Zanussi ZES3921 User manual

HR Upute za uporabu 2
EN User manual 10
EL Οδηγίες Χρήσης 18
PT Manual de instruções 27
ES Manual de instrucciones 35
Ploča za kuhanje
Hob
Εστίες
Placa
Placa de cocción
ZES3921

Sadržaj
Sigurnosne upute _ _ _ _ _ _ _ _ _ _ _ _ _ 2
Postavljanje _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3
Opis proizvoda _ _ _ _ _ _ _ _ _ _ _ _ _ _ 6
Rad uređaja _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 6
Korisni savjeti i preporuke _ _ _ _ _ _ _ _ _ 6
Čišćenje i održavanje _ _ _ _ _ _ _ _ _ _ _ 7
Rješavanje problema _ _ _ _ _ _ _ _ _ _ _ 8
Tehnički podaci _ _ _ _ _ _ _ _ _ _ _ _ _ _ 9
Briga za okoliš _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 9
Zadržava se pravo na izmjene.
Sigurnosne upute
Prije postavljanja i korištenja uređaja,
pozorno pročitajte ove upute. To je u in-
teresu vaše sigurnosti i osiguravanja isprav-
nog rukovanja. Čuvajte ove upute i uvjerite se
da se one nalaze uz uređaj ako ga selite ili
prodajete. Sve osobe koje koriste uređaj
moraju biti u potpunosti upoznate s
rukovanjem i sigurnosnim svojstvima.
Opća sigurnost
Upozorenje Osobe (uključujući djecu)
sa smanjenim fizičkim, osjetnim,
mentalnim sposobnostima ili bez iskustva i
znanja ne smiju koristiti ovaj uređaj. Njih
treba nadzirati ili uputiti u rukovanje uređajem
osoba odgovorna za njihovu sigurnost.
Uređaj nije predviđen za rad s vanjskim
tajmerom ili odvojenim sustavom
daljinskog upravljanja.
Roditeljska blokada
•Ovimuređajem smiju se služiti samo
odrasle osobe. Djeca moraju biti pod nad-
zorom kako bi se izbjeglo igranje s ure-
đajem.
• Svu ambalažu čuvajte izvan dohvata djece.
Postoji opasnost od gušenja ili tjelesne
ozljede.
• Držite djecu dalje od uređaj za vrijeme i
nakon rada, sve dok se uređaj ne ohladi.
Sigurnost tijekom rada
• Prije prve uporabe iz uređaja uklonite svu
ambalažu, naljepnice i prevlake.
• Polja za kuhanje postavite na "isključeno"
nakon svake uporabe.
• Opasnost od opeklina! Nemojte stavljati
jedaći pribor ili poklopce na površinu za
kuhanje jer se mogu zagrijati.
Upozorenje Opasnost od požara!
Pregrijane masti i ulja vrlo se brzo
zapale.
Ispravno rukovanje
• Uvijek nadzirite uređaj dok radi.
• Koristite uređaj samo za pripremu jela u
kućanstvu!
• Nemojte koristiti uređaj kao radnu površinu
ili za čuvanje stvari.
• Nemojte stavljati ni držati vrlo zapaljive
tekućine i materijale ili predmete koji se
mogu rastopiti (od plastike ili aluminija) na
uređaj ili blizu njega.
• Pazite pri spajanju uređaja na utičnice u
blizini. Ne dopustite da električni kabeli do-
diruju uređaj ili vruće posuđe. Ne dopustite
da se električni kabeli zapletu.
Kako spriječiti oštećivanje uređaja
• Ako predmeti ili posuđe padnu na
staklokeramiku, površina se može oštetiti.
•Posuđe za kuhanje od lijevanog željeza,
lijevanog aluminija ili s oštećenim dnom
prilikom pomicanja može ogrepsti
staklokeramiku.
• Ne dopustite da se posuđe isprazni
kuhanjem, tako ćete spriječiti oštećivanje
posuđa i staklokeramike.
• Polja za kuhanje ne koristite s praznim po-
suđem ili bez posuđa za kuhanje.
• Nemojte pokrivati nijedan dio uređaja
aluminijskom folijom.
2
www.zanussi.com

• Ako je površina napukla, odspojite na-
pajanja kako biste spriječili električni udar.
Odlaganje uređaja
• Kako biste spriječili opasnost od tjelesnih
ozljeda ili oštećenja
– Isključite uređaj iz mrežnog napajanja.
– Odrežite kabel napajanja na mjestu gdje
se spaja s uređajem i bacite ga.
– Obratite se ovlaštenom lokalnom do-
bavljaču radi odlaganja uređaja.
Postavljanje
Postavljanje
Upozorenje Pažljivo pročitajte i slijedite
upute. Postoji opasnost od ozljeda ili
oštećenja uređaja.
• Provjerite da uređaj nije oštećen tijekom
transporta. Ne priključujte oštećeni uređaj.
Po potrebi, obratite se dobavljaču.
•Postavljanje i spajanje uređaja na
električnu mrežu smije izvršiti samo
kvalificirano osoblje.
• Ugradbene uređaje koristite samo nakon
postavljanja u odgovarajuće ormare za
ugradnju i radne ploče koje su u skladu s
normama.
• Ne mijenjajte specifikacije i nemojte modifi-
cirati ovaj proizvod. Postoji opasnost od
ozljeda ili oštećenja uređaja.
• U potpunosti se pridržavajte zakona,
odredbi, smjernica i normi koje su na snazi
u zemlji u kojoj koristite uređaj (sigurnosni
propisi, propisi o recikliranju, pravila o
električnoj sigurnosti, itd.).
• Održavajte minimalni razmak od drugih
uređaja i kuhinjskih elemenata.
• Postavite zaštitu od strujnog udara, na
primjer: ladice postavite samo ukoliko je
ispod uređaja ugrađena zaštitna ploča.
•Akojepričvrsni nosačpored priključnog
bloka, uvijek pazite da priključni kabel ne
dođe u kontakt s rubom nosača.
•Oštećenja od vlage na izrezanim površi-
nama radne ploče spriječite prikladnim brt-
vilom!
•Uređaj zabrtvite na radnu površinu priklad-
nim brtvilom tako da između njih nema
praznog prostora.
• Spriječite oštećenje dna uređaja uslijed pa-
re i vlage, npr. iz perilice posuđa ili pećni-
ce.
•Uređaj ne postavljajte pored vrata niti ispod
prozora. Prilikom otvaranja vrata ili prozora
vruće posuđe možete gurnuti s ploče za
kuhanje.
•Prije obavljanja bilo kakvog održavanja
ili čišćenja uređaj isključite iz električne
mreže.
Upozorenje Opasnost od ozljeda
uzrokovanih električnom strujom.
Pažljivo se pridržavajte uputa za spajanje na
električnu mrežu.
• Stezaljka električnog priključka je pod na-
ponom.
• Isključite napon na stezaljki električnog
priključka.
• Ispravnom ugradnjom osigurajte zaštitu od
strujnog udara.
• Labavi i neispravni spojevi utikača i utični-
ca mogu dovesti do pregrijavanja stezaljke.
• Kvalificirani električar mora pravilno ugradi-
ti stezne priključke.
• Koristite stezaljku za uklanjanje napetosti
na kabelu.
• Koristite odgovarajući priključni električni
kabel i oštećeni kabel zamijenite kabelom
odgovarajućeg tipa. Obratite se svom
lokalnom servisnom centru.
Električna instalacija uređaja mora omoguća-
vati njegovo iskapčanje iz električne mreže i
imati na svim polovima širinu otvora kontakta
od najmanje 3 mm. Morate imati odgova-
rajuće uređaje za izolaciju: automatske
sklopke, osigurači (osigurače na uvrtanje iz-
vaditi iz držača), prekidači i sklopnici struje
zemnog spoja.
3
www.zanussi.com

