YORKVILLE EX2 User manual

U.S.A.
Yorkville Sound Inc.
4625 Witmer Industrial Estate
Niagara Falls, New York
14305 USA
Voice: [phone]
Fax: [phone]
WORLD HEADQUARTERS
WEB ACCESS: http://www.yorkville.com
CANADA
Yorkville Sound
550 Granite Court
Pickering, Ontario
L1W-3Y8 CANADA
Voice: [phone]
Fax: [phone]
Quality and Innovation Since 1963
Printed in Canada
SERVICE MANUAL
éXcursion 2000
TYPE: YS1031

IMPORTANT SAFETY INSTRUCTIONS
safety-4v2.eps Aug 26/05
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS
Read Instructions
The Owner’s Manualshould be read and understood
before operation of your unit. Please, save these instruc-
tions for future reference.
Packaging
Keep the box and packaging materials, in case the unit
needs to be returned for service.
Warning
When using electric products, basic precautions should
always be followed, including the following:
Power Sources
Your unit should be connected to a power source only of the voltage
specified in the owners manual or as marked on the unit. This unit has
a polarized plug. Do not use with an extension cord or receptacle
unless the plug can be fully inserted. Precautions should be taken so
that the grounding scheme on the unit is not defeated.
Hazards
Do not place this product on an unstable cart, stand, tripod, bracket or
table. The product may fall, causing serious personal injury and serious
damage to the product. Use only with cart, stand, tripod, bracket, or
table recommended by the manufacturer or sold with the product.
Follow the manufacturer’s instructions when installing the product and
use mounting accessories recommended by the manufacturer.
The apparatus should not be exposed to dripping or splashing water;
no objects filled with liquids should be placed on the apparatus.
Terminals marked with the “lightning bolt” are hazardous live; the
external wiring connected to these terminals require installation by an
instructed person or the use of ready made leads or cords.
No naked flame sources, such as lighted candles, should be
placed on the apparatus.
Power Cord
The AC supply cord should be routed so that it is unlikely that it will be
damaged. If the AC supply cord is damaged DO NOT OPERATE THE UNIT.
Service
The unit should be serviced only by qualified service personnel.
AVIS:
AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE,
N’ENLEVEZ PAS LE COUVERT (OU LE PANNEAU ARRIERE)
NE CONTIENT AUCUNE PIECE
REPARABLE PAR L’UTILISATEUR.
CONSULTEZ UN TECHNICIEN QUALIFIE
POUR L’ENTRETIENT
INSTRUCTIONS RELATIVES AU RISQUE
DE FEU, CHOC ÉLECTRIQUE, OU
BLESSURES AUX PERSONNES
Veuillez Lire le Manuel
Il contient des informations qui devraient êtres comprises
avant l’opération de votre appareil. Conservez S.V.P. ces
instructions pour consultations ultérieures.
Emballage
Conservez la boite au cas ou l’appareil devait être
retourner pour réparation.
Attention:
Lors de l’utilisation de produits électrique, assurez-vous
d’adhérer à des précautions de bases incluant celle qui
suivent:
Alimentation
L’appareil ne doit être branché qu’à une source d’alimentation
correspondant au voltage spécifié dans le manuel ou tel qu’indiqué sur
l’appareil. Cet appareil est équipé d’une prise d’alimentation polarisée.
Ne pas utiliser cet appareil avec un cordon de raccordement à moins
qu’il soit possible d’insérer complètement les trois lames. Des
précautions doivent êtres prises afin d’eviter que le système de mise à
la terre de l’appareil ne soit désengagé.
Risque
Ne pas placer cet appareil sur un chariot, un support, un trépied ou une
table instables. L’appareil pourrait tomber et blesser quelqu’un ou subir
des dommages importants. Utiliser seulement un chariot, un support,
un trépied ou une table recommandés par le fabricant ou vendus avec
le produit. Suivre les instructions du fabricant pour installer l’appareil et
utiliser les accessoires recommandés par le fabricant.
Il convient de ne pas placer sur l’appareil de sources de flammes
nues, telles que des bougies allumées.
L’appeil ne doit pas être exposé à des égouttements d’eau ou des
éclaboussures et qu’aucun objet rempli de liquide tel que des vases
ne doit être placé sur l’appareil.
Les dispositifs marqués d’une symbole “d’éclair” sont des parties
dangereuses au toucher et que les câblages extérieurs connectés à
ces dispositifs de connection extérieure doivent être effectivés par un
opérateur formé ou en utilisant des cordons déjà préparés.
Cordon d’Alimentation
Évitez d’endommager le cordon d’alimentation. N’UTILISEZ PAS
L’APPAREIL si le cordon d’alimentation est endommagé.
Service
Consultez un technicien qualifié pour l’entretien de votre appareil.

