Zener ECODRIVE 8000 User guide

SW08024 Application Guide
PID Irrigator Control
ZENER 8000

Application SW08024: PID Irrigator
Page 1 Document: IM00160A 15/07/19
Important Warnings:
ALL PROTECTION PROVIDED BY THE ZENER 8000 IS FOR OPERATIONAL PURPOSES ONLY. SEPARATE
INDEPENDENT METHODS MUST BE EMPLOYED TO PREVENT ECONOMIC LOSS.
THIS EQUIPMENT CONTAINS HIGH VOLTAGE AND REMAINS CHARGED FOR A PERIOD AFTER POWER IS
REMOVED. ALWAYS ALLOW 15 MINUTES FOR COMPLETE DISCHARGE AND CHECK FOR THE PRESENCE OF
AC OR DC VOLTAGE BEFORE ACCESSING MOTOR PHASE TERMINALS, WIRING OR INTERNAL
COMPONENTS.
Check List: What information you need to know
1. What is the motor nameplate Full Load Current ? __________Amps
2. What is the motor nameplate RPM ? __________rpm
3. What is the desired operating pressure (in psi) ? __________psi
4. What is the maximum system pressure allowable (in psi) ? __________psi
5. What is the transducer’s pressure rating (ie. @ 20mA) ? __________psi
6. What is the minimum operating speed of the pump (= X% of 50Hz) ? __________Hz
Product Support
www.zener.com.au/support-8r.php
Reference Manual
www.zener.com.au/images/im00140.pdf
PID Irrigator Application Guide (this document)
www.zener.com.au/images/im00160.pdf

Application SW08024: PID Irrigator
Page 2 Document: IM00160A 15/07/19
Commissioning Overview
Each step must be completed in order shown before proceeding to the next. Before proceeding to power
the ZENER 8000 and operating the pump, check all wiring is correct and that the pump and plumbing
system is in a state fit for operation. If any parameters are changed it is important to ‘save changes’ when
prompted exiting the menu.
Preparation:
1.
Read all safety instructions & warnings
Refer to the installation manual
2.
Install as per instruction manual and this
‘Application’ guide
Refer to the installation manual and Page 4
of this guide
3.
Read this application guide carefully and ensure
it meets your requirements
Go to page 3
4.
Familiarise yourself with operating the ZENER
8000 and application menus
Go to page 5 to 11
Preliminary Checks:
5.
Load the application & adjust initial parameters
Go to Page 7
6.
Operate in local mode to check direction
Go to Page 11
7.
Check pressure transducer feedback
Go to Page 11
Operational Check &Fine Tuning:
8.
Operate in remote mode and check PID.
Calibrate PID if required
Go to Page 12
10.
Check & calibrate ‘PIPE FILL’ if required
Go to Page 14
11.
Check overall operation and protection
12.
Save ‘Custom Defaults’ and/or record settings

Application SW08024: PID Irrigator
Page 3 Document: IM00160A 15/07/19
Application Overview
Part Number: SW08024
App Group: Standard
Description: PID Irrigator Control
Menu Text: PID Irrigator
Compatibility: ZENER 8000 Firmware 5.2.13 or later
Application Guide: IM00160
What is a ZENER ‘Application’?
An ‘Application’ is firmware that aims to simplify wiring, programming and the
commissioning of ZENER 8000. An ‘Application’ programs the drive and creates new
user friendly menus with the essential settings. This eliminates timely setups, the
reading & interpretation of complex manuals and ensures all critical protection is
installed & set up correctly. There is generally no reason to program additional
parameters unless there is a variation to the intended operation of this ‘Application’.
PID Irrigator Application Summary:
This application provides an advanced PID Pressure Control System using an external pressure transducer. The
ZENER 8000 will maintain a constant pressure with changing water consumption requirements.
1 of 4 user configured set points provides the pressure for the system to maintain. As the pressure changes the
ZENER 8000 automatically adjusts the speed to ensure constant pressure is maintained.
When demand decreases the drive will reduce speed to reduce pressure accordingly. As the flow & speed
reduce the load (current) also reduces. If the installed flow switch detects “no-flow”, the ZENER 8000 will stop
pumping and await reset.
A ‘Pipe Fill’ feature is available to run at a set speed during filling then automatically changeover to PID mode
when the set pressure is reached.
ZENER 8000 protection for the pump & motor:
i. Motor Overload protection
ii. Output Short Circuit protection
iii. Loss of transducer signal
iv. High Pressure Pulse Protection
v. Pressure Out of Regulation Protection
vi. Optional Low Bore level protection
vii. Optional No Flow protection

