York PT8DH Quick start guide

TECHNICAL GUIDE
AFFINITY
MODELS: PT8*DH
GAS-FIRED
HIGH EFFICIENCY TWO STAGE
DOWNFLOW/HORIZONTAL FURNACES
STANDARD & Low NOx
NATURAL GAS
40 - 120 MBH INPUT
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at www.york.com for the most
up-to-date technical information.
Additional rating information can be found at
www.gamanet.org.
EFFICIENCY
RATING
CERTIFIED
ISO 9001
Certified Quality
Management System
246796-YTG-D-0407
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
These high efficiency, compact units employ induced com-
bustion, reliable hot surface ignition and high heat transfer
tubular heat exchangers. The units are factory shipped for
installation in downflow or horizontal applications.
These furnaces are designed for residential installation in a
basement, closet, alcove, attic, recreation room or garage
and are also ideal for commercial applications. All units are
factory assembled, wired and tested to assure safe depend-
able and economical installation and operation.
These units are Category I listed and may be common
vented with another gas appliance as allowed by the
National Fuel Gas Code ANSI Z223.1 (latest edition).
WARRANTY
20-year limited warranty on the heat exchanger.
10-year heat exchanger warranty on commercial applica-
tions.
5-year limited parts warranty.
FEATURES
• Two stage heating operation includes:
- Two stage gas valve
- Two stage inducer operation
This provides both increased comfort level and very
quiet unit operation
• Delay timer allows two stage operation with single stage
thermostat
• Acoustically insulated blower compartment for reduced
blower sound level
• Humidifier and Electronic Air Cleaner control wires are
provided to the power wiring box for easy field connec-
tion.
• 100% shut off main gas valve for added safety
• Rollout safety control
• Low unit amp requirement for easy replacement appli-
cation
• High quality two speed inducer motor for quiet operation
• Built-in self diagnostics with fault code display
• 40 VA control transformer fuse protected
• Cooling relay supplied for easy installation of add-on
cooling
• Multi-speed PSC, direct-drive blower motor to match
cooling requirements
• Adjustable fan-off settings to eliminate "cold-blow"
• Compact 40-in. height allows installation in small space
confines
• All models are propane convertible
• Low NOx models have been designed to meet specific
code requirements.
• Low NOx models may not be converted to propane
unless screens are removed.

246796-YTG-D-0407
2Unitary Products Group
Wire size and over current protection must comply with the National Electrical Code (NFPA-70-latest edition) and all local codes.
The furnace shall be installed so that the electrical components are protected from water.
Annual Fuel Utilization Efficiency (AFUE) numbers are determined in accordance with DOE Test procedures.
FRONT
A
B
40
3/4
LEFT SIDE RIGHT SIDE
FRONT FRONT
BOTTOM IMAGE
TOP IMAGE
20
28-1/2
1-1/4
7-1/4
A
C
20
1-1/4
T’STAT
WIRING
7/8” K.O.
GAS INLET
1-1/4” X 2-1/2”
ALT. GAS INLET
1-1/4” X 2-1/2”
(VENT CONNECTION)
30-1/8
5
20
B
D
3-3/4
4” DIAMETER
POWER
WIRING
7/8 K.O.
4” DIA. VENT
CONNECTION
5/8”
5/8”
T’STAT
WIRING
7/8” K.O.
CABINET AND DUCT DIMENSIONS
MODEL Airflow
CFM Cabinet Size CABINET DIMENSION
A(in.) B(in.) C(in.) D(in.)
