Zanussi ZOD35712B User manual

EN
ZOD35712B
ZOD35712X
User Manual
Oven

Contents
Safety information 2
Safety Instructions 3
Product description 5
Before first use 5
Daily use 6
Clock functions 8
Using the accessories 9
Additional functions 10
Hints and tips 10
Care and cleaning 17
Troubleshooting 19
Subject to change without notice.
Safety information
Before the installation and use of the appliance, carefully read the
supplied instructions. The manufacturer is not responsible if an
incorrect installation and use causes injuries and damages.
Always keep the instructions with the appliance for future
reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Keep all packaging away from children.
•Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts are hot.
•If the appliance has a child safety device, we recommend you
activate it.
•Cleaning and user maintenance shall not be made by children
without supervision.
•Children of less than 3 years should be kept away unless
continuously supervised.
General Safety
•Only a qualified person must install this appliance and replace
the cable.
2 www.zanussi.com

•Internally the appliance becomes hot when in operation. Do not
touch the heating elements that are in the appliance. Always
use oven gloves to remove or put in accessories or ovenware.
•Before maintenance cut the power supply.
•Ensure that the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the glass door since they can scratch the surface, which
may result in shattering of the glass.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its Authorised Service Centre or similarly
qualified persons in order to avoid a hazard.
•To remove the shelf supports first pull the front of the shelf
support and then the rear end away from the side walls. Install
the shelf supports in the opposite sequence.
•The means for disconnection must be incorporated in the fixed
wiring in accordance with the wiring rules.
Safety Instructions
Installation
WARNING!
Only a qualified person must install
this appliance.
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Obey the installation instruction supplied
with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always wear
safety gloves.
• Do not pull the appliance by the handle.
• Keep the minimum distance from the other
appliances and units.
• Make sure that the appliance is installed
below and adjacent safe structures.
• The sides of the appliance must stay
adjacent to appliances or to units with the
same height.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• All electrical connections should be made by
a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical information on
the rating plate agrees with the power
supply. If not contact an electrician.
• Always use a correctly installed shockproof
socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable. Should
the mains cable need to be replaced, this
must be carried out by our Authorised
Service Centre.
• Do not let mains cables to come in touch
with the appliance door, specially when the
door is hot.
• The shock protection of live and insulated
parts must be fastened in such a way that it
cannot be removed without tools.
• Connect the mains plug to the mains socket
only at the end of the installation. Make sure
that there is access to the mains plug after
the installation.
www.zanussi.com 3

• If the mains socket is loose, do not connect
the mains plug.
• Do not pull the mains cable to disconnect
the appliance. Always pull the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type fuses
removed from the holder), earth leakage trips
and contactors.
• The electrical installation must have an
isolation device which lets you disconnect
the appliance from the mains at all poles.
The isolation device must have a contact
opening width of minimum 3 mm.
• This appliance complies with the E.E.C.
Directives.
Use
WARNING!
Risk of injury, burns and electrical
shock or explosion.
• Use this appliance in a household only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings are
not blocked.
• Do not let the appliance stay unattended
during operation.
• Deactivate the appliance after each use.
• Be careful when you open the appliance
door while the appliance is in operation. Hot
air can release.
• Do not operate the appliance with wet hands
or when it has contact with water.
• Do not apply pressure on the open door.
• Do not use the appliance as a work surface
or as a storage surface.
• Open the appliance door carefully. The use
of ingredients with alcohol can cause a
mixture of alcohol and air.
• Do not let sparks or open flames to come in
contact with the appliance when you open
the door.
• Do not put flammable products or items that
are wet with flammable products in, near or
on the appliance.
WARNING!
Risk of damage to the appliance.
• To prevent damage or discoloration to the
enamel:
– do not put ovenware or other objects in
the appliance directly on the bottom.
– do not put aluminium foil directly on the
bottom of the appliance.
– do not put water directly into the hot
appliance.
– do not keep moist dishes and food in the
appliance after you finish the cooking.
– be careful when you remove or install
the accessories.
• Discoloration of the enamel has no effect on
the performance of the appliance. It is not a
defect in the sense of the warranty law.
• Use a deep pan for moist cakes. Fruit juices
cause stains that can be permanent.
• This appliance is for cooking purposes only.
It must not be used for other purposes, for
example room heating.
• Always cook with the oven door closed.
Care and cleaning
WARNING!
Risk of injury, fire, or damage to the
appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.
• Make sure the appliance is cold. There is the
risk that the glass panels can break.
• Replace immediately the door glass panels
when they are damaged. Contact the
Service.
• Be careful when you remove the door from
the appliance. The door is heavy!
• Clean regularly the appliance to prevent the
deterioration of the surface material.
• Remaining fat or food in the appliance can
cause fire.
• Clean the appliance with a moist soft cloth.
Only use neutral detergents. Do not use
abrasive products, abrasive cleaning pads,
solvents or metal objects.
• If you use an oven spray, obey the safety
instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
Internal light
• The type of light bulb or halogen lamp used
for this appliance is only for household
appliances. Do not use it for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect the
appliance from the power supply.
• Only use lamps with the same specifications.
4 www.zanussi.com

Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent children
and pets to get closed in the appliance.
Product description
General overview
8
8
10
9
9
1 3 5 6 742 24
1
2
3
4
12
11
11
12
1
2
3
4
5
1Knob for the top oven functions
2Power lamp / symbol / indicator
3Knob for the top oven temperature
4Temperature lamp / symbol / indicator
5Electronic programmer
6Knob for the main oven functions
7Knob for the main oven temperature
8Heating element
9Lamp
10 Fan
11 Shelf support, removable
12 Shelf positions
Accessories
•Wire shelf
For cookware, cake tins, roasts.
•Grill- / Roasting pan
To bake and roast or as pan to collect fat.
•Trivet
For roasting and grilling.
Use the trivet only with the Grill- /
roasting pan.
Before first use
WARNING!
Refer to Safety chapters.
Initial Cleaning
Remove all accessories and removable shelf
supports from the appliance.
Refer to "Care and cleaning"
chapter.
Clean the appliance before first use.
Put the accessories and the removable shelf
supports back to their initial position.
Setting the time
You must set the time before you operate the
oven.
Only the top oven works without the
set time.
The indicator for the Time of day function
flashes when you connect the appliance to the
electrical supply, when there was a power cut
or when the timer is not set.
Press the or button to set the correct
time.
www.zanussi.com 5

After approximately five seconds, the flashing
stops and the display shows the time of day you
set.
Changing the time
You cannot change the time of day if
the Duration or End function
operates.
Press again and again until the indicator for
the Time of Day function flashes.
To set a new time, refer to "Setting the time".
Preheating
Preheat the empty appliance to burn off the
remaining grease.
Preheat the two ovens. Heat up one
oven at a time. Set the functions
listed below, if applicable.
1. Set the function and the temperature to
250ºC.
Let the appliance operate for 1 hour.
2. Set the function and the temperature to
250ºC.
Let the appliance operate for 15 minutes.
3. Set the function and the temperature to
250ºC.
Let the appliance operate for 15 minutes.
Accessories can become hotter than usual. The
appliance can emit an odour and smoke. This is
normal. Make sure that the airflow is sufficient.
Daily use
WARNING!
Refer to Safety chapters.
Retractable knobs
To use the appliance, press the control knob.
The control knob comes out.
Activating and deactivating the top /
main oven
It depends on the model if your
appliance has knob symbols,
indicators or lamps:
• The indicator comes on when the
oven heats up.
• The lamp comes on when the
oven operates.
• The symbol shows whether the
knob controls one of the cooking
zones, the oven functions or the
temperature.
1. Turn the knob for the top / main oven
functions to select an oven function.
2. To deactivate the oven turn the knob for the
top / main oven functions to the off position.
Top oven functions
Oven function Application
Light To activate the lamp without a cooking function.
Conventional
Cooking To bake and roast food on 1 shelf position.
6 www.zanussi.com

