York MP SERIES Quick start guide
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
5006167-YTG-F-0517
TECHNICAL GUIDE
MODULAR PSC AIR HANDLERS
FOR USE WITH SPLIT-SYSTEM
COOLING & HEAT PUMPS
MODELS: MP SERIES
Due to continuous product improvement,
specifications are subject to change without notice.
Visit us on the web at:
www.upgnet.com and www.york.com
A
dditional rating information can be found at:
www.ahridirectory.org
WARRANTY SUMMARY
Standard 5-year limited parts warranty.
Extended 10-year limited parts warranty when product is
registered online within 90 days of purchase for replacement
or closing for new home construction.
®
®
DESCRIPTION
This unique modular system allows the flexibility to handle any
application. These versatile MP blowers may be used for
upflow, downflow, or horizontal left or right applications. They
may be combined with cased coils to function as a cooling only
unit or with a heat pump including electric heat for 1 and 3
phase applications.
FEATURES
COMMON MP AIR HANDLER AND MATCH-UP CM COIL
Rigid Case Construction - An interior endoskeleton for
structural support, smooth sides, and locks in insulation.
Powder-painted - G30 galvanized steel case provide a coated
edge that resists corrosion and rust creep.
Quality Construction - Structural components are made of
Aluminum or G90 galvanized steel to prevent corrosion.
Improved Insulation Design - Single piece with no external
screws to reduce thermal transmission paths to prevent
sweating. Foil faced insulation for ease of cleaning.
Case Depth - These models have 20.5” casing which provide
ease of attic access and tight applications.
MP AIR HANDLERS
Factory Sealed - Achieves 2% or less total airflow leakage rate
at duct leakage test conditions in positive and negative
pressure for system airflow verification.
Electric Heat Kits - 6HK series of field installed electric heat
kits are available for installation-friendly and easy service
applications.
Blowers - All models use direct-drive, multi-speed PSC motors.
CM COILS
MaxAlloyTM Coil - Long life aluminum coils built to deliver
lasting performance, efficiency and reliability.
Thermostatic Expansion Valve - The accessory chatleff style
TXV provides easy installation to convert the indoor coil to the
required refrigerant that does not require brazing to replace or
install. Some models are available with factory installed TXV.
Thermoset Drain Pan - Low retention and positive slope for
drainage to reduce potential mold or contaminants.
Accessories - A full line of matching accessories available for
use with the blower and coils to provide for any type of
application.
2 Johnson Controls Unitary Products
5006167-YTG-F-0517
LIST OF SECTIONS
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
NOMENCLATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DIMENSIONS & DUCT CONNECTION DIMENSIONS . . . . . . . . . . . 3
DIMENSIONS - MP MODULAR AIR HANDLERS &
CM MULTI-POSITION FULL CASED COILS . . . . . . . . . . . . . . . . . . 3
COOLING CAPACITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PHYSICAL & ELECTRICAL DATA - COOLING ONLY . . . . . . . . . . 5
ELECTRICAL DATA - COOLING ONLY . . . . . . . . . . . . . . . . . . . . . . 5
ELECTRICAL HEAT - MINIMUM FAN SPEED . . . . . . . . . . . . . . . . . 6
ELECTRIC HEAT PERFORMANCE DATA: 208/230-1-60 &
208/230-3-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ELECTRICAL DATA FOR
SINGLE SOURCE POWER SUPPLY: 208/230-1-60 . . . . . . . . . . . . 7
ELECTRICAL DATA FOR
MULTI-SOURCE POWER SUPPLY: 208/230-1-60 . . . . . . . . . . . . . 8
ELECTRICAL DATA FOR
SINGLE SOURCE POWER SUPPLY: 208/230-3-60 . . . . . . . . . . . . 8
ELECTRICAL DATA FOR
MULTI-SOURCE POWER SUPPLY: 208/230-3-60 . . . . . . . . . . . . . 9
kW & MBH CONVERSIONS - FOR
TOTAL POWER INPUT REQUIREMENT . . . . . . . . . . . . . . . . . . . . . 9
APPLICATION FACTORS - RATED CFM VS. ACTUAL CFM . . . . . 9
POWER WIRING - LINE CONNECTIONS . . . . . . . . . . . . . . . . . . . . 9
BLOWER SPEED CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
FILTER RACK DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
COMBUSTIBLE FLOOR BASE ACCESSORY . . . . . . . . . . . . . . . . 11
LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TYPICAL APPLICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TYPICAL THERMOSTAT CONNECTION . . . . . . . . . . . . . . . . . . . . 12
AIR FLOW DATA - CFM (208 Volt) . . . . . . . . . . . . . . . . . . . . . . . . 13
AIR FLOW DATA - CFM (230 Volt) . . . . . . . . . . . . . . . . . . . . . . . . 14
NOMENCLATURE
PRODUCT TYPE MM= Modular Blower
POSITION
MOTOR TYPE PP= Multi PSC
E= Multi Std ECM
V= Multi VS ECM
OPTIONS -C= Communications Ready
- (No Designator) = Standard (No Options)
NOMINAL
AIR FLOW 12
08 = 800 CFM
12 = 1,200 CFM
14 = 1,400 CFM
16 = 1,600 CFM
20 = 2,000 CFM
CABINET WIDTH B
A= 14.5"
B= 17.5"
C= 21.0"
D= 24.5"
OPTIONS NN= No options
VOLTAGE
(Voltage-Phase-Hertz) 21= 115-1-60 3= 208/230-3-60
2= 208/230-1-60 4= 460-3-60
GENERATION
(MAJOR REVISION) 11= 1st Gen
2= 2nd Gen
etc.
