ZinWave UNITIVITY 5000 User manual

Software Version 5.16

UNItivity 5000 User Manual
Copyright © 2022 Zinwave. All rights reserved. i
© 2016-2022 Zinwave Ltd All Rights Reserved
Zinwave retains all ownership rights to all computer programs offered by Zinwave, their products, and
the contents of this manual. The source code for both software and firmware are confidential trade
secrets of Zinwave. You may not attempt to decipher, decompile, develop or otherwise reverse
engineer Zinwave software, firmware, or products. Information necessary to achieve interoperability is
furnished upon request.
This manual is furnished under license and may only be used or copied in accordance with the terms
of such license. The information in the manual is furnished for informational use only, is subject to
change without notice, and should not be construed as commitment by Zinwave. Zinwave assumes no
responsibility or liability for any errors or inaccuracies that may appear in this manual. No part of this
manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, recording, or otherwise, without the express written permission of Zinwave.
Existing artwork or images that you may desire to scan may be protected by copyright law. Be sure to
obtain permission for use of existing artwork.
Trademarks
This product carries the Trademark of Zinwave, Ltd. All the trademarks of component parts used by
Zinwave in the manufacture of this product are the property of their respective owners. The Zinwave
logo is a registered trademark of Zinwave
All brand or product names are trademarks or registered trademarks of their respective companies or
organizations.
Warranty
The material contained in this document is provided “as is,” and is subject to being changed, without
notice, in future editions. Further, to the maximum extent permitted by applicable law, Zinwave
disclaims all warranties, either express or implied, with regard to this manual and any information
contained herein, including but not limited to the implied warranties of merchantability and fitness for a
particular purpose. Zinwave shall not be liable for errors or for incidental or consequential damages in
connection with the furnishing, use, or performance of this document or of any information contained
herein. Should Zinwave and the user have a separate written agreement with warranty terms covering
the material in this document that conflict with these terms, the warranty terms in the separate
agreement shall control

Copyright © 2022 Zinwave. All rights reserved. ii
Table of Contents
Safety and Regulatory Information................................................... vii
Safety Information............................................................................................................................vii
RF Exposure......................................................................................................................vii
Installation..........................................................................................................................vii
Signal and Input Power .....................................................................................................vii
Fiber Considerations ........................................................................................................ viii
Optical Safety Precautions .................................................................................................ix
Software Installation ...........................................................................................................ix
Symbols...............................................................................................................................x
Regulatory Information.......................................................................................................................x
UL NRTL Listing .................................................................................................................xi
FCC ....................................................................................................................................xi
Innovation, Science and Economic Development Canada Compliance Statement........ xvi
CE Information.................................................................................................................. xvi
RoHS Information............................................................................................................xviii
UKCA Information............................................................................................................. xix
About this Manual.............................................................................. xx
Intended Audience...........................................................................................................................xx
Conventions xx
Getting Help xx
1System Overview..................................................................... 1-1
1.1 How Does It Work?................................................................................................... 1-1
1.2 Key Features............................................................................................................. 1-2
1.3 Network Topologies .................................................................................................. 1-2
1.3.1 Single-Star Configuration................................................................................. 1-2
1.3.2 Double Star Configuration ............................................................................... 1-3
1.3.3 Mixed Topology Configuration......................................................................... 1-3
1.3.4 Support for MIMO Services ............................................................................. 1-4
1.4 Understanding Optional Components....................................................................... 1-5
1.4.1 How the PSU Fits in......................................................................................... 1-5
1.4.2 How the Active POI Fits in............................................................................... 1-6
2Understanding the Components ............................................2-1
2.1 Hubs.......................................................................................................................... 2-2
2.1.1 Configuration GUI ............................................................................................ 2-2
2.1.2 Primary Hub..................................................................................................... 2-2