Application SW08024: PID Irrigator
Page 4 Document: IM00160A 15/07/19
System Requirements:
1. ZENER 8000 with the Application: “PID Irrigator”fitted with an extended features board (AF08001).
2. A pressure transducer and a pressure gauge (for calibration purposes) located between the pump and
any discharge valves.
3. A 4-20mA pressure transducer. However different devices can be used by varying the appropriate
parameters.
4. Non return valves may be located as determined by the application. Their location does not affect
pressure regulation.
5. The motor & pump are in good working order.
6. The “HI PRESSURE” trip and “PRESSURE ERR” trip are for operational purposes only. Separate and
independent methods must be employed to prevent economic loss. A pressure relief valve is
recommended.
7. Optional control input available for ‘Bore level’. External level sensing device required.
8. Optional control input available for ‘Flow Switch’. Closed contact indicates flow.

Application SW08024: PID Irrigator
Page 5 Document: IM00160A 15/07/19
Control Wiring:
Note: All control wiring should be screened.
*************************************************************************
Ensure the ZENER 8000 is in local mode (remove link in terminal 5) to prevent
operation while programming and performing preliminary checks.
NOTES:
1. If the optional ‘Flow switch’ is not installed, a bridging link must be fitted. i.e. +5V D3(35)
2. If the optional ‘Low Bore Level’ switch is not installed, a bridging link must be fitted. i.e. +5V D4(37)
3. The set up supports several run wiring methods. As shown in the diagram above these include:
“START/STOP” with pushbuttons, “RUN/Stop” and “Power Up /Start Up”.
ZENER 8000
Main Control PCB
1
2
3
4
5
6
7
8
9
+5V
D1 (/RESET)
D2 (~STOP)
D4 (REMOTE)
D3 (FWD&LATCH)
ENABLE
COM
SCN
Vref
Extended Features Card (LHS)
31 D1
33 D2
35 D3
37 D4
39 DO+
41 DO-
32 AI+
34 AI-
36 AO+
38 AO-
40 TH+
42 TH-
43 +
44 -
- +
4- 20mA
Pressure
transducer
Low Bore Level (OPEN)
(Optional; note 1)
Flow Switch (CLOSES with flow)
(Optional; note 2)
Stop Start
(note 3)
1 2 3 4 6
Run/Stop
(note 2)
1 2 3 4 6
Power Up Start Up (note 2)
1 2 3 4 6
Remove this link to
operate the
motor/pump using
local controls to test
direction.
Selector 1 Input
Selector 2 Input
Selector 2
Selector 1
Required Pressure
Open
Open
Pressure Ref 1
Open
CLOSED
Pressure Ref 2
CLOSED
Open
Pressure Ref 3
CLOSED
CLOSED
Pressure Ref 4

Application SW08024: PID Irrigator
Page 6 Document: IM00160A 15/07/19
Operation Displays
The operational displays show the operating state of the ZENER 8000. The operational displays include: Speed
/ Reference Display, Meter Display, PID Display, PID / Meter Display and kWhr / Hours Run Display. Press
(ENTER) to step through each display.
Speed / Reference Display
The top line displays the operating output frequency
and the second line displays the speed reference and
the drive status
Meter Display
The top line displays the operating output frequency
and power and the second line displays motor load and
output current.
PID Display
The top line displays the process variable (PV) with its
units and the second line displays set-point variable
(SV) expressed with the same units.
PID / Meter Display
The top line displays the operating output frequency
and process variable (PV) and the second line displays
output current and motor speed.
kWhr / Hours Run Display
The top line displays the kWhrs consumed by the motor
and the second line displays accumulated running time
of the motor
Display Messages
Message
Meaning
REM
REMOTE MODE: Start/stop control from digital inputs.
LOC
LOCAL MODE: Start/stop control from local console.
PID-A ON (OFF)
PID ON (or OFF): PID controller is operating or not.
FWD or REV
Forward or Reverse direction selected from local console or Digital inputs or internal
logic.
PV-A OOR
‘Out of Regulation’: A warning that PID is operating and the PV is not equal to the SV.
-DRY-
Bore level switch is indicating a low bore and/or in the timeout period before
restarting.
Filling
Pipe Fill Mode is active. When set pressure is reached will switch to PID mode.
Fill T/out
Warning: The fill time has lapsed and pressure has not reach required level
Refer to the installation manual for a full list of warnings
(Meter Display)
(PID Display)
(PID / Meter Display)
ENTER
ENTER
ENTER
ENTER
ENTER
(Speed / Reference Display)
(kWhr / Hours Run Display)





