Zero DSR 2018 User manual

2018 ZERO S / SR / DS / DSR
2018
ZERO S™
ZERO SR™
ZERO DS™
ZERO DSR™
HARGE
TORCYCLES.COM
E
E
E
™
Y
C
YY
L
E
S
.
CO
M
88-08922.03
OWNER’S MANUAL
OWNER’S MANUAL
Zero Owner's Manual (S and DS).book Page 1 Wednesday, February 28, 2018 11:21 AM

Zero Owner's Manual (S and DS).book Page 2 Wednesday, February 28, 2018 11:21 AM

Table Of Contents
TOC.1
Introduction.................................................... 1.1
Introduction.................................................................. 1.1
An Important Message From Zero............................ 1.1
About This Manual.................................................... 1.1
Useful Information For Safe Riding........................... 1.2
Unplug Your Z-Force® Power Pack™...................... 1.2
California Proposition 65........................................... 1.2
California Perchlorate Advisory................................. 1.2
Identification Numbers................................................ 1.3
Owner Information .................................................... 1.3
Power Pack Serial Number....................................... 1.4
Motor Serial Number................................................. 1.4
Key Code Number .................................................... 1.4
Vehicle Identification Number (VIN) / Chassis
Number..................................................................... 1.4
General Information .................................................... 1.5
Emissions Information............................................... 1.5
Vehicle Range........................................................... 1.5
Maximizing Your Range............................................ 1.6
Transporting.............................................................. 1.9
Safety Information......................................... 2.1
General Safety Precautions........................................ 2.1
General Safety Precautions......................................2.1
Important Operating Information...............................2.2
Location of Important Labels ..................................... 2.3
Location of Important Labels.....................................2.3
Controls and Components ........................... 3.1
Controls and Components.......................................... 3.1
Motorcycle Controls ..................................................3.2
Left Side View ...........................................................3.4
Right Side View.........................................................3.6
Dash Overview..........................................................3.8
Warning Indicator Lights .........................................3.10
Dash Settings.......................................................... 3.13
Smartphone Application..........................................3.16
Bluetooth® Pairing..................................................3.16
Handlebar Controls ................................................. 3.17
Performance Level Mode Button.............................3.21
Front Brake Lever Adjuster ..................................... 3.22
Parking Brake Operation (if equipped)....................3.22
Tank Storage Compartment....................................3.23
Power Tank (if equipped)........................................3.24
Charge Tank (if equipped) ......................................3.24
Side Storage Compartment (if equipped)................ 3.25
Zero Owner's Manual (S and DS).book Page 1 Wednesday, February 28, 2018 11:21 AM

Table Of Contents
TOC.2
Starting and Operating.................................. 4.1
General Operation........................................................4.1
General Operation .....................................................4.1
Key Switch/Steering Lock Positions...........................4.2
Motorcycle Tip-Over Sensor......................................4.3
Operating Your Motorcycle........................................4.4
ABS (Anti-lock Braking System) ................................4.6
Front Suspension Adjustment....................................4.9
Rear Shock Adjustment...........................................4.14
Charging and Power Pack Information........ 5.1
Power Pack and Charging...........................................5.1
Power Pack................................................................5.1
On-Board Power Pack Charger.................................5.2
Charging the Power Pack..........................................5.4
Quick Charging (Off-Board Accessory Charger)........5.6
Charge Tank (if equipped).........................................5.9
Public Charging Stations..........................................5.10
Add On Electrical Equipment...................................5.10
Maintaining Your Motorcycle........................ 6.1
Maintaining Your Motorcycle......................................6.1
Owner’s Responsibilities............................................6.1
Parts/Maintenance Items...........................................6.2
Service History...........................................................6.2
Scheduled Maintenance ............................................6.2
Component Fasteners ...............................................6.6
Power Pack .................................................................. 6.9
Power Pack............................................................... 6.9
General Maintenance ................................................ 6.10
Brakes..................................................................... 6.10
Parking Brake ......................................................... 6.14
Suspension............................................................. 6.15
Wheels And Tires.................................................... 6.16
Tire Inflation............................................................ 6.16
Drive Belt ................................................................ 6.17
Headlight Alignment................................................ 6.21
Turn Signal Light Bulb Replacement ...................... 6.24
Brake/Tail LED Replacement.................................. 6.24
Running Light Bulb Replacement ........................... 6.25
Cleaning.................................................................. 6.26
Parking and Long Term Storage............................. 6.27
Zero Motorcycles Accessories................................ 6.27
Fuses...................................................................... 6.27
Troubleshooting............................................ 7.1
Troubleshooting.......................................................... 7.1
Electric Motorcycle Precautions................................ 7.1
Troubleshooting Your Motorcycle............................. 7.1
System Warning Indicator......................................... 7.2
Dash Error Codes ..................................................... 7.5
General Troubleshooting .......................................... 7.8
Cold and Hot Weather Considerations ..................... 7.9
Safety Interlocks ..................................................... 7.11
Zero Owner's Manual (S and DS).book Page 2 Wednesday, February 28, 2018 11:21 AM