Copyright © 2022 Zinwave. All rights reserved. iii
2.1.3 Secondary Hub ................................................................................................ 2-4
2.2 Service Module ......................................................................................................... 2-5
2.3 Optical Module.......................................................................................................... 2-6
2.4 Transport Module...................................................................................................... 2-7
2.5 Remote Unit .............................................................................................................. 2-8
2.5.1 Antennas.......................................................................................................... 2-9
2.6 Fiber Patch Cords..................................................................................................... 2-9
3Hub and Module LEDs........................................................... 3-10
3.1 Primary Hub Front Panel LEDs............................................................................... 3-10
3.2 Secondary Hub Status LEDs................................................................................... 3-10
3.2.1 Optical Link to Primary Hub........................................................................... 3-10
3.2.2 Optical Links to 8x Remote Units................................................................... 3-11
3.3 Service, Optical and Transport Module LEDs......................................................... 3-11
3.3.1 Power LED—Right......................................................................................... 3-12
3.3.2 Communications—Middle.............................................................................. 3-12
3.3.3 Status—Left ................................................................................................... 3-12
3.4 Start-up Sequence.................................................................................................. 3-13
3.4.1 Service Module .............................................................................................. 3-13
3.4.2 Optical Module............................................................................................... 3-13
3.4.3 Transport Module........................................................................................... 3-14
3.5 Remote Unit LEDs .................................................................................................. 3-15
4Performing a Basic Installation ..............................................4-2
5Installing and Populating Hubs .............................................. 5-1
5.1 Installing the Hub ...................................................................................................... 5-1
5.1.1 Mounting Kit..................................................................................................... 5-1
5.1.2 Standard 19" (48.26cm) Rack Mounting.......................................................... 5-2
5.1.3 Open Frame Rack Mounting............................................................................ 5-2
5.1.4 Installing Blank Panels..................................................................................... 5-3
5.2 Installing Secondary Hub.......................................................................................... 5-4
5.3 Installing Service Modules in Primary Hub ............................................................... 5-6
5.4 Installing Optical Modules in Primary Hub................................................................ 5-7
5.5 Powering the Primary Hub........................................................................................ 5-7
5.6 Powering the Secondary Hub ................................................................................... 5-8
6Installing Remote Units........................................................... 6-1
6.1 Mounting Remote Units ............................................................................................ 6-1
6.1.1 Considerations before Mounting...................................................................... 6-1
6.2 Powering Remote Units ............................................................................................ 6-4
6.2.1 PSU DC Power................................................................................................ 6-4

Copyright © 2022 Zinwave. All rights reserved. iv
7DAS Installation Considerations ............................................7-1
7.1 Antenna Requirements ............................................................................................. 7-1
7.1.1 Isolation............................................................................................................ 7-1
7.1.2 Isolation Measurement Techniques................................................................. 7-1
7.2 Uplink/Downlink Balance .......................................................................................... 7-2
7.3 Connecting Antennas to Remote Units..................................................................... 7-2
7.4 Connecting the PSU or Secondary Hub Power Port to Remote Units ..................... 7-2
7.4.1 Power Distribution Requirements..................................................................... 7-2
7.4.2 Understanding Connectors & Cabling ............................................................. 7-3
7.5 Uplink System Noise................................................................................................. 7-4
7.5.1 Introduction ...................................................................................................... 7-4
7.5.2 Optimising SNR and Noise Level .................................................................... 7-4
7.5.3 UniTransport .................................................................................................... 7-6
8Performing Basic Configuration............................................. 8-7
9Understanding the Configuration GUI.................................... 9-2
9.1 Supported Browsers.................................................................................................. 9-2
9.2 Initial Standalone Access.......................................................................................... 9-2
9.3 Accessing the GUI .................................................................................................... 9-4
9.4 Understanding the Main Window.............................................................................. 9-6
9.4.1 Address Bar ..................................................................................................... 9-6
9.4.2 Login Bar.......................................................................................................... 9-6
9.4.3 Help Button ...................................................................................................... 9-6
9.4.4 Display Area..................................................................................................... 9-7
9.4.5 Progress Indicator............................................................................................ 9-7
9.4.6 Changing User Passwords and Timeouts ....................................................... 9-8
10 Initial System Setup............................................................... 10-1
10.1 Connection to DAS System .................................................................................... 10-1
10.2 Software Upgrade................................................................................................... 10-1
10.2.1 Full System Software Upgrade...................................................................... 10-1
10.2.2 To update RU and SH Firmware from an Installed Primary Hub Software
Release: 10-3
10.3 System Setup.......................................................................................................... 10-3
10.3.1 Import Coverage Tool setting ........................................................................ 10-3
10.3.2 Primary Hub Configuration ............................................................................ 10-3
10.3.3 Service Module Downlink AGC...................................................................... 10-4
10.3.4 Transport Module AGC.................................................................................. 10-4
10.3.5 Rack-Mount Power Supply Unit Configuration .............................................. 10-5
10.3.6 Secondary Hub Configuration and Controls.................................................. 10-5
10.3.7 Remote Unit Configuration ............................................................................ 10-5
10.4 System Status......................................................................................................... 10-7

