Ypsomed YpsoPump User manual

Caregiver
Guide.
Important information about
the mylife™YpsoPump®insulin pump system.
More freedom. More confidence. With mylife™.

2
Contents
Important contact information 3
Tips for caregivers 4
mylife™YpsoPump®system overview 6
Menu map 8
Operation 10
Access lock 16
The mylife™App bolus calculator 20
Bolus calculation 21
How to deliver a bolus 30
Standard bolus 30
Extended bolus 31
Combination bolus 32
How to activate a temporary basal rate 35
How to change the cartridge and the infusion set 37
How to start insulin delivery 50
How to stop insulin delivery 51
How to change the battery 53
Icon overview 57
Warnings and alarms 60
Supplies 67
Read the User Guide
The instructions for use in this Caregiver Guide are only valid for the following
mylife™YpsoPump®article: REF 700012342.
You find the mylife™YpsoPump®reference number on the device and on the
Starter Kit label.

3
Important contact information
As a caregiver for a child with diabetes, you want to make sure that you are doing the
right thing and providing proper care. This guide is intended to be used in conjunction
with the child’s diabetes management plan, input from the parents and/or healthcare
provider and the mylife™YpsoPump®User Guide. Refer to the mylife™YpsoPump®User
Guide for complete information on how to use the system and for a description of all
related warnings and alarms. The User Guide is available online:
www.mylife-diabetescare.co.in/ypsopump-userguide
Whether you are a parent, grandparent, school nurse, daycare provider or any
secondary caregiver for a child using the mylife™YpsoPump®insulin pump, this guide
will lead you through some of the key functions that you may need to perform.
In an emergency, call the child’s healthcare provider as well as the emergency contact.
mylife™YpsoPump®user
First name / last name: Date of birth:
Healthcare provider
Medical facility:
First name / last name healthcare professional:
Phone:
Emergency contacts
First name / last name: First name / last name:
Relationship: Relationship:
Phone: Phone:
Glucose monitoring
Target range: mg/dL to mg/dL
Meter brand: Routine testing times:
Can the user perform a glucose test herself/himself? Yes No

4
Tips for caregivers
School and everyday life
Nursery/School/Sport
As a caregiver, you can discuss with the child, whether it wants to show and explain
its diabetes with its blood glucose monitoring system, insulin pump or pen. Maybe the
child would also like to make a presentation about its diabetes in front of the class.
To make sure that the child always has everything with it at school, it is important that
you check with it whether it has an emergency box (spare material and suitable food
in case of hypoglycaemia) and the parents’ phone number with it or has positioned it
somewhere in the classroom.
When the child notices that it has a low blood glucose level, it should immediately be
able to consume some glucose and measure its blood glucose level again afterwards.
Low blood glucose levels make concentration and thinking difficult.
Before sports lessons, the child must measure its blood glucose level. Depending on
the age of the child, you can help it decide what it should do because of its measured
blood glucose level. It should have some fast and slow carbohydrates available in its
sports bag.
In case of a low level, the child should eat or drink first (juice, fruit, bread, muesli bar or
yoghurt) and then measure its blood glucose level again after a certain period of time.
If the child does not feel well during the lesson and thinks it might be suffering
from hypoglycaemia, it should stop exercising immediately and should think about the
measurements in case of hypoglycaemia and act accordingly.

5
School excursions and overnight stays
A school excursion is similar to an overnight stay. There are a few things which need to
be kept in mind.
As a caregiver, it makes sense to discuss in advance with the child and its parents what
it can already do on its own and how you can support it. The blood glucose measure-
ment times, the insulin delivery and, if necessary, also the carbohydrate amounts should
be discussed in advance. While hiking, playing or romping, the child needs less insulin.
If necessary, the measurements in case of a hypoglycaemia should be discussed again
and it should be defined whether the emergency syringe should also be taken along
and who could and would want to give it in case of emergency. The child should always
have the bag with the emergency box and the parents’ phone number with it.
Child’s birthday
Of course, the child may participate in everything at its friends’ birthday parties. Eating
cake, ice cream or pasta, playing football, climbing, having fun. Nonetheless, there are a
few things which need to be kept in mind.
As a caregiver, you should be informed about the diabetes by the child or the parents. It
makes sense to discuss in advance with the child and its parents what it can already do
on its own and how you can support it.
The child should always have the bag with the emergency box and the parents’ phone
number with it. While playing and romping, the child needs less insulin. The child
should only drink light or zero drinks. Please get them or ask the child to take them with
it. If there is no sugar in the drinks, no insulin is needed.
If special excursions or activities are planned, it makes sense to inform the child in
advance so that it can discuss with its parents, when, how and how much insulin it will
need. Great treats can also be discussed in advance.