Proizvođačnije odgovoran za bilo kakve
ozljede osoba i kućnih ljubimaca ili ošte-
ćenja imovine uzrokovane nepoštivanjem
ovih zahtjeva.
Spajanje na električnu mrežu
•Uređaj uzemljite u skladu sa sigurnosnim
propisima.
• Nazivni napon i vrsta napajanja na nazivnoj
pločici trebaju biti u skladu s naponom i
snagom lokalne niskonaponske mreže.
•Ovajuređaj opremljen je kabelom na-
pajanja. Kabel treba imati odgovarajući
utikačkoji može izdržati opterećenje nave-
deno na nazivnoj pločici uređaja. Utikačse
treba utaknuti u odgovarajuću utičnicu.
• Sve električne komponente mora postaviti i
mijenjati tehničar servisne službe ili kvalifi-
cirano servisno osoblje.
• Uvijek koristite pravilno ugrađenu utičnicu
sa zaštitom od strujnog udara.
• Provjerite može li se utičnici lako pristupiti
nakon postavljanja.
•Nepovlačite kabel napajanja kako biste
utikačizvukli iz utičnice. Uvijek uhvatite i
povucite utikač.
•Uređaj se ne smije priključivati produžnim
kabelom, adapterom ili višestrukom
priključnicom (opasnost od požara).
Provjerite da je priključak uzemljenja u
skladu sa standardom i važećim propisima.
• Kabel napajanja mora biti postavljen tako
da ne dira nijedan vrući dio.
•Uređaj priključite na napajanje pomoću na-
prave koja omogućuje isključivanje uređaja
s napajanja na svim polovima s otvorom
kontakta od najmanje 3 mm, kao što su, na
primjer, automatske sklopke, prekidači ili
osigurači uzemljenja.
• Niti jedan dio kabela napajanja ne smije
doseći temperaturu od 90 °C. Plava žica
nule mora se priključiti na stezaljku ozna-
čenu slovom "N". Smeđa (ili crna) žica faze
(priključena na stezaljku označenu slovom
"L") uvijek mora biti spojena na fazu pod
naponom.
Zamjena električnog kabela
Za zamjenu kabela za priključivanje koristite
samo H05V2V2-F T90 ili odgovarajuću vrstu.
Provjerite je li presjek kabela u skladu s na-
ponom i radnom temperaturom. Žuto-zelena
žica uzemljenja mora biti otprilike 2 cm dulja
od smeđe (ili crne) žice faze.
Sklop
40-50 mm
55 mm
30 mm
min. 650 mm 490 mm
min. 100 mm
270 mm
Ako je potrebno postaviti nekoliko ploča od
30 cm jednu pored druge u isti otvor, u na-
šem servisnom centru možete nabaviti
komplet za sastavljanje koji sadrži bočni no-
sači dodatne brtve. Odgovarajuće upute za
postavljanje nalaze se u kompletu.
==
270+1mm
600mm
R 5mm
490+1mm
4
www.zanussi.com

Mogućnosti ugradnje
Na kuhinjski element s vratima
Ploča koja se postavlja ispod ploče za
kuhanje mora se lako uklanjati i omogućavati
jednostavan pristup u slučaju intervencije ser-
visa.
min 20 mm
(max 150 mm)
30 mm
60 mm
b
a
a) Ploča koja se može ukloniti
b) Mjesto za priključke
Kuhinjski element s pećnicom
Dimenzije otvora ploče za kuhanje moraju
odgovarati prikazu i kuhinjski element mora
biti opremljen otvorima za provjetravanje
kako bi omogućio neprekidan dovod zraka.
Spajanje na električnu mrežu ploče za
kuhanje i pećnice mora se postaviti odvojeno
radi sigurnosnih razloga i radi omogućavanja
jednostavnog uklanjanja pećnice iz
kuhinjskog elementa.
50 cm2
360 cm2180 cm2
120 cm2
5
www.zanussi.com

Opis proizvoda
Izgled površine za kuhanje
1
2
3
4
180
mm
145
mm
1Stražnja zona kuhanja 1700 W
2Prednja zona kuhanja 1200 W
3Indikator napajanja
4Regulatori
Upravljački gumbi električnih zona
kuhanja
Simbol Funkcija
0položaj „OFF“
(Isključeno)
Simbol Funkcija
1minimalna toplina
6maksimalna toplina
Rad uređaja
Za uključivanje i povećavanje stupnja topline
okrenite regulator u smjeru suprotno od
kazaljke na satu. Za smanjenje stupnja
topline okrenite regulator u smjeru kazaljke
na satu. Za isključivanje okrenite regulator na
0.
Indikatorsko svjetlo aktivira se kada se uključi
bilo koje od polja i ostaje uključeno dok se
polja ne isključe.
Prije prve uporabe
Na svaku zonu kuhanja stavite posudu s vo-
dom, podesite na maksimalan položaj i pusti-
te uređaj da radi 10 minuta. Ovaj postupak
treba obaviti zbog spaljivanja ostataka u ure-
đaju. Nakon toga pustite da uređaj 20 minuta
radi u maksimalnom položaju. Tijekom tog
perioda može se osjetiti neugodan miris i
pojaviti dim. To je sasvim normalno. Osigu-
rajte dovoljan protok zraka.
Kad zona kuhanja radi, neko vrijeme se
čuje zvuk. To je tipično za sve zone
kuhanja staklokeramičke ploče i ne znači da
uređaj ne radi ispravno.
Korisni savjeti i preporuke
Posuđe za kuhanje
• Dno posuđa za kuhanje treba biti što
je moguće deblje i ravnije.
•Posuđe od čeličnog emajla ili s dnom
od aluminija ili bakra može uzrokovati
promjenu boje na staklokeramičkoj po-
vršini.
Ušteda energije
• Ako je moguće, posuđe uvijek poklopi-
te poklopcem.
•Posuđe za kuhanje stavite na polje za
kuhanje prije uključivanja.
6
www.zanussi.com

