Contents
Safety information _ _ _ _ _ _ _ _ _ _ _ _ _ _ 2
Safety instructions _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3
Product description _ _ _ _ _ _ _ _ _ _ _ _ _ 5
Daily use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 5
Helpful hints and tips _ _ _ _ _ _ _ _ _ _ _ _ _ 6
Care and cleaning _ _ _ _ _ _ _ _ _ _ _ _ _ _ 7
Troubleshooting _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 7
Installation _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 9
Technical information _ _ _ _ _ _ _ _ _ _ _ _ 13
Environment concerns _ _ _ _ _ _ _ _ _ _ _ 13
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read the
supplied instructions. The manufacturer is not responsible if an in-
correct installation and use causes injuries and damages. Always
keep the instructions with the appliance for future reference.
Children and vulnerable people safety
Warning! Risk of suffocation, injury or permanent disability.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental ca-
pabilities or lack of experience and knowledge if they are super-
vised by an adult or a person who is responsible for their safety.
• Do not let children play with the appliance.
• Keep all packaging away from children.
• Keep children and pets away from the appliance when it operates
or when it cools down. Accessible parts are hot.
• If the appliance has a child safety device, we recommend that you
activate it.
• Cleaning and user maintenance shall not be made by children
without supervision.
General Safety
• The appliance and its accessible parts become hot during use.
Do not touch the heating elements.
• Do not operate the appliance by means of an external timer or
separate remote-control system.
2
www.zanussi.com

• Unattended cooking on a hob with fat or oil can be dangerous
and may result in fire.
• Never try to extinguish a fire with water, but switch off the appli-
ance and then cover flame e.g. with a lid or a fire blanket.
• Do not store items on the cooking surfaces.
• Do not use a steam cleaner to clean the appliance.
• Metallic objects such as knives, forks, spoons and lids should not
be placed on the hob surface since they can get hot.
Safety instructions
Installation
Warning! Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied
with the appliance.
• Keep the minimum distance from the other
appliances and units.
• Always be careful when you move the appli-
ance because it is heavy. Always wear safety
gloves.
• Seal the cut surfaces with a sealant to pre-
vent moisture to cause swelling.
• Protect the bottom of the appliance from
steam and moisture.
• Do not install the appliance adjacent to a
door or under a window. This prevents hot
cookware to fall from the appliance when the
door or the window is opened.
• If the appliance is installed above drawers
make sure that the space, between the bot-
tom of the appliance and the upper drawer,
is sufficient for air circulation.
• The bottom of the appliance can get hot. We
recommend to install a non-combustile sepa-
ration panel under the appliance to prevent
access to the bottom.
Electrical connection
Warning! Risk of fire and electrical shock.
• All electrical connections must be made by a
qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make sure
that the appliance is disconnected from the
power supply.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable tangle.
• Make sure the mains cable or plug (if appli-
cable) does not touch the hot appliance or
hot cookware, when you connect the appli-
ance to the near sockets
• Make sure the appliance is installed correct-
ly. Loose and incorrect electricity mains ca-
ble or plug (if applicable) can make the termi-
nal become too hot.
• Make sure that a shock protection is instal-
led.
• Use the strain relief clamp on cable.
• Make sure not to cause damage to the mains
plug (if applicable) or to the mains cable.
Contact the Service or an electrician to
change a damaged mains cable.
• The electrical installation must have an isola-
tion device which lets you disconnect the ap-
pliance from the mains at all poles. The isola-
tion device must have a contact opening
width of minimum 3 mm.
• Use only correct isolation devices: line pro-
tecting cut-outs, fuses (screw type fuses re-
3
www.zanussi.com

