Zephyr Essentials Twister AK8000BS Installation guide

Use, Care, and Installation Guide
www.zephyronline.com
Model number:
Serial Number:
Date of Purchase:
Sales Dealer:
DEC16.0501 © Zephyr Ventilation LLC.
Twister
AK8000BS
AK8000AS-ES
Tornado I
AK8100AS
READ AND SAVE THESE INSTRUCTIONS
AK8100AS
AK8000AS-ES
AK8000BS

www.zephyronline.com

1
SAFETY NOTICE ................................................................. 2-3
LIST OF MATERIALS....................................................... 4
INSTALLATION
Ducting Calculation Sheet....................................... 5
Mounting Height & Clearance................................ 6
Ducting Options........................................................... 7
Specications ............................................................... 8
Electrical ......................................................................... 9
Installing the Power Pack........................................ 10
FEATURES & CONTROLS
Slide Controls ............................................................... 11
MAINTENANCE
Cleaning and Installing Filters ............................... 12
AK8000BS Recirculating Kit................................... 13
Lights................................................................................ 14
TROUBLESHOOTING................................................................ 15
WIRING DIAGRAMS................................................................... 16
LIST OF PARTS AND ACCESSORIES .............................. 17
WARRANTY.................................................................................... 18-19
PRODUCT REGISTRATION.................................................... 20
Table of Contents

Important Safety Notice
READ AND SAVE THESE INSTRUCTIONS
2
www.zephyronline.com
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY SOLID-STATE CONTROL DEVICE.
WARNING
TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a. Use this unit only in the manner intended by the manufacturer, if you have questions, contact the manufacturer.
b. Before servicing or cleaning unit, switch power off at service panel and lock panel to prevent power from being switched on accidentally.
When the service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service
panel.
CAUTION
For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. Take care when using cleaning
agents or detergents. Suitable for use in household cooking area.
WARNING
TO REDUCE THE RISK OF RANGE TOP GREASE FIRE:
a. Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly
on low or medium settings.
b. AlwaysturnhoodONwhencookingathighheatorwhenamingfood
c. Cleanventilatingfansfrequently.Greaseshouldnotbeallowedtoaccumulateonfanorlter.
d. Use proper pan size. Always use cookware appropriate for the size of the surface element.
e. Keepfan,ltersandgreaseladensurfacesclean.
f. Use high setting on hood only when necessary.
g. Don’t leave hood unattended when cooking.
h. Always use cookware and utensils appropriate for the type of and amount of food being prepared.
WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE TOP FIRE, OBSERVE THE FOLLOWING:
a. SMOTHERFLAMESwithaclose-ttinglid,cookiesheet,ormetaltray,thenturnofftheburner.BECAREFULTOPREVENTBURNS.
Iftheamesdonotgooutimmediately,EVACUATEANDCALLTHEFIREDEPARTMENT.
b. NEVER PICK UP A FLAMING PAN – You may be burned.
c. DO NOT USE WATER, including wet dishcloths or towels – a violent steam explosion will result.
d. Use an extinguisher ONLY if:
1. You know you have a Class ABC extinguisher, and you already know how to operate it.
2. Thereissmallandcontainedintheareawhereitstarted.
3. Theredepartmentisbeingcalled.
4. Youcanghttherewithyourbacktoanexit
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a. Installationworkandelectricalwiringmustbedonebyqualiedperson(s)inaccordancewithallapplicablecodesandstandards.
Includingre-ratedconstruction.
b. Sufcientairisneededforpowercombustionandexhaustingofgasesthroughtheue(chimney)offuelburningequipmenttoprevent
back-drafting. Follow the heating equipment manufacturer’s guideline and safety standards such as those published by the National
FireProtectionAssociation(NFPA)andtheAmericanSocietyforHeating,RefrigerationandAirConditioningEngineers(ASHRAE)and
the local code authorities.
c. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
d. Ducted fans must always vent to the outdoors.
e. NEVER place a switch where it can be reached from a tub or shower.
f. Make sure the power is off before installing, wiring or maintenancing.

