Zanussi ZTE278 User manual

Instruction booklet
Condenser Dryer
ZTE278

2
The following symbols are used in this user manual:
Important information concerning your personal safety and information on
how to avoid damaging the appliance.
General information and tips
Environmental information
Important safety information. . . . . . . .3
Product description. . . . . . . . . . . . . . .6
Bedienfeld. . . . . . .. . . . . . . .. . . . . . . .7
Drying programmes. . . . . . . . . . . . . . 9
Drying hints. . . . . . . . . . . . . . . . . . . . 12
Use. . . . . . . . . . . . . . . . . . . . . . . . . . 14
Care and cleaning. . . . . . . . . . . . . . . 19
Something not working?. . . . . . . . . . 22
Technical data. . . . . . . . . .. . . . . . . . .24
Consumption values. . . . . . . . . . . . . 25
Environment concerns. . . . . . . . . . . .26
Adjusting level of conductivity. . . . . . 27
Installation. . . . . . . . . . . . . . . . . . . . . 28
Contents
Dear Customer
Thank you for choosing one of our high-quality products. With this appliance you will
experience the perfect combination of functional design and cutting edge
technology. Convince yourself that our appliances are engineered to deliver the best
performance and control - indeed we are setting the highest standards of
excellence. In addition to this you find environmental and energy saving aspects as
an integral part of our products. To ensure optimal and regular performance of your
appliance please read this instruction manual carefully. It will enable you to navigate
all processes perfectly and most efficiently. To refer to this manual any time you
need to, we recommend you to keep it in a safe place. And please pass it to any
future owner of the appliance. We wish you much joy with your new appliance.

3
Important safety information
In the interest of your safety and to ensure the correct use, before installing
and first using the appliance, read this user manual carefully, including its
hints and warnings. To avoid unnecessary mistakes and accidents, it is
important to ensure that all people using the appliance are thoroughly
familiar with its operation and safety features. Save these instructions and
make sure that they remain with the appliance if it is moved or sold, so that
everyone using it through its life will be properly informed on appliance use
and safety.
General safety
• It is dangerous to alter the
specifications or attempt to modify this
product in any way.
• This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for
their safety.
• Make sure that small pets do not
climb into the drum. To avoid this,
please check into the drum before
using.
• Any objects such as coins, safety
pins, nails, screws, stones or any
other hard, sharp material can cause
extensive damage and must not be
placed into the machine.
• In order to avoid danger of fires
caused by excessive drying, do not
use appliance to dry the following
items: Cushions, quilts and the like
(these items accumulate heat).
• Items such as foam rubber (latex
foam), shower caps, waterproof
textiles, rubber backed articles and
clothes or pillows fitted with foam
rubber pads should not be dried in the
tumble dryer.
• Always unplug the appliance after
use, clean and maintenance.
• Under no circumstances should you
attempt to repair the machine
yourself. Repairs carried out by
inexperienced persons may cause
injury or serious malfunctioning.
Contact your local Service Centre.
Always insist on genuine spare parts.
• Items that have been soiled with
substances such as cooking oil
acetone, petrol, kerosene, spot
removers, turpentine, waxes and wax
removers should be washed in hot
water with an extra amount of
detergent before being dried in the
tumble dryer.
• Danger of explosion: Never tumble
dry items that have been in contact
with inflammable solvents (petrol,
methylated spirits, dry cleaning fluid
and the like). As these substance are
volatile, they could cause an
explosion. Only tumble dry items
washed with water.
• Risk of fire: items that have been
spotted or soaked with vegetable or
cooking oil constitute a fire hazard