STYLE LETTER
(MINOR REVISION)
NOT USED FOR
ORDERING AA= Style A
B= Style B
etc.
Johnson Controls Unitary Products 3
5006167-YTG-F-0517
DIMENSIONS & DUCT CONNECTION DIMENSIONS
(
)
$
$
6(59,&(',6&211(&7
3$1(/
723287/(7
',0(16,216
%27720,1/(7
',0(16,216
'
´
´
%´
´
$
'23(1,1*
%2772023(1,1*
',0(16,216
´
%
)
23(1,1*´ &23(1,1*
´
$,5+$1'/(5
&2,/
´
&23(1,1*
DIMENSIONS - MP MODULAR AIR HANDLERS & CM MULTI-POSITION FULL CASED COILS
Models
Dimensions 1
1. All dimensions are in inches as actual size (Dimensions in parenthesis are Conduit size).
Height Width Opening Widths Wiring Knockouts
AB C D EF
Power Control
MP08BN21 21-1/2 17-1/2 16-1/2 16-1/2
7/8 (1/2),
1-3/8 (1),
1-23/32 (1-1/4) 7/8 (1/2)
MP12BN21 21-1/2 17-1/2 16-1/2 16-1/2
MP14DN21 22-1/2 24-1/2 23-1/2 23-1/2
MP16CN21 22-1/2 21 20 20
MP20DN21 22-1/2 24-1/2 23-1/2 23-1/2
Models2
2. Asterisk (*) denotes coils available with Factory installed TXV.
Dimensions 1
Height Width Opening Widths Refrigerant Connections 3,4,5
3. Refrigerant line sizes may require larger lines for extended line lengths. See Application Data part number 247077.
4. Adapter fitting must be field installed for other line set size.
5. See outdoor unit technical guide for proper line set size.
Line Size
A B C D Liquid Vapor
CM18A* 19-1/2 14-1/2 13-1/2 13-1/2
3/8
3/4
CM18B 19 17-1/2 16-1/2 16-1/2
CM24A* 19-1/2 14-1/2 13-1/2 13-1/2
CM24B* 19 17-1/2 16-1/2 16-1/2
CM24C 21 21 20 20
CM30A* 25-1/2 14-1/2 13-1/2 13-1/2
CM30B* 23 17-1/2 16-1/2 16-1/2
CM30C 23 21 20 20
CM30D 25 24/1/2 23-1/2 23-1/2
CM36A 25-1/2 14-1/2 13-1/2 13-1/2
CM36B* 25-5/8 17-1/2 16-1/2 16-1/2
CM36C* 25 21 20 20
CM36D 25 24-1/2 23-1/2 23-1/2
CM42C* 27 21 20 20
7/8
CM42D 27 24-1/2 23-1/2 23-1/2
CM48C* 33 21 20 20
CM48D* 32-3/4 24-1/2 23-1/2 23-1/2
CM60C* 33 21 20 20
CM60D* 32-3/4 24-1/2 23-1/2 23-1/2
CM64D 32-3/4 24-1/2 23-1/2 23-1/2
4 Johnson Controls Unitary Products
5006167-YTG-F-0517
COOLING CAPACITY1
Models Rated CFM2Entering Air
Dry/Wet Bulb (°F) MBH@ Evap. Temp. and Corresponding R-410A Pressure (°F/PSIG)
35/107.9 40/118.9 45/130.7 50/143.3
CM18B 600
85/72 45.7 41.6 36.8 30.5
80/67 38.5 33.9 28.5 22.3
75/62 31.5 26.5 20.5 15.9
70/57 24.4 19.5 15.2 11.5
CM24B 800
85/72 52.2 47.5 41.8 35.0
80/67 43.6 38.3 31.9 24.5
75/62 35.2 29.5 22.7 16.2
70/57 27.1 20.7 15.5 11.4
CM24C 800
85/72 52.2 47.5 41.8 35.0