moved from the holder), earth leakage trips
and contactors.
Gas connection
• All gas connections should be made by a
qualified person.
• Make sure that there is air circulation around
the appliance.
• The information about the gas supply is on
the rating plate.
• This appliance is not connected to a device,
which evacuates the products of combus-
tion. Make sure to connect the appliance ac-
cording to current installation regulations.
Pay attention to requirements regarding ade-
quate ventilation.
Use
Warning! Risk of injury, burns or electric
shock.
• Use this appliance in a household environ-
ment.
• Do not change the specification of this appli-
ance.
• Do not let the appliance stay unattended
during operation.
• Do not operate the appliance with wet hands
or when it has contact with water.
• Do not put cutlery or saucepan lids on the
cooking zones. They become hot.
• Set the cooking zone to “off” after use.
• Do not use the appliance as a work or as a
storage surface.
Warning! Risk of fire or explosion.
• Fats and oil when heated can release flam-
mable vapours. Keep flames or heated ob-
jects away from fats and oils when you cook
with them.
• The vapours that very hot oil releases can
cause spontaneous combustion.
• Used oil, that can contain food remnants, can
cause fire at a lower temperature than oil
used for the first time.
• Do not put flammable products or items that
are wet with flammable products in, near or
on the appliance.
Warning! Risk of damage to the
appliance.
• Do not keep hot cookware on the control
panel.
• Do not let cookware to boil dry.
• Do not activate the cooking zones with emp-
ty cookware or without cookware.
• Do not put aluminium foil on the appliance.
• Do not let acid liquids, for example vinegar,
lemon juice or limescale remover touch the
hob. This can cause matt patches.
• Provide good ventilation in the room where
the appliance is installed.
• Make sure that the ventilation openings are
not blocked.
• Use only stable cookware with the correct
shape and diameter larger than the dimen-
sions of the burners. There is a risk of over-
heating and rupture of the glass plate (if ap-
plicable).
• Make sure the flame does not go out when
you quickly turn the knob from the maximum
to the minimum position.
• Make sure pots are centrally positioned on
the rings and do not stick out over edges of
the cooking surface.
• Use only the accessories supplied with the
appliance.
• Do not install a flame diffuser on the burner.
Care and Cleaning
Warning! Risk of damage to the
appliance.
• Clean regularly the appliance to prevent the
deterioration of the surface material.
• Do not use water spray and steam to clean
the appliance.
• Do not clean the burners in the dishwasher.
• Clean the appliance with a moist soft cloth.
Only use neutral detergents. Do not use
4
www.zanussi.com

abrasive products, abrasive cleaning pads,
solvents or metal objects.
Disposal
Warning! Risk of injury or suffocation.
• Contact your municipal authority for informa-
tion on how to discard the appliance correct-
ly.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Flat the external gas pipes.
Service
• Contact the Service to repair the appliance.
We recommend only the use of original
spare parts.
Product description
2
1
6
5
4
3
1Semi-rapid burner
2Semi-rapid burner
3Control knobs
4Spark generator button
5Auxiliary burner
6Rapid burner
Control knobs
Symbol Description
no gas supply / off posi-
tion
Symbol Description
ignition position / maxi-
mum gas supply
minimum gas supply
Daily use
Warning! Refer to the Safety chapters.
Ignition of the burner
Warning! Be very careful when you use
open fire in kitchen environment.
Manufacturer decline any responsibility in case
misuse of the flame
Always light the burner before you put
cookware.
To light the burner:
1. Push and hold the spark generator button
.
2. At the same time turn the control knob
counterclockwise to the maximum position
and push it down to light the burner.
3. Release the spark generator button when
burner lights but keep the control knob on
this position for approximately 5 seconds;
this will let thermocouple to warm up. If
not, the gas supply will be interrupted.
4. Adjust the flame after it is regular.
If after some tries the burner does not
light, check if the crown and its cap are in
correct positions.
5
www.zanussi.com