• Polja za kuhanje isključite prije za-
vršetka kuhanja kako biste iskoristili
preostalu toplinu.
• Dno posude i polje za kuhanje trebali
bi biti jednake veličine.
Koristite posude i tave s dnom koje od-
govara dimenzijama zona kuhanja.
Zona kuhanja Promjeri posuđa
Prednja maks. 145 mm
Stražnja maks. 180 mm
Primjeri načina kuhanja
Postavka
topline:
Koristite za:
1 Držanje na toplom
Postavka
topline:
Koristite za:
2Lagano vrenje
3Vrenje
4Pečenje / završno pečenje
5Priprema za ključanje
6Priprema za ključanje / brzo pr-
ženje / prženje
Podaci o akrilamidima
Važno rema najnovijim znanstvenim
spoznajama, ako hrana puno potamni
(naročito ona koja sadrži škrob), akrilamidi
mogu dovesti zdravlje u opasnost. Stoga
preporučujemo da kuhate na nižim
temperaturama i da ne tamnite previše hranu.
Čišćenje i održavanje
Očistite uređaj nakon svake uporabe.
Uvijek koristite posuđe za kuhanje s čistim
dnom.
Upozorenje Prije bilo kakvog održavanja
ili čišćenja morate isključiti ploču za
kuhanje iz napajanja.
Ploču za kuhanje je najbolje očistiti dok
je još topla jer se tada prljavština može
lakše ukloniti nego kad se ohladi.
Upozorenje Oštra i gruba sredstva za
čišćenje oštećuju uređaj.
Radi vlastite sigurnosti nemojte čistiti ovaj
uređaj aparatima na paru ili pod visokim
tlakom.
Ogrebotine ili tamne mrlje na
staklokeramici ne utječu na rad uređaja.
Za uklanjanje prljavštine:
1. – Odmah uklonite:plastiku koja se topi,
plastičnu foliju i hranu koja sadrži še-
ćer. U suprotnom, prljavština može uz-
rokovati oštećenje uređaja. Koristite
posebni strugačza staklo. Stavite stru-
gačna staklenu površinu pod oštrim
kutom i pomičite oštricom po površini.
–Uklonite nakon što je uređaj do-
voljno hladan:krugove od vapnenca,
krugove od vode, mrlje od masnoće,
metalnosjajne promjene boje. Koristite
posebno sredstvo za čišćenje
staklokeramike ili nehrđajućeg čelika.
2. Očistite uređaj vlažnom krpom i s malo
sredstva za čišćenje.
3. Na kraju, prebrišite uređaj čistom
krpom.
7
www.zanussi.com

Rješavanje problema
Problem Mogući uzrok i rješenje
Uređaj ne radi. • Provjerite osiguraču električnoj instalaciji kućanstva u kutiji s osi-
guračima. Ako osigurači stalno izbacuju, obratite se ovlaštenom
električaru.
Zona kuhanja se ne grije. • Provjerite je li uređaj priključen na napajanje i je li električno na-
pajanje uključeno.
• Provjerite jeste li okrenuli odgovarajući regulator.
• Provjerite osiguraču električnoj instalaciji kućanstva u kutiji s osi-
guračima. Ako osigurači stalno izbacuju, obratite se ovlaštenom
električaru.
Učinkovitost ploče za kuhanje
nije zadovoljavajuća.
• Provjerite je li ploča za kuhanje čista i suha.
• Provjerite odgovara li veličina posuđa veličini zone kuhanja.
• Provjerite je li dno posuđa ravno.
• Provjerite odgovara li stupanj kuhanja vrsti kuhanja.
Ako postoji pogreška, najprije pokušajte sami
pronaći rješenje. Ako ne možete sami pronaći
rješenje problema, obratite se dobavljaču ili
najbližoj servisnoj službi.
Ako ste nepravilno rukovali uređajem ili
postavljanje nije izvršio registrirani tehni-
čar, rad servisera službe za kupce ili do-
bavljača neće biti besplatan, čak ni za
vrijeme jamstvenog roka.
Naljepnice u vrećici s priborom
Samoljepive naljepnice nalijepite kao što je
prikazano dolje:
MOD.
PROD.NO.
SER.NO
DATA
MOD.
PROD.NO.
SER.NO
DATA
MODELMODEL
MOD.
PROD.NO.
SER.NO.
03 IT
MADE IN ITALY
TYPE
230V-50Hz
IP20
0049
1 2 3
1Nalijepite na jamstveni list i pošaljite ovaj
dio
2Nalijepite na jamstvenii list i zadržite ovaj
dio
3Nalijepite na knjižicu s uputama
Ovi podaci su potrebni za brzu i učinkovi-
tu pomoć. Ovi podaci dostupni su na ispo-
ručenoj nazivnoj pločici.
• Opis modela .................
• Broj proizvoda (PNC) .................
• Serijski broj (S.N.) .................
8
www.zanussi.com