80/67 43.6 38.3 31.9 24.5
75/62 35.2 29.5 22.7 16.2
70/57 27.1 20.7 15.5 11.4
CM30B 1000
85/72 75.3 67.8 56.8 47.1
80/67 62.6 54.6 44.2 34.5
75/62 50.2 41.3 32.0 22.9
70/57 37.8 30.1 21.5 16.2
CM30C 1000
85/72 75.3 67.8 56.8 47.1
80/67 62.6 54.6 44.2 34.5
75/62 50.2 41.3 32.0 22.9
70/57 37.8 30.1 21.5 16.2
CM30D 1000
85/72 75.3 67.8 56.8 47.1
80/67 62.6 54.6 44.2 34.5
75/62 50.2 41.3 32.0 22.9
70/57 37.8 30.1 21.5 16.2
CM36B 1000
85/72 82.1 73.7 64.1 54.4
80/67 68.6 60.1 50.5 39.5
75/62 56.3 47.0 37.3 29.2
70/57 43.5 36.0 28.3 21.6
CM36B 1200
85/72 91.6 82.4 71.3 59.4
80/67 76.5 65.4 54.6 42.8
75/62 61.3 51.2 40.0 30.5
70/57 47.5 38.1 28.7 22.3
CM42C 1200
85/72 98.0 88.6 77.4 66.4
80/67 82.6 72.6 61.7 50.6
75/62 68.5 57.6 47.5 36.6
70/57 53.9 44.8 35.0 28.4
CM36C 1200
85/72 91.6 82.4 71.3 59.4
80/67 76.5 65.4 54.6 42.8
75/62 61.3 51.2 40.0 30.5
70/57 47.5 38.1 28.7 22.3
CM36D 1200
85/72 91.6 82.4 71.3 59.4
80/67 76.5 65.4 54.6 42.8
75/62 61.3 51.2 40.0 30.5
70/57 47.5 38.1 28.7 22.3
CM42C 1400
85/72 100.6 89.8 78.2 64.7
80/67 83.5 73.7 59.8 48.0
75/62 67.8 55.8 44.7 32.5
70/57 52.3 41.5 30.7 23.7
CM42D 1400
85/72 100.6 89.8 78.2 64.7
80/67 83.5 73.7 59.8 48.0
75/62 67.8 55.8 44.7 32.5
70/57 52.3 41.5 30.7 23.7
For notes, see Page 5.
Johnson Controls Unitary Products 5
5006167-YTG-F-0517
CM48C 1400
85/72 108.0 98.4 88.1 73.8
80/67 93.3 82.1 69.7 57.0
75/62 75.9 64.4 53.1 41.9
70/57 60.7 49.9 39.4 32.4
CM48C 1600
85/72 115.2 105.0 93.9 79.0
80/67 88.3 78.2 65.5 52.6
75/62 72.7 60.8 50.1 37.6
70/57 57.7 46.9 36.6 29.7
CM48D 1600
85/72 115.2 105.0 93.9 79.0
80/67 88.3 78.2 65.5 52.6
75/62 72.7 60.8 50.1 37.6
70/57 57.7 46.9 36.6 29.7
CM60C 1800
85/72 115.1 103.0 91.7 78.6
80/67 96.8 85.9 73.7 60.5
75/62 80.7 69.4 57.5 43.5
70/57 58.7 48.9 37.7 32.7
CM60D 1800
85/72 115.1 103.0 91.7 78.6
80/67 96.8 85.9 73.7 60.5
75/62 80.7 69.4 57.5 43.5
70/57 58.7 48.9 37.7 32.7
CM64D 1800
85/72 133.6 118.5 103.2 86.6
80/67 111.4 96.2 80.3 62.8
75/62 90.7 75.1 60.0 43.5
70/57 70.6 56.9 42.5 32.8
1. See Condensing Unit or Heat Pump Technical Guide for Total Cooling Capacity and Sensible Capacity.
2. Airflow is calculated for each system tonnage.
COOLING CAPACITY1(Continued)
Models Rated CFM2Entering Air
Dry/Wet Bulb (°F) MBH@ Evap. Temp. and Corresponding R-410A Pressure (°F/PSIG)