Oven function Application
Top Heat To brown bread, cakes and pastries. To finish cooked dishes.
Bottom Heat To bake cakes with crispy bottom and to preserve food.
Grilling To grill flat food and to toast bread.
Fast Grilling To grill flat food in large quantities and to toast bread.
Main oven functions
Symbol Oven function Application
Light To activate the lamp without a cooking function.
True Fan Cooking To bake on up to 3 shelf positions at the same time and
to dry food. Set the temperature 20 - 40 °C lower than
for Conventional Cooking.
Turbo Grilling To roast larger meat joints or poultry with bones on 1
shelf position. Also to make gratins and to brown.
Grilling To grill flat food and to toast bread.
Fast Grilling To grill flat food in large quantities and to toast bread.
Conventional Cooking To bake and roast food on 1 shelf position.
Bottom Heat To bake cakes with crispy bottom and to preserve food.
Defrost To defrost frozen food.
Display
The electronic programmer works
only with the main oven.
www.zanussi.com 7

A B C
A) Function indicators
B) Time display
C) Function indicator
Buttons
Button Function Description
MINUS To set the time.
CLOCK To set a clock function.
PLUS To set the time.
Clock functions
Clock functions table
Clock function Application
Time of day To set, change or check the time of day.
Minute Minder To set countdown time. This function has no effect on the operation
of the appliance.
Duration To set the cooking time of the oven.
End To set the time of day when the oven should deactivate.
You can use the functions Duration
and End at the same time to
set the time for how long the
appliance should operate and when
the appliance should deactivate.
This lets you activate the appliance
with a delay in time. First set the
Duration and then the End .
Setting the clock functions
For Duration and End , set an oven
function and temperature of cooking. This is not
necessary for the Minute Minder .
1. Press again and again until the indicator
for the necessary clock function starts to
flash.
2. Press or to set the necessary clock
function.
The clock function operates. The display shows
the indicator for the clock function you set.
For the Minute Minder function the
display shows the time left.
3. When the time ends the indicator of the
clock function flashes and an acoustic
signal sounds. Press a button to stop the
clock function.
8 www.zanussi.com

4. Turn the knob for the oven functions and
the knob for the temperature to the off
position.
With the Duration and End
functions, the appliance deactivates
automatically. The functions work
only for the main oven.
Cancelling the clock functions
1. Press the again and again until the
necessary function indicator flashes.
2. Press and hold .
The clock function goes out after some
seconds.
Using the accessories
WARNING!
Refer to Safety chapters.
Inserting the accessories
Wire shelf:
Push the shelf between the guide bars of the
shelf support and make sure that the feet point
down.
Deep pan:
Push the deep pan between the guide bars of
the shelf support.
Wire shelf and the deep pan together:
Push the deep pan between the guide bars of
the shelf support and the wire shelf on the
guide bars above.
• All accessories have small
indentations at the top of the
right and left side to increase
safety. The indentations are also
anti-tip devices.
• The high rim around the shelf is a
device which prevents cookware
from slipping.
Trivet and Grill- / Roasting pan
WARNING!
Be careful when you remove the
accessories from a hot appliance.
There is a risk of burns.
You can use the trivet to roast larger pieces of
meat or poultry on one shelf position.
1. Put the trivet into the deep pan so that the
supports of the wire shelf point up.
2. Put the deep pan into the oven on the
necessary shelf position.
You can use the trivet to grill flat dishes in large
quantities and to toast.
www.zanussi.com 9

1. Put the trivet into the deep pan so that the
supports of the wire shelf point down. 2. Put the deep pan into the oven on the necessary shelf position.
Additional functions
Cooling fan
When the appliance operates, the cooling fan
activates automatically to keep the surfaces of
the appliance cool. If you deactivate the
appliance, the cooling fan can continue to
operate until the appliance cools down.
Hints and tips
WARNING!
Refer to Safety chapters.
The temperature and baking times in
the tables are guidelines only. They
depend on the recipes and the
quality and quantity of the
ingredients used.
Double oven
Top oven
The top oven is the smaller of the two ovens. It
has 4 shelf positions. Use it to cook smaller
quantities of food. It gives especially good
results when used to cook fruitcakes, sweets
and savoury flants or quiche.
Main oven
The main oven is the bigger of the two ovens. It
is particularly suitable for cooking larger
quantities of food.
Baking
• Your oven can bake or roast differently to the
appliance you had before. Adapt your usual
settings (temperature, cooking times) and
shelf positions to the values in the tables.
• The manufacturer recommends that you use
the lower temperature the first time.
• If you cannot find the settings for a special
recipe, look for the one that is almost the
same.
• You can extend baking times by 10 – 15
minutes if you bake cakes on more than one
level.
• Cakes and pastries at different heights do
not always brown equally at first. If this
occurs, do not change the temperature
setting. The differences equalize during the
baking procedure.
• With longer baking times, you can deactivate
the oven approximately 10 minutes before
the end of the baking time and then use the
residual heat.
When you cook frozen food, the trays in the
oven can twist during baking. When the trays
become cold again, the distortions are gone.
Tips on baking
Baking results Possible cause Remedy
The bottom of the cake is not
browned sufficiently. The shelf position is incorrect. Put the cake on a lower shelf.
10 www.zanussi.com

