YORKVILLE AP 6040 Professional Series User manual

AP 6040
MODEL TYPE: YS6040
U.S.A.
Yorkville Sound Inc.
4625 Witmer Industrial Estate
Niagara Falls, New York
14305 USA
Voice: [phone]
Fax: [phone]
WORLD HEADQUARTERS
CANADA
Yorkville Sound
550 Granite Court
Pickering, Ontario
L1W-3Y8 CANADA
Voice: [phone]
Fax: [phone]
Quality and Innovation Since 1963
Printed in Canada
SERVICE MANUAL
W E B AC C E SS: http:/ /www. yor k ville .com

IMPORTANT SAFETY INSTRUCTIONS
safety-4v1.eps Aug 26/05
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS
Read Instructions
The Owner’s Manualshould be read and understood
before operation of your unit. Please, save these instruc-
tions for future reference.
Packaging
Keep the box and packaging materials, in case the unit
needs to be returned for service.
Warning
When using electric products, basic precautions should
always be followed, including the following:
Power Sources
Your unit should be connected to a power source only of the voltage
specified in the owners manual or as marked on the unit. This unit has
a polarized plug. Do not use with an extension cord or receptacle
unless the plug can be fully inserted. Precautions should be taken so
that the grounding scheme on the unit is not defeated.
Hazards
Do not place this product on an unstable cart, stand, tripod, bracket or
table. The product may fall, causing serious personal injury and serious
damage to the product. Use only with cart, stand, tripod, bracket, or
table recommended by the manufacturer or sold with the product.
Follow the manufacturer’s instructions when installing the product and
use mounting accessories recommended by the manufacturer.
The apparatus should not be exposed to dripping or splashing water;
no objects filled with liquids should be placed on the apparatus.
Terminals marked with the “lightning bolt” are hazardous live; the
external wiring connected to these terminals require installation by an
instructed person or the use of ready made leads or cords.
No naked flame sources, such as lighted candles, should be
placed on the apparatus.
Power Cord
The AC supply cord should be routed so that it is unlikely that it will be
damaged. If the AC supply cord is damaged DO NOT OPERATE THE UNIT.
Service
The unit should be serviced only by qualified service personnel.
AVIS:
AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE,
N’ENLEVEZ PAS LE COUVERT (OU LE PANNEAU ARRIERE)
NE CONTIENT AUCUNE PIECE
REPARABLE PAR L’UTILISATEUR.
CONSULTEZ UN TECHNICIEN QUALIFIE
POUR L’ENTRETIENT
INSTRUCTIONS RELATIVES AU RISQUE
DE FEU, CHOC ÉLECTRIQUE, OU
BLESSURES AUX PERSONNES
Veuillez Lire le Manuel
Il contient des informations qui devraient êtres comprises
avant l’opération de votre appareil. Conservez S.V.P. ces
instructions pour consultations ultérieures.
Emballage
Conservez la boite au cas ou l’appareil devait être
retourner pour réparation.
Attention:
Lors de l’utilisation de produits électrique, assurez-vous
d’adhérer à des précautions de bases incluant celle qui
suivent:
Alimentation
L’appareil ne doit être branché qu’à une source d’alimentation
correspondant au voltage spécifié dans le manuel ou tel qu’indiqué sur
l’appareil. Cet appareil est équipé d’une prise d’alimentation polarisée.
Ne pas utiliser cet appareil avec un cordon de raccordement à moins
qu’il soit possible d’insérer complètement les trois lames. Des
précautions doivent êtres prises afin d’eviter que le système de mise à
la terre de l’appareil ne soit désengagé.
Risque
Ne pas placer cet appareil sur un chariot, un support, un trépied ou une
table instables. L’appareil pourrait tomber et blesser quelqu’un ou subir
des dommages importants. Utiliser seulement un chariot, un support,
un trépied ou une table recommandés par le fabricant ou vendus avec
le produit. Suivre les instructions du fabricant pour installer l’appareil et
utiliser les accessoires recommandés par le fabricant.
Il convient de ne pas placer sur l’appareil de sources de flammes
nues, telles que des bougies allumées.
L’appeil ne doit pas être exposé à des égouttements d’eau ou des
éclaboussures et qu’aucun objet rempli de liquide tel que des vases
ne doit être placé sur l’appareil.
Les dispositifs marqués d’une symbole “d’éclair” sont des parties
dangereuses au toucher et que les câblages extérieurs connectés à
ces dispositifs de connection extérieure doivent être effectivés par un
opérateur formé ou en utilisant des cordons déjà préparés.
Cordon d’Alimentation
Évitez d’endommager le cordon d’alimentation. N’UTILISEZ PAS
L’APPAREIL si le cordon d’alimentation est endommagé.
Service
Consultez un technicien qualifié pour l’entretien de votre appareil.

AP6040 Parts List 4/6/2006
YS # Description Qty. YS # Description Qty. YS # Description Qty.
3562 16 PIN SOCKET W3116T WINSLOW 1 4520 _10K TRIM POT 4 4864 1/4W 2K7 5% T&R RES 4
5906 RED 3MM LED 1V9 20MA .4SPCER T&R 3 2444 25.0 AMP CIRCUIT BREAKER 1 6124 1/4W 3K 5%MINI T&R RES 12
5908 GRN 3MM LED 1V9 20MA .4SPCER T&R 3 714 1.5 MIL X 36" CLEAR POLY SHEETING 4 6136 1/4W 3K3 5%MINI T&R RES 8
6419 BRIDGE 35A 400V WIRE LEAD GI3504 3 3820 ___4UH COIL 14AWG ZOBEL HORIZONTAL 4 4774 1/4W 4K12 1% T&R RES 2
6425 BAV21 200V 0A25 DIODE T&R 24 3441 CLIP 250X032 16-14AWG RIGHT ANGLE 28 4827 1/4W 4K7 5% T&R RES 1
6825 1N4148 75V 0A45 DIODE T&R 100 3459 QUIK DISCNCT TERM 250X032 10-12AWG 2 4982 1/4W 4K7 5%MINI T&R RES 34
6438 1N4007 400V 1A0 DIODE T&R 13 3470 CLIP 250X032 14-16AWG DISCO-LOK 8 6128 1/4W 4K99 1%MINI MF T&R RES 8
6934 MR854 400V 3A0 DIODE FASREC 32 3485 CLIP 250X032 18-22AWG RIGHT ANGL 1 4978 1/4W 6K8 5%MINI T&R RES 2
6439 1N5225B 3V0 0W5 ZENER 5% T&R 2 3492 GROUND LUG FOR NO8-10 STUD 1 6121 1/4W 6K98 1%MINI MF T&R RES 8
6440 1N750ARL 4V7 0W5 ZENER 5% T&R 6 3601 RING TERMINAL 16AWG WIRE & #8 SCREW 1 4887 1/4W 7K5 5% T&R RES 2
6436 1N753ARL 6V2 0W5 ZENER 5% T&R 4 3682 250 MALE PCB TAB REEL 42 4663 1/2W 8K2 5% T&R RES 2
6461 1N5240BRL 10V0 0W5 ZENER 5% T&R 2 3380 RED ON LEFT DUAL BINDING POST TPP5 1 4990 1/4W 8K2 5%MINI T&R RES 8
6486 1N5244B 14V0 0W5 ZENER 5% T&R 4 3385 RED ON RIGHT DUAL BINDING POST TPP5 1 4762 1/4W 9K760 0.1% *** T&R RES 8
6822 1N4745A 16V0 1W0 ZENER 5% T&R 8 3498 1/4" JCK PCB MT HORZ 2 4829 1/4W 10K 5% T&R RES 2
6824 1N5246B 16V0 0W5 ZENER 5% T&R 4 6956 SPKON 4C PCB MT HORZ GRY #4 2 6116 1/4W 10K0 1%MINI MF T&R RES 32
6432 1N5248B 18V0 0W5 ZENER 5% T&R 2 3417 6-32 SCREW TERMINAL PC MNT SNAP-IN 4 4856 1/4W 12K 5% T&R RES 12
6465 1N5250B 20V0 0W5 ZENER 5% T&R 4 3922 XLR FEML PCB MT HORZ THIN SNAP-IN 2 4630 1/2W 15K 5% T&R RES 8
6463 1N5251BRL 22V0 0W5 ZENER 5% T&R 1 3451 EYELET SMALL 0.089 OD PLATED 83 4830 1/4W 15K 5% T&R RES 6
6466 1N5256B 30V0 0W5 ZENER 5% T&R 3 3864 FAN 92MM X 92MM 60CFM 24VDC 2 4876 1/4W 16K 5% T&R RES 2
6433 1N5257B 33V0 0W5 ZENER 5% T&R 2 3894 AAVID 5972-B H/S W/TAB B.O. 4 4771 1/4W 17K8 1% T&R RES 4
5101 BC550C TO92 NPN TRANSISTOR T&R 32 3501 B52200F006 COMP WASH #4 SMALL 32 6125 1/4W 18K 5%MINI T&R RES 8
5102 BC560C TO92 PNP TRANSISTOR T&R TB 28 8433 AP SERIES PLASTIC KNOB 2 6123 1/4W 20K0 1%MINI MF T&R RES 8
5103 MPSA06 TO92 NPN TRANSISTOR T&R TA 4 8661 BUTTON KNOB FLAT GREY 4 6118 1/4W 22K 5%MINI T&R RES 8
5107 2N5551 TO92 NPN TRNSISTR DARL T&RTA 4 8437 FAN FILTER LABEL 1 4840 1/4W 33K 5% T&R RES 4
5108 2N5401 T092 PNP TRNSISTR DARL T&RTA 8 3401 30 AMP 125V TWISTLOC PLUG 1 4853 1/4W 39K 5% T&R RES 4
6854 2N6517 TO92 NPN TRANSISTOR TA 8 3839 STRAIN RELEIF 0.8 INCH W/DOME NUT 1 4834 1/4W 47K 5% T&R RES 3
5105 MPSA13 TO92 NPN TRANS DARL T&R 1 8261 GE VELVET/MATTE LEXAN .007"X12"X24" 0.5 6119 1/4W 47K 5%MINI T&R RES 6
5106 MPSA63 TO92 PNP TRNSISTR DARL T&RTA 1 3638 12 CIR CABLE HOLDER .098 2 4835 1/4W 56K 5% T&R RES 4
6814 MJF6668 T221D PNP TRAN DARL TJ 1 3676 8 CIR CABLE HOLDER .098 1 4836 1/4W 68K 5% T&R RES 2
6815 MJF6388 T221D NPN TRNSISTR DARL TJ 2 5989 4 CIR CABLE HOLDER .098 2 4586 1/4W 82K 5%MINI T&R RES 10
6873 MJE340 TO126 NPN TRANSISTOR TG 12 8701 4-40 KEPS NUT ZINC 35 4838 1/4W 100K 5% T&R RES 3
6874 MJE350 TO126 PNP TRANSISTOR TG 12 8666 6-32 X 1/4" INSERT CFS0632-8 2 4851 1/4W 120K 5% T&R RES 2
6752 IRF630NPBF TO220 NCH MFET TN 4 8760 6-32 KEPS NUT TIN PLATED 96 4894 1/4W 130K 5% T&R RES 2
6933 MTP23P06 TO220 PCH TRNSISTR MFET TN 4 8800 6-32 KEPS NUT ZINC 10 4790 2.0W 150K 5%10MM BODY T&R RES 4
6909 MJ21196 TO3 NPN TRANSISTOR TH 24 8844 6-32 PEMNUT 4 4841 1/4W 220K 5% T&R RES 1
6989 MJL1302A TO3P PNP TRANSISTOR TK 4 8841 10-32 KEPS NUT ZINC 3 6126 1/4W 220K 5%MINI T&R RES 16
6990 MJL3281A TO3 NPN TRANSISTOR TK 4 3797 TO-247 THERMO CONDUCTIVE PAD 8 6127 1/4W 470K 5%MINI T&R RES 6
6910 MJ21195 TO3 PNP TRANSISTOR TH 24 3823 TO-220 THERMO PAD SMALL HOLE 12 4844 1/4W 1M 5% T&R RES 2
6840 MC33078P IC DUAL OP AMP 3 3846 TO220 THERMO PAD LARGE HOLE 56359B 8 4888 1/4W 4M7 5% T&R RES 2
6884 NE5532N IC DUAL OP AMP 4 3916 TO3 SIL-PAD REPLACES MICA 48 6132 1/4W 8M2 5%MINI T&R RES 2
6745 LM13600N IC XCONDUCTANCE AMP 2 8498 6-32 X 3/8 STEEL PEM STUD 6 4751 1/4W 22M 5% T&R RES 2
5190 MBS4992 TO92 8V5 TRNSISTR DIAC T&R 2 3580 12 CIR WAFER W/LCK VT 0.1" 2 3618 STAR RING TERMINAL14-16AWG #10SCREW 5
6517 STM-BTB-600BRG TO220 ??A TRIAC 600V 2 3583 _8 CIR WAFER W/LCK 0.1" 1 3700 RELAY 2C 01AMP DC24 015MA PC-S 2
5191 MCR100-6 TO92 0.8A SCR 600V 1 4597 22AWG STRAN TC WIR JMP 51 3722 RELAY 1A 30AMP DC24 036MA PC-C 1
6880 4N35 OPTO-COUPLER 4 4599 22AWG SOLID SC WIR T&R JMP 147 8870 #4 X 1/4 PAN PH TYPE A ZINC 2
6478 AS35FN-TO92 TEMPERATURE SENSOR 2 5299 24AWG SOLID SC WIR RAD JMP 32 8865 4-40 X 5/16 PAN PH MS JS500 4
6489 5R0 20% NTC THERMISTOR-SURGTR 2 4745 5.0W 0R1 5% BLK RES 25 8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK 8
5401 _10P 500V 5%CAP T&R RAD CER.2"NPO 12 2005 1.0W 0R47 5%FLAME PROOF T&R RES 4 8861 4-40 X 3/8 PAN PH MS JS500 3
5410 100P 100V 10%CAP T&R BEAD NPO 2 2006 1.0W 1R 5%FLAME PROOF T&R RES 1 8741 4-40 X 1/2 PAN PH MS JS500 20
5197 220P 100V 2%CAP T&R RAD CER.2"NPO 12 2007 1/4W 1R 5%FLAME PROOF T&R RES 24 8871 4-40 X 5/8 PAN PH MS JS500 8
5412 220P 100V 10%CAP T&R BEAD NPO 4 4677 1/2W 1R 5% T&R RES 8 8799 #6 X 1/4 PAN PH TYPE B JS500 4
5206 __1N 400V 5%CAP T&R RAD .2"FLM 10 4911 1/4W 2R2 5% T&R RES 16 8832 6-32 X 1/4 PAN PH TAPTITE JS500 7
5273 __1N5 200V 5%CAP T&R RAD CER.2"NPO 2 4748 2.0W 3R9 5% T&R 8 8807 6-32 X 5/16 PAN PH MS JS500 2
5208 __2N2 400V 5%CAP T&R RAD .2"FLM 14 4733 5.0W 5R6 5% BLK RES 4 8801 6-32 X 3/8 PAN PH TAPTITE JS500 4
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC 1 2009 1/4W 10R 2%FLAME PROOF T&R RES 2 8829 6-32 X 3/8 FLAT PH TAPTITE BO#4 HEA 40
5272 __6N8 100V 5%CAP T&R RAD .2"FLM 8 2010 1/8W 10R0 2%FLAME PROOF T&R RES 12 8761 6-32 X 1/2 PAN PHIL MS ZINC CLEAR 96
5834 _10N 250V 20%CAP BLK RAD POLY FLM 4 4875 1/4W 10R 5% T&R RES 2 8999 8-32 X 5/8 PAN PH TAPTITE JS500 20
5210 _22N 100V 10%CAP T&R RAD .2"FLM 17 2039 1/4W 22R0 FUSIBLE T&R RES 4 8809 10-32 X 1/4 PAN PH TAPTITE JS500 8
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC 2 2016 1/8W 39R 2%FLAME PROOF T&R RES 36 8753 #10 X 1/2 PAN PH TYPE A JS500 BLACK 3
5226 _68N 100V 5%CAP T&R RAD .2"FLM 4 4811 1/4W 68R 5% T&R RES 4 8773 10-32 X 1 1/4 PN PH TT FULL THD JS5 3
5228 100N 100V 5%CAP T&R RAD .2"FLM 16 2018 1/8W 75R 2%FLAME PROOF T&R RES 16 8772 1/4-20 X 1 TRUSS PH MS JS500 BLACK 2
5314 100N 50V 10%CAP T&R BEAD X7R 4 2019 1/8W 100R0 1%FLAME PROOF T&R RES 32 8663 11/64 NYLON SPACER (MICRO PLASTIC) 96
5229 150N 63V 10%CAP T&R RAD .2"FLM 4 4987 1/4W 120R 5%MINI T&R RES 4 3752 SNAP IN 1/4 SPACER RICHCO 3
5231 220N 63V 10%CAP T&R RAD .2"FLM 2 4984 1/4W 150R 5%MINI T&R RES 20 8629 10-32 X 1/4 SPACER PHENOLIC 12
5882 220N 250VDC 10%CAP BLK RAD POLY FLM 8 2021 1/4W 200R 1%FLAME PROOF T&R RES 12 8851 .250 SPACER ID.190 OD.31 ALUMINUM 6
5234 470N 63V 10%CAP T&R RAD .2"FLM 1 4977 1/4W 220R 5%MINI T&R RES 12 3743 SNAP ON 0.5" SPACER RICHCO 6
5322 470N 50V 10%CAP T&R BEAD Z5U 2 2046 1/4W 241R FUSIBLE T&R RES 8 3851 1/2 PCB PLASTIC SPACER 3
5255 __1U 63V 20%CAP T&R RAD .2"EL 4 4867 1/4W 270R 5% T&R RES 2 8667 SHOULDER WASHER SWS-229 LENGTH 1/8 8
5259 __4U7 63V 20%CAP T&R RAD .2"EL 10 4945 1/4W 270R 5% .2"U T&R RES 2 3517 NYLON WASHER #8 0.062 1
5629 _10U 160V 20%CAP BLK 10X13MM EL 8 4855 1/4W 330R 5% T&R RES 2 8818 3/4 OD X 3/8 ID X .080 THICK WASHER 1
5945 _10U 63V 20%CAP T&R RAD .2"EL 9 4736 5.0W 390R 5% BLK RES 2 3511 #6 FLAT WASHER NYLON 2
5260 _22U 50V 20%CAP T&R RAD .2"EL 10 4980 1/4W 470R 5%MINI T&R RES 12 8852 #6 INTERNAL TOOTH LOCKWASHER 1
5961 _33U 16V 20%CAP T&R RAD .2"NP 14 2030 1/8W 681R 1%FLAME PROOF T&R RES 24 3436 DPDT PUSH SW PCMT H BREAK B4 MAKE 4
5267 100U 25V 20%CAP T&R RAD .2"EL 3 2033 1/8W 1K 2%FLAME PROOF T&R RES 16 3587 DPDT ROKR SW QUIK 250"AC/PWR ON-OFF 1
5914 100U 63V 20%CAP BLK 10X13MM EL 1 4726 5.0W 1K 5% BLK RES 9 CH1194 AP6040 125VAC 60HZ T'RD 1
5630 330U 25V 20%CAP BLK 10X13MM EL 12 4823 1/4W 1K 5% T&R RES 4
5618 470U 25V 20%CAP BLK 10X15MM EL 1 4988 1/4W 1K5 5%MINI T&R RES 8
5895 6800U 63V 20% CAPACITOR BLK 25X50MM 12 4791 1/4W 1K54 1% T&T RES 4
5898 8200U 50V 20% CAPACITOR 25X50MM ELS 12 6113 1/4W 2K 5%MINI T&R RES 10
4390 _10K AUD 16MM DETENT P22 2 6104 1/4W 2K2 5%MINI T&R RES 8

