Zanussi SC9412 Assembly instructions

INSTRUCTIONS FOR THE USE & CARE
OF YOUR ZANUSSI COOKER

CONTENTS
Please refer to the sections in this leaflet as appropriate to the features on your particular
model.
Page
Warnings to Users 1
Installation 3
Before Use 3
Manual Control 3
Reversible Main Oven Door 4
The Control Panel 5
The Grill 6
The Main Oven 7
Timer Control 8
Cleaning
Cleaning the hob 15
Cleaning the grill 15
Cleaning the oven 15
Stayclean Liners
Cooking 16
Cleaning 16
Oven Cooking Chart 17
Instructions for Cooking a Complete Meal 18
Guarantee Record 20
Before Calling a Service Engineer Check List 21

WARNINGS - ELECTRIC COOKERS
IMPORTANT:
PLEASE RE AO THE
INSTRUCTION BOOK
BEFORE USING THIS
APPLIANCE
IT IS MOST IMPORTANT THAT THIS
INSTRUCTION BOOK SHOULD BE
RETAINED WITH THE APPLIANCE FOR
FUTURE REFERENCE. SHOULD THE
APPLIANCE BE SOLD OR
TRANSFERRED TO ANOTHER OWNER,
OR SHOULD YOU MOVE HOUSE AND
LEAVE THE APPLIANCE, ALWAYS
ENSURE THAT THE BOOK IS SUPPLIED
WITH THE APPLIANCE IN ORDER THAT
THE NEW OWNER CAN BE
ACQUAINTED WITH THE
FUNCTIONING OF THE APPLIANCE
AND THE RELEVANT WARNINGS.
PLEASE ENSURE THAT YOU HAVE
READ THE WHOLE INSTRUCTION
BOOK BEFORE USING THE APPLIANCE
AND THAT YOU FOLLOW THE
RECOMMENDATIONS GIVEN.
THESE WARNINGS ARE PROVIDED IN
THE INTERESTS OF YOUR SAFETY.
YOU MUST READ THEM CAREFULLY
BEFORE INSTALLING OR USING THE
APPLIANCE.
• This appliance is designed to be
operated by adults only. Children should
not be allowed to tamper with the
controls or play with or near the
product.
• Any installation work must be
undertaken by a qualified electrician
or competent person. The appliance
must be installed according to the
instructions.
• Any electrical work required to install
this appliance should be carried out
by a qualified electrician or competent
person.
• Do not try to move the appliance by
pulling the door handles. Refer to
installation instructions.
• It is dangerous to alter the specifications
or modify the product in any way.
• This product should be serviced by an
authorised Zanussi Network Service
Centre and only genuine approved
spare parts should be used. Details of
servicing arrangements are supplied.
• Under no circumstances should you
attempt to repair the machine yourself.
Repairs carried out by inexperienced
persons may cause injury or more
serious malfunctioning. Refer to your
local Zanussi Network Service Centre.
Always insist on approved spare parts.
Details of servicing arrangements are
supplied.
• Always ensure that all control knobs
are in the ‘off position when not in
use.
• Take great care when heating fats and
oils as they will ignite if they become
too hot.
• For hygiene and safety reasons this
appliance should be kept clean at all
times. A build-up of fats or other
foodstuffs could result in a fire.
• Do not leave utensils containing
foodstuffs e.g. fat or oil in or on the
appliance in case it is inadvertently
switched on.
• This product has been designed for
cooking edible foodstuffs only, and must
not be used for any other purposes.
• Always switch off the isolator switch at
the cooker point and allow the appliance
to cool before any maintenance or
cleaning work is carried out.
• Only clean this appliance in accordance
with the instructions given in this
book.
• This appliance is heavy and care must
be taken when moving it.
• Cookers and hobs become very hot
with use, and retain their heat for a long
period of time after use. You must
1