éXcursion 2000 Parts List pg 1 2/7/2005
YS # Description Qty. YS # Description Qty. YS # Description Qty.
5906 RED 3MM LED 1V9 20MA .4SPCER T&R 2 5233 330N 63V 5%CAP T&R RAD .2"FLM 4 3543 20 PIN BRKAWAY 90 LOCK .156 1.2
5907 YEL 3MM LED 1V9 20MA .4SPCER T&R 2 5234 470N 63V 10%CAP T&R RAD .2"FLM 7 3549 TRIFURCON TERM .156 36
5908 GRN 3MM LED 1V9 20MA .4SPCER T&R 1 5322 470N 50V 10%CAP T&R BEAD Z5U 1 3558 TERM HOUSING 4 CIR .156/RAMP 2
6772 BRIDGE 25A 400V WIRE LEAD SIP 4 5266 680N 250V 20%CAP BLK 'X2' 30MM AC 2 3559 TERM HOUSING 8 CIR .156/RAMP 3
6425 BAV21 200V 0A25 DIODE T&R 17 5255 __1U 63V 20%CAP T&R RAD .2"EL 8 3654 PCB CONN 4 CIR .100 LOCKING 1
6825 1N4148 75V 0A45 DIODE T&R 47 5925 __1U5 100V 10%CAP BLK RAD POLY FLM 4 3658 _8 CIR WAFER W/LCK RA 0.1" GOLD 1
6892 UF4004 200V 1A0 DIODE ULTRAFAST 18 5257 __2U2 63V 20%CAP T&R RAD .2"EL 1 3662 _6 CIR WAFER W/LCK VT 0.1" GOLD 2
6438 1N4007 400V 1A0 DIODE T&R 7 5949 __3U3 140V 20%CAP BLK RAD POLY FLM 4 3672 6 CIR CABLE HOLDER .098 2
6934 MR854 400V 3A0 DIODE FASREC 8 5951 __3U3 250VAC 20%CAP BLK POLY FLM 1 3676 8 CIR CABLE HOLDER .098 1
6733 BAT85 30V 0A2 DIODE SCHTKYT&R 11 5258 __4U7 63V 20%CAP T&R 8X7MM .2"EL 6 3694 _4 CIR WAFER W/LCK RA 0.1" GOLD 1
6440 1N750ARL 4V7 0W5 ZENER 5% T&R 2 5281 _10U 16V 20%CAP T&R RAD .2"NP 4 8701 4-40 KEPS NUT ZINC 8
6459 1N4732A 4V7 1W0 ZENER 5% T&R 1 5930 _10U 100V 10%CAP BLK RAD POLY FLM 4 8800 6-32 KEPS NUT ZINC 2
6450 1N5242B 12V0 0W5 ZENER 5% T&R 6 5945 _10U 63V 20%CAP T&R RAD .2"EL 8 8787 8-32 KEPS NUT ZINC 18
6486 1N5244B 14V0 0W5 ZENER 5% T&R 2 5879 100U 16V 20%CAP T&R 8X7MM .2"EL 3 8602 1/4-20 T NUT 24
6824 1N5246B 16V0 0W5 ZENER 5% T&R 8 5880 100U 35V 20%CAP BULK .1"EL 4 8797 5/16-18 KEPS NUT JS500 1
6432 1N5248B 18V0 0W5 ZENER 5% T&R 7 5268 220U 35V 20%CAP T&R RAD .2"EL 2 3895 ELASTOMER PAD 15GTR 1.5 X 4.6 1
6465 1N5250B 20V0 0W5 ZENER 5% T&R 3 5635 1000U 35V 20%CAP RADIAL ELECT BUL 1 4017 SARCON THERMAL GASKET 3.60"X0.75" 4
6506 1N4750A-T 27V0 1W0 ZENER 5% T&R 1 5884 3300U 160V 20%CAP RAD 35X50MM ELS 4 8581 CUSTOM PBL TRANSISTOR SPACER 2
6728 MC78L05ACP TO92 P 5V0 REG T&R V4 1 5636 4700U 50V 20%CAP BLK 25X40MM EL 4 3818 EMI SUPPRESSION FERRITE BEAD T&R 2
6732 MC79L05ACP TO92 N 5V0 REG V4 1 5900 10000U 63V 20%CAP BLK 35X45MM ELS 2 4597 22AWG STRAN TC WIR JMP 19
6856 NJM7815FA TO220 P 15V0 REG IS V1 2 4434 _10K B LIN 9MM DETENT P32 3 4599 22AWG SOLID SC WIR T&R JMP 74
6857 NJM7915FA TO220 N 15V0 REG IS V2 1 4522 __4K7 TRIM POT 2 4660 5.0W 0R047 5% BLK RES 2
5101 BC550C TO92 NPN TRAN T&R TB 5 3606 12.0 AMP CIRCUIT BREAKER 1 4698 2.0W 0R27 10% T&R RES 12
5102 BC560C TO92 PNP TRANSISTOR T&R TB 2 711 30 X 50 X 1.5MIL PLASTIC BAG 2 4682 1/2W 1R 5%PHILIPS SMAL T&R RES 2
5103 MPSA06 TO92 NPN TRANSISTOR T&R TA 2 712 32 X 30 X 72 2 MIL PLASTIC BAG 1 4703 2.0W 2R 5% T&R RES 8
5107 2N5551 TO92 NPN TRNSISTR DARL T&RTA 5 3961 SNAP ON 1.16" INSULATING BUSHING 1 4911 1/4W 2R2 5% T&R RES 3
5108 2N5401 T092 PNP TRNSISTR DARL T&RTA 12 3819 ___5UH COIL 18AWG R000 AIR CORE 2 4687 10.W 2R7 5% BLK RES 2
5105 MPSA13 TO92 NPN TRNSISTR DARL T&RTA 8 3777 _130UH COIL 22AWG R000 BOBBIN 2 4711 15.W 3R9 10% BLK RES 2
5119 2N5638 TO92 NCH JFET T&R TC 2 3784 _300UH COIL 22AWG R000 BOBBIN 2 4748 2.0W 3R9 5% T&R 7
6815 MJF6388 T221D NPN TRNSISTR DARL TJ 1 6497 _304UH CHOKE 95T18AWG/77111MAGNTKS 2 4813 1/4W 6R2 5% T&R RES 2
6891 TIP50 TO220 NPN TRAN TE 2 3005 1800UH COIL 18AWG R??? IRN CORE 2 2008 1.0W 10R 5%FLAME PROOF T&R RES 4
6911 BDX54C TO220 PNP TRAN DARL TE 6 6500 2700UH COIL COMMON MODE 7AMP 1 2009 1/4W 10R 2%FLAME PROOF T&R RES 4
6912 BDX53C TO220 NPN TRAN DARL TE 6 8483 ADAPTOR,SPEAKER STAND,METAL,BLACK 1 2010 1/8W 10R0 2%FLAME PROOF T&R RES 2
6782 IRFP31N50L TO247 NCH MFET TM 4 8484 ADAPTOR,SPEAKER STAND,PLASTIC,SMALL 2 2038 1/4W 11R FUSIBLE T&R RES 4
6953 IRF4905 TO220 PCH MFET 4 8520 RUBBER BUMPER WITH WASHER -MEDIUM- 12 4740 10.W 27R 5% BLK RES 2
6954 IRF3205 NCH MFET TN 4 8521 RUBBER BUMPER WITH WASHER VERYSMALL 8 4882 1/4W 27R 5% T&R RES 4
6840 MC33078P IC DUAL OP AMP 4 8538 RUBBER BUMPER W/ WASHER 1.375X1.375 8 2014 1/8W 33R 2%FLAME PROOF T&R RES 2
6882 TL072CP IC FET DUAL OP AMP 7 8547 PLASTIC FOOT BLACK, POLYETHYLENE 8 4816 1/4W 33R 5% T&R RES 3
6884 NE5532N IC DUAL OP AMP 12 8570 CORNER, 2 LEGS NOTCED LIP BLACK 16 2017 1/4W 47R5 1%FLAME PROOF T&R RES 2
6640 LM311 IC VOLTAGE COMPARATOR 1 8589 2 1/2" GREY SWIVEL CASTER 4 4817 1/4W 47R 5% T&R RES 9
6745 LM13600N IC XCONDUCTANCE AMP 4 3478 CLIP 205/187X032 18-22AWG DISCO/INS 2 2019 1/8W 100R0 1%FLAME PROOF T&R RES 2
6935 1455P1 IC SINGLE TIMER 1 3485 CLIP 250X032 18-22AWG RIGHT ANGL 2 4602 1/8W 100R 5% T&R RES 4
6603 74HC14N IC HEX INV SCHMID 2 3489 CLIP 250X032 18-22AWG DISCO/INSL 30 4652 1/2W 100R 5% T&R RES 2
6605 74HC86N IC QUAD 2INP XOR 1 3490 CLIP 250X032 14-16AWG DISCO/INSL 12 4852 1/4W 100R 5% T&R RES 12
6887 IR2110 IC HILO FET DRIVER 2 3491 CLIP 205/187X020 18-22AWG DISCO/INS 4 4819 1/4W 180R 5% T&R RES 2
6858 NSL-32SR2 OPTO-COUPLER LDR 2 3682 250 MALE PCB TAB REEL 52 4857 1/4W 220R 5% T&R RES 6
6467 10K 10% THERMISTOR NTC TO-92 3 3921 1/4" JCK PCB MT VERT STER RT SWT 3 4867 1/4W 270R 5% T&R RES 4
6489 5R0 20% NTC THERMISTOR-SURGTR 1 3924 1/4" JCK PCB MT VERT 2XTIP HICURNT 4 2025 1/8W 274R 1%FLAME PROOF T&R RES 4
5198 __4P7 100V 5%CAP T&R RAD CER.2"NPO 2 3628 SPKON 4C PCB MT VERT 250TAB GRY #4 4 4821 1/4W 470R 5% T&R RES 10
5200 _10P 200V 5%CAP T&R RAD CER.2"NPO 1 4010 XLR FEML PCB MT VERT 24MM AA-SERIES 2 4933 1/4W 470R 5% .2"U T&R RES 1
5401 _10P 500V 5%CAP T&R RAD CER.2"NPO 2 8598 SLIM BLACK XOVERDISH PLASTIC CNFG4 2 5015 1/4W 475R0 0.1% *** T&R RES 8
5402 _15P 100V 10%CAP T&R BEAD NPO 2 3451 EYELET SMALL 0.089 OD PLATED 53 4873 1/4W 680R 5% T&R RES 7
5817 _15P 100V 2%CAP T&R RAD CER.2"NPO 1 3414 INTERNATIONAL PC MOUNT FUSEHOLDER 6 5017 2.0W 910R 5% T&R RES 1
5408 _47P 100V 10%CAP T&R BEAD NPO 1 2414 8.0 AMP SLO-BLO .25X1.25 FUSE 4 2033 1/8W 1K 2%FLAME PROOF T&R RES 1
5199 100P 100V 2%CAP T&R RAD CER.2"NPO 2 2438 12.0 AMP SLO-BLO .25X1.25 FUSE 2 4823 1/4W 1K 5% T&R RES 6
5197 220P 100V 2%CAP T&R RAD CER.2"NPO 2 3864 FAN 92MM X 92MM 60CFM 24VDC 1 4981 1/4W 1K 5%MINI T&R RES 1
5201 470P 100V 5%CAP T&R RAD CER.2"NPO 2 8458 10.5" STRAP HANDLE, PLASTIC COVERS 1 6110 1/4W 1K0 1%MINI MF T&R RES 4
5416 470P 50V 10%CAP T&R BEAD NPO 2 8564 SMALL BAR HANDLE ALL METAL 2 4996 1/4W 1K070 0.1% *** T&R RES 6
5815 680P 200V 5%CAP T&R RAD CER.2"NPO 4 8565 BAR HANDLE ALL METAL 4 4998 5.0W 1K2 5% BLK RES 4
5816 680P 100V 5%CAP T&R RAD CER.2"NPO 2 8604 10-32 T NUT 12 4769 1/4W 1K4 1% T&R RES 4
5213 __1N 400V 5%CAP T&R RAD PRO. 2"FM 6 HD120 8R 40W 1"DRIVER HD1208R 2 4824 1/4W 1K5 5% T&R RES 3
5852 _10U 35V 20%CAP BLK 05X05MM EL 1 3501 B52200F006 COMP WASH #4 SMALL 8 4935 1/4W 1K5 5% .2"U T&R RES 2
5208 __2N2 400V 5%CAP T&R RAD .2"FLM 10 3745 DUAL XSISTOR PBL SPRING CLEAR ZINC 2 4988 1/4W 1K5 5%MINI T&R RES 3
5274 __2N2 200V 5%CAP T&R RAD CER.2"NPO 1 3978 5POS XSISTOR TO220SPRING 2 4683 1.0W 1K8 5% T&R RES 1
5275 __3N3 100V 5%CAP T&R RAD .2"FLM 4 3979 6POS XSISTOR TO220SPRING 2 4808 1/4W 2K 5% T&R RES 6
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC 6 3645 AC SOCKET RECEPTACLE WITH 0.250 TAB 1 4647 1/2W 2K2 5% T&R RES 4
5433 __5N6 50V 10%CAP T&R BEAD X7R 1 3803 NYLON SECUR-A-TACH MINI PLASTIC TIE 3 4847 1/4W 2K2 5% T&R RES 11
5272 __6N8 100V 5%CAP T&R RAD .2"FLM 1 3810 4" NYLON CABLE TIE 13 6148 1/4W 2K05 1%MINI MF T&R RES 1
5204 _10N 100V 10%CAP T&R RAD .2"FLM 7 3841 5.5" NYLON CABLE TIE 6 4864 1/4W 2K7 5% T&R RES 6
5205 _15N 100V 10%CAP T&R RAD .2"FLM 4 3852 STICK ON CABLE WRAP ANCHOR 1 5006 1.0W 2K7 5% T&R RES 4
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC 1 8937 11-3/8" NYLON CABLE TIE 1 4850 1/4W 3K9 5% T&R RES 4
5223 _39N 100V 10%CAP T&R RAD .2"FLM 2 8632 ROUND PUSH BUTTON 1/4" GREY 1 4627 1/2W 4K7 5% T&R RES 1
5224 _47N 100V 10%CAP T&R RAD .2"FLM 4 9916 GRY SOFT GRAY RIB KNOB 0-DEG 3 4827 1/4W 4K7 5% T&R RES 17
5226 _68N 100V 5%CAP T&R RAD .2"FLM 2 3426 8' 3/16 SJT AC LINE CORD REMOVB-CSA 1 4862 1/4W 5K6 5% T&R RES 2
5212 100N 63V 5%CAP T&R RAD .2"FLM 63 8258D "Y" LOGO ELITE SERIES MEDIUM DOMED 3 4717 1/4W 6K19 1%MINI T&R RES 4
5242 100N 250V 20%CAP BLK 'X2' 22MM AC 2 3641 S.C BAYONET WIRE SOCKET TINNED 2 4787 1/4W 7K960 0.1% *** T&R RES 12
5314 100N 50V 10%CAP T&R BEAD X7R 2 3647 12V 18W SC BAYONET #1141 BULB 2 4762 1/4W 9K760 0.1% *** T&R RES 2
5865 100N 250V 10%CAP BLK RAD POLY FLM 4 3817 _1.5MH COIL INPUT COM MODE 1 4768 5.0W 12K 5% BLK RES 2
5231 220N 63V 10%CAP T&R RAD .2"FLM 9 6497CO 77111-A7 KOOL MU POWDER CORES 2 4800 1/4W 10K0 1% T&R RES 1
5318 220N 50V 10%CAP T&R BEAD X7R 2 3538 24 PIN BREAKAWAY LOCK .156 1.659 4829 1/4W 10K 5% T&R RES 23