INSTRUCTIONS PERTAINING TO A RISK
OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Read Instructions:
The
Owner's Manual
should be read and understood
before operation of your unit. Please, save these
instructions for future reference.
Packaging:
Keep the box and packaging materials, in case the unit
needs to be returned for service.
Warning:
When using electric products, basic precautions should
always be followed, including the following:
Power Sources:
Your unit should be connected to a power source only of the
voltage specified in the owners manual or as marked on the unit.
This unit has a polarized plug. Do not use with an extension cord or
receptacle unless the plug can be fully inserted. Precautions should
be taken so that the grounding scheme on the unit is not defeated.
Hazards:
Do not place this product on an unstable cart, stand, tripod, bracket or
table. The product may fall, causing serious personal injury and serious
damage to the product. Use only with cart, stand, tripod, bracket, or table
recommended by the manufacturer or sold with the product. Follow the
manufacturer's instructions when installing the product and use mounting
accessories recommended by the manufacturer.
The apparatus should not be exposed to dripping or splashing
water; no objects filled with liquids should be placed on the
apparatus.
Terminals marked with the “lightning bolt” are hazardous live;
the external wiring connected to these terminals require installation
by an instructed person or the use of ready made leads or cords.
No naked flame sources, such as lighted candles, should be
placed on the apparatus.
Power Cord:
The AC supply cord should be routed so that it is unlikely that it will
be damaged. If the AC supply cord is damaged DO NOT
OPERATE THE UNIT.
Service:
The unit should be serviced only by qualified service personnel.
INSTRUCTIONS RELATIVES AU RISQUE
DE FEU, CHOC ÉLECTRIQUE, OU
BLESSURES AUX PERSONNES.
AVIS:
AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE,
N'ENLEVEZ PAS LE COUVERT (OU LE PANNEAU
ARRIERE). NE CONTIENT AUCUNE PIECE REPARABLE
PAR L'UTILISATEUR.
CONSULTEZ UN TECHNICIEN QUALIFIE
POUR L'ENTRETIENT.
Veuillez lire le manuel:
Il contient des informations qui devraient êtres comprises avant
l'opération de votre appareil. Conservez S.V.P. ces instructions
pour consultations ultérieures
Emballage:
Conservez la boite au cas ou l'appareil devait être
retourner pour réparation.
Warning:
Attention: Lors de l'utilisation de produits électrique,
assurez-vous d'adhérer à des précautions de bases
incluant celle qui suivent:
Alimentation:
L'appareil ne doit être branché qu'à une source d'alimentation
correspondant au voltage spécifié dans le manuel ou tel qu'indiqué
sur l'appareil. Cet appareil est équipé d'une prise d'alimentation
polarisée. Ne pas utiliser cet appareil avec un cordon de
raccordement à moins qu'il soit possible d'insérer complètement les
trois lames. Des précautions doivent êtres prises afin d'eviter que le
système de mise à la terre de l'appareil ne soit désengagé.
Hazard:
Ne pas placer cet appareil sur un chariot, un support, un trépied ou une
table instables. L'appareil pourrait tomber et blesser quelqu'un ou subir des
dommages importants. Utiliser seulement un chariot, un support, un trépied
ou une table recommandés par le fabricant ou vendus avec le produit.
Suivre les instructions du fabricant pour installer l'appareil et utiliser les
accessoires recommandés par le fabricant.
Il convient de ne pas placer sur l'appareil de sources de flammes
nues, telles que des bougies allumées.
L'appeil ne doit pas être exposé à des égouttements d'eau ou des
éclaboussures et qu'aucun objet rempli de liquide tel que des vases
ne doit être placé sur l'appareil.
Les dispositifs marqués d'une symbole “d'éclair” sont des parties
dangereuses au toucher et que les câblages extérieurs connectés à
ces dispositifs de connection extérieure doivent être effectivés par un
opérateur formé ou en utilisant des cordons déjà préparés.
Cordon d'alimentation:
Évitez d'endommager le cordon d'alimentation. N'UTILISEZ PAS
L'APPAREIL si le cordon d'alimentation est endommagé.
Service:
Consultez un technicien qualifié pour l'entretien de votre appareil.
IMPORTANT SAFETY INSTRUCTIONS
SAFE_V4.doc Version 4.0 02/11/99 11:54 AM
AP6040 Parts List 5/18/00
YS #
Description
Qty.
YS #
Description
Qty.
YS #
Description
Qty.
3562
16 PIN SOCKET W3116T WINSLOW
1
5914
100U 63V 20%CAP BLK 10X13MM EL
1
6124
1/4W 3K 5%MINI T&R RES
12
3747
CUSTOM .5 LED SPACER BLACK
4
5630
330U 25V 20%CAP BLK 10X13MM EL
12
6136
1/4W 3K3 5%MINI T&R RES
8
5906
RED 3MM LED 1V9 20MA .4SPCER T&R
3
5618
470U 25V 20%CAP BLK 10X15MM EL
1
4774
1/4W 4K12 1% T&R RES
2
6405
RED 3MM LED 1V7 5MA BRT
2
5895
6800U 63V 20%CAP BLK 25X50MM ELS
12
4827
1/4W 4K7 5% T&R RES
1
5908
GRN 3MM LED 1V9 20MA .4SPCER T&R
3
5898
8200U 50V 20%CAP RADIAL ELECT BULK
12
4982
1/4W 4K7 5%MINI T&R RES
34
6408
GRN 3MM LED 1V9 5MA FROSTED
2
4390
_10K AUD 16MM DETENT P22
2
6128
1/4W 4K99 1%MINI MF T&R RES
8
6419
BRIDGE 35A 400V WIRE LEAD GI3504
3
4520
_10K TRIM POT
4
4828
1/4W 6K8 5% T&R RES
2
6425
BAV21 200V 0A25 DIODE T&R
24
2444
25.0 AMP CIRCUIT BREAKER
1
4801
1/4W 6K98 1% T&R RES
8
6825
1N4148 75V 0A45 DIODE T&R
100
3820
___4UH COIL 14AWG ZOBEL HORIZONTAL
4
4887
1/4W 7K5 5% T&R RES
2
6438
1N4004 400V 1A0 DIODE T&R
13
3602
RING TERMINAL 18AWG WIRE & #8 SCREW
1
4663
1/2W 8K2 5% T&R RES
2
6934
MR854 400V 3A0 DIODE FASREC
32
3615
STAR RING TERMINAL 18 AWG #10 SCREW
6
4990
1/4W 8K2 5%MINI T&R RES
8
6439
1N5225B 3V0 0W5 ZENER 5% T&R
2
3682
250 MALE PCB TAB BULK CARTRIGE
42
4762
1/4W 9K760 0.1% *** T&R RES
8
6440
1N750ARL 4V7 0W5 ZENER 5% T&R
6
3380
RED ON LEFT DUAL BINDING POST TPP5
1
4829
1/4W 10K 5% T&R RES
1
6436
1N753ARL 6V2 0W5 ZENER 5% T&R
4
3385
RED ON RIGHT DUAL BINDING POST TPP5
1
6116
1/4W 10K0 1%MINI MF T&R RES
32
6461
1N5240BRL 10V0 0W5 ZENER 5% T&R
2
3498
1/4" JCK PCB MT HORZ
2
4856
1/4W 12K 5% T&R RES
12
6486
1N5244B 14V0 0W5 ZENER 5% T&R
4
6956
SPKON 4C PCB MT HORZ GRY #4
2
4630
1/2W 15K 5% T&R RES
8
6822
1N4745A 16V0 1W0 ZENER 5% T&R
8
3922
XLR FEML PCB MT HORZ THIN SNAP-IN
2
4830
1/4W 15K 5% T&R RES
6
6824
1N5246B 16V0 0W5 ZENER 5% T&R
4
3864
FAN 92MM X 92MM 60CFM 24VDC
2
4876
1/4W 16K 5% T&R RES
2
6432
1N5248B 18V0 0W5 ZENER 5% T&R
2
3894
AAVID 5972-B H/S W/TAB B.O.
4
4771
1/4W 17K8 1% T&R RES
4
6465
1N5250B 20V0 0W5 ZENER 5% T&R
4
3501
B52200F006 COMP WASH #4 SMALL
32
6125
1/4W 18K 5%MINI T&R RES
8
6463
1N5251BRL 22V0 0W5 ZENER 5% T&R
1
8498
6-32 X 3/8 STEEL PEM STUD
6
6123
1/4W 20K0 1%MINI MF T&R RES
8
6466
1N5256B 30V0 0W5 ZENER 5% T&R
3
3518
CLEAR PVC TUBING .500" DIA. 105'C
1
6118
1/4W 22K 5%MINI T&R RES
8
6433
1N5257B 33V0 0W5 ZENER 5% T&R
2
3788
QUICKON MALETAB
1
4840
1/4W 33K 5% T&R RES
4
5101
BC550C TO92 NPN TRAN T&R TB
33
3801
5/8" BUMPER BUTTON BLACK
6
4853
1/4W 39K 5% T&R RES
4
5102
BC560C TO92 PNP TRAN T&R TB
28
3803
NYLON SECUR-A-TACH MINI PLASTIC TIE
1
4834
1/4W 47K 5% T&R RES
9
5103
MPSA06 TO92 NPN TRAN T&R TA
3
3810
4" NYLON CABLE TIE
10
4835
1/4W 56K 5% T&R RES
4
5107
2N5551 TO92 NPN TRAN T&R TA
4
3827
SQUARE BUMPER BUTTON BLACK
5
4836
1/4W 68K 5% T&R RES
2
5108
2N5401 TO92 PNP TRAN T&R TA
8
8433
AP SERIES PLASTIC KNOB
2
4586
1/4W 82K 5%MINI T&R RES
10
6789
2N3904 TO92 NPN TRAN TA
1
8661
BUTTON KNOB FLAT GREY
4
4838
1/4W 100K 5% T&R RES
3
6854
2N6517 TO92 NPN TRAN TA
8
3401
30 AMP 125V TWISTLOC PLUG
1
4851
1/4W 120K 5% T&R RES
2
5105
MPSA13 TO92 NPN DARL T&R TA
1
3839
STRAIN RELEIF 0.8 INCH W/DOME NUT •
1
4894
1/4W 130K 5% T&R RES
2
5106
MPSA63 TO92 PNP DARL T&R TA
1
3638
12 CIR CABLE HOLDER .098
2
4790
2.0W 150K 5%10MM BODY T&R RES
4
6814
MJF6668 T221D PNP TRAN DARL TJ
1
3676
8 CIR CABLE HOLDER .098
1
4841
1/4W 220K 5% T&R RES
1
6815
MJF6388 T221D NPN TRAN DARL TJ
2
5989
4 CIR CABLE HOLDER .098
2
6126
1/4W 220K 5%MINI T&R RES
16
6873
MJE340 TO126 NPN TRAN TG
12
8701
4-40 KEPS NUT ZINC
35
6127
1/4W 470K 5%MINI T&R RES
2
6874
MJE350 TO126 PNP TRAN TG
12
3797
TO-247 THERMO CONDUCTIVE PAD
8
4844
1/4W 1M 5% T&R RES
2
6752
MTP10N15L TO220 NCH MFET TN
4
3815
TO3 PREGREASED MICA 56-03-2AP
48
4888
1/4W 4M7 5% T&R RES
2
6933
MTP23P06 TO220 PCH MFET TN
4
3823
TO-220 THERMO PAD SMALL HOLE
12
6132
1/4W 8M2 5%MINI T&R RES
2
6909
MJ21196 TO3 NPN TRAN TH
24
3846
TO220 THERMO PAD LARGE HOLE 56359B
8
4751
1/4W 22M 5% T&R RES
2
6989
MJL1302A TO3P PNP TRAN TK
4
3580
12 CIR WAFER W/LCK VT 0.1"
2
3706
13" 8C-26AWG RIB 1 W/LCK HDR 098
1
6990
MJL3281A TO3P NPN TRAN TK
4
3583
8 CIR WAFER W/LCK 0.1"
1
3612
23" 9C-24AWG RIBBON HITMP 0.1"
6910
MJ21195 TO3 PNP TRAN TH
24
4597
22AWG STRAN TC WIR JMP
49
3740
15" 12C-26AWG RIB 1 W/LCK HDR 098
1
6840
MC33078P IC DUAL OP AMP
3
4599
22AWG SOLID SC WIR T&R JMP
151
3519
28" 12C-26AWG RIB 1 W/LCK HDR 098
1
6884
NE5532N IC DUAL OP AMP
4
5299
24AWG SOLID SC WIR RAD JMP
30
3673
12" 16C-28AWG DIP HDR CABLE .05"
1
6745
LM13600N IC XCONDUCTANCE AMP
2
4745
5.0W 0R1 5% BLK RES
24
3700
RELAY 2C 01AMP DC24 ???MA PC-S
2
5190
MBS4992 TO92 8V5 DIAC
4
4974
1.0W 0R47 5%FLAME PROOF T&R RES
4
3722
RELAY 1A 30AMP DC24 036MA PC-C
1
6444
MAC224-4 TO220 40A TRIAC 200V
4
4677
1/2W 1R 5% T&R RES
8
9580
HEATSINK(TAPTREE) AP4020 LGTH 11'6"
5
5191
MCR100-6 TO92 SCR 600V 0.8A
1
4877
1/4W 1R 5%FLAME PROOF T&R RES
24
9583
BLACK 'U' EXTRUSION DIE #943
6880
4N35 OPTO-COUPLER
4
4973
1.0W 1R 5%FLAME PROOF T&R RES
1
9640
.025" FISHPAPER ( FLAT 48" SHEETS )
2
6478
AS35FN-TO92 TEMPERATURE SENSOR
2
4911
1/4W 2R2 5% T&R RES
16
8870
#4 X 1/4 PAN PH TYPE A ZINC
2
6489
5R0 20% NTC THERMISTOR-SURGTR
2
4748
2.0W 3R9 5% T&R
8
8729
#4 X 3/8 FLAT QUAD TYPE A JS500 BLK
8
5401
_10P 500V 5%CAP T&R RAD CER.2"NPO
12
4733
5.0W 5R6 5% BLK RES
4
8861
4-40 X 3/8 PAN PH MS JS500
7
5410
100P 100V 10%CAP T&R BEAD NPO
2
4594
1/8W 10R0 2%FLAME PROOF T&R RES
12
8741
4-40 X 1/2 PAN PH MS JS500
20
5197
220P 100V 2%CAP T&R RAD CER.2"NPO
12
4610
1/4W 10R 2%FLAME PROOF T&R RES
2
8871
4-40 X 5/8 PAN PH MS JS500
8
5412
220P 100V 10%CAP T&R BEAD NPO
4
4875
1/4W 10R 5% T&R RES
2
8799
#6 X 1/4 PAN PH TYPE B JS500
4
5201
470P 100V 5%CAP T&R RAD CER.2"NPO
2
4591
1/8W 22R1 1%FLAME PROOF T&R RES
4
8801
6-32 X 3/8 PAN PH TAPTITE JS500
4
5206
__1N 400V 5%CAP T&R RAD .2"FLM
4
4607
1/8W 39R 2%FLAME PROOF T&R RES
36
8829
6-32 X 3/8 FLAT PH TAPTITE BO#4 HEA
47
5273
__1N5 200V 5%CAP T&R RAD CER.2"NPO
2
4811
1/4W 68R 5% T&R RES
4
8761
6-32 X 1/2 PAN PHIL MS ZINC CLEAR
96
5208
__2N2 400V 5%CAP T&R RAD .2"FLM
14
4608
1/8W 75R 2%FLAME PROOF T&R RES
16
8999
8-32 X 5/8 PAN PH TAPTITE JS500
20
6451
__4N7 250V 20%CAP BLK 'Y' 10MM AC
1
4590
1/8W 100R0 1%FLAME PROOF T&R RES
28
8809
10-32 X 1/4 PAN PH TAPTITE JS500
8
5272
__6N8 100V 5%CAP T&R RAD .2"FLM
8
4987
1/4W 120R 5%MINI T&R RES
4
8753
#10 X 1/2 PAN PH TYPE A JS500 BLACK
3
5834
_10N 250V 20%CAP BLK RAD POLY FLM
4
4984
1/4W 150R 5%MINI T&R RES
20
8786
10-32 X 1 1/4 PAN QD MS JS500 BLACK
3
5210
_22N 100V 10%CAP T&R RAD .2"FLM
17
6201
1/4W 200R 1%FLAME PROOF T&R RES
12
8772
1/4-20 X 1 TRUSS PH MS JS500 BLACK
2
6435
_22N 275V 20%CAP BLK 'X2' 15MM AC
2
4977
1/4W 220R 5%MINI T&R RES
12
8663
11/64 NYLON SPACER (MICRO PLASTIC)
96
5226
_68N 100V 5%CAP T&R RAD .2"FLM
4
4606
1/8W 249R 2%FLAME PROOF T&R RES
8
8851
.250 SPACER ID.190 OD.31 ALUMINUM
6
5228
100N 100V 5%CAP T&R RAD .2"FLM
16
4867
1/4W 270R 5% T&R RES
2
3744
SNAP IN .375 SPACER RICHCO
4
5314
100N 50V 10%CAP T&R BEAD X7R
2
4945
1/4W 270R 5% .2"U T&R RES
2
3743
SNAP ON 0.5" SPACER RICHCO
6
5229
150N 63V 10%CAP T&R RAD .2"FLM
4
4855
1/4W 330R 5% T&R RES
2
3851
1/2 PCB PLASTIC SPACER
3
5231
220N 63V 10%CAP T&R RAD .2"FLM
2
4736
5.0W 390R 5% BLK RES
2
8667
SHOULDER WASHER SWS-229 LENGTH 1/8
8
5882
220N 250V 10%CAP BLK RAD POLY FLM
8
4980
1/4W 470R 5%MINI T&R RES
12
3517
NYLON WASHER #8 0.062
1
5234
470N 63V 10%CAP T&R RAD .2"FLM
1
4781
1/8W 681R 1%FLAME PROOF T&R RES
24
8818
3/4 OD X 5/16 ID X .08 THICK WASHER
1
5322
470N 50V 10%CAP T&R BEAD Z5U
2
4609
1/8W 1K 2%FLAME PROOF T&R RES
8
3511
#6 FLAT WASHER NYLON
2
5255
__1U 63V 20%CAP T&R RAD .2"EL
4
4726
5.0W 1K 5% BLK RES
9
3436
DPDT PUSH SW PCMT H BREAK B4 MAKE
4
5259
__4U7 63V 20%CAP T&R RAD .2"EL
10
4823
1/4W 1K 5% T&R RES
5
3587
DPDT ROKR SW QUIK 250"AC/PWR ON-OFF
1
5281
_10U 16V 20%CAP T&R RAD .2"NP
2
4981
1/4W 1K 5%MINI T&R RES
8
3417
PC SCREW TERMINAL PC MOUNT
2
5629
_10U 160V 20%CAP BLK 10X13MM EL
8
4988
1/4W 1K5 5%MINI T&R RES
8
8666
6-32 X 1/4" INSERT CFS0632-8
2
5945
_10U 63V 20%CAP T&R RAD .2"EL
13
4791
1/4W 1K54 1% T&T RES
4
1194
AP6040 125VAC 60HZ T'RD
1
5260
_22U 50V 20%CAP T&R RAD .2"EL
6
6113
1/4W 2K 5%MINI T&R RES
10
0
M1151 POWER SUPPLY AP6040 1PER 2OZ
1
5961
_33U 16V 20%CAP T&R RAD .2"NP
12
6104
1/4W 2K2 5%MINI T&R RES
8
0.9
M1150 POWER AMP AP6040 1PER 2OZ
2
5267
100U 25V 20%CAP T&R RAD .2"EL
3
4864
1/4W 2K7 5% T&R RES
4