35/107.9 40/118.9 45/130.7 50/143.3
PHYSICAL & ELECTRICAL DATA - COOLING ONLY
Models MP08B MP12B MP14D MP16C MP20D
Blower - Diameter x Width 10 x 8 10 x 8 10 x 10 10 x 10 10 x 10
Motor HP 1/4 HP 1/2 HP 1/2 HP 1/2 HP 1 HP
Nominal RPM 850 1085 1085 1040 1007
Voltage 208/230 208/230 208/230 208/230 208/230
Full Load Amps @230V 1.4 2.6 2.8 2.9 4.1
Filter1
Type DISPOSABLE OR PERMANENT
Size 16 x 20 x 1 16 x 20 x 1 22 x 20 x 1 20 x 20 x 1 22 x 20 x 1
Bottom Rack Kit 1BR01117 1BR01117 1BR01124 1BR01121 1BR01124
Permanent Type Kit 1PF0601 1PF0601 1PF0603 1PF0602 1PF0603
Shipping / Operating Weight (lbs.) 52/51 52/51 75/74 68/67 75/74
1. Field Supplied.
ELECTRICAL DATA - COOLING ONLY
Models Motor FLA1Minimum Circuit Ampacity MOP2
MP08B 1.4 1.8
15
MP12B 2.6 3.3
MP14D 2.8 3.5
MP16C 2.9 3.6
MP20D 4.1 5.1
1. FLA = Full Load Amps.
2. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. Refer to the latest edition of the National Electric Code
or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
6 Johnson Controls Unitary Products
5006167-YTG-F-0517
ELECTRICAL HEAT - MINIMUM FAN SPEED
Heater Kit
Models1,2,3 Nom. kW
@240V Air Handler Models
MP08B MP12B MP14D MP16C MP20D
6HK(0,1)6500206 2.4kW Low Low Low Low Low
6HK(0,1)6500506 4.8kW Low Low Low Low Low
6HK(0,1)6500806 7.7kW Low Low Low Low Low
6HK(0,1)6501006
6HK36501025 9.6kW Low Low Low Low Low
6HK(1,2)6501306 12.5kW Med Low Low Low Low
6HK(1,2)6501506
6HK36501525 14.4kW – Med Low Low Low
6HK(1,2)6501806
6HK36501825 17.3kW – Med Low Low Low
6HK(1,2)6502006
6HK46502025 19.2kW – Med Med High Low
1. (0,1) - 0 = no service disconnect OR 1 = with service disconnect.
2. (1,2) - 1 = with service disconnect, no breaker jumper bar OR 2 = with service disconnect & breaker jumper bar.
3. 6HK3 = 3-Phase with terminal block connectors only, 6HK4 = 3-Phase with service disconnect.
ELECTRIC HEAT PERFORMANCE DATA: 208/230-1-60 & 208/230-3-60
Heater
Models1,2,3 Nominal kW
@240V
Total Heat 4kW Staging
kW MBH W1 Only W1 + W2
208V 230V 208V 230V 208V 230V 208V 230V
1PH
6HK(0,1)6500206 2.4 1.8 2.2 6.2 7.5 1.8 2.2 1.8 2.2
6HK(0,1)6500506 4.8 3.6 4.4 12.3 15 3.6 4.4 3.6 4.4
6HK(0,1)6500806 7.7 5.8 7.1 19.7 24.1 5.8 7.1 5.8 7.1
6HK(0,1)6501006 9.6 7.2 8.8 24.6 30.1 7.2 8.8 7.2 8.8
6HK(1,2)6501306 12.5 9.4 11.5 32 39.2 3.1 3.8 9.4 11.5
6HK(1,2)6501506 14.4 10.8 13.2 36.9 45.1 3.6 4.4 10.8 13.2
6HK(1,2)6501806 17.3 13 15.9 44.3 54.2 6.5 7.9 13 15.9
6HK(1,2)6502006 19.2 14.4 17.6 49.2 60.2 7.2 8.8 14.4 17.6
3PH
6HK36501025 9.6 7.2 8.8 24.6 30.1 7.2 8.8 7.2 8.8
6HK36501525 14.4 10.8 13.2 36.9 45.1 10.8 13.2 10.8 13.2
6HK36501825 17.3 13 15.9 44.3 54.2 13 15.9 13 15.9
6HK46502025 19.2 14.4 17.6 49.2 60.2 7.2 8.8 14.4 17.6
1. (0,1) - 0 = no service disconnect OR 1 = with service disconnect.
2. (1,2) - 1 = with service disconnect, no breaker jumper bar OR 2 = with service disconnect & breaker jumper bar.
3. 6HK3 = 3-Phase with terminal block connectors only, 6HK4 = 3-Phase with service disconnect.
4. For different power distributions, see conversion table on Page 9.
Johnson Controls Unitary Products 7
5006167-YTG-F-0517
ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY: 208/230-1-60
Air Handler
Models Heater
Models1,2
Heater
Amps
@240V
Field Wiring
Min. Circuit Ampacity MOP.3
208V 230V 208V 230V
MP08B
6HK(0,1)6500206 10 12.6 13.7 15 15
6HK(0,1)6500506 20 23.4 25.7 25 30
6HK(0,1)6500806 32 36.6 40.3 40 45
6HK(0,1)6501006 40 45.0 49.6 45 50
6HK(1,2)6501306 52 58.2 64.3 60 70
MP12B
6HK(0,1)6500206 10 14.1 15.2 15 20
6HK(0,1)6500506 20 24.9 27.2 25 30
6HK(0,1)6500806 32 38.1 41.8 40 45
6HK(0,1)6501006 40 46.5 51.1 50 60
6HK(1,2)6501306 52 59.7 65.8 60 70
6HK(1,2)6501506 60 68.2 75.0 70 80
6HK(1,2)6501806 72 81.4 89.7 90 90
6HK(1,2)6502006 80 89.8 98.9 90 100
MP14D
6HK(0,1)6500206 10 14.3 15.5 15 20
6HK(0,1)6500506 20 25.1 27.4 30 30
6HK(0,1)6500806 32 38.4 42.1 40 45
6HK(0,1)6501006 40 46.8 51.3 50 60
6HK(1,2)6501306 52 60.0 66.0 60 70
6HK(1,2)6501506 60 68.4 75.2 70 80
6HK(1,2)6501806 72 81.6 89.9 90 90
6HK(1,2)6502006 80 90.0 99.2 90 100
MP16C
6HK(0,1)6500206 10 14.4 15.6 15 20
6HK(0,1)6500506 20 25.3 27.5 30 30
6HK(0,1)6500806 32 38.5 42.2 40 45
6HK(0,1)6501006 40 46.9 51.5 50 60
6HK(1,2)6501306 52 60.1 66.1 70 70
6HK(1,2)6501506 60 68.5 75.4 70 80
6HK(1,2)6501806 72 81.8 90.0 90 90
6HK(1,2)6502006 80 90.2 99.3 90 100
MP20D
6HK(0,1)6500206 10 15.9 17.1 20 20
6HK(0,1)6500506 20 26.8 29.0 30 30
6HK(0,1)6500806 32 40.0 43.7 40 45
6HK(0,1)6501006 40 48.4 53.0 50 60
6HK(1,2)6501306 52 61.6 67.6 70 70
6HK(1,2)6501506 60 70.0 76.9 70 80
6HK(1,2)6501806 72 83.3 91.5 90 100
6HK(1,2)6502006 80 91.7 100.8 100 110
1. (0,1) - 0 = no service disconnect OR 1 = with service disconnect.