Baking results Possible cause Remedy
The cake sinks and becomes
soggy, lumpy or streaky. The oven temperature is too high. The next time you bake, set a slightly lower oven tempera-
ture.
The cake sinks and becomes
soggy, lumpy or streaky. The baking time is too short. Set a longer baking time. You cannot decrease baking
times by setting higher
temperatures.
The cake sinks and becomes
soggy, lumpy or streaky. There is too much liquid in the mixture. Use less liquid. Be careful with mixing times, especially if you
use a mixing machine.
The cake is too dry. The oven temperature is too
low. The next time you bake, set a higher oven temperature.
The cake is too dry. The baking time is too long. The next time you bake, set a
shorter baking time.
The cake browns unevenly. The oven temperature is too
high and the baking time is too
short.
Set a lower oven temperature
and a longer baking time.
The cake browns unevenly. The mixture is unevenly distrib-
uted. Spread the mixture evenly on the baking tray.
The cake is not ready in the
baking time given. The oven temperature is too low. The next time you bake, set a slightly higher oven tempera-
ture.
Baking
To bake in the top oven use the function
Conventional Cooking.
Top oven
Food Temperature (°C) Time (min) Shelf position
Biscuits 170 - 190 10 - 20 2
Bread 200 - 220 30 - 35 1
Bread rolls / buns 170-180 10 - 15 1
Cakes:
- Small & Queen 160 - 170 18 - 25 2
- Sponges 160 - 175 20 - 30 2
- Victoria Sandwich 160 - 170 18 - 25 2
- Madeira 140 - 150 75 - 90 2
www.zanussi.com 11

Food Temperature (°C) Time (min) Shelf position
- Rich Fruit 140 - 150 120 - 150 2
- Gingerbread 140 - 150 75 - 90 2
- Meringues 90 - 100 150 - 180 2
- Flapjack 160 - 170 25 - 30 2
- Shortbread 130 - 150 45 - 65 2
Casseroles:
- Beef / Lamb 160 - 170 150 - 180 1
- Chicken 160 - 180 75 - 90 1
Convenience Foods Follow manufacturer's instructions.
Fish 170 - 190 20 - 30 2
Fish Pie (Potato Topped) 190 - 200 20 - 30 2
Fruit Pies, Crumbles 190 - 200 30 - 50 2
Milk Puddings 150 - 170 90 - 120 2
Pasta, Lasagne etc. 170 - 180 40 - 50 2
Pastry:
- Choux 180 - 190 30 - 40 2
- Eclairs, Profiteroles 180 - 190 30 - 40 2
- Flaky / Puff Pies 210 - 220 30 - 40 2
Shortcrust:
- Mince Pies 190 - 210 15 - 20 2
- Meat Pies 190 - 210 25 - 35 2
- Quiche, Tarts, Flans 180 - 200 25 - 50 2
Scones 220 - 230 8 - 12 2
Shepard's Pie 180 - 190 30 - 40 2
Souffles 190 - 200 20 - 30 2
Vegetables:
- Baked Jacket Potatoes 180 - 190 60 - 90 2
- Roast Potatoes 180 - 190 60 - 90 2
Yorkshire Pudding:
- Large 200 - 210 25 - 40 1
- Individual 210 - 220 15 - 25 1
12 www.zanussi.com