120v 220n
C30B
4V7
1N750
ZD6B
1R
0.5W
R123B
2N5401
Q4
50V 22n
C38B
220K
R160B
2K
R63B
D26B
681R:FP
R174B
1K5
R27
400V1N
C51B
400V1N
C51A
100R
R182B
100R
R182A
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
D
D
D
D
D
NOV/29/04
AUG/31/04
NOV/22/01
.
SEP/24/01
V
V
V
V
V
8.10
.
1.30
.
1.20
N
N
N
N
N
FIX ERROR , C11A/B,C12A/B 16V->50V
R99A/B,R100A/B 249R->241R FUSIBLE
PC#6472_ADD_R182A,R182B,C51A,C51B
R181B
PC#6454_C50A_470P->1N_ADD_R181A,
AP6040
M1150.SCH_DATABASE_HISTORY
470K
R181B
470K
R181A
D21A
2R2
R165B
SHEET OF
YORKVILLE NAME: PCB#&VER:
MODELS: SCH VERSION:
TITLE:
DATE: 1
M1150
POWER_AMP
AP6040
M1150.SCH
NOV/22/2001
2000W.PWR.AMP
8.10
1N4004
D37
6V2
500mW
ZD8
220R
R32
A
C
NC
E
C
B
4N35
U5
1
2
34
5
6
D20A
4u7
10v
C16A
1N4004
D38
500mW
6V2
ZD9
220R
R33
A
C
NC
E
C
B
4N35
U6
1
2
34
5
6
FP
200R
R109A
FP
39R
R87A
4U7
10V
C17A
MJE340
Q17A
MJE350
Q18A
FU
241R
R99A
MJE350
Q24A
FU
241R
R100A
330u
16v
C20A MJE340
Q23A
FP
39R
R104A
FP
200R
R106A
FP
39R
R105A
150K
2WATT
R81A
1K
5W
R131A
1K5
R28
BC550
Q14B
75R
R73B
75R
R72B
BC560
Q9B
BC550
Q14A 75R
R73A
75R
R72A 10R
R82A
D6A
10p
200v
C15A
10K:1%
R60A
D19A
D18A
D17A
MJE340
Q12A
MJE350
Q11A
4148
D41A
4148
D39A
BC560
Q9A
100R
R71A
10R
R85A
BC550
Q13A
BC560
Q10A
1K
R168B
17K8:1%
R61A
3K
R62A
2K
R70A
BAV21
D42A
4K7
R55A
4K7
R59A
BAV21
D40A
1K
R67A
1K
R66A
MR854
D29B
2N5401
Q8A
2N5551
Q7A
4K7
R58A
4K7
R56A
10p
200v
C14A
D14A
D13A
D11A
D12A
220R
R57A
22u
50v
C12A
22u
50v
C11A
10u
120v
C19A
10u
120v
C18A
10R
R86A
100R
R74A
MJL1302A
Q26A
4K7
R59B
4K7
R55B
8K2
R80A
CLP
LVGND
-15 +15 PRT SIG REF LIM TMP
681R:FP
R170A
4148
D2
4148
D1
PURP
-42
FP
22R
R103A
BC550
Q20A
BC550
Q22A
BC560
Q21A
BC560
Q19A
2R2
R90A
2R2
R91A
150R
R94A
150R
R96A
2K7
R95A
CW
10K
LIN
RTA
1N
C22A
2N2
C23A
12K
R98A
FP
39R
R78A
FP
75R
R84A
12K
R101A
350V
2N6517
Q27A
FP
150R
R89A
MJL3281A
Q25A
S
G
D
N
MTP10N15L
Q32A
FP
75R
R83A
39K
R102A
6K98
R93A
FP
200R
R108A
FP
150R
R92A
6K98
R97A
63V
10u
C24A
63V
10u
C25A 1W
16v
ZD11A
68R
R88A
120v
1n5
C21A
82K
R134A
22K
R135A
0R47
1W
R107A
22K
R138A
82K
R139A
0R1
5W
R149A
0R1
5W
R146A
100V220P
C2
100V220P
C1
0R1
5W
R150A
0R1
5W
R147A
10K0
R1
10K0
R3
0R1
5W
R151A
0R1
5W
R148A
10K0
R4
10K0
R2
4148
D3
47K
R18
100V10P
C6
100V10P
C5
BLUE
-100
BAV21
D28A
BAV21
D27A
120R
R152A
100R
R8
270R
R153A
100R
R10
7K5
R26
1K5
R25
MR854
D30A
1K5
R22
D6B
P
S
G
D
MTP23P06
Q33A
4K7
R20
14V
500mW
ZD4A
10K
R19
16V
500mW
ZD5A
30V
500mW
ZD2
330u
16v
C26A
330u
16v
C27A
200v 6N8
C35A
100R
R126A
1K
5W
R130A
100R
R124A
200v 6N8
C33A
MR854
D35A
100v 2N2
C34A
39R
R125A
100v 2N2
C36A
39R
R127A
10V
500mW
ZD1
220K
R21
MR854
D34A
1K
R167A
MR854
D33A
D25A
681R:FP
R173A
4148
D7
2R2
R165A
2R2
R162A
MR854
D32A
10K
R23
MJ21195
Q36B
D22A
MR854
D30B
D23A
150R
R120A
470R
R121A
16v 22n
C31A
16v 22n
C32A
3K
R110A
3K
R111A
4K7
R6
BC550
Q29A
220K
R118A
220K
R116A
1u
63V
C28A
4K7
R115A
D24A
350V
2N6517
Q28A
2K2
R114A
330R
R31
20K
R136A
681R:FP
R171B
681R:FP
R174A
4148
D5A
681R:FP
R175A
D5B
1N4004
D8
39R
R132A
39R
R133A
1R
0.5W
R122A
1R
0.5W
R123A
120v 220n
C29A
20K
R137A
3R9
2W
R156A
150v
10N
C39A
1N4004
D4
A06
Q1
20V
500mW
ZD7A
MR854
D36A
10K
R7
2K2
R112A
4K7
R113A
3A
2A
5A
6K8
R5
6A
1A
12K
R13
4A
BC550
Q2
1M
R24
4u7 63v
C7
18K
R117A
2N5401
Q3
12K
R17
C+ C-
K1
NC
COMNO
NC
COM
NO
100R
R16
100R
R15
100R
R12
100R
R11
18K
R9
16V
33U
C10B
33U16V
C9B
16V
33U
C10A
33U16V
C9A
.
D9B .
D10B
.
D9A .
D10A
10K0
R53B
4K99
R52B
BLK/BRN
OUT-
18K
R14
10K0
R51B
4K99
R50B
10K0
R51A
4K99
R50A
4K99
R52A
10K0
R53A
5532
1/2
(4=V-,8V+)
U1A
2
3
1
5532
1/2
(4=V-,8V+)
U1B
6
5
7
5532
1/2
(4=V-,8V+)
U3B
6
5
7
5532
1/2
(4=V-,8V+)
U3A
2
3
1
PIN 11
D
IABC
1/2
LM13600
(6=V-,11=V+)
U2B
13
15
14
16
12910
PIN 11
D
IABC
1/2
LM13600
(6=V-,11=V+)
U2A
4
2
3
1
587
68K
D21B
D20B
4u7
10v
C16B
FP
75R
R84B
FP
39R
R78B
4U7
10V
C17B
MJE340
Q17B
3K3
R76A
MJE350
Q18B
FP
75R
R83B
MJE350
Q24B
FP
39R
R77B
330u
16v
C20B MJE340
Q23B
FP
241R
R99B
FP
241R
R100B
FP
200R
R108B
150K
2WATT
R81B
10R
R82B
10p
200v
C15B
10K:1%
R60B
D19B
D18B 50V 22n
C37B
D17B
MJE340
Q12B
MJE350
Q11B
4148
D41B
4148
D39B
100R
R71B
47K
R54A
10R
R85B
BC550
Q13B
BC560
Q10B
17K8:1%
R61B
3K
R62B
2K
R70B
BAV21
D42B
22M
R177
BAV21
D40B
1K
R67B
1K
R66B
2N5401
Q8B
2N5551
Q7B
4K7
R58B
4K7
R56B
10p
200v
C14B
D14B
D13B
BC550
Q15A
D11B
D12B
220R
R57B
22u
50v
C12B
BC560
Q16A
22u
50v
C11B
10u
120v
C19B
3K3
R79A
8K2
R75A
10u
120v
C18B
10R
R86B
100R
R74B
MJL1302A
Q26B
8K2
R80B
681R:FP
R170B
1R
R142A
BC550
Q20B
BC550
Q22B
BC560
Q21B
1R
R144A
1R
R143A
1R
R141A
BC560
Q19B
2R2
R90B
2R2
R91B
150R
R94B
150R
R96B
2K7
R95B
CW
10K
LIN
RTB
1N
C22B
2N2
C23B
12K
R98B
FP
22R
R103B
FP
39R
R104B
12K
R101B
350V
2N6517
Q27B
FP
200R
R109B
MJL3281A
Q25B
S
G
D
N
MTP10N15L
Q32B
FP
39R
R77A
FP
39R
R105B
39K
R102B
6K98
R93B
FP
39R
R87B
FP
150R
R92B
6K98
R97B
63V
10u
C24B
63V
10u
C25B 1W
16v
ZD11B
16v
1W
ZD10B
68R
R88B
120v
1n5
C21B
16v
1W
82K
R134B
22K
R135B
0R47
1W
R107B
1R
R140A
1R
R145A
22K
R138B
82K
R139B
0R1
5W
R149B
0R1
5W
R146B
MJ21195
Q37A
0R1
5W
R150B
0R1
5W
R147B
0R1
5W
R151B
0R1
5W
R148B
MJ21196
Q43A
BAV21
D28B
BAV21
D27B
MJ21195
Q44A
MJ21196
Q39A
120R
R152B
270R
R153B
MJ21195
Q40A
MJ21196
Q35A
MJ21196
Q34A
MR854
D31B
MJ21196
Q42A
P
S
G
D
MTP23P06
Q33B
MJ21196
Q38A
14V
500mW
ZD4B
MJ21195
Q41A
16V
500mW
ZD5B
MJ21195
Q45A
MR854
D31A
330u
16v
C26B
681R:FP
R171A
MJ21195
Q36A
MR854
D29A
330u
16v
C27B
200v 6N8
C35B
1K
R168A
100R
R126B
1K
5W
R130B
1K
5W
R131B
100R
R124B
200v 6N8
C33B
MR854
D35B
100v 2N2
C34B
39R
R125B
100v 2N2
C36B
39R
R127B
MR854
D34B
1K
R167B
MR854
D33B
D25B
681R:FP
R173B
681R:FP
R172A
2R2
R162B
50V 22n
C37A
MR854
D32B
D22B
D23B
150R
R120B
470R
R121B
16v 22n
C31B
16v 22n
C32B
3K
R110B
3K
R111B
100V100N
BC550
Q29B
220K
R118B
220K
R116B
1u
63V
C28B
4K7
R115B
D24B
350V
2N6517
Q28B
2K2
R114B
20K
R136B
D9
4K7
R119A
FUNC
39R
R132B
39R
R133B
1R
0.5W
R122B
FUNC
120v 220n
C29B
FUNC
470R
R180A
33V
1N5257
ZD3
20K
R137B
3R9
2W
R156B
150v
10N
C39B
RED
+100
20V
500mW
ZD7B
4V7
1N750
ZD6A
MR854
D36B
2K2
R112B
4K7
R113B
3B
BAV21
D38B
2B
120v 220n
C30A
5B
6B
1B
4B
BAV21
D37B
18K
R117B
YEL
+42
RED/YEL
OUT+
3K3
R76B
47K
R54B
BAV21
D38A
BAV21
D37A
681R:FP
R175B
BC550
Q15B
BC560
Q16B
3K3
R79B
D26A
8K2
R75B
681R:FP
R172B
BC560
Q47B
1R
R142B
1R
R144B
1R
R143B
1R
R141B
FP
200R
R106B
BC550
Q46B
BC560
Q47A
1R
R140B
1R
R145B
470R
R29
400V1N
C50A
MJ21195
Q37B
MJ21196
Q43B
MJ21195
Q44B
MJ21196
Q39B
MJ21195
Q40B
MJ21196
Q35B
MJ21196
Q34B
MJ21196
Q42B
MJ21196
Q38B
MJ21195
Q41B
MJ21195
Q45B
IN
REF
OUT
AS35
U4
1
2
3
BC550
Q46A
2K
R63A
50V 22n
C38A
220K
R160A
FP
150R
R89B
4K7
R119B
-F15-F15
+15
+15
+15
RCLIM LCLIM
LVGND
LVGND
LVGND
CLP
CLP
-15
-15
AOG
AOG
AOG
AOG
AOG
AOG
AOG
-42
-42
-42
+42
+42
+42
+42
+42
BGD
BGD
BGD
BGD
-100
-100
-100
-100
-100
AGD
AGD
AGD
AGD
BOG
BOG
BOG
BOG
+100
+100
+100
+100
+100
+100
+100
FP
FP
FP
FP
FP
FP
FP
FP
FP
OVERHEAT SHUTDOWN
TEST POINT
U:\M1150V13.PRN