Koristite samo originalne rezervne dijelove.
Na raspolaganju su u servisnom centru i trgo-
vinama s originalnim rezervnim dijelovima.
Tehnički podaci
Dimenzije ploče za kuhanje
Širina: 290 mm
Duljina: 510 mm
Dimenzije otvora za ploču
Širina: 270 mm
Duljina: 490 mm
Nazivne vrijednosti vruće ploče
Stražnja zona kuhanja
180 mm
1,7 kW
Prednja zona kuhanja
145 mm
1,2 kW
Ukupna nazivna snaga 2,9 kW
Električno napajanje 230 V ~ 50 Hz
Briga za okoliš
Simbol na proizvodu ili na njegovoj
ambalaži označuje da se s tim proizvodom ne
smije postupiti kao s otpadom iz
domaćinstva. Umjesto toga treba biti uručen
prikladnim sabirnim točkama za recikliranje
elektroničkih i električkih aparata. Ispravnim
odvoženjem ovog proizvoda spriječit ćete
potencijalne negativne posljedice na okoliš i
zdravlje ljudi, koje bi inače mogli ugroziti
neodgovarajućim rukovanjem otpada ovog
proizvoda. Za detaljnije informacije o
recikliranju ovog proizvoda molimo Vas da
kontaktirate Vaš lokalni gradski ured, uslugu
za odvoženje otpada iz domaćinstva ili
trgovinu u kojoj ste kupili proizvod.
Pakiranje
Materijali za pakiranje su prihvatljivi za
okoliš i mogu se reciklirati. Plastične
komponente posebno su označene:
>PE<,>PS< itd. Bacite materijale za pakiranje
u kućanski otpad na odgovarajućem
lokalnom odlagalištu.
9
www.zanussi.com

Contents
Safety information _ _ _ _ _ _ _ _ _ _ _ _ _ _ 10
Installation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 11
Product description _ _ _ _ _ _ _ _ _ _ _ _ _ 14
Operation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 14
Helpful hints and tips _ _ _ _ _ _ _ _ _ _ _ _ 15
Care and cleaning _ _ _ _ _ _ _ _ _ _ _ _ _ 15
What to do if… _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 16
Technical data _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 17
Environment concerns _ _ _ _ _ _ _ _ _ _ _ 17
Subject to change without notice.
Safety information
For your safety and correct operation of
the appliance, read this manual carefully
before installation and use. Always keep these
instructions with the appliance even if you move
or sell it. Users must fully know the operation
and safety features of the appliance.
General safety
Warning! Persons (including children)
with reduced physical sensory, mental
capabilities or lack of experience and
knowledge must not use the appliance. They
must have supervision or instruction for the
operation of the appliance by a person
responsible for their safety.
The appliance is not intended to be oper-
ated with external timer or separated re-
mote-control system.
Child safety
• Only adults can use this appliance. Children
must get supervision to make sure that they
do not play with the appliance.
• Keep all packaging away from children.
There is a risk of suffocation and physical in-
jury.
• Keep children away from the appliance dur-
ing and after the operation, until the appli-
ance is cold.
Safety during operation
• Remove all packaging, stickers and layers
from the appliance before the first use.
• Set the cooking zones to "off" after each use.
• Risk of burns! Do not put cutlery or saucepan
lids on the cooking surface, as they can be-
come hot.
Warning! Fire danger! Overheated fats
and oils can ignite very quickly.
Correct operation
• Always monitor the appliance during opera-
tion.
• Only use the appliance for domestic cooking
tasks!
• Do not use the appliance as a work or a stor-
age surface.
• Do not put or keep very flammable liquids
and materials, or fusible objects (made of
plastic or aluminium) on or near the appli-
ance.
• Be careful when you connect the appliance
to the near sockets. Do not let electricity
bonds touch the appliance or hot cookware.
Do not let electricity bonds tangle.
How to prevent a damage to the
appliance
• If the objects or cookware fall on the glass
ceramic, the surface can be damaged.
• Cookware made of cast iron, cast aluminium
or with damaged bottoms can scratch the
glass ceramic if you move them on the sur-
face.
• Do not let cookware boil dry to prevent the
damage to cookware and glass ceramics.
• Do not use the cooking zones with empty
cookware or without cookware.
• Do not cover any part of the appliance with
aluminium foil.
• If there is a crack on the surface, disconnect
power supply to prevent the electric shock.
10
www.zanussi.com

Disposal of the appliance
• To prevent the risk of physical injury or dam-
age
– Disconnect the appliance from the power
supply.
– Cut off the mains cable where it connects
with the appliance and discard it.
– Speak to your local authorised facilities for
disposal of your appliance.
Installation
Installation
Warning! Read and follow the
instructions carefully. There is a risk of
injury or damage to the appliance.
• Make sure that the appliance is not damaged
because of transportation. Do not connect a
damaged appliance. If it is necessary, speak
to the supplier.
•Installation and connection of the ap-
pliance to the power supply must only
be done by qualified personnel.
• Only use built-in appliances after you assem-
ble the appliance into correct built-in units
and work surfaces that obey the standards.
• Do not change the specifications or modify
this product. There is a risk of injury or dam-
age to the appliance.
• Fully obey the laws, ordinances, directives
and standards in force in the country where
you use the appliance (safety regulations, re-
cycling regulations, electrical safety rules
etc.).
• Keep the minimum distances to other appli-
ances and units.
• Install anti-shock protection, for example in-
stall the drawers only with a protective panel
directly below the appliance.
• If the fixing bracket is near to the terminal
block, always make sure the connection ca-
ble does not come in contact with the edge
of the bracket.
• Prevent damage of the cut surfaces of the
worktop against moisture with a correct seal-
ant!
• Seal the appliance to the worktop with no
space left with a correct sealant.
• Prevent damage of the bottom of the appli-
ance from steam and moisture, e.g. from a
dishwasher or oven.
• Do not install the appliance adjacent to
doors and below windows. Hot cookware
can be hit off the hob when you open doors
or windows.
•Disconnect the appliance from the elec-
trical supply, before you do mainte-
nance work or cleaning.
Warning! Risk of injury from electrical
current. Carefully obey the instructions for
electrical connections.
• The electrical mains terminal is live.
• Make the electrical mains terminal free of
voltage.
• Install correctly to give anti-shock protection.
• Loose and incorrect mains plug and socket
connections can make the terminal become
too hot.
• A qualified electrician must install the clamp-
ing connections correctly.
• Use a strain relief clamp on cable.
• Use the correct mains connection cable and
replace the damaged mains cable with the
proper cable type. Speak to your local Serv-
ice Centre.
The appliance must have the electrical installa-
tion which lets you disconnect the appliance
from the mains at all poles with a contact open-
ing width of minimum 3 mm. You must have
correct isolation devices: line protecting cut-
outs, fuses (screw type fuses removed from the
holder), ground leakage trips and contactors.
The manufacturer is not responsible for
any injury to persons and pets or damage
to property caused by failure to obey
these requirements.
11
www.zanussi.com

