1. Introduction
The Yocto-RangeFinder is a 58x20mm module enabling you to detect the presence of objects up to
one or two meters away depending on conditions, and to evaluate the distance of the closest object.
This module is based on a "ToF" (Time of Light) technology. The sensor emits laser pulses and
measures the time they take to come back to the sensor after reflection against an obstacle. The
Yocto-RangeFinder can also measure its own temperature, in order to determine when a new
calibration is required, and estimate the ambient light.
This small and relatively cheap module, using a quite harmless laser, does not pretend to be a true
telemeter that you could use to measures distances with a millimeter accuracy. Its accuracy is
limited, and the detection range depends on the environment. You can find tables describing the
expected accuracy depending on the surrounding conditions in the section called Working principles
and limitations of this user's guide.
The Yocto-RangeFinder module
The Yocto-RangeFinder is intended to be used as laboratory equipment, or as industrial process-
control equipment, but also for similar applications in domestic and commercial environments 1.
Yoctopuce thanks you for buying this Yocto-RangeFinder and sincerely hopes that you will be
satisfied with it. The Yoctopuce engineers have put a large amount of effort to ensure that your
Yocto-RangeFinder is easy to install anywhere and easy to drive from a maximum of programming
languages. If you are nevertheless disappointed with this module, do not hesitate to contact
Yoctopuce support2.
1 i.e. the scope of IEC 61010-1:2010 international standard
2 [email protected]
www.yoctopuce.com 1

1.1. Safety Information
Caution: The Yocto-RangeFinder is not certified for use in hazardous locations,
explosive environments, or life-threatening applications.
Caution: The Yocto-RangeFinder is not certified for use in medical
environments or life-support applications.
1. Introduction
2 www.yoctopuce.com

2. Presentation
1: Micro-B USB socket 5: ToF Laser sensor
2: Yocto-button 6: Temperature sensor
3: Yocto-led 7: Pad for Picoflex connector
4: Detection led
2.1. Common elements
All Yocto-modules share a number of common functionalities.
USB connector
Yoctopuce modules all come with a micro-B USB socket. The corresponding cables are not the most
common, but the sockets are the smallest available.
Warning: the USB connector is simply soldered in surface and can be pulled out if the USB plug acts
as a lever. In this case, if the tracks stayed in position, the connector can be soldered back with a
good iron and using flux to avoid bridges. Alternatively, you can solder a USB cable directly in the
1.27mm-spaced holes near the connector.
Yocto-button
The Yocto-button has two functionalities. First, it can activate the Yocto-beacon mode (see below
under Yocto-led). Second, if you plug in a Yocto-module while keeping this button pressed, you can
www.yoctopuce.com 3

then reprogram its firmware with a new version. Note that there is a simpler UI-based method to
update the firmware, but this one works even in case of severely damaged firmware.
Yocto-led
Normally, the Yocto-led is used to indicate that the module is working smoothly. The Yocto-led then
emits a low blue light which varies slowly, mimicking breathing. The Yocto-led stops breathing when
the module is not communicating any more, as for instance when powered by a USB hub which is
disconnected from any active computer.
When you press the Yocto-button, the Yocto-led switches to Yocto-beacon mode. It starts flashing
faster with a stronger light, in order to facilitate the localization of a module when you have several
identical ones. It is indeed possible to trigger off the Yocto-beacon by software, as it is possible to
detect by software that a Yocto-beacon is on.
The Yocto-led has a third functionality, which is less pleasant: when the internal software which
controls the module encounters a fatal error, the Yocto-led starts emitting an SOS in morse 1. If this
happens, unplug and re-plug the module. If it happens again, check that the module contains the
latest version of the firmware, and, if it is the case, contact Yoctopuce support2.
Current sensor
Each Yocto-module is able to measure its own current consumption on the USB bus. Current supply
on a USB bus being quite critical, this functionality can be of great help. You can only view the
current consumption of a module by software.
Serial number
Each Yocto-module has a unique serial number assigned to it at the factory. For Yocto-RangeFinder
modules, this number starts with YRNGFND1. The module can be software driven using this serial
number. The serial number cannot be modified.
Logical name
The logical name is similar to the serial number: it is a supposedly unique character string which
allows you to reference your module by software. However, in the opposite of the serial number, the
logical name can be modified at will. The benefit is to enable you to build several copies of the same
project without needing to modify the driving software. You only need to program the same logical
name in each copy. Warning: the behavior of a project becomes unpredictable when it contains
several modules with the same logical name and when the driving software tries to access one of
these modules through its logical name. When leaving the factory, modules do not have an assigned
logical name. It is yours to define.
2.2. Specific elements
The sensor
The Yocto-RangeFinder is based on a VL53L0X sensor manufactured by ST Microelectronics. It
contains a laser coupled to an infrared light detector. This laser is conformed to the "LASER CLASS
1" security limits and does not present any particular danger, as long as its normal beam is not
altered, either by optical devices or otherwise. This sensor does not require any specific
maintenance, but make sure that it stays clean.
The detection led
The detection led signals when the Yocto-RangeFinder has detected an object less than one meter
away.
1 short-short-short long-long-long short-short-short
2 [email protected]
2. Presentation
4 www.yoctopuce.com

