Zetronix ATOM User manual

USER MANUAL
Self-Install
ATOM
Hidden Camera Kit

❶
❺
❹
❼
❽
❷
❾
❶Camera
❷Pinhole Function Button
❸Function LED Indicator
❹Battery Connector
❺Memory Card Slot
❻Recording Mode Switch
❼On/Off Switch
❽USB Power & Charge Port
❾Charge LED Indicator
C M
❻
FUNCTION
❸
ON OFF

Setting the Date and Time
stamp for your videos iseasy.
Zetronix provides an easy-to-
use application for both
Windows and Mac that will
automatically help you set up
the time stamp.
It can befound at thefollowing
address.
http://zetronix.com/download/
Date/Time Stamp Setup –1/2

On some systems you may get a warning during installation.
This is normal. Simply click RUN ANYWAY and continue.
On an Apple computer you may get a similar warning. Go into
CONTROL PANEL and choose SECURITY. UNLOCK the security
settings and choose ALLOW ALL
Once you have installed the program, make sureyou turn
SECURITY SETTINGS back on.
Insert a Micro SD Memory Card into the card slot.
Date/Time Stamp Setup –2/2

Continuous Recording Mode
1. Connect the battery to the battery connector
❹
2. Insert a Micro SD memory card into the card slot ❺
3. Switch the Recording Mode Switch ❻ to the "C" position.
4. Place the On/Off switch ❼ to the “On”position.
The function LED indicator ❸ will blink blue five times and
go out to indicate a recording has started.
To pause the recording, use the included pin to
press the function button ❷ this will put the camera
in stand-by mode indicated by a solid blue light.
Operation –1/2

To resume recording, press the function button ❷ again.
The LED will blink blue twice and turn off to indicate that it is
recording again.

Motion Detection Recording Mode
1. Connect the battery to the battery connection ❹
2. Insert a Micro SD memory card into the card slot ❺
3. Switch the Recording Mode Switch ❻to the "M" position.
4. Place the On/Off switch ❼to the “On”position.
The LED indicator ❸will blink Blue three times and Red once
to indicate the recording has started.
When motion is detected the camera will record for 3 minutes. It
will stop recording if no motion is detected during the 3 minutes.
Use the included pin to press the Function button ❷to pause
all recording and enter standby mode; indicated by solid Red.
Press it again to resume recording. The Red LED will turn off
and continue recording once motion isdetected.
Operation –2/2

Formatting the memory card
deletes all files and may fix
recording issues caused by
memory corruption.
Locateyour hard drive directory.
It will be under “MyComputer”
or “This PC”. You can also open a
new File Explorer window and
your drives will be listed there.
The camera will appear as a
removabledrive likethis.
Right Click on the removable drive and select Format
Formatting Memory on a PC/Windows - 1/2

From the options shown, make sure
thatyou have selected FAT32 or
asyour file system. Leave other
settings at their defaults.
ClickStart.
WARNING: Anyfilesonyourcard
willbelost including your time-
stamp settings. Record at least one
video with your camera to install the
file directory on your card. After you
have restored the directory you can re-
install thetime-stamp settings.
Formatting Memory on a PC/Windows - 2/2

Formatting the memory card
deletes all files and may fix
recording issues caused by
memory corruption.
Locate and open a program called
“Disk Utility”. It is usually found
by going into the application
folder and opening the utility
folder.
AppLocations >Utilities
Formatting Memory on a Mac/iOS –1/2

In Disk Utility, Select your camera removable drive from the list on the
left. From the options on the right click the menu button labeled
Erase (highlighted inblue below) From the dropdown menu labeled
Format, choose MS-DOS (FAT).
You can name the drive
whatever you’d like.
When ready, clickthe
button in the lower right
corner labeled Erase.
Recorda videoofany
length to reinstall the
file system onthe
memory card.
Formatting Memory on a Mac/iOS –2/2

Videos can be reviewed and copied to a hard drive by removing the micro SD
card from the camera and inserting it into a computer.
It will come up as a removable drive and all the files can be accessed by
opening the folder named "DCIM':
For playback we currently recommend a free program called VLC Player found
at www.videolan.org
Zetronix is NOT A FFIL IATED w ithw ww .videolan.org
Video Playback