PT8A12(N,L)040DH11 1200 A 14 1/2 13 1/4 12 10 3/8
PT8A12(N,L)060DH11 1200 A 14 1/2 13 1/4 12 10 3/8
PT8A12(N,L)080DH11 1200 A 14 1/2 13 1/4 12 10 3/8
PT8B16(N,L)080DH11 1600 B 17 1/2 16 1/4 15 11 3/4
PT8C16(N,L)080DH11 1600 C 21 19 3/4 18 1/2 13 1/2
PT8B12(N,L)100DH11 1200 B 17 1/2 16 1/4 15 11 3/4
PT8C16(N,L)100DH11 1600 C 21 19 3/4 18 1/2 13 1/2
PT8C20(N,L)120DH11 2000 C 21 19 3/4 18 1/2 13 1/2
RATINGS & PHYSICAL / ELECTRICAL DATA
MODEL Input
High/Low Output BTU/H High/Low Nominal Airflow Cabinet Width AFUE Blower Blower Size
MBH MBH CFM In Hp Amps In
PT8A12(N,L)040DH11 57/42 46/34 1200 14-1/2 80.0 1/2 7.7 10 x 8
PT8A12(N,L)060DH11 80/59 64/48 1200 14 1/2 80.0 1/2 7.7 10 x 8
PT8A12(N,L)080DH11 80/59 64/48 1600 17-1/2 80.0 3/4 9.6 10 x 10
PT8B16(N,L)080DH11 80/59 64/48 1600 21 80.0 3/4 9.6 10 x 10
PT8C16(N,L)080DH11 100/65 80/53 1600 17 1/2 80.0 3/4 9.6 10 x 10
PT8B12(N,L)100DH11 100/65 80/53 1600 21 80.0 3/4 9.6 10 x 10
PT8C16(N,L)100DH11 100/65 80/53 2000 21 80.0 1 12.8 11 x 10
PT8C20(N,L)120DH11 120/78 96/64 2000 21 80.0 1 12.8 11 x 10
MODEL Input/Cabinet
High/Low Max. Outlet Air Temp Low Fire Air Temp. Rise High Fire Air Temp. Rise Unit
Amps
Max
Over-Current
Protect
Min. wire Size
(awg) @ 75 ft
one way
Operation
Weight
MBH °F °F °F Lbs
PT8A12(N,L)040DH11 57/42 165 25-55 35-65 9.0 20 14 107
PT8A12(N,L)060DH11 80/52 170 40-70 40-70 9.0 20 14 117
PT8A12(N,L)080DH11 80/59 155 25-55 25-55 12.0 20 14 129
PT8B16(N,L)080DH11 80/59 155 25-55 25-55 12.0 20 14 140
PT8C16(N,L)080DH11 100/65 170 40-70 40-70 12.0 20 14 128
PT8B12(N,L)100DH11 100/65 170 40-70 40-70 12.0 20 14 140
PT8C16(N,L)100DH11 100/65 170 40-70 40-70 14.0 20 12 145
PT8C20(N,L)120DH11 120/78 165 35-65 35-65 14.0 20 12 147

246796-YTG-D-0407
Unitary Products Group 3
NOTES:
1. Airflow expressed in standard cubic feet per minute (CFM).
2. Motor voltage at 115 V.
BLOWER PERFORMANCE CFM - (WITHOUT FILTER)
MODELS Speed
Airflow Data
Ext. Static Pressure
0.10.20.30.40.50.60.70.80.91.0
PT8A12(N,L)040DH11
High 1620 1590 1480 1400 1310 1240 1140 1040 910 760
Medium High 1430 1390 1340 1280 1220 1140 1050 960 820 710
Medium Low 1210 1210 1190 1200 1100 1020 940 850 730 620
Low 980 980 970 950 920 870 810 720 620 520
PT8A12(N,L)060DH11
High 1500 1470 1390 1320 1240 1170 1070 960 830 700
Medium High 1380 1340 1280 1210 1150 1060 970 870 760 610
Medium Low 1220 1200 1160 1110 1050 990 910 820 700 600
Low 960 950 940 920 890 840 770 710 630 530
PT8A12(N,L)080DH11
High 1550 1480 1410 1330 1250 1150 1050 940 810 700
Medium High 1400 1360 1290 1220 1150 1060 970 860 730 590
Medium Low 1230 1210 1170 1120 1060 990 910 810 680 560
Low 980 970 960 930 890 830 760 680 550 450
PT8B16(N,L)080DH11 High 2070 2000 1930 1850 1770 1670 1580 1470 1360 1250 Medium 1650 1630 1610 1560 1490 1420 1360 1270 1170 1040
Low 1410 1400 1370 1340 1320 1270 1210 1140 1050 950
PT8C16(N,L)080DH11 High 1895 1812 1736 1624 1544 1437 1311 1153 1032 836
Medium 1726 1645 1581 1491 1412 1311 1192 1049 908 750
Low 1561 1493 1430 1373 1304 1199 1089 967 816 699
PT8B12(N,L)100DH11
High 1710 1650 1580 1510 1420 1330 1260 1160 1090 930
Medium High 1480 1440 1380 1330 1270 1180 1090 980 790 630
Medium Low 1240 1230 1200 1170 1110 1030 950 850 710 600
Low 980 980 980 970 930 890 800 720 630 530
PT8C16(N,L)100DH11 High 2210 2160 2100 2030 1940 1850 1750 1640 1520 1400
Medium 1640 1640 1620 1590 1530 1500 1430 1360 1270 1160
Low 1410 1410 1370 1360 1300 1260 1210 1150 1090 1010
PT8C20(N,L)120DH11
High 2400 2310 2220 2120 2010 1910 1800 1660 1520 1350
Medium High 2090 2030 1970 1880 1790 1730 1640 1520 1370 1190
Medium Low 1720 1690 1650 1600 1550 1460 1370 1270 1150 980
Low 1440 1430 1400 1340 1280 1220 1140 1040 930 830

246796-YTG-D-0407
4Unitary Products Group
HORIZONTAL SIDEWALL VENTING
For applications where vertical venting is not possible, the
only approved method of horizontal venting is the use of an
auxiliary power vent. Approved power venters are Fields
Controls Model SWG-4Y or the appropriate Tjernlund GPAK
model. Follow all application and installation details provided
by the manufacturer of the power vent. This unit may be hori-
zontally vented using 4” (10.2 cm) diameter pipe with a mini-
mum length of 4.5 feet (1.37 m) and a maximum length of
34.5 feet (10.82 m) with up to 4 elbows.