35.0 Hz
35.0 FWD
LOC
35.0Hz 100.0psi
0% 750rpm
0 kWhrs
0 hours
35.0Hz 6.1kW
0% 8.0A
P
V100.0 psi
S
V100.0 PIDO N

Application SW08024: PID Irrigator
Page 7 Document: IM00160A 15/07/19
Loading an Application:
Loading an Application will program the drive for you
and create a unique menu with the parameters you
need to adjust.
If ‘APPLICATION <NONE>’is displayed this means there
is no Application loaded.
If ‘APP: PID Irrigator’is displayed this means this an
application has been loaded. The application will be
displayed.
To remove an unwanted application, see the section
“Removing an Application” below.
To load the application:
Removing an Application:
Factory defaults must be restored to prepare
the ZENER 8000 for application loading. To
restore defaults follow the procedure below.
Application
<NONE>
A00 DEFAULTS
ESC
ENTER
&
DOWN
Application
<NONE>
ENTER
PRESS ▼DOWN TO FIND THE DESIRED APPLICATION
PID Irrigator
Config (default)
OR
Application
PID Irrigator
Load factory
defaults?
a
PID Irrigator
User Menu
ESC
ENTER
ENTER
CAUTION MAY START WITHOUT
NOTICE CHECK WIRING. CONTINUE ?
ENTER
Load Complete ?
Press ESC and ENTER to SAVE CHANGES when prompted.
Power Down the ZENER 8000 completely and then
REPEAT the procedure to load the application.
ENTER TO SELECT & LOAD
This will take you direct to the ‘CONFIG MENU’.
Go to page 9
a
A00 DEFAULTS
CONTINUE WITH
FACTORY DEFAULTS
▼DOWN
NOTE:
To restore defaults the ZENER 8000 must not be
in REMOTE mode. Remove terminal 5.
This should be performed in LOCAL MODE as
the pump may run. (Remove link in terminal 5)

Application SW08024: PID Irrigator
Page 8 Document: IM00160A 15/07/19
Application ‘CONFIG’ & ‘USER’ Menu:
There are now 2 additional menus with this application, a ‘CONFIG MENU’and a ‘USER MENU’.
Always remember to press ‘ENTER’ when
prompted to save changes.
Do not remove power while saving!!
Pressure Ref 1
100.0 psi
ESC
ENTER
PID Irrigator
config (default)
A00 DEFAULTS
ESC
ENTER
&
DOWN
ENTER
CONFIG MENU
The ‘CONFIG MENU’ is created for initial
setup. This can be found in the A00 DEFAULT’
Menu and has all the parameters required.
General access to this menu can be locked
out.
USER MENU
The ‘USER MENU’ is created for the operator.
In this application it provides access to the ‘Set
pressure’ only. Access to other settings can be
locked out.
PID Irrigator
user menu
PARAMETERS IN MENU:
Pressure Ref 1
Pressure Ref 2
Pressure Ref 3
Pressure Ref 4
Pressure Tol.
Pressure Q time
Low Bore Timeout
No flow Q time
PARAMETERS IN MENU:
Rated motor amps
Overload current
Motor RPM
Transducer units
Transducer scale
Pressure Ref 1
Pressure Ref 2
Pressure Ref 3
Pressure Ref 4
Pressure Tol.
Pressure Q time
Low Bore Timeout
No flow Q time
Hi Pressure Lvl
Minimum Speed
Pipe Fill
Fill Speed(Hz)
Fill to Level
Fill Time(s)
ENTER to edit
and
ENTER to save
changes
SAVE CHANGES
ENTER=YES ESC=NO
ENTER
ESC
“WHEN EXITING MENU”
PID Irrigator
user menu
DOWN
Rated Motor Amps
20 Amps
DOWN