Copyright © 2022 Zinwave. All rights reserved. v
10.4.1 System Status Topology Tree and Modules.................................................. 10-7
10.4.2 Unit and Module Details................................................................................. 10-7
10.5 Event Log................................................................................................................ 10-7
10.6 Hub Setup............................................................................................................... 10-8
10.6.1 Restart Hub.................................................................................................... 10-8
10.6.2 IP Settings...................................................................................................... 10-8
10.6.3 SNMP Settings............................................................................................... 10-8
10.6.4 User Interface Settings .................................................................................. 10-9
10.6.5 Date & Time................................................................................................... 10-9
10.6.6 Security Settings............................................................................................ 10-9
10.7 Alarms Setup......................................................................................................... 10-10
10.8 System Maintenance............................................................................................. 10-10
10.9 System Views........................................................................................................ 10-11
10.9.1 System Snapshot......................................................................................... 10-11
10.9.2 Alarm Counts ............................................................................................... 10-11
10.9.3 Link Quality .................................................................................................. 10-12
10.9.4 RU DC Power .............................................................................................. 10-12
10.9.5 RU Calculations ........................................................................................... 10-12
10.9.6 RF System Check........................................................................................ 10-12
11 Additional System Setup..................................................... 11-14
11.1 System Uplink/Downlink Balance ......................................................................... 11-14
11.2 Calculated Input Level .......................................................................................... 11-14
11.3 Changing or Swapping Equipment ....................................................................... 11-14
11.3.1 Hub............................................................................................................... 11-15
11.3.2 Remote Unit................................................................................................. 11-15
11.3.3 Optical Module............................................................................................. 11-15
11.4 Factory Reset of a Primary Hub............................................................................ 11-15
12 UniTransport System Setup................................................ 12-17
12.1 UniTransport Functionality.................................................................................... 12-17
12.2 Configuration of UniTransport Hub ....................................................................... 12-18
12.3 Configuration of Downstream Primary Hub .......................................................... 12-19
12.4 Remote Configuration of UniTransport Hub ......................................................... 12-20
13 Understanding Alarms & Reporting................................... 13-22
13.1 Alarms................................................................................................................... 13-22
13.1.1 Loss of Service ............................................................................................ 13-22
13.1.2 Service Warning........................................................................................... 13-23
13.1.3 Hardware Warning....................................................................................... 13-25
13.1.4 Informational ................................................................................................ 13-27
13.2 Alarms Setup......................................................................................................... 13-28
13.3 Alarm Connections................................................................................................ 13-28

Copyright © 2022 Zinwave. All rights reserved. vi
13.4 SNMP.................................................................................................................... 13-29
13.4.1 SNMP V3 Manager Configuration ............................................................... 13-29
13.4.2 SNMP Trap Events...................................................................................... 13-30
13.4.3 SNMP Get Objects....................................................................................... 13-30
13.4.4 3000 SNMP Traps ....................................................................................... 13-31
13.4.5 Additional 5000 SNMP Objects ................................................................... 13-31
14 Performing Diagnostics and Testing.................................... 14-1
14.1 Diagnosing Optical Links with an OTDR................................................................. 14-1
14.1.1 Diagnose an Optical Link............................................................................... 14-1
14.2 LED Testing ............................................................................................................ 14-2
14.2.1 Modules ......................................................................................................... 14-2
14.2.2 Remote Unit LED Test................................................................................... 14-3
14.3 Event Log................................................................................................................ 14-4
14.3.1 Viewing and saving the Event Log................................................................. 14-4
14.3.2 System Logging............................................................................................. 14-4
14.4 Downloading Event Log.......................................................................................... 14-4
14.5 System Log ............................................................................................................. 14-4
15 Specifications ........................................................................ 15-1

