Zetronix NEPTUNE User manual

HIDDEN CAMERA BOTTLE
MANUAL

MA N UA

Contents
In the Box
Page 1
Diagram
Page 2
Getting Started
Page 3
Camera Operation
Page 7
Media Playback Computer
Page 8
Date & Time Stamp Settings
Page 9
Troubleshooting
Page 10
Formatting on PC
Page 11
Formatting on Mac
Page 13
Product Specifications
Page 15
Warranty
Page 16

Page 1
E
C
D
A
B
A. 1x Bottle
B. 1x USB cable
C. 1x Extra Labels
D. 1x This Manual
E. 1X Camera Device

Page 2
1
2
3
4
6
5
❹USB Port
❺Function Button
❻Camera Lens
❶Micro USB Card Slot
❷Reset pinhole
❸Hidden blue Light

Page 3
Charge the Camera Device
Please fully charge the camera before
operation.
Connect the included USB cable (B) to an
USB AC Charger, and to the bottle
Camera Device’s USB Port ❹.
While charging the blue light ❸will blink
slowly. Once fully charged the light will
stay on solid.
Connect a micro SD memory card.
A Micro SD memory card is required to
record video files to.
To insert the memory card, hold the
camera device (E) with the camera lens
❻facing you. The memory card’s gold
pins should also be facing you, with the
card notch towards the left.

Page 4
Push the card all the way into the card
slot ❶until you feel a click. You may
have to use your fingernail or a small tool.
To remove the card, simply push it
further in again so it toggles back out.
Notch

Page 5
Hide the Camera
Place the camera device in the bottle’s
depression; Ensure the function button
❺is towards the top of the bottle.
Next use one of the included labels (C) to
wrap it around the bottle while holding
the camera device in place.
Button

Page 6
Function
Button
Make sure the hole on the label lines
up with the camera lens ❻.
Since the function ❺
button will be hidden
behind the label, you
will have to poke around
about half inch above the
camera hole until you feel it
click. It should be right on
top of the “tto”at the end of
the word “SanBeweketto”.
Hole
Camera

Page 7
Turning the camera ON/OFF.
To turn on the camera device, press and
hold the Function Button ❺for 3
seconds. The Blue light ❸will come on
indicating the camera is on stand -by.
To turn off the device, simply press and
hold the Function button ❺again for 3
seconds again, the blue light ❸should
go out.
Recording Video
After turning on the device, while on
stand-by (solid blue light), quickly press
the function button ❺to start the
recording. The blue light ❸will flash 3
times and go out, indicating video is
being recorded.
By quickly hitting the function button ❺
again, the camera will pause recording
and go back to stand by; solid blue light.

Page 8
To view the recorded videos, connect the
Camera Device to your computer by
connecting the included USB cable (B) to
the Camera’s USB port ❹and your
computer’s USB port.
In 30 seconds your computer should
prompt you with options for viewing the
files. If it doesn’t, please browse the files
from “This PC”, “My Computer”, or “File
Explorer” if using a windows system, or
look for a new drive in your desktop if
using Mac OS.
For playback we currently recommend
a free program called VLC Player, found
at www.videolan.org

Page 9
To update or remove the video date/time
stamp watermark on the video recording,
please download the zUtility App from the
Zetronix website.
https://www.zetronix.com/download
After downloading and installing the App,
you will be prompted to choose the
device. From here choose the zBottle,
choose Time/date Setup and follow the
on-screen instructions.

Page 10
Most issues can be solved by formatting
the memory card or by resetting the
camera
Formatting the memory:
WARNING: formatting the memory will
wipe out all the recorded media
previously stored.
Formatting the memory will clean up
any file corruption that may exist
preventing the device from operating
correctly.
Please refer to Page 11 or 13 on how to
format the memory card.
Resetting the Camera
Using a paperclip or a pin press and
hold the hidden pinhole switch ❷for
about 10 seconds.

Page 11
1. First ensure that the memory card is in the
camera device, connect the camera to your
PC as instructed on page 8 of this manual.
2.
3. Locate your hard drive directory. It will be
under “My Computer” or “This PC”. You can
also open a new File Explorer window and
your drives will be listed there. The memory
card will appear as a “Removable Drive” or
“USB Drive”.
4. Right Click on the removable drive and
select Format.
5.

Page 12
6.
7. From the options shown, make sure that you
have selected FAT32 as your file system.
Leave other settings at their defaults.
8. Click Start. After a few seconds the memory
will be formatted.

