....CLIP NUT 5/16-18
539 11572914.. ....2 ....ROD END - RH
539 10108015.. ....2 ....DECK SWITCH
539 11668916.. ....2 ....ROD END COUPLER
539 11669017.. ....2 ....ROD END - LH
539 11747618.. ....2 ....ROD
539 11786319.. ....1 ....PLATED PIVOT, RH
539 11786520.. ....1 ....PLATED PIVOT, LH
539 11790021.. ....2 ....MOUNT, DAMPENER
539 11794922.. ....1 ....SPRT, STEER CNTRL RH
539 11795023.. ....1 ....SPRT, STEER CNTRL LH
539 12089924.. ....2 ....GRIP
539 12095025.. ....1 ....LEVER, PLATED LH
539 12095126.. ....1 ....LEVER, PLATED RH
539 12095627.. ....2 ....BUSHING ½ ID x ¾ OD
539 12106528.. ....2 ....LEVER, UPPER
539 12264529.. ....2 ....DAMPENER, DUALACTION
539 91112130.. ....4 ....BELLEVILLE WASHER,
5/8
539 97693531.. ....4 ....5/16-18 x 1½ HHB
539 97695232.. ....4 ....PAN HD SCR,10-24 x 5/8
539 97697733.. ....4 ....10-24 HEX NUT NYLOC
539 99019634.. ....2 ....5/16-18 HEX NUT
539 99020935.. ..10 ....5/16-18 x 1 HHB
539 99025036.. ....6 ....½ FLAT WASH NARROW
539 99031637.. ....2 ....5/16-18 x ¾ ZD
539 99058038.. ....4 ....¼-20 x ¾ HHB
539 99071739.. ..10 ....5/16-18 HEX NUT NYLOC
539 99100340.. ....2 ....¼-20 x 1¾ HHB
539 99111241.. ....2 ....¼-20 HEX JAM NUT

10
PARKING BRAKE
8
14
6
6
15
26
11
24
19
22
9
4
16
10
12
1
18
2
7
5
21
4
24
13
17
20
25
23
1
2
3
26
9
14
24
24
26
26 28
29
27

11
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
PARKING BRAKE
539 1072711.. ....2 ....RHSSNB 5/16-18 x 1
539 1093322.. ....2 ....NUT 3/8-16 HEX JAM
539 1156173.. ....2 ....NUT
5/16-18 HEX NUT NYLOC
539 1156684.. ....2 ....ROLL PIN,
3/16 x 1¼
539 1218615.. ...1 ...BRAKE SWITCH
539 1156806.. ....4 ....HAIR PIN COTTER
539 1163507.. ....1 ....SPRING
539 1174778.. ....1 ....SHAFT, BRAKE
539 1174789.. ....2 ....SWIVEL, BRAKE
539 11752210.. ....1 ....ROD, BRAKE LH
539 11752311.. ....1 ....ROD, BRAKE RH
539 11753112.. ....1 ....WLDMT, BRAKE SHOE LH
539 11753213.. ....1 ....WLDMT, BRAKE SHOE RH
539 11753614.. ....2 ....WLDMT, BRAKE PIVOT
539 11782315.. ....1 ....BRAKE LINK, DRILLED
539 11782416.. ....1 ....BRAKE HANDLE DRILLED
539 13280717.. ....1 ....BRACKET, TANK MNT, LH
539 13280618.. ....1 ....BRACKET, TANK MNT, RH
539 11789819.. ....2 ....E-RING
7/8
539 11892820.. ....2 ....GREASE ZERK-¼
539 12092121.. ....1 ....GRIP, BRAKE HANDLE
539 97694122.. ....1 ....HHB 3/8-16 x 1¼
539 97697923.. ....1 ....NUT 3/8-16 HEX NYLOC
539 99031624.. ....6 ....RHSNB 5/16-18 x ¾
539 99061325.. ....1 ....NUT 3/8-16 HEX FLANGE
539 99071726.. ....2 ....NUT 5/16-18 HEX NYLOC
539 11785127.. ....1 ....MOUNT, SWITCH
539 97697728.. ....2 ....NUT #10-24 HEX NYLOC
539 97695229.. ....2 ....SCREW #10-24 x .625