2. (1,2) - 1 = with service disconnect, no breaker jumper bar OR 2 = with service disconnect & breaker jumper bar.
3. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps.
Refer to the latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
8 Johnson Controls Unitary Products
5006167-YTG-F-0517
ELECTRICAL DATA FOR MULTI-SOURCE POWER SUPPLY: 208/230-1-60
Air Handler
Models Heater
Models
Heater
Amps
@240V
Min. Circuit Ampacity MOP.1
208V 230V 208V 230V
Circuit Circuit
1st 2nd 1st32nd 1st32nd 1st32nd
MP08B 6HK16501306 52 20.5 37.6 22.5 41.5 25 40 25 45
MP12B
6HK16501306 52 22.0 37.6 24.0 41.5 25 40 25 45
6HK16501506 60 24.9 43.3 27.2 47.9 25 45 30 50
6HK16501806 72 42.3 39.0 46.4 43.1 45 40 50 45
6HK16502006 80 46.6 43.3 51.2 47.9 50 45 60 50
MP14D
6HK16501306 52 22.3 37.6 24.3 41.5 25 40 25 45
6HK16501506 60 25.2 43.3 27.5 47.9 30 45 30 50
6HK16501806 72 29.5 39.0 46.6 43.1 30 40 50 45
6HK16502006 80 32.4 43.3 51.4 47.9 35 45 60 50
MP16C
6HK16501306 52 22.4 37.6 24.4 41.5 25 40 25 45
6HK16501506 60 25.3 43.3 27.6 47.9 30 45 30 50
6HK16501806 72 42.6 39.0 46.8 43.1 30 40 50 45
6HK16502006 80 47.0 43.3 51.5 47.9 35 45 60 50
MP20D
6HK16501306 52 23.9 37.6 25.9 41.5 25 40 30 45
6HK16501506 60 26.8 43.3 29.1 47.9 30 45 30 50
6HK16501806 72 44.1 39.0 48.3 43.1 45 40 50 45
6HK16502006 80 48.5 43.3 53.0 47.9 50 45 60 50
1. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps.
Refer to the latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
ELECTRICAL DATA FOR SINGLE SOURCE POWER SUPPLY: 208/230-3-60
Air Handler
Models Heater
Models1
Heater
Amps
@240V
Field Wiring
Min. Circuit Ampacity2MOP
208V 230V 208V 230V
MP08B 6HK36501025 23.1 26.8 29.4 30 30
MP12B
6HK36501025 23.1 28.3 30.9 30 35
6HK36501525 34.6 40.8 44.7 45 45
6HK36501825 41.6 48.4 53.2 50 55
6HK46502025346.2 53.3 58.5 55 60
MP14D
6HK36501025 23.1 28.5 31.1 30 35
6HK36501525 34.6 41.0 45.0 45 45
6HK36501825 41.6 48.7 53.4 50 55
6HK46502025346.2 53.5 58.8 55 60
MP16C
6HK36501025 23.1 28.6 31.3 30 35
6HK36501525 34.6 41.1 45.1 45 50
6HK36501825 41.6 48.8 53.6 50 55
6HK46502025346.2 53.6 58.9 55 60
MP20D
6HK36501025 23.1 30.1 32.8 35 35
6HK36501525 34.6 42.6 46.6 45 50
6HK36501825 41.6 50.3 55.1 55 60
6HK46502025346.2 55.1 60.4 60 70
1. 6HK3 = 3-Phase with terminal block connections only, 6HK4 = 3-Phase with service disconnect
2. The 20kW and 25kW heater models (6HK46502025 and 6HK46502525) come with service disconnects standard. Single source power MCA and MOP
requirements are given here only for reference if used with field installed single point power modification (S1-32436041000).
3. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps.