Table Of Contents
TOC.3
Technical Specifications............................... 8.1
Specifications (Europe) .............................................. 8.1
VIN Breakdown......................................................... 8.1
Zero S (11kW)........................................................... 8.2
Zero S ....................................................................... 8.4
Zero SR..................................................................... 8.6
Zero DS (11kW)........................................................ 8.8
Zero DS................................................................... 8.10
Zero DSR................................................................ 8.12
Specifications (Rest Of The World) ......................... 8.14
VIN Breakdown....................................................... 8.14
Zero S ..................................................................... 8.15
Zero SR................................................................... 8.17
Zero DS................................................................... 8.19
Zero DSR................................................................ 8.21
Warranty and Customer Information ........... 9.1
Limited Warranty Information .................................... 9.1
Who Is The Warrantor?............................................. 9.1
Who Does This Limited Warranty Cover?................. 9.1
What Does This Limited Warranty Cover?................ 9.1
What Is The Coverage Period Of This Limited
Warranty? ................................................................. 9.2
What Is Not Covered By This Limited Warranty?...... 9.3
What Other Limitations Or Disclaimers Apply To
This Limited Warranty............................................... 9.5
What Are Your Responsibilities As A Customer? ..... 9.6
What Will Zero Do Under This Limited Warranty?.... 9.7
How Does This Limited Warranty Relate To
State Law?................................................................9.7
How Do You Obtain Service Under This Limited
Warranty?..................................................................9.8
Transfer Of Ownership And Limited Warranty ..........9.9
Customer Information............................................... 9.10
Customer Assistance..............................................9.10
Reporting Safety Defects........................................9.11
Maintenance Record ................................... 10.1
Maintenance Record.................................................. 10.1
Service History........................................................10.1
Index
First Responder Information – High Voltage
Component Locations
Zero Owner's Manual (S and DS).book Page 3 Wednesday, February 28, 2018 11:21 AM

Zero Owner's Manual (S and DS).book Page 4 Wednesday, February 28, 2018 11:21 AM

Introduction
1.1
IntroductionIntroduction
An Important Message From Zero
Congratulations and thank you for purchasing the 2018
Zero S, Zero SR, Zero DS, or Zero DSR electric
motorcycle; we welcome you to the community of Zero
Motorcycles riders. This manual is designed to provide you
with a better understanding of the operation, inspection,
and basic maintenance requirements of this motorcycle.
Zero continually seeks advancements in product design
and quality. Therefore, this manual contains the most
current product information available at the time of printing.
Because of this, your motorcycle may differ from the
information supplied in this owner’s manual. No legal
claims can be made on the basis of data in this manual.
When it comes time to sell your Zero S/SR/DS/DSR,
please ensure that this manual stays with the motorcycle; it
is, by law, an important part of the vehicle. If you have any
questions concerning the operation or maintenance of
your motorcycle, please contact your authorized Zero
Motorcycles dealer.
For 24 hour updates and additional information about your
motorcycle, visit the Owner Resources section of the Zero
Motorcycles website:
http://www.zeromotorcycles.com/owner-resources/
About This Manual
This manual covers the following motorcycles (standard
features and equipment include Integrated Z-Force®
Power Pack and charger, belt drive, 17-inch wheels
(unless otherwise specified), and regenerative braking):
Zero S: Street
Cast Wheels
Street Tires
Zero SR: Street - Max Performance
Cast Wheels
Street Tires
Zero DS: Dual Sport
Cast Wheels (19-inch diameter front)
Dual Sport Tires
Zero DSR: Dual Sport - Max Performance
Cast Wheels (19-inch diameter front)
Dual Sport Tires
Locating and referencing information
A good place to locate information about the motorcycle is
in the index in the back of the manual.
The terms “right” or “left” refer to the rider’s right or left
when sitting on the motorcycle.
Zero Owner's Manual (S and DS).book Page 1 Wednesday, February 28, 2018 11:21 AM