12
1
2
3
9
5
4
7
8
13
14
11
12
10
15
6
20
18
20
21
22
17
16
16
23
21
19
24
25
26
HYDRAULIC PUMP-MOTOR
17

13
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
539 1152781.. ....1 ....IDLER PULLEY
539 1155462.. ....1 ....WASHER.445 x 1.387 x .255
539 1080103.. ....1 ....NUT ½-13 HEX NYLOC
539 1160084.. ....1 ....BUSHING 1.90
539 1178555.. ....1 ....TUBE HYD LH-A
539 1178566.. ...1 ....TUBE HYD LH-B
539 1178577.. ....1 ....TUBE HYD RH-A
539 1178588.. ....1 ....TUBE HYD RH-B
539 1178729.. ....1 ....T-ASM HYD SUCTION
539 11787310.. ....1 ....T-ASM HYD CASE DRAIN
539 11788511.. ....1 ....BELT TENSIONER
539 11801212.. ....1 ....V-BELT
539 11876213.. ....1 ....SPRING
539 11886914.. ....1 ....HHB
3/8-16 x 3
539 11896315.. ....1 ....HHB ½-13 x 1¾
539 12175916.. ....4 ....FITTING HYDRAULIC
539 12176017.. ....4 ....FITTING HYDRAULIC
539 12176118.. ....2 ....FITTING HYDRAULIC
539 12185919.. ....1 ....SPRING MOUNT
539 12688820.. ....2 ....ADAPTER-MALE 9/16-18
539 12693721.. ....1 ....WASHER 3/8INT EXT L
539 97697922.. ....1 ....NUT 3/8-16 HEX NYLOC
539 99051723.. ....1 ....WASHER 3/8FLAT
539 99056324.. ....1 ....HHB 3/8-16 x 1
539 13214525.. ....1 ....PUMP, LH
539 13214626.. ....1 ....PUMP, RH
HYDRAULIC PUMP-MOTOR

14
MOWER LIFT / DECK LIFT
23
33
33
33
19
19
19
27
27
27
36
36
36
30
30
25
30
20
25
24
5
9
24
5
9
4
4
1
4
6
18
8
35
35
28
14
12
29
38
2
21
17
8
35
26
37
16
7
35
10
83431
35
32
30
26
29
22
61
28
2
13
35
3
11
14
33
19
27 36
15

15
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
539 1004761.. ....4 ....NUT 5/8-11 HEX JAM
539 1083692.. ....2 ....HHB ½-13 x 1¼
539 1153593.. ....1 ....BLADE ADAPTOR
539 1155014.. ....4 ....HAIR PIN COTTER
539 1155185.. ....2 ....WASHER
5/8STD FLAT
539 1155586.. ....2 ....NUT ½-20 HEX JAM
539 1155657.. ....1 ....WASHER
5/8x .063
539 1080108.. ....3 ....NUT ½-13 HEX NYLOC
539 1157699.. ....2 ....NUT ½-20 HEX JAM LH
539 11603910.. ....3 ....SPACER
539 13283411.. ....1 ....WLDT, LIFT ARM, LH
539 13283312.. ....1 ....WLDT, LIFTARM, RH
539 13281013.. ....1 ....LINK, LIFT HANDLE
539 11789814.. ....2 ....E-RING
7/8
539 11790315.. ....1 ....OUTER QUADRANT
539 13281416.. ....1 ....LIFT HANDLE WELDMENT
539 13281317.. ....1 ....LIFT LATCH
539 13281518.. ....1 ....FOOT PEDAL
539 11816519.. ....4 ....HHB
3/8-16 x 1½ FLG
MOWER LIFT / DECK LIFT
539 11878320.. ....1 ....CLEVIS PIN
539 11901221.. ....1 ....SPACER
539 12025922.. ....1 ....HAIR PIN COTTER
539 12092123.. ....1 ....GRIP, BRAKE HANDLE
539 12130924.. ....2 ....FEMALE CLEVIS RH
539 12132125.. ....2 ....FEMALE CLEVIS LH
539 12132926.. ....2 ....LIFT SPRING
539 12133327.. ....4 ....CHAIN
539 12133828.. ....2 ....WASHER, .65 x 1¼
539 12155729.. ....2 ....TIE BAR
539 12262730.. ....4 ....CLEVIS PIN ½ x 1½
539 97693431.. ....1 ....HHB 5/16-18 x ¾
539 97693532.. ....3 ....HHB 5/16-18 x 1½
539 97697933.. ....4 ....NUT 3/8-16 HEX NYLOC
539 99018834.. ....1 ....WASHER 5/16 FLAT
539 99025035.. ....6 ....WASHER ½ FLAT NARROW
539 99061336.. ....4 ....NUT 3/8-16 HEX FLANGE
539 99064637.. ....1 ....HHB ½-13 x 1
539 99071738.. ....3 ....NUT 5/16-18 HEX NYLOC