Main oven
Food Temperature (°C) Time (min) Shelf posi-
tion
Conventional
Cooking True Fan Cooking
Biscuits 180 - 190 180 - 190 10 - 20 2
Bread 200 - 220 190 - 210 30 - 35 2
Cakes:
- Small & Queen 170 - 180 160 - 170 18 - 25 2
- Sponges 170 - 180 160 - 170 20 - 25 2
- Madeira 150 - 160 140 - 160 60 - 75 2
- Rich Fruit 140 - 150 130 - 140 120 - 150 2
- Christmas 140 - 150 130 - 140 180 - 270 2
Fish 170 - 180 160 - 180 20 - 30 3
Fruit Pies, Crum-
bles 180 - 200 170 - 180 30 - 50 3
Milk Puddings 150 - 170 140 - 160 60 - 90 3
Pastry:
- Choux 180 - 190 180 - 190 30 - 40 3
- Shortcrust 190 - 200 180 - 190 25 - 35 3
- Flaky 190 - 210 180 - 190 30 - 40 3
- Puff Follow manufacturer's instructions. Reduce the temperature by 20ºC for True
Fan Cooking Function.
Plate Tarts 190 - 200 180 - 190 25 - 45 3
Quiches / Flans 200 - 210 170 - 180 25 - 45 3
Scones 220 - 230 210 - 230 8 - 12 2
Roasting
• Use heat-resistant ovenware to roast (refer
to the instructions of the manufacturer).
• You can roast large roasting joints directly in
the deep pan (if present) or on the wire shelf
above the deep pan.
• Roast lean meats in the roasting tin with the
lid. This keeps the meat more succulent.
• All types of meat that can be browned or
have crackling can be roasted in the roasting
tin without the lid.
• We recommend that you cook meat and fish
weighing 1 kg and above in the appliance.
• To prevent the meat juices or fat from
burning onto the pan, put some liquid into
the deep pan.
• If necessary, turn the roast (after 1/2 - 2/3 of
the cooking time).
• Baste large roasts and poultry with their
juices several times during roasting. This
gives better roasting results.
• You can deactivate the appliance
approximately 10 minutes before the end of
the roasting time, and use the residual heat.
www.zanussi.com 13

Roasting tables - Main oven
Beef
Food Quantity Temperature
(°C) Time (min) Shelf position
Roast beef or fillet:
rare per cm. of thickness 190 - 200 1) 5 - 6 2
Roast beef or fillet:
medium per cm. of thickness 180 - 190 1) 6 - 8 2
Roast beef or fillet:
well done per cm. of thickness 170 - 180 1) 8 - 10 2
1) Preheat the oven.
Pork
Food Quantity Temperature
(°C) Time (min) Shelf position
Shoulder, neck, ham 1 - 1.5 kg 160 - 180 90 - 120 2
Pork chop 1 - 1.5 kg 160 - 180 60 - 90 2
Meat loaf 750 g - 1 kg 160 - 170 45 - 60 2
Knuckle of pork
(precooked) 750 g - 1 kg 150 - 170 90 - 120 2
Veal
Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Roast veal 1 160 - 180 90 - 120 2
Knuckle of veal 1.5 - 2 160 - 180 120 - 150 2
Lamb
Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Leg of lamb,
roast lamb 1 - 1.5 150 - 170 75 - 120 2
Saddle of lamb 1 - 1.5 160 - 180 60 - 90 2
Game
Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Saddle of hare,
leg of hare Up to 1 kg 220-250 25 - 40 2
14 www.zanussi.com

Food Quantity (kg) Temperature
(°C) Time (min) Shelf position
Loin of Game 1.5-2 210-220 75 - 105 1
Leg of Game 1.5-2 200-210 90 - 135 1
Poultry
Food Quantity Temperature
(°C) Time (min) Shelf position
Poultry pieces 200 - 250 g
each 200 - 220 35 - 50 3
Half chicken 400 - 500 g
each 190 - 210 35 - 50 3
Poultry 1 - 1.5 kg 190 - 210 45 - 75 1
Duck 1.5 - 2 kg 180 - 200 75 - 100 1
Goose 3.5 - 5 kg 160 - 180 150 - 210 1
Turkey 2.5 - 3.5 kg 160 - 180 105 - 150 1
Turkey 4 - 6 kg 140 - 160 150 - 240 1
Fish (steamed)
Type of meat Quantity (kg) Temperature
(°C) Time (min) Shelf position
Whole fish 1 - 1.5 210 - 220 40 - 60 1
Grilling
Always grill with the maximum temperature
setting.
Set the shelf into the shelf position as
recommended in the grilling table.
For grilling in the top oven adjust the shelf
position to suit different thicknesses of food.
Always set the pan to collect the fat into the first
shelf position.
Grill only flat pieces of meat or fish.
Always preheat the empty oven with the grill
functions for 5 minutes.
CAUTION!
Always grill with the oven door
closed.
Grilling and Fast Grilling - Top oven
Food Time (min)
Bacon Rashers 5 -6
Beefburgers 10 - 20
Chicken Joints 20 - 40
www.zanussi.com 15