Important Safety Notice
3
WARNING
TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK.
CAUTION
Toreduceriskofreandtoproperlyexhaustairoutside-Donotventexhaustairintospaceswithinwalls,ceilings,
attics, crawl spaces or garages.
OPERATION
Alwaysleavesafetygrillesandltersinplace.Withoutthesecomponents,operatingblowerscouldcatchontohair,ngers
and loose clothing.
The manufacturer declines all responsibility in the event of failure to observe the instructions given here for installation,
maintenance and suitable use of the product. The manufacturer further declines all responsibility for injury due to
negligence and the warranty of the unit automatically expires due to improper maintenance.
*NOTE: Please check www.zephyronline.com for revisions before doing any custom work.
ELECTRICAL REQUIREMENTS
Important:
Observe all governing codes and ordinances.
It is the customer’s responsibility:
- Tocontactaqualiedelectricalinstaller.
- To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/NFPA 70
latest edition* or CSA standards C22.1-94, Canadian Electrical Code, Part 1 and C22.2 No.0-M91 - latest edition** and
all local codes and ordinances.
Ifcodespermitandaseparategroundwireisused,itisrecommendedthataqualiedelectriciandeterminethatthe
ground path is adequate.
Do not ground to a gas pipe.
Checkwithaqualiedelectricianifyouarenotsuretherangehoodisproperlygrounded.
Do not have a fuse in the neutral or ground circuit.
*National Fire Protection Association Batterymarch Park, Quincy, Massachusetts 02269
** CSA International 8501 East Pleasant Valley Road, Cleveland, Ohio 44131-5575
This appliance requires a 120V 60Hz electrical supply and connected to an individual properly grounded branch circuit
protected by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire with ground. Please also refer to
Electrical Diagram on product.
AK8000BS(400cfm)-315W,2.7Amps
AK8000AS-ES(290cfm)-96W,1.2Amps
AK8100AS(600cfm)-377W,3.3Amps
Acablelockingconnector(notsupplied)mightalsoberequiredbylocalcodes.Checkwithlocalrequirements,purchase
and install appropriate connector if necessary.

List of Materials
4
www.zephyronline.com
MODELS: AK8000BS, AK8000AS-ES, AK8100AS
PARTS SUPPLIED
1 - Power Pack
1-Aluminummeshlter(AK8000BS&AK8000AS-ES)
1-Decorativemeshlter(AK8100AS)
2-Halogenlightbulbs(AK8000BS&AK8100AS)
2-Fluorescentlightbulbs(AK8000AS-ES)
1-Singleinternalblower(pre-installed)
1 - Hardware package
HARDWARE PACKAGE CONTENTS
PARTS NOT SUPPLIED
- Ducting, conduit and all installation tools
- Cable connector (if required by local codes)
- Optional stainless steel liner (AK08xxAS)
-OptionalRecirculatingKitforAK8000BS(ZRC-0100)
Suction Cup (1)
AK8000BS, AK8100AS
Wire Caps (3)
M4 x 1” (4)
M4 x 1-1/2” (4)

5
Installation – Ducting Calculation Sheet
Duct pieces To tal
Equivalent number
length x used =
3-1/ 4” x 10”
Rect.,
straight
1 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect.to
6” round
transition
5 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect.to
6” round
transition
900 elbow
20 Ft. x ( ) =Ft.
6”, 7”, 8”, 10”
Round,
900
15 Ft. x ( ) =Ft.
6”, 7”, 8”, 10”
Round,
450
9 Ft. x ( ) =Ft.
Ft.
6”, 7”, 8”, 10”
Round,
straight
1 Ft. x ( ) =Ft.
Subtotal column 1 =
Duct pieces To tal
Equivalent number
length x used =
6”, 7”, 8”, 10”
Round, wall
cap with
damper
30 Ft. x ( ) =Ft.
Ft.
Ft.
Ft.
6”, 7”, 8”, 10”
Round
roof cap
30 Ft. x ( ) =Ft.
Subtotal column 2 =
Subtotal column 1 =
Total ductwork =
Maximum Duct Length: For satisfactory air movement,
the total duct length
should not exceed 100 equivalent feet.
6” round to
3-1/ 4” x 10”
rect.
transition
1 Ft. x ( ) =Ft.
6” round to
3-1/ 4” x 10”
rect.
transition
900 elbow
16 Ft. x ( ) =Ft.
7” round to
3 1/ 4” x 10”
rect.
transition
8 Ft. x ( ) =Ft.
7” round to
3-1/ 4” x 10”
rect.
transition
900 elbow
23 Ft. x ( ) =Ft.
elbow
elbow
7” to 6” or
8” to 7” Round
tapered
reducer
25 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect.900
elbow
15 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect.450
elbow
9 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect.900
flat elbow
24 Ft. x ( ) =Ft.
3-1/ 4” x 10”
Rect.
wall cap
with damper
30 Ft. x ( ) =Ft.
Ft. x ( ) =Ft.
15
6”, 7“, 8”
Round
in-line
damper