Warning! The appliance must be earthed.
Electrical connection
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug (if
applicable).
• The appliance must not be connected with
an extension cable, an adapter or a multiple
socket. There is a risk of fire.
• Do not let the power cable to heat up to a
temperature of more than 90° C. The cable
should be guided by means of clamps fixed
to the side of the cabinet, in order to avoid
any contact with the equipment beneath the
cooktop.
• Make sure that there is access to the mains
plug after the installation.
Electrical Requirements
Permanent electrical installation must agree
with the latest I.E.E. Regulations and local Elec-
tricity Board regulations. For your own safety
the installation must be done by a qualified
electrician (e.g. your local Electricity Board, or a
contractor who is on the roll of the National In-
spection Council for Electrical Installation Con-
tracting [NICEIC]).
The manufacturer refuses to be held re-
sponsible, if these safety measures are not
abided by.
Supply connections:
This hob has to be connected to 230 — 240 V
( 50 Hz) electricity supply.
The hob has a terminal block which is
marked as follows:
•L— Live terminal
•N— Neutral terminal
•or E— Earth terminal
Before carrying out the connection, make sure:
1. The limiter valve and the electrical system
can take the appliance load (see the rating
plate)
2. The supply system is equipped with an effi-
cient earth connection in compliance with
the current standards and regulations
3. The outlet or omnipolar switch used for
connection is easily accessible with the
appliance installed.
The appliance is supplied with a 3 core flexible
power cable requiring a 3 amp plug. You must
purchase and install the plug.
The wires in the cord are coloured as follows:
Green and yellow - Earth
Blue - Neutral
Brown - Live
Replacement of the connection cable
1. Connect the green and yellow (earth) wire
to the terminal in the plug which is marked
with the letter 'E', or the earth symbol ,
or coloured green and yellow.
2. Connect the blue (neutral) wire to the ter-
minal in the plug which is marked with the
letter 'N' or coloured blue.
3. Connect the brown (live) wire to the termi-
nal in the plug which is marked with the let-
ter 'L' and is always connected to the net-
work phase.
There must be no cut or stray strands of wire
present. The cord clamp must be correctly at-
tached to the outer sheath.
To replace the connection cable use only
H05V2V2-F T90 or equivalent type. Make
sure that the cable section is applicable to the
voltage and the working temperature. The yel-
low/green earth wire (B) must be approximately
2 cm longer than the live and neutral wire (A).
AB
12
www.zanussi.com

Warning! A cut off plug inserted into a 13
amp socket is a serious safety (shock)
hazard. Ensure that the cut off plug is disposed
of safely.
Important! The replacement of electric cable
must be carried out exclusively by the service
force centre or by personnel with similar
competencies, in accordance with the current
regulations.
Assembly
40-50 mm
55 mm
30 mm
min. 650 mm 490 mm
min. 100 mm
270 mm
If several 30 cm hobs are to be installed side by
side into the same cut out, an assembly kit in-
cluding a support side bracket and supplemen-
tary seals is available at our Service Centres.
The relevant installation instructions are sup-
plied within the kit package.
==
270+1mm
600mm
R 5mm
490+1mm
Possibilities for insertion
Kitchen unit with door
The panel installed below the hob must be easy
to remove and let an easy access in case a
technical assistance intervention is necessary.
min 20 mm
(max 150 mm)
30 mm
60 mm
b
a
a) Removable panel
b) Space for connections
13
www.zanussi.com

Kitchen unit with oven
The hob recess dimensions must obey the indi-
cation and the kitchen unit must be equipped
with vents to let a continuous supply of air. The
electrical connection of the hob and the oven
must be installed separately for safety reasons
and to let easy remove oven from the unit.
50 cm2
360 cm2180 cm2
120 cm2
Product description
Cooking surface layout
1
2
3
4
180
mm
145
mm
1Rear cooking zone 1700 W
2Front cooking zone 1200 W
3Power indicator
4Control knobs
Electric cooking zones control knobs
Symbol Function
0off position
Symbol Function
1minimum heat
6maximum heat
Operation
To switch on and increase the heat setting turn
the knob counterclockwise. To decrease the
heat setting turn the knob clockwise. To switch
off turn the knob to the 0.
Power indicator is activated when either of the
zones are turned on, and will stay on until the
cooking zones are switched off.
Before first use
Put cookware containing water on each cook-
ing zone, set the maximum position and operate
the appliance for 10 min. This is to burn off the
residue in the appliance. After that, operate the
appliance at minimum position for 20 min. Dur-
ing this period, an odour and smoke can occur.
This is normal. Make sure that the airflow is suf-
ficient.
When a cooking zone operates, it hums
for a short time. This is typical of all ceram-
ic glass cooking zones and does not show that
the appliance operates incorrectly.
14
www.zanussi.com

Helpful hints and tips
Cookware
• The bottom of the cookware must be as
thick and flat as possible.
• Cookware made of enamelled steel and
with aluminium or copper bottoms can
cause discoloration on glass ceramic
surface.
Energy saving
• If possible, always put the lids on the
cookware.
• Put cookware on a cooking zone before
you start it.
• Stop the cooking zones before the end
of the cooking time to use residual heat.
• The bottom of pans and cooking zones
must have the same dimension.
Use pots and pans with bottom applicable
to the dimension of the cooking zones.
Cooking zone Diameters of cookware
Front max. 145 mm
Cooking zone Diameters of cookware
Rear max. 180 mm
Examples of cooking applications
Heat
setting:
Use to:
1 Keeping warm
2Gentle simmering
3Simmering
4Frying / browning
5Bringing to the boil
6Bringing to the boil / quick frying /
deep-frying
Information on acrylamides
Important! According to the newest scientific
knowledge, if you brown food (specially the one
which contains starch), acrylamides can pose a
health risk. Thus, we recommend that you cook
at the lowest temperatures and do not brown
food too much.
Care and cleaning
Clean the appliance after each use.
Always use cookware with clean bottom.
Warning! Before any maintenance or
cleaning can be carried out, you must
disconnect the hob from the electricity supply.
The hob is best cleaned while it is still
warm, as spillage can be removed more
easily than if it is left to cool.
Warning! Sharp objects and abrasive
cleaning agents will damage the
appliance.
For your safety, do not clean the appliance with
steam blasters or high-pressure cleaners.
Scratches or dark stains on the glass ce-
ramic have no effect on how the appliance
operates.
To remove the dirt:
1. – Remove immediately:melted plastic,
plastic foil, and food with sugar. If not,
the dirt can cause damage to the appli-
ance. Use a special scraper for the
glass . Put the scraper on the glass sur-
face at an acute angle and move the
blade on the surface .
–Remove after the appliance is suffi-
ciently cool:limescale rings , water
rings, fat stains, shiny metallic discolora-
tions. Use a special cleaning agent for
glass ceramic or stainless steel.
2. Clean the appliance with a moist cloth and
some detergent.
3. At the end rub the appliance dry with a
clean cloth.
15
www.zanussi.com