6
mylife™YpsoPump®system overview
Cannula
(soft or steel)
Cannula base
Tape Adapter
Tubing cap
Tubing
Infusion set

7
Function button
Battery
compartmentTouchscreen
Cartridge
compartment with
viewing window
Self-filled (mylife™YpsoPump®
Reservoir) 1.6 ml reservoir

8
Menu map
Display of last bolus
Cartridge change
Basal rates
Bolus
Status screen
Main menu
Standard
bolus
Extended
bolus
Combination
bolus
Temporary basal
rate function
Basal rate profiles
A and B
Switch basal
rate profile
Therapy
data
Alarm
history
Submenu
The mylife™YpsoPump®imagery in this Caregiver Guide is for illustrative purposes
only and should not be considered as suggestions for user settings.

9
Prime infusion set
Unlock screen
Main menu
Prime
tubing
Prime
cannula
Data SettingsStop / Run mode
Submenu
Time
of day Date
Bolus
increment
Blind bolus
inactive/active
Access lock
inactive/active
Rotate
screen
Bluetooth®
inactive/active
Bluetooth®
pairing

10
Operation
Function button
Function button
The mylife™ YpsoPump®has a function button. It is located next to the opening
of the cartridge compartment on the side.
The function button has two different functionalities:
Short press (for up to 0.8 seconds)
Long press (for at least 2 seconds until the mylife™ YpsoPump®vibrates)
With the function button, you can:
switch the screen on and off.
programme a blind bolus.
return to the status screen.
Function button

11
Operation
Navigation
Touchscreen
The mylife™YpsoPump®has a touchscreen (referred to below as the screen). You control
the screen by using your finger to tap icons and values or swipe through menus and
values. The screen of the mylife™YpsoPump®may only be controlled with one finger.
Do not use any objects to operate the screen.
Tap an icon with your finger to select it.
Using your finger, swipe up or down
through the values displayed in order to
scroll up or down.
By swiping to the left or to the right,
you can select the different main menu
and submenu icons.
You can also tap the upper or lower value
directly in order to increase or reduce it by
one unit each time.

12
Active and inactive icons
Active icons are bright. That means the
function is available and can be selected
with your finger.
Conrmation and cancellation
Inactive icons are displayed in a darker
grey. This means the function is not
available and cannot be selected with your
finger.
To confirm a value or select a function,
tap .
To cancel a procedure or function, tap .
Additionally, bolus cancellation always has
to be confirmed by tapping .
Back function
If you have selected a function or value by mistake or made a wrong setting, you can go
back at any time by swiping to the right once until or appears.
If appears, you go one step back. If appears, you move up one menu
level.

1
13
2/6: The mylife™ YpsoPump®has a screen
lock. It is visualised by a padlock icon
at the top right of the screen, next to the
battery charge indicator.
1/6: The status screen of the mylife™
YpsoPump®is switched on and
off by pressing the function button (short
button press).
3/6: Swipe to the left to unlock the status
screen and the main menu.
4/6: Tap the currently active number
successively to unlock the status screen.
Operation
User interface
Unlock screen
2
34

5
14
6/6: Swipe to the right to access the
unlocked status screen (no padlock icon).
5/6: When the mylife™ YpsoPump®has
been unlocked successfully, you are in
the main menu. Swipe to the left to access
all available menu items.
Make sure that the pump screen is switched off before storing the mylife™YpsoPump®
in a trouser pocket or carrying system in order to avoid unintentional operation of
the pump.
6