éXcursion 2000 Parts List Pg 2
YS No. Description Qty. YS No. Description Qty.
4940 1/4W 10K 5% .2"U T&R RES 2 18/063Y8
M
18" 8R1200WPGM SPEAKER DCR6.1R 1
4983 1/4W 10K 5%MINI T&R RES 1 8482 3/8 1D FLAT WASHER 3
5031 1.0W 10K0 5% T&R 2 8818 3/4 OD X 3/8 ID X .080 THICK WASHER 1
6116 1/4W 10K0 1%MINI MF T&R RES 8 8820 #8 FLAT WASHER JS500 2
4775 1/4W 14K0 1% T&R RES 1 8489 1/4-20 SPLIT WASHER ZINC 20
4630 1/2W 15K 5% T&R RES 6 8817 #10 FLAT WASHER FOR 3/16" BOLT 20
4830 1/4W 15K 5% T&R RES 9 3522 DPDT MINI PC VERT SNP AL
T
1
4831 1/4W 18K 5% T&R RES 4 3585 DPDT ROKR SW QUIK 250" AC/PWR IEC65 1
6125 1/4W 18K 5%MINI T&R RES 1 8480 VELCRO STRAP 1.5"X10.5',BLACK,HOOK 1
6123 1/4W 20K0 1%MINI MF T&R RES 5 CH1334U EX2SUB 117/230/245VAC PWR XFMR TR'D 1
4777 1/4W 21K5 1% T&R RES 4
4832 1/4W 22K 5% T&R RES 6
4833 1/4W 27K 5% T&R RES 4
4890 1/4W 30K 5% T&R RES 3
4840 1/4W 33K 5% T&R RES 6
6122 1/4W 33K 5%MINI T&R RES 5
4878 1/4W 43K 5% T&R RES 2
4834 1/4W 47K 5% T&R RES 16
4927 1/4W 47K 5% .2"U T&R RES 1
4836 1/4W 68K 5% T&R RES 5
4837 1/4W 82K 5% T&R RES 1
4838 1/4W 100K 5% T&R RES 9
4942 1/4W 100K 5% .2"U T&R RES 1
6120 1/4W 100K 5%MINI T&R RES 5
4776 1/4W 113K 1% T&R RES 6
4839 1/4W 150K 5% T&R RES 1
4849 1/4W 180K 5% T&R RES 1
4949 1/4W 180K 5% .2"U T&R RES 2
6137 1/4W 200K 5%MINI T&R RES 1
4641 1/2W 220K 5% T&R RES 1
4841 1/4W 220K 5% T&R RES 4
4879 1/4W 270K 5% T&R RES 1
6135 1/4W 270K 5%MINI T&R RES 1
4842 1/4W 330K 5% T&R RES 1
6127 1/4W 470K 5%MINI T&R RES 2
4844 1/4W 1M 5% T&R RES 8
4948 1/4W 1M 5% .2"U T&R RES 3
4751 1/4W 22M 5% T&R RES 3
6510 24" 4C-28AWG RIB 2 W/LCK HDR 098 1
3710 17" 6C-26AWG RIB 1 W/LCK HDR 098 1
4013 26" 6C-26AWG RIB 1 W/LCK HDR 098 1
3664 13" 8C-26AWG RIB 1 W/LCK HDR 098 1
3722 RELAY 1A 30AMP DC24 036MA PC-C 2
3962 EMI FILTER FOR ROUND CABLE 2
8865 4-40 X 5/16 PAN PH MS JS500 8
8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK 4
8741 4-40 X 1/2 PAN PH MS JS500 4
8871 4-40 X 5/8 PAN PH MS JS500 4
8842 #4 X 5/16 PAN QUAD TYPE A JS500 BLK 8
8832 6-32 X 1/4 PAN PH TAPTITE JS500 20
8801 6-32 X 3/8 PAN PH TAPTITE JS500 9
8835 6-32 X 1/2 PAN QUAD MS TIN PLATED 2
8796 6-32 X 5/8 PAN PH TAPTITE ZINC 7
8828 6-32 X 3/4 PAN PH TAPTITE JS500 13
8823 6-32 X 1 PAN PH TAPTITE JS500 10
8812 #6 X 1 1/8 FLAT SQ. SOCKT CLEAR ZNC 12
8803 8-32 X 3/8 PAN QUAD TAPTITE JS500 12
8767 #8 X 3/4 PAN PHIL TYPE A JS500 BLK 42
8785 #8 X 3/4 OVAL PH TYPE A BLACK OXIDE 12
8815 8-32 X 3/4 PAN PH TAPTITE JS500 8
8874 8-32 X 1" PAN PHIL TAPTITE JS500 2
8804 8-32X1.25 PAN PH MS ZINC CLEA
R
4
8809 10-32 X 1/4 PAN PH TAPTITE JS500 8
8749 10-32 X 1/2 QDX PH TAPTITE JS500 17
8753 #10 X 1/2 PAN PH TYPE A JS500 BLAC
K
28
8756 #10 X 3/4 PAN PH TYPE A BLACK OXIDE 60
8781 #10 X 7/8 FLAT PHIL TYPE A JS500BLK 30
8727 #10 X 1" PAN PH TYPE A JS500 BLAC
K
26
8912 10-32 X 1 FLAT PHIL MS JS500 BLK 8
8786 10-32 X 1 1/4 PAN QD MS JS500 BLACK 16
8862 #10 X 1 1/2 PAN PH TYPE A JS500 12
8777 #14 X 1FLAT PH TYPE A JS500 M6 HEAD 12
8906 #14X2 ALLEN FLAT HD WOOD SCRW JS500 6
8928 #14X11/4 ALLEN FLHD WOOD SCRW JS500 8
8936 1/4-20 X 3/4 PAN PH MS BLACK OXIDE 16
8780 5/16-18X3 3/4 CARRIAGE BOLT ZINC 1
8903 M5 X 16 DIN 7985 HH ZINC SCREW 4
3744 SNAP IN .375 SPACER RICHCO 30
3859 1/2 PLASTIC HEX SPACER #4 4
7409 12" 4R 300WPGM SPEAKER EMININENCE 2

1
3
2
∑
1
3
2
BALANCED
BALANCED
STEREO
MONO
RIGHT IN
RIGHT SPKR
OUTPUT
LEFT SPKR
OUTPUT
SUBWOOFER
AUX BAL
SUB IN
LEFT IN
RIGHT
AMP
SUBWOOFER
AMP
LEFT
AMP
RIGHT LEVEL
SUBWOOFER
LEVEL
LEFT LEVEL
NOTE: GROUND LIFT NOT REQUIRED
BLOCK-DIAG-EX2-1v0.pdf

Product
Date:
Filename:
PCB# ofSheet
Rev:
21
VER.2.00
M1206-3V0p5.sch2002
EX2
Wed Dec 01, 2004
M1206EX2
-41V
+41V
+55V
-29V
+29V
-55V
-55V
+29V
-55V
D10
MR854
R7
1/4W
33K
D26
MR854
-15VIN
+15VIN
-15V
+15V
1
W2:A 6
SIGNAL+
SIGNAL-
3
W2:C 6 SIGNALGND
-15V
+15V
-15V
+15V
-15V
+15V
+15V
SIGNALGND
OUTPUTGND
OUTPUTGND 3W1:C0
OUTPUT+
-15V
FET_CNTL
R42
1.0W
FLMP
10R
R109
1/4W
.
100K
SIGNALGND
SIGNALGND
D69
1N5250B 20V0
0W5
FAN_POS
2W4:B4
FAN_NEG
OUTPUTGND
OUTPUTGND
FAN
SIGNALGND
BIAS1-____
BAV21
D14
-41V
-29V
OUTPUTGND
THERMISTOR PLACE
ON HEATSPREADER
2
W2:B 6
4
W2:D 6
5
W2:E 6
6
W2:F 6
R39
1/8W
100R
OUTPUTGND
U2:E
R28
1/4W
0.1%
475R0
R10
1/4W
0.1%
475R0
SIGNALGND
R99
1/4W
27R
R97
1/4W
10K
R107
1/4W
15K
R100
1/4W
22K
1/4W
4K7
R111
R105
1/4W
4K7
YELLOW
LEFT-OUTPUT
W8
OUTPUT+ 1W1:A0
2W1:B0
4W1:D0
C127
63V
1U
R110
1/4W
2K7
R108
1/4W
10K
C12
100V
100N
L23819
5UH
R48
1/4W
220K
Q9
5119
TO92
2N5638
4W4:D4
3W4:C4
FAN_POS
1W4:A4
FAN_NEG
D39
4148
Q33
5107
TO92
2N5551
R21
1/4W
18K C8
100V
680P
C92
100V3N3
OUTPUTGND
C3
63V
4U7
C9
16V
10U
TO92
2N5401
Q6
5108
R219
1/4W
470R
8W3:H0
5W3:E0
6W3:F0
3W3:C0
4W3:D0
1W3:A0
R116
1/4W
4K7
R33
1/4W
4K7
C10
100V
15P
D22
BAT85
M
4K7
Taper
4522
P1
Function
R4
5.0W
1K2
R3
5.0W
1K2
C19
100V
100N
R27
1/4W
47R
R24
1/4W
1K5
6891
Q11
{Function}
TIP50
TO220
Q3
5105
TO92
MPSA13
R15
1/4W
68K
C1
200V
680P
R34
1/4W
100R
R35
1/4W
100R
D11
1N5242B
0W5
12V0 C13
63V
10U
R6
1/4W
FUSIBLE
11R3
R37
1/4W
100R
R36
1/4W
100R
BAV21
D4
R26
1/2W
.
2K2
D9
1N5246B
0W5
16V0
Q14
5102
TO92
BC560C
100V
C18
47N
D16
0A2 BAT85
R44
1/4W
100R
BAV21
D12
BAV21
D8
R2
1/2W
.
2K2
R29
1.0W
.
2K7
BAV21
D15
R11
2.0W
0R27
.
BIAS1+____
+55V
R46
2.0W
0R27
.
R220
1/4W
6R2
ORANGE
RIGHT-OUTPUT
W6
R45
2.0W
0R27
.
MR854
D23
+41V
C7
100V
100N
Q7
6467
NTC
10K
FAN
MR854
D3
R38
1/8W
100R
C65
100V 4P7
1/4W
100K
R112
C126
63V
1U
BLACK
LEFT-GND
W7
AMP
R16
1/4W
2K2
R5
1/4W
10K
2W3:B0
7W3:G0
C4
35V
220U
R23
1/4W
FUSIBLE
11R3
D1
0W5
12V0
1N5242B
C2
63V
10U
100V
C17
47N
D17
0A2 BAT85
R9
1/4W
100R
BAV21
D5
Q4
5101
TO92
BC550C
D25
1N5246B
0W5
16V0
R17
2.0W
0R27
.
BLACK
RIGHT-GND
W5
R25
1.0W
FLMP
10R
SIGNALGND
HORN SIGNAL
-15VIN
FET_CNTL
SIGNALGND
BREAK AWAY PCB
R30
1/8W
FLMP
274R
C132
100V
100N
C120
100V
100N
C122
100V
100N
U2:A
LM13600N
(VCC)
6745
U2:D
LM13600N
Dual VCA
{Function}
8
V+
4V-
U1:C
R103
1/4W
22M
U2:B
LM13600N
R102
1/4W
27R
R101
1/4W
10K
R104
1/4W
27KR22
1/4W
0.1%
475R0
C16
100V10N
LIMITER
R106
1/4W
30K
R19
1/4W
0.1%
475R0
C15
100V10N
+15VIN
1N750ARL D37
Q34
5101
TO92
BC550C
Q32
5108
TO92
2N5401
R20
1/4W
1M
U1:B
MC33078P
R13
1/4W
2K2
C11
16V10U
1+
1_
3628
J2:A SPEAKON 4C
LEFT OUTPUT
2+
2_
J2:B
C20
100V
100N
D40
BAV21
1/4W
10K
R114
D6
BAV21
R14
1/4W
18K
R8
1/4W
100K
Q5
5108
TO92
2N5401
C6
500V10P
DS
G
Q22
6953
P
TO220
{Function}
IRF4905
R31
1.0W
.
2K7
C14
200V
680P
R18
2.0W
0R27
.
R40
1/8W
FLMP
274R
R41
1/4W
21K5
C5
100V
100N
R32
1/4W
21K5
R12
2.0W
0R27
.
6912
Q16
BDX53C
TO220
{Function}
6912
Q2
TO220
BDX53C
{Function}
D13
1N5246B
0W5
16V0
G
D
S
Q12
6954N
TO220
{Function}
IRF3205
D2
16V0
0W5 1N5246B
BREAK AWAY PCB
L13819
5UH
C123
100V
100N
(VCC)
6745
U2:C
LM13600N
Dual VCA
{Function}
U1:A
MC33078P
FAN
SILENT ON/OFF
POWER SUPPLY
LIMITER SENSE
R1
1/4W
5K6
6911
Q21
{Function}
BDX54C
TO220
6911
Q10
{Function}
BDX54C
TO220
C118
2N2
400V
DS
G
Q1
6953
P
TO220
{Function}
IRF4905
2+
2_
RIGHT OUTPUT
J1:B
3628
SPEAKON 4C
1+
1_
3628
J1:A SPEAKON 4C
RIGHT OUTPUT
TO BREAKAWAY
G
D
S
Q13
6954N
TO220
{Function}
IRF3205
FROM INPUT PCB
6912
Q17
BDX53C
TO220
{Function}
225 WATT SATELLITE
FAN JUNCTION
9
10
11
12
13
MODEL(S):-
DATE VER# DESCRIPTION OF CHANGE#
1
2
3
4
5
6
7
8
N
N
COLLISION ON ASSEMBLED UNIT
MOVED COMPONENTS ON BREAKAWAY TO AVOID MECH
V
V
.
.
.
.
D
D
.
OCT-13-2004 #3543 RIGHT ANGLE MOLEX
ON BREAKAWAY CHANGED TABS TO EYELETS AND
.
.
3.00
.
.
OCT-12-2004
JUL-15-2004
.
M1206.PCB_DATABASE_HISTORY
.
SEP-02-2004
AUG-09-2004
MAY-13-2004 1.00
.
2.00
.
FIRST CREATION
PC#6712: CHANGED COLOUR ATTRIBUTES ON TABS 5 & 11
ADDED TESTPINS
Artwork has pads for NODE_R_WPAD and added
clinch hole on right side
CHANGED OUTPUT AND BLACK TABS TO #3538 MOLEX,
EXCURSION 2000
PC#6737 ZIPPERED OFF 0.2
BIAS ADJUSTMENT AT POINTS BIAS1+ AND BIAS1-:
BETWEEN 1-3 mVdc
6911
Q23
{Function}
BDX54C
TO220
EXCURSION 2000