Copyright © 2022 Zinwave. All rights reserved. vii
Safety and Regulatory Information
Safety Information
The following safety warnings and cautions are listed to prevent damage to equipment or property and
prevent any risk of personal injury.
RF Exposure
Warning: This equipment complies with European, FCC and Canadian radiation exposure limits
set forth for an occupational/ controlled environment. The Remote Unit should be operated with
a minimum distance of 20cm (8 in) between antenna and your body
Installation
Caution: Incorrect installation, operation, and use of this equipment may causefailure to
product and could cause accidents which may harm personnel.
Caution: Optical Module must ONLY be installed on the front panel of a Primary Hub or the unit
will not function as expected.
Warning: The Remote Unit should be installed in Restricted Access Locations only
where the maximum ambient operating temperature is 50degC. If the Remote Unit is
installed in an Operator Access Area, then the maximum ambient operating
temperature must be de-rated to 45degC.
Warning: This is NOT a CONSUMER device. It is designed for installation by an
installer approved by an ISED licensee (Innovation, Science and Economic
Development Canada). You MUST have an ISED LICENCE or the express consent of
an ISED licensee to operate this device.
Signal and Input Power
Warning: If the service module is connected directly to the output of a BTS or any RF
input source, maximum power delivered to a service module must not exceed 15dBm
(damage level is 22dBm). Use additional equipment to attenuate the power.
Caution: The input power to the Zinwave Remote Unit should not exceed -10dBm. Power
levels greater than +10dBm will damage the unit
Caution: The total broadband composite output power of the 305-0007 Remote Unit is
limited to +18 dBm in Europe and +20 dBm in the USA and Canada.
The maximum allowed composite EIRP inthe USA & Canada is +28 dBm which
corresponds to an antenna gain of 8 dBi except for the following bands where restrictions
apply:
•Maximum radiated power in the 653 to 663 MHz band is +13dBm (20mW) EIRP
•Maximum antenna port power in the 2345 –2360 MHz band is 16 dBm
Contact Zinwave for the maximum output power in other regions.
Caution: The total broadband composite output power of the 306-0007 Remote Unit is
limited to +22 dBm in Europe.
Contact Zinwave for the maximum output power in other regions.

Copyright © 2022 Zinwave. All rights reserved. viii
Caution: Alarm Relays on the Hubs and Remote Unit are intended for low voltage/current
signaling only. Maximum operating voltage 50V, maximum operating current 1A.
CAUTION :
DOUBLE POLE/NEUTRAL FUSING
The Power Supply Module in the Secondary Hub 305-0004 and 306-0004 has
multiple sources and may include a fuse in the Neutral AC connection. After
operation of the fuse, parts of the equipment that remain energized might represent
a hazard during servicing.
Fiber Considerations
Caution: Avoid dust ingress to fiber connectors by mounting the Remote Unit with the fiber
connector facing downwards, or by leaving the dust-caps in place until the fiberis connected.
Caution: Connector types must match (i.e. SC-APC to SC-APC). Otherwise, there will be an
air gap between the connector faces that will create highback reflection and high optical loss.
Caution: Zinwave hardware ONLY supports SINGLE Mode Fiber.
Caution: Fiber handling procedures should be carefully observed so as not to damage or
introduce dirt to fiber interfaces during installation.
Caution: Observe safety precautions when working with fiber cables and devices.

Copyright © 2022 Zinwave. All rights reserved. ix
Optical Safety Precautions
Warning: Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
Caution: Do not remove the fiber Port dust covers unless the port is in use. Donot stare
directly into a fiber Port.
Caution: Cover any unconnected fiber ends with an approved cap.
Caution: Do not stare with unprotected eyes at any broken ends of the fiber.
Caution: Use only approved methods for cleaning optical fiber connectors.
Caution: Do not make any unauthorized modifications to this fiber optical system.
Caution: No warning signs are required as it is a Class 1 hazard.
Caution: Use Class 1 test equipment.
Software Installation
Caution: When new firmware is being installed it is very important not to break or interrupt
the connection between source file and the Hub. Interrupting firmware installation may put
the Hub into an irrecoverable state that requires factory reset.
Caution: While the system can be configured with poor optical links present, this may affect
the system performance and such links should be examined and brought into specification
in order to obtain optimum performance.