therefore take care when using the
appliance, supervise children at all
times and do not allow them to touch
the cooker or hob surface or be in the
vicinity of the appliance until it has
cooled after use.
• Ensure that all packaging, both inside
and (where applicable) outside the
appliance is removed before the
appliance is used.
• If you use a saucepan which is smaller
than the heated area on the hob the
handle may become hot. Ensure that
you protect your hand before touching
the handle.
• Never cook directly on the hob surface
without a saucepan/cooking utensil.
Never place plastic or any other material
which may melt on the hob surface or
in the oven itself.
• Always carefully lift saucepans on and
off the hob. This will prevent accidents
caused by spillage and will also keep
cleaning to a minimum. Similarly ensure
saucepans and cooking utensils are
large enough to contain foods and
prevent spillages and boil overs.
• Unstable or misshapen pans are
dangerous and should not be used on
the hotplate as unstable pans may tip
or spill and cause an accident. You must
follow the recommendations for
saucepans given in this book.
• For ceramic hobs - Do not use the
appliance if the ceramic glass is
damaged. Contact your Zanussi
Network Service Centre. Details
supplied.
• Do not place heavy weights on the
ceramic glass.
• Always use oven gloves to remove and
replace the grill pan handle when
grilling. Do not leave the handle in
position when grilling as it will become
hot.
• Always support the grill pan when it is
in the withdrawn or partially withdrawn
position.
• Always ensure that all vents (where
fitted) are left unobstructed to ensure
ventilation of the oven cavity.
• Never line any part of the appliance
with aluminium foil.
• Ensure that the anti-tip oven shelves
are put in place in the correct way. (See
instructions).
• Take care when removing items from
the oven to avoid spillages and burns.
• Always stand back from the appliance
when opening the oven door(s) to allow
any build up of steam or heat to
release.
• Keep feet and legs clear when opening
the drop down oven door (where
applicable). Do not allow it to ‘fall’ open
- support it using the door handle, until
it is fully open.
• Do not place sealed cans or aerosols
inside the oven. They may explode if
they are heated.
• Do not stand on the appliance or on
the open oven doors.
• Do not hang towels or dishcloths from
the appliance or its handles. They are
a safety hazard.
• Do not use this appliance if it is in
contact with water. Similarly never
operate it with wet hands.
2

Installation
Connection to the electricity supply must be
made by a competent electrician, using a
suitable double pole switch. Ensure that the
cooker is standing level. On some models
levelling feet are fitted to accommodate
uneven floors.
The cable connecting the electricity supply
to this appliance must have conductors of
sufficiently high cross sectional area to
prevent overheating and degradation.
Six square millimetres is the minimum
recommended cross sectional area. The
cord should also be routed away from
potentially hot areas.
The appliance must be protected by a
suitably rated fuse or circuit breaker. The
rating of the appliance is given on the rating
plate.
WARNING: THIS APPLIANCE MUST
BEEARTHED
Positioning the Cooker
460 mm (18 in) models-
Allow an air gap of at least 10 mm (%”)
between the cooker and adjacent cabinets,
walls, etc. This will also give extra space
when moving the cooker for cleaning.
Some models have rollers fitted to the rear
to assist when moving the cooker.
550 mm (21 in) models -
The cooker has adjustable feet to assist in
positioning the cooker and is designed to
slot-in between kitchen cabinets.
The space either side need only be
sufficient to allow withdrawal of the cooker
for servicing or cleaning.
It can be fitted with cabinets on one or both
sides as well as in a corner setting. It can
also be situated as a free-standing model.
Adjacent side walls which project above
hob level, should be protected by heat
resistant material, but in any case should
not be nearer to the cooker than 75 mm (3
in). Any overhanging surface or cooker
hood should not be nearer than 685 mm (27
in) above the hob.
Some models have rollers fitted to the rear
to assist when moving the cooker.
To move the cooker, open the oven door
and raise the cooker by lifting the inside top
of the oven. Do not move the cooker by
pulling the top compartment door or door
handle.
Before Use
Record the model and serial numbers on
the back of this leaflet.
Please ensure that any protective film and
all packaging has been removed from the
cooker before switching on.
Allow all elements to run for a short period
to burn off any residue from the surfaces of
the elements. If the odour emitted during
the initial burning off is unpleasant, it may
be necessary to open a window for
ventilation.
During Use
This cooker has passed all the approved
temperature and safety requirements.
However, when using various parts of the
cooker, certain areas may become hot.
Manual Control
If your cooker is fitted with a timer control
and the oven indicator light does not glow
when the oven control dial is turned on, it is
most likely that the cooker is set for
automatic cooking.
To return the cooker to manual operation:
For the Fully Automatic Timer
Control
(with start and stop knobs)
Turn the clock through 12 hours and push
in the STOP knob. Alternatively turn the
START and STOP knobs to the time set on
the clock and allow the knobs to spring out.
Then push in the STOP knob.
Or for the Delay Timer
(with single control knob)
Turn the control knob to manual U -
This appliance complies with the Radio
Interference requirements of EEC
Directive 82/499/EEC.
3