VCD
.020"
.012"
.008"
.005"
.020"
.012"
.008"
.005"
.020"
.012"
.008"
.005"
.020"
.012"
.008"
.005"
M1150-9.00
ASSEMBLY M1150-9.00
/FITV
USE 2OZ COPPER
WARNING
BOARDS
BEFORE REMOVING
SUPPLY WIRES
DISCONNECT POWER
BLANK SIZE=18.000" X 13.900"
ASSEMBLY M1150-8.10
U2C
33078P
U1
5532
U3
5532
220R
D5B
4148
D4
1N4004
D37
1N4004
Q24A
FUNCTION
MJE350
Q23A
FUNCTION
MJE340
Q17B
MJE340
FUNCTION
Q23B
FUNCTION
MJE340
Q24B
FUNCTION
MJE350
Q18B
MJE350
FUNCTION
ZD11A
16V/1W
ZD10A
16V/1W
ZD10B
16V/1W
ZD11B
16V/1W
J4C
J59
J66
J11
J48
J21
J37
J56
J42
J43
J163A
D37B
BAV21
D39B
4148
D40B
BAV21
D42B
BAV21
D41B
4148
D38B
BAV21
D38A
BAV21
D37A BAV21
Q20A
BC550
Q22A
BC550
Q21A
BC560
Q19A
BC560
Q47A
BC560
Q4C
BC560
Q5C
BC560
Q6C
BC560
Q29A
BC550
Q14A
BC550
Q9A
BC560
Q13A
BC550
Q10A
BC560
Q2
BC550
Q15A
BC550
Q16A
BC560
Q46A BC550
Q16B
BC560
Q15B
BC550
Q10B
BC560
Q13B
BC550
Q9B
BC560
Q14B
BC550
Q29B
BC550
Q19B
BC560
Q21B
BC560
Q22B
BC550
Q20B
BC550
Q47B
BC560
Q46B
BC550
Q3C
BC560
Q12A
MJE340
Q18A
MJE350
Q17A
MJE340
Q11A
MJE350
Q11B
MJE350
Q12B
MJE340
Q27A
2N6517
Q2C
A63
Q28A2N6517
Q4
2N5401
Q8A
2N5401
Q7A
2N5551
Q1
A06
Q3
2N5401
Q28B
2N6517
Q27B
2N6517
Q8B
2N5401
Q7B
2N5551
Q1C
A13
R122A
0.5W
1R
R123A
0.5W
1R
R123B
0.5W
1R
R122B
0.5W
1R
J2
TP3A
J5
TP1A
J39
J49
J50
TP4B
TP1B
TP6B
TP2B
TP3B
J38
J62
R131A
5W 1K
R130A
5W 1K
R130B
5W
1K
R131B
5W
1K
D5A
4148
D9C 4148
D22A
4148
D20A 4148
D6C 4148
R132A
39R
R133A
39R
R86A
10R
R78A
39R
R73B
75R
R78B
39R
R12100R
R74B
100R
R16100R
R57B
220R
R133B
39R
R132B
39R
R86B
10R
J61
ZD4A
14V
ZD5A
16V
ZD7A
20V
D2C
4V7
ZD6A
4V7
ZD6B
4V7
ZD7B
20V
ZD5B
16V
ZD4B
14V
ZD9
6V2
ZD3
33V
D1C
3V0
D27A BAV21
D28A BAV21
D25A
1N4148
D26A 1N4148
D9
4148
D39A 4148
D40A
BAV21
D42A
BAV21
D41A
4148
D21A 4148
R77B39R
D19A
4148
D18A 1N4148 D17A4148
D14A
4148 D13A
4148
D11A
4148
D12A
4148
D2 4148
4K7
D3
4148
R71B100R
D7
4148
R23
10K
D9A4148 D10A4148
D25B
4148
D24B
4148
D17B
4148
D18B
4148
D19B
4148
D20B4148
D21B4148
D26B
4148
D28B
BAV21
D27B
BAV21
D23B 4148
D22B 4148
R56B
4K7
R8 100R
D14B
4148 D13B
4148
D11B4148
D12B
4148
C5
10P
C6
10P
C1
220P
C2
220P
C21A
1n5
C14A
10p
C15A
10p
C22A 1N
C23A
2N2
C35A
6N8
C33A
6N8
C34A2N2
C36A
2N2
C31A
22n
C32A
22n
C37A
22n
C38A
22n
C42
100N
C02C
100N
C9 100N
C50
100N
C10
100N
C38B
22n
C37B
22n
C32B
22n
C31B
22n
C36B
2N2
C34B 2N2
C33B
6N8
C35B
6N8
C23B
2N2
C22B
1N
C15B
10p
C14B
10p
C21B
2N2
C01C
100N
C50A
1N
R89A
150R
R90A
2R2
R91A
2R2
R94A150R
R96A
150R
R95A
2K7
R98A
12K
R99A241R
R165A
2R2
R101A
12K
R93A 6K98
R92A
150R
R97A
6K98
R134A
82K
R124A
100R
R125A
39R
R121A
470R
R118A
220K
R115A
4K7
R142A
1R
R144A
1R
R143A
1R
R141A
1R
R140A
1R
R145A
1R
R160A
220K
R04C
15K
R177
22M
R59B
4K7
R60A
10K0
R61A
17K8
R18 47K
R5 6K8
R10
100R
R26
7K5
R22 1K5
D6A
4148
D8
4004
R21
220K
R28
1K5
D1
4148
R6
4K7
R7 10K
R13
12K
R24 1M
R17 12K
R54A
47K
R63A
2K
R88B
68R
R165B
2R2
R140B
1R
R141B
1R
R142B
1R
R137B
20K
R114B
2K2
R124B
100R
R126B
100R
R139B 82K
R134B
82K
R72B75R
R92B
150R
R93B
6K98
R101B
12K
R98B
12K
R95B
2K7
R96B
150R
R89B
150R
R31
330R
R53B
10K0
R51B
10K0
R61B
17K8
R62B
3K
R53C
220R
R52C
470R
R51C
220K
R49C
15K R48C4K7
R47C470R
R45C
4K12
C27C
100n
R42C 10K0
R41C 10K
R40C 4K12
R35C
10K0
R34C
470R
R33C
4K7
R32C
15K
R31C
220K
R30C
470R
R29C
220R
U2C1
10K
R7C
10K
R2C
100K
R4C 470K
R50C
15K
R1C
100K
R55B
220R
U5
4N35
U6
4N35
RTA
BIAS
10K
RTB
BIAS
10K
R107A
1W
0R47
R107B
1W
0R47
R156A
2W
3R9
R81A
2WATT
150K
R81B
2WATT
150K
R156B
2W
3R9
Q25A
PART#
FUNCTION
MJL3281A
Q26A
PART#
FUNCTION
MJL1302A
Q26B
PART#
FUNCTION
MJL1302A
Q25B
PART#
FUNCTION
MJL3281A
Q42A
21196
NPN
OUTPUT1
Q44A
21195
PNP
OUTPUT1
Q34A
21196
NPN
OUTPUT1
Q38A
21196
NPN
OUTPUT1
Q36A
21195
PNP
OUTPUT1
D31A
MR854
D29A
MR854
D30A
MR854
D30B
MR854
D29B
MR854
D31B
MR854
Q40A
21195
PNP
OUTPUT1
Q43A
21196
NPN
OUTPUT1
Q39A
21196
NPN
OUTPUT1
Q35A
21196
NPN
OUTPUT1
R146A
5W
0R1
R147A
5W
0R1
R148A
5W
0R1
R149A
5W
0R1
R150A
5W
0R1
R151A
5W
0R1
D33A
MR854
D32A
MR854
D34A
MR854
Q37A
21195
PNP
OUTPUT1
Q41A
21195
PNP
OUTPUT1
Q45A
21195
PNP
OUTPUT1
Q45B
21195
PNP
OUTPUT1
Q41B
21195
PNP
OUTPUT1
Q37B
21195
PNP
OUTPUT1
J9
J45
J25
J6C
R171A
681R
R168A
1K
R170A
681R
R173A
681R
R174A
681R
R172A
681R
R167A
1K
R82A
10R
R175A
681R
R84A
75R
R85A
10R
R83A
75R
R83B
75R
R84B
75R
R175B
681R
R82B
10R
R167B 1K
R174B
681R
R173B
681R
R168B 1K
C25A
10U 63V
C16A
4U7 63V
C36C 50V
22u
C24A
10U 63V
C28A
1U
63V
C12A
22U 50V
C11A
22U 50V
C17A
4U7 63V
C7
4U7
63V
C28B
1U
63V
C24B
10U
63V
C25B
10U
63V
C12B
22u
50V
C11B
50V
22u
C16B
4U7 63V
C17B
4U7
63V
C35C
50V
22u
R144B
1R
R30
68K
J22
11
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
NOV/26/99
OCT/18/99
SEP/16/99
AUG/24/99
.
.
.
.
.
AUG/10/99
MAY12/99
4.00
.
.
3.00
.
.
.
.
.
2.00
1.00
PC#6066_REPAIR_ERROR
#3673_RIBBON->#3562_SKT
PC#6098_CHANGES_AS_PER_PC
PC#6066_C126C_1_PIN_V-_->GND
PC#6033_R163A/R158A->J163A/J158A
ELIMINATE_SHORT_TO_SCREW
PC#6042_C50A_B_TO_C_Q24A_ADD_J63_TO
->4K99_R35C/R42C_20K0->10K0
PC#_____ADD_R30_R50A/B_R52A/B_10K0
PC#6043_RELAY_CONNECTIONS_ALTERED
PILOT_RUN_RELEASE
AP6040
M1150-PCB_DATABASE_HISTORY
R46C
15K
ZD1
10V
1
MX1
#3580
TO_M1151-POWER_SUPPLY_PCB
R111A
3K
R120A
150R
R15
100R
R136A
20K
R110A
3K
R116A 220K
R3C 470K
R119A
4K7
R117A
18K
R113A
4K7
ZD8
6V2
R135A
22K
R62A
3K
R75A
8K2
4004
D9B
4148
R70A
2K
R67A
1K
R66A
1K
R57A
220R
R59A
4K7
R79A
3K3
R2
10K0
R1
10K0
R3
10K0
R9
18K
R14
18K
R50A
4K99
D10B
4148
R52A
4K99
R51A
10K0
R53A
10K0
R80A
8K2
R52B4K99
R180A
470R
R4
10K0
R138A
22K
R145B
1R
R138B
22K
R80B
8K2
R79B
3K3
R70B
2K
R75B
8K2
R135B
22K
R113B
4K7
R117B
18K
R119B
4K7
R94B
150R
R116B
220K
R110B
3K
R136B 20K
R120B
150R
R111B
3K
R121B
470R
R97B
6K98
R63B
2K
R152A
120R
R160B
220K
R55A
4K7
R115B
4K7
R118B
220K
R152B
120R
R76A
3K3
R58B
4K7
R54B
47K
R67B
1K
R66B
1K
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1REDUCE_WIDTH_OF_PCB_EACH_SIDE_.125"
PC#_6262_MOVE_C20B_R86B
PC#6303_ADDÉC27C.C28C_
PC#6454_C50A_470P->1N_ADD_R181A,R181B
CORRECT_TRACE_AT_Q23B7.00
.
6.00
.
5.00MAY/08/00
.
SEP/24/01
.
NOV/19/01
D
D
D
D
D
D
JUL/05/05
SEP/15/04
AUG/31/04
JAN/15/02
NOV/22/01
V
V
V
V
V
V
9.00
8.10
.
8.00
.
N
N
N
N
N
N
PC#6844 REDO SOLDERMASK
C11A-C12A_10U/63V->22U/50V
R99A/B,R100A/B_249R->241R_FUSIBLE
NEW_SOLDERMASK_FOR_TABS
PC#6472_ADD_R182A,R182B,C51A,C51B
R50B
4K99
R5C
8M2
R76B
3K3
R32220R
R36C 8M2
J19
C29A
220N
250V
C30A
220N
250V
C30B
220N
250V
C29B
220N
250V
GS
Q33A
MTP23P06
FUNCTION
GSQ32A
MTP10N15L
FUNCTION
GS
Q32B
MTP10N15L
FUNCTION
GS
Q33B
MTP23P06
FUNCTION
R112A
2K2
R102A
39K
R112B
2K2
R162A
2R2
DOWN
BAR
D35A
MR854
DOWN
BAR
MR854
DOWN
BAR
MR854
DOWN
BAR
D35B
MR854
PART#
PART#
C26A
330u
16v
C19A
120v
10u
C20A
16v
330u
C27A
330u
16v
C18A
120v
10u
C20B
16v
330u
C18B
120V
10u
C27B
330u
16v
C19B
120v
10u
C26B
330u
16v
NO NC C
K1
AROMAT_RELAY
U2
LM13600
TB7
250TAB
OUT_B
TB6
250TAB
-100V
TB2
250TAB
+100V
C25C
16V
33u
C26C 16V
33u
C10B
33U
16V
C10A
33U 16V
C9B
16V
33U
C9A
33U 16V
J3
J4
J60
C51A
1N/400V
J63C
J17
J7
J15
J20
J35
J6
J16
J12
J24
J41
J34
J51
J32
R182A
100R
R11
100R
R58A
4K7
R126A
100R
R56A
4K7
D23A
4148
R19
10K
R87B
39R
R182B
100R
J26
J30
J29
R137A
20K
R25
1K5
R102B
39K
R114A
2K2
D24A
4148
J57
J31
D34B
MR854
D32B
MR854
D33B
MR854
R91B
2R2
1K5
J54
R151B
5W
0R1
R150B
5W
0R1
R149B
5W
0R1
R148B
5W
0R1
R147B
5W
0R1
R146B
5W
0R1
Q35B
21196
NPN
OUTPUT1
Q39B
21196
NPN
OUTPUT1
Q43B
21196
NPN
OUTPUT1
Q40B
21195
PNP
OUTPUT1
Q36B
21195
PNP
OUTPUT1
Q38B
21196
NPN
OUTPUT1
Q34B
21196
NPN
OUTPUT1
Q44B
21195
PNP
OUTPUT1
Q42B
21196
NPN
OUTPUT1
C39B
10N
250V
C39A
10N
250V
R71A
100R
R72A
75R
R73A
75R
R74A
100R
R77A
39R
R109B
200R
R109A
200R
R106B
200R
R100A
241R
R105A
39R
R127A
39R
R103A
22R
R106A
200R
R85B
10R
R103B
22R
R104B
39R
R127B
39R
R99B
241R
R100B
241R
R104A
39R
R105B
39R
R125B
39R
R108B
200R
R108A
200R
J58
J55
J64 J65
J23
J33
J47
R162B
2R2
R153B
270R
R90B
2R2
J28
J3C
R139A
82K
R60B
10K0
U4
AS35
D3C
3V0
ZD2
30V
LD6
SP
RED
LD1C
SP
GRN
LD2C
SP
GRN
LD6C
SP
RED
R153A
270R
R172B681R
R170B
681R R171B681R
J53
J40
J46
J44
J52
GUIDE
ETCH
GUIDE
ETCH
GUIDE
ETCH
GUIDE
ETCH
5W
0R1
16-PIN.SOCKET
C38C
220p C37C 220p
R39C
15K
R55C
220R
C22C
220n
C21C
220n
C127C
100n C126C
100n
C18C 100P
C17C
100P
C4C
470N
C3C
470N
C2C
220p
C1C
220p
P2C
10K
-
-
L_GAIN
P1C
-
10K
-
R_GAIN
R88A
68R
R87A
39R
R20
4K7
D6B
4148
R181A
470K
5W
0R1
TB5
250TAB
-42V
TB4
250TAB
OUT_B
TB3
250TAB
+42V
C28C
100n
R44C
10K
R181B
470K
J27
R29
470R
J158A
J8
C51B
1N/400V
R143B
1R
LIM
LVGND
REF
SIG
CLP
+100
PRT
AGD
+15
-42
TMP
GNDB
-15
+42
OG
-100
TB7
TB4
TB6
TB5
TB3
TB2
#8760 6-32 KEPS NUT
#8761 BOLT
Q32A,Q32A
MOUNTING HARDWARE FOR Q33A,Q33B
#3823 THERMO PAD
Q23A Q24A Q23B Q24B
MOUNTING HARDWARE FOR Q17B,Q18B
#3797 THERMO PAD
Q26B,Q25B
MOUNTING HARDWARE FOR Q26A,Q25A
R130A, R131A R130B AND R131B
14AWG
14AWG
14AWG
14AWG
BRN
T126 TYPE DEVICE
PRODUCTION NOTES
T264 DEVICE
#8741 4-40X 1/2" BOLT
BLU
YEL
RED
COOLED FROM WAVE SOLDER IS 6 INCH/LB
INITIAL TORQUE FOR TO-3'S IS 8 INCH/LB
MOUNTING DETAILS FOR 5W
OUTPUT -
OUTPUT +
TAB WIRE COLOURS
MOUNTING HARDWARE FOR TO3 OUTPUTS
TORQUE 4 INCH/LB
TORQUE 4 INCH/LB
TORQUE 4 INCH/LB
1
#8701 4-40 KEPS NUT
#8701 4-40 KEPS NUT
#8701 4-40 KEPS NUT
#8871 4-40X 1/2" BOLT
PCB
PCB
PCB
HEATSPREADER
HEATSPREADER
HEATSPREADER
HEATSPREADER
#3846 MICA
T-220 DEVICE
#8667 SHOULDER WASHER
#3501 BELL WASHER
#3501 BELL WASHER
#3501 BELL WASHER
#8741 4-40X 1/2" BOLT
5 WATT RESISTORS
ADD #8629 SPACERS ONLY ON
FINAL TORQUE AFTER HEATSINK HAS
#8663 SPACER
#3815 MICA
TO-3 TRANSISTOR
BOTH SIDES OF THE MICA PAD
MICA GREASE IS REQUIRED ON
ASSEMBLY M1150-9.00
FOR TEST JIG
FOR TEST JIG
HEAT SINK TOOLING PINS
HEAT SINK TOOLING PINS
HEAT SINK TOOLING PINS
HEAT SINK TOOLING PINS
METAL
METAL
METAL
METAL
BLANK SIZE=18.000" X 13.900"
VER 9.00
VER.9.00
IT IS NOT CONNECTED
Q17B AND Q18B
SPACER TO PROTECT
IS USED AS A
THIS RESISTOR
BEFORE REMOVING BOARDS
DISCONNECT POWER SUPPLY WIRES
WARNING
RED
YEL
SPKR OUT
BRN
BLUE
USE 2 OZ. COPPER
AP 6040
AP 6040
M1150
M1150
ASSEMBLY M1150-9.00
P:\1150VR8.PRN

