Zedbed Z-PEDIC User manual

FOR A BETTER QUALITY OF LIFE
Zedbed – 2014
WARRANTY
USER GUIDE
MAINTENANCE

TABLE OF CONTENTS
Safety Instructions ................................................................................................1
Contact Zedbed ................................................................................................... 2
Installation guide ............................................................................................3-4-5
Synchronizing Two Zedbed adjustable bed systems ...........................................5
To Un-Synchronize two Zedbed adjustable bed systems ....................................6
Electrical Specications ........................................................................................6
Troubleshooting ...................................................................................................7
Warranty .......................................................................................................8-9-10
How to le a service request .........................................................................10-11
Power outage......................................................................................................11

1
SAFETY INSTRUCTIONS
Please read all of the instructions before using your ZEDBED adjustable bed system.
IMPORTANT! Always disconnect the power source to your Zedbed adjustable
bed system before performing any service, maintenance or repair.
1. The Zedbed system is meant to be used only for the purposes as described
in this user’s guide. Do not use any parts that have not been recommended
by the manufacturer.
2. Do not use the Zedbed system if the wires, extension cords or wall plugs
have been damaged or if the Zedbed system is not operating as usual. Do
not use the system if it has come in to contact with water or if it has been
damaged. Please contact your retailer for instructions on their return policy
and how to book a service call.
3. Please make sure children are well supervised if they are on or around the
Zedbed system.
4. The head portion of the Zedbed system has independent movement, we
recommend you make sure no children or pets nd themselves underneath
this area when in use.
5. Do not use outdoors.
6. Keep all wires away from any heat source.
7. Do not operate when aerosol (spray) products are being used or where
oxygen is being administered.
8. If you are subject to any condition involving the use of medical products,
and/or if you are under a health professional or physician’s care, please
contact them before using this product.
9. If the product is defective, please contact your retailer to inquire about their
return procedure and how to set up a service call.

2
CONTACT ZEDBED
Please contact us by mail, email or by phone to receive more information on
your Zedbed adjustable bed system :
Zedbed Customer Service
5352 Burrill Street, P.O. Box. 21066
Shawinigan (Quebec)
G9N 8M7
Visit us at : www.zedbed.com
Send an e-mail to : [email protected]
Or call us Toll Free at : 1-866-533-1151 ext. : 226
A copy of this manual is
available on our Web site :
www.zedbed.com

3
INSTALLATION GUIDE
HOW TO INSTALL THE BED LEGS
• Flip over the entire Zedbed adjustable bed system, you should be able to
see the motor when you do this. Once you have ipped the bed around
please remove from their packaging the legs, the power cable, the remote
and the foot end rail (depending on your model). You will want to make
sure everything is well connected.
• For models with metal legs you will need to select the desired height. You
will have a choice of 4 height options: for 1.5” you will only need to use
part A. For 2.5” you will need to thread part A into part B. For 6.5” you
will need to thread part A with part C. For 8.5” you will need to thread
together part A, part B and part C. ATTENTION part A must ALWAYS be
used.
• You will have 4 legs in total that will need to be screwed into the Zedbed
system making sure that there is no visible gap between the metal base
and the legs. No tools are required for assembly.
• After the instructions above have been done you will need to ip the
Zedbed system so that it is resting on the legs (back to its original
position). Now it is ready to be paired with the mattress.
A B C

4
ATTENTION
• For all models sold with a wood foundation, please make sure to align the
“HEAD” of the wooden base with the “HEAD” of the Zedbed system. This
is very important.
• Make sure no wire is caught between the Zedbed system and the wooden
foundation or any other bed component.
• When ipping the Zedbed system onto the legs, please ensure that you do
not bend the legs or apply pressure to the legs. Please see picture below.
Do not apply pressure
or bend the leg.
To avoid damaging
the adjustable base
always open the box
when the Zedbed
system is resting
at on the oor.

5
INSTALLING THE FOOT RAIL
• Install the rail at the foot of the bed. You only need to slide the rods in the
“U” shaped clips. See the circle in the image below for more information.
Connecting your adjustable bed
• Plug the 110V wire cable in the wall outlet.
Installing your mattress
• Simply install the mattress on the bed.
SYNCHRONIZING TWO ZEDBED
ADJUSTABLE BED SYSTEMS
1. For two Zedbed systems that need to be synchronized, you will have two
adjustable bases of the same size each with their own respective wiring
components.
2. Position the two beds so that you may begin to connect the synchronization
cables together.
3. Under one of the two Zedbed systems you will notice that the remote
receiver cable is not connected, this is normal and important that YOU DO
NOT CONNECT IT if you have selected the synchronized option.
4. Connect both systems to your wall outlets. It is important that both systems
are connected in order to have full power for each system.
5. At any time your Zedbed systems can be unsynchronized, however it is
important to note you will require two separate mattresses.