Reversible Main Oven Door
On some models the main oven door of the cooker can be changed from left to right hand
hinging, if required.
This is a reasonably simple operation if carried out in accordance with these instructions.
1 pozi-drive screwdriver and 1 small adjustable spanner are needed.
(i) Open door wide and support whilst removing the two screws from the top L.H. hinge
bracket. Remove hinge bracket and place to one side. Having done so, the door can now
be lifted off the bottom hinge pin (A).
(ii) Remove the eight screws that secure the inner door panel to the outer door panel, and
remove the inner panel being careful not to disturb the insulation material (B).
(iii) The inner door panel can now be turned through 180°. The door latch roller assembly
will then be on the opposite end of the door (L.H.). Replace and secure inner door panel to
outer door panel (C).
(iv) Remove button plugs and hinge bushes (top and bottom) and transfer positions (D).
(v) The upper L.H. hinge bracket (already removed) should now be transfered to the R.H.
lower position (E).
(vi) Remove the door catch striker and plate from R.H. side of chassis (F).
Remove blanking screw from L.H. side of chassis (H).
Replace blanking screws to R.H. side of chassis.
Refit door catch and plate into opposite L.H. position (Do not tighten at this stage).
(vii) The door can now be located onto the R.H. bottom hinge and held in place while the
R.H. top hinge is fitted to the door and then secured to the chassis.
(The R.H. top hinge is the same hinge removed from the bottom L.H.) (G).
(viii) Final adjustment: With the door still closed the door catch adjustment is automatic
and can now be tightened from the side.
Open inner glass door to 90°and remove by lifting up and
out. Release the top hinge from the inside of the oven by
removing the two fixing screws. Remove hinge pin by
loosening the fixing screws, and replace into opposite end
of hinge, re-tightening the screw. Remove blanking screws
from holes in right hand side of oven, and using these holes
4

replace hinge in new position with pin
upright. Repeat procedure for bottom
hinge. Replace blanking screws in left hand
hinge positions in oven. Remove glass
door stop and replace in new position on
opposite side of oven, invert glass door and
rehang in new position.
THE CONTROL PANEL
The control panel knob layout may be as
follows (there are no symbols on the control
panel).
Rear
Hotplates
Grill
© © ©
Front
Hotplates
Oven
Some models have symbols on the control
panel. Here is a guide to identify these:
Back left hotplate (where fitted)
Front left hotplate
oo
o#
o#
oo
©
Front right hotplate
Back right hotplate
Grill
Oven
Automatic timer operation - set
Automatic timer operation - end
THEHOB
Use of the Hob
The hotplates give rapid heat and are fast
boiling. The control switches provide a very
flexible control from slow simmer to fast
boil. The highest number is the hottest
setting. These switches have intermediate
positions.
The numbers do not denote any set
temperature, but after using the hob a few
times no difficulty will be experienced in
selecting an appropriate setting.
The control knobs can be turned in either
direction to vary the heat setting; turn the
control knobs to the highest setting for fast
cooking.
To reduce the heat to cook more slowly or
simmer, choose a lower setting although
this will vary with the size and type of
saucepan, the quantity and type of food
and whether or not a lid is used.
Saucepans
For fastest, most economical cooking, we
recommend pans with flat bases and close
fitting lids. The saucepans should cover the
hotplates as much as possible - up to 225
mm (9”) diameter saucepans on a nominal
180 mm (7”) hotplate. If using larger
diameter pans, only use pans with ground
bases. Damage may occur to the hob if
large preserving pans or fish kettles are
placed across two hotplates. Saucepans
should be lifted onto and off hotplates and
not slid on, since this may in time scratch
the surface finish of the hob.
Never leave the hotplates on for long
periods when not covered with a pan ...
never place a utensil with a skirt on the
hotplate e.g. a bucket ... never use an
asbestos mat, or line the spillage tray with
aluminium foil.
Any guidelines or recommendations given
by the saucepan or cooking utensil
manufacturer should be followed.
5