FILTER PERFORMANCE
The airflow capacity data published in Blower Performance
Tables above, represents blower performance WITHOUT fil-
ters. To determine the approximate blower performance of
the system, apply the filter drop value for the filter being used
or select an appropriate value from the Table below.
NOTE: The filter pressure drop values in Blower Perfor-
mance Tables are typical values for the type of filter listed and
should only be used as a guideline. Actual pressure drop rat-
ings for each filter type vary between filter manufacturer.
NOTES:
1. Air velocity through throwaway type filters may not exceed 300
feet per minute. All velocities over this require the use of high
velocity filters.
RECOMMENDED FILTER SIZES
CFM Cabinet Size Top Return (in)
1200 A (2) 14 x 20
1600 B (2) 14 x 20
1200 B (2) 14 x 20
1600 C (2) 14 x 20
2000 C (2) 14 x 20
FILTER PERFORMANCE - PRESSURE DROP INCHES W.C. AND (KPA)
Airflow Range Minimum
Opening Size Filter Type
Disposable Washable Fiber Pleated
CFM in2In W.C. In W.C. In W.C.
0 - 750 230 0.01 0.01 0.15
751 - 1000 330 0.05 0.05 0.20
1001 - 1250 330 0.10 0.10 0.20
1251 - 1500 330 0.10 0.10 0.25
1501 - 1750 380 0.15 0.14 0.30
1751 - 2000 380 0.19 0.18 0.30
2001 & Above 463 0.19 0.18 0.30
UNIT CLEARANCES TO COMBUSTIBLES
Application Top Front Rear Left
Side Right Side Flue Floor/
Bottom Closet Alcove Attic Line
Contact
In. In. In. In. In. In.
Downflow 160036 11Yes Yes Yes No
Downflow B-Vent 1 3 0 0 0 1 11Yes Yes Yes No
Horizontal 1 6 0 0 3 6 Combustible No Yes Yes Yes2
Horizontal B-Vent 1 3 0 0 0 1 Combustible No Yes Yes Yes2
1 Special floor base or air conditioning coil required for use on combustible floor.
2 Line contact only permitted between lines formed by the intersection of the rear panel and side panel (top in horizontal position) of the furnace
jacket and building joists, studs or framing.

246796-YTG-D-0407
Unitary Products Group 5
APPLYING FILTER PRESSURE DROP TO
DETERMINE SYSTEM AIRFLOW
To determine the approximate airflow of the unit with a filter in
place, follow the steps below:
1. Select the filter type.
2. Select the number of return air openings or calculate the
return opening size in square inches to determine the
proper filter pressure drop.
3. Determine the External System Static Pressure (ESP)
without the filter.
4. Select a filter pressure drop from the table based upon
the number of return air openings or return air opening
size and add to the ESP from Step 3 to determine the
total system static.
5. If total system static matches an ESP value in the airflow
table (i.e. 0.20, 0.60, etc,) the system airflow corre-
sponds to the intersection of the ESP column and Model/
Blower Speed row.
6. If the total system static falls between ESP values in the
table (i.e. 0.58, 0.75, etc.), the static pressure may be
rounded to the nearest value in the table determining the
airflow using Step 5 or calculate the airflow by using the
following example.
Example: For a 60,000 Btuh furnace operating on high
speed blower, it is found that total system static is 0.58" w.c.