2.3. Optional accessories
The accessories below are not necessary to use the Yocto-RangeFinder module but might be useful
depending on your project. These are mostly common products that you can buy from your favorite
hacking store. To save you the tedious job of looking for them, most of them are also available on the
Yoctopuce shop.
Screws and spacers
In order to mount the Yocto-RangeFinder module, you can put small screws in the 2.5mm assembly
holes, with a screw head no larger than 4.5mm. The best way is to use threaded spacers, which you
can then mount wherever you want. You can find more details on this topic in the chapter about
assembly and connections.
Micro-USB hub
If you intend to put several Yoctopuce modules in a very small space, you can connect them directly
to a micro-USB hub. Yoctopuce builds a USB hub particularly small for this purpose (down to
20mmx36mm), on which you can directly solder a USB cable instead of using a USB plug. For more
details, see the micro-USB hub information sheet.
YoctoHub-Ethernet, YoctoHub-Wireless and YoctoHub-GSM
You can add network connectivity to your Yocto-RangeFinder, thanks to the YoctoHub-Ethernet, the
YoctoHub-Wireless and the YoctoHub-GSM which provides repectiveley Ethernet, WiFi and GSM
connectivity. All of them can drive up to three devices and behave exactly like a regular computer
running a VirtualHub.
1.27mm (or 1.25mm) connectors
In case you wish to connect your Yocto-RangeFinder to a Micro-hub USB or a YoctoHub without
using a bulky USB connector, you can use the four 1.27mm pads just behind the USB connector.
There are two options.
You can mount the Yocto-RangeFinder directly on the hub using screw and spacers, and connect it
using 1.27mm board-to-board connectors. To prevent shortcuts, it is best to solder the female
connector on the hub and the male connector on the Yocto-RangeFinder.
You can also use a small 4-wires cable with a 1.27mm connector. 1.25mm works as well, it does not
make a difference for 4 pins. This makes it possible to move the device a few inches away. Don't put
it too far away if you use that type of cable, because as the cable is not shielded, it may cause
undesirable electromagnetic emissions.
Enclosure
Your Yocto-RangeFinder has been designed to be installed as is in your project. Nevertheless,
Yoctopuce sells enclosures specifically designed for Yoctopuce devices. These enclosures have
removable mounting brackets and magnets allowing them to stick on ferromagnetic surfaces. More
details are available on the Yoctopuce web site 3. The suggested enclosure model for your Yocto-
RangeFinder is the $SPECBOX$.
3 http://www.yoctopuce.com/EN/products/category/enclosures
2. Presentation
www.yoctopuce.com 5

You can install your Yocto-RangeFinder in an optional enclosure
Picoflex connectors and flexible ribbon cable
If you intend to move the sensor away from the Yocto-RangeFinder module using a pluggable cable,
you will need 4-wire ribbon cable of 1.27mm pitch, and Picoflex connectors.4You can find more
details on this topic in the chapter about assembly and connections.
4 Header Molex ref 90325-3004 or 90325-0004, available from most electronic components suppliers (www.mouser.com,
www.digikey.com, www.farnell.com, www.distrelec.ch...). To be used with connectors ref 90327-3304 or 90327-0304.
2. Presentation
6 www.yoctopuce.com