Special Frying Note:
For safety purposes when deep fat frying,
fill the pan only one-third full of fat or oil. Do
not cover the pan with a lid, and do not
leave the pan unattended. In the unfortu¬
nate event of a fire, leave the pan where it
is and switch off at the electricity supply.
Place a damp cloth or correct fitting lid over
the pan to assist in smothering the flames.
Do not use water on the fire. Leave the
pan to cool for at least 30 minutes.
Do not leave the fat or oil in the frying pan
on the hob to store it, in case the hob is
inadvertently switched on.
To Raise the Hob
On some models the hob is hinged to allow
easy cleaning of the spillage tray.
Lift the hob and secure in a raised position
by means of the support arm, where fitted.
Cleaning of the under side of the hob and
spillage tray can now be carried out. On
models where the hob is not hinged, simply
slide out the spillage tray for cleaning.
The chromium plated hotplate trims may be
removed for cleaning, but the hotplate
spider supports should not be removed.
THE GRILL
Operation of the Grill
To operate the grill turn the grill control
clockwise from the ‘0’ position.
For grilling and toasting, the control should
normally be turned to 5 for initial pre¬
heating of 3 minutes and then adjusted as
necessary. The pre-heating may be
increased to 8-12 minutes when flash
grilling blue, rare or medium steaks.
The grill pan is supplied with a removable
handle. To remove the handle, press the
knob on the handle with the thumb, and
pivot handle upwards.
Reverse this action when replacing handle.
Positioning the Grill Pan
For 460 mm (18 in) wide models - the grill
pan is placed on runners in the grill
compartment. For 550 mm (21 in) wide
models - the grill pan is placed on the shelf,
ensuring that the cut out on the underside
of the handle bracket locates over the front
edge of the shelf.
The runners in the grill compartment side
panels provide alternative grilling positions,
in addition, there is a reversible grid within
the pan.
When toasting bread we suggest that the
top runner position is used with the grid in
either position. This is dependant on the
thickness and freshness of the bread and
the grid position must be adjusted to suit.
Do not line the grill pan or grid with
aluminium foil. It is advisable not to leave
food, i.e. fat or oil in the meat pan, grill pan
or in a fry pan in or on the cooker, in case
the cooker is inadvertently switched on.
The grill door must be left open during
grilling.
The pan may be stored in this compartment
with the handle removed.
6

THE OVEN
Use of the Main Oven
1. The oven door should be opened by
pulling at the top right hand corner and
closed by a gentle push.
2. The oven is supplied with specially
designed non-tip shelves. To ensure that
these can be pulled out to attend to food
without tipping, they should be fitted in the
runners with the straight rods uppermost
and the forms to the back of the oven.
The runners give a variety of positions and
before switching the oven ON arrange the
shelves as required. (A guide to shelf
positions is given in the oven cooking
chart). In addition non-critical dishes can be
cooked on the floor of the oven.
3. Set the oven control dial to the required
temperature. The oven indicator light will
glow until the oven has reached the desired
temperature, and then go out. It will cycle
On and Off periodically during cooking
showing that the temperature is being
maintained.
4. The oven is fitted with side elements.
The top of the oven is the hottest and the
bottom is the coolest, although there is very
little temperature differential between the
top and bottom.
5. Do not line any part of the oven with
aluminium foil.
6. The use of oven thermometers are not
recommended as they do not give accurate
temperature readings and therefore can
give misleading information to the user.
Inner Glass Door
Some models are fitted with an inner glass
door and food can be seen during cooking
without loss of heat. It is advisable to use an
oven cloth when opening the inner glass
door.
7

TIMER CONTROL
(where fitted)
Fully Automatic Timer
(Horizontal version illustrated but timer
may be mounted vertically).
This timer will automatically switch the
oven on and off at the selected ‘start’ and
‘stop’times.
It also includes a clock and minute minder.
Clock
The clock will operate even if the automatic
control is not being used. If the cooker is
switched off at the wall control panel, the
clock will stop. It will start as soon as the
cooker is switched on again. To set the
correct time of day, push in and turn the
clock knob until the hands indicate the right
time.
Minute Minder
The minute minder gives an audible
reminder for any period of cooking up to 60
minutes. It is not part of the automatic
control and is operated by the clock knob.
Automatic Cooking
When the main oven is set on the timer
control, the grill can be operated manually.
Auto-Timer Lights
Where fitted these are situated on the
control panel.
When using the timer control for the first
time it is advisable to let it operate while you
are at home. The indicator lights (see
setting the timer control) can be
checked to show that it is operating
correctly and you will then feel confident to
leave a meal to cook automatically in the
future.
Notes
A. The delay time plus the cooking period
must not exceed 11 Vz hours.
B. Although the automatic timer control
and minute minder operate within limits
which ensure excellent cooking results,
their accuracy is subject to a small variation
in the set cooking period. The electric clock
keeps accurate time.
To set, do not push in, but turn the knob in
the direction of the arrow until the pointer
reaches the desired time period. At the end
of the set period, a continuous buzz will be
heard. To cancel, turn the clock knob to the
‘Off position (indicated by the bell
symbol -Q ).