Installation – Mounting Height & Clearance
6
www.zephyronline.com
DUCTING
A minimum of 6” round or 3-1/4” x 10” rectangular
ductmustbeusedtomaintainmaximumairow
efciency.
Always use rigid type metal ducts only. Flexible
ductscouldrestrictairowbyupto50%.
Alsousecalculation(onpage5)tocomputetotal
available duct run when using elbows, transitions
and caps.
ALWAYS, when possible, reduce the number or
transitions and turns. If long duct run is required,
increase duct size.
If turns or transitions are required; install as far
away from hood duct output and as far apart,
between the two as possible.
Minimum mount height between range top to hood
bottom should be no less than 26”.
Maximum mount height should be no higher than
36”.
It is important to install the hood at the proper
mounting height. Hoods mounted too low could
resultinheatdamageandrehazard;whilehoods
mounted too high will be hard to reach and will
loseitsperformanceandefciency.
If available, also refer range manufacturer’s height
clearance requirements and recommended hood
mounting height above range.
Vertical Ducting:
6” round minimum
Horizontal Ducting:
N/A
DAMAGE-SHIPMENT / INSTALLATION:
• Pleasefullyinspectunitfordamagebefore
installation.
• Iftheunitisdamagedinshipment,returnthe
unit to the store in which it was bought for
repair or replacement.
• Iftheunitisdamagedbythecustomer,repair
or replacement is the responsibility of the
customer.
• Iftheunitisdamagedbytheinstaller(ifother
thanthecustomer),repairofreplacementmust
be made by arrangement between customer
and installer.
Min 26" - Max 36"
36"

7
WARNING FIRE HAZARD
NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages.
All exhaust must be ducted to the outside.
Use metal ductwork only.
FastenallconnectionswithsheetmetalscrewsandtapealljointswithcertiedSilverTapeorDuctTape.
Some Ducting Options
Installation – Ducting Options
side wall cap
w/ gravity damper
side wall cap
w/ gravity dampe
r
Soffit or crawl space
Roof Pitch w/
Flashing & Cap

8
www.zephyronline.com
Installation – Specications
top
front
bottom side
4-1/8”
5-3/8”
3-3/4”
10-5/8”
5-7/8”
1-1/16”
10-1/2”
11-13/16”
26-9/16”
27-9/16”
27-9/16”
25-3/4”
9-3/8”
8-11/16”
11-3/16”
11-3/16”
10-5/16”
1-5/16”
15”
18-15/16”
10-5/16”
1-1/8”
C/L

9
ELECTRICAL
WARNING
All Electrical work must be performed by qualied electrician or person with similar technical know
how and background.
For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not use
extension cord or adapter plug with this appliance.
Follow national electrical codes or prevailing local codes and ordinances.
Electrical Supply:
This appliance requires a 120V 60Hz electrical supply, and connected to an individual, properly grounded
branch circuit, protected by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire w/
ground. Please also refer Electrical Diagram labeled on product.
Cable Lock:
Acablelockingconnector(notsupplied)mightalsoberequiredbylocalcodes.Checkwithlocalrequirements
and codes, purchase and install appropriate connector if necessary.
Installation – Electrical
Cable Lock

10
www.zephyronline.com
Installation – Installing the Power Pack
1. Install optional AK08xxAS Stainless Steel Liner. Review
manual included with liner for more details.
2. If no liner is used cut out an opening in the bottom of the
cabinet by following the dimensions in FIG 1.
3. Lift Power Pack into opening and ensure locking clip has
lockedintoposition.(lockingclipislocatedonleftsideof
Power Pack. FIG 2
4.Fasten(2)M4screwsintoeachlongsideofPowerPack.
If a liner is used the screws will go through the Power Pack
mounting holes, then the liner and into the wood base.
note: Wood blocking may need to be added to cabinet
base if additional support is needed. see FIG 3 and FIG 4
5. Install duct work and seal with duct tape.
7. Install electrical.
8. Remove all packing materials before using Power
Pack. Switch power on and check for leaks around duct
tape.
9.Installlter.
The ducting from this fan to the outside of the building has a strong
effectontheairow,noiseandenergyuseofthefan.Usetheshortest,
straightest duct routing possible for best performance, and avoid
installing the fan with smaller ducts than recommended. Insulation
around the ducts can reduce energy loss and inhibit mold growth. Fans
installedwithexistingductsmaynotachievetheirratedairow.
CAUTION: At least two installers ar
e
required
due to the weight and size of
the
hood.
!
Ductwork
wood base
wood base
2” minimum
secure (2) M4 screws to mounting
holes on each long side of Power Pack
metal or other non
combustible material
D
uctwor
k
wood base
woo
d
b
as
e
2
” minimum
FIG 1
FIG 2
FIG 3
FIG 4
locking clip
mounting holes
controls
front view
right side view
Ductwork
cabinet bottom cut-out size
26
7/8 ”
10
5/8
”
Power Pack
Stainless Steel Liner
C/L
C/L