4
and should not be placed in the
tumble dryer.
• If you have washed your laundry with
stain remover you must execute an
extra rinse cycle before loading your
tumble dryer.
• Please make sure that no gas lighters
or matches have accidentally been left
in pockets of garments to be loaded
into appliance
WARNING!
Never stop a tumble dry before
the end of the drying cycle unless
all items are
quickly removed and spread out
so that the heat is dissipated.
RISK OF FIRE!
Installation
• This appliance is heavy. Care should
be taken when moving it.
• When unpacking the appliance, check
that it is not damaged. If in doubt, do
not use it and contact the Service
Centre.
• All packing and transit bolts must be
removed before use. Serious damage
can occur to the product and to
property if this is not adhered to. See
relevant section in the user manual.
• The final part of a tumble dryer cycle
occurs without heat ( cool down cycle
) to ensure that the items are left at a
temperature that ensures that items
will not be damaged.
• Any electrical work required to install
this appliance should be carried out
by a qualified electrician or competent
person.
• Care must be taken to ensure that the
appliance does not stand on the
electrical supply cable.
• If the machine is situated on a
carpeted floor, please adjust the feet
in order to allow air to circulate freely.
• After having installed the appliance,
check that it is not pressing or
standing on its electrical supply cable.
• If the tumble dryer is placed on top of
a washing machine, it is compulsory
touse the stacking kit (optional
accessory).
Use
• This appliance is designed for
domestic use. It must not be used for
purposes other than those for which it
was designed.
• Only wash fabrics which are designed
to be machine dried. Follow the
instructions on each garment label.
• Do not dry unwashed items in the
tumble dryer.
• Do not overload the appliance. See
the relevant section in the user
manual.
• Clothes which are dripping wet should
not be placed in the dryer.
• Garments which have been in contact
with volatile petroleum products
should not be machine dried. If
volatile cleaning fluids are used, care
should be taken to ensure that the
fluid is removed from the garment
before placing in the machine.
• Never pull the power supply cable to
remove the plug from the socket;
always take hold of the plug itself.
• Never use the tumble dryer if the
power supply cable, the control panel,
the working surface or the base are
damaged so that the inside of the
tumble dryer is accessible.

5
• Fabric softeners, or similar products
should be used as specified by the
fabric softener instructions.
Child safety
• This machine is not intended for use
by young children or infirm persons
without supervision.
• Children should be supervised to
ensure that they do not play with the
appliance.
• The packaging components (e.g.
plastic film, polystyrene) can be
dangerous to children - danger of
suffocation! Keep them out of
children’s reach.
• Keep all detergents in a safe place
out of children’s reach.
• Make sure that children or pets do not
climb into the drum.

6
Product description
1.Control panel
2. Fluff filters
3. Rating Plate
4. Condenser unit
5. Water reservoir
6.Adjustable feet

7
Delicate button Pressing this button allows drying to be performed
at a lower temperature, for delicate items.
Anticrease button
Programme selector dial
1
2
3
Quick button By depressing this button the drying time is reduced
in all programmes from cotton (Katoen) and synthetics
(Synthetica) sections
4
Buzzer button By depressing button the acoustic signal is switched
off
5
Time button
Select the required programme run time, settable
with an interval of 10 min, from 20 min. up to 120
minutes.
6
Bedienfeld
Allows you to select electronically controlled or time
controlled drying. Turn the dial to the required programme
or time.
The drying cycle is automatically followed by a anti-crease
phase which lasts around 90 minutes.
2
10
10
8
1 4 75 6 39
Lage temp.
Lange anti-kreuk
Kort
Zoemer
Tijd

8
Indicator lights
Start/Pause button Press this button to start the dryer after having
selected the programme and any required options.
Delay start button
9
8
10
Display
The display shows the following information:
•duration of selected programme
•delayed start
•end of programme
•incorrect option selection
•alarm code
7
With the DELAY button, you can delay the start of a programme
by between 30 minutes and a maximum of 20 hours
• “Waterhouder” - full tank
llight
• “Condensor” - condenser light
• “Filter” - filter light
Start/Pauze
Startuitstel

9
Programme Type of
laundry Options Description of programme
Extra droog
(extra dry)
Cotton
and linen
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Kort (quick dry)
• Lange anti-kreuk (long
anticrease)
• Startuitstel (delay start)
Drying thick or multi-
layered textiles,
e.g. terry towelling items
Sterkdroog
(strong dry)
Cotton
and linen
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Kort (quick dry)
• Lange anti-kreuk (long
anticrease)
• Startuitstel (delay start)
Drying thick textiles, e.g.
terry towelling items,
towels.
Kastdroog
(cupboard dry)
Cotton
and linen
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Kort (quick dry)
• Lange anti-kreuk (long
anticrease)
• Startuitstel (delay start)
Drying textiles of even
thicknesses,
e.g. terry towelling items,
knitted items, towels.
Strijkdroog+
( damp) Cotton
and linen
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Kort (quick dry)
• Lange anti-kreuk (long
anticrease)
• Startuitstel (delay start)
For thin textiles which are
still to be
ironed, e.g. knitted items,
cotton shirts.
Strijkdroog
(
iron dry) Cotton
and linen
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Kort (quick dry)
• Lange anti-kreuk (long
anticrease)
• Startuitstel (delay start)
For cotton or linen
laundry which are still to
be put through a
machine, e.g. bedding,
table linen.
Drying programmes