10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
D
D
D
D
D
D
D
D
D
SEP/24/01
V
V
V
V
V
V
V
V
V
1.20
N
N
N
N
N
N
N
N
N
PC#6303_ADD_C27C,C28C
AP6040
M1150.SCH_DATABASE_HISTORY
15K
R46C
15K
R04C
50V
100N
C27C
4148
D9C
50V
100N
C28C
220R
R53C
470R
R52C
22u
16v
C36C
220K
R51C
15K
R49C
BC560
Q6C
4K7
R48C
470R
R47C
RED
LD6C
BC560
Q5C
(4=V-,8=V+)
1/2
MC33078P
U2C
2
3
1
15v 220p
C38C
4K12
R45C
33u16V
C26C
10K
R44C
CW
GAIN
25A
10K
P2C
3V0
1N5225B
D1C
100P
C18C
10K0
R42C
CW
GAIN
25A
10K
P1C
10K
R41C
33u16V
C25C
4K12
R40C
15v 220p
C37C
A63
Q2C
15K
R39C
(4=V-,8=V+)
1/2
MC33078P
U2C
6
5
7
BC560
Q4C
RED
LD5C
8M2
R5C
SHEET OF
YORKVILLE NAME: PCB#&VER:
MODELS: SCH VERSION:
TITLE:
DATE: 1
M1150
POWER_AMP_POT_PCB
AP6040
M1150.SCH
SEP/24/2001
2000W.PWR.AMP
8.10
100P
C17C
10K0
R35C
470R
R34C
4K7
R33C
BC560
Q3C
15K
R32C
220R
R55AC
220K
R31C
4148
D6C
22u
16v
C35C
470R
R30C
220R
R29C
500mW
4.7V
D2C
15K
R50C
A13
Q1C
10K
R8C
10K
R7C
3V0
1N5225B
D3C
GREEN
LD2C
GREEN
LD1C
220R
R55BC
8M2
R36C
470K
R3C
470K
R4C
15v220n
C21C
15v220n
C22C
220p
C1C
220p
C2C
100K
R1C
100K
R2C
25V
100n
C02C
50V
100n
C127C
25V
100n
C126C
25V
470N
C3C
25V
470N
C4C
25V
100n
C01C
LIMABLE
BREF
BREF
AREF
AREF
BCLP
BCLP
BLIM
LVGND
LVGND
LVGND
LVGND
LVGND
LVGND
ACLP
ACLP
ASPOST
+18V
+18V
+18V
+18V
+18V
+18V
+18V
BSPOST
ALIM
ASPRE
ASPRE
BSPRE
BSPRE
-18V
-18V
-18V
-18V
-18V
(V+)-3v
VOLUME CONTROL/ LIMITER
ACTIVITY LEDS CIRCUIT
LVGND
LIMABLE

22 22
21 21
20 20
19 19
18 18
17 17
16 16
15 15
14 14
13 13
12 12
11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
R
R
S
S
T
T
U
U
V
V
W
W
X
X
Y
Y
Z
Z
AA
AA
AB
AB
AC
AC
AD
AD
AE
AE
AF
AF
AG
AG
AH
AH
4
M1151-6V2sch.sch2002
Date:
Product
PCB# of
Rev:
Sheet 3
V6.20
Filename:
Fri May 12, 2006
M1151
{Drawing Number}
4
M1151-6V2sch.sch2002
Date:
Product
PCB# of
Rev:
Sheet 3
V6.20
Filename:
Fri May 12, 2006
M1151
{Drawing Number}
TAB
15 amps
25A
S5
C51
250V4N7
C50
275V22N
C68
50V8200U
C56
63V6800U
C80
16V33U
R26
1/4W
MINI
2K
GRN/YELL
C74
63V6800U
C62
50V8200U
WC10E
CSA
250V
C50E
680n
W64E
W67E
TAB
WC17E
CH1194E
3682
WC3YEL
100N 100V
C23
100N 100V
C20
R73
5.0W
.
390R
4007
D13
W11:H
W11:E
W11:C
8
W1:H 8
3
W1:C 8
1
W1:A 8
3682 GROUND
WC33
3682
BROWN
A- OUT
WC37
3682
BLUE
-100V
WC23
3682
WC26
3682
RED
+100V
WC29
W13:A
W13:C
W13:E
W13:G
W13:I
A
3682
BLUE
A+ OUT
WC36
3682
YEL
B+ OUT
WC35
W14:D
W14:B
3682
BLACK
B- OUT
WC34
4148
D8
4n7C51E
CSA
TAB TAB
TAB
DUMMY
3682
W15
1194E
3682
WC13
TRANSFORMER
R10
1/4W
0.1%
9K76
220P 100V
C12
R4
1/4W
0.1%
9K76
220P 100V
C4
R2
1/4W
0.1%
9K76
NTC
5R0
R29
6489
NTC
5R0
R27
6489
3682
BLUE
FROM SWITCH
WC19
K1:B
3722
3722
K1:A
3682
RED
TO SWITCH
WC5
1/4W
MINI
82K
R74A
R20
1/4W
.
120K
150N 63V
C17
4148
D2
R15
1/4W
.
56K
R16
1/4W
.
56K
C25
275V22N
100N 100V
C24
R19
1/4W
.
120K
4148
D1
R14
1/4W
.
56K
R13
1/4W
.
56K
68N 100V
C7
Q13
MPSA06
5103
TO92
4007
D15
R77
1/4W
.
33K
4007
D14
C64
50V8200U
C52
63V6800U
1
2-
3+
MC33078P
U1:A
8
V+
4V-
U1:C
In
Com
Out
S4:A
3436
GRND LIFT
In
Com
Out
S4:B
3436
GRND LIFT
R78
1/4W
.
220K
R79
1/4W
.
47K
R80B
1/4W
.
130K
R80A
1/4W
.
130K
C66
50V8200U
C67
50V8200U
C54
63V6800U
C55
63V6800U
C18
16V33U
In
Com
Out
S2:A
3436
LIMITER
In
Com
Out
S2:B
3436
LIMITER
C69
50V8200U
C57
63V6800U
W11:B
W11:A
W11:F
W11:D
R83
1/4W
.
10R
R82
1/4W
.
33K R95
1/2W
.
15K
R91
1/2W
.
15K
7
W1:G 8
2
W1:B 8
5
W1:E 8
4
W1:D 8
LVGNDOK
Tie Here
2+
2_
6956
SPEAKON 4C H
SPKON_A
J5:B
3682
BLUE
-100V
WC22
3682
RED
+100V
WC30
B
W13:B
W13:D
W13:F
W13:H
YELL
A+
.
W8
C82
16V33U
BLK
.
.
W10
R22
1/4W
.
10K
R23
1/4W
.
10K
4148
D16
4148
D17
2+
2_
6956
SPEAKON 4C H
Function
J6:B
R24
1/4W
.
47K
L43820
4UH
R38
5.0W
5R6
4148
D19
4148
D18
R59
1/4W
.
1K
W14:C
W14:A
R28
1/4W
.
47K
RED
LD1
PRT
5906
R25
1/4W
MINI
2K
BLACK
FAN1
{AWG}
W5
4148
D7
TO92
MPSA06
Q23
5103
C43
25V100U
BLACK
FAN2
{AWG}
W4
CBE
RED
FAN1
{AWG}
W6
R34
1/4W
.
1K
AGC
R70
1.0W
FLMP
1R
MJF6388
6815
Q11
T221D
FAN SUPPLY
4007
D12
4007
D11
GMT2MT1
MBS4992
S6
SCH_DPDT
R8
1/4W
0.1%
9K76
220P 100V
C13
In
Com
Out
S1:A
3436
STEREO/MONO
220P 100V
C3
R98
5.0W
390R
BRIDGE
BR2
Flat
6419
BRIDGE
BR3
Flat
6419
BRIDGE
BR1
Flat
6419
68N 100V
C16
150N 63V
C8
100N 100V
C21
C78
25V100U
1N5251BRL 22V0
D220W5
C58
50V8200U
C70
63V6800U
In
Com
Out
S3:B
3436
FILTER SWITCH
8
V+
4V-
U2:C
C79
63V100U
1/4W
.
100K
R81
C73
63V6800U
C60
50V8200U
C61
50V8200U
C72
63V6800U
R21
1/4W
.
33K
C75
63V6800U
C63
50V8200U
W11:G
G
MT1 MT2
TO220
Q16
6517
STM-BTB-600BRG
R93
1/2W
.
15K
R96
1/2W
.
15K
6
W1:F 8
W33
3417
G
MT1 MT2
TO220
STM-BTB-600BRG
Q20
6517
R60
1/4W
.
1K
R64
1/4W
.
16K
R63
1/4W
.
16K
1N5248B 18V0
D230W5
1N5256B 30V0
D240W5
TO92
BC550C
Q9
5101
22N 100V C45
C42
25V100U
RED
FAN2
{AWG}
W3
1N750ARL 4V7
D200W5
1+
1_
6956
SPEAKON 4C H
SPKON_A
J5:A
1+
1_
6956
SPEAKON 4C H
Function
J6:A
1N5248B 18V0
D210W5
FROM W64E AND DUMMY TAB
TRANSFORMER SHOWN WIRE D FOR
ORN
BRN/BLK
100N 100V
C19
TURN ON RELAY
3682
BLUE
FROM SWITCH
WC21
C77
63V 10U
3682 TRANSFORMER
WC6RED
3682
RED
TRANSFORMER
WC2
220P 100V
C2
C9
16V33U
3682
BROWN
-42V
WC25
1
W2:A
2
W2:B
3
W2:C
4
W2:D
5
W2:E
6
W2:F
7
W2:G
8
W2:H
9
W2:I
11
W2:K
10
W2:J
W13:K
R87
1/4W
.
10R
230VAC INPUT VOLTAGE. FOR 245VAC
SWITCH BROWN AND BRN \ BLK LEADS
TAB
WC13E
BRN
3682
GREEN
GROUND
WC17
3682
WHITE
POWER CORD
WC10
3682
BLACK
TRANSFORMER
WC7
3682
TO WC19 EURO
N/C FOR N.A.
WC4
R9
1/4W
.
1K54
3922
J4:A
1 3
5
6
4 2
SRT
-
--
J2
R3
1/4W
.
1K54
R1
1/4W
.
1K54
100N 100V
C22
Q14
BC550C
5101
TO92
R75
1/4W
.
1K
R76
1/4W
.
4K7
3682
RED WC20
TO SWITCH
3682
BLACK WC1
FROM BREAKER
1/4W
MINI
82K
R74B
C65
50V8200U
C53
63V6800U
R12
1/4W
0.1%
9K76
7
6-
5+U1:B
MC33078P
220P 100V
C11
150N 63V
C15
220P 100V
C10
R6
1/4W
0.1%
9K76
1
2-
3+U2:A
MC33078P
R5
1/4W
0.1%
9K76
220P 100V
C1
68N 100V
C5
5190
TO92
Q15
MBS4992
R35
5.0W
5R6
L13820
4UH
GREY
A-
.
W7
R94
1/2W
.
15K
3682
BROWN
-42V
WC24
3682
GREY
+42V
WC28
3682
GREY
+42V
WC27
R90
1/2W
.
15K
12
W2:L
W13:J
W13:L
R37
5.0W
5R6
R36
5.0W
5R6
R86
1/4W
.
33K
L33820
4UH
L23820
4UH
RB
Banana Jacks
BANANA_V_B+RJ8
B OUTPUT
RED
B+
.
W9
R57
1/2W
.
8K2
60CFM
24VDC
FAN1
FAN
MJF6388
6815
Q7
T221D
+16V
GRN
LD2
PWR
5908
BCE
MPSA06
7
6
1
2
3
4
5
CH1194
T1
R7
1/4W
.
1K54
In
Com
Out
S1:B
3436
STEREO/MONO
1 3
5
6
4 2
SRT
-
--
J1
3922
J3:A
MCR100-6
Q12
5191 C59
50V8200U
C71
63V6800U
470N 63V
C76
In
Com
Out
S3:A
3436
FILTER SWITCH
R18
1/4W
.
4M7
R11
1/4W
0.1%
9K76 68N 100V
C14
R17
1/4W
.
4M7
7
6-
5+U2:B
MC33078P
.
W26 GREEN
TO CHASSIS
150N 63V
C6
R92
1/2W
.
15K
R97
1/2W
.
15K
W34
3417
MBS4992
Q19
5190
TO92
R58
1/2W
.
8K2
C46
25V470U
MJF6668
6814
Q8
T221D
-16V R62
1/4W
FLMP
10R
R61
1/4W
FLMP
10R
.
FAN2
FAN
60CFM
MJF6388
MJF6668
CBE 3722_DRW
3682 TRANSFORMER
WC18GRE Y
3682
GREY
TRANSFORMER
WC14
RB
Banana Jacks
A OUTPUT
BANANA_V_B+R J7
12in 16C
W16
3673
7
4
1
9
2
3
5
6
8
13
10
11
12 D
Feb 23, 2006
.
JUN/10/03
JUL/08/02
N
Add marconi flange. output ji g drill files
ADD TESTNODES
ROUTING CHANGED AT JB2
PC#6553 REPLACE SHEAR WITH ROUT
APR/24/06
D
.
FEB/01/2005
SEP/18/03
D
JUL/15/02
NOV-10-2005
N
PC#7007 MAC224-4 TO STM-BTB-600BRG
PC#7009 ENLARGE MOUNT HOLES FOR Q16&Q20 #6444
GT:PC#7008:C82 #5281 10U/16V->#5961 33U/16V,
CONVERT TO PCAD2002 . AC UPDATED FOR CE STANDRD
PC#6626 C80 10u -> 33u/16V NP
CHAN A SPEAKON TO STEREO
PC#6395 MOVE R9E . PC#6426 REWIRE
V
.
.
5.10
4.20
V
6.20
.
6.10
6.00
5.20
.
5.00
MAC224
G
MT1 MT2
9
10
11
12
13
MODEL(S):-
DATE VER# DESCRIP TION OF CHANGE#
1
2
3
4
5
6
7
8
ADD RTV HOLES TO RELAY
PC#6207 REPLACE FUSE WITH 390R 5W
SCHEMATIC
Q23 BC550 TO MPSA06 (TO MATCH
4.10
.
4.00
.
3.10
FEB/23/01
NOV/15/01
JUN/02/00
.
JAN/31/00 RIBBON CABLE
REPLACE 14 PIN IC SOCKET WITH #3673
CHANGE SPACING OF COILS
PC#6125 CHANGE SPACING R73. PC#6128
TRACES ENLARGED
R84, R88,Q21, C83, R89 DELETED
TRIACS Q18 Q22 DELETED. R85, Q17. C81
.
.
.
3.00
.
.
.
2.00
OCT/18/99
.
SEP/28/99
.
.
.
AP6040
M1151
PC#6034 LD2 ROTATEDAUG/10/99
.
PC#6242 SHEAR MOVED 0.050" IN X

