EXPRESS 5800 HX4100/6100 Page 1/11
PRODUCT
MAINTENANCE
RELEASE
BULLETIN
Product Information:
Product Line : Servers
Product Family : Express5800
Product Type: LS2400
Model Name(s) : see below
Market Introduction : June 1998
PMRB Revision : 1.0
PMRB Date : 09 / 07 / 98
EMAIL: [email protected]
Model Identification:
Machine MI Description
LS2400 ISG-5470-HU PPRO 350Mhz, 512KB cache Model 0, NORAM, NOHDD
ISG-5491-XU PPRO 350Mhz, 512KB cache, 128MB/9GB
** = Country codes: AA = Danish, BB = British, CD = Swiss/German, CF = Swiss/French, DD = German, EE = Spanish, FF = French, JJ
= Dutch, NN = Norwegian, PP = Portuguese, SS = Swedish, TT = Italian, TU = Italian /American, UU = Euro/American, YY =
Belgian/Flemish

EXPRESS 5800 LS2400 Page 2/11
Board supports the following features:
DESCRIPTION COMMENTS
CPU Pentium II Klammath 266 L2 cache
Deshutes up to 400MHz L1/L2 cache
Up to 2 with a 100 MHZ BUS
512KB cache ECC
Memory Sockets 4
Memory Sticks DIMM 32/64/128/256
Max. Memory 1GB
Memory type, Speed, ECC SDRAM 72 Pin, 100MHZ, Yes
Incr. Memory 1 Stick, 4 Times
Internal Bays 4
Drive Bays, 5.25” 3
Drive Bays, 3.5” 1
TOTAL DRIVE BAY 8
SCSI Integrated
Ultra-Wide SCSI x 2 ch SYMBIOS
53C876
IDE integrated 2 channels with PIIX4 up to 22 MB/s
RAID Contr. NEC SECURAID 100/ 500 optional
Integrated NIC On board 82558 10/100 PCI LAN
Integrated Graphics CL-GD5480 1280x1024, 16.7M colors
1MB not upgradable
CDROM 24xCDROM 8240B
Expansion Slots 3 PCI
1 PCI/ISA shared
1 ISA
TOTAL Expan SLOT
External I/F CRT,
Keyboard,
Mouse
Serial x 2
EPP Parallel x 1
Rj45 Network
I/F for RAS Board
Yes (SMB Pro(PCI) or SMB Lite (ISA) :
TBI)
Power Supply 260W
Redundant and Hot Swap Power NO
Redundant and Hot swap FAN NO
Hot Swap FAN NO
Dimensions
(H x W x D) ATX
21.54x43.18x45.21cm

EXPRESS 5800 LS2400 Page 3/11
Server supports the following features:
DESCRIPTION FEATURE COMMENTS
CPU
Family Pentium II Klamath
Pentium II Deshutes
Internal frequency 266mhz,
300-400 mhz 2CPU :512KB cache
External frequency 100 MHz Supports 100 MHz
Total # of CPUs 2 CPU The CPU’s must be the same Mhz,
CACHE must be same size and
CPU stepping may be a consideration.
CACHE On CPU Chip No Option Available
Memory
Sockets 4Gold sockets only
Capacity 1GB Supports 1GB using 256MB
Type X72 SDRAM
Data Protection ECC with error logging SDRAM
SCU & BIOS
BIOS Type Phoenix Browse our Web
Languages FLASH Update
Flash 1MB
Graphics
Controller CIRRUS Logic 5480 OS Dependent
BIOS Independent
Bus PCI
Memory 2MB capacity standard 2MB
Resolutions 640x480, 800x600, 1024x768,
1280x1024
Colors
16MEG @ 640x480 & 800x600, 64K
@ 1024x768 & 256 @ 1289x1024
Output Port 15 pin analog
Disk Controllers
SCSI Ultra Wide Symbios53C876
(2 channels) 1 channel : for Internal HDD bays
1 channel : for Internal 5» bays and
CHA A ultra Wide connector
CH B Narrow
IDE 2 Channels
Floppy connector on board
I/O
Slots (Total) 6
Dedicated ISA 1
Dedicated PCI 3One of them is shared with SCSI
Shared PCI/ISA 1