Copyright © 2022 Zinwave. All rights reserved. x
Symbols
This section identifies the symbols that are displayed on UNItivity devices. Labels or symbols may not
appear on every device.
Symbol
Description
Consult Manual
Electric shock hazard
UL certified UL NRTL Listing
The European CE mark
The UKCA (UK Conformity Assessed) marking is a new UK product marking that is used for
goods being placed on the market in Great Britain (England, Wales and Scotland). It covers
most goods which previously required the CE marking.
ISO 9001 Certified
USB Port
Ethernet Port
Electrostatic Discharge Sensitive
This symbol indicates that the waste of electrical and electronic equipment must not be
disposed as unsorted municipal waste and must be collected separately. Please contact an
authorized representative of the manufacturer for information concerning the
decommissioning of your equipment.
Regulatory Information
•EN 50174/50173 series: Information technology –Cabling installation
•ANSI/TIA/EIA-568 series North America Cabling
•ISO/IEC 11801 - International cabling
•IEC 60825-2: Safety of laser products –Part 2: Safety of optical fiber communication systems
(OFCS)
•This equipment complies with 21CFR1040 - Performance Standards For Light-Emitting
Products (FDA).
•EN 55032/CISPR32
•FCC Part 15 Class A
•European Radio Equipment Directive 2014/53/EU
•Electrical Safety IEC 60950-1
•Laser Safety EN 60825-1:2007 (305-0XXX units) and EN 60825-1:2014 (306-XXXX units and
305-1007 units)
•ISO 9001

Copyright © 2022 Zinwave. All rights reserved. xi
•UL-60950-1
•RoHS DIRECTIVE 2011/65/EU
•UL2043 compliance
In reference to UL2043 compliance, Remote Units are suitable for use in environmental air space in
accordance with Section 300-22(c) of the National Electrical Code, and Sections 2-128, 12-010(3) and
12-100 of the Canadian Electrical Code, Part 1, CSA C22.1.
Note: The system contains a device which is classified as a “CLASS I LASER PRODUCT”, with an
internal Class 1 laser source (as defined in CBTR # DE3-500286 by TUV). The component within the
unit is in compliance with “U.S. Code of Federal Regulations, 21 CFR 1040”. See the Detailed Data
Sheet for label placement.
UL NRTL Listing
UNItivity has been tested and shown to meet UL and CSA requirements through testing carried
out at a Nationally Recognized Testing Laboratory (NRTL). The UL certification Mark indicates
national compliance to UL and CSA standards by virtue of accreditations obtained.
Product: Distributed Antenna System
Model: UNItivity 5000 Primary Hub 305-0001, Secondary Hub 305-0004 and Remote Unit 305-0007
UL Listing ID: E486578
FCC
FCC Compliance and Interference Statements
Hub: UNItivity devices comply with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
1) This device must accept any interference and
2) This device must accept any interference received including interference that may cause
undesired operation
Changes or modifications not expressly approved by Zinwave Ltd. could void the user’s authority to
operate the equipment.
305-0007 Remote Unit: This device complies with Part 22, Part 24, Part 27, Part 74 and Part 90 of the
FCC rules. Changes or modifications not expressly approved by Zinwave Ltd. could void the user’s
authority to operate the equipment. For a list of services, please contact Zinwave.
•This device must only be used with antennas having a maximum gain of 8 dBi
•When operating on channel or channels under 47CFR part 90 as identified in the table below,
this is a
Class B booster as defined in 47CFR90.219.
Class B boosters must be registered with the FCC prior to operation, which can be done at the
FCC Part 90 Class B Signal Booster Registration & Discovery website:
https://signalboosters.fcc.gov/signal-boosters/