1. Connect the battery to the battery connection ❹
2. Connect the included USB cable to the USB port ❽
3. Connect the other end of the USB cable to the USB wall
charger and plug in the charger to an A/C outlet.
A full charge may take anywhere from 1 to 6 hours. The LED
charge indicator light ❾will be on until fully charged.
Battery Charging

Sensor
Video Resolution
Compression Format
Video Format
Frame Rate
Camera Angle
Max Memory
2MegapixelCMOS
1920x1080
h.264
.MOV
30 FPS
90 Degrees
64GB
Device Specifications

Still Have Questions?
Do not return your camera
For additional assistance contact
Zetronix Tech Support
By Phone••••••••••••••••••••••••• 877-644-7592
By Email•••••••••••••••••[e-mail]
Live Chat at Zetronix.com
9AM-5PM EST Monday to Friday

Zetronix Corporation ("Zetronix") warrants this product against defects in material or
workmanship as follows: PRODUCT: Zetronix will repair this product with new or
refurbished parts, free of charge, for a period of one (1) year from the date of original
purchase in the event of a defect in materials or workmanship. REP AIRS: Zetronix will
repair or replace defective parts used in the repair or replacement of this product with
new or refurbished parts, free of charge, for a period equal to the remainder of the
original limited warranty period on the original product, or for 60 days after the date
of the repair or replacement, whichever is longer. This w arranty is extended only to
the original purchaser. Proof of purchase in the form of a bill of sale or receipted
invoice, which is evidence that the unit is within the warranty period, must be
presented to obtain warranty service. To obtain warranty service, you must take this
product, or deliver the product freight prepaid, in either its original packaging or
packaging affording an equal degree of protection, to Zetronix Corporation. See
below for additional information. This warranty only covers failures due to defects in
materials and workmanship, which occur during normal use.
The warranty does not cover damages, which occurred in shipment, cosmetic damage,
damage that is attributable to acts of God, failures which are caused by products not
supplied by the warrantor, or failures which result from accident, misuse, abuse,
neglect, mishandling, faulty installation, misapplication, improper installation,
operation or maintenance, alteration, modification, introduction of sand, humidity or
liquids, line power surge, improper voltage supply, lightning damage, or subjecting
the product to operating/environmental conditions in excess of the maximum values or

below the minimum values set forth in the applicable specifications, or products
serviced by anyone other than Zetronix. This warranty is invalid if the factory-applied
serial number has been altered or removed from the product. This warranty does not
cover products sold AS IS or WITH ALL FAULTS. This warranty excludes consumable
parts such as batteries and power supplies.
Zetronix Corporation ("Zetronix") warrants this product against defects in material or
workmanship as follows: PRODUCT: Zetronix will repair this product with new or
refurbished parts, free of charge, for a period of one (1) year from the date of original
purchase in the event of a defect in materials or workmanship. REPAIRS: Zetronix will
repair or replace defective parts used in the repair or replacement of this product with
new or refurbished parts, free of charge, for a period equal to the remainder of the
original limited warranty period on the original product, or for 60 days after the date
of the repair or replacement, whichever is longer. This warranty is extended only to the
original purchaser. Proof of purchase in the form of a bill of sale or receipted invoice,
which is evidenc e that the unit is within the warranty period,
must be presented to obtain warranty service. To obtain warranty service, you must
take this product, or deliver the product freight prepaid, in either its original packaging
or packaging affording an equal degree of protection, to Zetronix Corporation. See
below for additional information. This w arranty only covers failures due to defects in
materials and w orkmanship, which occur during normal use.

The warranty does not cover damages, which occurred in shipment, cosmetic
damage, damage that is attributable to acts of God, failures which are caused by
products not supplied by the warrantor, or failures which result from accident,
misuse, abuse, neglect, mishandling, faulty installation, misapplication, improper
installation, operation or maintenance, alteration, modification, introduction of
sand, humidity or liquids, line power surge, improper voltage supply, lightning
damage, or subjecting the product to operating/environmental conditions in excess
of the maximum values or below the minimum values set forth in the applicable
specifications, or products serviced by anyone other than Zetronix. This warranty is
invalid if the factory-applied serial number has been altered or removed from the
product. This warranty does not cover products sold AS ISor WITH ALLFAULTS. This
warranty excludes consumable parts such as batteries and power supplies.
