➲ 60-watt 6.5-inch Ceiling Mount Speaker
➲ Coaxial 6.5-inch woofer and 3/4-inch
titanium coated tweeter
➲ 70-volt taps at 7.5, 15, 30 or 60-watts
➲ 100-volt taps at 15, 30 or 60-watts
➲100 to 20,000 Hz Frequency Response
➲Screw Terminal Inputs
➲Aluminum / ABS Plastic Cabinet Construction
➲Two-year Unconditional Warranty*
*Warrany valid in Canada and the United States only
The C165W is a 60-watt 6.5-inch high performance ceiling mount loudspeaker. Ideal for any
background music or paging system where superior sound quality is a priority, this speaker is
made for louder club or restaurant / retail environments. Featuring an innovative design and
employing high quality materials, the C165W maintains excellent performance from a compact
ceiling loudspeaker. The C165W contains a coaxial 6.5-inch woofer and 3/4-inch titanium
coated tweeter. Built in 70-volt taps at 7.5, 15, 30 or 60-watt operation means that high
fidelity full range sound can be achieved over an extremely wide coverage pattern area. Virtually
any 70-volt amplification or paging system, including the Coliseum CA1 or CA1T can drive the
C165W.
Coliseum C165W
Coliseum C165W
Features:
Overview:
yorkville.com
100-watt Ceiling Speaker
100-watt Ceiling Speaker
C165W Specifications:
Model
TYPE
SYSTEM
PROGRAMPOWER (watts)
IMPEDANCE (ohms)
SENSITIVITY (dB @ 1W/1m)
FREQ. RESP. (+/-3dB)
WOOFER
TWEETER
INPUTS
CABINET CONSTRUCTION
STANDARD COLOR
OPTIONAL COLOR
STANDARD HARDWARE
OPTIONAL HARDWARE
70V TRANSFORMER TAPS
DIMENSIONS (DxWxH inches)
DIMENSIONS (DxWxH cm)
WEIGHT (lbs / kg)
After years of experience with enclosure design, it was logical for Yorkville to apply its knowledge
to the design of a range of speaker cabinets that have been specifically designed for small-scale
installation purposes. The knowledge that we gained while developing the TX, élite, Pulse and
Performance series enclosures was applied to yield a series of practical yet cost effective
installation enclosures.
All enclosures and grilles can be easily refinished and many have the option of coming in either a
black or white finish. Designed for fixed installation or live use, the Coliseum Mini Series like the
C110, C170 and WM5T have a complete list of features that make them an extremely good value.
The practically configured C110 incorporates a multi-tap 70V transformer for fixed installations
while the waterproof C120 is perfect for indoor or outdoor application as a loudspeaker or can be
mounted on a microphone stand as a mini monitor. The WM5T in-wall speaker is a clean, high
performance solution that is sure to solve space constraint issues. Basic mounting hardware is
included with most models.
Coliseum Mini Series Overview:
C165W
Ceiling Speaker
Full Range ‘Pot Light’
60
70V Transformer / Passive 8Ω
92
100 - 20k
6"
3/4”
Screw Terminal
Aluminum / ABS Plastic
White
-
Ceiling Mount Clips
-
2.5W / 5W / 10W
10 (Diameter) x 7 (Depth)
25 (Diameter) x 18 (Depth)
7.3 / 3.3