11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
Product
SPUTNIK INPUT PCB
Date:
Filename:
PCB#
m1207v3.00.sch2002
EXCURSION 2000
Mon Feb 14, 2005
M1207 ofSheet
Rev:
41
VER3.00
Product
SPUTNIK INPUT PCB
Date:
Filename:
PCB#
m1207v3.00.sch2002
EXCURSION 2000
Mon Feb 14, 2005
M1207 ofSheet
Rev:
41
VER3.00
+15V
+15V
Boost
+15V
-15V
+15V
D1
4148
IGND
-15V
IGND
R37
1/4W
1M
R41
1/4W
47K
R48
1/4W
15K
.
-15V
4148
D10
+15V
+15V
IGND
IGND
SUB-GND
SIGNALGND
LEDGND
FET_CNTL
SIGNALGND
R4
1/4W
0.1%
1K07
IGND
CLIP
SATELLITES
SUB-GND
Boost
CLIPSAT
NET00118
+15V
SUB-GND
SUB-GND
SUB-GND
+15V
SUB-GND
SUBWOOFER
4148
D15
FET_CNTL
SUB-GND
SIGNAL-SUB
C32
63V220N
SUB-GND
R67
1/4W
1M
C36
63V470N
W29:H
W29:G
W29:F
W29:E
W29:D
W29:C
W29:B
W29:A
SIGNAL-SUB
LEDGND
R2
1/4W
1K5
RAD
+15V
L1
5908
POWER
GRN
1/4W
1K
R173
Tie-net Name
Tie Here
+15V
-15V
LEDGND
C3
100V
100N Q1
5105
TO92
MPSA13
5906
L2
RED
CLIP
C2
400V
2N2
R3
1/4W
0.1%
1K07
SUB-GND
R11
1/4W
0.1%
7K96
LEDGND
D35
4148
4148
D36
C85
63V220N
R12
1/4W
2K7
R19
1/4W
47K
SUB-GND
R17
1/4W
47K
-15V
R13
1/4W
113K
SUB-GND
R16
1/4W
.
2K2
SUB-GND
C7
100V
100N
-15V
D7 4148
4148
D6
4148
D4
C6
63V220N
R22
1/4W
2K7
8
V+
4V-
U5:C
SUB-GNDSUB-GND
100V
C10
100N
R27
1/4W
2K2
R29
1/4W
2K2
U6:B
NE5532N
4148
D8
-15V
SUB-GND
C21
16V
100U
1/4W
100K
R33
100V
C22
220P
R186
1/4W
MINI
20K0
R30
1/4W
.
15K
8
V+
4V-
U7:C
C89
100V
100N
R39
1/4W
22M
C4
200V
10P
SUB-GND
C23
100V
100N
8
V+
4V-
U8:C
R44
1/4W
10K
SUB-GND
C25
63V10U
C24
16V
100U
SUB-GND
1/2W
220K
R43
100V
220P
C26
SUB-GND
1/4W
27K
R55
1/4W
15K
R50
R53
1/4W
47K R52
1/4W
47K
R54
1/4W
47K
1/4W
47K
R59
SUB-GND
D12
4148
Q4
5108
TO92
2N5401 SUB-GND
SUB-GND
R57
1/4W
10K
R60
1/4W
10K
SUB-GND
C33
63V220N
C31
50V
100N R65
1/4W
1M
4148
D16 R68
1/4W
4K7
SIGNAL TO
AMP INPUT
4148
D2
C1
400V
2N2
1/4W
1K5
R10
MINI
1/4W
100K
R1
RAD
1/4W
270K
R5
MINI
1/4W
7K96
R9
0.1%
Q7
5105
TO92
MPSA13
R165
1/4W
113K
C84
63V
470N
R18
1/4W
47K
R14
1/4W
1K5
.
C8
100V
100N
TO92
2N5551
Q3
5107
R25
1/4W
47K
R24
1/4W
27K
.
4148
D5
R21
1/4W
22K
R23
1/4W
22K
100V
C11
100N
C13
100V
100N C12
100V
100N
100V
C20
100N
C18
100V
100N
63V
C16
220N
R34
1/4W
220R
1/4W
100K
R36
1/4W
15K
R38
U1:A
LM13600N
R45
1/4W
220R
R46
1/4W
100K
R51
1/4W
4K7
C29
63V220N
1/4W
10K
R58
63V
C30
220N
W5
8
V+
4V-
U2:C
8
V+
4V-
U3:C
4W15:D
1W15:A
FROM POWER SUPPLY PCB
SUB EQ #1
SUBWOOFER
SUB-SIGNAL
R7
1/4W
0.1%
7K96
SUBWOOFER INPUT
SUB-GND
SUB-GND
R28
1/4W
15K
SUB-GND
4148
D9
R66
1/4W
220K
C34
63V470N
R169
1/4W
33R
R168
1/4W
33R
R167
1/4W
33R
(VCC)
LM13600N
Dual VCA
6745
U1:D
{Function}
(VCC)
LM13600N
Dual VCA
6745
U1:C
{Function}
LEFT-GND
RIGHT-GND
R177
1/4W
MINI
33K
1/4W
1K5
R176
MINI
1/4W
200K
R175
MINI
2W15:B
3W15:C
SUB-GND
R166
1/4W
.
1K4
FROM L&R CHANNELS
U2:A
TL072CP
D3
4148
R6
1/4W
0.1%
7K96
8
V+
4V-
U4:C
U1:E
SIGNALGND
C17
100V
100N
U5:B
TL072CP
TO92
2N5551
Q2
5107
1/4W
150K
R32
1/4W
270K
R31
SUB-GND
100V
C15
100N
U4:A
TL072CP
C9
63V220N
R26
1/4W
47K
R35
1/4W
10K
R20
1/4W
470R
SUB-GND
8
V+
4V-
U9:C
Q5
5103
TO92
MPSA06
SUB-GND
U4:B
TL072CP
R47
1/4W
.
180K
C28
63V10U 4148
D11
R42
1/4W
47K
R61
1/4W
4K7
200V
C5
2N2
4148
D13
R40
1/4W
2R2
R62
1/4W
10K
R49
1/4W
30K
.
U9:B
TL072CP
C88
100V
100N
R8
1/4W
MINI
33K
5906
L4
RED
CLIP
U3:B
NE5532N
100V
C14
100N
U5:A
TL072CP
D29
4148
R187
1/4W
RAD
10K
1/4W
1K5
R63
MINI
R64
1/4W
20K0
MINI
U7:A
TL072CP
U9:A
TL072CP
U1:B
LM13600N
C27
63V220N
R56
1/4W
10K
U8:B
TL072CP
TO SUB AMP
U7:B
TL072CP
8
V+
4V-
U6:C
YEL
D14 LIMITER
SPUTNIK INPUT PCB
U3:A
NE5532N
U2:B
TL072CP
4434
P1:A
M
10K
B
SUBWOOFER LEVEL CONTROL
U6:A
NE5532N
U8:A
TL072CP
RING
J1
1/4in JCK PCB MT VERT STER RT SWT
SUB INPUT