11
17
0 I II III
Blower On/Off Speed Selection
1Lights Bright/Dim/Off
2
0 I II
Features & Controls – Slide Controls
BLOWER ON/OFF/SPEED SELECTION
0 is off, I is low speed, II is medium speed and III is high speed.
LIGHTS BRIGHT/DIM/OFF
0 is off, I is dim, and II is bright.
1
2
BLOWER ON/OFF/SPEED SELECTION
0 is off, I is low speed, II is medium speed and III is high speed.
LIGHTS ON/OFF
0 is off and I is on.
1
2
17
0 I II III
Blower On/Off Speed Selection
1Lights On/Off
2
0 I
AK8000BS & AK8100AS
AK8000AS-ES

12
www.zephyronline.com
SURFACE MAINTENANCE:
Clean periodically with hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent, or steel wool/
scoring pads which will scratch and damage surface. Do not use products containing chlorine bleach or orange cleaners.
For heavier soil use liquid degreaser.
After cleaning, you may use non-abrasive stainless steel polish/ cleaners, to polish and buff out the stainless luster and
grain.Alwaysscrublightlyusingamicroberorcleancottonclothandwiththegrain.
Aluminum Mesh and Decorative Mesh Filters
Theltersareintendedtotrapresidueandgreasefromcooking.Althoughtheltersshouldneverneedreplacing,theyare
required to be cleaned every 30 days or more often depending on cooking habits.
FiltersmaybeplacedindishwasheratlowheatorsoakedinhotsoapywaterDryltersandre-installbeforeusinghood.
Installing Aluminum Mesh Filter, FIG 5:
1.PlacebackoflterintochannelonleftsideofPowerPack.
2. PushlterhandleintowardsleftsideofPowerPack.
3.Pivotlterupandlockintoplace.
Hood Model: Part No. Qty. to Order
AK8000BS 50200022 1
AK8000AS-ES 50200022 1
Installing Decorative Mesh Filter, FIG 6:
Hood Model: Part No. Qty. to Order
AK8100AS 50200024 1
1.PlacebackoflterintochannelonleftsideofPowerPack.
2. Pulllterhandledown.
3.Pivotlterupandlockintoplace.
3
FIG 5
FIG 6
2
1
1
23
Maintenance – Cleaning and Installing Filters

13
DUCTLESS RECIRCULATING (AK8000BS ONLY):
Ductless recirculating is intended for applications where an exhaust duct work is not possible to be installed.
When converted, the power pack functions in air “purifying” mode rather than exhausting the air. Fumes and
exhaustfromcookingisdrawnandlteredbyacharcoallter.Theairisthenpuriedandrecirculatedback
into the kitchen.
We recommend to always exhaust air outside of the home by employing existing or installing new duct work, if
possible.Thepowerpackismosteffectiveandefcientasanexhaustunit.Onlywhentheexhaustoptionis
not possible should you use the power pack in recirculating mode.
Whenconvertedtorecirculatingmode,acharcoallterisrequiredtobeinstalledontopofthestandard
aluminummeshlterandareturnairventisneededtodirectairbackintothekitchen.Thestandard
aluminummeshlterisintendedtocaptureresiduefromcookingandtheoptionalcharcoallterhelpsto
purify fumes exhausted from cooking in recirculating mode.
Purchase recirculating kit as follows, for AK8000AS ONLY:
Hood Model: Part No. Qty. to Order
AK8000BS ZRC-0100 1
Charcoalltersmustbereplacedapproximatelyevery3monthsbasedoffanaverageusageof1houraday.
Orderreplacementcharcoalltersasfollows:
Hood Model: Part No. Qty. to Order
AK8000BS Z0F-C002 1
For detailed installation instructions please refer to manual included with recirculating kit.
Installcharcoalfilter(plasticsideup)into
filter bracket. Insert tab cut-out side Dof
charcoal filter into bracket first. Lock
charcoal filter into place by pushing down
on side Ewith locking tabs.
D
E
Maintenance – AK8000BS Recirculating Kit