Refer to the latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
Johnson Controls Unitary Products 9
5006167-YTG-F-0517
ELECTRICAL DATA FOR MULTI-SOURCE POWER SUPPLY: 208/230-3-60
Air Handler
Models Heater
Models1
Heater
Amps
@240V
Min. Circuit Ampacity MOP.2
208V 230V 208V 230V
Circuit Circuit
1st 2nd 1st32nd 1st32nd 1st32nd
MP12B 6HK46502025 46.2 28.3 25.0 30.9 27.6 30 25 35 30
MP14D 6HK46502025 46.2 28.5 25.0 31.1 27.6 30 25 35 30
MP16C 6HK46502025 46.2 28.6 25.0 31.3 27.6 30 25 35 30
MP20D 6HK46502025 46.2 30.1 25.0 32.8 27.6 35 25 35 30
1. The 20kW heater model (6HK46502025) come with service disconnects standard.
2. MOP = Maximum Overcurrent Protection device; must be HACR type circuit breaker or time delay fuse. The 1st circuit includes blower motor amps.
Refer to the latest edition of the National Electric Code or in Canada the Canadian electrical Code and local codes to determine correct wire sizing.
kW & MBH CONVERSIONS - FOR TOTAL POWER INPUT REQUIREMENT
For a power distribution voltage that is different than the provided nominal voltage, multiply the kW and MBH data from the table by the conversion
factor in the following table.
DISTRIBUTION POWER NOMINAL VOLTAGE CONVERSION FACTOR
208V 240V 0.75
220V 240V 0.84
230V 240V 0.92
APPLICATION FACTORS - RATED CFM VS. ACTUAL CFM
% Of Rated Airflow (CFM) 80% 90% 100% 110% 120%
Capacity Factor 0.96 0.98 1.00 1.02 1.03
POWER WIRING - LINE CONNECTIONS
),(/'32:(5:,5,1*
9
&20321(17&2'(6
*1'*5281'/8*
6'6(59,&(',6&211(&7
&.7&,5&8,7
&1:,5(&211(&725187
*1'
12(/(&75,&+($7
32:(5
6833/< &1
&1
*1'
-803(5%$5
6,1*/(6285&(32:(5
08/7,6285&(32:(5
08/7,6285&(32:(5
:,7+-803(5%$5
7(50,1$/%/2&.25
6(59,&(',6&211(&7
32:(5
6833/< 32:(5
6833/<
6,1*/(6285&(32:(5
&,5&8,7621N:N:
&,5&8,7621N:
7(50,1$/%/2&.25
6(59,&(',6&211(&7
&.7
&.7
32:(5
6833/<
6'
6'
6'
6'
6'
32:(5
6833/<
*1'
*1'
*1'
*1'
32:(5
6833/<
/
/
/
/
/
/
&.7
/
/
/
/
6'
6'
6'
/
/
/
/
/
/
/
/
/
08/7,6285&(32:(5
&.7
&.7
&,5&8,7621N:N:
&,5&8,7621N:
3+$6((/(&75,&+($7237,216
3+$6((/(&75,&+($732:(5237,216
$
BLOWER SPEED CONNECTIONS
FACTORY WIRED TO
TRANSFORMER
FACTORY WIRED TO
FAN MOTOR RELAY
TERMINAL ON
CONTROL BOARD
PUR
PUR
HIGH
MED
LOW
GND.
230 VOLT
BLOWER MOTOR
CAP
BRN
BLK
A0342-001
PSC STANDARD MOTOR
FACTORY WIRED TO
TRANSFORMER
FACTORY WIRED TO
FAN MOTOR RELAY
TERMINAL ON
CONTROL BOARD
PSC STANDARD MOTOR
ALTERNATE CONNECTION
AP60, RFCX60, MP20
ALL OTHER AIR HANDLER
GND.
CAP
BRN
BLK
H M L
RC
PRP PRP
230 VOLT
BLOWER
MOTOR
10 Johnson Controls Unitary Products
5006167-YTG-F-0517
ACCESSORIES
Refer to Price Manual for specific model numbers where not
shown.
TXV Kits - Air handlers are shipped with “Flex-coils” without a
factory installed metering device. For added flexibility, an R-22
or R-410A TXV or orifice can be field installed to meet your
refrigerant choice. All kits are chatleff style and require no
brazing to install.
Electric Heaters - 6HK models shown under electrical data
include sequential operation and temperature dual limit
switches for safe, efficient operation. Service disconnects are
provided where shown.
Bottom Rack Filter Kit - The filter frame accessory allows
installation of an external air handler filter in an upflow
application, a downflow application, or a horizontal application
(refer to the following illustration/table for Filter Rack
Dimensions).
For upflow platform return applications, cut the hole in the
return air platform the same size as the filter frame opening
(dimensions for E x D in Table 1). DO NOT cut an oversized
hole.
Combustible Floor Base Accessory - If an electric heat
accessory which is rated for greater than zero clearance to
combustible surfaces is installed in these air handlers in the
downflow operating positions on a combustible floor, one of the
following combustible floor base accessory models is required:
S1-1FB1917, S1-1FB1921, S1-1FB1924.
Breaker Moisture Seal Accessory - A clear service
disconnect moisture barrier seals the service disconnect(s)
from humidity and dust. The flexibility of the clear cover allows
service disconnects to be turned ON or OFF without removing
the cover. The cover firmly attaches to the access panel around
the service disconnects with the use of double backed adhesive
tape. To ensure that moisture or dust does not contaminate
service disconnects, an S1-02435672000 Cover Breaker
Moisture Seal may be ordered.