Copyright © 2022 Zinwave. All rights reserved. xii
Warning: This is NOT a CONSUMER device. It is designed for installation by FCC
LICENSEES and QUALIFIED INSTALLERS. You MUST have an FCC LICENSE or express
consent of an FCC Licensee to operate this device. YouMUST register Class B signal boosters
(as defined in 47 CFR 90.219) online at www.fcc.gov/signal-boosters/registration.
Unauthorized use may result in significant forfeiture penalties, including penalties in excess of
$100,000 for each continuing violation.
When operating on a channel or channels under 47CFR parts 22, 24, 27 or 74 as identified in the
following table, the 305-0007 Remote Unit is an Industrial Booster as per 47CFR part 20.
Remote Unit 305-0007 with FCC ID: FCC ID UPO305-0007 only supports services in the following
bands of operation:
Rule Downlink Frequency
Part Band Range (MHz) Service Modulation
90
VHF Public Safety
150.8 –156.2475
157.1875 –161.575
161.775 –161.9625
162.0325 –173.4
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
UHF Public Safety
406.1 - 420
421 - 430
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
FM
FM ±5.0kHz dev'n
456.0 –462.5375
462.7375 - 467.5375
467.7375 - 512.0
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
FM
FM ±5.0kHz dev'n
74
UHF PMSE
470 –608
614 –679.9
FM
FM ±75kHz dev'n
90
700MHz Public Safety
769 –775
P25
C4FM (QPSK)
OpenSky
4-level GFSK
Band 14
758-768
LTE
64 QAM
27
700MHz LTE
698 - 758
LTE
64 QAM
90
800MHz Public Safety
851 –854, 854- 861
862 - 869
P25
C4FM (QPSK)
OpenSky
4-level GFSK
800MHz SMR
851 –854, 854- 861
862 - 869
FM & EDACS
FM ±5.0kHz dev'n
900MHz ESMR
935 - 940
LTE
64-QAM
800MHz ESMR
854 –861
862 - 869
EVDO
(QPSK+QAM)
QPSK + QAM
FD-LTE
QPSK + QAM

Copyright © 2022 Zinwave. All rights reserved. xiii
Rule Downlink Frequency
Part Band Range (MHz) Service Modulation
22
Cellular
869 - 894
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
CDMA
QPSK
CDMA2000 Ev-DO
8PSK, 16-QAM
929 Paging
929 - 930
FSK
FSK
931 Paging
931 - 932
FSK
FSK
24
PCS
1930 - 1995
GSM
GMSK
EDGE
8-PSK
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
FDD LTE (band
2/25)
QPSK + QAM
CDMA
QPSK
CDMA2000 Ev-DO
8PSK, 16-QAM
27
AWS
2110 - 2180
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
FD-LTE (band 4)
16-QAM/64-QAM
FD-LTE (band 10)
16-QAM/64-QAM
AWS-4
2180 –2200
FD-LTE
16-QAM/64-QAM
WCS
2345 - 2360
FD-LTE
16-QAM/64-QAM
BRS/EBS
2496 –2690
LTE
16-QAM/64-QAM

Copyright © 2022 Zinwave. All rights reserved. xiv
When operating on a channel or channels under 47CFR parts 22, 24, 27 or 74 as identified in the
following table, the 305-1007 Remote Unit is an Industrial Booster as per 47CFR part 20.
Remote Unit 305-1007 with FCC ID: FCC ID:UPO305-1007 only supports services in the following
bands of operation:
Rule Downlink Frequency
Part Band Range (MHz) Service Modulation
90
VHF Public Safety
150.8 –156.2475
157.1875 –161.575
161.775 –161.9625
162.0325 –173.4
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
UHF Public Safety
406.1 - 420
421 - 430
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
FM
FM ±5.0kHz dev'n
456.0 –462.5375
462.7375 - 467.5375
467.7375 - 512.0
P25
C4FM (QPSK)
FM
FM ±2.5kHz dev'n
FM
FM ±5.0kHz dev'n
74
UHF PMSE
470 –608
614 –679.9
FM
FM ±75kHz dev'n
27
Digital Dividend
617 - 652
FD-LTE (band 71)
16-QAM/64-QAM
90
700MHz Public Safety
769 –775
P25
C4FM (QPSK)
OpenSky
4-level GFSK
Band 14
758-768
LTE
64 QAM
27
700MHz LTE
698 - 758
LTE
64 QAM
90
800MHz Public Safety
851 –854, 854- 861
862 - 869
P25
C4FM (QPSK)
OpenSky
4-level GFSK
800MHz SMR
851 –854, 854- 861
862 - 869
FM & EDACS
FM ±5.0kHz dev'n
900MHz ESMR
935 - 940
LTE
64-QAM
800MHz ESMR
854 –861
862 - 869
EVDO
(QPSK+QAM)
QPSK + QAM
FD-LTE
QPSK + QAM
22
Cellular
869 - 894
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
CDMA
QPSK

