YUNEEC ST10+ User manual

1
BATTERY WARNINGS AND USAGE GUIDELINES
WARNING: Lithium Polymer (LiPo) baeries are significantly more
volale than alkaline, NiCd or NiMH baeries. All instrucons and
warnings must be followed exactly to prevent property damage and/or
serious injury as the mishandling of LiPo baeries can result in fire. By
handling, charging or using the included LiPo baery you assume all risks
associated with LiPo baeries. If you do not agree with these condions
please return the complete product in new, unused condion to the place
of purchase immediately.
• You must always charge the LiPo baery in a safe, well-venlated area
away from flammable materials.
• Never charge the LiPo baery unaended at any me. When charging
the baery you must always remain in constant observaon to monitor the
charging process and react immediately to any potenal problems that may
occur.
• Aer flying/discharging the LiPo baery you must allow it to cool to
ambient/room temperature before recharging.
• To charge the LiPo baery you must use only the included charger or a
suitably compable LiPo baery charger. Failure to do so may result in a
fire causing property damage and/or serious injury.
• If at any me the LiPo baery begins to balloon or swell, disconnue
charging or discharging immediately. Quickly and safely disconnect the
baery, then place it in a safe, open area away from flammable materials to
observe it for at least 15 minutes. Connuing to charge or discharge a
baery that has begun to balloon or swell can result in a fire. A baery that
has ballooned or swollen even a small amount must be removed from
service completely.
• Do not over-discharge the LiPo baery. Discharging the baery too low
can cause damage to the baery resulng in reduced power, flight duraon
or failure of the baery enrely. LiPo cells should not be discharged to
below 3.0V each under load.
• Store the LiPo baery at room temperature and in a dry area for best
results.
• When charging, transporng or temporarily storing the LiPo baery the
temperature range should be from approximately 40–120° F (5–49° C). Do
not store the baery or aircra in a hot garage, car or direct sunlight. If
stored in a hot garage or car the baery can be damaged or even catch fire.
• Never leave baeries, chargers and power supplies unaended during
use.
• Never aempt to charge low voltage, ballooned/swollen, damaged or wet
baeries.
• Never allow children under 14 years of age to charge baeries.
• Never charge a baery if any of the wire leads have been damaged or
shorted.
• Never aempt to disassemble the baery, charger or power supply.
• Never drop baeries, chargers or power supplies.
• Always inspect the baery, charger and power supply before charging.
• Always ensure correct polarity before connecng baeries, chargers and
power supplies.
• Always disconnect the baery aer charging.
• Always terminate all processes if the baery, charger or power supply
malfuncons.
IMPORTANT NOTE: It’s safer and beer for the longevity of the baery to
store it only parally charged for any length of me. Storing the baery
approximately 50% charged (which is around 3.85V per cell) is typically
best, however, it will take some careful management of the charge me and
the use of a volt meter to achieve this voltage. If you have the equipment
and skills to achieve the 50% charge level for storage it is recommended. If
not, simply be sure to not store the baery fully charged whenever
possible. In fact, as long as the baery will be stored at approximately room
temperature and for no more than a few weeks before the next use, it may
be best to store the baery in the discharged state aer the last flight (as
long as the baery was not over-discharged on the last flight).