11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
Product
SPUTNIK INPUT PCB
Date:
Filename:
PCB#
m1207v3.00.sch2002
EXCURSION 2000
Mon Feb 14, 2005
M1207 ofSheet
Rev:
42
VER3.00
Product
SPUTNIK INPUT PCB
Date:
Filename:
PCB#
m1207v3.00.sch2002
EXCURSION 2000
Mon Feb 14, 2005
M1207 ofSheet
Rev:
42
VER3.00
+15V
-15V -15V
+15V
1/4W
33K
R111
.
+15V
RIGHT-GND
LEFT-GND
-15V
+15V
LEFT-GND
-15V
+15V
W7:E
W7:B
IGND
IGND
SUB-SIGNAL
RIGHT-GND
LEFT-GND
+15V
BOOST
RIGHT-GND
-15V
+15V
-15V BOOST
LEFT-GND
-15V
NOTCH
NOTCH
+15V
RIGHT-GND
4148
D28
CLIPSAT
LEFT-GND
LEFT-GND
4148
D22
C77
63V470N
-15V
C76
63V470N
4148
D26
R156
1/4W
10K
R160
1/4W
.
3K9
4148
D25
SIGNAL-RIGHT
SIGNAL-LEFT
FET_CNTL
SIGNAL-RIGHT
C65
100V
100N
C64
100V
100N
IGND
+15V
R78
1/4W
0.1%
1K07
W7:F
W7:D
W7:C
W7:A
400V
C46
2N2
100V
C69
100N
RIGHT-GND
100V
C68
100N
400V
C43
2N2
1/4W
47K
R95
RAD
LIMITER SENSE
R94
1/4W
RAD
10K
SATELLITES
U12:A
NE5532N
R172
1/4W
2K
C79
100V
100N
R90
1/4W
0.1%
7K96
R89
1/4W
0.1%
7K96
R171
1/4W
2K
1/4W
33K
R99
LEDGND
1/4W
1K5
R96
RAD
100V
C51
3N3
C49
63V470N
100V
C50
3N3
C48
63V470N
-15V
12KHZ
+15V
12KHZ
R107
1/4W
.
1K
+15V
1/4W
6K19
R103
MINI
RIGHT-GND
100V
C56
10N
C58
100V15N
R115
1/4W
.
1K
LEFT-GND
1/4W
33K
R112
.
R113
1/4W
.
2K
1/4W
270R
R120
.
NOTCH
1/4W
43K
R127
.
100V
C60
68N
1
2
NSL-32SR2
U18:A
6858
U16:A
NE5532N
900HZ
-15V
U15:B
NE5532N
8V+ 4
V-
U15:C
NOTCH
R129
1/4W
.
680R
R138
1/4W
.
47R
R174
1/4W
.
470R
R135
1/4W
.
470R
R170
1/4W
.
470R
4148
D19
4148
D27
63V
C74
4U7
1/4W
68K
R142
.
+15V
1/4W
2K7
R69
.
RIGHT-GND
-15V
1/4W
2K
R145
63V
C72
4U7
1/4W
68K
R141
.
1/4W
2K7
R15
.
R143
1/4W
.
15K
-15V
-15V
R150
1/4W
.
10K
1/4W
47K
R148
.
1/4W
47R
R152
.
1/4W
47K
R147
.
4148
D23
1/4W
47R
R151
.
+15V
R158
1/4W
10K
1/4W
6K19
R154
MINI
RIGHT-GND
+15V
-15V
R157
1/4W
10K
LEFT-GND
R159
1/4W
.
3K9
RIGHT-GND
LEFT-GND
IGND
400V
C45
2N2
400V
C42
2N2
R91
1/4W
0.1%
7K96
R92
1/4W
0.1%
7K96
U11:A
NE5532N
1/4W
33K
R98
R108
1/4W
680R
4148
D31
R114
1/4W
.
2K
R117
1/4W
.
1K
100V
C57
10N
100V
C61
68N
1/4W
43K
R128
.
1/4W
270R
R119
.
R130
1/4W
.
680R
1
2
NSL-32SR2
U17:A
6858
900HZ
4148
D20
R136
1/4W
.
470R
R137
1/4W
.
47R
1/4W
2K
R146
8V+ 4
V-
U22:C
R144
1/4W
.
15K
+15V
4148
D24
R149
1/4W
.
10K
-15V
8V+ 4
V-
U20:C
R155
1/4W
10K
8V+ 4
V-
U19:C
1/4W
6K19
R153
MINI
8V+ 4
V-
U21:C
W2:E
LIMITSENSE
W2:B
-15V
TO SUB INPUT
R101
1/4W
.
680R
RIGHT-GND
C81
63V330N
R162
1/4W
470R
LEFT-GND
4148
D21
LEFT-GND
C80
63V330N
CLIPSAT
FET_CNTL
W2:F
Q6
5103
TO92
MPSA06
W2:C
W2:D
LEFT SIGNAL RIGHT SIGNAL
RIGHT-GND
SIGNAL-LEFT
W2:A
J7
RIGHT INPUT
4010
TO SUB INPUT
100V
C71
100N
C63
100V
100N
LEFT-GND
RIGHT-GND
100V
C70
100N
C62
100V
100N
EXCURSION 2000 INPUT PCB
R85
1/4W
0.1%
7K96
LEFT-GND
SUB-SIGNAL
R84
1/4W
0.1%
7K96
R77
1/4W
0.1%
1K07
U14:A
NE5532N
2K3HZ RIGHT-GND
C55
400V2N2
100V
C67
15N
R126
1/4W
2K2
+15V
8V+ 4
V-
U12:C
U12:B
NE5532N
C53
63V330N
1/4W
6K19
R102
MINI
-15V
U13:B
NE5532N
8V+ 4
V-
U13:C
U13:A
NE5532N
LEFT-GND
C54
400V2N2
R118
1/4W
.
1K
C59
100V15N
R116
1/4W
.
1K
R125
1/4W
2K2
U11:B
NE5532N
C52
63V330N
U15:A
NE5532N
R109
1/4W
.
3K9
4148
D34
4148
D18
1/4W
47K
R134
U20:B
NE5532N
LIMITSENSE
4
3
NSL-32SR2
U18:B
6858
RIGHT-GND
P5:A
4434
M
B
10K
RIGHT GAIN
1/4W
47K
R133
63V
C73
1U
LIMITSENSE LEFT LIMITER
4
3
NSL-32SR2
U17:B
6858
R139
1/4W
.
680R
R161
1/4W
470R
R131
1/4W
2K2
U21:A
NE5532N
4148
D32
4148
D33
R86
1/4W
0.1%
7K96
R87
1/4W
0.1%
7K96
R79
1/4W
0.1%
1K07
R80
1/4W
0.1%
1K07
5907
L3
YEL
LIMITER
J6
4010
LEFT INPUT
8V+ 4
V-
U14:C
U14:B
NE5532N
8V+ 4
V-
U16:C
R110
1/4W
.
3K9
8V+ 4
V-
U11:C
S1:A
3522
DOWN UP
MONO/STEREO
2K3HZ
R100
1/4W
.
680R
100V
C66
15N
R132
1/4W
2K2
63V
C75
1U
U22:A
NE5532N
RIGHT LIMITER
R140
1/4W
.
680R
4148
D17
U19:B
NE5532N
P4:A
4434
M
B
10K
LEFT GAIN
U20:A
NE5532N
RIGHT INPUT
LEFT INPUT
U22:B
NE5532N
U16:B
NE5532N
RING
RIGHT INPUT
J5
U19:A
NE5532N
U21:B
NE5532N
RING
J4
LEFT INPUT

11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
Product
SPUTNIK INPUT PCB
Date:
Filename:
PCB#
m1207v3.00.sch2002
EXCURSION 2000
Mon Feb 14, 2005
M1207 ofSheet
Rev:
44
VER3.00
Product
SPUTNIK INPUT PCB
Date:
Filename:
PCB#
m1207v3.00.sch2002
EXCURSION 2000
Mon Feb 14, 2005
M1207 ofSheet
Rev:
44
VER3.00
9
10
11
12
13
MODEL(S):-
DATE VER# DESCRIPTION OF CHANGE#
1
2
3
4
5
6
7
8
N
N
N
N
N
V
V
V
V
V
D
D
D
D
DGT: removed 1OZ Copper label (production request)
pc#6742 R64 15K->20K0, R47 130K->180K
Force update 3921 jacks for clinch - fixed blank and repeat field
DISCONNECT PIN3 ON W2 &W7, PIN6 ON W29 RIBBONS
PC#6711: W15 CONNECTOR MOVED FOR SHEARING
CHANGE C5, C84, R166, ADD DRILL & PEND. TABLES
PC#6709: ADD RIGHT CORNER CLINCH HOLE, PC#6710:
3.00
2.10
2.00
-
-
-
2.00
1.00
SEP/30/2004
17 Aug, 2004
-
-
-
JUL-14-2004
EXCERSION 2000
M1207 HISTORY
FIRST CREATIONJUN-08-2004
JAN-25-2005