What to do if…
Problem Possible cause and remedy
The appliance does not operate. • Examine the fuse in the electrical system of the house in the fuse box.
If the fuses blow time after time, speak to an authorised electrician.
The cooking zone does not heat
up.
• Make sure that the appliance is plugged in and the electrical supply
is switched on.
• Make sure that you turn the correct control knob.
• Examine the fuse in the electrical system of the house in the fuse box.
If the fuses blow time after time, speak to an authorised electrician.
The effectiveness of the hob is not
satisfactory.
• Make sure that the hob is clean and dry.
• Make sure that the cookware is the correct size for the cooking zone.
• Make sure that the cookware has a flat bottom.
• Make sure that the heat setting is correct for this type of cooking.
If there is a fault, first try to find a solution to the
problem yourself. If you cannot find a solution to
the problem yourself, speak your dealer or the
local Service Force Centre.
If you operated the appliance incorrectly,
or the installation was not carried out by a
registered engineer, the visit from the customer
service technician or dealer may not take place
free of charge, even during the warranty period.
Labels supplied with the accessories bag
Stick the adhesive labels as indicated below:
MOD.
PROD.NO.
SER.NO
DATA
MOD.
PROD.NO.
SER.NO
DATA
MODELMODEL
MOD.
PROD.NO.
SER.NO.
03 IT
MADE IN ITALY
TYPE
230V-50Hz
IP20
0049
1 2 3
1Stick it on Guarantee Card and send this
part
2Stick it on Guarantee Card and keep this
part
3Stick it on instruction booklet
These data are necessary to help you
quickly and correctly. These data are
available on the supplied rating plate.
• Model description .................
• Product number (PNC) .................
• Serial Number (S.N.) .................
16
www.zanussi.com

Use the original spare parts only. They are
available at Service Force Centre and approved
spare parts shops.
Technical data
Hob dimensions
Width: 290 mm
Length: 510 mm
Hob recess dimensions
Width: 270 mm
Length: 490 mm
Hot plate rating
Rear cooking zone 180
mm
1.7 kW
Front cooking zone 145
mm
1.2 kW
Total rating 2.9 kW
Electric supply 230 V ~ 50 Hz
Environment concerns
The symbol on the product or on its
packaging indicates that this product may not
be treated as household waste. Instead it
should be taken to the appropriate collection
point for the recycling of electrical and
electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent
potential negative consequences for the
environment and human health, which could
otherwise be caused by inappropriate waste
handling of this product. For more detailed
information about recycling of this product,
please contact your local council, your
household waste disposal service or the shop
where you purchased the product.
Packaging material
The packaging materials are friendly to the
environment and can be recycled. The
plastic components are identified by marking:
>PE<,>PS<, etc. Discard the packaging mate-
rials as household waste at the waste disposal
facilities in your municipality.
17
www.zanussi.com

Περιεχόμενα
Οδηγίες για την ασφάλεια _ _ _ _ _ _ _ _ 18
Εγκατάσταση _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 19
Περιγραφή προϊόντος _ _ _ _ _ _ _ _ _ _ 22
Λειτουργία _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 22
Χρήσιμες συμβουλές _ _ _ _ _ _ _ _ _ _ _ 23
Φροντίδα και καθάρισμα _ _ _ _ _ _ _ _ _ 23
Τι να κάνετε αν... _ _ _ _ _ _ _ _ _ _ _ _ _ 24
Τεχνικά χαρακτηριστικά _ _ _ _ _ _ _ _ _ 25
Περιβαλλοντικά θέματα _ _ _ _ _ _ _ _ _ _ 26
Υπόκειται αε αλλαγές χωρίς προειδποίηση.
Οδηγίες για την ασφάλεια
Για την προσωπική σας ασφάλεια και τη
σωστή λειτουργία της συσκευής, διαβά-
στε το παρόν εγχειρίδιο προσεκτικά πριν από
την εγκατάσταση και τη χρήση. Φυλάσσετε
πάντα τις οδηγίες αυτές μαζί με τη συσκευή,
ακόμη και εάν μετακομίσετε ήπουλήσετε τη
συσκευή. Οι χρήστες πρέπει να είναι πλήρως
εξοικειωμένοι με τη λειτουργία και τα χαρα-
κτηριστικά ασφαλείας της συσκευής.
Γενική ασφάλεια
ΠΡΟΕΙΔΟΠΟΙΗΣΗ Ησυσκευή δεν
πρέπει να χρησιμοποιείται από άτομα
(συμπεριλαμβανομένων παιδιών) με
μειωμένες σωματικές, αισθητηριακές ή
διανοητικές ικανότητες ήμε έλλειψη εμπειρίας
και γνώσεων. Τα άτομα αυτά πρέπει να
βρίσκονται υπό επιτήρηση ήνα έχουν λάβει
οδηγίες σχετικά με τη χρήση της συσκευής
από κάποιο άτομο που είναι υπεύθυνο για
την ασφάλειά τους.
Ησυσκευή δεν προορίζεται για λειτουρ-
γία με εξωτερικό χρονοδιακόπτη ήμε ξε-
χωριστό σύστημα τηλεχειρισμού.
Ασφάλεια για τα παιδιά
•Ησυσκευή αυτή πρέπει να χρησιμοποιείται
μόνο από ενήλικες. Τα παιδιά πρέπει να
επιβλέπονται, ώστε να διασφαλίζεται ότι
δεν παίζουν με τη συσκευή.
•Φυλάσσετε όλα τα υλικά συσκευασίας μα-
κριά από τα παιδιά. Υπάρχει κίνδυνος
ασφυξίας και τραυματισμού.
•Κρατάτε τα παιδιά μακριά από τη συσκευή
τόσο κατά τη διάρκεια όσο και μετά από τη
λειτουργία της, μέχρι ησυσκευή να είναι
κρύα.
Ασφάλεια κατά τη λειτουργία
•Αφαιρέστε όλα τα υλικά συσκευασίας, τα
αυτοκόλλητα και τις ζελατίνες από τη συ-
σκευή πριν από την πρώτη χρήση.
•Θέστε τις εστίες μαγειρέματος εκτός λει-
τουργίας μετά από κάθε χρήση.
•Κίνδυνος εγκαυμάτων! Μην τοποθετείτε
μαχαιροπίρουνα ήκαπάκια μαγειρικών
σκευών πάνω στην εστία, καθώς μπορεί
να ζεσταθούν.
ΠΡΟΕΙΔΟΠΟΙΗΣΗ Κίνδυνος
πυρκαγιάς!Τα θερμά λάδια και λίπη
μπορούν να αρπάξουν φωτιά πολύ γρήγορα.
Σωστή λειτουργία
•Παρακολουθείτε πάντα τη συσκευή κατά τη
διάρκεια της λειτουργίας.
•Χρησιμοποιείτε τη συσκευή μόνο για οικια-
κές εργασίες μαγειρέματος!
•Μη χρησιμοποιείτε τη συσκευή ως επιφά-
νεια εργασίας ήαπόθεσης αντικειμένων.
•Μην τοποθετείτε ήαποθηκεύετε εξαιρετικά
εύφλεκτα υγρά και υλικά ήεύτηκτα αντικεί-
μενα (κατασκευασμένα από πλαστικό ή
αλουμίνιο) πάνω ήκοντά στη συσκευή.
•Προσέχετε κατά τη σύνδεση τη συσκευής
στην πρίζα ρεύματος. Μην επιτρέπετε στις
ηλεκτρικές συνδέσεις να ακουπήσουν τη
συσκευή ήζεστά μαγειρικά σκεύη. Μην
αφήσετε να μπερδευτούν οι ηλεκτρικές
συνδέσεις.
Τρόπος αποφυγής ζημιών στη συσκευή
•Αν τα αντικείμενα ήτα μαγειρικά σκεύη πέ-
σουν επάνω στην υαλοκεραμική εστία, η
επιφάνεια μπορεί να καταστραφεί.
18
www.zanussi.com

