Yealink RoomPanel User manual

RoomPanel
Quick Start Guide (V1.0)
EN / CN / DE / FR / ES

Table of Contents
English..............................................................1
简体中文 .......................................................... 9
Deutsch...........................................................17
Français...........................................................25
Español...........................................................33

1
Package Contents
1
RoomPanel
Security Latch
6-32 x 3/4 in × 6
(For mounting U.S.
electrical box)
M3.5 x 25mm × 4
(For mounting U.K. electrical
box)
φ6 × 30mm × 6
(For mounting bracket)
T4 x 30mm × 6
(For mounting bracket)
M3 x 6mm × 6
(For mounting Metal
Bracket)
Screw Kit
0° Mounting Bracket 20° Mounting Bracket
3M Adhesive Tape × 2
USB-C Port
Protective Cover
Power Adapter
Power Extension Cable
(Optional)
Screwdriver Quick Start Guide
Metal Bracket
Mounting Bracket and Accessory Kit
E
N
G
L
I
S
H
(Default × 1)(Optional × 1)

2
Power Option
Hardware Component Instructions
3
2

①DC Power Option: ②PoE (Power over Ethernet) Option:
Microphone Microphone
Speaker
Internet
port
DC12V
port
Reset
Speaker USB-C
port
E
N
G
L
I
S
H

3
Step 3: Connect the Cable and Install the RoomPanel
Security Latch
RoomPanel
Step 2: Install the Security Latch (Optional)
Install the security latch to the RoomPanel so that it cannot be easily
removed from the mounting bracket after installation.
Installation
4
Step 1: Install the Metal Bracket
Option 1: Mount into the Electrical Box
The RoomPanel installs over a standard 2-gang U.S.electrical box.
2-gang U.S.electrical box
Metal Bracket
Screws:
6-32 x 3/4 in
Keep the facing up.
Attach the metal bracket to the electrical box (as shown in the following
illustrations).
Push the RoomPanel gently into the metal bracket.
E
N
G
L
I
S
H

4
Step 1: Install the Mounting Bracket to the Wall
Option2: Mount on the Wall
This guide mainly takes 0° Mounting Bracket as an example for reference.
116mm
48mm
Keep the facing up.
Screws:
φ6 × 30mm Screws:
T4 x 30mm
Step 2: Route the Ethernet Cable
Step 3: Install the Metal Bracket to the Mounting Bracket
Option 1 Option 2
Keep the facing up.
Screws:
M3 x 6mm
E
N
G
L
I
S
H
E
N
G
L
I
S
H

5
Step 5: Connect the Cable and Install the RoomPanel
Security Latch
RoomPanel
Step 4: Install the Security Latch (Optional)
Install the security latch to the RoomPanel so that it cannot be easily
removed from the mounting bracket after installation.
E
N
G
L
I
S
H

6
Note:
1. Clean the surface of the glass or wood before gluing the 3M tape.
2. Press the 3M tape hard to help improve bond strength between the
glass or wood and the mounting bracket.
3. Wait 1 hour after gluing the mounting bracket and install the RoomPanel
next.
Option 3: Mount on the Glass or Wood
Step 1: Glue the Mounting Bracket to the Glass
Step 2: Route the Ethernet Cable
Option 1 Option 2
Keep the facing up.
3M tape
Glass
A B
This guide mainly takes A3M tape as an example for reference.
Choose A3M tape if you route the cable in the wall, otherwise choose B.
E
N
G
L
I
S
H

7
Security Latch
RoomPanel
Step 4: Install the Security Latch (Optional)
Install the security latch to the RoomPanel so that it cannot be easily
removed from the mounting bracket after installation.
Step 5: Connect the Cable and Install the RoomPanel
Step 3: Install the Metal Bracket to the Mounting Bracket
Keep the facing up.
Screws:
M3 x 6mm
E
N
G
L
I
S
H

8
Remove the RoomPanel
5
1. If the security latch has not be installed you can directly pull the
RoomPanel to disengage the mounting bracket.
2. If the security latch has be installed:
a. Pull the RoomPanel away from the wall until it stops.
b. Use the screwdriver to rotate the latch to the open position, which
retracts the security latch arms.
c. Pull the RoomPanel to disengage it from the mounting bracket with
the arms retracted.
RoomPanel
Mounting
Bracket
Use the screwdriver here