A
B
C
D
A) Burner cap
B) Burner crown
C) Ignition candle
D) Thermocouple
Warning! Do not keep the control knob
pushed for more than 15 seconds.
If the burner does not light after 15 seconds,
release the control knob, turn it into off position
and try to light the burner again after minimum
1 minute.
Important! In the absence of electricity you
can ignite the burner without electrical device;
in this case approach the burner with a flame,
push the relevant knob down and turn it
counter-clockwise to maximum gas release
position.
If the burner accidentally goes out, turn the
control knob to the off position and try to
light the burner again after minimum 1 minute.
The spark generator can start automatical-
ly when you switch on the mains, after in-
stallation or a power cut. It is normal.
Turning the burner off
To put the flame out, turn the knob to the sym-
bol .
Warning! Always turn the flame down or
switch it off before you remove the pans
from the burner.
Helpful hints and tips
Warning! Refer to the Safety chapters.
Energy savings
• If possible, always put the lids on the pans.
• When the liquid starts to boil, turn down the
flame to barely simmer the liquid.
Use cookware with diameters applicable to the
size of burners.
Burner Diameters of cookware
Rapid 180 - 260 mm
Semi-rapid 120 - 220 mm
Auxiliary 80 - 160 mm
Warning! Make sure that the bottoms of
pots do not stand above the control
knobs. If the control knobs are under the
bottoms of pots, the flame heats them up.
Do not put the same pan on two burners.
Warning! Make sure that pot handles is
not above the front edge of the cooktop.
Make sure that pots are centrally put on the
rings in order to get maximum stability and to
get lower gas consumption.
Do not put unstable or damaged pots on the
rings to prevent from spill and injury.
Warning! Do not use a flame diffuser.
6
www.zanussi.com

Care and cleaning
Warning! Refer to the Safety chapters.
Warning! Deactivate the appliance and
let it cool down before you clean it.
Disconnect the appliance from the electrical
supply before you do cleaning or maintenance
work.
Scratches or dark stains on the surface
have no effect on how the appliance oper-
ates.
• You can remove the pan supports to easily
clean the hob.
• To clean the enamelled parts, cap and
crown, wash them with warm soapy water
and dry them carefully before you put them
back.
• Wash stainless steel parts with water, and
then dry them with a soft cloth.
• The pan supports are not dishwasher proof.
They must be washed by hand.
• When you wash the pan supports by hand,
take care when you dry them as the enamel-
ling process occasionally leaves rough
edges. If necessary, remove stubborn stains
using a paste cleaner.
• Make sure you position the pan supports
correctly after cleaning.
• To make the burners work correctly, make
sure that the arms of the pan supports are in
the centre of the burner.
•Be very careful when you replace the
pan supports to prevent the hob top
from damage.
After cleaning, dry the appliance with a soft
cloth.
Removing the dirt:
1. – Remove immediately: melting plastic,
plastic foil, and food containing sugar.
–Stop the appliance and let it cool
down before you clean: limescale rings,
water rings, fat stains, shiny metallic dis-
colorations. Use a special cleaner appli-
cable for surface of hob.
2. Clean the appliance with a damp cloth and
some detergent.
3. At the end rub the appliance dry with a
clean cloth.
The stainless steel can become tarnished if it is
too much heated. Refer to this you must not
cook with potstones, earthenware pans or cast
iron plates.
Cleaning of the spark plug
This feature is obtained through a ceramic igni-
tion candle with a metal electrode. Keep these
components well clean to prevent difficult light-
ing and check that the burner crown holes are
not obstructed.
Periodic maintenance
Periodically speak your local Service Force
Centre to check the conditions of the gas sup-
ply pipe and the pressure adjuster, if fitted.
Troubleshooting
Problem Possible cause Remedy
There is no spark when lighting
the gas
• There is no electrical supply • Make sure that the unit is con-
nected and the electrical supply
is switched on.
• Control the fuse. If the fuse is
released more than one time,
refer to a qualified electrician.
7
www.zanussi.com