Setting the Timer Control
Follow these simple steps:
A. TO SETTHE TIMER TO SWITCH 'ON' AND 'OFF' AUTOMATICALLY
OPERATION NOTES
1 . Make sure the electricity supply is
switched ON.
2. Place food in oven.
3. Check that the clock shows the correct
time of day. Adjust if necessary.
Push in and turn clock knob clock-wise or
anti-clockwise as required.
4.
Set the STOP time.
Push in and turn the STOP knob in either
direction until the pointer is at the time you
wish the food to STOP cooking.
5.
Set the START time.
Push in and turn START knob in either
direction until the pointer is at the time you
wish the food to START cooking.
6. Set the oven control to the required Both the oven indicator light and the auto
temperature. end (®) light should be OFF. The auto
set (®[ light will be ON as an indication
that the timer is set and ready to operate.
When the automatic timed period starts, the auto set [ 0 ] light will switch OFF and the oven
thermostat light will cycle on and off as usual.
B. TO SET THE TIMER TO SWITCH 'OFF' ONLY
Follow Points t -3 previously, then:
4. Set the STOP time.
Push in and turn the STOP knob in either
direction until the pointer is at the time you
wish the food to STOP cooking.
5. Override the START time.
Push in the start knob slightly. DO NOT
TURN. Allow to spring out.
6. Set the oven to the required temperature.
9

To Return the Cooker to Manual Operation
Follow the steps below to ensure that after use the oven is returned to manual, otherwise
it will not operate.
At the end of a timed cooking operation
the auto end (g) light will come on.
Ignore the auto set (®) light as this may
be either on or off due to the cycle of the
thermostat.
Turn oven control to off position ‘O’.
The auto end ® light will remain on. If
the auto set {©) light is on at the end of
cooking it will now go out.
Push in STOP knob.
The auto end (®) light will go out.
Turn the oven controls on to check that
the ovens operate manually.
The thermostat lights will come on.
Turn the oven controls OFF.
No indicator lights should operate.
Note: During manual use of the oven the start clock will rotate with the time of day.
To Cancel the Timer
If there is any doubt that the timer is set for automatic cooking and the oven will not switch
on manually:
1. Turn START knob to the time of day,
indicated on the clock.
The knob will pop out and the oven
indicator light will come ON.
2. Turn the STOP knob to the time of day,
The knob will pop out and the oven
indicated on the clock.
indicator light will go OFF.
The auto end gj light will operate.
3.
Push in STOP knob lightly.
DONOTTURN.
4.
The oven should now be operating
manually.
The oven indicator light should be ON.
5.
Turn oven control OFF.
10

Delay Timer (where fitted)
The delay timer, which is extremely easy to
operate, offers the facility of a maximum of
12 hours delay with a preset 2 hour cooking
period. This means that the cooker will
automatically switch on after the chosen
delay time, cook for 2 hours and then switch
off. If a period of either less than 2 hours
or more than 2 hours is required, the
cooker must be switched off manually (for
less than 2 hours cook) or returned to the
manual position V!V after the 2 hour
cook period, (for more than 2 hours cook).
Examples
A meal which requires
2 hour cook time
Cook Temperatures : 190°C
Time Meal Required : 6 pm
Cook Time : 2hrs
Time Oven to Switch On : 4 pm
Time Now : 7 am
Delay Required : 9 hr
1. Set timer control to 9 hours on the
delay period time display.
2. Set the oven control dial to 190°C.
(The timer control will switch the oven on at
4 pm after the 9 hours delay period and
switch off at 6 pm).
3. Turn the oven control off and return the
timer control to manual.
A meal which requires
MORE than 2 hour
cooktime
Cook Temperatures : 150°C
Time Meal Required : 1 pm
Cook Time : 3hrs
Time Oven to Switch On : 10 am
Time Now : 6 am
Delay Required : 4 hrs
1. Set timer control to 4 hours on the
delay period time display.
2. Set the oven control dial to 150°C.
(The timer control will switch the oven on at
10 am after the 4 hour delay period).
3. At 12 o’clock the timer control will
switch the oven off. Therefore the timer
control must be returned to the manual
position to allow the meal to carry on
cooking for the final hour. Alternatively,
reset the cook period on the timer control to
1 hour.
4. At the end of the 3 hours cook time, the
oven control dial should be switched off and
the timer control returned to the manual
position.
A meal which requires
LESS than 2 hour
cook time
Cook Temperature : 200°C
Time Meal Required : 8 pm
Cook Time : IVahrs
Time Oven to Switch On : 6.30 pm
Time Now : 2 pm
Delay Required : 4Vz hrs
1. Set timer control to 4Vfe hours on the
delay period time display.
2. Set the oven control dial to 200°C.
(The timer control will switch the oven on at
6.30 pm after the 4V2 hours delay period).
3. At 8 pm the oven control dial should be
switched off and the timer control returned
to the manual position. (If the oven is not
switched off as given in Point 3, the timer
control will automatically switch off at 8.30
pm after the 2 hou r preset cooking period).
11