Thermostat - Compatible thermostat controls are available
through accessory sourcing. For optimum performance, these
outdoor units are fully compatible with our York touch screen
thermostat with proprietary (patent-pending) hexagon interface.
For more information, see the thermostat section of the Product
Equipment Catalog.
SINGLE SOURCE POWER ACCESSORIES (SINGLE PHASE)
S1-02435670000 For heat kits with 2 service disconnects.
S1-02435671000 For heat kits with 3 service disconnects.
SINGLE SOURCE POWER ACCESSORY (THREE PHASE)
S1-32436041000 Contains a terminal block and wiring to
connect service disconnects together.
NOTICE
Filter frames are orientation specific. The block-off box pro-
vided with the kit is to be inserted after the air filter has been
installed.
NOTICE
When attaching return air duct system to filter frame, mount-
ing hardware should not have sharp extruding points
exposed.
FILTER RACK DIMENSIONS
Galvanized
Models A B C D E Filer Size
1BR01117 17.50 21.56 4.00 18.63 14.25 16 x 20 x 1 or 2
1BR01121 21.00 21.56 4.00 18.63 17.75 20 x 20 x 1 or 2
1BR01124 24.50 21.56 4.00 18.63 21.25 20 x 24 x 1 or 2
Note: Filters - Not supplied with kit.
A
C
B
D
E
A0146-003
SIDE
TRACKS
11/16
Johnson Controls Unitary Products 11
5006167-YTG-F-0517
COMBUSTIBLE FLOOR BASE ACCESSORY
LIMITATIONS
These units must be wired and installed in accordance with all
national and local safety codes.
Voltage limits are as follows:
Airflow must be within the minimum and maximum limits
approved for electric heat, indoor coils and outdoor units.
TYPICAL APPLICATIONS
Floor Base
Models Used with Dimensions
ABC
1FB1917 MP08B, MP12B 17.5 14.0 16.0
1FB1921 MP16C 21.0 17.5 19.5
1FB1924 MP14D, MP20D 24.5 21.0 23.0
DOWNFLOW
AIR HANDLER
WARM AIR PLENUM
with 1” flange out
on each side.
FIBERGLASS
INSULATION
FIBERGLASS TAPE
under flange.
COMBUSTIBLE FLOOR
BASE ACCESSORY
AB
BA
AIR HANDLER
DEPTH
FRONT
FLOOR
1”
11”
PLENUM
13”
FLOOR OPENING
APPROX. 1/2”
CLEARANCE
ALL AROUND
FLOOR
A
AIR HANDLER
WIDTH
COMBUSTIBLE
FLOOR BASE
APPROX. 1/2”
CLEARANCE
ALL AROUND
C
FLOOR OPENING
B
PLENUM
1” 1”
A0457-001
CROSS SECTION (A-A) FROM SIDE
CROSS SECTION (B-B) FROM FRONT
Air Handler Voltage 1Normal Operating Voltage
Range
1. Rated in accordance with ARI Standard 110, utilization range “A”.
208/230-1-60 187-253
A0346-001
UPFLOW DOWNFLOW
HORIZONTAL RIGHT
HEAT
HORIZONTAL LEFT
HEAT
HEAT
HEAT
HEAT
12 Johnson Controls Unitary Products
5006167-YTG-F-0517
TYPICAL THERMOSTAT CONNECTION
A0370-002
W2
X/L X/L
X/LX/L
FIELD INSTALLED
JUMPER IF SINGLE
STAGE THERMOSTAT
IS USED.
Johnson Controls Unitary Products 13
5006167-YTG-F-0517
Dry coil conditions only, tested without filters.
For optimal performance, external static pressures of 0.2" to 0.5" are recommended. Heating applications tested at 0.50” w.c. esp.