Problem Possible cause Remedy
• Burner cap and crown are
placed uneven
• Make sure that the burner cap
and crown are in correct posi-
tions.
The flame is blow out immediately
after ignition
• Thermocouple is not heated
sufficient
• After lightning the flame, keep
the knob pushed for approxi-
mately 5 seconds.
The gas ring burns unevenly • Burner crown is blocked with
food residues
• Make sure that the injector is
not blocked and the burner
crown is clear of food particles.
If there is a fault, first try to find a solution to the
problem yourself. If you cannot find a solution to
the problem yourself, speak your dealer or the
local Service Force Centre.
If you operated the appliance incorrectly,
or the installation was not carried out by a
registered engineer, the visit from the customer
service technician or dealer may not take place
free of charge, even during the warranty period.
These data are necessary to help you
quickly and correctly. These data are
available on the supplied rating plate.
• Model description .................
• Product number (PNC) .................
• Serial Number (S.N.) .................
Use the original spare parts only. They are
available at Service Force Centre and approved
spare parts shops.
Labels supplied with the accessories bag
Stick the adhesive labels as indicated below:
MOD.
PROD.NO.
SER.NO
DATA
MOD.
PROD.NO.
SER.NO
DATA
MODELMODEL
MOD.
PROD.NO.
SER.NO.
03 IT
MADE IN ITALY
TYPE
230V-50Hz
IP20
0049
1 2 3
1Stick it on Guarantee Card and send this
part
2Stick it on Guarantee Card and keep this
part
3Stick it on instruction booklet
8
www.zanussi.com

Installation
Warning! Refer to the Safety chapters.
Warning! The following instructions about
installation, connection and maintenance
must be carried out by qualified personnel in
compliance with standards and local
regulations in force.
Important safety requirements
This hob must be installed in accordance with
the Gas Safety (Installation and Use) Regula-
tions (Current Edition) and the IEE Wiring Reg-
ulations (Current Edition).
For appliances installed in the Republic of Ire-
land please refer to NSAI- Domestic Gas In-
stallation I.S. 813 Current Editions and the ET-
CI Rules for Electrical Installations.
Provision for ventilation
Detailed recommendations are contained in the
following British Standards Codes Of Practice:
B.S. 6172/ B.S. 5440, Par. 2 and B.S. 6891
Current Editions.
The hob should not be installed in a bed sitting
room with a volume of less than 20 m³. If it is
installed in a room of volume less than 5 m³ an
air vent of effective area of 100 cm² is required.
If it is installed in a room of volume between 5
m³ and 10 m³ an air vent of effective area of 50
cm² is required, while if the volume exceeds 11
m³ no air vent is required.
However, if the room has a door which opens
directly to the outside no air vent is required
even if the volume is between 5 m³ and 11 m³.
If there are other fuel burning appliances in the
same room, B.S. 5440 Part 2 Current Edition,
should be consulted to determine the requisite
air vent requirements.
For appliances installed in the Republic of Ire-
land please refer to the NSAI- Domestic Gas
Installation I.S. 813 Current Editions Table
Four.
Location
The hob may be located in a kitchen, a kitchen/
diner or bed sitting room (with a volume greater
than 20 m³), but not in a bathroom or shower
room.
The minimum distance combustible material
can be fitted above the hob in line with the
edges of the hob is 400 mm. If it is fitted below
400 mm a space of 50 mm must be allowed
from the edges of the hob.
For appliances installed in the Republic of Ire-
land please refer to NSAI- Domestic Gas In-
stallation I.S 813 Current Edition Section 7-
Permitted Locations of Appliance.
Gas Connection
Warning! Any gas installation must be
carried out by a GAS SAFE REGISTER
installer.
Make sure that, once the hob is installed, it is
easily accessible for the engineer in the event
of a breakdown.
The manufacturer will not accept liability,
should the above instructions or any of the oth-
er safety instructions incorporated in this in-
struction booklet be ignored.
On the end of the shaft, which includes the G
1/2" threaded elbow, adjustment is fixed so that
the washer is fitted between the components
as shown in the diagram. Screw the parts to-
gether without using excessive force.
ABC
A) End of shaft with nut
B) Washer
C) Elbow
Connection to the gas supply should be with
either rigid or semi-rigid pipe, i.e. steel or cop-
per.
The connection should be suitable for connect-
ing to R 1/2 (1/2 BSP male thread).
9
www.zanussi.com