•Τα μαγειρικά σκεύη από χυτοσίδηρο, αλου-
μίνιο ήαυτά με φθαρμένο πάτο μπορούν
να χαράξουν την κεραμική επιφάνεια εάν
τα μετακινήσετε επάνω στην επιφάνεια.
•Μην αφήσετε να τελειώσει το νερό των μα-
γειρικών σκευών κατά το βράσιμο για να
αποφύγετε τη ζημιά στα μαγειρικά σκεύη
και την υαλοκεραμική εστία.
•Μη χρησιμοποιείτε τις εστίες μαγειρέματος
με άδειο μαγειρικό σκεύος ήχωρίς μαγειρι-
κό σκεύος.
•Μην καλύπτετε τμήμα της συσκευής με
αλουμινόχαρτο.
•Εάν υπάρχει μια ρωγμή στην επιφάνεια,
αποσυνδέστε την παροχή ρεύματος για να
αποφύγετε την ηλεκτροπληξία.
Απόρριψη της συσκευής
•Για την αποτροπή του κινδύνου τραυματι-
σμού ατόμων ήπρόκλησης βλάβης στη
συσκευή
–Αποσυνδέστε τη συσκευή από την πα-
ροχή ρεύματος.
–Κόψτε το καλώδιο τροφοδοσίας στο ση-
μείο όπου συνδέεται με τη συσκευή και
απορρίψτε το.
–Επικοινωνήστε με τις αρμόδιες τοπικές
υπηρεσίες για την απόρριψη της συ-
σκευής σας.
Εγκατάσταση
Εγκατάσταση
ΠΡΟΕΙΔΟΠΟΙΗΣΗ Διαβάστε και
ακολουθήστε τις οδηγίες προσεκτικά.
Υπάρχει κίνδυνος τραυματισμού ή
πρόκλησης ζημιάς στη συσκευή.
•Βεβαιωθείτε ότι ησυσκευή δεν έχει υποστεί
ζημιά κατά τη μεταφορά. Μη συνδέετε τη
συσκευή εάν έχει υποστεί ζημιά. Εάν απαι-
τείται, επικοινωνήστε με τον προμηθευτή.
•Ηεγκατάσταση και ησύνδεση της συ-
σκευής στο ηλεκτρικό δίκτυο πρέπει να
πραγματοποιείται μόνο από ειδικευμέ-
νους τεχνικούς.
•Χρησιμοποιείτε εντοιχιζόμενες συσκευές
μόνο μετά την εγκατάστασή τους σε κατάλ-
ληλα έπιπλα εντοιχισμού και πάγκους ερ-
γασίας που πληρούν τα ισχύοντα πρότυ-
πα.
•Μην αλλάζετε τις προδιαγραφές και μην
τροποποιείτε αυτή τη συσκευή. Υπάρχει
κίνδυνος τραυματισμού ήπρόκλησης ζη-
μιάς στη συσκευή.
•Ακολουθείτε πλήρως τη νομοθεσία, τις δια-
τάξεις, τους κανονισμούς και τα πρότυπα
που ισχύουν στη χώρα που θα χρησιμο-
ποιηθεί ησυσκευή (κανονισμοί ασφαλείας,
κανονισμοί ανακύκλωσης, κανονισμοί ηλεκ-
τρικής ασφάλειας κ.λπ.).
•Τηρείτε τις ελάχιστες αποστάσεις από τις
άλλες συσκευές και μονάδες.
•Χρησιμοποιείτε προστασία από τα χτυπή-
ματα, για παράδειγμα τοποθετήστε τα συρ-
τάρια κάτω από τη συσκευή, μόνο εάν δια-
θέτουν προστατευτικό πλαίσιο ακριβώς κά-
τω από αυτήν.
•Αν οβραχίονας στερέωσης βρίσκεται κο-
ντά στο μπλοκ ακροδεκτών, διασφαλίστε
ότι το καλώδιο σύνδεσης δεν έρχεται σε
επαφή με το άκρο του βραχίονα.
•Χρησιμοποιήστε κατάλληλο υλικό στεγανο-
ποίησης για προστασία των κομμένων επι-
φανειών του πάγκου εργασίας από την
υγρασία!
•Χρησιμοποιήστε κατάλληλο μονωτικό για
να μονώσετε τη συσκευή στον πάγκο εργα-
σίας χωρίς να αφήσετε κενά.
•Προστατέψτε το κάτω μέρος της συσκευής
από ατμούς και υγρασία, π.χ. από το πλυ-
ντήριο πιάτων ήτο φούρνο σας.
•Μην τοποθετείτε τη συσκευή δίπλα σε πόρ-
τες ήκάτω από παράθυρα. Τα καυτά μα-
γειρικά σκεύη μπορεί να πέσουν από την
εστία όταν ανοίγετε πόρτες ήπαράθυρα.
•Αποσυνδέστε τη συσκευή από την
ηλεκτρική τροφοδοσία πριν πραγματο-
19
www.zanussi.com