A meal which requires to
switch off only, i.e. no
delay
Cook Temperature : 210°C
Time Meal Required : 2 pm
Cook Time : IVfehrs
Time Oven to Switch On : Now
Time Now : 12.30
Delay Required : None
1. Set timer control to 1 Vz hours on the
preset 2 hour cook time.
2. Set the oven control dial to 210°C.
(The oven will now be switched on. At 2 pm
the timer control will switch the oven off).
3. Turn the oven control off and return the
timer control to manual.
When a delay/cook time has been set,
slight vibration may be felt through the
knob. This is perfectly normal and is
caused by the timer mechanism working.
12

TIMER CONTROL
(where fitted)
Fully Automatic Timer
A. Inner section of control knob.
B. Outer section of control knob.
1. Clock second hand.
2. Hand for minute minder.
3. Off position for minute minder.
4. Start time indicator line.
5. Stop time indicator.
6. Cook time.
7. Area indicating completion of
automatic programme. When only this area
is visible, return cooker to manual (see
page 14).
8. Dot indicator
This timer will automatically switch the
oven on and off at the selected cook period
and off at the selected ‘stop’ time.
It also includes a clock and minute minder.
Clock
The clock will operate even if the automatic
control is not being used. If the cooker is
switched off at the wall control panel, the
clock will stop. It will start as soon as the
cooker is switched on again. To set the
correct time of day, push in and turn the
inner section, of the knob (A) in either
direction until the hands indicate the right
time.
Minute Minder
The minute minder gives an audible
reminder for any period of cooking up to 55
minutes. It is not part of the automatic
control and is operated by the inner section
of the knob (A).
To set, do not push in, but turn the knob in
either direction until the pointer reaches the
desired time period. At the end of the set
period, a continuous audible signal will be
heard. To cancel, turn the inner section of
the knob (A) to the ‘Off’ position (indicated
by the bell symbol ).
Automatic Cooking
Either the main and/or second oven can be
set on the timer control. However, both
ovens can only be used on the timer control
when the same delay period and cooking
time is required for each oven. When the
timer control has been set for one oven only
it is not possible to use the other oven for
manual cooking.
When the main oven is set on the timer
control, the grill can be operated manually.
When using the timer control for the first
time it is advisable to let it operate while you
are at home. You wHI then feel confident to
leave a meal to cook automatically in the
future.
Notes
A. Maximum cooking duration is 3V2 hours
B. The delay time plus the cooking period
must not exceed 15 hours.
C. Although the automatic timer control
and minute minder operate within limits
which ensure excellent cooking results,
their accuracy is subject to a small variation
in the set cooking period. The electric clock
keeps accurate time.
13

Setting the Timer Control
Follow these simple steps:
A. TO SET THE TIMER TO SWITCH 'ON' AND 'OFF' AUTOMATICALLY
OPERATION NOTES
1. M a ke sure the electricity supply is
switched on.
2. P l a ce food in oven.
3. C h eck that the clock shows the correct Push in and turn the inner section of the
time of day. Adjust if necessary. knob (A) clockwise or anticlockwise as
required.
4. Set the stop time. Turn the outer section of the knob (B)
(This must be set first) clockwise towards $zf until the stop
time indicator (5) and dot indicator are at
the time you wish the food to stop
cooking.
5. Set the start time. Turn the outer section of the knob (B)
anticlockwise towards to bring the
start time indicator line (4) to the ti me at
which cooking is to start (The 111 area
shows the cook time).
6. S et the oven control to the required IllliS The oven indicator light should be off.
temperature.
When the automatic timed period starts, the oven thermostat light will cycle on and off as
usual and the [ilffffj area will gradually disappear giving an indication of the cook time
remaining.
B. TO SETTHE TIMER TO SWITCH 'OFF' ONLY
Follow points 1 -4 previously, then:
5. To start cooking immediately. Turn the outer section of the knob (B)
anticlockwise until the start time indicator
line is exactly in line with the hour hand.
6. Set the oven temperature control to
the required temperature, if the oven is
not already on.
14