Food Time (min)
Lamb Chops 15 - 25
Pork Chops 20 - 25
Whole Fish, Trout / Makarel 10 - 12
Fillets, Plaice / Cod 4 - 6
Kebabs 12 - 18
Kidneys, Lamb / Pig 6 - 10
Sausages 20 - 30
Toasted Sandwiches 3 - 4
Steaks:
- Rare 4 - 6
- Medium 6 - 8
- Well Done 12 - 15
Grilling - Main oven
Food Temperature
(°C) Time (min) Shelf position
1st side 2nd side
Roast beef 210 - 230 30 - 40 30 - 40 2
Filet of beef 230 20 - 30 20 - 30 3
Back of pork 210 - 230 30 - 40 30 - 40 2
Back of veal 210 - 230 30 - 40 30 - 40 2
Back of lamb 210 - 230 25 - 35 20 - 25 3
Whole Fish, 500
- 1000 g 210 - 230 15 - 30 15 - 30 3 / 4
Fast Grilling - Main oven
Food Time (min) Shelf position
1st side 2nd side
Burgers / Burgers 8 - 10 6 - 8 4
Pork fillet 10 - 12 6 - 10 4
Sausages 10 - 12 6 - 8 4
Fillet / Veal steaks 7 - 10 6 - 8 4
16 www.zanussi.com

Food Time (min) Shelf position
1st side 2nd side
Toast / Toast 1) 1 - 3 1 - 3 5
Toast with topping 6 - 8 - 4
1) Preheat the oven.
Defrost - Main oven
Remove the food packaging and put the food
on a plate.
Use the first shelf position from the bottom.
Do not cover the food with a bowl or a plate, as
this can extend the defrost time.
Food Quantity Defrosting
time (min) Further de- frosting
time (min)
Comments
Chicken 1 kg 100 - 140 20 - 30 Put the chicken on an upturned sau-
cer in a big plate. Turn halfway
through.
Meat 1 kg 100 - 140 20 - 30 Turn halfway through.
Meat 500 g 90 - 120 20 - 30 Turn halfway through.
Trout 150 g 25 - 35 10 - 15 -
Straw-
berries 300 g 30 - 40 10 - 20 -
Butter 250 g 30 - 40 10 - 15 -
Cream 2 x 200 g 80 - 100 10 - 15 Whip the cream when still slightly fro-
zen in places.
Gateau 1.4 kg 60 60 -
Care and cleaning
WARNING!
Refer to Safety chapters.
Notes on cleaning
• Clean the front of the appliance with a soft
cloth with warm water and a cleaning agent.
• To clean metal surfaces, use a usual
cleaning agent.
• Clean the appliance interior after each use.
Fat accumulation or other food remains may
result in a fire. The risk is higher for the grill
pan.
• Clean stubborn dirt with a special oven
cleaner.
• Clean all accessories after each use and let
them dry. Use a soft cloth with warm water
and a cleaning agent.
• If you have nonstick accessories, do not
clean them using aggressive agents, sharp-
edged objects or a dishwasher. It can cause
damage to the nonstick coating.
www.zanussi.com 17