10
Programme Type of
laundry Options Description of programme
Extra droog
(extra dry)
Synthetics
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Lange anti-kreuk (long anticrease)
• Kort
• Startuitstel (delay start)
Drying thick or multi-
layered textiles,
e.g. pullovers,
bedding, table linen.
Kastdroog
(cupboard dry)
Synthetics
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Lange anti-kreuk (long anticrease)
• Kort
• Startuitstel (delay start)
For thin textiles which
are not ironed,
e.g. easy care shirts,
table linen, baby’s
clothes, socks,
underwear.
Strijkdroog
(iron dry) Synthetics
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Lange anti-kreuk (long anticrease)
• Kort
• Startuitstel (delay start)
For thin textiles which
are still to be ironed,
e.g. knitted items,
cotton shirts.
Special-
programme
Mix
Synthetics
Cotton
Dryness
• Lage temp. (low temp.) A1
• Zoemer (buzzer)
• Lange anti-kreuk (long anticrease)
• Startuitstel (delay start)
Special programme
for cotton and easy
care, which can drying
together in the same
time.
Tijd
(time)
Synthetics
Cotton
Dryness
• Lage temp. (low temp.)
• Tijd ( time)
• Zoemer (buzzer)
• Lange anti-kreuk (long anticrease)
• Startuitstel (delay start)
Drying thick or multi-
layered textiles, e.g.
terry towelling items.
For drying individual
items of laundry or for
small volumes of less
than 1kg.

11
Programme Type of
laundry Options Description of programme
Special-
programme
Jeans
Cotton
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Lange anti-kreuk (long
anticrease)
• Startuitstel (delay start)
Special programme for
leisure clothing, such as
jeans, sweat-shirts, etc., of
different material
thicknesses (e.g. at the
cuffs and seams).
Anti-kreuk
(anticrease)
Synthetics
Dryness
• Lage temp. (low temp.)
• Startuitstel (delay start)
• Zoemer (buzzer)
• Lange anti-kreuk (long
anticrease)
Special programme with
anti-crease mechanism for
easy care textiles such
shirts and blouses; for
minimum ironing effort. The
result depends on the type
and quality of textiles. (The
loading volume
corresponds to approx. 4 to
5 shirts.)
Recommendation: Place
textiles in the dryer straight
after spinning. Once dried,
immediately remove
textiles and place on
clothes hanger.
Baby Cotton
Dryness
• Lage temp. (low temp.)
• Zoemer (buzzer)
• Lange anti-kreuk (long
anticrease)
• Startuitstel (delay start)
Is a special programme
for jumpers to
be dried “ready to wear”
Luchten
(cooling) Synthetics
Cotton
• Zoemer (buzzer)
For refreshing or gently
cleaning textiles with
commercially available dry
cleaning sets.
1A- automatic

12
Before loading the laundry
Never tumble dry the following:
Particularly delicate items such as
net curtains, woollen, silk, fabrics with
metal trim, nylon tights, bulky
materials such as anoraks, blankets,
eiderdowns, sleeping bags, feather
quilts and any items containing
rubber foam or materials similar to
rubber foam.
• Always follow the instructions on
garment labels:
may be tumble dried
normal drying (high
temperature)
delicate drying (low
temperature)
do not tumble dry
• Close pillowcases and covers with
fasteners to prevent small laundry
items getting tangled inside them.
Close press studs, zips and hooks
and tie belts and apron strings.
• Sort laundry according to type and
degree of drying required.
• Do not over-dry laundry, this avoids
creasing and saves energy.
• Avoid drying dark clothes with light
coloured fluffy items such as towels
as they could attract the fluff.
• The laundry must be thoroughly spun
before tumble drying.
•Easy-care items, too, e.g. shirts,
should be briefly pre-spun before
drying (depending on crease
resistance approx. 30 seconds or
using the special brief spin
programme of your washing
machine).
• Knitted textiles (knitted underwear)
may shrink a little during drying.
Please do not overdry items of this
type. It is advisable to allow for
shrinkage when choosing the size of
new purchases.
• You can also put starched items into
your dryer. However, to achieve the
desired starched effect, choose the
programme “iron dry”. To remove any
starch residues, wipe out the internal
drum after drying with a moist cloth
and then rub it dry.
• To avoid a static charge when drying
is completed, use either a fabric
softener when you are washing the
laundry or a fabric conditioner
specifically for tumble dryers.
• Remove the laundry when the dryer
has finished drying.
• If individual items are still damp after
drying, set a brief post-drying time,
but at least 30 minutes. This will be
necessary particularly for
multilayered items (e.g. collars,
pockets, etc.).
Make sure that no metal objects are
left in the laundry (e.g. hair clips,
safety pins, pins).
Button up pillowcases, close zip
fasteners, hooks and poppers. Tie any
belts or long tapes.
Remove persistent stains before
washing.
Rub particularly soiled areas with a
special detergent or detergent paste.
Treat curtains with special care. Remove
Drying hints