To determine the system airflow, complete the following
steps:
1. Obtain the airflow values at 0.50" & 0.60" ESP.
Airflow @ 0.50": 1240 CFM
Airflow @ 0.60": 1170 CFM
2. Subtract the airflow @ 0.50" from the airflow @ 0.60" to
obtain airflow difference.
1170 - 1240 = -70 CFM
3. Subtract the total system static from 0.50" and divide this
difference by the difference in ESP values in the table,
0.60" - 0.50", to obtain a percentage.
(0.58 - 0.50) / (0.60 - 0.50) = 0.8
4. Multiply percentage by airflow difference to obtain airflow
reduction.
(0.8) x (-70) = -56
5. Subtract airflow reduction value from airflow @ 0.50" to
obtain actual airflow @ 0.58" ESP.
1240 - 56 = 1184
ACCESSORIES
PROPANE (LP) CONVERSION KIT -
1NP0347 - All Models
These accessory conversion kits may be used to convert nat-
ural gas (N) units for propane (LP) operation. Conversions
must be made by qualified distributor or dealer personnel.
COMBUSTIBLE FLOOR BASE -
1CB0314 - for 14-1/2” cabinet models
1CB0317 - for 17-1/2” cabinet models
1CB0321 - for 21” cabinet models
HIGH ALTITUDE PRESSURE SWITCHES -
For installation where the altitude is less than 8,000 feet it is
not required that the pressure switch be changed. For alti-
tudes above 8,000 feet see kits below. Conversion must be
made by qualified distributor or dealer personnel.
1PS0313 - 040, 060, 080, 100 MBH
1PS0314 - 120 MBH
ROOM THERMOSTATS - A wide selection of compatible
thermosets are available to provide optimum performance
and features for any installation.
1H/1C, manual change-over electronic non-programmable
thermostat.
1H/1C, auto/manual changeover, electronic programmable,
deluxe 7-day, thermostat.
1H/1C, auto/manual changeover, electronic programmable.
* For the most current accessory information, refer to the
price book or consult factory.

246796-YTG-D-0407
6Unitary Products Group
For additional connection diagrams for all UPG equipment refer to “Low Voltage System Wiring” document available online at
www.upgnet.com in the Product Catalog Section.
Thermostat Chart - AC
AC9 2 Stage Scroll A/C w/2 Stage Furnace, 2 Stage Cooling Ready- PT8/9; (F,L)*8/9T, (G,L)*8/9T, XYG8S-U, XYF8S-U / XYF8S-U*L
THERMOSTAT
*DP22U70124
C
24-Volt Common
Thermostat Installer Setup
Number 15 - Compressor
Protection - must be set to 5
Y2
Second Stage Cool
W2
Second Stage Heat
R
24-Volt Hot
R
24-Volt Hot
C
24-Volt Common
Y1
First Stage Cool
Y
First Stage Cool
C
24-Volt Common
R
24-Volt Hot
Y1
First Stage Cool
C
24-Volt Common C
24-Volt Common C
24-Volt Common
Y1
First Stage Cool
Comfort Alert
Interface
24V HUMIDIFIER
(Optional)
R
24-Volt Hot
G
Fan
R
24-Volt Hot
W2
Second Stage Heat
E/W1
First Stage Heat
W
First Stage Heat
W2
Second Stage Heat
Step 1 of Thermostat User
Configuration Menu must be
set to MS 2
Step 16 of Thermostat User
Configuration Menu must be set
to ON to use Comfort Alert
Features
HM
Humidistat
L
Malfunction Light
E/W1
First Stage Heat
G
Fan
G
Fan
Connection of the "C" Termainal,
24-Volt Common, is optional
when used with batteries
Thermostat Installer Setup
Number 1 - System Type -
must be set to 6 -
2 Heat/2 Cool Conventional
R
24-Volt Hot (Heat XFMR)
W2
Second Stage Heat
RC
24-Volt Hot (Cool XFMR)
E/W1
First Stage Heat
G
Fan
*DN22U00124
THERMOSTAT
Y2
Second Stage Cool
Y2
Second Stage Cool
Y
First Stage Cool
Y2
Second Stage Cool Y2
Second Stage Cool
Y/Y2
Single/Second Stage
Cool
Y1