V6.20M1151
RELAY
C77
RTV
BANANNA JACKS MOUNTED ON CHASSIS
Top Assy
MUST BE BROKEN HERE
IT IS IMPERATIVE THAT LEGS
MARKED 2 AND 3 ARE BENT FLAT
DO NOT CUT LEGS #2 OR #3
IMPORTANT
PT# 3922
AGAINST THE COPPER SURFACE
THIS CONNECTION
BEND LEGS IN DIRECTION SHOWN
AFTER MOUNTING DEVICE
6 BEND C77 OVER
AND RTV TO RELAY
4 FOR CE REMOVE R74A, R80A AND C50 -> #5266
5 R73, BEND THE LEADS IN SAME DIRECTION.
2 CUT LARGE CAP LEADS BEFORE WAVE SOLDER.
USE #8799 TO MOUNT TRIAC Q30
PRODUCTION NOTES
3 SCREW DOWN BRIDGES WITH #8753 SCREW.
1 MOUNTING DETAILS FOR Q30 TRIAC
BEND DOWN 1/4" FROM BODY OF TRANSISTOR
V6.20
V6.20
NOTE: FOR CE REMOVE R74A & R80A
V6.20M1151
USE 2OZ COPPER
CE ONLY
Pcb Mech
BlankSize - 15000x10000
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
W24
X1
X58
R81
100K
R79
47K
W30
C21
100N
R20
120K
V
T
R
V
T
R
X88
X85
X84
V
T
R
V
T
R
D1 4148
R3
1K54
R95 1/2W
15K
X83
C1 220P
V
T
R
X81 X82
D2118V0 D2
4148
C45
22N
C10
220P
X37
X36
W3
RED
FAN2
X80
X100
R252K
R83 10R
W25
R91
15K
1/2W
X2
R75
1K
R74A
82K
R80B
130K
R80A
130K
X5
Q12 TO93
MCR100-6
R90
15K
1/2W
X8
X54 X53
X49
X57 X56
X50
W29
X52
R184M7
R17
4M7
X12 X13 X15
R13 56K
V
T
R
R4
9K76
R6 9K76
R2 9K76
R5 9K76
R93
15K
1/2W
X79
C3
220P
X78
R16
56K
X75
R15
56K
X33 R129K76
R109K76
R89K76
C12
220P
X63 X60
X61
X66 X67 X69 X71 X74 X20
X19
X17
X16
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
RV
T
R
C6 150N
X25
X29
X27
D2430V0
R2847K
X41
C14
68N
D18 4148
X40
V
T
R
W8
.
A+
YELL
V
T
R
WC7
TRANSFORMER
BLACK
WC13
TRANSFORMER
R29
5R0
V
T
R
C80
33U
16V
W23
Q15
TO92
MBS4992
W7
.
A-
GREY
V
T
R
C78
100U
25V
.
..
.
V
T
R
R96 1/2W
15K
V
T
R
WC37
A- OUT
BROWN
D15
4007
D144007
X59
R76
4K7
Q13
MPSA06
W27
W28
X101
V
T
R
R97
15K
1/2W
V
T
R
C82 33U
16V W9
.
B+
RED
V
T
R
V
T
R
V
T
R
V
T
R
R21
33K
W10
.
.
BLK
V
T
R
X89
C768N
C17
150N
X91 X90
C24
100N
C16
68N
C8
150N
V
T
R
WC28
GREY
+42V
V
T
R
V
T
R
X86
X87
V
T
R
WC27
GREY
+42V
D124007
WC25
-42V
BROWN
D114007
C9
33U
16V
U2
MC33078P
C5 68N
X22
X23
X28
X26
X24
WC26
SPKR GND
BLK
R94 15K
1/2W
V
T
R
C2
220P R1
1K54
C4
220P
C19
100N
V
T
R
Q23
MPSA06
X32
X31
C43
100U
25V
W14
V
T
R
V
T
R
C20
100N
C15
150N
C23
100N
R63 16K
W4
FAN2
BLACK
V
T
R
W6
FAN1
RED
W5
BLACK
FAN1
C11
220P
W12
Q9
BC550C
R7
1K54
R9 1K54
+
-
LD1
PRT
RED
+
-
LD2
PWR
GRN
WC10
POWER CORD
WHITE
R8233K
R36
5R6
5.0W
W22
R74B
82K
X3 C79
100U
63V
R35
5.0W
5R6
L1
4UH
R78 220K
R77 33K
C76
470N
V
T
R
C77
10U
63V
Q14
BC550C
R37
5R6
5.0W
X10
X9 X6 X7
R86
33K
R87
10R
Q19
TO92
MBS4992
X48X55 X51
R38
5R6
5.0W
R19
120K
X11
V
T
R
X14
WC24
-42V
BROWN
WC6
TRANSFORMER
RED
R14 56K
R92
15K
1/2W
X21
X77
2
J3
C22
100N
C46
25V
470U
C42
100U
25V
V
T
R
R119K76
U1
MC33078P
V
T
R
W33
C13220P
ORIGIN
CLINCH
X64 X68 X65
S3
FILTER SWITCH
S4
GRND LIFT
7
J1
-
-
-
X73 X72 X70 X18
D13
4007
D22
22V0
V
T
R
V
T
R
D23
18V0 W13
15in 12C
R578K2
1/2W
X39
R60
1K
R6110R
X35
R34
1K D17
4148
D20
4V7
D194148
R23 10K
R24
47K
R64
16K
W15
DUMMY
R73
5.0W
390R
R98
5.0W
390R
WC19
BLUE
FROM SWITCH
C50
22N
275V
C51
250V
4N7
V
T
R
V
T
R
WC20
TO SWITCH
RED
WC1
FROM BREAKER
BLACK
WC4
N/C FOR N.A.
TO WC19 EURO
R27
5R0
WC21
FROM SWITCH
BLUE
V
T
R
WC36
A+ OUT
BLUE
WC35
B+ OUT
YEL
WC14
TRANSFORMER
GREY
WC29
+100V
RED
WC2
TRANSFORMER
RED
WC30
+100V
RED
WC18
GREY
TRANSFORMER
AP6040
M1151 1/2
V
T
R
W11
C25
22N
275V
V
T
R
D16
4148
R59
1K
X30
R22 10K
Q7
MJF6388
+16V
D7 4148
R58
8K2
1/2W X38
X34
R62
10R
W1
Q8
MJF6668
-16V
WC3
XFMR GND
YEL
D8 4148
V
T
RV
T
R
V
T
R
R26
2K
C18
33U
16V
AP6040
M1151 2/2
C56
6800U
63V
C57
6800U
63V
C54
6800U
63V
C55
6800U
63V
X4
WC5
TO SWITCH
RED
C2
-
C1
+
NO
NC
K1
RELAY 1A
WC17
GROUND
GREEN
WC23
-100V
BLUE
+1
-2 -1
+2
J5
SPEAKON 4C H
SPKON_A
C74
6800U
63V
C75
6800U
63V
C70
6800U
63V
C73
6800U
63V
L2
4UH
L3
4UH
WC33
GROUND
Q16
.
STM-BTB-600BRG
.
.
Q20
.
STM-BTB-600BRG
.
.
WHTRED
J8
Banana Jacks
B OUTPUT
WHT RED
J7
Banana Jacks
A OUTPUT
-
AC1
AC2 +
BR2
BRIDGE
-
+
AC2
AC1
BR3
BRIDGE
C52
6800U
63V
C53
6800U
63V
C58
8200U
50V
C59
8200U
50V
WC22
BLUE
-100V
C65
8200U
50V
C66
8200U
50V
W26
.
GREEN
TO CHASSIS
C71
6800U
63V
C72
6800U
63V
L4
4UH
R70
1R
1.0W
W2 28in 12C
C61
8200U
50V
C63
8200U
50V
C62
8200U
50V
X76
Q11
MJF6388
FAN SUPPLY
W16
12in 16C
2
J4
W34
C64
8200U
50V
C69
8200U
50V
C68
8200U
50V
M
M
S2
LIMITER
S1
STEREO/MONO
7
J2
-
-
-
WC34
B- OUT
BLACK
13
12
11
10
9
DESCRIPTION OF CHANGE
5
4
3
2
1
# VER#DATE
MODEL(S):-
8
7
6
FEB/23/01
.
JAN/31/00 3.10
.
4.00
.
4.10
JUN/02/00
NOV/15/01
Q23 BC550 TO MPSA06 (TO MATCH
SCHEMATIC
PC#6207 REPLACE FUSE WITH 390R 5W
PC#6242 SHEAR MOVED 0.050" IN X
ADD RTV HOLES TO RELAY
.
OCT/18/99
..
.
.
AP6040
2.00
.
.
.
3.00
AUG/10/99
.
.
.
SEP/28/99
M1151
PC#6125 CHANGE SPACING R73. PC#6128
TRACES ENLARGED
R84, R88,Q21, C83, R89 DELETED
TRIACS Q18 Q22 DELETED. R85, Q17. C81
PC#6034 LD2 ROTATED
CHANGE SPACING OF COILS
REPLACE 14 PIN IC SOCKET WITH #3673
RIBBON CABLE
5
2
#
6
3
4
1
DATE
MODEL(S):-
VER# DESCRIPTION OF CHANGE
D
D
V
V
N
N
D
D
D
MAY/02/06
V
V
V
6.20
N
N
N
PC#7004 MAC224-4 TO STM-BTB-600BRG
M1151 PCB HISTORY
AP6040
12
9
6
3
13
11
10
5
4
8
7
2
1
D
FEB/01/2005
D
V
6.00
.
N
CONVERT TO PCAD2002 . AC UPDATED FOR CE STANDRD
CHAN A SPEAKON TO STEREO
D
D
D
JUN/10/03
SEP/18/03
JUL/08/02
JUL/15/02
V
V
V
5.10
5.20
4.20
5.00
N
N
N
PC#6626 C80 10u -> 33u/16V NP
ROUTING CHANGED AT JB2
PC#6395 MOVE R9E . PC#6426 REWIRE
PC#6553 REPLACE SHEAR WITH ROUT
ADD TESTNODES..
NOV-10-2005 6.10 GT:PC#7008:C82 #5281 10U/16V->#5961 33U/16V,
PC#7009 ENLARGE MOUNT HOLES FOR Q16&Q20 #6444..
4
1
6
5
3
#
2
MODEL(S):-
PC#
*PLACE IMPLEMENTED CHANGES INTO BOARD HISTORY
PENDING CHANGE
X
X
X
X
X
PC
PC
PC
PC
PC
PC
M1151 PENDING CHANGES
AP6040
X
-
AC1
AC2 +
BR1
BRIDGE
C60
8200U
50V
+1
-2 -1
+2
J6
SPEAKON 4C H
C67
8200U
50V

Yorkville Sound
Yorkville SoundYorkville Sound
Yorkville Sound Phone: [phone] Ext.218
550 Granite Court Fax: [phone]
Pickering, Ontario Email: [email protected]
Canada L1W 3Y8 www.yorkville.com
SERVICE BULLETIN
Date
DateDate
Date :
::
: February 29, 2000
Re
ReRe
Re :
::
: AP6020 / AP6040 Internal Fuse Problem
Dear Staff & Dealers,
We are sorry to advise that a service issue has developed with the AP6020 and AP6040 power
amplifiers that will eventually affect every unit shipped before February 26th, 2000. All units in
stock in Canada and the USA have been reworked to correct this problem.
The problem is serious enough that it is necessary to modify all units in the field, so we are here
by issuing a service bulletin that will be followed up with letters and phone calls to all affected
dealers and distributors.
All units should be modified as soon as possible. The units can either be returned to Yorkville for
modification, or can easily be modified in the field by a qualified service technician. We will, of
course, accept warranty claims for this modification.
Required Modification:
--------------------------------
- Remove the lid from the unit and both power amp boards.
- Locate the small 0.1A fuse on lower power supply board (#M1151 - AP6040 or M1177 -
AP6020). This is the only fuse in the unit.
- Replace this fuse with a 5W 390R resistor (YSL Part#4736).
- Dress all wires away from the two 5W 390R resistors.
- In order to be sure that no damage was done to the upper power amp boards when they were
removed it is strongly advised that the technician carefully retouch the solder on the three legs
of each of the following transistors: #Q32A,Q32B,Q33A and Q33B on each of the two power
amp boards (AP6040 - M1176/M1176A, AP6020 - M1150/M1150A)
- Replace the upper boards and lid.
Sorry for any inconvenience caused as a result of this problem. For further technical information
or assistance please contact Peter Mourtos at Yorkville Sound via phone at [phone]
Ext.218 or via email at [email protected] .
Enclosed
EnclosedEnclosed
Enclosed - Layouts for AP6020/AP6040 Power Supply and Power Amplifier boards.