Application SW08024: PID Irrigator
Page 9 Document: IM00160A 15/07/19
CONFIG MENU Parameters:
After loading the application the CONFIG MENU will appear. Modify the following parameters. If the CONFIG
menu does not appear read page 8.
Ensure the ZENER 8000 is in local mode (remove terminal 5) to prevent unexpected operation.
Initial parameters to adjust:
Parameter
Default
Explanation
1.
Rated Motor Amps
?? Amps.
Enter Motor nameplate full load current.
2.
Overload Current
?? Amps.
Enter Motor nameplate full load current.
3.
Rated Motor rpm
1470 rpm
Enter Motor nameplate speed in rpm.
4.
Transducer units
“psi”
Select the desired pressure units.
5.
Transducer Scale
200.0
Enter the rating of the pressure transducer at 20mA, in psi
6.
Pressure Ref 1
100 psi
Enter the desired operating pressure when this reference is
selected.
7.
Pressure Ref 2
100 psi
Enter the desired operating pressure when this reference is
selected.
8.
Pressure Ref 3
100 psi
Enter the desired operating pressure when this reference is
selected.
9.
Pressure Ref 4
100 psi
Enter the desired operating pressure when this reference is
selected.
10.
Pressure Tol.
25%
Enter the tolerance of pressure from the reference as a
percentage of the transducer pressure scale
11.
Pressure Q time
30 sec
Enter the out of tolerance time to register “PRESSURE ERR”
12.
Low Bore timeout
0 sec
Leave at 0 sec for the moment.
This feature requires an external bore level switch. Link
terminal 1 to Terminal D4(37) if no bore level switch
installed.
Enter the time to restart after the ‘Low Bore’ switch-
contact returns to the closed position. “-DRY-” is
displayed during the timeout period.
Motor Rated Amps
22.0Amps
PID Irrigator
config (default)
ENTER
PRESS ▼TO STEP THROUGH APPLICATION PARAMETERS
PRESS ENTER TO EDIT AND SAVE CHANGES

Application SW08024: PID Irrigator
Page 10 Document: IM00160A 15/07/19
Parameter
Default
Explanation
13.
No Flow Q time
20 sec
Enter the out of tolerance time to register “No Flow”
This feature requires an external no flow switch. Link terminal
1 to Terminal D3(35) if a flow switch is not installed.
14.
High Trip Level
180 psi
Adjust if required .Adjust level for ‘high pressure’trip (in psi).
The trip time (default 0 seconds) can be adjusted in another
menu if required (Refer to User Alarm 4).
15.
MIN Speed (Hz)
0 Hz
Leave at 0Hz (or minimum pump speed) to check pump
rotation. This should be at least the minimum operating
speed for the pump. Eg. 30Hz. When started, the pump will
run to this speed.
16.
Pipe Fill
OFF
Leave OFF for the moment. Pipe fill mode runs the pump at a
fixed speed until the pipes fill and the pressure begins to
build. When the ‘Fill to Level’ pressure is reached it
automatically switches to PID mode. Select ‘PV Threshold’
for pipe fill based on pressure.
17.
Pipe Fill Speed
(Hz)
40 Hz
Leave for the moment. This is the operating speed for pipe fill
mode
18.
Fill to Pressure
80.0 psi
Leave for the moment. This is the pressure level to change
from Pipe Fill to PID mode
19.
Fill Time
40 sec
Leave for the moment. This is the time period for the pipe fill
to reach pressure.
When back to the beginning (first parameter ‘Rated Motor Amps’), press ESC until:
PID Irrigator
config (default)
ESC
A00 DEFAULT
ESC
SAVE CHANGES
ENTER=YES
ENTER
PV 0.0 psi
SV 100

Application SW08024: PID Irrigator
Page 11 Document: IM00160A 15/07/19
Preliminary Checks
The following should be performed with the ZENER 8000 in local mode to provide better control to carry out
the checks. Ensure the motor, pump and plumbing is ready and safe to operate.
To operate in local mode:
Remove the link in terminal 5, this
selects local mode.
REM= REMOTE OR PID MODE [Control using terminal inputs]
LOC = LOCAL MODE [Control using push buttons]
Top display: Actual Speed in Hz (50Hz = full speed)
Bottom Display: Set speed
Press FWD/▲to start
Press FWD/▲to increase the speed
Press STOP to stop the pump
Note: If there is a minimum speed set it will go straight to that
speed. To increase above this speed you will need to hold down the
UP button until it goes above the minimum speed setting.
Check motor/pump direction:
Press FWD/ ▲to start and increase the motor speed sufficient to test the direction. The ZENER 8000 will run
to the minimum speed. Use the ▲to increase the speed above the minimum speed level.
If the motor shaft or pump rotates in the wrong direction, remove the input power, wait for the ZENER 8000 to
discharge and swap any two motor phase wires. Re-apply input power and recheck direction
Check pressure transducer feedback:
Press FWD/ ▲to start & increase the motor speed until the desired operating pressure is indicated on the
pressure gauge. Press(ENTER) to scroll through the operator displays (see page 5) to the PID display shown
below.
Check that the top display (PV) is displaying the
correct pressure as per the pressure gauge.
The service menu can be used to display the
mA being received from the transducer. If this
is not within acceptable tolerance, investigate
and rectify.
Check the motor & pump are adequate and operating correctly.