14
www.zephyronline.com
REPLACING LIGHT BULBS
CAUTION: Light bulb becomes extremely hot when turned on.
DO NOT touch bulb until switched off and cooled. Touching hot bulbs could cause serious burns.
Make sure all power is turned off and bulbs are not hot.
Remove by turning bulb counter clockwise. Note: Bulb does not unscrew; it turns 60 degrees, stops and
falls out.
Ifbulbsaredifculttoturnduetoprolongeduse,rmlyattachaglasssuctioncupapproximatelythe
diameter of the bulb or use a rubber/latex glove and turn counter clockwise.
Replacement bulbs are available at specialty lighting stores.
AK8000BS&AK8100AS:PurchasetypeMR16(GU-10)35Whalogen.   
AK8000AS-ES: Purchase type: 13w Fluorescent, GU-24 CFL, STS T3 13GUS
For Zephyr part numbers please turn to page 17 of the manual.
Maintenance – Lights
3
FIG 5
FIG 6
2
1
1
23
AK8000BS & AK8100AS AK8000AS-ES

Troubleshooting
15
TROUBLESHOOTING PROCEDURES FOR TWISTER AND TORNADO 1
Issue Cause What to do
After installation,
the unit doesn’t
work.
1. The power source is not turned ON. 1. Make sure the circuit breaker and the unit’s
power is ON.
2. The power line and the cable locking connector
is not connecting properly.
2. Check the power connection with the unit is
connected properly.
Light works,
but motor is not
turning.
1. The motor plug is disconnected. 1. Connect the motor plug.
2. The motor is defective, possible seized. 2. Change the motor.
3. The thermally protected system detects if the
motor is too hot to operate and shuts the motor
down.
3. The motor will function properly after the
thermally protected system cool down.
4. Damaged capacitor. 4. Change the capacitor.
The unit is
vibrating.
1. The blower is not secure in place. 1. Tighten the blower in place.
2. Damaged blower wheel. 2. Change the blower.
3. The hood is not secured in place. 3. Check the installation of the hood.
The motor is
working, but the
lights are not.
1. Defective light bulb. 1. Change the light bulb.
2. The light bulb is loose. 2. Tighten the light bulb.
The hood is
not venting out
properly.
1. The hood might be hanging to high from the
cook top.
1. Adjust the distance between the cook top and
the bottom of the hood within 26” to 36” range.
2. The wind from the opened windows or opened
doors in the surrounding area are affecting the
ventilation of the hood.
2. Close all the windows and doors to eliminate
theoutsidewindow.
3. Blocking in the duct opening or duct work. 3. Remove all the blocking from the duct work or
duct opening.
4. The direction of duct opening is against the wind. 4. Adjust the duct opening direction.
5. Using the wrong size of ducting. 5. Change the ducting to at least 6” or higher.
Metallteris
vibrating.
1. Metallterisloose. 1. Changethemetallter.
2. Spring clip is broken. 2. Change the spring clip.

16
www.zephyronline.com
Wiring Diagrams
Model: AK8000AS-ES
Voltage: 120V 60Hz 1.2A
Total: 96W
Lamp: Max.13Wx2
Fan: 70W
THERMALLY PROTECTED
Power Consumption
BLUE
BLUE
BROWN
BROWN GREY
YELLOW
YELLOW
RED
WHITE
WHITE
WHITE
WHITE
WHITE
BLACK
BLACK
BLACK
BLACK
GREEN
GREEN
BODY
BODY
CIRCUIT DIAGRAM
B/W
B/W
B/W
Model: AK8100AS
Voltage 120V 60Hz 3.3A
Total: 377W
Lamp: Max.35Wx2
Fan: 307W
THERMALLY PROTECTED
DATE:
182766
Power consumption

17
DESCRIPTION PART #
Replacement Parts
HalogenLightBulb,GU-10,35W(AK8000BS,AK8100AS)  Z0B-0023   
FluorescentLightBulb,13W(AK8000AS-ES)   Z0B-0036
AluminumMeshFilter(AK8000BS,AK8000AS-ES)   50200022
DecorativeMeshFilter(AK8100AS)    50200024
Optional Accessories
Liner,30” AK0800AS
Liner,36” AK0836AS
RecirculatingKit(AK8000BSONLY) ZRC-0100
To order parts, visit us online at http://store.zephyronline.com or call us at 1.888.880.8368
List of Parts and Accessories