Stainless steel or aluminium appliances
Clean the oven door with a wet
sponge only. Dry it with a soft cloth.
Do not use steel wool, acids or
abrasive materials as they can
damage the oven surface. Clean the
oven control panel with the same
precautions.
Removing the shelf supports
To clean the oven, remove the shelf supports.
1
Pull the front of the
shelf support away
from the side wall.
1
1
2
2
Pull the rear end of
the shelf support
away from the side
wall and remove it.
2
Install the shelf supports in the opposite
sequence.
Catalytic cleaning
CAUTION!
Do not clean the catalytic surface
with oven sprays, abrasive cleaning
agents, soap or other cleaning
agents. This will damage the
catalytic surface.
Spots or discolouration of the
catalytic surface have no effect on
catalytic properties.
WARNING!
Keep children away when you clean
the oven at a high temperature. The
oven surface becomes very hot and
there is a risk of burns.
CAUTION!
Always turn the oven light on while
using the catalytic cleaning (if
applicable).
Before activating the catalytic
cleaning remove all the accessories
from the oven.
The walls with a catalytic coating are self-
cleaning. They absorb fat which collects on the
walls while the appliance operates.
To support the self-cleaning procedure, heat
the empty oven on a regular basis.
1. Clean the oven floor with warm water and
washing up liquid, then dry it.
2. Set the function if applicable. If not, set
.
3. Set the temperature to 250ºC and let oven
operate for 1 hour.
4. When the appliance is cool, clean it with a
soft and moist sponge.
Removing and installing the door
You can remove the door and the internal glass
panels to clean it. The number of glass panels is
different for different models.
WARNING!
Be careful when you remove the
door from the appliance. The door is
heavy.
1. Open the door fully.
2. Fully lift up the clamping levers (A) on the
two door hinges.
A
A
3. Close the door until it is at an angle of
approximately 45°.
45°
18 www.zanussi.com

4. Hold the door with one hand on each side
and pull it away from the appliance at an
upwards angle.
5. Put the door with the outer side down on a
soft cloth on a stable surface. This is to
prevent scratches.
6. Hold the door trim (B) on the top edge of
the door at the two sides and push inwards
to release the clip seal.
2
B
1
CAUTION!
Rough handling of the glass,
especially around the edges of the
front panel, can cause the glass to
break.
7. Pull the door trim to the front to remove it.
8. Hold the door glass panels on their top
edge one by one and pull them up out of
the guide.
9. Clean the glass panel with water and soap.
Dry the glass panel carefully.
When the cleaning is completed, install the
glass panels and the door. Do the above steps
in the opposite sequence. Install the smaller
panel first, then the larger.
Replacing the lamp
Put a cloth on the bottom of the interior of the
appliance. It prevents damage to the lamp glass
cover and the cavity.
WARNING!
Danger of electrocution! Disconnect
the fuse before you replace the
lamp. The lamp and the lamp glass
cover can be hot.
1. Deactivate the appliance.
2. Remove the fuses from the fuse box or
deactivate the circuit breaker.
The back lamp
The lamp glass cover is at the back
of the cavity.
1. Turn the lamp glass cover counterclockwise
to remove it.
2. Clean the glass cover.
3. Replace the oven lamp with a suitable 300
°C heat-resistant oven lamp.
Use the same oven lamp type.
4. Install the glass cover.
Troubleshooting
WARNING!
Refer to Safety chapters.
What to do if...
Problem Possible cause Remedy
The oven does not heat up. The oven is deactivated. Activate the oven.
The oven does not heat up. The clock is not set. Set the clock.
The oven does not heat up. The necessary settings are not
set. Make sure that the settings are correct.
www.zanussi.com 19

Problem Possible cause Remedy
The oven does not heat up. The fuse is released. Make sure that the fuse is the
cause of the malfunction. If the
fuse releases again and again,
contact a qualified electrician.
The lamp does not operate. The lamp is defective. Replace the lamp.
Steam and condensation settle
on the food and in the cavity of
the oven.
You left the dish in the oven for
too long. Do not leave the dishes in the oven for longer than 15 - 20
minutes after the cooking
process ends.
The display shows "12.00". There was a power cut. Reset the clock.
Service data
If you cannot find a solution to the problem
yourself, contact your dealer or an Authorised
Service Centre.
The necessary data for the service centre is on
the rating plate. The rating plate is on the front
frame of the appliance cavity. Do not remove
the rating plate from the appliance cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
ENVIRONMENTAL CONCERNS
Recycle the materials with the symbol . Put
the packaging in applicable containers to
recycle it. Help protect the environment and
human health and to recycle waste of electrical
and electronic appliances. Do not dispose
appliances marked with the symbol with the
household waste. Return the product to your
local recycling facility or contact your municipal
office.
20 www.zanussi.com
*