CLEANING
THE ELECTRICITY SUPPLY MUST BE
SWITCHED OFF BEFORE CLEANING
In the interests of your own safety, please
DO NOT attempt to remove the timer, or
any part of the timer (such as the control
knobs for cleaning). Removal of the timer or
any parts of the timer should be undertaken
by an authorised technician.
All exterior surfaces are hard wearing,
easily cleaned and impervious to all normal
heat and spillage encountered during
cooking. Vitreous enamel can be chipped
by a hard blow and reasonable care should
be exercised. The exterior surfaces
including the oven doors should be cleaned
using a little liquid detergent in hot water,
and polished with a soft cloth.
Cleaners which contain bleach should not
be used as they may dull the surface. Harsh
abrasives may also affect the finish and
should not be used. When removing parts
of the cooker for cleaning, we recommend
that they are not subjected to thermal
shock, i.e. do not plunge a very hot grill pan
or meat pan into warm or cold water.
Note:
Before using any proprietary oven cleaner,
ensure that it is suitable for application on
polished surfaces e.g. chromium, anodized
aluminium, stainless steel, vitreous
enamel. Certain cleaners may have an
adverse effect.
Cleaning the Hob
The chromium plated hotplate trims may be
removed for cleaning, but the hotplate
spider supports should not be removed.
Spillage will pass through the open spiral
radiant hotplate elements and drain away
to the coolest part of the spillage tray below.
Remove obstinate soilage with a soap
impregnated steel wool pad. Non-abrasive
cleaners may be used on the hob to remove
obstinate marks.
Cleaning the Grill
It is essential to keep the underside of the
removable vitreous enamel grill deflector
absolutely clean. After grilling, thorough
cleaning of the surface with a soap
impregnated steel wool pad is advised.
The deflector can be removed by opening
the grill compartment door without lifting
the hob. Clean the grill pan in a similar
manner.
When replacing the grill deflector make
sure it is in position immediately above the
grill element, with the front lip down.
Cleaning the Oven
If ‘STAY CLEAN’ panels have been fitted to
this oven, instructions for cleaning these
panels are given under ‘Care of Stay-
Clean’.
Vitreous enamel may be cleaned using
normal oven cleaners.
Oven shelves if heavily soiled will wipe
clean if first soaked in hot soapy water.
Inner Glass Door
(where fitted)
To assist cleaning, the glass door may be
removed from its hinges. The door should
be opened 90 degrees to enable it to be
lifted off easily. This allows the door to be
completely soaked to remove obstinate
soilage, alternatively clean with a warm
soapy cloth. Rough abrasives should be
avoided as these will scratch the surface.
Note:
If aerosol cleaners are used on any parts of
the cooker the manufacturers’ instructions
must be followed, and it is recommended
that all parts are well rinsed afterwards.
AEROSOL CLEANERS MUST NOT BE
USED ON ‘STAY-CLEAN’ LINERS, AND
MUST NOT BE ALLOWED TO COME
INTO CONTACT WITH THE ELEMENTS
AS THIS MAY CAUSE DAMAGE.
15