6
ELECTRICAL SPECIFICATIONS
IN : AC 100V/110V – 50/60Hz – 1.6A
OUT : DC 29V – 2A
In case of a power surge, the transformer is equipped with a device that will stop
the bed from functioning. You will need to let the unit rest for a few minutes
before it begins to function again.
TO UN-SYNCHRONIZE TWO ZEDBED
ADJUSTABLE BED SYSTEMS
1. Disconnect both systems from the wall outlets.
2. Disconnect the 2 cables that are connected to both units.
3. Flip the units so that you may access the electrical components.
4. You need to connect the remote control receiver cable into the motor of
the unit where the remote control receiver was not connected to the motor
but you must rst disconnect the cable that is plugged in, this will no longer
be used.
5. Connect one of the two beds to the wall outlet. You will hear a signal (beeping).
6. Take one of the remotes and hold the two top buttons (the rst button of
each column) until the beeping is continuous and then stops. The remote
will now work for this Zedbed system.
7. Redo step #5 and #6 again for the 2nd Zedbed system.

7
TROUBLESHOOTING
Please refer to “warranty” section of this guide for service.
• Before contacting our customer service department, please make sure that
the wall outlet is now working order. Plug in another item (i.e. table lamp)
to verify.
In the case where a technician is sent to your house and
the issue is due to malfunction of wall outlet,
a charge of 75$ will be billed to you for the visit.

8
WARRANTY
You are now the proud owner of a ZEDBED.
For a better QUALITY OF LIFE.
The experts at ZEDBED invest their talent and know-how to manufacture one of
the best adjustable beds in the North-American market. Manufactured with only
premium quality components, Zedbed is a highly innovative and technologically
advanced product that incorporates a rened design and provides excellent
comfort.
We ask you to take a few minutes to review the installation procedures and our
warranty policy guidelines. There is also important information relating to your
new Zedbed system.
This limited warranty is only valid for its original owner and cannot be sold, given
or transferred in all or in part to a subsequent buyer or owner of the product.
Repairs or replacement of parts under the present warranty do not extend the
duration beyond it’s original expiration date.
Zedbed Warranty Scale
ZEDBED Components Free repair or
replacement period
Remote control
Electronic components
Massage features
Motor
Iron mechanism
2 years
2 years
2 years
5 years
20 years

9
WHAT DOES THE WARRANTY COVER ?
The warranty covers all manufacturers’ defects as well as the components.
Repairs or replacement of parts under the present warranty do not
extend the duration beyond it’s original expiration date.
WHAT DOES THE WARRANTY NOT COVER ?
This guarantee does not apply to :
• the fabric cover ;
• noise related to the articulation of the unit ;
• if the system is not properly supported. Please refer to this chart for
approved support according to your model :
Z-PEDIC Z-MOTION 900 9000 CUSTOMZ/
WALLHUGGER Z-PEDIC
WITH LEG
BASE X
METAL BED
FRAME X X X X
PLATFORM
BEDS WITH A
SLAT SYSTEM
XXXXX
ZEDBED BASE
WITH LEG X X

10
This warranty will be void if :
• the ZEDBED product is obtained elsewhere than at an authorised ZEDBED
retailer ;
• when inspected by a ZEDBED accredited technician, the ZEDBED product
incorporated one or more foreign components, not approved by Zedbed ;
• if the adjustable bed has spots and/or stains and/or is burned ;
• after sale service has been done by someone not authorized by Zedbed or
its retailers ;
• the product is used for commercial use ;
• there is evidence of inadequate or abusive usage of the adjustable bed.
NEVER SIT ON THE HEAD OF THE BED WHEN IT IS LIFTED. The bed is
made for a maximal weight of 600 pounds (1 motor) and 1000 pounds (2
motors), INCLUDING the mattress ;
• the product is exposed to excessive heat and/or humidity ;
• the product has been used with a power bar that has caused the motor
and/or remote to have a power surge and stop working.
HOW TO FILE
A SERVICE REQUEST
• Should you notice some defects, please contact your authorised ZEDBED
retailer.
• You shall be required to present a proof of purchase with the transaction
date.
• Corporate and judicial labels must be intact in order to certify the model.
• Do not send the bed to be repaired without the authorisation of an
authorised ZEDBED representative.

11
HOW TO FILE
A SERVICE REQUEST (CONTINUED)
• Your Zedbed system (adjustable base) or other Zedbed components will
be repaired or replaced by the manufacturer’s discretion. Freight and non-
warrantable parts are not covered.
• If identical components are not available at the time of repair or
replacement, the manufacturer reserves the right to substitute the
components for equal or better quality.
• Repairs or replacement of the adjustable bed or other components do not
prolong the existing warranty.
• With the exception of the warranty explained in this approved document,
all other warranties put forward by any verbal communication or by a
physical person shall be considered void.
• This warranty is valid only for the initial buyer and is effective at the
purchase date.
POWER OUTAGE
Your adjustable base has one (1) emergency power cycle in case it is in an upward
position during a power outage.
NOTE : the emergency power supply is designed for a single use. You need to
replace the batteries once it has been used to lower the bed.