VCD
.020"
.012"
.008"
.005"
.020"
.012"
.008"
.005"
.020"
.012"
.008"
.005"
.020"
.012"
.008"
.005"
M1150-4.00
ASSEMBLY M1150-4.00
WARNING
BOARDS
BEFORE REMOVING
SUPPLY WIRES
DISCONNECT POWER
BLANK SIZE=18.000" X 13.900"
ASSEMBLY M1150-4.00
U2C
33078P
U1
5532
U3
5532
D37
1N4004
D8
1N4004
D4
1N4004
D37
1N4004
Q24A
FUNCTION
MJE350
Q23A
FUNCTION
MJE340
Q17B
MJE340
FUNCTION
Q23B
FUNCTION
MJE340
Q24B
FUNCTION
MJE350
Q18B
MJE350
FUNCTION
ZD11A
16V/1W
ZD10A
16V/1W
ZD10B
16V/1W
ZD11B
16V/1W
J4C
J59
J66
J11
J48
J21
J37
J56
J42
J43
J163A
D37B
BAV21
D39B
4148
D40B
BAV21
D42B
BAV21
D41B
4148
D38B
BAV21
D38A
BAV21
D37A BAV21
Q20A
BC550
Q22A
BC550
Q21A
BC560
Q19A
BC560
Q47A
BC560
Q4C
BC560
Q5C
BC560
Q6C
BC560
Q29A
BC550
Q14A
BC550
Q9A
BC560
Q13A
BC550
Q10A
BC560
Q2
BC550
Q15A
BC550
Q16A
BC560
Q46A
BC550
Q16B
BC560
Q15B
BC550
Q10B
BC560
Q13B
BC550
Q9B
BC560
Q14B
BC550
Q29B
BC550
Q19B
BC560
Q21B
BC560
Q22B
BC550
Q20B
BC550
Q47B
BC560
Q46B
BC550
Q3C
BC560
Q12A
MJE340
Q18A
MJE350
Q17A
MJE340
Q11A
MJE350
Q11B
MJE350
Q12B
MJE340
Q27A
2N6517
Q2C
A63
Q28A
2N6517
Q4
2N5401
Q8A
2N5401
Q7A
2N5551
Q1
A06
Q3
2N5401
Q28B
2N6517
Q27B
2N6517
Q8B
2N5401
Q7B
2N5551
Q1C
A13
R122A
0.5W
1R
R123A
0.5W
1R
R123B
0.5W
1R
R122B
0.5W
1R
J2
TP3A
J5
TP1A
J39
J49
J50
TP4B
TP1B
TP6B
TP2B
TP3B
J38
J62
R131A
5W 1K
R130A
5W 1K
R130B
5W
1K
R131B
5W
1K
D5A
4148
D9C 4148
D22A
4148
D20A 4148
D6C 4148
R132A
39R
R133A
39R
R86A
10R
R78A
39R
R77B
39R
R78B
39R
R74B
100R
R71B
100R
R72B
75R
R73B
75R
R133B
39R
R132B
39R
R86B
10R
ZD8
6V2
ZD4A
14V
ZD5A
16V
ZD7A
20V
D2C
4V7
ZD6A
4V7
ZD6B
4V7
ZD7B
20V
ZD5B
16V
ZD4B
14V
ZD9
6V2
ZD3
33V
D1C
3V0
D27A BAV21
D28A BAV21
D25A
1N4148
D26A 1N4148
D9
4148
D39A 1N4148
D40A
BAV21
D42A
BAV21
D41A
1N4148
D21A 1N4148
D6A
1N4148
D19A
1N4148
D18A 1N4148
D17A1N4148
D14A
1N4148 D13A
1N4148
D11A
1N4148
D12A
1N4148
D2 4148
D1
4148
D3
4148
D6B
1N4148
D7
4148
D5B 1N4148
D9A4148
D10A4148
D25B
4148
D24B
4148
D17B 1N4148
D18B
1N4148
D19B
1N4148
D20B1N4148
D21B
1N4148
D26B
1N4148
D28B
BAV21
D27B
BAV21
D23B 4148
D22B 4148
D9B 4148
D10B 4148
D14B
1N4148 D13B
1N4148
D11B1N4148
D12B
1N4148
C5
10P
C6
10P
C1
220P
C2
220P
C21A
1n5
C14A
10p
C15A
10p
C22A 1N
C23A
2N2
C35A
6N8
C33A
6N8
C34A2N2
C36A
2N2
C31A
22n
C32A
22n
C37A
22n
C38A
22n
C42100N
C02C
100N
C9 100N
C50
100N
C10
100N
C38B
22n
C37B
22n
C32B
22n
C31B
22n
C36B
2N2
C34B 2N2
C33B
6N8
C35B
6N8
C23B
2N2
C22B
1N
C15B
10p
C14B
10p
C21B
2N2
C01C
100N
C50A
470P
R89A
150R
R90A
2R2
R91A
2R2
R94A150R
R96A
150R
R95A
2K7
R98A
12K
R99A249R
R165A
2R2
R101A
12K
R93A 6K98
R92A
150R
R97A
6K98
R134A
82K
R124A
100R
R125A
39R
R121A
470R
R118A
220K
R115A
4K7
R142A
1R
R144A
1R
R143A
1R
R141A
1R
R140A
1R
R145A
1R
R160A
220K
R04C
15K
R177
22M
R59B
4K7
R60A
10K0
R61A
17K8
R18
47K
R8
100R
R10
100R
R26
7K5
R25
1K5
R20
4K7
R19
10K
R21
220K
R23
10K
R6
4K7
R7 10K
R5 6K8
R13
12K
R24
1M
R17 12K
R54A
47K
R63A
2K
R88B
68R
R165B
2R2
R54B
47K
R140B
1R
R141B
1R
R142B
1R
R137B
20K
R114B
2K2
R124B
100R
R126B
100R
R139B 82K
R134B
82K
R97B
6K98
R92B
150R
R93B
6K98
R101B
12K
R98B
12K
R95B
2K7
R96B
150R
R89B
150R
R31
330R
R53B
10K0
R51B
10K0
R61B
17K8
R62B
3K
R53C
220R
R52C
470R
R51C
220K
R49C
15K
R48C4K7
R47C470R
R45C
4K12
R44C10K
R42C 10K0
R41C 10K
R40C
4K12
R35C
10K0
R34C
470R
R33C
4K7
R32C
15K
R31C
220K
R30C
470R
R29C
220R
U2C1
10K
R7C
10K
R2C
100K
R4C 470K
R50C
15K
R1C
100K
R55B
220R
U5
4N35
U5
4N35
RTA
BIAS
10K
RTB
BIAS
10K
R107A
1W
0R47
R107B
1W
0R47
R156A
2W
3R9
R81A
2WATT
150K
R81B
2WATT
150K
R156B
2W
3R9
Q25A
PART#
FUNCTION
MJL3281A
Q26A
PART#
FUNCTION
MJL1302A
Q26B
PART#
FUNCTION
MJL1302A
Q25B
PART#
FUNCTION
MJL3281A
Q42A
21196
NPN
OUTPUT1
Q44A
21195
PNP
OUTPUT1
Q34A
21196
NPN
OUTPUT1
Q38A
21196
NPN
OUTPUT1
Q36A
21195
PNP
OUTPUT1
D31A
MR854
D29A
MR854
D30A
MR854
D30B
MR854
D29B
MR854
D31B
MR854
Q40A
21195
PNP
OUTPUT1
Q43A
21196
NPN
OUTPUT1
Q39A
21196
NPN
OUTPUT1
Q35A
21196
NPN
OUTPUT1
R146A
5W
0R1
R147A
5W
0R1
R148A
5W
0R1
R149A
5W
0R1
R150A
5W
0R1
R151A
5W
0R1
D33A
MR854
D32A
MR854
D34A
MR854
Q37A
21195
PNP
OUTPUT1
Q41A
21195
PNP
OUTPUT1
Q45A
21195
PNP
OUTPUT1
Q45B
21195
PNP
OUTPUT1
Q41B
21195
PNP
OUTPUT1
Q37B
21195
PNP
OUTPUT1
J9
J45
J25
J6C
R171A
681R
R168A
1K
R170A
681R
R173A
681R
R174A
681R
R172A
681R
R167A
1K
R82A
10R
R175A
681R
R84A
75R
R85A
10R
R83A
75R
R83B
75R
R84B
75R
R175B
681R
R82B
10R
R167B 1K
R174B
681R
R173B
681R
R168B 1K
C25A
10U 63V
C16A
4U7 63V
C36C
50V
22u
C24A
10U 63V
C28A
1U
63V
C12A
10U 63V
C11A
10U 63V
C17A
4U7 63V
C7
4U7
63V
C28B
1U
63V
C24B
10U
63V
C25B
10U
63V
C12B
22u
50V
C11B
50V
22u
C16B
4U7 63V
C17B
4U7
63V
C35C
50V
22u
J158A
R30
68K
J22
11
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
NOV/26/99
OCT/18/99
SEP/16/99
AUG/24/99
.
.
.
.
.
AUG/10/99
MAY12/99
4.00
.
.
3.00
.
.
.
.
.
2.00
1.00
PC#6066_REPAIR_ERROR
#3673_RIBBON->#3562_SKT
PC#6098_CHANGES_AS_PER_PC
PC#6066_C126C_1_PIN_V-_->GND
PC#6033_R163A/R158A->J163A/J158A
ELIMINATE_SHORT_TO_SCREW
PC#6042_C50A_B_TO_C_Q24A_ADD_J63_TO
->4K99_R35C/R42C_20K0->10K0
PC#_____ADD_R30_R50A/B_R52A/B_10K0
PC#6043_RELAY_CONNECTIONS_ALTERED
PILOT_RUN_RELEASE
AP6040
M1150-PCB_DATABASE_HISTORY
R46C
15K
ZD1
10V
1
MX1
#3580
TO_M1151-POWER_SUPPLY_PCB
R111A
3K
R120A
150R
R15
100R
R136A
20K
R110A
3K
R116A 220K
R3C 470K
R119A
4K7
R117A
18K
R113A
4K7
R28
1K5
R135A
22K
R62A
3K
R75A
8K2
R27
1K5
R50A
4K99
R70A
2K
R67A
1K
R66A
1K
R57A
220R
R59A
4K7
R79A
3K3
R2
10K0
R1
10K0
R3
10K0
R9
18K
R14
18K
R12
100R
R16
100R
R52A
4K99
R51A
10K0
R53A
10K0
R80A
8K2
R22
1K5
R180A
470R
R4
10K0
R138A
22K
R29
470R
R138B
22K
R80B
8K2
R79B
3K3
R70B
2K
R75B
8K2
R135B
22K
R113B
4K7
R117B
18K
R119B
4K7
R94B
150R
R116B
220K
R110B
3K
R136B 20K
R120B
150R
R111B
3K
R121B
470R
R32
220R
R63B
2K
R152A
120R
R160B
220K
R55A
4K7
R115B
4K7
R118B
220K
R152B
120R
R76A
3K3
R55B
4K7
R56B
4K7
R52B
4K99
R67B
1K
R66B
1K
R58B
4K7
R50B
4K99
R5C
8M2
R76B
3K3
R32220R
R36C 8M2
J19
C29A
220N
250V
C30A
220N
250V
C30B
220N
250V
C29B
220N
250V
GS
Q33A
MTP23P06
FUNCTION
GSQ32A
MTP10N15L
FUNCTION
GS
Q32B
MTP10N15L
FUNCTION
GS
Q33B
MTP23P06
FUNCTION
R112A
2K2
R102A
39K
R112B
2K2
R162A
2R2
DOWN
BAR
D35A
MR854
DOWN
BAR
MR854
DOWN
BAR
MR854
DOWN
BAR
D35B
MR854
PART#
PART#
C26A
330u
16v
C19A
120v
10u
C20A
16v
330u
C27A
330u
16v
C18A
120v
10u
C20B
16v
330u
C18B
120V
10u
C27B
330u
16v
C19B
120v
10u
C26B
330u
16v
NO NC C
K1
AROMAT_RELAY
U2
LM13600
TB7
250TAB
OUT_B
TB3
250TAB
+42V
TB4
250TAB
OUT_B
TB5
250TAB
-42V
TB6
250TAB
-100V
TB2
250TAB
+100V
C25C
16V
33u
C26C 16V
33u
C10B
33U
16V
C10A
33U 16V
C9B
16V
33U
C9A
33U 16V
J3
J4
J60
J27
J63C
J17
J7
J15
J20
J35
J6
J16
J12
J24
J41
J34
J51
J32
J61
R11
100R
R58A
4K7
R126A
100R
R56A
4K7
D23A
4148
R87A
39R
R87B
39R
J8
J26
J30
J29
R137A
20K
R88A
68R
R102B
39K
R114A
2K2
R57B
220R
D24A
4148
J57
J31
D34B
MR854
D32B
MR854
D33B
MR854
R91B
2R2
R144B
1R
R143B
1R
R145B
1R
R151B
5W
0R1
R150B
5W
0R1
R149B
5W
0R1
R148B
5W
0R1
R147B
5W
0R1
R146B
5W
0R1
Q35B
21196
NPN
OUTPUT1
Q39B
21196
NPN
OUTPUT1
Q43B
21196
NPN
OUTPUT1
Q40B
21195
PNP
OUTPUT1
Q36B
21195
PNP
OUTPUT1
Q38B
21196
NPN
OUTPUT1
21196
NPN
OUTPUT1
Q44B
21195
PNP
OUTPUT1
Q42B
21196
NPN
OUTPUT1
C39B
10N
250V
C39A
10N
250V
R71A
100R
R72A
75R
R73A
75R
R74A
100R
R77A
39R
R109B
200R
R109A
200R
R106B
200R
R100A
249R
R105A
39R
R127A
39R
R103A
22R
R106A
200R
R85B
10R
R103B
22R
R104B
39R
R127B
39R
R99B
249R
R100B
249R
R104A
39R
R105B
39R
R125B
39R
R108B
200R
R108A
200R
J58
J55
J64
J65
J23
J33
J47
R162B
2R2
R153B
270R
R90B
2R2
J28
J3C
R139A
82K
R60B
10K0
U4
AS35
D3C
3V0
ZD2
30V
LD6
SP
RED
LD1C
SP
GRN
LD2C
SP
GRN
LD6C
SP
RED
R153A
270R
R172B681R
R170B
681R
R171B681R
J53
J40
J46
J54
J44
J52
GUIDE
ETCH
GUIDE
ETCH
GUIDE
ETCH
GUIDE
ETCH
5W
0R1
16-PIN.SOCKET
C38C
220p C37C 220p
R39C
15K
R55C
220R
C22C
220n
C21C
220n
C127C
100n C126C
100n
C18C
100P
C17C
100P
C4C
470N
C3C
470N
C2C
220p
C1C
220p
P2C
10K
-
-
L_GAIN
P1C
-
10K
-
R_GAIN
LIM
LVGND
REF
SIG
CLP
+100
PRT
AGD
+15
-42
TMP
GNDB
-15
+42
OG
-100
14AWG
14AWG
14AWG
14AWG
BRN
T126 TYPE DEVICE
PRODUCTION NOTES
MOUNTING HARDWARE FOR Q11,Q12
MOUNTING HARDWARE FOR Q40,Q41
MOUNTING HARDWARE FOR Q5,Q6
T264 DEVICE
#8741 4-40X 1/2" BOLT
BLU
YEL
RED
COOLED FROM WAVE SOLDER IS 6 INCH/LB
INITIAL TORQUE FOR TO-3’S IS 8 INCH/LB
MOUNTING DETAILS FOR 5W
OUTPUT -
OUTPUT +
TAB 7
TAB 6
TAB 5
TAB 4
TAB 3
TAB 2
TAB WIRE COLOURS
MOUNTING HARDWARE FOR TO3 OUTPUTS
TORQUE 4 INCH/LB
TORQUE 4 INCH/LB
TORQUE 4 INCH/LB
1
#8701 4-40 KEPS NUT
#8701 4-40 KEPS NUT
#8701 4-40 KEPS NUT
#3797 THERMO PAD
#3797 THERMO PAD
#8871 4-40X 1/2" BOLT
PCB
PCB
PCB
HEATSPREADER
HEATSPREADER
HEATSPREADER
HEATSPREADER
#3846 MICA
T-220 DEVICE
#8667 SHOULDER WASHER
#3501 BELL WASHER
#3501 BELL WASHER
#3501 BELL WASHER
#8741 4-40X 1/2" BOLT
R29, R29A R45 AND R45A
5 WATT RESISTORS
ADD #8629 SPACERS ONLY ON
FINAL TORQUE AFTER HEATSINK HAS
#8835 BOLT
#8663 SPACER
#3815 MICA
TO-3 TRANSISTOR
#8800 6-32 KEPS NUT
BOTH SIDES OF THE MICA PAD
MICA GREASE IS REQUIRED ON
ASSEMBLY M1150-4.00
FOR TEST JIG
FOR TEST JIG
HEAT SINK TOOLING PINS
HEAT SINK TOOLING PINS
HEAT SINK TOOLING PINS
HEAT SINK TOOLING PINS
METAL
METAL
METAL
METAL
BLANK SIZE=18.000" X 13.900"
VER.4.00
VER.4.00
BEFORE REMOVING BOARDS
DISCONNECT POWER SUPPLY WIRES
WARNING
RED
YEL
SPKR OUT
BRN
BLUE
USE 2 OZ. COPPER
AP 6040
AP 6040
M1150
M1150
ASSEMBLY M1150-4.00
P:\1150VR4.PRN