When the final connection has been made, it is
essential that a thorough leak test is carried out
on the hob and installation.
Make sure that the main connection pipe does
not exert any strain on the hob.
If you use flexible metal pipes make sure that
they agree to ISO 10380 and ISO 10807
standards. Be careful they do not come in
touch with mobile parts or they are not
squeezed. Also be careful when the hob is put
together with an oven.
Important! It is important to install the elbow
correctly, with the shoulder on the end of the
thread, fitted to the hob connecting pipe.
Important! Failure to ensure the correct
assembly will cause leakage of gas.
Important! Make sure that the gas supply
pressure of the appliance obeys the
recommended values.
Rigid connection:
Carry out connection by using metal rigid pipes
(copper with mechanical end).
Injectors replacement
1. Remove the pan supports.
2. Remove the caps and crowns of the burn-
er.
3. With a socket spanner 7 remove the injec-
tors and replace them with the ones which
are necessary for the type of gas you use
(see table in "Technical Information" chap-
ter).
4. Assemble the parts, follow the same pro-
cedure backwards.
5. Replace the rating plate (it is near the gas
supply pipe) with the one for the new type
of gas supply. You can find this plate in the
package supplied with the appliance.
If the supply gas pressure is changeable or dif-
ferent from the necessary pressure, you must fit
an applicable pressure adjuster on the gas sup-
ply pipe.
Adjustment of minimum level
To adjust the minimum level of the burners:
1. Light the burner.
2. Turn the knob on the minimum position.
3. Remove the knob.
4. With a thin screwdriver, adjust the by-pass
screw position.
A
A) The by-pass screw
• If you change from natural gas G20 20 mbar
to liquid gas, fully tighten the adjustment
screw in.
• If you change from liquid gas to natural gas
G20 20 mbar, undo the by-pass screw ap-
proximately 1/4 of a turn.
Warning! Make sure the flame does not
go out when you quickly turn the knob
from the maximum position to the minimum
position.
Electrical connection
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• The appliance must not be connected with
an extension cable, an adapter or a multiple
socket. There is a risk of fire.
• Do not let the power cable to heat up to a
temperature of more than 90° C. The cable
should be guided by means of clamps fixed
to the side of the cabinet, in order to avoid
any contact with the equipment beneath the
cooktop.
• Make sure that there is access to the mains
plug after the installation.
Electrical Requirements
Permanent electrical installation must agree
with the latest I.E.E. Regulations and local Elec-
tricity Board regulations. For your own safety
the installation must be done by a qualified
electrician (e.g. your local Electricity Board, or a
10
www.zanussi.com

contractor who is on the roll of the National In-
spection Council for Electrical Installation Con-
tracting [NICEIC]).
The manufacturer refuses to be held
responsible, if these safety measures
are not abided by.
Supply connections:
This hob has to be connected to 230 — 240 V
( 50 Hz) electricity supply.
The hob has a terminal block which is
marked as follows:
•L— Live terminal
•N— Neutral terminal
•or E— Earth terminal
Before carrying out the connection, make sure:
1. The limiter valve and the electrical system
can take the appliance load (see the rating
plate)
2. The supply system is equipped with an effi-
cient earth connection in compliance with
the current standards and regulations
3. The outlet or omnipolar switch used for
connection is easily accessible with the
appliance installed.
The appliance is supplied with a 3 core flexible
powercable with a 3 amp plug. If it is necessary
to change the fuse, use a 3 amp ASTA-ap-
proved (BS 1362) fuse.
AB
C
D
E
A) Green and Yellow
B) 3 amp fuse
C) Brown
D) Cord clamp
E) Blue
The wires in the cord are coloured as follows:
Green and yellow - Earth
Blue - Neutral
Brown - Live
Replacement of the connection cable
1. Connect the green and yellow (earth) wire
to the terminal which is marked with the
letter 'E', or the earth symbol , or col-
oured green and yellow.
2. Connect the blue (neutral) wire to the ter-
minal which is marked with the letter 'N' or
coloured blue.
3. Connect the brown (live) wire to the termi-
nal which is marked with the letter 'L'. It
must always be connected to the network
phase.
There must be no cut or stray strands of wire
present. The cord clamp must be correctly at-
tached to the outer sheath.
11
www.zanussi.com