3. Working principle and limitations
The Yocto-RangeFinder emits laser pulses and measures the time that they take to come back to the
sensor after their reflection against an obstacle. Time intervals for such a measure are so short that
the sensor uses indirect physical principles to evaluate them. Therefore, a number of external
perturbations can hinder the measure.
3.1. Ambient light
As long as it does not hide the reflection of the emitted laser pulses, the ambient light does not
perturb the workings of the sensor. But naturally, the infrared laser reflection in a bright outside
environment is much harder to detect than reflection in an inside environment that is poor in infrared.
Generally speaking, the maximal detection distance is reduced by a factor of two outside (sunlight
about 5000 lux), and accuracy is reduced by half. If the infrared sensor is saturated by a strong
radiation, the measure can even prove impossible.
3.2. Color and reflectivity of the detected objects
The sensor is designed to estimate the distance of objects independently from their color and their
reflectivity. However, these parameters have an influence on the quantity of reflected light, and
therefore on the maximal detection range and on the accuracy. A light object (white 88%) is typically
detected at a distance almost twice as far as a dark object (gray 17%), and with a twice as good an
accuracy.
3.3. Workings behind a protective glass
Even if it is transparent to infrared light, a protection glass necessarily creates glints which interferes
with the measure. In presence of glints, the sensor is faced with two simultaneous reflections to be
measured: an intentional reflection, and a parasitic reflection. It is unfortunately impossible to directly
filter the parasitic reflection. However, you can counter the measure bias that it introduces through a
material calibration of the sensor. Its process is described below.
Even if you perform the calibration with the greatest care, it cannot do anything against the fact the
radiations reflected against the glass are not going to reach the object of which you want to measure
the distance. The presence of glass has therefore also as side effect to decrease the maximal
detection distance and the measure accuracy. To limit this negative effect, you must absolutely use
the thinnest and the most transparent glass possible, and above all to press it against the sensor.
The more space between the sensor and the glass, the more the reflections hinder the measure.
www.yoctopuce.com 7

3.4. Working modes
Depending on its use, you can configure the Yocto-RangeFinder to maximize accuracy (by
measuring on a longer period), the maximal distance (by increasing sensitivity to low reflections), or
the measure frequency. The default behavior is a compromise that you can use for standard
applications. Here is an estimate of expected sensor performances, in its different working modes:
Default mode characteristics
Measuring frequency: about 25 Hz
Maximal detection distance: 1.2m (inside, white target)
Expected accuracy:
Conditions Distance Standard deviation
Light target, inside 120cm 4%
Dark target, inside 70cm 7%
Light target, outside 60cm 7%
Dark target, outside 40cm 12%
High accuracy mode characteristics
Measuring frequency: about 5 Hz
Maximal detection distance: 1.2m (inside, white target)
Expected accuracy: < 3%
Long distance mode characteristics
Measuring frequency: about 25 Hz
Maximal detection distance: 2m (inside, white target)
Expected accuracy:
Conditions Distance Standard deviation
Light target inside 200cm 6%
Dark target inside 70cm 7%
High frequency mode characteristics
Measuring frequency: 30 Hz
Maximal detection distance: 1.2m (inside, white target)
Expected accuracy: 5%
3.5. Temperature variations
The distance sensor uses a detection principle which is sensitive to the temperature. You can
counter this sensitivity with a simple automatic sensor re-calibration process, which does not require
any external intervention. In order to avoid perturbing measure linearity, the Yocto-RangeFinder does
not trigger this calibration automatically. It is equipped with a temperature sensor which allows you to
decide when to trigger this calibration when the temperature difference since the latest calibration
reaches 8 degrees Celsius.
The next section describes using hardware calibration procedures.
3.6. Hardware calibration procedures
Calibration procedures described in the following paragraphs are specific to the VL53L0CXV0DH/1
sensor in the Yocto-RangeFinder and act directly on its detection principle. You must not mistake
3. Working principle and limitations
8 www.yoctopuce.com