First Stage Cool
Connection of the "C"
Termainal, 24-Volt Common,
is optional when used with
batteries
2 STAGE PSC
FURNACE CONTROL TWO STAGE
AIR CONDITIONING
*DN22C00124 *PP32U71124
THERMOSTAT
*PP32U72124
THERMOSTAT
Step 1 of Thermostat User
Configuration Menu must be set
to MLTI STG
W/W1
Single/First Stage Heat
C
24-Volt Common
THERMOSTAT
*PP32U70124
Thermostat Installer Setup
Number 0170 - System Type -
must be set to 8 - 2 Heat/2 Cool
Multistage Conventional
Y
First Stage Cool
Y2
Second Stage Cool
R
24-Volt Hot (Heat XFMR)
RC
24-Volt Hot (Cool XFMR)
G
Fan
W2
Second Stage Heat
Connection of the "C"
Termainal, 24-Volt Common,
is optional when used with
batteries
E/W1
First Stage Heat
W2
Second Stage Heat
G
Fan
Connection of the "C" Termainal,
24-Volt Common, is optional
when used with batteries

246796-YTG-D-0407
Unitary Products Group 7
Thermostat Chart - HP
HP23 Two Stage H/P - H*5B, YZE - w/Two Stage Furnace, 2 Stage Cooling Ready - PT8/9, (F,L)*8/9T, (G,L)*8/9T, XYG8S-U, XYF8S-U / XYF8S-U*L
W/031-01996- Series Demand Control; Hot Heat Pump Mode OR Conventional
Thermostat Installer Setup Number 0210 -
External Fossil Fuel Kit - must be set to 0 -
External Fossil Fuel Kit is Controlling
Heat Pump Backup Heat
Change FFuel Jumper on
Heat Pump to ON
Thermostat Installer Setup Number 0190 -
Reversing Valve (O/B) Operation - must be set to 0
- O/B Terminal Energized in Cooling
Step 1 of Thermostat User
Configuration Menu must be
set to Heat Pump 2
Thermostat Installer Setup Number 0200
- Backup Heat Source - must be set to 1 - Heat
Pump Backup Heat Source is Fossil Fuel
24V HUMIDIFIER
(Optional)
Thermostat Installer Setup Number 0170
- System Type - must be set to
12 - 3 Heat/2 Cool Heat Pump
Selection of GAS/ELEC switch on
thermostat not necessary Step 1 of Thermostat User Configuration
Menu must be set to Heat Pump 2 Set W2 Delay on furnace to OFF
HM
Humidistat BSG
Bonnet Sensor
Bonnet Sensor
(Optional) BS
Bonnet Sensor
W2
Second Stage Auxiliary Heat W2
Second Stage Auxiliary Heat
AUX
Auxiliary Heat E/W1
First Stage Auxiliary Heat E/W1
First Stage Auxiliary Heat W
Auxiliary Heat
Y2
Second Stage Heat/Cool Y2
Second Stage Heat/Cool Y2
Second Stage Heat/Cool Y2
Second Stage Heat/Cool
L
Malfunction Light L
Malfunction Light L
Malfunction Light X/L
Malfunction Light
O/B
Reversing Valve O
Reversing Valve–Energized in Cool O
Reversing Valve–Energized in Cool O
Reversing Valve–Energized in Cool
G
Fan G
Fan G
Fan G
Fan
W1 OUT
First Stage Auxiliary Heat Output
DHM
Dehumidistat W2
Second Stage Heat W2 OUT
Second Stage Auxiliary Heat Output
E
Emergency Heat W/W1
Single/First Stage Heat
Y2 OUT
Second Stage Cool Output
R
24-Volt Hot (Heat XFMR) R
24-Volt Hot R
24-Volt Hot R
24-Volt Hot R
24-Volt Hot
RC
24-Volt Hot (Cool XFMR) Y/Y2
Single/Second Stage Cool
C
24-Volt Common C
24-Volt Common
Y
First Stage Heat/Cool Y1
First Stage Heat/Cool Y1
First Stage Heat/Cool Y1
First Stage Cool Y1
First Stage Heat/Cool
*PP32U72124
C
24-Volt Common C
24-Volt Common C
24-Volt Common
TWO STAGE
HEAT PUMP
*PP32U70124 *DN22H00124 *PP32U71124
THERMOSTAT THERMOSTAT THERMOSTAT PSC-2 STAGE
COOLING READY
FURNACE CONTROL
*DP22U70124

Subject to change without notice. Printed in U.S.A. 246796-YTG-D-0407
Copyright © by York International Corp. 2007. All rights reserved. Supersedes: 246796-YTG-C-0806
Unitary 5005 Norman
Products York OK
Group Drive 73069
NOTES