Introduction
1.2
Useful Information For Safe Riding
This manual contains the word WARNING to indicate
something that could hurt you or others. It also contains
the word CAUTION to indicate things that could damage
your motorcycle.
WARNING! Please read this manual carefully and
completely before operating this motorcycle. Do not
attempt to operate this motorcycle until you have attained
adequate knowledge of its controls and operating features,
and until you have been trained in safe and proper riding
techniques. Regular inspections and proper maintenance,
along with good riding skills, help you safely enjoy the
capabilities and the reliability of this motorcycle.
Disregarding the aforementioned, however, may render
the warranty invalid.
This symbol is located in various locations
on the motorcycle to inform you that
exposure to high voltage can cause shock,
burns and even death.
The high voltage components on the motorcycle should be
serviced only by technicians with special training.
High voltage cable or wiring has an orange covering. Do
not probe, tamper with, cut, or modify high voltage cable or
wiring.
Unplug Your Z-Force®Power Pack™
CAUTION: Proper care of the motorcycle’s power pack is
essential! Once your motorcycle is charged, disconnect
the power pack from AC power. Leaving your motorcycle
unplugged will maximize long-term power pack health.
See “Power Pack”, on page 5.1 for other important
information regarding the power pack.
California Proposition 65
WARNING: Certain motorcycles contain or emit chemicals
known to the State of California to cause cancer and birth
defects or other reproductive harm. In addition, certain
fluids contained in vehicles and certain products of
component wear contain or emit chemicals known to the
State of California to cause cancer and birth defects or
other reproductive harm.
California Perchlorate Advisory
WARNING: Certain components of this motorcycle such
as lithium batteries may contain perchlorate material.
Special handling may apply for service or end of life
disposal. See www.dtsc.ca.gov.
Zero Owner's Manual (S and DS).book Page 2 Wednesday, February 28, 2018 11:21 AM

Identification Numbers
1.3
Identification Numbers
Owner Information
Record information pertaining to your motorcycle here. When contacting your dealer, you may need to provide this
information.
Zero Owner's Manual (S and DS).book Page 3 Wednesday, February 28, 2018 11:21 AM

Identification Numbers
1.4
Power Pack Serial Number
The Power Pack serial number is located on the upper
front left of the power pack.
Motor Serial Number
The motor serial number is stamped on the right hand side
of the motor housing.
Key Code Number
The key code is a 5-digit number used to create duplicate
keys. This number is located on a tag that accompanies
the original keys.
Vehicle Identification Number (VIN) / Chassis
Number
The VIN / Chassis Number (A) is a 17-digit number
stamped on the head tube of the frame. Do not alter or
remove this number as it is the legal identifier for your
motorcycle.
For information on the breakdown of the VIN, see
“Technical Specifications”, on page 8.1.
For the location of other important labels, see page 2.3.
Zero Owner's Manual (S and DS).book Page 4 Wednesday, February 28, 2018 11:21 AM