ESC
EXIT
C
FWD
REV
ENTER
STOP
25.0 Hz
35.0 FWD LOC
ZENER 8000
Main Control PCB
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
+5V
D1
D2
D4
D3
EN
COM
SCN
Vref
+IN
-IN
Remove the link into terminal 5 to operate
motor/pump using local controls to test direction
=
P
V100.0 psi
S
V100.0 psi FWD LOC

Application SW08024: PID Irrigator
Page 12 Document: IM00160A 15/07/19
Checking the PID operation
Ensure the system is ready to pump and discharge valve is open for flow required. Re-install the wire
in terminal 5 to operate in Remote/PID Mode and apply power to the ZENER 8000.
Find the PID display to monitor the performance:
Check the following:
1. Start the system as intended.
2. The ZENER 8000 operates and stabilises at a speed where the PV = SV.
3. The pressure (i.e. PV) indicated on the ZENER 8000 is correct with reference to the gauge. If
not correct turn the pump off and investigate.
4. Check that the control is stable and responds as desired to changes in set point. Refer to PID
tuning guide if unstable. These parameters are found in the following menu:
5. Check pressure regulation with all combinations of equipment connected to the discharge
port.
6. Check to see that pressure is maintained and the system responds acceptably. Refer to tuning
guide if response is slow or over shooting occurs.
H00 PID CONTROL
PID Irrigator
User menu
ESC
DOWN
ENTER
PID-A Controller
ENTER
H01 Prop Band
200 %
ENTER
TO
EDIT & SAVE
DOWN
H02 Integ. Time
2.00 sec/r
DOWN to “Diff Time”
P
V0 psi
S
V75 PID ON
Process Variable is the pressure feedback from the transducer
Set Point Variable is the desired operating pressure
Operating Status: Refer to Page 6
PID ON = Pressure control active
OOR = a warning only that the PV is a set % from the SV
-DRY- = Low Bore input or time out period is active

Application SW08024: PID Irrigator
Page 13 Document: IM00160A 15/07/19
PID Tuning Guide
The Proportional gain: amplifies the difference between the set point reference and feedback signals. The H01
Prop. Band value is the proportion of input required to generate 100% at the output of the PID control. For
example H01 Prop. Band is 200.0%, the proportional gain is 100/200 = 0.5. That is 2 units of input will generate
1 unit of output. The higher the % value, the lower the ‘proportional gain’.
The integral time: The integral action adds a corrective component to reduce a constant error difference
between set point and feedback signals. The greater the error, the quicker the gain increases. The H02 Integ.
time value sets the time to ‘repeat’ the error difference between set point and feedback signals - This assumes
the Proportional gain is equal to 1.
A low H02 Integ. time value attempts to regulate the process variable quickly. However if excessively low, over
shooting and under shooting will be more prominent.
A high H02 Integ. time value diminishes over shooting and under shooting. However regulation takes longer to
achieve.
Guide to PID Tuning:
The guide below assumes short ramp times. Long ramp times will dominate system
performance and the steps below will have little or no effect.
Step
Problem
Action
1.
The plumbing is set for typical flow
but the system responds too slowly
1.1 Stop the ZENER 8000 & pump
1.2 Halve the value of H01 Proportional band. Avoid adjustments below 10%.
1.3 If H01 Proportional band is below 10% proceed to step2.
1.4 Stop & restart the ZENER 8000 & pump.
1.5 Observe the time it takes to reach pressure (or reacts to changes)
1.6 Repeat from step 1.2 if the response is slow. Otherwise proceed to step 2.
2.
The system starts to overshoot or
oscillate
2.1 Stop the ZENER 8000
2.2 Double the value H01 Proportional band
2.3 Start the ZENER 8000 and observe the time it takes to reach pressure or reacts to
changes
2.4 Repeat from step 2.1 if the system still overshoots or oscillates. Otherwise
proceed to step 3.
3.
The system still responds slowly
(after adjusting H01 Proportional
band )
3.1 Halve the H02 Integral Time
3.2 Observe the time it takes to reach the pressure (or reacts to changes)
3.3 Repeat from step 3.1 if the response is still slow. Otherwise proceed to step 4
4.
The system starts to overshoot or
oscillate
(after initial adjustments to H02
Integral Time )
4.1 Double the H02 Integral Time
4.2 Observe the time it takes to reach the pressure (or reacts to changes)
4.3 Repeat from step 4.1 if the system still overshoots or oscillates
4.4 If the response is acceptable then you may stop tunning