13
hooks or tie them up in a bag or net.
Maximum loads
Recommended loads are indicated in the
programme charts.
General rules:
Cotton, linen: drum full but not too
tightly packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum
no more than one third full.
Try to load to the maximum capacity
of the machine as small loads are
uneconomical.
Laundry weights
The following weights are indicative:
1200 gbathrobe 100 gnapkin 700 gquilt cover 500 gsheet 200 gpillow case 250 gtablecloth 200 gtowelling towel 100 gtea cloth 200 gnight dress 100 gladies’ briefs 600 gman’s work shirt 200 gman’s shirt 500 gman’s pyjamas 100 gblouse 100 gmen’s underpants

14
Daily Use
Load the laundry
Connect the
appliance.
Open the door
(see picture).
Place the laundry
in the drum, one
item at a time,
shaking them out
as much as
possible.
Select the
required
programme
Turn the
programme
selector dial to the
required
programme.The
light “Start/Pauze”
starts to flash.
The selector dial
is divided into
following sections:
Cottons
Synthetics
Special
Allows you to
select
electronically
controlled or time
controlled drying.
Turn the dial to
the required
programme or
time.
Electronically
controlled drying
(automatic)
The appliance
runs these
programmes with
the help of probes
which detect the
degree of
dampness of the
laundry. Simply
select the
programme
according to the
type of laundry
and degree of
drying required.
The selector dial
can be turned
either clockwise
or anticlockwise.
At the end of the
programme the
selector dial must
be turned to
position “O”, to
switch the
machine off.
Attention!
If you turn the
programme
selector dial to
another
programme when
the machine is
working, the lights
of the programme
progress display
start to flash. The
machine will not
perform the new
selected
programme.
Programme
Option buttons
Depending on the
programme,
different functions
can be combined.
These must be
selected after
choosing the
desired
programme and
before depressing
the “Start/Pauze”
button. When
these buttons are
pressed, the
corresponding
pilot lights come
on. When they are
pressed again,
the pilot lights go
out.
Select “Lage
temp”
Pressing this
button allows
drying to be
performed at a
lower
temperature, for
delicate items.
The corresponding
pilot light comes on.
This option can also
be used for time
controlled drying.
“Lage temp.” is only
suitable for use
with loads of up to
3kg!
Select the
“Zoemer”
When the drying
Use
9
P1108

15
cycle has finished,
an intermittent
audible signal will
sound.
By depressing this
button the
acoustic signal is
switched off in the
following cases:
• when selecting
the programme
• when depressing
the buttons
• when the
programme
selector dial is
turned to another
position during
the programme
or when you
depress an
option button
during the cycle
•at the end of the
programme.
The
corresponding
light comes on
Select the “Kort”
By depressing this
button the drying
time is reduced in
all programmes
from cotton and
synthetic sections.
The
corresponding
pilot light comes
on.
This option
cannot be
selected with
“Lage temp.”
function.
Select the
“Lange anti-
kreuk” button
The drying cycle
is automatically
followed by a anti-
crease phase
which lasts
around 90
minutes.
Select the “Tijd”
This option can be
used for WOOL
programmes.
Select the
required
programme run
time, settable with
an interval of 10
min, from 20 min.
up to 120
minutes.
Press the button
as many times as
necessary until
the required
programme
running time is
shown in the
display
Select the
“Start/Pauze”
Press this button
to start the dryer
after having
selected the
programme and
the options. The
relevant light will
stop flashing. If
the programme
selector dial is
turned to another
position, when the
machine is
running, the
buzzer will sound
and the
programme phase
indicator lights will
flash. The drum
turns alternately in
both directions
during drying.
All drying
programmes end
with a 10 minute
cooling phase
(light Cooling is
on). You may
remove the
laundry after this
phase.
The display will
show the symbol
Long Anticrease,
and lights “Filter”
and
“Waterhouder”
illuminate and the
buzzer sounds
If the door of the
appliance or the
small door at the
bottom is opened
while the
programme is
running, this
button must be