16
1
2
3
4
5
6
78
9
10
13
14
15
16
18
19
20
21
22
23
25
26
27
29
30
31
32
33
34
35
24
17
12
11
6
8
28
11
20
21
27
34" DECK
37
40
35
37
3641
42
44
43
45
39
38
36
34
46 14

17
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
539 1083461.. ....2 ....HHB ½-13 x 2½
539 1095542.. ....1 ....WASHER ½ FLAT
539 1328293.. ....1 ....HINGE, DEFLECTOR
539 1328304.. ....1 ....DEFLECTOR
539 1152205.. ....3 ....BUSHING ½ ID x ¾OD
539 1152786.. ....2 ....IDLER PULLEY
539 1155747.. ....1 ....EYEBOLT
5/16 x 3½
539 1156098.. ....3 ....NUT ½-13 HEX NYLOC
539 1156409.. ....6 ....SCREW ¼-20 x ½
539 11564710.. ....1 ....STUD ½-13 x 2
539 99071711.. ....3 ....NUT 5/16-18 HEX NYLOC
539 99051712.. ....1 ....WASHER 3/8FLAT
539 11594813.. ....1 ....SPACER H.D. PULLEY
539 11601014.. ....1 ....TUBE-.51 x.75 x .63
539 11622515.. ....1 ....DEFLECTOR PIN
539 11635116.. ....1 ....BELT GUARD
539 99031617.. ....2 ....RHSNB 5/16-18 x ¾
539 13283518.. ....1 ....DECK ASSEM W/DECALS
539 11781119.. ....1 ....V-BELT
539 11783820.. ....2 ....BLADE WASHER
539 11783921.. ....2 ....HHB
5/8-18 x 2¼ GR 8
539 11788622.. ....2 ....PULLEY GUARD, 34
539 11788823.. ....1 ....IDLER WELDMENT
539 99025024.. ....2 ....WASHER ½ FLAT NARROW
539 13283125.. ....1 ....DEFLECTOR MNT WLDMT
539 11795526.. ....2 ....SPINDLE ASSEMBLY
539 11803927.. ....2 ....BLADE 34" HI-LIFT
539 99018828.. ....3 ....WASHER 5/16 FLAT
539 12025929.. ....2 ....HAIR PIN COTTER
539 12092030.. ....1 ....SPRING, DECK BELT
539 12147831.. ....1 ....HHB 3/8-16 x 6
539 12257432.. ....1 ....BUSHING
539 12263333.. ....1 ....ROLLER, 3¾
539 97697934.. ....5 ....NUT 3/8-16 HEX NYLOC
539 11796835.. ...1 ...DECK HUB
539 11532636.. ...2 ...HUB PULLEY SPACER
539 11926037.. ...2 ...BEARING - 6305 - 2RS
539 11795438.. ...1 ...TRASH GUARD
539 11795339.. ...1 ...SHAFT, SPINDLE
539 11796940.. ...1 ...SPACER
539 11981141.. ...1 ...TRASH GUARD
539 11926442.. ...1 ...PULLEY
539 11538743.. ...1 ...KEY ¼ x .88
539 11563644.. ...1 ...WASHER, .525 x 1.375 x .25
539 11551145.. ...1 ...HHB ½-20 x 1¼
539 99065546.. ...4 ...HCS 3/8-16 x 1½
539 11563847.. ...1 ...GREASE ZERK
34" DECK

18
5
4
15
8
1
2
3
10
12
14
13
6
3
CONTROLS
7
9
11
3
16

19
ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
539 1100741.. ....1 ....HOUR METER
539 1152082.. ....1 ....BACKING PLATE
539 1156403.. ....4 ....¼-20x½ SCREW
539 1158504.. ....1 ....CIRCUIT BREAKER
539 1324405.. ....1 ....FENDER
539 1319316.. ....1 ....CONTROL PANEL
539 1324437.. ....1 ....DECAL,CONTROL PANEL
539 1032758.. ....1 ....THROTTLE CABLE
539 1075419.. ....1 ....IGNITION SWITCH
CONTROLS
539 10754410.. ....1 ....IGNITION SWITCH KEY
539 10176811.. ....1 ....CLUTCH SWITCH
539 97693412.. ....2 ....5/16-18 x ¾ HHB GR 5
539 97695213.. ....2 ....PAN HD SCR #10-24 x 5/8
539 97697714.. ....2 ....10-24 HEX NUT NYLOC
539 99018815.. ....2 ....5/16 FLAT WASHER
539 12273616.. ....1 ....CHOKE CABLE

20
FUEL SYSTEM
1
8
2
8
5
7
4
3
6
7