EXPRESS 5800 LS2400 Page 4/11
Server supports the following features (con’t)
DESCRIPTION FEATURE COMMENTS
Ports & Connectors
On Base Board and
Riser Card 1 x Fan headers 1 x FDD interface
2 x SCSI 68 Pin Ultra Wide High
Density cabled to 2 connectors
( A Ultra, B Narrow)
1 x Power Supply
1 x Server management board I/F*
On System IO Board
On System IO Board
On System IO Board
On System IO Board
On System IO Board
On System IO Board
On System IO Board
On System IO Board
On System IO Board
Output Ports
I/O Ports All Located On Riser Card -
Contains the Following:
1 Mouse, 1 Keyboard port, 1 Serial
1 Parallel Port, 1 RJ45
Board
Dimensions
Length / Width ATX format
Real Time Clock National PC87306 I/O Chip
Server Management
Via PIAZZA &
HECETA
SMB Pro or SMB Lite(not fixed)
CPU and Chassis Fan Alarm
Temperature Sensor
Voltage Sensor
Intrusion Detection
SMI
Shut Down
Event Log
SMB Interface(SMB Pro or Lite) è
BMC (Board management)
PIAZZA
HECETA
HECETA
PIAZZA + HECETA
HECETA + OSB2
PIAZZA
PIAZZA + NVRAM
PIAZZA
Hot Swap Backplane
Logging All critical events to on board
non volatile memory ECC Events, Voltage,
Temperature, Fan & Etc.
Ease of Upgrade Easy upgrade of 2nd, CPU,
Main Memory,
(end user, not technician)

EXPRESS 5800 LS2400 Page 5/11
Chassis supports the following features:
DESCRIPTION FEATURE COMMENTS
Rack Mountable Fits into Std. 19”
Rack Frame Side Rails fit both NEC Rittal 19” Rack Frame
(VR383551) and Compaq Rittal 19” Rack Frame
(165753-293)
3.5» Removable Bays
One 3.5» Bays Bay 1 - 3.5” FDD
5.25» Removable Bays
Three 5.25» Bays Supports 5.25” SCSI Devices connected to
Internal SCSI controler
HDD Bays Four SCSI SCA HDD
Device Bays Support 18GB/10Krpm
Power Supplies
Hot - Swap One 260 Watt Power
NO
Cooling For CPU
HDD bays
Add In Board Slots
6ISA, PCI
I/O Ports Riser Card
Switches Power, Reset Labeled on chassis with international icons
Indicators Power, Fault, Activity, NIC
Activities Labeled on chassis with international icons

EXPRESS 5800 LS2400 Page 6/11
Operating System Specific Solutions
NOS specific information is key installation information for those NOS’s covered in the
Configuration Guide.
Utilities
•Express Builder Version 2.1 Setup and Configuration
⇒SYM53C876 DRIVERS
⇒Express5800 LS2400 UTILITIES, SSU
⇒On Line service Manual, user’s Guide
⇒AMI configuration Utilities,
•ESMPro Management Suite Version 1.4
Bios•Express5800 LS2400 Flash PHENIX BIOS (see latest version on WEB)
•User & supervisor passwords supported
•DMI 2.0 capable
MAINTENANCE PLAN:
Under limited warranty, maintenance is performed to the major module assembly level. After
warranty, approved ZDS service organizations can perform maintenance as required. The Field
Replaceable Units (FRU) section of this PMRB lists the major assemblies.
APPROVED SERVICE ORGANIZATION:
Commercial Sales :Approved ZDS Service Centers and Field Engineers.
Contract Sales :Refer to applicable contract.
Zenith Data Systems reserves the sole right to determine, direct, and conduct any and all
factory-authorized reworks or upgrades, including the choice of service providers, based on
quality and cost of provider.
DATE OF FIRST SHIPMENT:
July 1998
TRAINING:
For service training in Europe, contact the Zenith Data Systems or Bull subsidiaries in each
country. A list of subsidiaries and phone numbers may be obtained by
calling ZDS in France at + (33) 1 5523 7200