15
Overview of the main menu
On the screen, you will see three menu icons at a time. To see the other menu icons,
swipe to the left across the screen with your finger.
The navigation bar above the icons shows you the number of menu icons available.
The small squares highlighted in white indicate where you currently are in the main
menu. When operating the mylife™ YpsoPump®, always make sure you use the various
functions properly.
If the mylife™YpsoPump®is not operated on the status screen, the screen switches
off after 20 seconds and the screen lock is activated. If the mylife™YpsoPump®is
not operated in the main menu or in a submenu, the screen switches off after two
minutes and the screen lock is activated. Any changes that have not been saved
are lost.
Bolus Cartridge change
Stop / Run modeBasal rates Prime
infusion set
Data Settings

16
When the access lock function is activated,
all inactive icons are displayed in a darker
grey. This means the function is not available
and cannot be selected.
Access lock
The access lock function offers access protection.
When the access lock function is activated, only the following mylife™YpsoPump®
functions can be operated:
Data: View therapy data and alarm history
Settings: Rotate screen
Settings: Deactivate access lock function
The following mylife™YpsoPump®functions cannot be operated when the
access lock function is activated:
All types of bolus delivery
Temporary basal rate function
Programming and switching basal rate profiles
Returning threaded rod for cartridge change
Priming infusion set and cannula
Switch to run or stop mode
Time and date settings
Bolus increment settings
Activate/deactivate blind bolus
Activate/deactivate Bluetooth®
Bluetooth®pairing
The icons for these functions are shaded grey in the menu.

1 2
3 4
5
17
Activating access lock
1/5: Open the main menu and tap the
“Settings” icon.
2/5: Swipe to the left and tap the
“Access lock inactive / activate” icon.
3/5: Confirm by tapping . The mylife™
YpsoPump®vibrates briefly, and
the access lock function is activated.
4/5: The status screen appears.
The activated access lock function is
visualised by an access lock icon at
the top of the screen.
5/5: If you open the main menu again,
tap the “Settings” icon and swipe to the
left, the “Access lock active / deactivate”
icon now appears.
Basal rate delivery continues when the access lock is activated.

1
3
5
2
4
18
1/5: Open the main menu and tap the
“Settings” icon.
2/5: Swipe to the left and tap the
“Access lock active / deactivate” icon.
Deactivating access lock
3/5: Confirm by tapping . The mylife™
YpsoPump®vibrates briefly, and
the access lock function is deactivated.
4/5: The status screen appears.
The access lock icon at the top of the
screen disappears. All icons are
now active and the functions can be
operated again.
5/5: If you open the main menu again,
tap the “Settings” icon and swipe
to the left, the “Access lock inactive /
activate” icon now appears.

U
g
U
U
U
Bolus calculator
Blood glucose
mg/dL
Carbohydrates
Correction
bolus
Suggested bolus
Meal bolus
Insulin on
board
Reset
Save
172
15
3.4
1.3
4.1
0.6
Ypsomed 13:34 100%
U
U
U
U
g
U
Bolus calculator
Blood glucose
mg/dL
Carbohydrates
Correction bolus
Suggested bolus
Adj. insulin on board
Correction insulin Meal bolus
Save
Reset
1.3
3.4
3.4
0
1.3
172 15
Ypsomed 13:34 100%
20
The mylife™App bolus calculator
Method 1: see page 21 Method 2: see page 25
Important: The mylife™App bolus calculator offers two methods for the calculation
of a bolus suggestion. Your patient’s physician or diabetes counsellor will have
selected the one method that ts best the targeted therapy.
To be sure what method your patient is using, please compare the bolus calculator
screen in your patient’s mylife™ App prole with the two images below. Then go
to the respective page number indicated to nd more information in this Caregiver
Guide about the selected method. For further information, the mylife™App User
Guide is available in the mylife™App itself or on our website:
www.mylife-diabetescare.co.in/downloads
