YELLOWRIVER YR-668B-II User manual

YELLOWRIVER
GuangzhouYellowRiver StageLightingFactory
Moving-headSpotLight
(Model: YR-668B- )
Instruction Book
Please read this manualcarefully
before you use this machine

1
quartzlens
SafetyProtection:cutting the poweroff automaticallywhen the machine is
overheated orthe systemstartstomalfunction
SignalControl: SignalDMX512
Channel: 13DMX channels
Control Channels:
Channel1: color
Channel2: gobo
Channel3: gobo self-rotation
Channel4: dimmer, strobe
Channel5: Pan
Channel6:Tilt
Channel7: prism
Channel8:, prismself-rotation
Channel9: focus
Channel10: Pan/TiltSpeed adjustable
Channel11:Pan 16 bit
Channel12:Tilt 16 bit
Channel13:systemreset
Foryoursafety, pleaseread the manualcarefullybeforeyou usethe
machine.The machine must be installed and repaired bythe technicians.
Attention:
The machine requiresworkinginaproperenvironmentwithtemperature
between 0~35 degreecentigrade.The surfacetemperatureofthe seriesis
between 40~70 degree centigrade.The user,therefore,isstronglyadvisedto
followthe safetyinstructionsand warnings.
Mind you:
Pleasefollowthe instructionsstrictlyinthismanualforthe problems
caused bynot observingthe rulesarebeyond the maintenanceguarantee.
YR-668B II TechnicalData
Working Voltage：AC110V~130V，220V~240V（Optional）
Working Frequency: 50/60HZ
Rated PowerConsumption:650W
Lamp: HMI575W
FlashRate: 1-7flashpersecond
ColorTemperature: 6000K
Color: 7colors+white, rainboweffect, rolling effect
Gobo: 7self-rotating gobos, specialgoboscustomizable
Gobo InwardandOutwardTurningFunction:speedanddirection adjustable,
Electricautomaticfocusof definition forgobo
Scan: Pan 540 º, Tilt250º
OpticalSystem: lenswithlinearadjustablefocaldistance, high-accuracy

2
Functionsand address setofDigital IndicateBoard:
Thiscontroldisplaymenu isspeciallydesignedformulti-typesof
moving-heads.It enablesthe controlmodesofseveralfuntionsand iseasy to
control.The correspondingmenu choiceswill notworkifthereisno motion for
sometypesof moving-heads.
Reposition Function:press the button “down”or “up”.When “rest”showsup,
press “enter”. Reposition isfinished when “rest”comesout.
DMX512(Addressset): thisisforyou tochange the addressnumber., Press
the button “ESC”onceormorethan onceuntil itdisplays “A.001”.Press the
button “enter”,then the word “A”disappearsfollowedbehind 3figures.Use
“up”and “down”toset the addresscodes. Press “enter”.
Self-walkand sound controlset
Press “up”or “down”until itshows “audi”.Press “enter”toshow “off ”or “on”.
Then press “down”or “up”again. Choose “off ”or “on”(“off”isforself-walk. “on”
isforsound control.)Afterfinishing the choice,press “enter”backto “audi”.
Press “down”or “up”toshow “test”.Press “enter”againtoshow “nod.1”.Press
“enter”again, indicating “run”. Then the machine will workasset above(“off”for
self-walkand “on”forsound control.)Whensoundcontrolisinuse,greenled
will flashaccording tothe frequency of the sound control.
Master/slaveIn-phasecontrol
Mainlighting set: Press “down”or “up”toindicate “test”. Press “enter”again
toshow “nod.1”.Press “down”or “up”toshow “nast”.Press “enter”againto
show “off”or “on”.Press “down”or “up”tochoose “off”or “on”with “on”forthe
mainlighting.Then press “enter”backto “nast”.Press “down”or “up”otshow
Installation:
makesurethereisnohighlyflammableand explosiveobjects(decorations)
within0.5mwhileinstalling the machine.
Pleaseensurethe machine isinstalled inalocation withadequateventilation
and no ventilation slotsareblocked.
Pleasekeep the machine awayfromrain,moistureand humidity.Cutoff
powerbeforeopening the outershell.
You onlyneed toopen the back boardtoreplacethe bulb.
Connectthe signalline packed withthe machine tothe controllertoworkthe
machine.
Instructionsforusingthe machine:
Beforeturning onthe machine,pleasecheckifpowerand voltage isnormal.
You areadvisedtouse220Vvoltage regulatortosupplypowerifthe voltage
fluctuatesvastlyinyourarea.
The machine compliestolighting ofthe first-grade protection.Therefore,the
yellowand green line must be correctlyearthed and maintained bytechnicians.
Donot touchthe outershell when the machine isinuse.
Pleaserestartthe machine after20 minutesuntilthe bulbcooled well
becauseit isgasdischarge bulb.
The interiorpartsofthe machine (e.g.trigger) mustbe boughtfromthe
manufacturer.
The powerline shouldbe correctlyearthed.
When using the controller,be surethatthereisnotdisturbing sourcearound
it(e.g. wireless interphone, high-frequencyradiation source)

3
“nod.1”andthen press “enter”toworkthe machine(If the mainlighting isset,
read DMXwill be on.)Ifin-phaseworkingistobe set, the subordinatelighting
mustdisplaying the addresscodes.(If the machine isnotconnected toDMX
controller,the displayscreen will glisten,otherwise,itwill notglisten.And the
DMXsignalindication lightwill glisten duetoavailabilityofsignals.If “on”is
chosen,disconnectDMXcontroller.Onlyone lightcan be settobethemain
light.)The DMXaddress setofthesubordinatelightwill notchange.e.g.The
address code of the subordinatelight can be “001”orotherfigures.
RPAN(PANinverse).Thisenablespan inverse.
Press “up”or “down”toindicate “rpan”.Choose “on”toenablepan inverse.
Press “enter”toconfirmand storethe setting and then exit.
rtilt(tiltinverse).Thisenablestilt inverse.
Press “up”or “down”toindicate “rtilt”.Choose “on”toenabletiltinverse.
Press “enter”toconfirmand storethe setting and then exit.
Working mode:
Press “down”or “up”toshow “dn.pr”.Then press “enter”toshow “nod.1”or
“nod.2”.Then press “enter”tofinishthe setting. “nod.1”and “nod.2”arethe
twoworking modes.( “nod.1”isforthe controlwithchannelsofregualrnumber
and “nod.2”isforthe controlof fewerchannels.)
Wereserverighttochangethemanualwithoutfurthernotice.