them with software calibration which you can perform a posteriori on the measures of all Yoctopuce
sensors.
Calibration for temperature variations
To ensure proper operation of the sensor, you must run an automatic calibration process when the
temperature varies of more than 8°C. The Yocto-RangeFinder includes a temperature sensor located
right next to the distance sensor, allowing you to detect temperature variations and to run this
calibration if needed.
To know the current temperature, you must call the get_currentTemperature() method. To
know the latest calibration temperature, you must call the
get_hardwareCalibrationTemperature() method. When the two are too far apart, you
must call the triggerTemperatureCalibration() method:
YRangeFinder rf = YRangeFinder.FirstRangeFinder();
Double currTemp = rf.get_currentTemperature();
Double calibTemp = rf.get_hardwareCalibrationTemperature();
if (Math.abs(currTemp - calibTemp)> 8.0){
rf.triggerTemperatureCalibration();
}
You do not need to put a target in front of the sensor to perform a temperature calibration.
Calibration to compensate reflections on a protection glass
Reflections caused by a protection glass introduce several types of biases in the measure. They can
be compensated only in applying the calibration procedures described below, in the given order.
These calibrations do not need to be repeated as long as the glass does not change position (this
calibration is relatively stable with regards to external conditions). But do not forget that even the best
calibration cannot compensate a too low signal/noise ratio. It is therefore critical to reduce as much
as possible the distance between the glass and the sensor, and to use the most transparent and
thinnest glass possible.
Before you start the calibration process, start by asserting that the sensor receives enough signal to
work. Even without calibration, at a relatively short distance, the sensor should be able to correctly
detect an object. If it is not the case, it means that the signal is too perturbed and you must either
move the glass closer to the sensor, or use a thinner glass, or most likely both. In good conditions,
the value measured by the sensor compared to the actual distance should conform to the following
graph:
The effect of an intervening glass on the distance measure, without calibration
Note the three areas of this graph: in the area close to the sensor, the measured value varies in
parallel to the distance of the object. In the median area, the measured value keeps on growing with
the distance, but the actual distance is more and more under-estimated. In the most distant area, the
measured value decreases, so that it is in no case possible to measure a distance, even after
calibration.
3. Working principle and limitations
www.yoctopuce.com 9

As a calibration target, we used the JJC GC-3 color balance card deck.
Phase 1: photon detector calibration
The aim of this calibration is to measure the level of ambient light (behind the glass), without any
particular reflection. Do not put the target directly against the glass for this calibration, nor any
specific light source.
To run the calibration, call the triggerSpadCalibration() method.
This calibration is almost instantaneous.
Phase 2: offset calibration
The aim of this calibration is to correct the measure offset (fixed offset) introduced by the laser going
through the glass. This calibration must be performed with a white target, positioned at a known
distance from the sensor, close enough from the sensor (linear area), ideally at about 100mm if the
glass allows it. We recommend that you redo a temperature calibration right before running an offset
calibration.
To run the calibration , call the triggerOffsetCalibration() method, giving as parameter
the distance of the target in millimeters or in inches, depending on the module configuration.
This calibration takes about half a second.
Phase 3: cross-talk calibration
The aim of this calibration is to correct the non-linearity introduced in the measure because of the
interferences between reflections against the glass and reflections against the measured object.
Ideally, this calibration must be performed with a gray target, positioned at a known distance from the
sensor, in the measure area where the interference effect is the strongest, that is at 80% to 90% of
the maximal measurable distance.
To run this calibration, call the triggerXTalkCalibration() method, and pass as parameters
the distance of the target in millimeters or in inches, depending on the module configuration.
This calibration may take 5 to 10 seconds. The detection led blinks during calibration.
Phase 4: testing et saving the results
When calibration has been performed, the module should provide correct measures, independently
of the color of the object, as long as it is detected. If it is not the case, it is probably because
calibration did not occur in good distance conditions. In this case you must determine usable
distances with the selected glass again, drawing the measured distance graph (without calibration)
depending on the actual distance of a target.
For the result of calibration to be kept after the module restarts, you must save the computed
parameters in the Yocto-RangeFinder flash memory. To do so, you must call the module
saveToFlash() method.
YRangeFinder rf = YRangeFinder.FirstRangeFinder();
rf.get_module().saveToFlash();
Calibrating with the command line library
If you want to perform calibration once and for all, without writing you own piece of code, you can use
our command line library, which you can download from www.yoctopuce.com in the Support section.
The corresponding commands are the following, naturally in positioning the corresponding targets
and in replacing distances depending on the target actual positions:
YRangeFinder any triggerSpadCalibration
YRangeFinder any triggerTemperatureCalibration
YRangeFinder any triggerOffsetCalibration 100
YRangeFinder any triggerXTalkCalibration 700
3. Working principle and limitations
10 www.yoctopuce.com

