Z&X PRECISE P1 User manual

1/ 13
PRECISE P1 GIMBAL
User Guide (V1.0)
ShenZhen ShengHangDa Technology co., LTD

2/ 13
Contents
I Product introduction·········································3
II The Gimbal Design··········································3
III Mobile phone installation and balance adjustment ·4
IV Operation Modes············································5
VGimbal control panel······································· 6
VI Download and APP installation···························7
VII APP features··················································7
VIII Gimbal charging and Mobile phone charging·········9
IX Upgrading firmware·········································10
XResetting the gimbal········································11
XI Disclaimer··············································· ·····11
XII Precautions and warranty·································11
XIII Specifications·········································· ·····13

3/ 13
I Product introduction
Thank you for using Precise P1 Gimbal. It is a high-end
stabilizer with anti-shake ability and beautiful design while it is also
specially designed for enthusiasts who love using their mobile
phones for photography and videography. ① The creative single
function touch buttons can help you operate more conveniently
and efficiently. ② You can operate the Gimbal handle really easily
with the four different stabilizer modes.③ Smooth slide zooming
allows you to zoom in and out freely.④ One-click seamlessly
stitched panoramas always make you feel amazed. ⑤ Multiple
time-lapse photography will give you a fantastic sense of time. ⑥
Additional smart tracking is a great way to free your hands. ⑦ The
most advanced kinematics control algorithm allows you to shoot a
clear, smooth and highly stable picture. We firmly believe, the
photographic material you take by our Precise P1 Gimbal will be
beyond your imagination. We strongly recommend reading the
User Guide carefully before operating the mobile gimbal.
II The Gimbal Design

4/ 13
III Mobile phone installation and balance adjustment
1.Mobile phone installation: Stretch the clip outward with your
hands and attach the phone. Make sure the phone is close to the
back plate of the clip and the right-hand side of the phone is close
to the support. You can adjust the phone to the horizontal or
vertical shooting mode by the horizontal/vertical shooting screw.
Please see the following diagram:
2. Balance adjustment: Unscrew the balance adjustment screw and
move the expansion arm from side to side until the phone is
balanced, then tighten the balance adjustment screw, Please see
the following diagram:

5/ 13
Caution
1) Please make sure the mobile gimbal is powered off before you install
the mobile phone, adjust the balance or uninstall the mobile phone.
2) If the mobile phone is not balanced, the motor will consume more
power and it will begin getting hot after an extended period of time.
3) Before turning on the power, be sure to tighten the balance
adjustment screw and the horizontal/vertical shooting screw, otherwise
high-frequency vibration may occur.
IV Operation modes
1.The Pan-Following mode.
2.The Locking mode.
3.The Pan & Pitch-Following mode.
4.The Fast response mode: Extreme response in The Pan & Pitch-

6/ 13
Following mode.
5. Manual positioning: In the Pan-Following mode, you can adjust
the pitch angle of the mobile phone manually. In the locking mode,
you can adjust the pitch angle and the panning angle manually.
Please see the following diagram:
6.Flashlight mode/mobile phone horizontal and vertical mode
switch/suspension mode. Please see the following diagram:
V Gimbal control panel

7/ 13
Cautions
1) Buttons 1/2/3/4/5/9/10 as above can be used only when the mobile
gimbal has been connected to the APP.
2) Buttons 6/7/8 as above are mobile gimbal’s functional mode buttons,
they can be used whether the APP has been connected or not.
VI Download and APP installation
Download the APP in the mobile phone’s APP store by searching
APP or scan the QR code as provided. After the installation, turn
on the phone’s Bluetooth and connect the phone with the mobile
gimbal according to the prompt. When the phone has been
connected to the gimbal, you can take photos or videos with it.
VII APP features
(I).APP-the main interface（Bluetooth is disconnected）

8/ 13
(II).APP-the main interface（Bluetooth is connected）
When the Bluetooth is connected, the interface will be as followed.
Smart tracking button
Click the smart tracking, then click the box to select the target.
After that, the mobile gimbal will track the target automatically.
Click the video button to start recording. If you answer a phone
call during the process, the video recording shall be terminated
automatically.
(III).APP-menu interface and the sub-menu introduction
（Bluetooth is connected）