ποιηθεί οποιαδήποτε εργασία καθαρι-
σμού ήσυντήρησης.
ΠΡΟΕΙΔΟΠΟΙΗΣΗ Κίνδυνος
τραυματισμού από το ηλεκτρικό ρεύμα.
Τηρείτε προσεκτικά τις οδηγίες για τις
ηλεκτρικές συνδέσεις.
•Οακροδέκτης του ηλεκτρικού δικτύου βρί-
σκεται υπό τάση.
•Διασφαλίστε ότι οακροδέκτης του ηλεκτρι-
κού δικτύου δεν είναι υπό τάση.
•Ηεγκατάσταση πρέπει να έχει πραγματο-
ποιηθεί κατά τρόπον ώστε να παρέχεται
προστασία από ηλεκτροπληξία.
•Οι χαλαρές ήλανθασμένες ηλεκτρικές συν-
δέσεις μπορούν να οδηγήσουν σε υπερ-
θέρμανση του ακροδέκτη.
•Οι συνδέσεις μέσω κλέμας πρέπει να
πραγματοποιηθούν σωστά από επαγγελ-
ματία ηλεκτρολόγο.
•Τοποθετήστε συνδετήρα ανακούφισης κα-
ταπόνησης στο καλώδιο.
•Χρησιμοποιήστε κατάλληλο καλώδιο ηλεκ-
τρικής σύνδεσης και αντικαταστήστε τυχόν
φθαρμένα καλώδια με καλώδια κατάλληλου
τύπου. Επικοινωνήστε με το τοπικό κέντρο
σέρβις.
Στην ηλεκτρική εγκατάσταση της συσκευής
θα πρέπει να προβλέπεται διάταξη που θα
επιτρέπει την αποσύνδεση της συσκευής από
το δίκτυο ρεύματος από όλους τους πόλους,
με μια ελάχιστη απόσταση 3 mm μεταξύ των
επαφών. Πρέπει να έχετε σωστές διατάξεις
απομόνωσης: ασφαλειοδιακόπτες, ασφάλειες
(βιδωτές ασφάλειες αφαιρούμενες από την
ασφαλειοθήκη), διακόπτες και ρελέ διαφυγής
ρεύματος.
Οκατασκευαστής δεν ευθύνεται για τραυ-
ματισμούς ατόμων και κατοικίδιων ζώων
ήγια υλικές ζημιές που οφείλονται σε μη
συμμόρφωση με τις παρούσες απαιτή-
σεις.
Ηλεκτρική σύνδεση
•Γειώστε τη συσκευή σύμφωνα με τις προ-
φυλάξεις ασφαλείας.
•Βεβαιωθείτε ότι ηονομαστική τάση και ο
τύπος ισχύος που αναγράφονται στην πι-
νακίδα τεχνικών χαρακτηριστικών αντιστοι-
χούν στην τάση και την ισχύ του τοπικού
ηλεκτρικού δικτύου.
•Ησυσκευή παρέχεται με καλώδιο τροφο-
δοσίας. Σε αυτό πρέπει να τοποθετηθεί ένα
κατάλληλο φις, ικανό να υποστηρίξει το
φορτίο που αναγράφεται στην πινακίδα τε-
χνικών χαρακτηριστικών. Το φις πρέπει να
συνδεθεί σε κατάλληλη πρίζα.
•Όλα τα ηλεκτρικά εξαρτήματα πρέπει να
εγκαθίστανται ήνα αντικαθίστανται από τον
τεχνικό του κέντρου εξυπηρέτησης πελα-
τών ήάλλο εξουσιοδοτημένο προσωπικό
σέρβις.
•Χρησιμοποιείτε πάντα μια σωστά εγκατε-
στημένη πρίζα με προστασία κατά της
ηλεκτροπληξίας.
•Μετά την εγκατάσταση, βεβαιωθείτε ότι η
πρόσβαση στο φις τροφοδοσίας είναι δυ-
νατή.
•Μην τραβάτε το καλώδιο τροφοδοσίας για
να αποσυνδέσετε τη συσκευή. Τραβάτε
πάντα το φις τροφοδοσίας.
•Ησυσκευή δεν πρέπει να συνδέεται στο
ρεύμα με μπαλαντέζα, μετασχηματιστή ή
πολύπριζο (υπάρχει κίνδυνος πυρκαγιάς).
Βεβαιωθείτε ότι ηγείωση της σύνδεσης εί-
ναι σύμφωνη με τα ισχύοντα πρότυπα και
τους σχετικούς κανονισμούς.
•Το καλώδιο τροφοδοσίας πρέπει να τοπο-
θετηθεί έτσι ώστε να μην έρχεται σε επαφή
με κανένα θερμό μέρος.
•Συνδέστε τη συσκευή στο ηλεκτρικό δίκτυο
χρησιμοποιώντας μια διάταξη που να επι-
τρέπει την πλήρη αποσύνδεσή της, με
απόσταση τουλάχιστον 3 mm μεταξύ των
επαφών, π.χ. αυτόματο διακόπτη προστα-
σίας γραμμής, διακόπτη διαφυγής ήασφά-
λεια.
•Κανένα τμήμα του καλωδίου σύνδεσης δεν
πρέπει να υπερβαίνει σε θερμοκρασία τους
90 °C. Το μπλε ουδέτερο καλώδιο πρέπει
να συνδεθεί στο μπλοκ ακροδεκτών με τη
σήμανση «N». Το καφέ (ήμαύρο) καλώδιο
φάσης (συνδεδεμένο στον ακροδέκτη του
μπλοκ ακροδεκτών με τη σήμανση «L»)
20
www.zanussi.com
