Zeal-All ZA-POS19A2L User manual

ZA-POS19A2L Motherboard
User Manual
Support Intel J1900 2.42GHz Processor
®

ZA-POS19A2LMotherboard Diagram

尺寸：170mm x 170mm 板形结构
中央处理器
图形显示
芯片组
系统存贮器
前置I/O接口
后置I/O接口
BIOS
板载 MINI_PCIE
板载 LAN
板载音效芯片
操作系统
系统监控和管理
板载串行SATA
工作环境湿度
工作环境温度
Intel HD Graphics
J1900
1个DDR3内存槽,1066/1333/MHz最大支持8GB
2组USB排针支持3个USB2. 0
1个系统风扇连接器
1个CPU风扇连接器
1个SATA接口
2组LVDS排针(可选EDP和LVDS屏)
2个COM排针(可选4个COM接口)
1个4Pin ATX 电源输入接口
1个LPC打印接口
1个COM 接口
1个VGA 接口
3个USB2.0
1个USB3.0
1个LAN 端口
1个PS/2 鼠标+键盘接口
1个音频输入输出接口
1个MINI-PCIE(支持MSATA)
1个SATA接口,1个SATA插槽，1个WiFi插槽
1个Realtek 8111E,10/100/1000以太网控制器
ALC662 2声道输出
Windows7
Windows8
Linux
网络唤醒
电压管理
智能温控风扇
系统电源管理温度管理
0%～95%（相对湿度，无冷凝）
-10°C～55°C
支持 Intel J1900 2.42GHz 处理器
AMIBIOS 64Mbit 闪存
Motherboard Specification

Motherboard I/O Interface Diagram
MSATA
CPU_FANSATA2
DDR3
COMA
FUN1 LPT VGA2
CFPA
FUSB1
FUSB2
SYSFAN
MSATA2
LVDS
LVDSP
WIFI1
INVERT
LPC
COM2
FUN2
FP1
LPT1 VGA USB2.0 LAN
USB2.0
Mic/Lineout
PS2
MS/KB
ATXPWR1
JSP2

SYS_FAN
CPU_FAN
JSATA1-2
SATA 2
+5V 2. GND 3.GND 4.+12V
USB3.0
USB3.0
DDR3
Note: these fan connectors are not jumpers, and the jumper cap is placed above the head.
Installation memory:
1. Please turn off the power before installing or removing the
memory, and dial down the AC power cord.
2. Carefully hold both ends of the memory stick, and do not touch
the metal contact above.
3. Align the gold fingers of the memory stick with the memory stick
slot, and pay attention to the convex point of the gold finger socket
to the upper slot in the direction;
4. Insert the memory stick 30 degrees into the memory slot, and
then press the memory stick down to the sound of "click"
The memory has been installed successfully and can be used
(note: press down the memory bar to avoid damaging the memory
too much)
Memory installation diagram (for reference only) :
Note: static electricity damages electronic components of a computer or memory,
so before following these steps,Be sure to touch the grounded metal objects briefly
to remove static electricity from your body.

LAN
FP1
1
3
5
7
9
2
4
6
8
HDD LED+ PWR LED+
HDD LED- GND
GND
RESET_GND
P_SWIN
GND
GND
HDD Actiuve LED:1,3 Power Button:6,8
Power LED:2,4 Reset Button:5,7
SPK1
1
3
2
4SPKOUT_R+
SPKOUT_R-
SPKOUT_L+SPKOUT_L-
VGA
1
3
5
7
9
11
2
4
6
8
10
12
GND VGA_VSYNC
VGA_HSYNC GND
VGA_RED
VGA_GRN
GND
VGA_BULE
DDC_DATA
GND
GND
DDC_CLK
Define DefinePinPin
Define DefinePinPin
Define DefinePinPin

LVDS1
1LCDVDD 2 LCDVDD
3LCDVDD 4GND
5GND 6GND
7LVDSA_DATA0N 8 LVDSA_DATA0P
9LVDSA_DATA1N 10 LVDSA_DATA1P
11 LVDSA_DATA2N 12 LVDSA_DATA2P
13 GND 14 GND
15 LVDSA_CLKN 16 LVDSA_CLKP
17 LVDSA_DATA3N 18 LVDSA_DATA3P
19 LVDSB_TX0N 20 LVDSB_TX0P
21 LVDSB_TX1N 22 LVDSB_TX1P
23 LVDSB_TX2N 24 LVDSB_TX2P
25 GND 26 GND
27 LVDSB_CLKN 28 LVDSB_CLKP
29 LVDSB_TX3N 30 LVDSB_TX3P
FUSB1
INVERT
1 2
3ON/OFF 4ADJ
GND GND
12V 12V
5 6
or or
PIN 1-2 Close: PIN 3-4 Close: PIN 5-6 Close:
3V 5V 12V
1
2 4
3
6
5 1
2 4
3
6
51
2 4
3
6
5
FUSB1
12
34
56
78
910
VCC VCC
DATA 0- DATA1-
DATA1+
GND GND
NC(CUT) GND
DATA0+
CFPA
1
3
5
7
9
2
4
6
8
10
PROT1L SENSE1_R
AGND SENSE_S
PROT1R
PRESENCE#
NC
PORT2R
PORT2L
SENSE2_R
Define DefinePinPin
Define DefinePinPin
DefinePinDefinePin
DefinePinDefinePin

Mic-in/Line-out
*Other Matters Please consult the sales.