9/ 13
Caution
1) The slow motion function is just for use with the IOS system.
2) When you are taking video in panoramic/static delay/path delay
modes, please put the mobile gimbal on a tripod to keep it stable.
VIII Gimbal charging and mobile phone charging
1.Charge the mobile gimbal with the Type-C cable and the

10 / 13
adapter. The battery will be fully charged in about 3 hours. Please
make sure the battery is full for the first use.
2. Charge the mobile phone through the gimbal.
Please see the following diagram:
Caution
1) Remember, the USB charging port for mobile phone and type-C
charging port for the gimbal cannot be used in inverted.
2) Please turn off the gimbal before charging.
3) Battery care & replacement: If the battery is not cared for properly,
there may be an explosive risk. The battery should only be replaced
with the same specification battery.
IX Upgrading firmware
The gimbal can be upgraded by APP, and it will take
approximately 10 minutes to install. Please check the gimbal and
make sure the battery power is more than 50% before upgrading.
Then connect the gimbal to the APP, If the App prompts that you
can upgrade the firmware, please click accept. Do not exit the APP
upgrading interface during this process, and please pay attention

11 / 13
to the prompt information from the App. After the successful
upgrade, the system status indicator turns to green. Then restart
the gimbal and the App. If the upgrade has failed, please try again.
X Resetting the gimbal
Turn on the gimbal and enter the standby mode, leave it on a
flat, stable surface and wait for 30 seconds, the gimbal will finish
resetting automatically.
XI Disclaimer
1.Before you use the gimbal, please read this user guide carefully
to ensure you can operate it properly. If you operate it and do not
follow the instructions and warnings according to this user guide,
it may damage the gimbal or the surrounding objects. or even
cause injury to you or the people who around you.
2.Once you use this product, you will be deemed to have carefully
read the disclaimer and warnings, understand, confirm and accept
all of the terms and conditions of this statement, and promise to
undertake the full responsibility for the use of this product and the
possible consequences.
XII Precautions and warranty
1. Precautions
1) The gimbal is a high-precision control device, Falling or being
subjected to external force collision may damage the gimbal,

12 / 13
Cause work abnormally.
2) After you turn on the gimbal, make sure the rotation won’t be
impeded by any external force.
3) The gimbal is not waterproof, please keep it away from any
liquids or fluids. A soft dry cloth is recommended for cleaning
the gimbal.
4) Please pay attention to dust and sand when you are using the
gimbal.
2. Warranty
•Warranty period description:
1) Quality problems occur within 15 days from the receipt of the
product, the goods can be exchanged or repaired for free.
2) The warranty period of the product is one year from the date of
sale. During the warranty period, the product offers free
maintenance services which are provided by the company.
•Warranty does not cover the following:
1) Any unauthorized maintenance, misused, impacted, abused,
liquid damaged, accidental damage or modifications.
2) Incorrect use of this product, or tearing up, altering/removing
the label and the anti-counterfeiting label.
3) The warranty does not cover replacement or repair after the
warranty period has expired.

13 / 13
XIII Specifications
Items
Low limit
Standard
High limit
Operating voltage
6.0V
7.4V
8.4V
Operating current
120mA
300mA
2500mA
Charging input voltage
4.7V
5V
5.5V
Charging input current
500mA
800mA
2000mA
Product output voltage
4.9V
5V
5.2V
Product output current
400mA
500mA
600mA
Built-in battery capacity
-
4000mAh
-
Pitch axis freedom degrees
-
240°
-
Roll axis freedom degrees
-
240°
-
Pan axis freedom degrees
-
300°
-
Operating temperature
-10°C
25°C
45°C
Operating hours
-
About 7hrs
-
Fully Charged time
-
About 3hrs
-
Charging environment temperature
-5℃
20°C
40°C
Weight loading
75g
200 g
Expansion arm adjustment range
-
-
10mm
Mobile phone clip range
55mm
-
90mm