STAY-CLEAN LINERS
(where fitted)
Care of Stay-Clean
Cleaning of the ‘Stay-Clean’ surface is
initiated by an inclusion of special oxides in
the enamel; these are activated when the
temperature of the oven is raised, and
aided by oxygen, result in the soilage i.e.
food splatter and grease being destroyed.
The linings clean themselves during
normal roasting and baking.
As cleaning may be improved by exposure
to a higher temperature, it may be
necessary to run the oven at maximum
temperature for an hour or two per week.
Manual cleaning is not advisable on ‘Stay-
Clean’ panels. Do not use soap
impregnated steel wool pads, aerosol
cleaners, or any abrasive cleaners as these
may damage the surface of the panels.
Slight discolouration may occur in time,
together with polishing of the surface finish
by the oven shelves but this will not affect
the cleaning properties of the panels.
In order to ensure that the liners retain their
Stay-Clean properties and give years of
excellent service, it may be worthwhile
understanding the following points:-
Cooking
To minimise oven soilage
1. Cook at the recommended temper¬
atures. Higher temperatures during
roasting will increase soilage. Try cooking
at lower temperatures for an increased
length of time, you will save energy and
often the joint is more tender.
2. Use minimal, if any, extra cooking oil or
fat when roasting meat; potatoes only
require brushing with fat before cooking.
Extra fat in the oven during roasting will
increase splashing and soilage.
3. It is not necessary to add water to the
meat tin when roasting. The water and the
fat juices from the joint create excessive
splattering during cooking - even at normal
temperatures as well as causing con¬
densation.
4. Covering joints during cooking will also
prevent splashings onto the interior panels;
removing the covering for the last 20-30
minutes will allow extra browning if
required. Some large joints and turkeys
especially will benefit by this method of
cooking, allowing the joint to cook through
before the outside is over-browned.
5. Do use (where supplied) the trivet in the
roasting tin. During roasting, the fat from
the joint will be contained beneath the trivet
and therefore prevent it from splattering
onto the Stay-Clean liners.
Cleaning
1. The linings will clean themselves during
normal roasting and baking. It is important
to ensure that a build up of soilage does not
occur as excessive soilage can prevent the
Stay-Clean properties of the catalytic
enamel from working.
2. After roasting, always check the Stay-
Clean liners for soilage. If baking between
roasts, this will assist in the cleaning of the
liners.
3. As cleaning is improved by exposure to
a higher temperature, it may be necessary
to run the oven at maximum temperature
for an hour or two per week or after each
roast.
4. The panels which are directly next to the
oven elements reach higher temperatures
and clean more readily. It may be
necessary to expose the roof or back panel,
where fitted, to a radiant grill element to
assist in burning off excessive soilage. This
is not normally necessary but is worth
remembering if required.
16

OVEN COOKING CHART
The oven temperatures are intended as a guide only. It may be necessary to increase or
decrease the temperature by 10°C to suit individual preferences and requirements.
Note:
Shelf positions are counted from the bottom of the oven.
MAIN OVEN
FOOD SHELF POSITIONS
COOKING
TEMPERATURE °C
Biscuits 4 and 6 190-200
Bread
1 and 5 220-230
Casseroles
3
150
Cakes: Small and Queen 2 and 6 190-200
Sponges
2 and 6
190
Madeira 3
180
Rich Fruit
3
160
Christmas
2
150
Meringues
2
100
Fish 3 180-190
Fruit Pies and Crumbles
4
220
Milk Puddings
Pastry: Choux
Shortcrust
Flaky
Puff
2
Depending on dish
160
Plate Tarts 2 and 6
200
Scones 2 and 6 240
Roasting: Meat and Poultry 2 180-200
17

INSTRUCTIONS FOR COOKING A COMPLETE MEAL IN
THE MAIN OVEN
Many people today like to cook meat at comparatively low temperatures. When these lower
temperatures are used the joint is often more tender; also there is very little splashing of fat
onto the oven interior during cooking. When a ‘Full Meal’ including a joint, roast potatoes,
fruit pie and Yorkshire Pudding is required, cooking times may vary slightly according to the
thickness of the joint and how ‘well done’ one likes the meat and potatoes etc. Slight
temperature adjustment may be necessary. We hope this will prove to be a useful guide to
your new cooker.
Roast Beef, Roast Potatoes, Yorkshire Pudding, Apple Pie
Preparation
Beef
Potatoes
Yorkshire
Pudding
Apple Pie
Cooking
Pre-heat oven to 220°C
Arrange Beef, Potatoes and Apple Pie in
the oven as follows:
1 V 2 kg (3 lb) Arrange in the roasting tin.
600g (1V 2 lb) Brush with melted fat or oil, sprinkle with salt and
arrange around joint.
250 ml (V 2 pt) Mix together 10Og (4 oz) p flour and a pinch of salt,
pouring batter Gradually mix in a beaten egg and 250 ml (V 2 pt)
milk until smooth.
300g(12oz) Shortcrust pastry;
1kg (2 lb) Prepared fruit.
Sugar to taste.
Place fruit and sugar in 1 litre (2 pt) oval pie
dish and cover the fruit with rolled out pastry.
Beef and Potatoes Shelf position 1
Apple Pie Shelf position 4
Cook at 220°C for approximately 50 minutes.
Remove pie and raise temperature to 230°C.
Yorkshire Pudding: Heat 25g (loz) lard in a 23 cm (9 in) square tin for approximately 5
minutes on shelf position 4. Pour in batter. Cook for 35 minutes approximately.
TOTAL COOKING TIME APPROXIMATELY: 1 hour 30 minutes
These instructions are a guide only and should be altered to suit individual requirements. If
the joint is preferred very well cooked we suggest allowing an extra 15-30 minutes cooking
time after removing the pie and before cooking the Yorkshire Pudding.
18