Application SW08024: PID Irrigator
Page 14 Document: IM00160A 15/07/19
Remaining Parameters:
The remaining parameters to implement & adjust if required are:
Pipe Fill:
The pipe fill option allows the ZENER 8000 to operate at a reduced speed to fill the pipes on start. Pipe
fill is only activated when a start/run command is first given.
Pipe Fill DISABLED To Enable, set to ‘PV Threshold’. This will provide an automatic
changeover to PID when a pressure level is reached.
Pipe Fill Speed (Hz) 40 Adjust the speed to operate during pipe fill mode
Pipe Fill Level 80 psi Adjust the level to switch from ‘Pipe Fill Mode’ to ‘PID mode’
Pipe Fill time (s) 40 Adjust to the time required to reach the ‘Pipe Fill Level’ pressure.
Bore Level Timeout:
Low Bore timeout 0 Enter a time period to restart after a ‘Low Bore’ is detected or
install link if a ‘Bore level switch’ is not installed.
This feature requires a bore level switch to be installed.
When an ‘open contact’ is present on input D4( terminal 37) the
ZENER 8000 stops and displays the warning ‘–DRY-’. When the
contact closes there is a delay before the pump restarts.
Note:
1. If no ‘Bore Level switch’ is installed fit a bridging link between terminal 1 and 37.
2. If operated with a start/stop switch the low bore switch will stop the pump and not allow a restart until
the time-out period has lapsed.
Variations & Other Adjustments:
Other parameters may need to be adjusted because:
The setup may vary from the intended application Eg. Use different set point source/reference such as
a potentiometer.
Additional requirements which the application does not include. Eg. An additional alarm for over
current.
Parameters that you may want adjustment include:
Change Ramp Times:
Ramp types: C030 Accel Time & C031 Decel time = ramp time above minimum speed
C032 S-time = ramp time to minimum speed
ESC to Menu> <DOWN>>> C00 PERFORMANCE <ENTER><DOWN>>>C03 RAMP<ENTER to edit><UP/DOWN to select ramp
type>>and<ENTER to save><ESC> (‘ramp time’ is time taken from 0 to 50Hz)
Note: The time entered is the time from 0 –B03 MOTOR Hz.

Application SW08024: PID Irrigator
Page 15 Document: IM00160A 15/07/19
Thermistor Input:
Allows a thermistor input for motor protection into terminals 40 and 42 on the option board. This function
needs to be enabled if required.
ESC to Menu> <DOWN>>> G00 INPUT/OUTPUT <ENTER><DOWN>>>G09 Thermistor<ENTER to edit><<UP/DOWN to select
enable>>and<ENTER to save><ESC>
Set point Variable:
The set point in this application is a preset value. It is possible to alter this to another source such as;
Potentiometer
Multiple speed
Analogue reference signal (0-5V, 0-10V, 4-20mA)
Or other
ESC to Menu> <DOWN>>> H00 PID PARAMETER <ENTER>PID-A Controller<ENTER><DOWN>>>H06 SV Choice<ENTER to
edit><<UP/DOWN>> and <ENTER to save><ESC>
Potentiometer:
To select Analogue input for SV Choice:
ESC to Menu> <DOWN>>> H00 PID PARAMETER <ENTER>PID-A Controller<ENTER><DOWN>>
>H06 SV Choice<ENTER to edit><<Select AI(10,11)>> and <ENTER to save><ESC>
To configure Potentiometer input for 0-5Vdc:
ESC to Menu> <DOWN>>> G00 INPUT/OUTPUT <ENTER> <DOWN>>>Analogue Inputs<ENTER to edit><<Select
AI(10,11)><ENTER><Select 0-5V><ENTER. <ESC>
Others:
For other Set point variable sources refer to the reference manual for details on connection, wiring and the
input parameters required.
Max Hz:
To reduce or increase the maximum speed output.
ESC to Menu> <DOWN>>> C00 PERFORMANCE <ENTER><DOWN>>>C02 MAX Hz<ENTER to edit><<UP/DOWN>>and<ENTER to
save><ESC>
Motor Volts & Hz:
Adjust the output voltage and frequency as per motor nameplate information.
ESC to Menu> <DOWN>>> B00 MOTOR <ENTER><DOWN>>>B01 MOTOR VOLTS <ENTER to edit><<UP/DOWN>>and<ENTER to
save><ESC>
ESC to Menu> <DOWN>>> B00 MOTOR <ENTER><DOWN>>>B03 MOTOR HZ <ENTER to edit><<UP/DOWN>>and<ENTER to
save><ESC>
Adjust Transducer feedback Zero/Span:
If there is a slight error in the PV reading it may be necessary to make minor adjustment to the input signal for
the transducer feedback. Adjust the ‘Ref @ MIN in’ and/or ‘Ref @ MAX in’.
ESC to Menu> <DOWN>>> G00 INPUT/OUTPUT <ENTER> <DOWN>>>Analogue Inputs<ENTER to edit><<Select
AI(32,34)><ENTER><DOWN>G103 ref @ MIN in><ENTER><UP/DOWN to adjust><ENTER to save><ESC>
<DOWN>G104 ref @ MAX in><ENTER><UP/DOWN to adjust><ENTER to save><ESC>