CHARGING THE BATTERIES
WARNING: Lithium Ion (LiIon) and Lithium Polymer (LiPo) baeries are
significantly more volale than alkaline, NiCd or NiMH baeries. All
instrucons and warnings must be followed exactly to prevent property
damage and/or serious injury as the mishandling of LiIon/LiPo baeries
can result in fire. By handling, charging or using the included LiIon/LiPo
baeries you assume all risks associated with them. If you do not agree
with these condions please return the complete product in new, unused
condion to the place of purchase immediately.
CHARGING THE LI-ION ST10+ BATTERY
You can charge the LiIon baery installed in the ST10+ from a 100-240V
AC outlet using the USB adapter/charger, or from a suitable USB power
source (2.0 amps max), with the USB to micro USB cable. While the ST10+
is powered off connect the cable to the USB adapter/charger, then plug it
into the USB connector/charging port on the right side. Aer approximate-
ly 30-45 seconds the LED indicator for the baery will blink blue while the
baery is charging, and will glow solid blue when the baery is fully
charged. It will take approximately 5.5 hours to charge a fully discharged
(not over-discharged ) baery.
NOTE: The AC plug type will vary depending on the region in which the
product was imported/purchased (AU = Australian; EU = European; UK =
United Kingdom; US = United States). 2
1
2
3
4
5
6
7
8 9 10
11
12
13
14
15
17
18
16
ST10+ OVERVIEW
1 Proporonal Control Rate Slider
2 USB Connector/Charging Port
3 Audio/Earphone Jack
4 Take Sll Photo Buon
5 Start/Stop Motors Buon
6 Rudder/Yaw Control (for Mode 2 and Mode 1)
7 Throle/Altude Control (for Mode 2)
Elevator/Pitch Control (for Mode 1)
8 5.8GHz Antenna (located inside the case)
9 Status Indicators (for ST10+ baery, 5.8GHz WiFi
and GPS)
10 2.4GHz Antenna (located inside the handle)
11 Start/Stop Video Recording Buon
12 Flight Mode Selecon Switch
13 Aileron/Roll Control (Mode 2 and Mode 1)
14 Elevator/Pitch Control (Mode 2)
Throle/Altude Control (Mode 1)
15 Power Switch
16 Volume and Navigaon Touch-Acvated Buons
(Volume Down/Volume Up/Menu/Home/Back)
17 CGO2+ Pitch Angle/Posion Control Slider
18 SD Card Slot (located under the baery)

3
ST10+ DISPLAY
1 Model Name
2 Frames Per Second for Video Recording Buon
3 Status Informaon
4 Direcon to Home Point
5 Clock/Current Time
6 GPS Status and Number of Satellites for ST10+
7 5.8GHz WiFi Video Link Status
8 ST10+ Baery Charge Level Status Icon
9 Aircra Baery Voltage
10 Altude of Aircra (Above Ground Level)
11 Ground Speed of Aircra
12 Distance of Aircra from Home Point
13 Model Select Menu Buon
14 Flight Sengs Menu Buon
15 System Sengs Menu Buon
16 Latude/Longitude Posion of Aircra
17 Number of Satellites for Aircra
18 GPS Status for Aircra
19 Flight Mode of Aircra
The ST10+ is equipped with a touchscreen display that allows for changing various sengs and viewing real-me telemetry data and streaming video during
flight.
QUICK TIP: Double tap on the screen to increase the size of the video viewing area to full-screen and double tap again to return to the standard size).
WARNING: NEVER aempt to fly TYPHOON via First-Person View (FPV). There’s a slight ‘lag’ in the CGO2+ streaming video downlink to the ST10+, and
as a result the streaming video/FPV should only be used for aligning camera shots and not for flying! Aempng to fly via FPV can result in a crash that will
cause damage to the product, property and/or cause serious injury.
IMPORTANT NOTE: Streaming video from the CGO2+ to the ST10+ and to a separate phone/tablet (or another Yuneec transmier/personal ground
staon) at the same me is NOT recommended as it will result in a very significant lag in the video downlink.
9
10
11
12
19
18
17
16
1415 13
65213 4 87

dot next to the me length of the recording near the upper right-hand
corner on the screen of the ST10+.
TAKING PHOTOS AND RECORDING VIDEO
The ST10+ seamlessly integrates control of the CGO2+ so you can easily
take sll photos and start/stop video recording using the corresponding
buons located on top:
TO TAKE A STILL PHOTO
TO START/STOP RECORDING VIDEO
Press the buon located near the top
right corner of the ST10+. You’ll hear an
audible indicaon from the ST10+ each
me the recording starts/stops. And
while video is recording the LED indica-
tor on the front of the CGO2+ will flash
blue and green, and there will be a red
Press the buon located near the top
le corner of the ST10+. You’ll hear an
audible ‘shuer’ sound from the
ST10+ and the LED indicator on the
front of the CGO2+ will change from
glowing solid green to glowing solid
blue. It will take approximately 5
seconds to capture the photo and before you can take another sll photo.
IMPORTANT NOTE: You cannot take sll photos while recording video.
You MUST stop recording video in order to take sll photos.
IMPORTANT NOTE: You can choose to record video at 48, 50 (PAL) or 60
(NTSC) frames per second by tapping the corresponding buon near the
upper le-hand corner on the screen of the ST10+. And keep in mind that
the delay in the live video stream will be lowest at 48 and 50 as compared
to 60 frames per second.
The slider located on the le side of the ST10+ allows you to set the
pitch/lt posion of the CGO2+ from approximately straight ahead (when
the slider is in the uppermost posion) to approximately straight down
(when the slider is in the lowermost posion). And you can easily set a
posion in between by adjusng the slider accordingly.
QUICK TIP: There’s an adjustable counterbalance located on the rear of
the CGO2+. This counterbalance has been adjusted at the factory to
provide the best balance and performance overall so typically it should
NOT need to be adjusted. However, if you find that the CGO2+ is making
any ‘buzzing’ sounds while powered on, carefully twist the counterbalance
in or out unl the sound stops in order to achieve the best balance, perfor-
mance and photo/video quality.
4

