YitaHome FTPLWP-0005 User manual

ASSEMBLY INSTRUCTIONS
Pure & Easy
POND FOUNTAIN
CONTACT US:
,
󾋸󾋿󾋿󾋿󾋾󾋸󾋾󾋿󾋷󾋿󾋻󾋿󾋷󾋷󾋻󾋺󾋷󾋿󾋷󾋷󾋸󾋹󾋷󾋷


󾋸
󾋹“”󽦁
󾋺“”
FTPLWP-0005
FTPLWP-0006
FTPLWP-0007
FTPLWP-0008
SHYKB-V1

ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
1 2
DO NOT PUT NEAR FLAME.
CHILDREN UNDER THE AGE OF 16 SHOULD USE
THIS PRODUCT UNDER ADULT SURERVISION.
Thank you for buying this product. For an excellent user experience,
please install according to these instructions and give to appropriate
person for retention and future reference.
Waterproof rubber ring
Note:
This is just a brief installation,customers should prepare different necessary
accessories before installment,for example,a suitable water pump and water pipe.
Contents:
1× Main waterfall blade
1× LED light bar (waterproof)
1× Transformer
1 x Controller
1 x Remote control
1 x PVC Joint for one water inlet (L30cm,L45cm)
2×PVC Joint for two water inlet(L60CM,L90CM,L120CM,L150CM)
Features:
1. Different models & sizes available for different water effects
2. LED is powered by external 12V DC, which is safe and reliable
3.17 lighting patterns are available
4. Led light strip and waterfall is parted, but can connect easily.
Safety Instructions:
FAILURE TO FOLLOW THESE SAFETY INSTRUCTIONS MAY RESULTI NSERIOUS
INJURYOR ORDAMAGE.
*Proper and complete assembly and operation is essential to reduce the risk of injury.
*2 people are required for assembly.
*If technical assistance is required,contact to your point of sale.
*To clean the product, always use adry and soft fabrics. Do not use paint, organic
solvent, or chemically impregnated fabrics.
*Always turn off the products when not in use or cleaning.
LED LIGHT
WATER PUMP
WATER PUMP
LED LIGHT

ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
3 4
1.Turn On/Standby
Press this key to turn on unit or switch to standby mode. At power on, unit will automaticly turn
on and restore to previous status.
2/9.Dynamic Mode Adjust
Switch to dynamic mode from static color, or switch between dynamic modes.
3/10.Dynamic Speed Adjust
Adjust dynamic playing speed.Press SPEED+ to increase speed and press SPEED-to decrease.
Unit will switch to dynamic mode lf press this key at static color mode.
4/5.Static Color Adjust
Switch to static color mode from dynamic mode,or switch between static colors.
6.Direct Color Select
Shortcut key to static colors. When press the specific color key,LED will play the same static color.
The direct colors are included in 'COLOR+' and "COLOR-' operation.
7/8.Brightness Adjust
Adjust static color brightness. Press BRIGHT+ to increase brightness and press BRIGHT-to decrease.
Unit will switch to static color mode If press this key at dynamic mode.
11.Demo Mode
Press this key will switch to Demo mode.At demo mode,it plays 17 dynamic modes in loop,each
mode repeat 3 times.
1.Power Supply
This unit accepts DC 5V to 24V power supply. The DC xjack's inner pole (or red cable) is
positive and sleeve (or black cable)is negative. Also please make sure the power supply voltage is
same as the LED load.
2.LED Output
This unit support common anode connection LED products. The mark ' ' indicates the common
connection node.
The peak output current is 4 amperes and maximum constant current is 2 amperes per channel.
Please reduce load if main unit is overheating.
CAUTION! Do not short circuit or overload the LED outputs, this may lead to permanent damage!
Installing
Operation
1. Using Remote Controller
Please pull out the battery insulate tape before using. The RF wireless remote signal can pass
through barrier, so it's not necessary to aim at the main unit when operate.
For proper receiving remote signal, please do not install the main unit in closed metal parts.

ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
5 6
2.Pairing New Remote
The remote and main unit is 1 to 1 paired as default. Further more, main unit can be paired to 3
remote controllers and each remote controller can be paired to any main unit. Please do
following steps to pair new remote controller:
1).Plug off the power of main unit and plug in after 5 seconds.
2).Press 'SPEED-' and 'SPEED+' key together in 5 seconds after power on.
After this operation, the main unit will recognize the new remote controller.
3.Free Remote Pairing Mode
In some specific cases; the main unit may need to be paired to any remote controllers.Please do
following steps for free remote pairing mode:
1).Plug off the power of main unit and plug in after S seconds.
2).Press 'ON/OFF' and 'MODE+'key together in 5 seconds after power on.
After this operation, the main unit will recognize any remote controller. To pair the main unit
back to specific remote, please repeat the 'Pairing New Remote' operation.
4.Switch Output Color Sequence
The controller's default output signal sequence is
Common-Green-Red-Blue. If the LED application is in different cable sequence,the direct color
keys will not match the LED color. In this case, user can adjust the output signal sequence with
following steps:
1).Plug off the power of main unit and plug in after 5 seconds.
2).Press'RED'and'BLUE'color key together in 5 seconds after power on.
With this operation,the output sequence will switch between 6 possible combinations. The
sequence will be memorized and it won't change before next same operation.