SHEAR
SHEAR
SHEAR
SHEAR
CLINCH
ORIGIN
.175
.225
.475 .475
.175
.225
.475 .475
Pcb Mech M1207
BlankSize - 13700x9150
V3.00 StepAndRepeat - [email protected],[email protected]
Top Assy V3.00M1207
PRODUCTION NOTES:
+
-
+
-
NOL
NCL
NOR NCR
CL CR
GUIDE
ETCH
GUIDE
ETCH
+
-
+
-
+
-
2 1
3
2 1
3
1
RING
TIP-SW
TIP
SLEEVE
RING-SW
RING
TIP-SW
TIP
SLEEVE
RING-SW
RING
TIP-SW
TIP
SLEEVE
RING-SW
KNOBPART#FUNCTIONREF
MODEL(S):-
{NEW}
N
N
N
N
N
N
N
N
N
N
N
N
K
K
K
K
K
K
K
K
K
P
P
P
P
P
P
P
P
P
F
F
F
F
F
F
F
F
F
R
R
R
R
R
R
R
R
R
M1207
P4
P5
P1
LEFT GAIN
RIGHT GAIN
9916
9916
9916SUB GAIN
EXCURSION 2000
#4434
#4434
#4434
6
3
#
5
4
2
1
DATE
MODEL(S):-
VER# DESCRIPTION OF CHANGE
D
D
V
V
N
N
D
D
D
D
V
V
V
V
N
N
N
N
EXCURSION 2000
M1207 DRILL HISTORY
13
12
11
10
9
DESCRIPTION OF CHANGE
5
4
3
2
1
# VER#DATE
MODEL(S):-
8
7
6
D
D
DV
V
V
V
V
D
D
N
N
N
N
N
SEP/30/2004 2.10 pc#6742 R64 15K->20K0, R47 130K->180K
EXCURSION 2000
JUN-08-2004 1.00 FIRST CREATION
JUL-14-2004 2.00 CHANGE C5, C84, R166, ADD DRILL & PEND. TABLES
DISCONNECT PIN3 ON W2 &W7, PIN6 ON W29 RIBBONS
M1207 HISTORY
PC#6709: ADD RIGHT CORNER CLINCH HOLE, PC#6710:
PC#6711: W15 CONNECTOR MOVED FOR SHEARING
17 Aug, 2004 2.00
-
-
-
-
-
-
Force update 3921 jacks for clinch - fixed blank and repeat field
JAN-25-2005 3.00 GT: removed 1OZ Copper label (production request)
4
1
6
5
3
#
2
MODEL(S):-
PC#
*PLACE IMPLEMENTED CHANGES INTO BOARD HISTORY
PENDING CHANGE
X
X
X
X
X
X
PC
PC
PC
PC
PC
PC
M1207 PENDING CHANGES
EXCURSION 2000
POWER
LIMITER
MONO/STEREO
CLIP
LIMITER
LEFT GAIN RIGHT GAIN
CLIP
SUBWOOFER LEVEL CONTROL
LEFT INPUT RIGHT INPUT
FROM POWER SUPPLY
SUB INPUT
LEFT INPUT
RIGHT INPUT
3676
5908
5907
3522
4013
6858
6858
5906
5907
4434 4434
5906
4434
4010
3710
3664
4010
3694
3921
3921
3921
100N 100N
100N 100N 4148
4148 20K0
MPSA06
6K19
47K
15N
1K
47R
27K
100N
2K7
33K
7K96
100N
33R
100N
47K
10K
2K
470R
68K
10K
2N5551
220P
4148
1K
33K
1K 15K
4148
4148
3K9
100N
7K96
1K07
47R
470R
68K
4148
4148
1K5
4148
470N
100N
30K
220N
4148
3N3 2N2
4148
4148
470R
220K
1/2W
15K
2N2
22M
680R
270R
470R
270R
2K2
220N
1M
10P
4148
2N2
680R
1K4
1K5
4148
7K96
2K
470N330N
1K07
1K07
2N2
100K
2N2
4148
NE5532N
47K
2K
470R
100N
MPSA13
10K
10K
10K
47R
4148
63V
4U7
63V
1U
47K
TL072CP
1M
4K7
47K
47K
TL072CP
22K
15K10K
100N
10N
200K
470N
1K5
GRN
680R
2K7
10K
1K5
220R
100K
47K
TL072CP
15K
4148
15K
MPSA06
16V
100U
16V
100U
43K
NE5532N
100N
68N YEL
WHT
2N2
2K2
NE5532N
680R
NE5532N
10N
3N3
1K5
NE5532N
47K
2R2
10K
6K19
100N
1K07
7K96
7K96
7K96
100N
33K
220N
TL072CP
113K
4148
2K2
4148
270K
330N
7K96
2K
7K96
2N2
2N2
100N 33R
47K
1U
63V
NSL-32SR2
NSL-32SR2
4148
47K
NE5532N
RED
3K9
470N
680R
220P
100N
220N
2N5551
15N
2K
YEL
10U
63V
10U
63V
7K96 1K07
2K
100N
470N
470N 1K
1K07
33K
33K
6K19
2K2
4148
2K7
15K
330N
1K5
68N
3K9
15K
43K
680R
47R
470R
220N
10K
1K
4148
4148
33R 220N470N
4148
220K
4148
27K
4K7
20K0
10K 100K
4148
150K 4148 47K
2K2
220R
10K
4148
MPSA13
2K2 10K
4148
100N
22K
7K96
7K96
100N
4148
4U7
63V
470R
2K2
4148
1K
680R
B
10K
33K
NE5532N
4148
330N
2K7
B
10K
RED
4148
220N
NE5532N
15N
15N
10K
100N
47K
10K
47K
TL072CP
1M
220N
B
10K
100K
4148
47K
TL072CP
2N5401
47K
270K
LM13600N 100N
220N
4K7
4148
47K
100N
180K
3K9
2N2
6K19
NE5532N
113K
NE5532N
7K96
100N
NE5532N
100N
10K
100N
NE5532N
D
M1207
V3.00
TO LEFT SAT. AMP TO RIGHT SAT. AMP
TO SUBWOOFER AMP
SPUTNIK
X45
C17 C20
C62
C71
D13
D10
X11
R186
Q6
X10
R154
X3
R53
C59
X58
X28
R116
X24 R152
R55
X5
C69
R12
R8
R85
X43
X55
C63
X44
R168
C79
R147
R94 R146
R136
R142
X35 R57
Q2
X34
C22
D28
R107
X37 R111
X33
R115
R30
D2
D31
R110 X56
C18
R92
R3 X40
R137
R170
R141
X30
D25
D23
R96
D22
X51
C36
C31
R49
C29
X13
X14
D4
C50 C54
D36
D35
X19
R20
R43
X38
R38 C5
R39
R129
R119
X32
R162
R120
R132
C9
X2
X1
R37
C4
D34
C42
X23
R101
X49
X4
R166
R14
D3
R11
R171
X53
C49
C53
R79
R80
C45
R1
C2
D17
U19
R133
R145
R135
X31
C88
Q7
R155
R157
R149
R151
X54
D20
X41
C74
C75
R148
U7
R65
R68
R18
R19
U4
X18
R21
R28 R187
C14
C57
R175
C76
R176
L1 X26
R140
R22
R156
R63
X16
R45
R46
R52
U8
R48
D29
X17
R50
Q5
C24
C21
R127
U15
C64 C60
L3
S1
C55
R126
U16
X22
R108
U14
C56
C51
R10
U6
R26
R40
R35
R103
C65
R78
R84
X20
R86
R91
C68
R99
C85
U2
R165
D5
R16
X7
D1
R5
C52
R89
X48
X50
R172
R87
C46
C1
C70
R167
W2
R95
C73
U18
U17
D21
R134
X36
U21
L4
R159
C77
R100
C26
C13
C30
Q3
C66
R113
D14
C28C25
R90 R77
R114
X57
C10
C84
C48
R173
R4
X42
R98
X29
R112
R153
R131
D27
R15
R143
C80
R2
C61
R160
R144
R128
R130
R138
R174
C33 R158 R117
D24
D26
R169 C6C34
D15
R66
D8
R24
R61
R64
R60 R36
D9
R32 D16 R42
R27
R34
R58
D11 Q1
R29
R44
D7
C12 R23
R9
R6
C11
D33
C72
R161
R125
D19
R118
R139
P4
R177
U22
D32
C81
R69
P5 L2
D18
C32
U20
X27
C58
C67
R150
C7
R41
R56
R54
U9
R67
C27
P1
R33
D12
X15
R59
U5
Q4
R17
R31
U1
C23
C16
R51
D6
R25
C15
R47
R109
C43
J6
R102
U12
R13
U3
R7
C8
U13
W2
W29
C89
R62
C3
U11
J7
M1207
EXCURSION 2000
W15
J1
J4
J5