18
www.zephyronline.com
Warranty AK8000BS & AK8100AS
1-888-880-8368
STAPLE YOUR RECEIPT HERE
TO OBTAIN SERVICE UNDER WARRANTY OR FOR ANY SERVICE RELATED QUESTIONS, please call:
Zephyr Ventilation, LLC (referred to herein as “we” or “us”) warrants to the original consumer purchaser (referred to
herein as “you” or “your”) of Zephyr products (the “Products”) that such Products will be free from defects in materials
or workmanship as follows:
Ten Year Limited Warranty for Parts: For ten years from the date of your original purchase of the Products, we will
provide, free of charge, Products or parts (including LED light bulbs, if applicable) to replace those that failed due to
manufacturing defects. We may choose, in our sole discretion, to repair or replace parts before we elect to replace the
Products.
One Year Limited Warranty for Labor: For one year from the date of your original purchase of the Products, we will
provide, free of charge, the labor cost associated with repairing the Products or parts to replace those that failed due to
manufacturing defects. After the first year from the date of your original purchase, you are responsible for all labor costs
associated with this warranty.
Warranty Exclusions: This warranty covers only repair or replacement, at our option, of defective Products or parts and
does not cover any other costs related to the Products including but not limited to: (a) normal maintenance and service
required for the Products and consumable parts such as fluorescent, incandescent or halogen light bulbs, mesh and char-
coal filters and fuses; (b) any Products or parts which have been subject to freight damage, misuse, negligence, accident,
faulty installation or installation contrary to recommended installation instructions, improper maintenance or repair (other
than by us); (c) commercial use of the Products or use otherwise inconsistent with its intended purpose; (d) natural wear
of the finish of the Products or wear caused by improper maintenance, use of corrosive and abrasive cleaning products,
pads, and oven cleaner products; (e) chips, dents or cracks caused by abuse or misuse of the Products; (f) service trips
to your home to teach you how to use the Products; (g) damage to the Products caused by accident, fire, floods, acts of
God; or (h) Custom installations or alterations that impact serviceability of the Products. If you are outside our service
area, additional charges may apply for shipping costs for warranty repair at our designated service locations and for the
travel cost to have a service technician come to your home to repair, remove or reinstall the Products. After the first year
from the date of your original purchase, you are also responsible for all labor costs associated with this warranty.
Limitations of Warranty. OUR OBLIGATION TO REPAIR OR REPLACE, AT OUR OPTION, SHALL BE YOUR SOLE AND
EXCLUSIVE REMEDY UNDER THIS WARRANTY. WE SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR
SPECIAL DAMAGES ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THE PRODUCTS.
THE EXPRESS WARRANTIES IN THE PRECEDING SECTION ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS
WARRANTIES. WE HEREBY DISCLAIM AND EXCLUDE ALL OTHER EXPRESS WARRANTIES FOR THE PRODUCTS,
AND DISCLAIM AND EXCLUDE ALL WARRANTIES IMPLIED BY LAW, INCLUDING THOSE OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. Some states or provinces do not allow limitations on the duration of an implied
warranty or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not
apply to you. To the extent that applicable law prohibits the exclusion of implied warranties, the duration of any applicable
implied warranty is limited to the same ten-year period described above. Any oral or written description of the Products is for
the sole purpose of identifying the Products and shall not be construed as an express warranty. Prior to using, implementing
or permitting use of the Products, you shall determine the suitability of the Products for the intended use, and you shall assume
all risk and liability whatsoever in connection with such determination. We reserve the right to use functionally equivalent
refurbished or reconditioned parts or Products as warranty replacements or as part of warranty service. This warranty is not
transferable from the original purchaser and applies in the United States and Canada.
To Obtain Service Under Limited Warranty: To qualify for warranty service, you must: (a) notify us at the address or
telephone number stated below within 60 days of the discovery of the defect; (b) give the model number and part identifi-
cation number and serial number; and (c) describe the nature of any defect in the Product or part. At the time of the
request for warranty service, you must present evidence of your proof of purchase and proof of the original purchase
date. If we determine that the warranty exclusions listed above apply or if you fail to provide the necessary documenta-
tion to obtain service, you will be responsible for all shipping, travel, labor and other costs related to the services.
Please check our website for any revisions, www.zephyronline.com.
Zephyr Ventilation Service Department, 2277 Harbor Bay Parkway, Alameda, CA 94502 1-888-880-8368
Limited Warranty
AUG14.0301
Proof of the original purchase
date is needed to obtain
service under warranty