Copyright © 2022 Zinwave. All rights reserved. xv
Rule Downlink Frequency
Part Band Range (MHz) Service Modulation
CDMA2000 Ev-DO
8PSK, 16-QAM
929 Paging
929 - 930
FSK
FSK
931 Paging
931 - 932
FSK
FSK
24
PCS
1930 - 1995
GSM
GMSK
EDGE
8-PSK
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
FDD LTE (band
2/25)
QPSK + QAM
CDMA
QPSK
CDMA2000 Ev-DO
8PSK, 16-QAM
27
AWS
2110 - 2180
UMTS
QPSK
HSPA/HSPA+
16-QAM/64-QAM
FD-LTE (band 4)
16-QAM/64-QAM
FD-LTE (band 10)
16-QAM/64-QAM
AWS-4
2180 –2200
FD-LTE
16-QAM/64-QAM
WCS
2345 - 2360
FD-LTE
16-QAM/64-QAM
BRS/EBS
2496 –2690
LTE
16-QAM/64-QAM
Approvals for Remote Unit 306-0007 are in progress at the time of writing. Contact Zinwave for current
information.
FCC Cautionary Note
Any changes or modifications in construction of this equipment which are not expressly approved by
the party responsible for compliance could void the user's authority to operate the equipment.
FCC Verification: Primary and Secondary Hub
These devices comply with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, (2) this device must accept any
interference received, including interference that may cause undesired operation.
This is a Class A Digital Device
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against

Copyright © 2022 Zinwave. All rights reserved. xvi
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Note: This is Class A product (as defined in European Norm (EN) 55032). In a domestic environment
this product may cause radio interference.
Innovation, Science and Economic Development
Canada Compliance Statement
The nominal passband gain of 305-0XXX system is 25 dB and the 20dB bandwidth is 125 MHz to 3.14
GHz. The input and output impedances are 50 ohms and the RSS-131 rated mean output power PRATED
is:
•+15 dBm in 150-174 MHz band
•+19 dBm in the 406.1 –430 and 456 –470 MHz bands
•+20 dBm in all other bands
The system must be configured with maximum transmit power of +16 dBm in the 2345-2360 MHz band.
The nominal passband gain of 305-XXXX system through a 305-1007 Remote Unit is 29 dB and the
24dB bandwidth is 125 MHz to 3.14 GHz. The input and output impedances are 50 ohms and the RSS-
131 rated mean output power PRATED is:
•+15 dBm in 150-174 MHz band
•+19 dBm in the 406.1 –430 and 456 –470 MHz bands
•+20 dBm in all other bands below 1575 MHz
•+24 dBm in all other bands above 1575 MHz
The system must be configured with maximum transmit power of +16 dBm in the 2345-2360 MHz
The nominal passband gain of 306-XXXX system is 29 dB and the 24dB bandwidth is 3150 MHz to
4350 MHz. The input and output impedances are 50 ohms and the RSS-131 rated mean output power
PRATED is:
•+24 dBm in 3300 - 4200 MHz band
The Manufacturer's rated output power of this equipment is for single carrier operation. For situations
when multiple carrier signals are present, the rating would have to be reduced by 3.5 dB, especially
where the output signal is re-radiated and can cause interference to adjacent band users. This power
reduction is to be by means of input power or gain reduction and not by an attenuator at the output of
the device.
CE Information
UNItivity complies with the essential requirements of the Radio Equipment Directive
(2014/53/EU) and is therefore ‘CE’ marked when it is used in accordance with the instructions
provided in this Manual.
CE Declaration of Conformity
This equipment has been tested and found to comply with the limits set out by the Directive 2014/53/