Application SW08024: PID Irrigator
Page 16 Document: IM00160A 15/07/19
Parameters programmed by the Application:
The following parameters are automatically programmed by the ‘Application’ when it is loaded. They are
listed below for reference purposes only.
Application Menu:
1. "Rated motor amps"
B02= ?
2. "Overload current"
D020= ?
3. "Motor RPM"
B04= ?
4. "Transducer units" = “psi”
H08= 1
5. "Transducer scale" = 200psi
H09= 200.0
6. “Pressure Ref 1" = 100psi
F100= 50.0
7. “Pressure Ref 2" = 100psi
F100= 50.0
8. “Pressure Ref 3" = 100psi
F100= 50.0
9. “Pressure Ref 4" = 100psi
F100= 50.0
10. “Pressure Tol." = 25%
H131= 250
11. "Pressure Q time" = 30sec
H132= 30
12. “Low Bore Timeout" = 0sec
G070= 0
13. "No flow Q time" = 20sec
G252= 20
14. "Hi Pressure Lvl" = 180psi
H111=180.0
15. "Minimum Speed " = 0Hz
C01= 0
16. "Pipe Fill" = DISABLED
H120= 0
17. "Fill Speed(Hz)" = 40Hz
H123=40
18. "Fill to Level" = 80psi
H122=80.0
19. "Fill Time(s)" = 40sec
H121=40
Other Preset Parameters
C030= 3.0 //1 sec Accel
C031= 3.0 //1 sec Decel
C032= 1 //1sec Accel & Decel to Min Hz
C033= 1 // Dual ramp
F010= 2 //Remote ref: PID-A Opt
F061= 7 //USER REF1: PRESET1
F062= 8 //USER REF2: PRESET2
F0631=22 //Selector 1: D2(33)
F0630=26 //Selector 2: D1(31)
F1001=1 //PRESET1..4 units: PID-A
F1011=1
F1021=1
F1031=1
G108= 2 //AI(32,34) config: 4 to 20mA
// Pressure Error Trip config
G230= 2 //UA1 active in PID closed loop
G231= 101 //UA1 signal: "PV-A OutOfReg"
G232= 0 //no delay
G233= "UA1:PRESSURE ERR"
// Siganl lost Trip
G106= 2.0 //AI(32,34) cmp lo thresh = 2.0mA
G240= 1 //UA2 trip active with RUN cmd
G241= 64 //UA2 signal: Lo AI(32,34)
G243= "UA2: SIGNAL LOST"
// No Flow Trip config
G250= 1 //Run command
G251= 31 //UA3 signal: ~D3(35)
G253= "UA3: NO FLOW "
// High Pressure Trip config
G260= 0 //UA1 trip always active
G261= 72 //UA1 signal: PV-A OVER
G262= 0 // No time delay on this trip
G263= "UA4: HI PRESSURE"
// Low Bore config
G271=55 //~TMR1
G272=" -DRY- "
G01=7 //Custom
I02=95 //Logic Block 1
I201=10 //D2(3)
I202=54 //TMR1
I203=17 // LB1 logic
G071=2 //TMR1 mode: Delay ON Init
G0720=0 //TMR1 IN2=ON
G0721=34 //TMR1 IN1=D4(37)
// PID config
H01= 200.0,"Prop. band value"
H02= 2.00,"Integrator time"
H06= 15 //PID-A SV: REF SEL
H07= 1 //PID-A PV: AI(32,34)
H102= 1 //Resume: by PV threshold
J02 = 2 //display: PID disp