AIR FLOW DATA - CFM1
(208 Volt)
Models CM Models Blower
Motor Speed External Static Pressure (in. WC.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70
208 Volt
MP08B
CM18B High 975 965 953 926 889 772 724
Medium 729 719 700 643 614 540 354
Low 576 561 501 455 407 289 209
CM24B High 950 944 927 907 876 838 742
Medium 713 703 686 656 591 533 478
Low 560 546 511 448 398 294 208
MP12B
CM30B High 1459 1410 1342 1275 1200 1129 1022
Medium 1241 1210 1156 1110 1044 1002 917
Low 992 965 940 911 867 822 758
CM36B High 1487 1438 1383 1315 1245 1150 1073
Medium 1226 1202 1166 1119 1079 1007 945
Low 959 950 925 892 866 818 716
MP14D
CM30D High 1944 1891 1832 1767 1693 1594 1303
Medium 1518 1494 1470 1425 1377 1186 1071
Low 1208 1198 1180 1155 1019 968 830
CM36D High 1967 1920 1848 1781 1710 1623 1532
Medium 1520 1508 1486 1446 1398 1203 1101
Low 1207 1202 1176 1156 1028 970 885
CM42D High 1949 1912 1854 1791 1715 1645 1358
Medium 1538 1521 1492 1458 1406 1265 1144
Low 1197 1190 1179 1128 1052 998 903
MP16C
CM36C High 1776 1709 1646 1573 1491 1328 1171
Medium 1591 1545 1486 1424 1300 1173 1066
Low 1360 1331 1285 1194 1097 1027 941
CM42C High 1746 1687 1616 1536 1386 1265 1147
Medium 1564 1507 1451 1388 1246 1148 998
Low 1339 1301 1258 1136 1052 994 876
CM48C High 1817 1756 1678 1599 1511 1296 1120
Medium 1673 1618 1542 1477 1349 1138 915
Low 1448 1419 1362 1281 1136 1001 948
MP20D
CM42D High 2035 1994 1922 1858 1781 1658 1562
Medium 1849 1819 1771 1694 1650 1575 1364
Low 1679 1654 1624 1578 1526 1339 1263
CM48D High 2061 2001 1937 1871 1780 1684 1570
Medium 1867 1835 1786 1727 1653 1563 1328
Low 1678 1657 1615 1572 1518 1441 1235
CM60D High 2021 1979 1897 1833 1751 1668 1521
Medium 1852 1811 1758 1697 1639 1547 1389
Low 1646 1630 1596 1555 1491 1384 1247
CM64D High 1867 1832 1784 1729 1652 1572 1462
Medium 1498 1484 1443 1411 1361 1233 1138
Low 1128 1122 1115 1096 1020 967 893
1. Air handler units have been tested to UL 1995 / CSA 22.2 No. 236 standards up to 0.50" WC. external static pressure.
Subject to change without notice. Published in U.S.A. 5006167-YTG-F-0517
Copyright © 2017 by Johnson Controls, Inc. All rights reserved. Supersedes: 5006167-YTG-E-1116
York International Corp.
5005 York Drive
Norman, OK 73069
Dry coil conditions only, tested without filters.
For optimal performance, external static pressures of 0.2" to 0.5" are recommended. Heating applications tested at 0.50” w.c. esp.
AIR FLOW DATA - CFM1
(230 Volt)
Models CM Models Blower
Motor Speed External Static Pressure (in. WC.)
0.10 0.20 0.30 0.40 0.50 0.60 0.70
230 Volt
MP08B
CM18B High 1142 1126 1093 1057 1009 953 852
Medium 855 840 826 798 756 696 594
Low 676 663 638 584 528 482 404
CM24B High 1105 1088 1060 1030 987 948 859
Medium 825 815 802 780 752 678 591
Low 655 636 616 569 504 467 345
MP12B
CM30B High 1521 1471 1397 1322 1241 1161 1057
Medium 1369 1329 1281 1224 1166 1092 1015
Low 1130 1107 1071 1029 972 910 842
CM36B High 1557 1507 1440 1363 1289 1185 1125
Medium 1351 1321 1266 1207 1153 1076 1019
Low 1103 1083 1056 1024 976 928 851
MP14D
CM30D High 2092 2038 1958 1884 1795 1714 1591
Medium 1725 1697 1634 1598 1534 1454 1179
Low 1374 1366 1339 1316 1250 1070 904
CM36D High 2099 2040 1980 1903 1814 1680 1605
Medium 1725 1694 1652 1605 1541 1467 1182
Low 1388 1372 1340 1306 1277 1106 1026
CM42D High 2083 2033 1960 1894 1820 1720 1459
Medium 1690 1662 1623 1587 1534 1460 1233
Low 1399 1393 1370 1338 1269 1159 1073
MP16C
CM36C High 1850 1785 1705 1625 1541 1373 1242
Medium 1693 1642 1574 1499 1378 1261 1145
Low 1512 1465 1407 1324 1225 1101 1022
CM42C High 1815 1754 1680 1593 1472 1278 1206
Medium 1670 1613 1554 1473 1311 1210 1082
Low 1488 1445 1376 1259 1181 1056 979
CM48C High 1886 1818 1739 1646 1567 1348 1163
Medium 1742 1683 1622 1538 1461 1237 1121
Low 1563 1512 1455 1399 1234 1086 1019
MP20D
CM42D High 2123 2076 2001 1926 1840 1744 1439
Medium 1999 1959 1896 1821 1744 1651 1347
Low 1851 1819 1768 1698 1626 1544 1269
CM48D High 2178 2107 2034 1953 1878 1775 1604
Medium 2014 1965 1905 1843 1761 1660 1351
Low 1867 1832 1779 1727 1661 1544 1280
CM60D High 2132 2052 1993 1899 1813 1733 1594
Medium 1985 1941 1872 1798 1729 1648 1507
Low 1848 1810 1758 1695 1627 1548 1355
CM64D High 2069 2011 1929 1848 1755 1651 1402
Medium 1962 1902 1832 1758 1675 1558 1335
Low 1833 1787 1734 1667 1581 1382 1269
1. Air handler units have been tested to UL 1995 / CSA 22.2 No. 236 standards up to 0.50" WC. external static pressure.
Table of contents
Other York Modulator manuals