16
pressed again
after closing the
door in order to
restart the
programme from
the point at which
it was interrupted.
This button must
be depressed also
after a power
failure and after
having reinserted
the water
reservoir, if it has
been emptied in
the middle of a
programme after
lighting up of light
“Waterhouder”.
In both cases the
light of the
“Start/Pauze”
button flashes to
remind you that
the start button
needs to be
pressed again.
Select the
“Startuitstel”
With the
“Startuitstel”
button, you can
delay the start of a
programme by
between 30
minutes (30' and a
maximum of 20
hours (20H).
1.Select the
programme
2.Press the
“Startuitstel”
button as many
times as
necessary until
the required start
delay appears
on the multi
display, e.g. 12H
if the programme
is to be started in
12 hours.
If 20H is displayed
and you press
the button again,
the time delay
will be cancelled.
The display will
show 0' and then
the duration of
the selected
programme.
3.To activate the
delay timer,
press the
“Start/Pauze”
button. The
amount of time
remaining until
the programme
is set to start is
continuously
displayed (e.g.
12H, 11H, 10H,
… 30' e+tc).
If you wish to add
some laundry
while the machine
is performing the
countdown, after
having done so
and having closed
the door, press
“Start/Pauze”
again, in order to
allow the machine
to complete the
remaining
countdown time.
Display
The display
shows the
following
information:
Duration of
selected
programme
After you have
selected the
programme, its
duration (in hours
and minutes)
appears on the
display. It is
calculated
automatically on
the basis of the
maximum load
accepted for each
type of fabric and
of the required
degree of drying.
When the
programme starts,
the remaining
time is displayed
every 5 minutes.
Delayed start
If you have
selected a delay
time by means of
the relevant
button, the display
shows it for 3
seconds; then it
shows the
duration of the
previously
selected
programme. The
countdown is
displayed every
30 minutes until it
displays “90
minutes” and then
hour by hour.
End of
programme
A flashing zero
indicates the end
of the programme
and it is displayed
after the
“anticreasing”
phase.
3
1.20

17
Incorrect option
selection
If you select an
option that is not
compatible with
the programme
you have
selected, the
display shows Err
(error).
This code will
reappear during
the execution of
the programme if
you press one of
the option buttons
or turn the
programme
selector.
Alarm code
In case of a
functional
anomaly, the
display shows an
alarm code (e.g.
E21).
Indicator lights
These lights indicate
the following
functions:
“Water reservoir
full” light
“WATERHOUDER
”
This light comes
on at the end of
the programme to
remind you that the
water reservoir must
be emptied out. If
this light illuminates
during a programme
this means that the
water reservoir is full.
The buzzer sounds,
the programme
stops, the light of the
Start/Pause button
flashes.
“Filter cleaning”
light “FILTER”
It comes on every
80 cycles to remind
you that the
condenser must be
cleaned.
“Condenser
cleaning” light
“CONDENSOR”
This light
illuminates at the
end of the
programme to
remind you that
the filters must be
cleaned.
At the end of the
programme
All drying
programmes end
with a 10 minute
cooling phase.
You may remove
the laundry after
this phase. The
lights “FILTER”
and
“WATERHOUDER
”, and illuminate.
The display
shows a static
zero.
If the laundry is
not removed at
the end of the
cycle, the dryer
performs an anti-
creasing phase
(duration: 30
minutes
maximum). If you
do not remove the
laundry, the dryer
will stop
automatically at
the end of the
anti-creasing
phase.
Lights FILTER
and
WATERHOUDER
remain lit and the
buzzer sounds for
2 minutes.
If you do not intend
to carry out
another wash,
close the water
tap. Leave the
door open to
prevent the
formation of
mildew and
unpleasant smells.
Turn the
programme
selector dial to “O”
to switch the
machine off.
Remove the
laundry from the
drum and carefully
check that the
drum is empty. The
appliance is
switched off.
Remove the
laundry.
If you open and
then close the
door before
turning the
selector dial to “O”
all the lights
corresponding to
the phases
making up the
performed
programme come
on.
After each use
•Clean the filters.
•Empty the water
reservoir.
Important!
If the drying
programme has to
be stopped before
it reaches the
end, we
recommend that
you turn the
programme
selector dial to
position Cooling
“LUCHTEN” and
wait until the end
of this cooling
phase before
removing the
laundry. This will
avoid a build-up of
heat inside the
appliance.To do
this first turn the
E.27
0

