Yolink YL-11 User manual

Note: Please read this manual carefully before using the product and
properly keep. Children are not allowed to use this product.

Welcome
Phone Holder can be installed on the handlebars and fit for
almost any vehicle on the market, such as motorcycle,
mountain bike (MTB), e-bike, folding bike, scooter and etc.
Phone size requirement: 60-88 mm (4-7.2 inch) screen,
thickness of not more than 10 mm(0.4 inch).

Components
Adjusting Knob Plum Blossom Knob Pad
Body Connecting Buckle Screw

Install
Before installation, please make sure the vehicle is off and
parking on the center stand.
1. Take off the plum blossom knob.
2. Mount the connecting buckle on the body, then rotate
plum blossom knob to tighten.

3. As show in the image below, mount the phone holder on
the handlebar by fixating the buckle (Pay attention to
installation direction).
The rubber pad should be installed in the buckle for use if the
handlebar diameter is about 22.2 mm(0.87 inch).
Pad Buckle

4. Find to the proper position and angle, then tighten the
locking screw with your fingers.
5. You can adjust the angle by loosening plum blossom knob.

6. Loose the adjusting knob, put in the phone, then tighten
the knob.

Precautions
1. Before installation, please make sure the vehicle is off and
parking on the center stand.
2. The rubber pad should be required for the buckle when
mounted on the 22.2 mm(0.87 inch) handlebar, while no
rubber pad is required on the 31.8 mm(1.25 inch) handlebar.
3. To avoid accidents, do not use the phone when riding.
Production Information
Product: Phone Holder
Model: YL-11
Dimensions: 80 × 150 × 77 mm(3.1 × 5.9 × 3.0 inches)
Weight: About 175 g (6.2 ounces)
Materials: Aluminum Alloy & PA66 & TPU & TPE
Color: Gray

Warranty & Customer Support
If you have any questions with the product, please contact us
and we will solve it for you as soon as possible.