General Information
1.5
General Information
Emissions Information
The Zero S/SR/DS/DSR electric motorcycle is a true
freeway-capable zero-emissions vehicle under California
Air Resources Board (CARB), U.S. Federal (EPA), and
European Union standards. It uses no gasoline or other
liquid fuel. It has no tailpipe and therefore no tailpipe
emissions. It also has no exhaust or evaporative
emissions. Because the Zero S/SR/DS/DSR runs solely on
electricity, it is the only kind of vehicle which actually gets
cleaner in terms of air pollution each year, as the electricity
grid gets cleaner and more renewable. Zero Emissions
Vehicles (ZEV’s) offer greater efficiency, and can help
solve the serious air pollution, global warming, and energy
security problems facing the country and the world.
CAUTION: Please use only Zero approved parts and
accessories for your Zero Motorcycle. Parts and
accessories for your Zero Motorcycle have been checked
and tested for safety and suitability. Zero is unable to
accept any liability whatsoever for parts and accessories
which have not been approved.
Vehicle Range
The range of an electric vehicle is defined as the distance
the vehicle travels on a single full charge of the power
pack. Just like EPA mileage estimates on an automobile,
“your mileage may vary.” Your range results are a direct
reflection of your riding habits. The more conservatively
you ride, the better range you can expect from your Zero
S/SR/DS/DSR motorcycle.
Some of the factors which affect range include: speed,
acceleration, number of starts and stops, ambient air
temperature, as well as changes in elevation. The
combination of these factors, as you travel from one point
to another, defines your trip profile. In addition, tire
pressure and payload are important considerations.
We suggest that you ride conservatively when you first get
your Zero S/SR/DS/DSR motorcycle, and get to know your
motorcycle and your commute. Once you become familiar
with the range versus performance of your motorcycle,
then you can adjust your riding characteristics if you so
desire. This applies mainly to riders with trip profiles which
are at the edge of the performance envelope.
The reported motorcycle range values in this Owner’s
Manual are measured using different standards, according
to the country the Zero motorcycle is being sold.
Zero Owner's Manual (S and DS).book Page 5 Wednesday, February 28, 2018 11:21 AM

General Information
1.6
For Zero motorcycles sold within European countries,
range is calculated using European Union regulation EU
134/2014 Annex VII.
For Zero motorcycles sold in all other countries, range is
calculated using the following types of industry standard
test procedures:
1. “City”: This range test is specified to determine riding
during “stop-and-go” operation typically found in urban
areas. This estimate is provided following the SAE
J2982 Riding Range Test Procedure for On-Highway
Electric Motorcycles to provide a reasonable and
consistent basis for manufacturers to inform
prospective owners of the riding range that can be
expected under specified operating conditions. Actual
range will vary based on riding conditions and habits.
2. “Highway”: This test procedure uses two separate
constant speeds of 55 mph (89 km/h) and 70 mph
(113 km/h) to simulate highway riding.
Both of these test procedures are run on a single charge,
in order to report the associated measured range values.
Range values labeled “Combined” are based on a
calculation that assumes a duty cycle comprised of 50%
City / 50% Highway.
See technical specification charts on page 8.15 through
page 8.21 for these ranges.
Maximizing Your Range
Range varies in electric motorcycles similarly to how it
varies in gas motorcycles. However, the big difference
between electric and gas is that energy consumption is
averaged over a shorter distance on an electric
motorcycle. Electric motorcycles are designed for
convenient daily recharges versus less frequent and less
convenient trips to the gas station. As a result, the same
electric motorcycle often yields different ranges from one
full recharge to the next.
How to Predict the Range
To generally predict how an electric motorcycle’s range will
be affected, you can use the four factors:
route
rider
weather
motorcycle
By considering each of these factors, you can use
specifications such as ‘city range’ as standards to estimate
what the motorcycle’s real world range will be under your
particular usage case.
Zero Owner's Manual (S and DS).book Page 6 Wednesday, February 28, 2018 11:21 AM

General Information
1.7
Zero Owner's Manual (S and DS).book Page 7 Wednesday, February 28, 2018 11:21 AM

General Information
1.8
Zero Owner's Manual (S and DS).book Page 8 Wednesday, February 28, 2018 11:21 AM

General Information
1.9
Transporting
It is recommended that the motorcycle be tied-down using
ratchet straps while it is being transported. Place the
ratchet straps around a frame contact point. Soft straps
must be used to reduce scratches or other damage.
Use two ratchet straps in the front and two in the rear. The
tie down straps should be at a 45° angle from the
motorcycle. Follow the manufacturer’s instructions for the
ratchet straps you are using.
Zero Owner's Manual (S and DS).book Page 9 Wednesday, February 28, 2018 11:21 AM