VCD
.020"
.012"
.008"
.005"
.020"
.012" .008"
.005"
ROUTE
GAGE
0.01"/HOLE
SOLDERSIDE M1151-3.00
BLANK SIZE=15.000" X 10.000"
2oz.COPPER
DRILL DETL M1151-3.00
R81 100K
WC18
TRANS
R76
4K7
D13
4004
LEADS DOWN
BR1
KBPC__-W
C50
CSA
22n
C77
63V
10U
R58
.5W
8K2
D12
1N4004
Q14
BC550
V
T
R
D11
1N4004
R2847K
V
T
R
BE
Q11
MJF6388
BE
Q7
MJF6388
+16V\V+
R92
.5W 15K
C4522n
X1
#3673_RIBBON_CBL
MW1
C42
100U
25V
L1
#3820
4uH
C71
6800U
63V
J25
Q13
MPSA06
SURG2
SL225R012
VOLTAGE
#3414
C18
16V
33u
SW3A
FILTER
PART#
J27
LD1
RED
SP
JB4
CHANB_INPUT
C17 150N
R129K760
JB2
CHANB_INPUT
J80
Q15
MBS4992
SP1
CHANA_OUTPUT
#6956
SPEAKON
R37
5W
5R6
R74B
82K
V
T
R
V
T
R
V
T
R
D7
4148
V
T
R
R75
1K
R80A 130K
R79 47K
R70 1R
1WATT
V
T
R
V
T
R
R18
4M7
R64
16k
R26
2K
R57
.5W
8K2
EYE1
GRN/TO_CHASSIS
R20
120K
R15
56K
J90
R16 56K
R13
56K
R21
33K
R19
120K
R119K760
R109K760
R89K760
J87
R7
1K54
R9
1K54
R3
1K54
J83
R2 9K760
R4 9K760 R6 9K760
R5 9K760
R83 10R
R82
33K
J36
R86
33K
R87 10R
R34 1K
J59
WC17
GREEN/GRND
WC19
FROM_SWITCH
BLUE
WC6
TRANS
WC7
BLACK/TANS
WC3
SPK_GND/BLK
J50 J49
WC2
RED/TRANS
WC10
WHT_POWER_CORD
WC1
FROM_BREAKER
BLACK
WC14
GRY/TRANS
WC13
TRANS
WC22
BLUE
-100V
WC23 BLUE
-100V
WC24
BRN
-42V
WC25
BRN
-42V
WC26
TRANS_GND/YEL
WC27
GREY
+42V
WC28
GREY
+42V
WC29
RED
+100V
WC30
RED
+100V
J48
J57
WC33
GRD
WC34
BLACK/B-OUT
WC35
RED/B+OUT
WC36
BLU/A+OUT
WC37
BRN/A_OUT
V
T
R
LEADS DOWN
BR3
KBPC__-W
LEADS DOWN
BR2
KBPC__-W
C51
CSA
4n7
YEL
WC21
FROM_SWITCH
BLUE
C46
470U
25V
C78
25V
100U
J32
D21
18V
D14
1N4004
D23
18V
V
T
R
J31
R61 10R
R63 16k
Q9
BC550
U1
MC33078
U2
MC33078
D20
4V7
J37
V
T
R
D15
1N4004
D8
4148
R24
47K
R62
10R
F
RED
D24
30V
D2
4148
R17
4M7
J30
C43
100U
25V
R96
.5W 15K
V
T
R
R94
.5W 15K
R95
.5W 15K
R97
.5W 15K
R93
.5W 15K
J41
R91
.5W 15K
R90
.5W 15K
Q20
TRIAC_MAC224
#6444
TRIAC
WC20
TO_SWITCH
RED
J2
F
BLACK
R60 1K
C5
68N
C7 68N
C14 68N
C16 68N
C24
100n
C23 100n
C11 220p C10
220p
C2 220p
C1 220p
C19
100n
C20
100n
C22
100n
C21
100n
C3
220p C4
220p
C12
220p
C13220p
MW2
J3
L2
#3820
4uH
L3
#3820
4uH
L4
#3820
4uH
C70
6800U
63V
C75
6800U
63V
C74
6800U
63V
C73
6800U
63V
C57
6800U
63V
C56
6800U
63V
C55
6800U
63V
C54
6800U
63V
C53
6800U
63V
C52
6800U
63V
R14
56K
C68
8200U
50V
C67
8200U
50V
C66
8200U
50V
C65
8200U
50V
C64
8200U
50V
C63
8200U
50V
C62
8200U
50V
C61
8200U
50V
C60
8200U
50V
C59
8200U
50V
C58
PART#
8200U
50V
SURG1
SL225R012
VOLTAGE
C9
16V 33u
C80
10u 16v
C82
10u 16v
V
T
R
SW2A
LIMITER_DEFEAT
PART#
SW1A
MONO\STEREO
PART#
J28
J29
LD2
GREEN
SP
JB3
CHANA_INPUT
C6
150N
C8
150N
C15 150N
C76
470N
JB1
CHANA_INPUT
Q19
MBS4992
R73
390R
5WATT
SP3
CHANB_OUTPUT
#6956
SPEAKON
J4
R36
5W
5R6
R35
5W
5R6
R38
5W
5R6
J23
SW4A
GRND_LIFT
PART#
J6
J21
C72
6800U
63V
J7 J8 J9
J10
J20
J19
J18 J17
J16
J15
J14 J13 J12 J11
J75
Q23
MPSA06
J69 J68 J67 J66 J65 J64
Q16
TRIAC_MAC224
#6444
TRIAC
J22
J78
J77
J79 J76
J74
J5
J72 J70 J61
CSA-0.1ASB/120VAC
CE-T0.2A/230VAC
RED
J60
F
F
J71
J63
J73
J26
J24
M1151
AP6040
VER VER
3.10
J51
J52
J56 J53 J54 J55
J58
R78 220K R77 33K
D22
22V
R22 1K
V
T
R
J33
D18
4148
F
D17
4148
V
T
R
DUMMBY
DUMMY
J34
J39
D16
4148
R59 1K
1
FROM_INPUT
V
T
R
BEC
V
T
R
V
T
R
R74A 82K
R80B 130K
V
T
R
V
T
R
MW5
TO_POWER_SUP.
#3706
C25
22N
100V
R1 1K54
D1
4148
J92
J81
J84 J86 J85
C69
8200U
50V
J91
J89
J82
J88
J93
250VAC
680N
Q12
SCR
#3638
#3638
R23 10K
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
.
JAN/31/00
.
OCT/18/99
.
SEP/28/99
.
.
.
AUG/10/99
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
.
3.10
.
.
.
3.00
.
.
.
2.00
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
N
SCHEMATIC)
PC#_____Q23_BC550->MPSA06_(TO_MATCH
RIBBON_CABLE
REPLACE_16_PIN_IC-SOCKET_WITH_#3673
CHANGE_SPAING_OF_COILS
PC#6125_CHANGE_SPACING_R73_PC#6128
TRACES_ENLARGED
R84,R88,Q21,C83,R89_DELETED
TRIACS_Q18,Q22_DELETED._R85,Q17,C81
PC#6034_LD2_ROTATED
AP6040
M1151.PCB_DATABASE_HISTORY
GUIDE
ETCH
GUIDE
ETCH
NC
NO
C1
C2
-
+1A(SPST-NO)
RELAY
V
T
R
V
T
RV
T
RV
T
R
J35
BE
Q8
MJF6668
FAN_SUPPLY-16V\V-
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
RV
T
R
V
T
R
WC5 TO_SWITCH
RED
GRY
BLACK
PART#
1
FUNCTION
1
MC4
FUNCTION
MW4
PART#
WC4
TO_WC19_EURO
N.C.FOR_N.A.
C79
100U
63V
R25
2K
V
T
R
J38
D19
4148
ASSEMBLY M1151-3.10
CABLE OTHER
END DIRECTION
MUST BE BROKEN HERE
THIS CONNECTION
PT# 3922
BLANK SIZE=15.000" X 10.000"
PCB MECH M1151-3.10
B
A
RED
BLACK
LEFT FAN
RIGHT FAN
NOTE:FOR CE REMOVE R74A&R80A
TO BOTTOM AMP #3740
TO POT PCB
TO TOP AMP #3519
D
3 SCREW DOWN BRIDGES WITH #8753 SCREW.
2 CUT LARGE CAP LEADS BEFORE WAVE SOLDER.
DO NOT CUT LEGS #2 OR #3
1 MOUNTING DETAILS FOR Q30 TRIAC
USE #8799 TO MOUNT TRIAC Q30
3
2
1
AGAINST THE COPPER SURFACE
MARKED 2 AND 3 ARE BENT FLAT
IT IS IMPERATIVE THAT LEGS
BEND LEGS IN DIRECTION SHOWN
AFTER MOUNTING DEVICE
IMPORTANT
1/4"
OF TRANSISTOR
BEND DOWN 1/4" FROM BODY
P:\1151CMP.PRN

5W
1K
21196
NPN
21195
PNP
Q34A
21196
NPN
21196
NPN
Q36A
21195
PNP
21195
PNP
21196
NPN
21196
NPN
21196
NPN
21195
PNP
21195
PNP
21195
PNP
21195
PNP
21195
PNP
21195
PNP
1
G S
TB7
TB3
TB4
TB5
TB2
21196
NPN
21196
NPN
21196
NPN
21195
PNP
21195
PNP
21196
NPN
21196
NPN
21195
PNP
21196
NPN
+1 00
-42
+42
-100
VER.4.00
BEFORE R EMOVING BOARDS
DISCONNECT POW ER SUPPLY W IRES
RE D
YEL
SPKR O UT
BRN
BLUE
AP 6040
M1150
5W
1K
21196
NPN
21195
PNP
21196
NPN
21196
NPN
21195
PNP
21195
PNP
21196
NPN
21196
NPN
21196
NPN
21195
PNP
21195
PNP
21195
PN P
21195
PNP
21195
PNP
21195
PNP
1
G S
TB7
TB3
TB4
TB5
TB2
21196
NPN
21196
NPN
21196
NPN
21195
PNP
21195
PNP
21196
NPN
21196
NPN
21195
PNP
21196
NPN
+100
-42
+4 2
-1 0 0
VER.4.00
BEFORE REMOVING BOARDS
DISCO NNECT PO W ER S UPPLY W IRES
RED
YE L
SPKR OUT
BRN
BL U E
AP 6040
M1150
WC18
TRANS
D13
CSA22n
+16V\V+
#3673_RIBB ON_CBL
#3414
WC17
GREEN/GRND
WC19
FR OM _ SW ITCH
BLUE
WC6
TRA NS
WC7
BLACK/TANS
WC3
SPK_GND/BLK
WC2
RED /TRA N S
WC10
W HT_POWER_CORD
WC1
FROM_BREAKER
BLACK
WC14
GRY/TRANS
WC13
TR ANS
WC22
BLUE
-100V
WC23
BLUE
-100V WC24
BRN
-42V
WC25
BRN
-42V
TRANS_GND/YEL
WC27
GREY
+42V
WC28
GREY
+42V
WC29 RED
+100V WC30
RED
+100V
C51
4n7
WC21
FR OM_ SW ITCH
BL U E
F
RED
WC20
TO_ SW ITCH
RED
F
BLACK
390R
5WATT
FR OM _ IN PUT
250VAC
680N
#3638
RELAY
FAN_SUPPLY-16V\V-
WC5
TO _SW ITCH
RED
MW 4
WC4
TO_W C19_EURO
N.C.FOR_N.A.
B
A
RIGH T FAN
TO BOTTOM AMP #3740
TO PO T P CB
TO T OP AMP #3519
L1
#3820
4uH
FILTE R
SP
CHANB_INPUT
CHANB_INPUT
SP1
CHANA_OUTPUT
#6956
5W
5R6
EYE1
GRN/TO_CHASSIS
WC33
GRD
WC34
BLACK/B-OUT
WC35
RED /B+ OUTWC36
BLU/A+OUT
WC37
BRN/A_OUT
YEL
U2
C7
L2
#3820
4uH
L3 #3820
4uH
L4
#3820
4uH
LIMITER_DEFEAT
MONO\STEREO
SP
CHANA_INPUT
CHANA_INPUT
CHANB_OUTPUT
#6956
5W
5R6
5W
5R6
5W
5R6
GRND_LIFT
RED
F
M1151
AP6040
VER VER F
TO_POWER_SUP.
22N
R1
GRY
BLACK
D

WC18
TRANS
D13
CSA22n
+16V\V+
#3673_R IBBON_CBL
L1
#3820
4uH
#3414
FILTER
SP
CHANB_INPUT
CHANB_INPUT
SP1
CHANA_OUTPUT
#6956
5W
5R6
EYE1
GRN/TO_CHASSIS
WC17
GREEN/GRND
WC19
FROM_SWITCH
BLUE
WC6
TRANS
WC7
BLACK/TANS
WC3
SPK_GND/BLK
WC2
RED/TRANS
WC10
WHT_POWER_CORD
WC1
FROM_BREAKER
BLACK
WC14
GRY/TRANS
WC13
TRANS
WC22
BLUE
-100V
WC23
BLUE
-100V
WC24
BRN
-42V
WC25
BRN
-42V
TRANS_GND/YEL
WC27
GREY
+42V
WC28
GREY
+42V
WC29 RED
+100 V WC30
RED
+100V
WC33
GRD
WC34
BLACK/B-OUT
WC35
RED/B+OUT
WC36
BLU/A+OUT
WC37
BRN/A_OUT
C51
4n7
YEL
WC21
FROM _SW ITCH
BLUE
U2
F
RED
WC20
TO_ SW ITCH
RED
F
BLACK
C7
L2
#3820
4uH
L3 #3820
4uH
L4
#3820
4uH
LIMITER_DEFEAT
MONO\STEREO
SP
CHANA_INPUT
CHANA_INPUT
390R
5W A TT
CHANB_OUTPUT
#6956
5W
5R6
5W
5R6
5W
5R6
GRN D_LIFT
RED
F
M1151
AP 604 0
VER VER F
FROM _INPUT
TO _PO W ER_S UP.
22N
R1
250VAC
680N
#3638
RELAY
FAN_SUPPLY-16V\V-
WC5
TO_SW ITCH
RED
GRY
BLACK
MW 4
WC4
TO_W C 19_EURO
N.C.FOR_N.A.
B
A
RIGHT FAN
TO BOTTOM AMP #3740
TO POT PCB
TO TOP AMP #3519
D
FEB 1, 2000
FILE NAME AP604OAC.DRW
FAN FAN
BLUE
RED
BLUE
RED
BLK
YELLOW
RED
RED
GREY
GREY
PT#1194
AP6040 NORTH AMERICAN WIRES
LINE CORD
RED YEL
GREY
BLACK
GREEN
GRN/YEL

WC18
TRANS
D13
CSA22n
+16V\V+
#3673_R IBBON_CBL
L1
#3820
4uH
#3414
FILTER
SP
CHANB_INPUT
CHANB_INPUT
SP1
CHANA_OUTPUT
#6956
5W
5R6
EYE1
GRN/TO_CHASSIS
WC17
GREEN/GRND
WC19
FROM_SWITCH
BLUE
WC6
TRANS
WC7
BLACK/TANS
WC3
SPK_GND/BLK
WC2
RED/TRANS
WC10
WHT_POWER_CORD
WC1
FROM_BREAKER
BLACK
WC14
GRY/TRANS
WC13
TRANS
WC22
BLUE
-100V
WC23
BLUE
-100V
WC24
BRN
-42V
WC25
BRN
-42V
TRANS_GND/YEL
WC27
GREY
+42V
WC28
GREY
+42V
WC29 RED
+100 V WC30
RED
+100V
WC33
GRD
WC34
BLACK/B-OUT
WC35
RED/B+OUT
WC36
BLU/A+OUT
WC37
BRN/A_OUT
C51
4n7
YEL
WC21
FROM _SW ITCH
BLUE
U2
F
RED
WC20
TO_ SW ITCH
RED
F
BLACK
C7
L2
#3820
4uH
L3 #3820
4uH
L4
#3820
4uH
LIMITER_DEFEAT
MONO\STEREO
SP
CHANA_INPUT
CHANA_INPUT
390R
5W A TT
CHANB_OUTPUT
#6956
5W
5R6
5W
5R6
5W
5R6
GRN D_LIFT
RED
F
M1151
AP 604 0
VER VER F
FROM _INPUT
TO _PO W ER_S UP.
22N
R1
250VAC
680N
#3638
RELAY
FAN_SUPPLY-16V\V-
WC5
TO_SW ITCH
RED
GRY
BLACK
MW 4
WC4
TO_W C 19_EURO
N.C.FOR_N.A.
B
A
RIGHT FAN
TO BOTTOM AMP #3740
TO POT PCB
TO TOP AMP #3519
D
FEB 1, 2000
FILE NAME AP604OAC.DRW
FAN FAN
YELLOW
RED
RED
GREY
GREY
PT#1194E
ORANGE
BROWN
BLUE
BLUE
BROWN
AP6040CE WIRED FOR 230V
BROWN
BROWN/BLACK
SHOWN WIRED FOR 230V
RED YEL
GREY
BLACK
GREEN
GRN/YEL

WC18
TRANS
D13
CSA22n
+16V\V+
#3673_R IBBON_CBL
L1
#3820
4uH
#3414
FILTER
SP
CHANB_INPUT
CHANB_INPUT
SP1
CHANA_OUTPUT
#6956
5W
5R6
EYE1
GRN/TO_CHASSIS
WC17
GREEN/GRND
WC19
FROM_SWITCH
BLUE
WC6
TRANS
WC7
BLACK/TANS
WC3
SPK_GND/BLK
WC2
RED/TRANS
WC10
WHT_POWER_CORD
WC1
FROM_BREAKER
BLACK
WC14
GRY/TRANS
WC13
TRANS
WC22
BLUE
-100V
WC23
BLUE
-100V
WC24
BRN
-42V
WC25
BRN
-42V
TRANS_GND/YEL
WC27
GREY
+42V
WC28
GREY
+42V
WC29 RED
+100 V WC30
RED
+100V
WC33
GRD
WC34
BLACK/B-OUT
WC35
RED/B+OUT
WC36
BLU/A+OUT
WC37
BRN/A_OUT
C51
4n7
YEL
WC21
FROM _SW ITCH
BLUE
U2
F
RED
WC20
TO_ SW ITCH
RED
F
BLACK
C7
L2
#3820
4uH
L3 #3820
4uH
L4
#3820
4uH
LIMITER_DEFEAT
MONO\STEREO
SP
CHANA_INPUT
CHANA_INPUT
390R
5W A TT
CHANB_OUTPUT
#6956
5W
5R6
5W
5R6
5W
5R6
GRN D_LIFT
RED
F
M1151
AP 604 0
VER VER F
FROM _INPUT
TO _PO W ER_S UP.
22N
R1
250VAC
680N
#3638
RELAY
FAN_SUPPLY-16V\V-
WC5
TO_SW ITCH
RED
GRY
BLACK
MW 4
WC4
TO_W C 19_EURO
N.C.FOR_N.A.
B
A
RIGHT FAN
TO BOTTOM AMP #3740
TO POT PCB
TO TOP AMP #3519
D
FEB 1, 2000
FILE NAME AP604OAC.DRW
FAN FAN
YELLOW
RED
RED
GREY
GREY
PT#1194E
ORANGE
BROWN
BLUE
BLUE
BROWN
AP6040CE WIRED FOR 245V
BROWN
BROWN/BLACK
SHOWN WIRED FOR 245V
RED YEL
GREY
BLACK
GREEN
GRN/YEL