To check the current measure:
YRangeFinder any get_currentValue
And to save the current calibration in the module flash memory, add -s in any command, for example:
YRangeFinder -s any get_currentValue
3. Working principle and limitations
www.yoctopuce.com 11

12 www.yoctopuce.com

4. First steps
By design, all Yoctopuce modules are driven the same way. Therefore, user's guides for all the
modules of the range are very similar. If you have already carefully read through the user's guide of
another Yoctopuce module, you can jump directly to the description of the module functions.
4.1. Prerequisites
In order to use your Yocto-RangeFinder module, you should have the following items at hand.
A computer
Yoctopuce modules are intended to be driven by a computer (or possibly an embedded
microprocessor). You will write the control software yourself, according to your needs, using the
information provided in this manual.
Yoctopuce provides software libraries to drive its modules for the following operating systems:
Windows, Mac OS X, Linux, and Android. Yoctopuce modules do not require installing any specific
system driver, as they leverage the standard HID driver1provided with every operating system.
Windows versions currently supported are: Windows XP, Windows 2003, Windows Vista, Windows
7, Windows 8 and Windows 10. Both 32 bit and 64 bit versions are supported. Yoctopuce is
frequently testing its modules on Windows 7 and Windows 10.
Mac OS X versions currently supported are: 10.9 (Maverick), 10.10 (Yosemite), 10.11 (El Capitan)
and 10.12 (Sierra). Yoctopuce is frequently testing its modules on Mac OS X 10.11.
Linux kernels currently supported are the 2.6 branch, the 3.0 branch and the 4.0 branch. Other
versions of the Linux kernel, and even other UNIX variants, are very likely to work as well, as Linux
support is implemented through the standard libusb API. Yoctopuce is frequently testing its modules
on Linux kernel 3.19.
Android versions currently supported are: Android 3.1 and later. Moreover, it is necessary for the
tablet or phone to support the Host USB mode. Yoctopuce is frequently testing its modules on
Android 4.x on a Nexus 7 and a Samsung Galaxy S3 with the Java for Android library.
A USB cable, type A-micro B
USB connectors exist in three sizes: the "standard" size that you probably use to connect your
printer, the very common mini size to connect small devices, and finally the micro size often used to
1 The HID driver is the one that takes care of the mouse, the keyboard, etc.
www.yoctopuce.com 13

connect mobile phones, as long as they do not exhibit an apple logo. All USB modules manufactured
by Yoctopuce use micro size connectors.
The most common USB 2 connectors: A, B, Mini B, Micro A, Micro B.2
To connect your Yocto-RangeFinder module to a computer, you need a USB cable of type A-micro
B. The price of this cable may vary a lot depending on the source, look for it under the name USB A
to micro B Data cable. Make sure not to buy a simple USB charging cable without data connectivity.
The correct type of cable is available on the Yoctopuce shop.
You must plug in your Yocto-RangeFinder module with a USB cable of type A - micro B.
If you insert a USB hub between the computer and the Yocto-RangeFinder module, make sure to
take into account the USB current limits. If you do not, be prepared to face unstable behaviors and
unpredictable failures. You can find more details on this topic in the chapter about assembly and
connections.
4.2. Testing USB connectivity
At this point, your Yocto-RangeFinder should be connected to your computer, which should have
recognized it. It is time to make it work.
Go to the Yoctopuce web site and download the Virtual Hub software3. It is available for Windows,
Linux, and Mac OS X. Normally, the Virtual Hub software serves as an abstraction layer for
languages which cannot access the hardware layers of your computer. However, it also offers a
succinct interface to configure your modules and to test their basic functions. You access this
interface with a simple web browser4. Start the Virtual Hub software in a command line, open your
preferred web browser and enter the URL http://127.0.0.1:4444. The list of the Yoctopuce modules
connected to your computer is displayed.
2 Although they existed for some time, Mini A connectors are not available anymore http://www.usb.org/developers/
Deprecation_Announcement_052507.pdf
3 www.yoctopuce.com/EN/virtualhub.php
4 The interface is tested on Chrome, FireFox, Safari, Edge et IE 11.
4. First steps
14 www.yoctopuce.com