Notes
1.10
Zero Owner's Manual (S and DS).book Page 10 Wednesday, February 28, 2018 11:21 AM

General Safety Precautions
2.1
Safety InformationGeneral Safety Precautions
General Safety Precautions
This is a performance motorcycle and should be
treated with extreme caution.
Proper safety gear, including a regionally approved
helmet, eye protection, riding boots, gloves, and
protective clothing should be worn while riding to
reduce the risk of potential injury. We highly
recommend the use of full height riding boots. It is not
recommended to ride without the correct protective
clothing; this applies to even short journeys and to
every season of the year.
Read all additional warnings and product instructions in
this owner’s manual, as well as safety labels, before
operating your electric motorcycle.
Never permit a guest to ride your electric motorcycle
without proper instruction.
Never use alcohol or mind-altering drugs before
operating your electric motorcycle.
Persons unwilling or unable to take responsibility for
their actions should not use this motorcycle. You
assume all responsibility while operating your
motorcycle. The seller assumes no liability for misuse
or operator negligence.
Prior to each use the rider must check everything in the
“every ride” column of the maintenance schedule on
page 6.2, and the charge level of the power pack as
indicated on the dash display charge indicator.
Your safety depends in part on the good mechanical
condition of the motorcycle. Be sure to follow the
maintenance schedule and adjustment requirements
contained in this manual. Be sure you understand the
importance of checking all items thoroughly before
riding.
Modifications to the motorcycle may render the vehicle
unsafe and may cause severe personal injury. Zero
cannot be held liable for non-approved modifications.
Be very careful when loading or adding accessories to
your motorcycle. Large, bulky, or heavy items may
adversely affect the handling and performance of your
motorcycle.
Zero Owner's Manual (S and DS).book Page 1 Wednesday, February 28, 2018 11:21 AM

General Safety Precautions
2.2
Important Operating Information
Several operating considerations are listed below:
Always turn the key switch and motor stop switch to the
OFF position when not actively riding. It is very easy to
forget that the motorcycle is powered up because it is
silent. An accident can occur if the motorcycle is left
powered up while getting on or off the motorcycle.
Turn the motor stop switch OFF when backing up or
pushing the motorcycle while dismounted.
Use the rear brake when you are stopped on an incline.
Do not hold the motorcycle using partial throttle or
damage to the motor may occur.
Plug your motorcycle into an AC power source to
recharge it after each use. Once recharged, disconnect
from the AC power source. Leaving your motorcycle
unplugged between charges will maximize the
long-term health of the power pack. You should also
use the supplied cable as it is designed for use with
your motorcycle’s electrical components.
While unplugged with the key in the OFF position, the
motorcycle’s electronics will consume a very small
amount of power and the power pack will drain
extremely slowly. If you don’t ride for an extended
period of time (30 days or more), you may want to plug
the motorcycle into an AC power source to charge it for
a few hours prior to your next ride.
CAUTION: Only charge the Zero power pack with the
motorcycle’s on-board charger or the approved Zero
accessory charger.
The power pack does not require nor benefit from deep
discharging. To get the most power pack life, recharge
each power pack immediately after each ride. Leaving
a power pack in a discharged state will cause damage.
Failure to follow power pack storage and charging
instructions as described in this Owner’s Manual may
void the warranty of your Zero Motorcycle. These
guidelines have been rigorously tested to ensure
maximum power pack efficiency and service.
Zero Owner's Manual (S and DS).book Page 2 Wednesday, February 28, 2018 11:21 AM

Location of Important Labels
2.3
Location of Important Labels
Location of Important Labels
The motorcycle could contain the following information for both North American and European models:
A. VECI (Vehicle Emission Control Information) label
B. VIN label (North America) - certification label C. VIN label (European Union) - certification label D. Tire and loading information label

Notes
2.4
Zero Owner's Manual (S and DS).book Page 4 Wednesday, February 28, 2018 11:21 AM