18
dial to “Off” and
then to Cooling
“LUCHTEN” and
depress Start
button.
Modifying the
programme
To change a
programme which
is running, first
cancel it by
turning the
programme
selector dial to
“O”. Select the
new programme
and press the
Start button .
Child safety
device
The child lock can
be set to prevent
a programme
being accidentally
started or a
programme in
operation being
accidentally
changed. The
child safety device
locks all buttons
and the
programme knob.
The child safety
device can be
activated or
deactivated by
holding down the
“Lage temp.” (low
temp.) and “Lange
anti-kreuk” (long
anti-crease)
buttons
simultaneously for
5 seconds.
• Before
programme is
started:
Appliance cannot
be used
• After programme
is started:
Programme in
operation cannot
be changed
The symbol
appears in the
display to indicate
that the child
safety device is
activated.
The child safety
device is not
deactivated once
the programme
comes to an end.
If you want to set
a new
programme, you
must first
deactivate the
child safety
device.

19
Important!
You must DISCONNECT the appliance
from the electricity supply, before you
can carry out any cleaning or
maintenance work.
External cleaning
Use only soap and water and then dry
thoroughly.
Important: do not use methylated
spirit, diluents or similar products..
Cleaning the door
Clean periodically the interior part of
the door to remove any fluff from the
seals around the filter. Accurate
cleaning ensures correct drying.
Cleaning the filters
Your dryer will only function well if the
filters are clean.
The filters collect all the fluff which
accumulates during drying and they
must therefore be cleaned at the end
of each programme, before removing
the laundry, with a damp cloth. The
light “Filter” is on to remind you this
operation.
The filter in the inner door must be
removed for cleaning.
Do not be alarmed by the amount of fluff. It is
not due to excessive wear caused by the
dryer. All fabric loses fluff when drying
but it goes un-noticed in the air. In a
tumble dryer it simply collects in the
filter. After a while, a withish patina due
to detergent residue on laundry forms
on the filters. When this occurs, clean
the filters with warm water using a
brush. Remove the filter in the door
opening as per picture (it can be
positioned with the tooth facing to the
left or to the right).
AUTOREVERSE
kg 5
kg 2,5
800 / 900
70' - 90'
35' - 50'
1000 / 1200
65' - 85'
30' - 45'
800 / 900
80' - 100'
55' - 70'
1000 / 1200
75' - 95'
50' - 65'
650
50' - 60'
30' - 35'
kg 2,5
kg 1
AUTOREVERSE
kg 5
kg 2,5
800 / 900
70' - 90'
35' - 50'
1000 / 1200
65' - 85'
30' - 45'
800 / 900
80' - 100'
55' - 70'
1000 / 1200
75' - 95'
50' - 65'
650
50' - 60'
30' - 35'
kg 2,5
kg 1
110
AUTOREVERSE
kg 5
kg 2,5
800 / 900
70' - 90'
35' - 50'
1000 / 1200
65' - 85'
30' - 45'
800 / 900
80' - 100'
55' - 70'
1000 / 1200
75' - 95'
50' - 65'
650
50' - 60'
30' - 35'
kg 2,5
kg 1
P1150
Care and cleaning

20
Important!
Do not use the appliance without filters.
Cleaning the condenser unit
Clean the condenser when light
“Condensor” comes on.
The condenser is situated at the lower part
of the cabinet behind a small door. To open
the door, push the catch as per picture.
During the drying cycle or at the end, it is normal
for water to be present on the surface of the
condenser insertion.
To pull out the condenser, first turn the two
red stops downwards and then remove the
condenser unit holding it at the handle.
„
Clean it with a brush and rinse it under
theshower if necessary. Also clean the
outside, removing all fluff. Clean the
rubber seal round the condenser cabinet
and in the inner part of the small door
with a damp cloth.
Important
Do not use pointed objects or utensils to
clean the spaces between the plates, as
this could damage the condenser and
make it permeable. Re-fit the condenser,
turn the red stops upwards and close the
door.
Important!
Do not use this appliance if the
condenser has not been fitted.
Emptying the water reservoir
Water extracted from the laundry
condenses inside the machine and is
collected in a reservoir. The reservoir
must be emptied after each drying
cycle to ensure efficient operation when
the machine is next used. The pilot light
0639