EXPRESS 5800 LS2400 Page 7/11
MEAN TIME TO REPAIR (MTTR)
At the major module assembly level, 30 minutes.
MEAN TIME BETWEEN FAILURES (MTBF)
20 000 h at 25°C and 40 % R.H.
PREVENTATIVE MAINTENANCE
Clock/Calendar battery replacement at seven years.
SPECIAL TOOLS OR UTILITIES REQUIRED
Full static prevention measures should be taken! Perform all work on a static mat using a wrist
strap. Utilities will be available on the Information Resource Program Technical Support
Bulletin Board until released on the Information Resource ZD-ROM.
Flash-BIOS (Use latest available from WEB)
Diagnostics TESTVIEW ( License required)
9-pin Serial Loopback Connector 438-0073-00
LIMITED WARRANTY:
Three years on site Warranty with high end class conditions.
MANUALS:
It is recommended to keep a copy of the following manuals:
A. Service Manual Ref. : online / Express builder 2.1
B. User Manual Ref. : online / Express builder 2.1
Information:
Zenith data systems standard: +(33).(0)1.5523.7200
Web: WWW.ZDS-EUROPE.COM
ATTACHMENTS:
A. Detailed views
B. I/O board layout
C. Exploded View

EXPRESS 5800 LS2400 Page 8/11
ATTACHMENT A
DETAILED VIEW
Express5800 LS2400 Front & back Views
Front View Side view
Back view I/O board view
Manufacturers names shown are trademarked.
Copyright 1997 Zenith Data Systems Corporation, A division of Packard Bell NEC
NIC
I/O

N440BX Product Guide 11
System Board Connector and Component Locations
Y
D E FA CB
G
J
H
LM
N
O
I
K
W
V
U ST R Q P
X
CC
AA
BB
Z
Pri.
Sec.
OM06957
Figure 2. System Board Connector and Component Locations
A. Secondary processor connector P. Server monitor module (SMM) connector
B. Primary processor connector Q. Narrow SCSI connector
C. Heatsink fan connector R. Wide SCSI connector
D. Diskette drive connector S. Memory sockets for four DIMM components
E. Main power connector T. PCI slots for add-in boards
F. Hard drive LED connector U. ISA slots for add-in boards
G. Front panel connector, 16 pin V. Heatsink fan connector
H. Speaker connector W. USB connector
I. AT front panel connector X. RJ-45 network controller
J. Lithium backup battery Y. Serial port B (COM 2)
K. System fan connector Z. VGA monitor port
L. IDE connectors, primary and secondary AA. Parallel port
M. External I2C connector BB. Serial A (COM 1)
N. Configuration jumper blocks CC. Keyboard and Mouse PS/2 compatible connectors
O. System fan connector

EXPRESS 5800 LS2400 Page 10/11
EXPLODED VIEW
Unavailable Yet

EXPRESS 5800 LS2400 Page 11/11
PARTS LIST
No Description OKIT MODEL Part Number
1MOTHERBOARD 1818970000
5CPU 350 MHZ ECC W/512 UBP-2482-1C-xx 0820570000
7RETENTION BRKT PII 1499770000
8TERMINATOR BOARD 1301520000
10 HEATSINK PII è300Mhz 1499520000
11 HEATPAD PII è300Mhz 1499530000
12 DIMM, 32MB, 100MHz SDRAM Unbeffered AMS-4032-xx-30 0820610000
13 DIMM, 64MB, 100MHz SDRAM Unbeffered AMS-4064-xx-00 0820620000
14 DIMM, 128MB, 100MHz SDRAM Unbeffered AMS-4128-xx-00 0820590000
19 HDD, 4GB, 7200RPM, LVD, ST34573LW, ADH-7400-xx-30 3009110100
20 HDD, 9GB, 7200RPM, LVD, ST39173LW, ADH-7900-xx-30 3009130100
22 ADAPTEC AHA-2944UW HVD O1301630000
32 Power Supply, (260 W) Hi-Pro 1901720000
33 CD-ROM, 24X EIDE 8240B ADR-0240-xx-04 7303020200
34 Diskette drive, 3.5”, Mist White 3200610000
38 CBL, IDE Z221100100
39 CBL, FDD 0700170000
40 CBL, POWER CORD 6701850000
41 CBL, USB 1301550000
45 BEZEL 1499690000
46 I/O PANEL 1499700000
52 POWER SWITCH 1499760000
56 FAN ASSY 3W PULSE QUABBIN 1301610000
TBD= To Be Defined Copyright 1997 Zenith Data Systems Corporation, A division of Packard Bell NEC