Copyright © 2022 Zinwave. All rights reserved. xvii
EU.
Hereby, Zinwave Ltd declares that this Distributed Antenna System is in compliance with the essential requirements and other
relevant provisions of Directive 2014/53/EU.
Zinwave Ltd, vakuuttaa täten että Distributed Antenna System tyyppinen laite on direktiivin 12014/53/ EU oleellisten
vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen.
Hierbij verklaart Zinwave Ltd, dat het toestel Distributed Antenna System in overeenstemming is met de essentiële eisen en de
andere relevante bepalingen van richtlijn 2014/53/EU
Bij deze verklaart Zinwave Ltd, dat deze Distributed Antenna System voldoet aan de essentiële ‘le eisen en aan de overige
relevante bepalingen van Richtlijn 2014/53/EU.
Par la présente, Zinwave Ltd, déclare que ce Distributed Antenna System est conforme aux exigences essentielles et aux
autres dispositions de la directive 2014/53/UE qui lui sont applicables
Härmed intygar Zinwave Ltd, att denna Distributed Antenna System står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 2014/53/EU.
Undertegnede Zinwave Ltd, erklærer herved, at følgende udstyr Distributed Antenna System overholder de væsentlige krav og
øvrige relevante krav i direktiv 2014/53/EU
Hiermit erklärt Zinwave Ltd., dass sich dieser Distributed Antenna System in Übereinstimmung mit den grundlegenden
Anforderungen und den anderen relevanten Vorschriften der Richtlinie 2014/53/EU befindet
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Zinwave Ltd, ∆ΗΛΩΝΕΙ ΟΤΙ Distributed Antenna System ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩ∆ΕΙΣ
ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ∆ΙΑΤΑΞΕΙΣ ΤΗΣ Ο∆ΗΓΙΑΣ 2014/53/ EE
Con la presente Zinwave Ltd, dichiara che questo Distributed Antenna System è conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva 2014/53/EU.
Por medio de la presente Zinwave Ltd, declara que el Distributed Antenna System cumple con los requisitos esenciales y
cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/ UE
Zinwave Ltd, declara que este Distributed Antenna System está conforme com os requisitos essenciais e outras disposições
da Directiva 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
https://www.zinwave.com/regulatory-and-compliance
The 305-0XXX system complies with the Radio Equipment Directive, 2014/53/EU for operation in the
following bands with maximum antenna port power of +18dBm. When the system includes a 305-1007
Remote Unit, that path is similarly certified with a maximum antenna port power of +23dBm for Downlink
bands above 1575 MHz.
Band
Downlink Frequency
(MHz)
Uplink Frequency
(MHz)
Service
N/A
390 - 470
380 - 460
TETRA
20
791 –821
832 –862
E-UTRA (FDD)
8
925 - 960
880 - 815
E-GSM (FDD)
UMTS (FDD)
E-UTRA (FDD)
3
1805 - 1880
1710 - 1785
DCS 1800 (FDD)
UMTS (FDD)
E-UTRA (FDD)
2110 - 2170
1920 - 1980
UMTS (FDD)

Copyright © 2022 Zinwave. All rights reserved. xviii
1
E-UTRA (FDD)
40
2300-2400
2300-2400
E-UTRA (TDD)
7
2620 –2690
2500 –2570
E-UTRA (FDD)
38
2570 - 2620
2570 - 2620
E-UTRA (TDD)
The 306-XXXX system complies with the Radio Equipment Directive, 2014/53/EU for operation in the
following bands with maximum antenna port power of +22dBm:
Band
Downlink
Frequency (MHz)
Uplink Frequency
(MHz)
Service
N77
3300 –4200 [1]
3300 - 4200
5G / NR
N78
3400 - 3800
3400 - 3800
5G / NR
LTE 22
3510 –3590
3410 –3490
E-UTRA (FDD)
LTE 42
3400 - 3600
3400 - 3600
E-UTRA (TDD)
LTE 43
3600 - 3800
3600 - 3800
E-UTRA (TDD)
Note [1] : Approvals testing performed on 10 May 2021 covered 3400 –3800 MHz, but current hardware is
designed to meet 3300 –4200 MHz. Further certification is ongoing.
Compliance with national licensing requirements and COMMISSION IMPLEMENTING DECISION (EU)
2019/235.
Operation is subject to the following limits
•3410 MHz < F < 3800MHz: EIRP < -34dBm/5MHz = (-41dBm/1MHz
•F < 3390 MHz: EIRP < -50dBm/MHz
When a single channel is transmitting at 22 dBm, the maximum in-band “antenna gain + cable loss” is 4.5
dBi
The out of band noise floor below 3390 MHz is typically:
•-53.7 dBm for 22 dBm total output power
•-56.3 dBm for 17 dBm total output power
The operator is responsible for operating the system in accordance with national licensing requirements.
RoHS Information
This equipment fully complies with the requirements set out in the RoHS standard, Directive 2011/
65/EU.

Copyright © 2022 Zinwave. All rights reserved. xix
UKCA Information
UNItivity complies with the essential requirements of the Radio Equipment Regulations
2017 and is therefore ‘UKCA’ marked when it is used in accordance with the instructions
provided in this Manual.
UKCA Declaration of Conformity
This equipment has been tested and found to comply with the limits set out by the Radio Equipment
Regulations 2017. Further information is available from Zinwave on request.