11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
of
Filename:
PCB# Sheet 21
Product
Date: Rev: YsType: .
M1209-4V00.sch2002
M1209
Power Supply
Wed Mar 09, 2005 4.00
Excursion 2000
of
Filename:
PCB# Sheet 21
Product
Date: Rev: YsType: .
M1209-4V00.sch2002
M1209
Power Supply
Wed Mar 09, 2005 4.00
Excursion 2000
W38
W36
W10
W11
0V
0V
0V
115V
135V
Blue
White
Black
Brown
0V
0V
0V
2
115V
0V
115V
135V
+15V
+15V
-29V
W20
W21
W37
1/4W
4K7
R33
+15V
PSGND
1/4W
33K
R14
MINI
3682
Red/Wht1 W34
-15V
PSGND
+29V
3682
Red/Wht2 W35
2W15:B
4
W51
Green
DUMMY
Yel/Blk
Blue
White
Brown
Orange
THERM1 THERM2
Blue
W56
Blue
W57
W38
DUMMY
W36
W10
PSGND
BRKR1
THERM3
Blue
W53
Yel/Blk
115V
115V
135V
Orange
R32
1/4W
MINI
20K0
DUMMY
W37
W21
W20
PSGND
+29V
0V
SECMID2
SECMID1
L8
3818
RED/WHT1
+41V
SECMID2
+41V
Black
230V
CHASSIS GROUND
MADE THROUGH
1/4" INPUT JACKS
3682
Green
Ground
W26
IEC_RECT
1/4W
4K7
R35
4148
D17
1/4W
4K7
R34
W20
W21
W37
W11
3682
Green
PSGND W27
250V
C112
4N7
100V
C52
100N
7A
F1
4148
D14
4148
D19
1/4W
100K
R31
MINI
4148
D18
2.7mH
L56500
PSGND
1/4W
10K0
R28
MINI
W38
W36
W10
W11
1
1500UH
L63817
W54
RED
0V
1/4W
18K
R37
MINI
3682
Yellow W14
3682
Red1 W13
UF4004
D8
UF4004
D7
UF4004
D6
PSGND
250V
C89
4N7
SECMID1
R163
2.0W
3R9
R99
2.0W
3R9
3682
Grey2 W23
SECMID2
R100
2.0W
3R9
R162
2.0W
3R9
35V
C12
100U
1N5244B
D9
0W5
14V0
1N5242B
D10
0W5
12V0
PSGND
1/4W
220R
R26
1/4W
220R
R13
4007
D60
4007
D59
4007
D13
YEL W41
TO92
MPSA13
Q2
5105
1/4W
10R
R5
FLMP
1/4W
10R
R6
FLMP
63V
C6
2U2
35V
C95
1000U
OUTIN
GND
U31
NJM7915FA
6857 {Watts}
TO220
{Function}
OUTIN
GND
U30
6856
NJM7815FA
{Watts}
TO220
Function
RED/WHT2
PSGND
2.0W
910R
R12
.
W28
Brown
PSGND
W18
3
W15:C 4
1W15:A
4
BRN/WHT1
160V
C117
3300U
SECMID1
MDL8
3414
F6
MDL8
3414
F5
5.0W
12K
R104
250V
C88
4N7
12A MDA
3414
F3
MDA12
PSGND
5.0W
12K
R103
250V
C87
4N7
Green
W19
4700U
C10
50V
BLK
18AWG
W42
W45
White
W33
White
RED
18AWG
W22
Orange
W29
Orange
W25
-130V
+130V
W47
Brown
1/2W
15K
R22
4700U
C8
50V
Brown
W9
Yellow
W46
Yel
W12
1/2W
15K
R21
1/2W
15K
R20
250V
C106
680N
275V
C102
22N
1/4W
14K0
R29
.
R30
1/4W
MINI
100K
C1
100V47P
R1
1/4W
MINI
1K0
1/4W
10K0
R38
MINI
UF4004
D5
3682
Red2 W17
1/4W
20K0
R39
MINI
R40
1/4W
MINI
2K05
L7
3818
1/4W
10K0
R4
3682
Grey1 W6
35V
C13
10U
1N5250B
D24
0W5
20V0
R197
2.0W
3R9
4007
D29
TO92
2N5401
Q16
5108
BRIDGE
D4
SIP
6772
1N4750A
D12
1W0
27V0
MDL8
3414
F7
4007
D57
W30
Orange
MDL8
3414
F4
BRIDGE
D3
SIP
6772
160V
C113
3300U
12A MDA
3414
F2
MDA12
4700U
C4
50V
W52
Green
Red
W7
1/2W
15K
R23
4700U
C3
50V
CBE
BC550C
EBC
2N5551
EBC
MPSA13
IGND
D53
4007
-29V
RED/WHT2
BRN/WHT2
SECMID1
PSGND
SECMID2
+29V
BRN/WHT1
RED/WHT1
VGND
3682
Brn/Wht2 W40
29Vdc
41Vdc
3682
Brn/Wht1W39
W1
Red
CH1334U
115V
CE Power Supply
245V
Green
IGND
W16
250V
C84
4N7 NTC
5R0
R2
6489
1.0W
1K8
R187
3682
White
Neutral
W5
POWER SUPPLY
S4
DPDT Switch 3682
Black
Line
W4
4148
D16
U1:A
TL072CP
FAN2
FAN
1/4W
470K
R8
MINI
MJF6388
6815
Q3
T221D
{Function}
250V
C96
4N7
D54
4007
3682
Vio1W31
3682
Vio2 W32
SECHI1
SECHI2
ACDETECT
TO92
MPSA13
Q1
5105
FETCNTL
TO92
2N5401
Q6
5108
4W15:D
4
R36
1/4W
MINI
470K
UF4004
D15
UF4004
D11
+15V_LS
50V
C15
100N
W24
Black
20A
SIPBRIDGE
63V
C103
4U7
160V
C101
3300U
GRN W8
BRN/WHT2
1/2W
15K
R25
55Vdc
Black
W48
63V
C9
10000U
W3
Red
250V
C71
680N
16V
C5
100U
W55
Black
250V
C70
100N
250V
C38
100N
R3
2.0W
3R9
C- C+
K1:B
35V
C11
100U
U1:B
TL072CP
R7
1/4W
MINI
33K
8
V+
4V-
U1:C
63V
C110
4U7
160V
C104
3300U
BRIDGE
D1
SIP
6772
1/2W
15K
R24
BRIDGE
D2
SIP
6772
W2
Black
63V
C2
10000U
CH1334U
CH1334U
N.A. Power Supply
OUTIN
GND
6856
U26
NJM7815FA
{Watts}
Function
TO220
Violet2
Grey2
Red/Wht2
Violet1
Brn/Wht2
Yel
Red1
Red2
Brn/Wht1
Grey1
Red/Wht1
Orange
Brown
White
Yel/Blk
Blue
Black
3722
K1:A
9
10
11
12
13
MODEL(S):-
DATE VER# DESCRIPTION OF CHANGE#
1
2
3
4
5
6
7
8
N
N
N
N
N
V
V
V
V
V
D
D
D
D
D
Added free pad to accomodate new C70 15mm lead spacing
Force update #3682 & changed W51 tab to graphic ForDS
PC#6733&6735 CHANGED W15 TO #3654 (CK)
N
.
.
.
V3.00
V
V1.00
NOV/4/2004
OCT-21-2004
OCT-08-2004
SEP-24-2004
D
EX2
M1209 PCB History
Maiden Voyage2-JUN-2004
2-Jul-2004 V2.00 Thickened traces added notes
PC#6752 CORRECT F2 F3 8A TO 12A (HG)
PC#6750 (GT) BOARD MADE WITH 15MM SPACE FOR C70V4.00FEB-09-2005

6
3
#
5
4
2
1
DATE
MODEL(S):-
VER# DESCRIPTION OF CHANGE
D
D
V
V
N
N
D
D
D
D
V
V
V
V
N
N
N
N
M1209 DRILL HISTORY
EX2
4
1
6
5
3
#
2
MODEL(S):-
PC#
*PLACE IMPLEMENTED CHANGES INTO BOARD HISTORY
PENDING CHANGE
X
X
X
X
X
X
PC
PC
PC
PC
PC
PC
M1209 PENDING CHANGES
EX2

11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
M
M
N
N
O
O
P
P
Q
Q
of
Filename:
PCB# Sheet 21
Product
Date: Rev: YsType:{Company
N
m1210-3V0sch.sch2002
M1210
WooferAmp
Thu Aug 25, 2005 3.00
Excursion 2000
of
Filename:
PCB# Sheet 21
Product
Date: Rev: YsType:{Company
N
m1210-3V0sch.sch2002
M1210
WooferAmp
Thu Aug 25, 2005 3.00
Excursion 2000
-130V
-15V
100p
100p
UF4004
D5
1/4W
1K4
R74
1/4W
1K4
R70
WOOFGND
-15V
+15V
+130V
VGND
1/4W
1M
R52
RAD
UF4004
D6
UF4004
D8
1/4W
1K4
R63
VGND
UF4004
D7
+15V
+5V_MOD
+4V7_LS
WOOFGND
+5V_MOD
VGND
SDOWN
VGND
+5V_MOD
LEDGND
SIGNAL1
SIGNAL
-5V_MOD
WOOFGND
SIGNAL
SIGNAL1
DEBUMP
R192
1/4W
FLMP
47R5
WOOFGND
+4V7_LS
+15V_LS
NET00208
+12V ret
(ACDETECT)
Power tienet
R75
1/4W
470R
+4V7_LS
+15V_LS
+15V
WOOFGND
8
PSGND
-15V_MOD
R101
1/8W
FLMP
10R0
PSGND
FBACK-
FBACK+
+15V_MOD
D44
0A2BAT85
Red
SPKR+ IN
W1
Black
SPKR- OUT
W6
Black
SPKR- IN
W7
-5V_MOD
+15V_LS
+4V7_LS
-15V
8
V+
4V-
U12:C
100V
C59
100N
714 14
V+
7V-
U9:E
VGND
4
5
6
U9:B
74HC86N
6605
VGND
13
IN
12 OUT
U11:F
74HC14N
6603
R12
1/4W
4K7
U23:E
100V
C79
100N
R171
1/4W
47R
50V
C64
470P
100V
C80
100N
1/4W
1K0
R64
MINI
1/4W
1K0
R67
MINI
-15V_MOD
100V
C61
100N
DEBUMP
GNDA
1/4W
1M
R69
RAD 400V
C40
1N
+4V7_LS
C41
100V10N
R170
1/4W
MINI
100K
VGND
BAT85
D48
0A2
100V
C34
100N
1/2W
1R
R46
SMALL
R53
1/4W
2R2
UF4004
D17
1/4W
10K0
R156
MINI
100V
C2
100P
R71
1/4W
MINI
10K0
C77
100V100P
1/4W
1M
R57
RAD
63V
C25
10U 1N5248B
D12
0W5
18V0
R147
1/4W
22K
R149
1/4W
330K
1/4W
100K
R151
MINI
R158
1/4W
MINI
10K0
+15V_LS VGND
7
W3:G 0
6
W3:F 0
8
W3:H 0 1/4W
470R
R66
RAD
4148
D21
1/4W
180K
R41
RAD
D16
0W5
18V0
1N5248B
1/4W
22K
R150
4148
D36
-130V PSGND -15VTHERM3
3
W3:C 0
2
W3:B 0
4
W3:D 0
WOOFGND
1/4W
1M
R199
5.0W
0R047
R59
R182
2.0W
2R
2.0W
2R
R161
400V
C81
1N
FBACK+
2.0W
2R
R188
R186
2.0W
2R
1/4W
220K
R146
+15V
+5V_MOD
140V
C31
3U3 340V
C7
3U3
140V
C22
3U3
250V
C23
100N
R79
1/4W
68K
100V
C55
100N
100V
C56
100N
-15V
+4V7_LS
VGND
140V
C44
3U3
0
6
R80
1/4W
0.1%
9K76
1/4W
9K76
R76
0.1%
PSGND
+15V
2.0W
2R
R184
R183
2.0W
2R
400V
C82
1N
FBACK-
R189
2.0W
2R
R82
1/4W
113K
R78
1/4W
113K
100V
C45
470P
PSGND
R102
1/8W
FLMP
10R0
1N5248B
D23
0W5
18V0
1N5248B
D27
0W5
18V0
1/4W
180K
R43
RAD
Black
PSGND
W5
Red
SPKR+ OUT
W2
Red
+29V
W4
1.0W
10K0
R8
.
100V
C68
100N
OUTIN
GND
MC79L05ACP
6732
U3
TO92
63V
C28
1U
R51
1/4W
180R
100V
C26
100N
100V
C67
100N
OUTIN
GND
U19
6728
MC78L05ABPRM
TO92
+5V_MOD
UF4004
D18
1N5244B
D9
0W5
14V0
1/4W
47K
R4
.
VGND
SDOWN
1/4W
10R
R6
FLMP
1/4W
10R
R5
FLMP
TO92
MPSA13
Q2
5105
+4V7_LS
VGND
WOOFGND
BAV21
D28
VGND
100V
C33
100N
100V
C62
39N
50V
C65
470P
R167
1/4W
47R
1/4W
220R
R65
1/4W
33K
R117
MINI 400V
C69
1N
R1
1/4W
MINI
20K0
C1
50V470N
R44
1/8W
FLMP
33R
1/2W
4K7
R124
1/4W
100K
R125
MINI
4148
D33
1/4W
220R
R152
1/8W
1K
R60
FLMP
50V
C39
5N6
4148
D34
TO92
2N5401
Q8
5108
50V
C72
220N
L16497
304UH
400V
C85
1N
connect to heat
spreader
1/4W
1K0
R45
MINI
140V
C20
3U3
1N5248B
D22
0W5
18V0
100V
C63
100N
2.0W
2R
R190
100V
C46
470P
L26497
304UH
(VCC)
LM13600N
Dual VCA
6745
U23:D
{Function}
400V
C86
1N
1.0W
10K0
R9
.
1/8W
100R0
R115
FLMP
D26
0A2BAT85
63V
C27
10U
1/8W
100R0
R107
FLMP
35V
C12
100U
1N5242B
D10
0W5
12V0
100V
C76
100N
100V
C66
39N
5W29:E8
To input PCB
R50
1/4W
180R
D42
0A2 BAT85
+4V7_LS
5
connect to
heat spreader
-15V
+15V
THERM3
WOOFGND
+5V_MOD
8
V+
4V-
U24:C 1XC230
1XC220
8W29:H8
7W29:G8
6W29:F8
1/4W
10K
R168
MINI
Q6
5108
TO92
2N5401
1W29:A8
3W29:C8
2W29:B8
4W29:D8
714
R172
1/4W
270R
4148
D38
63V
C35
1U
R166
1/4W
270R 100V
C24
100N
R38
1/2W
100R
WOOFGND
Q18
5108
TO92
2N5401
loop1
Copper
Tie what Here
SIGNAL
FROM
INPUT
R109
1/4W
47R
100V
C60
100N
R154
1/4W
MINI
10K0
U12:B
MC33078P
+15V_MOD
From Power Supply
PCB
+130V
1
W3:A 0
5
W3:E 0
1N4732A
D25
1W0
4V7
1/4W
1M
R198
11 IN 10
OUT
U11:E
74HC14N
6603
13 IN 12
OUT
U20:F
74HC14N
6603
TO92
2N5551
Q17
5107
3IN 4
OUT
U11:B
74HC14N
6603
9IN 8
OUT
U20:D
74HC14N
6603
5.0W
0R047
R58
1N5248B
D20
0W5
18V0
1IN 2
OUT
U20:A
74HC14N
6603
G
D
S
IRFP31N50L
N
Q15
6782
TO247
Function
250V
C30
100N
WOOFGND
TO92
BC550C
Q10
5101
50V
C73
220N
C78
100V15P
1/4W
82K
R40
R157
1/4W
MINI
10K0
U24:A
MC33078P
-5V_MOD
100V
C54
100N
PSGND
-15V_MOD
+15V_MOD
100V
C53
100N
100V
C57
100N
100V
C29
100N
1/2W
1R
R47
SMALL
R62
1/4W
2R2
250V
C43
100N
1N5248B
D14
0W5
18V0
G
D
S
IRFP31N50L
N
Q23
6782
TO247
R195
1/2W
100R
NTC
10K
R200
6467
R81
1/4W
113K
R7
2.0W
3R9 35V
C11
100U
R77
1/4W
113K
TO92
MPSA13
Q4
5105
R61
1/4W
4K7
5
IN
6OUT
U11:C
74HC14N
6603
D19
0A2 BAT85
100V
C32
6N8
R155
1/4W
MINI
10K0
2
+
3
-
4V- 8
V+
5BAL
1GND
7OUT
6
STROBE
LM311
U10
6640
4148
D37
U24:B
MC33078P
R108
1/4W
1M
1IN 2
OUT
U11:A
74HC14N
6603
9IN 8
OUT
U11:D
74HC14N
6603
5IN 6
OUT
U20:C
74HC14N
6603
11 IN 10
OUT
U20:E
74HC14N
6603
G
D
S
IRFP31N50L
N
Q14
6782
TO247
Function
R72
1/4W
4K7
1/4W
1K
R145
MINI
LM13600N
U23:A
250V
C19
100N
LM13600N
U23:B
R54
1/8W
FLMP
33R
100V
C58
100N
R193
1/4W
FLMP
47R5
3722
K1:A
G
D
S
IRFP31N50L
N
Q24
6782
TO247
C- C+
K1:B
U13:A
6887
IR2110
13
12
11
U9:D
74HC86N
6605
1
2
3
U9:A
74HC86N
6605
3
IN
4OUT
U20:B
74HC14N
6603
U12:A
MC33078P
Anti-Thwak
Relay Circuit
10
9
8
U9:C
74HC86N
6605
(VCC)
LM13600N
Dual VCA
6745
U23:C
{Function}
WOOFER S2 #7465 8R 12000WPGM
U14:A
6887
IR2110