ST10+ AND RECEIVER BINDING
Step 1) Turn on TYPHOON, and
aer the Main LED Status Indicator
begins to flash blue rapidly, li the
back end upward approximately 45°
then back down to ‘level’ two (2)
mes to put the aircra/receiver into
bind mode. The Main LED Status
Indicator will begin to the flash
orange very rapidly when the
aircra/receiver are in bind mode.
2 x 45+°
Step 2) Turn on the ST10+,
and if required tap the
screen (outside of the pop
up status window) to
bypass the RC and WiFi
connecon process.
Step 3) Tap the ‘Model
Select’ buon, and if
required press ‘OK’ to
bypass any pop up
warnings/alerts.
Step 4) Select the exisng
model (for example:
‘TYPHOON’) you would
like to bind to (or create a
‘New Model’), and if
required press ‘OK’ to
bypass any pop up
warnings/alerts.
Step 5) Tap the ‘Flight
Sengs’ buon, and if
required press ‘OK’ to
bypass any pop up
warnings/alerts.
Step 6) Tap the ‘Bind’
buon and select the
‘SR24_XXXXX’ receiver
listed in the column under
‘Model’, then tap ‘OK’ aer
the connecon has been
established.
Step 7) Tap the ‘Back’
buon two (2) mes to
return to the main screen
and the model/receiver
should automacally
connect to the ST10+.
5
SR24_16042

ST10+ AND CGO2+ BINDING
Step 1) Turn on the ST10+, and if required tap the screen (outside of the
pop up status window) to bypass the RC and WiFi connecon process.
Step 5) if required tap the
screen (outside of the pop
up status window) to
bypass the RC and WiFi
connecon process, then
tap the ‘Flight Sengs’
buon and press ‘OK’ to
bypass any pop up
warnings/alerts.
Step 6) Tap the ‘Bind’
buon and select the
‘CGO2_XXXXXX’ camera
listed in the column under
‘Camera’, then enter the
password ‘1234567890’
when prompted and tap
‘OK’ aer the connecon
has b
Step 2) Tap the ‘Model
Select’ buon, and if
required press ‘OK’ to
bypass any pop up
warnings/alerts.
Step 3) Select the exisng
model (for example:
‘TYPHOON’) you would like
to bind to (or create a ‘New
Model’), and if required
press ‘OK’ to bypass any
pop up warnings/alerts.
Step 4) Turn on TYPHOON
and ensure that the CGO2+
is powered on.
6
CGO2_A10008

CERTIFICATION INFORMATION
7ST10+ Quickstart V1.0
FCC STATEMENT:
This equipment has been tested and found to comply with the limits for
Part 15 of the FCC rules. These limits are designed to provide reasonable
protecon against harmful interference in a residenal installaon. This
equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instrucons, may cause
harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a parcu-
lar installaon. If this equipment does cause harmful interference to radio
or television recepon, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
This device complies with part 15 of the FCC rules. Operaon is subject to
the following two condions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operaon.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not
occur in a parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
IC RADIATION EXPOSURE STATEMENT FOR CANADA
This device complies with Industry Canada licence-exempt RSS standard(s).
Operaon is subject to the following two condions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitaon est autorisée aux
deux condions suivantes : (1) l'appareil ne doit pas produire de brouillage,
et (2) l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est suscepble d'en compromere le
fonconnement.
This equipment complies with IC RSS-102 radiaon exposure limit set forth
for an uncontrolled environment.
Cet équipement respecte les limites d’exposion aux rayonnements IC
définies pour un environnement non contrôlé.