Application SW08024: PID Irrigator
Page 17 Document: IM00160A 15/07/19
Trouble Shooting Guide:
The following assumes all standard configurations programmed by the Application without any changes.
Symptom
Checks/Remedy
No Application ‘PID Irrigator’ Menu
is present
If you have not loaded the ‘Application’ following the instructions on page 7
If you have loaded the Application and no menu, restore defaults and reload following
the instructions on page 7
Pump running wrong direction
Swap two motor cables on the ZENER 8000 output or at the motor
PV display is 0 when gauge indicates
pressure
Check the application has been loaded. Refer to page 7
Check transducer scale has been entered and is correct.
In the service menu, check analogue input AI(32,34) is reading correct mA
If not reading correct mA, check transducer wiring & polarity
Measure DC mA in transducer wiring
PV reading is not correct
Check transducer scale has been entered and is correct.
In the service menu, check analogue input AI(32,34) is reading the correct mA
Measure & check DC mA in transducer wiring is correct and transducer is operating
correctly
If only a small error may need to adjust AI(32,34) to read correctly
Pump does not start
In the service menu, check digital inputs have ‘1’ on terminals 2,3,4,5 & 6. If a start
push button is used, check it provides a ‘1’ on terminal 4 when pushed. If not, check
input wiring.
Is the ‘SV’ on the display indicating the ‘Set pressure’entered in the ‘Application
Menu’? E.g. 100psi.
Is the PV reading the correct pressure (as per pressure gauge)
If a trip is displayed investigate & rectify. Will need to reset trip.
If pipe fill is enabled, check ‘Pipe Fill Speed’ entered is not 0Hz.
-DRY- is displayed and will not start
Bore level is low
Check bore level switch operating correctly and connections.
If no bore level switch, check bridging link is fitted between terminal 1 and 37.
Pressure does not build up to the ‘Set
Pressure’.
Ensure PV display is correct
Motor/Pump rotating wrong direction. Check & rectify.
If Pipe fill is enabled check ‘Fill speed (Hz)’is not too low. Disable Pipe fill and check
again
If the drive is not running at 50Hz, check motor current in all 3 phases and drive is not
indicating ‘current limit’
If running at 50Hz check pump and plumbing.
PID/ pressure control is unstable
Ensure Pressure Transducer is operating correctly and the feedback (PV) is stable when
the pump is not running and also running in local mode at a fixed speed.
Tune the PID using the parameters and guide on page 12
Current limit is displayed
Check the motor current and the drive is correctly matched to the motor & pump.
Check the current in each motor phase to ensure balanced
Continually in Pipe Fill Mode
Pipe Fill Speed too low, insufficient flow and pressure not reaching pipe fill level.
Problem with pump/motor not increasing pressure to pipe fill level. Check Pump/motor
More Information or Assistance:
For details on all the features and parameters available refer to the ZENER 8000 Reference Manual available on
the ZENER website: www.zener.com.au

ZENER AUSTRALIAN DISTRIBUTORS
New South Wales Queensland
Sydney Regional NSW
Zener Varidrive Solutions Zener Varidrive Solutions Zener Electric Queensland Pty Ltd
366 Horsley Road 1 William Street Unit 23, 28 Burnside Road
Milperra NSW 2214 Maryville NSW 2293 Yatala QLD 4207
Phone: [phone] Phone: [phone] Phone: [phone]
Email: [email protected] Email: [email protected] Email: [email protected]m.au
Western Australia South Australia Victoria
Power Control Products Rototech Pty Ltd Rototech Pty Ltd
Unit 5, 144-146 Bannister Road 34-36 Kinkaid Avenue 23 James Street
Canning Vale WA 6970 North Plympton SA 5037 Clayton South VIC 3169
Phone: [phone] Phone: [phone] Phone: [phone]
Email: [e-mail] Email: m[email protected]m.au Email: [email protected]m.au
http://www.zener.net
©Zener Electric Pty Ltd 2018