TAB
NORMAL
SOCKET
SOCKET WITH DIRECTION
NORMAL LARGE
SOCKET UPSIDE DOWN
Place within the board area.
Copy for any break-away boards.
V
T
R
V
T
R
V
T
R
V
T
R
V
T
R
V
T
RV
T
R
V
T
R
V
T
R
1
V
T
R
NC
NO
C1
C2
-
+
Function
Function Function Function
5865
5865
6782
3658
5949
5865
6782 6782
5949
5865
5949
5951
6782
3543
5949
100N
220R
4148
470P
12V0
47K
100N
18V0
68K
100N
100N
4K7
1M
4148
100N
113K
15P
100N
100K
BAT85
100R0
100N
1R
100N
UF4004
1K4
47R
270R
470P
UF4004
100N
1K0
4148
220K
82K
BAT85
22K
10K0
2N5401
BAT85
74HC14N
100N
100N
470R
TO92
MC79L05ACP
UF4004
18V0
2R2
2N5401
1N
47R
1K
270R
1N
2.0W
2R
2.0W
2R
35V
100U
UF4004
14V0
100U
35V
10R
4148
4148
100N
1M
1N
10K
10R
10N
470P
100N
1M
100N
BC550C
1K0
220N
220N
100N
IRFP31N50L
10K0
LM311
100N
6N8
1N
1U
63V
10U
63V
33R
220R
20K0
100P
100P
330K
BAT85
10K
63V
10U
100N
UF4004
1U
63V
3U3
140V
100N
9K76
MPSA13
470P
9K76
113K
39N
18V0
100N
MC33078P
1K0 100R
1/2W
18V0
180K
1.0W
10K0
BAV21
4K7
100N
33K
10R0
100R0
39N
180R
18V0 180K
1M
1N
47R
10K0
22K
4148
470R
47R5
2R2
1.0W
10K0
3R9
2.0W
1K4
4K7
1/2W
1K4
BAT85
MC78L05ABPRM
1N
10R0
1M 5N6
100K
2N5551
1M
IR2110
33R
47R5
100R
1/2W
100N
2R
2.0W
100N
IRFP31N50L IRFP31N50L
MC33078P
LM13600N
470N
100K
100N
10K0
2N5401
10K0
4K7
113K
4V7
1K
IR2110
180R
18V0
2R
2.0W
2R
2.0W
1R
UF4004
18V0
2.0W
2R
3U3
140V
100N
10K0
1455P1
113K
MPSA13
3U3
140V
Zinc
2.0W
2R
74HC14N
5.0W
0R047
3U3
340V
2.0W
2R
IRFP31N50L
74HC86N
RELAY 1A
140V
3U3
5.0W
0R047
Zinc
USE A #8835 SCREW
FROM THE BOTTOM
AND #8800 NUT TO
MOUNT HEAT SPREADER
C53
R65
D33 C64
D10
R4
C56
D22
R79 C59
C29
R12
R52
D21
C79
R77
C78
C26
R170
D42
R115
C67
R46
C24
D5
R70
R171
R172 C65
D18
C60
R67
D34
R146
R40
D26
R150
R71
Q6
D19
U20
C54
C63
R66
U3
D17
D12
R53
Q18
C40
R167
R60
R166
C81
R182 R161
5
C12
D6 D9
C11
R5
D37
D38
C43
R198
C82
R200
8
R6
C41
C46
C61
R108
C80
Q10
R45
C73
C72
C30
Q24
R155
U10
C58
C32
C86
C28
C27
R54
R152
R1
C2
C77
R149
D44
W29
R168
C25
C55
D8
C35
C20
C23
R76
Q2
C45
R80
R81
C66
D14
C76
U24
R64
R195 D23
R43
R8
D28
R61
C68 R117
R102
R107
C62
R50
D20 R41
R57
C85
R109
R158
R147
D36
R75
X5
R193
R62
R9
R7
R63
R124
R74
D48
U19
C69
R101
R69
C39
R125
Q17
R199
U13
R44
R192
R38
C34
R186
C33
Q14 Q15
Copper
Tie Here
U12
U23
C1
R151
C57
R157
Q8
R156
R72
R82
D25
R145
X2
U14
R51
D27
X3
R189
R190
R47
D7
D16
R188
C22
C19
R154
U8
R78
Q4
C31
R184
U11
R58
C7
R183
Q23
U9
K1
W3
C44
R59

L
N
M1206 LEFT SAT.
M1206 RIGHT SAT.
M1209 POWER SUPPLY
M1206 SPEAKON INPUT BREAKAWAY
M1210 SUBWOOFER AMP
M1207 INPUT PCB
WOOFER
FROM FAN
RIGHT
LEFT
YELLOW
BLACK
RED
BLACK
RED
BLACK
BLACK
ORANGE
GREY RIBBON
GREY RIBBON TO M1206 LEFTSAT.
GREY RIBBON TO M1206 RIGHTSAT.
BLUE
RED BLACK
YELLOW BROWN
ORANGEWHITE
GREY
BLUE
RED BLACK
YELLOW BROWN
ORANGEWHITE
GREY
GREEN
WHITE
BLACK
BLACK
BLACK
BLUE
WHITE
BLACK
ORANGE
BROWN
RED
BLUE
RED
BLUE
RED
GREY RIBBON TO M1209
GREY RIBBON
TO M1207
M1209
TO
M1210
M1206
TO
M1210
M1206
TO
M1210 BLACK
YELLOW

CH1334U
L
N
WHITE
GREEN
CIR. BRK
EX2
GREY
#3961
Insulating
Bushing
White
WIRES TO (2) M1206

CH1334U
L
N
WHITE
GREEN
CIR. BRK
EX2
GREY
WIRES TO M1210
#3961
Insulating
Bushing

ORN
BRN
WHT
YEL/BLK
CH1334U
PRIMARY WIRING
L
N
WHITE
GREEN
CIR. BRK
N/C
BLK
BLUE
230V CE
EX2

ORN
BRN
WHT
YEL/BLK
CH1334U
PRIMARY WIRING
L
N
WHITE
GREEN
CIR. BRK
N/C
BLK
BLUE
EX2
245VAC CE