Page 13
First ensure that the memory card is in the
camera device, connect the camera to your
Computer as instructed on page 8 of this
manual.
1. Locate and open a program called “Disk
Utility”. It is usually found by going into the
application folder and opening the utility
folder.
App Locations -> Utilities
2.

Page 14
3.
4. In Disk Utility, Select the drive from the list
on the left. Most likely named “NO NAME”.
5. Along the top of the window menu, click on
the button labeled Erase (highlighted in the
square above)
6. From the dropdown menu labeled Format,
choose MS-DOS (FAT).
7. When ready, click the button in the lower
right corner labeled Erase.
After a few seconds the memory will be
formatted.

Page 15
Item
Parameter
Sensor
2 Megapixel
Video Resolution
1920x1080
Video Format
AVI
Frame Rate
30 FPS
Memory Capacity
64GB MicroSD
USB type
Micro USB / USB 2.0
Mobile OS Support
Android / iOS
Desktop OS
Winsows 7,8,10/Mac OS X

Page 16
1Year Limited Warranty
Zetronix Corporation ("Zetronix") warrants this product against
defects in material or workmanship as follows: PRODUCT:
Zetronix will repair this product with new or refurbished parts,
free of charge, for a period of one (1) year from the date of
original purchase in the event of a defect in materials or
workmanship. REPAIRS: Zetronix will repair or replace defective
parts used in the repair or replacement of this product with new
or refurbished parts, free of charge, for a period equal to the
remainder of the original limited warranty period on the original
product, or for 60 days after the date of the repair or
replacement, whichever is longer. This warranty is extended only
to the original purchaser. Proof of purchase in the form of a bill of
sale or receipted invoice, which is evidence that the unit is within
the warranty period, must be presented to obtain warranty
service. To obtain warranty service, you must take this product,
or deliver the product freight prepaid, in either its original
packaging or packaging affording an equal degree of protection,
to Zetronix Corporation. See below for additional information.
This warranty only covers failures due to defects in materials and
workmanship, which occur during normal use.
The warranty does not cover damages, which occurred in
shipment, cosmetic damage, damage that is attributable to acts
of God, failures which are caused by products not supplied by the
warrantor, or failures which result from accident, misuse, abuse,
neglect, mishandling, faulty installation, misapplication, improper
installation, operation or maintenance, alteration, modification,
introduction of sand, humidity or liquids, line power surge,
improper voltage supply, lightning damage, or subjecting the
product to operating/environmental conditions in excess of the
maximum values or below the minimum values set forth in the
applicable specifications, or products serviced by anyone other
than Zetronix. This warranty is invalid if the factory-applied serial
number has been altered or removed from the product. This
warranty does not cover products sold AS IS or WITH ALL
FAULTS. This warranty excludes consumable parts such as
batteries and power supplies. Zetronix Corporation ("Zetronix")
Page16

Page 17
warrants this product against defects in material or workmanship
as follows: PRODUCT: Zetronix will repair this product with new
or refurbished parts, free of charge, for a period of one (1) year
from the date of original purchase in the event of a defect in
materials or workmanship. REPAIRS: Zetronix will repair or
replace defective parts used in the repair or replacement of this
product with new or refurbished parts, free of charge, for a
period equal to the remainder of the original limited warranty
period on the original product, or for 60 days after the date of
the repair or replacement, whichever is longer. This warranty is
extended only to the original purchaser. Proof of purchase in the
form of a bill of sale or receipted invoice, which is evidence that
the unit is within the warranty period, must be presented to
obtain warranty service. To obtain warranty service, you must
take this product, or deliver the product freight prepaid, in either
its original packaging or packaging affording an equal degree of
protection, to Zetronix Corporation. See below for additional
information. This warranty only covers failures due to defects in
materials and workmanship, which occur during normal use.
The warranty does not cover damages, which occurred in
shipment, cosmetic damage, damage that is attributable to acts
of God, failures which are caused by products not supplied by the
warrantor, or failures which result from accident, misuse, abuse,
neglect, mishandling, faulty installation, misapplication, improper
installation, operation or maintenance, alteration, modification,
introduction of sand, humidity or liquids, line power surge,
improper voltage supply, lightning damage, or subjecting the
product to operating/environmental conditions in excess of the
maximum values or below the minimum values set forth in the
applicable specifications, or products serviced by anyone other
than Zetronix. This warranty is invalid if the factory-applied serial
number has been altered or removed from the product. This
warranty does not cover products sold AS IS or WITH ALL
FAULTS. This warranty excludes consumable parts such as
batteries and power supplies.