To replace the connection cable use only
H05V2V2-F T90 or equivalent type. Make
sure that the cable section is applicable to the
voltage load and the working temperature. The
yellow/green earth wire (B) must be approxi-
mately 2 cm longer than the live and neutral
wire (A).
AB
Warning! A cut off plug inserted into a 13
amp socket is a serious safety (shock)
hazard. Ensure that the cut off plug is disposed
of safely.
Important! The replacement of electric cable
must be carried out exclusively by the service
force centre or by personnel with similar
competencies, in accordance with the current
regulations.
Building In
min. 55 mm
min. 650 mm
550 mm
min. 100 mm
min. 600 mm
30 mm
470 mm
B
A
A) supplied seal
B) supplied brackets
Caution! Install the appliance only on a
worktop with flat surface.
Possibilities for insertion
Kitchen unit with door
The panel installed below the hob must be easy
to remove and let an easy access in case a
technical assistance intervention is necessary.
min 20 mm
(max 150 mm)
30 mm
60 mm
B
A
a) Removable panel
b) Space for connections
Kitchen unit with oven
The hob recess dimensions must obey the indi-
cation and the kitchen unit must be equipped
with vents to let a continuous supply of air. The
electrical connection of the hob and the oven
must be installed separately for safety reasons
and to let easy remove oven from the unit.
50 cm2
360 cm2180 cm2
120 cm2
12
www.zanussi.com

Technical information
Hob dimensions
Width: 580 mm
Length: 500 mm
Hob recess dimensions
Width: 550 mm
Length: 470 mm
Heat input
Rapid burner: 3.0 kW
Semi-rapid burner: 2.0 kW
Auxiliary burner: 1.0 kW
TOTAL POWER: G20 (2H) 20 mbar = 8
kW
G30 (3+) 28-30 mbar
= 567 g/h
G31 (3+) 37 mbar =
557 g/h
Electric supply: 230 V ~ 50 Hz
3 core flexible cable
with non rewireable
plug fitted with a 3 amp
cartridge fuse
Gas connection: R 1/2 "
Category: II2H3+
Gas supply: G20 (2H) 20 mbar
Appliance class: 3
By-pass diameters
Burner Ø By-pass in 1/100
mm
Auxiliary 28
Semi-rapid 32
Rapid 42
Gas burners
BURNER
NORMAL
POWER
RE-
DUCED
POWER
NORMAL POWER
NATURAL GAS
G20 (2H) 20 mbar
LPG
(Butane/Propane) G30/G31 (3+)
28-30/37 mbar
kW kW inj. 1/100
mm m³/h inj. 1/100 mm
G30
28–30
mbar
G31
37 mbar
g/h g/h
Auxiliary 1.0 0.33 70 0.095 50 73 71
Semi-rapid 2.0 0.45 96 0.190 71 145 143
Rapid
3.0 (natural
gas)
2.8 (LPG)
0.75 119 0.286 86 204 200
Environment concerns
The symbol on the product or on its
packaging indicates that this product may not
be treated as household waste. Instead it
should be taken to the appropriate collection
point for the recycling of electrical and
electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent
13
www.zanussi.com

potential negative consequences for the
environment and human health, which could
otherwise be caused by inappropriate waste
handling of this product. For more detailed
information about recycling of this product,
please contact your local council, your
household waste disposal service or the shop
where you purchased the product.
Packaging material
The packaging materials are friendly to the
environment and can be recycled. The
plastic components are identified by marking:
>PE<,>PS<, etc. Discard the packaging mate-
rials as household waste at the waste disposal
facilities in your municipality.
14
www.zanussi.com

15
www.zanussi.com

www.zanussi.com/shop
397220502-A-492012
